Philips MAT960A1 User Manual

Owner’s Manual

Important!

Return your Warranty Registration

Card within 10 days. See why inside.

Internet Terminal

MAT960

Once your PHILIPS MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning
a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your
purchase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to ensure you

receive all the

benefits

you’re entitled to.

Congratulations

on your

purchase,

and welcome to the

“family!”

Dear PHILIPS MAGNAVOX product owner:

Thank you for your confidence in PHILIPS MAGNAVOX. You’ve selected one of the best-built, best-backed products
available today. And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the PHILIPS MAGNAVOX “family,” you’re entitled to protection by one of the most comprehensive war­ranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy
access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome–and thanks for investing in a PHILIPS MAGNAVOX product.
Sincerely,

Robert Minkhorst
President and Chief Executive Officer

For Customer Use

Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future refer­ence.

Model No. ____________________________________ Serial No. ______________________________________________

Know these

safetysymbols

t This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical

shock. For the safety of everyone in your household, please do not remove product covering.

s The “exclamation point” calls attention to features for which you should read the enclosed

literature closely to prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty
Verification

Registering your product within
10 days confirms your right to maxi­mum protection under the
terms and conditions of your
PHILIPS MAGNAVOX warranty.

Owner
Confirmation

Your completed Warranty Registra­tion Card serves as verification of
ownership in the event of product
theft or loss.

Model
Registration

Returning your Warranty
Registration Card right away guaran­tees you’ll receive all the informa­tion and special offers which you
qualify for as the owner of your
model.

P.S. Remember, to get the most from your

PHILIPS MAGNAVOX product, you must
return your Warranty Registration Card within
10 days. So please mail it to us right now!

R

E

G

I

S

T

R

A

T

I

O

N

N

E

E

D

E

D

W

I

T

H

I

N

1

0

D

A

Y

S

Hurry!

Visit our World Wide Web Site at http://www.philipsmagnavox.com

This product was designed and manufactured to meet strict quality and safety standards. There are, how-

ever, some installation and operation precautions which you should be particularly aware of.

1. Read Instructions - All the safety and operating instructions should be read and understood before
the appliance is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered

to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub,

washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a cart or stand that is recommended by
the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as
recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with
its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or sim­ilar surface that may block the ventilation openings; or, placed in a built-in installation, such as a book­case or cabinet that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.

10. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords and
plugs, convenience receptacles, and the point where they exit from the appliance.

11. Non-use Periods - The power cord of the appliance should be unplugged from the outlet when left
unused for a long period of time.

12. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled
into the enclosure through openings.

13. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a marked change in performance;

or

E. The appliance has been dropped, or the enclosure damaged.

14. Servicing - The user should not attempt to service the appliance beyond that described in the oper-

ating instructions. All other servicing should be referred to qualified service personnel.

This symbol is to alert you to important operating or servicing instructions that may appear in
your owner’s manual. When using your telephone equipment, always follow these basic safety
precautions in order to reduce the risk of fire, electric shock, and injury to persons.

15. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol clean­ers; use a damp cloth for cleaning. If the product comes in contact with any liquid, unplug the phone
line and the power adapter and let the unit dry thoroughly before plugging it back in.

16. This product should be operated only from the type of power source indicated on the marking label
or in the owner’s manual. If you are not sure of the type of power supply to your home, consult your
dealer or local power company.

3

Safety Information

READ BEFORE OPERATING EQUIPMENT

SAVE THESE INSTRUCTIONS

4
Safety Information (cont’d)

17. Do not overload wall outlets and extension cords, as this can result in the risk of fire or electric
shock.

18. Never push objects of any kind into this product through cabinet slots, as they may touch dangerous
voltage points or short out parts, resulting in the risk of fire or electric shock. Never spill liquid of
any kind on the product.

19. To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified ser­viceman when service or repair work is required. Opening or removing covers may expose you to
dangerous voltage or other risks. Incorrect reassembly can cause electric shock when this product
is subsequently used.

20. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the
following conditions: a) when the power supply cord or plug is damaged or frayed; b) if liquid has
spilled into the product; c) if the product has been exposed to rain or water; d) if the product does
not operate normally when you follow the operating instructions (adjust only those controls that are
discussed in the owner’s manual, as improper adjustment of other controls may result in damage,
often requiring extensive work by a qualified technician to restore the product to normal perfor­mance); e) if the product has been dropped or the cabinet has been damaged; f) if the product
exhibits a distinct change in performance.

21. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.

22. Do not use a telephone in the vicinity of a gas leak. If you suspect a gas leak, report it immediately,
but use a telephone away from the area where gas is leaking. With a cordless phone, also make sure
that the phone base is away from the gas leak.

23. Grounding or Polarization - This product may be equipped with a polarized alternating current line
plug (a plug having one blade wider than the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug still fails to fit, contact your electrician to replace the obsolete outlet.
Do not defeat the safety purpose of the grounding-type plug.

The Canadian Department of Communications label identifies certified equipment. This certification

means that the equipment meets certain telecommunications network protective, operational, and
safety requirements. The department does not guarantee the equipment will operate to the user’s
satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facili-

ties of the local telecommunications company. The equipment must be installed using an acceptable
method of connection. In some cases, the company’s inside wiring associated with a single line indi­vidual service may be extended by means of a certified connector assembly (telephone extension
cord). The customer should be aware that compliance with the above condition may not prevent
degradation of service in some situations.

Repairs to some certified equipment should be made by an authorized maintenance facility designated

by the supplier. Any repairs or alterations made by the user to this equipment, or any equipment
malfunctions, may give the telecommunications company cause to request the user to disconnect
the equipment.

Users should ensure for their own protection that the ground connections of the power utility, tele-

phone lines, and internal metallic water pipe system are connected together. This precaution may
be important particularly in rural areas.

CAUTION: Users should not attempt to make such connections themselves but should contact the

appropriate electrical inspection authority or electrician as appropriate.

The RINGER EQUIVALENCE NUMBER (REN) assigned to each terminal device denotes the percent-

age of the total load to be connected to a telephone loop which is used by the device to prevent
overloading. The termination on a loop may consist of any combination of devices subject only to
the requirement that the total of the REN of all devices does not exceed five.

The REN for the MAT960 is 0.9B.

5

Canadian Ringer Equivalence Number Notice

Federal Communications Commission (FCC) Statement
The Philips Magnavox MAT960 has been tested and found to comply with the limits for a Class B digi-

tal device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two condi­tions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

The FCC Class B limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a partic­ular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult your point of purchase or service representative for additional suggestions.

The manufacturer is not responsible for any radio or television interference caused by the use of

cables other than those recommended or by unauthorized changes or modifications to this equip­ment. Unauthorized changes or modifications could void the user’s authority to operate this equip­ment.

6
Federal Communications Commission Information

This equipment complies with Part 68 of the FCC rules. On the bottom of this equipment is a label

that contains, among other information, the FCC Registration Number and Ringer Equivalence
Number (REN) for this equipment. You must, upon request, provide this information to your tele­phone company. The REN is useful to determine the quantity of devices you may connect to your
telephone line and still have all of those devices ring when your telephone number is called. In
most, but not all areas, the sum of the RENs of all devices connected to one line should not
exceed five. To be certain of the number of devices you may connect to your line as determined
by the REN, you should contact your local telephone company to determine the maximum REN
for your calling area.

If your telephone equipment causes harm to the telephone network, the telephone company may dis-

continue your service temporarily. If possible, they will notify you in advance. But, if advance notice
is not practical, you will be notified as soon as possible. You will be informed of your right to file a
complaint with the FCC.

Your telephone company may make changes in its facilities, equipment, operations or procedures that

could affect the proper functioning of your equipment. If they do, you will be notified in advance to
give you an opportunity to maintain uninterrupted telephone service.

If you experience trouble with this telephone equipment, please contact Philips Consumer Electronics

Company repair facility at Philips Service Solutions Group, P.O. Box 555, Old Andrew Johnson
Highway, Jefferson City, TN 37760, for more information on obtaining service or repairs. The tele­phone company may ask that you disconnect this equipment from the network until the problem
has been corrected or until you are sure that the equipment is not malfunctioning.

This equipment may not be used on coin service provided by the telephone company. Connection to

party lines is subject to state tariffs.

This device is equipped with an RJ11 connector.

FCC Rules

Emissions Notice

Table of Contents

Safety Information . . . . . . . . . . .3-4

Canadian Ringer Equivalence

Number Notice . . . . . . . . . . . . . .5

Federal Communications

Commission Information . . . . . . .6

Introduction . . . . . . . . . . . . . . . . .7

Getting Started . . . . . . . . . . . . . . .8

Control Panels . . . . . . . . . . . . . . .9

Remote Control . . . . . . . . . . . . .10

General Information . . . . . . . . . .11

Connections . . . . . . . . . . . . .12-15

On-Screen Keyboard . . . . . . .16-17

Signing Up for WebTV . . . . .18-20

Connecting to the Home Page . .21

Explore . . . . . . . . . . . . . . . . . . . .22

Instructions . . . . . . . . . . . . . . . . .22

Search . . . . . . . . . . . . . . . . . . . . .23

Mail . . . . . . . . . . . . . . . . . . . .24-27

Favorites . . . . . . . . . . . . . . . . . . .28

Setup . . . . . . . . . . . . . . . . . . .29-31

Options Panel . . . . . . . . . . . .32-34

Advanced Options . . . . . . . . . . .35

Using a Computer Keyboard . . .36

Specifications . . . . . . . . . . . . . . .37

Limited Warranty . . . . . . . . . . . .38

Index . . . . . . . . . . . . . . . . . . . . .39

Accessories . . . . . . . . . . . . . . . .40

7

Introduction

◆ Before doing anything
else, record the model and
serial numbers in the
spaces provided on page

two. These numbers will
help us assist you if you ever call for
help.

Hello!

Thanks for purchasing the Philips Magnavox Internet
Terminal. You need to become a subscriber to the
WebTV™ Network to access the Internet with this
product. Becoming a subscriber is an easy process
once you’ve connected your Internet Terminal and
learned the basic remote control functions described
in the following pages.
This manual takes you through easy-to-follow instruc­tions so that you can ultimately enjoy the Internet.

WebTV Features

◆ Explore™ - A directory of the most useful and
exciting pages on the Internet

◆ E-mail (Electronic messages) - Exchange messages
with members of any Internet service

◆ Around Town™ - A catalogue of services and pages
on the Internet that are specific to your geographic
region

◆ Search - An easy way to locate information on spe­cific topics of interest

◆ Favorites - Provides instant access to your favorite
pages on the Internet

◆ Multiple accounts - Lets members of your household
have private mailboxes and Favorites lists

◆ Content filtering - Allows you to restrict access to
e-mail and pages on the Internet that contain mature
material

NOTES

WARNING: Any changes or modifications of this equip­ment not expressly approved by Philips Consumer
Electronics Company could void the user’s authority to
operate this equipment.
WebTV™ and Around Town™ are trademarks of
WebTV Networks, Inc.

Copyright 1998 by Philips Consumer Electronics
Company and WebTV Networks, Inc.

Package Contents

Before you connect your Internet Terminal, make sure
you have received all of the following items:

◆ Remote control

◆ Two AAA batteries

◆ AC power cord

◆ Phone cable

◆ Video cable (yellow)

◆ Audio cables (red and white)

◆ Telephone-splitter (T-splitter)

◆ Wireless Keyboard

Additional accessories are available. See page 40 for
details.

Battery Installation

8
Getting Started

1

Remove the battery compartment cover by pressing in
the tab, then lifting the cover.

2

Insert two batteries as indicated inside the battery
compartment.

3

Replace the battery compartment cover.

+

-

+

-

9

Control Panels

AC INPUT jack

Connect the AC (120V) power cord here. Plug the
other end into the wall outlet. (Connect the AC
power cord last.)

TEL LINE jack

Connect one end of a telephone cable to this jack.
Connect the other end to the wall telephone jack.

AUDIO (right and left) OUT jacks

Use audio cables to connect the Internet Terminal to
the AUDIO IN jacks on your TV.

KEYBOARD jack

You may connect a personal computer keyboard with
a PS/2 (6-pin connector) to the Internet Terminal. See
page 36 for details.

VIDEO OUT jack

Use a video cable to connect the Internet Terminal to
the VIDEO IN jack on your TV.

S-VIDEO OUT jack

Use an S-VIDEO cable (not supplied) to connect the
unit to the S-VIDEO IN jack on your TV.

RFU jack

Connect an RFU adapter (not supplied) here when you
connect the Internet Terminal to a TV without
Audio/Video jacks.

Infrared sensor

Receives the information from the remote control so
that you can operate your Internet Terminal from a
distance. You must point the remote control at the
Internet Terminal, not the TV.

POWER indicator

Indicates the Internet Terminal power is on.

CONNECTED indicator

This indicator flashes when the Internet Terminal is
connecting to WebTV. It remains lit while the unit is in
use. It also may flash when you try a different feature
or move among sites.

MESSAGE indicator

Indicates that you have a new e-mail message.

Vertical Sliding Door

Allows you to use Smart Card technology when it
becomes available. Accessories may be required.

WebTV port (on the side of the unit)
This port can be used for optional accessories that will
be introduced in the future. The door must be closed
for WebTV to operate. Additional accessories may be
required.

RESET Button

Press this button to reset the Internet Terminal.

BACK Button

Displays the last page viewed, or hides the on-screen
keyboard.

SCROLL (Up/Down) Buttons

Moves the page up or down when the page is too long
to be displayed on one screen.

GO Button

Activates a highlighted link or command; displays the
on-screen keyboard; displays a moveable arrow when
the currently displayed page contains an image map.

Arrow Buttons

Moves the yellow highlight box to a different command
or activity on the screen; selects different keys when
the on-screen keyboard is displayed.

HOME Button

Displays the WebTV Home Page.

OPTIONS Button

Displays the OPTIONS panel.

RECENT Button

Displays a panel that contains miniature versions of the
most recent pages you’ve visited.

SEARCH Button

Takes you directly to the Search page.

FAVORITES Button

Takes you directly to your Favorites list.

TV/WEB Button

Switches between WebTV and regular broadcast TV
when you are connected to a TV using the RFU
adapter.

POWER Button

Turns the Internet Terminal on and connects to
WebTV. Also disconnects from WebTV and turns off
the Internet Terminal.

10
Remote Control

◆ Areas on a page that can be highlighted are called

links, because they link you to another page. Links
can be words, pictures, icons, or boxes. WebTV finds
each link on a page for you when you press the
Arrow buttons on the remote. To activate a link, use
the Arrow buttons to highlight a link. Press the GO
button.
In some instances, the highlight might surround a
large area of the page or the entire page. When this
happens, an arrow will appear in the lower right cor­ner of the highlight to signify that this is an image
map.
To activate a link on an image map, press the GO
button. Another arrow will appear. Use the Arrow
buttons on the remote to move the arrow to the link
you want. Press the GO button to access the link.

Image map

11

General Information

The Title Bar

Any time you leave the Home Page, WebTV displays a Title Bar across the
bottom of your screen.

Page Title

Displays the title of the page currently on your screen.

Indicator Arrows

The indicator arrows are green when the currently displayed page is longer
than your screen. Green arrows indicate the direction or directions in which
more of the page can be viewed. Press the SCROLL buttons on the remote to
view more of the page.

When the down arrow is yellow, it indicates that the page is longer than your
screen, but WebTV has not finished loading the page into the system. The yel­low arrow will turn green when the page is loaded completely.

WebTV Connection Indicator

The connection indicator is green whenever you are connected to the WebTV
Network. When the indicator is moving, it tells you that WebTV is searching
the Internet for something you have requested.

The indicator becomes a straight red line when:

◆ You receive a telephone call (if you have Call Waiting).

◆ You use the HANG UP option. (See ADVANCED OPTIONS on page 35.)

◆ To keep your phone line free, your Internet Terminal automatically

disconnects from the WebTV Network if you do not use the remote con­trol for several minutes. This keeps your phone line free, so you don’t
have to wonder if you are disconnected from the WebTV Network. To
reconnect, press the GO button.

NOTES

Example of Title Bar information

Page Title Indicator

Arrows

Connection

Indicator

12
Connections

Connecting your System

Before you can connect to the WebTV Network, you
must connect your Internet Terminal to each of the
following:

◆ Your TV (either directly or through your VCR)

◆ A telephone line

◆ And an AC power outlet.

The type of connection you choose depends on
whether your TV:

◆ Has S-VIDEO, RCA-type A/V (audio/video), or RFU
coaxial jacks

◆ Or is connected to a VCR.
An S-VIDEO connection provides the best picture
quality of all the connection options. For optimum
audio performance, consider integrating the Internet
Terminal into your home entertainment system.

Telephone Line Connection Options

If possible, connect your Internet Terminal to a tele­phone jack that isn’t connected to a telephone. If you
have only one telephone jack, use the T-splitter to
share the line. This will enable you to keep both the
Internet Terminal and your telephone plugged in at the
same time. Plug the T-splitter into the wall telephone
jack.
If you don’t have Call Waiting service for your phone
line, a person trying to call you while you’re connected
to WebTV gets a busy signal.
If you have Call Waiting, see Select Dialing Options on
page 31. If you activate Call Waiting and you receive a
telephone call, your Internet Terminal temporarily dis­connects from the WebTV Network. When this hap­pens, your telephone will ring, and you can take the
call the way you normally do. To reconnect to the
WebTV Network, press the GO button on the
remote. WebTV reconnects you to the page you were
visiting when the call came in.
For information on disconnecting from the WebTV
Network to make a telephone call, see Advanced
Options/Hang Up on page 35.
If the telephones in your house are generally busy, you
might consider using a separate, or dedicated, tele­phone line for the WebTV Network. Contact your
local phone company to order a separate phone line.

Audio Cables

S-Video Cable

(not supplied)

Back of Internet Unit

Phone
Cable

AC
Power
Cord

TV

VIDEO

IN

L

R

IN

L

R

OUT

A
U
D
I
O

S - VIDEO

75V
ANT /
CABLE

13

Connections (cont’d)

Connecting to a TV with an S-VIDEO jack

This connection will provide the best picture quality.

Connect the AUDIO R(ight) and L(eft) jacks on the
Internet Terminal to your TV’s AUDIO IN jacks, using
the supplied audio cables.
Do not connect the VIDEO cable (yellow) to the
VIDEO OUT jack.

1

Use an S-VIDEO cable (not supplied) to connect the S­VIDEO OUT jack on your Internet Terminal to the S­VIDEO IN jack on your TV. (An S-VIDEO cable is
available from Philips Service Solutions Group or your
local dealer. See page 40 for details.)

Connect one end of the telephone cable to the
Internet Terminal’s TEL LINE jack. Connect the other
end to your home’s telephone outlet.

2

3

◆

Check that your local AC voltage corresponds
to the voltage indicated on the AC adapter
(120V) before connecting the unit to AC power.
If it does not, consult your dealer.

◆

If you choose the S-VIDEO setup, use the

remote control that came with your TV to set the video input,
when viewing WebTV, to S-VIDEO IN.

NOTES

4

Connect one end of the AC power cord to the
Internet Terminal’s AC INPUT jack. Connect the other
end to an AC outlet.

Back of Internet Unit

RFU Adapter

RF Coaxial Cable

Phone
Cable

TV

AC
Power
Cord

3CH

4CH

CHANNEL

75V
ANT /
CABLE

Connecting to a TV without Audio/Video jacks

If your TV does not have Audio/Video jacks, you must
use an RFU adapter (not supplied) to connect the
Internet Terminal to your TV.

Set the channel switch on the RFU adapter to VHF
channel 3 or 4, whichever is not used or least used in
your area.

1

Connect the RFU adapter to the VIDEO and AUDIO
OUT jacks on the Internet Terminal.

2

Use a RF coaxial cable to connect the ANTENNA
OUT jack on the adapter to the ANTENNA IN jack
on the back of your TV.
You may need to disconnect the antenna/cable from
your TV to make this connection. Connect the anten­na/cable to the ANTENNA IN jack on the RFU
adapter.

3

14
Connections (cont’d)

Connect one end of the telephone cable to the
Internet Terminal’s TEL LINE jack. Connect the other
end to your home’s telephone outlet.

4

Connect one end of the AC power cord to the
Internet Terminal’s AC INPUT jack. Connect the other
end to an AC outlet.

5

Set your TV to channel 3 or 4, whichever channel the
adapter is set to, when using the Internet Terminal.

6

Connect your cable
or antenna to the
ANTENNA IN jack
on the RFU adapter.

Audio Cables

Back of Internet Unit

Phone
Cable

AC
Power
Cord

Coaxial Cable

Video Cable

CH3 CH4

RF OUT

ANT.IN

AUDIO

VIDEO

IN OUT

IN OUT

R

L

VIDEO

IN

L

R

IN

A
U
D
I
O

75V
ANT /
CABLE

15

Connections (cont’d)

Connecting to a TV or a VCR with Audio/Video
jacks

◆ If you choose the Audio/Video jacks setup,
use the remote control that came with your
TV to set the video input, when viewing
WebTV, to VIDEO IN.

◆ If you connect through your VCR, the VCR
must be turned on, with the VCR’s External Input selected,
to access the WebTV Network.

NOTES

Connect the audio cables (red and white) to the
AUDIO OUT R(ight) and L(eft) jacks on the back of
the Internet Terminal and to the AUDIO IN jacks on
your TV, matching colors. If there is only one audio
jack, connect the white plugs.

1

3

2

Connect the video cable (yellow) to the VIDEO OUT
jack on the back of the Internet Terminal and to the
VIDEO IN jack on the back of your TV.

Connect one end of the telephone cable to the
Internet Terminal’s TEL LINE jack. Connect the other
end to your home’s telephone outlet.

4

Connect one end of the AC power cord to the
Internet Terminal’s AC INPUT jack. Connect the other
end to an AC outlet.

5

If connecting through your VCR, connect the audio
cables (red and white) to the AUDIO OUT R(ight) and
L(eft) jacks on the back of the Internet Terminal and to
the AUDIO IN jacks on your VCR, matching colors. If
there is only one audio jack, connect the white plugs.
Connect the video cable (yellow) to the VIDEO OUT
jack on the back of the Internet Terminal and to the
VIDEO IN jack on the back of your VCR.
Use a coaxial cable to connect the OUT jack on your
VCR to the VHF/UHF IN jack on your TV.
(Or, you may also use additional audio and video
cables to connect the Audio/Video Out jacks on your
VCR to the Audio/Video In jacks on your TV.)

16
On-Screen Keyboard

The On-Screen Keyboard

Use the on-screen keyboard to type information on your TV
screen. When you request an activity that requires typing, such
as sending an e-mail message, a text box appears on the screen.
A text box contains a vertical yellow line, which indicates
exactly where you can type in the text box.

◆ You can choose whether your keyboard displays letter keys in alpha-

betical order or standard typewriter order (QWERTY). See Setup on
page 30.

◆ You can type on-screen only when a text box is displayed.

NOTES

1

2

4

Press the GO button on the remote. The keyboard slides onto
your screen. To remove the on-screen keyboard at any time, press

the BACK button.

Displaying the on-screen keyboard

Move the yellow highlight to a text box using the remote con­trol Arrow buttons. The highlight becomes a vertical yellow
line inside the box.

1

2

Typing letters, numbers, and punctuation marks using the on-screen
keyboard

Highlight the desired character using the Arrow buttons on the remote control.

Press the GO button on the remote.

1

2

Typing upper case letters

Highlight SHIFT on the on-screen keyboard using the remote control Arrow
keys.

Press the GO button on the remote. The red light next to “caps” turns on.

Highlight the desired character using the remote control Arrow buttons.

3

Press the GO button on the remote.
To type more than one upper case letter, repeat these steps for each letter.

Moving to the next text box on the same page

Erasing or changing a character

121

Highlight an arrow key on the on-screen keyboard. Press the GO button
repeatedly until the vertical line is located to the right of the character you
want to erase.

Highlight DELETE on the on-screen keyboard, then press the GO button on
the remote.

Highlight the character you wish to substitute, then press the GO button on
the remote.

1

Moving to the next line in a text box

Highlight RETURN on the on-screen keyboard, then press the GO button on
the remote.

Note:

The yellow line generally moves to the next line when you come to the end of
a line in a text box.

Highlight CONTINUE on the on-screen keyboard, then press the GO button
on the remote.

17

On-Screen Keyboard (cont’d)

Press the GO button on the remote. The on-screen keyboard appears.

312

Moving to the previous text box on the same page

Press the BACK button to hide the keyboard.

Press the Up Arrow button on the remote. (The yellow line moves to the pre­vious text box.)

1

Inserting a space between characters

Highlight SPACE on the on-screen keyboard, then press the GO button on the
remote.

2

3

1

Hiding the on-screen keyboard

Press the BACK button on the remote control.

18
Signing Up for WebTV

1

Turn on your television.

Press the POWER button to turn on the Internet Terminal. The Philips
Magnavox logo will appear briefly.
The screen will show the Connecting to WebTV display. (If your unit is having
trouble connecting, you may see various messages on-screen. Follow the direc­tions on-screen carefully, then try again.) Information about WebTV will
appear.
Continue will be highlighted on screen. Press the GObutton.

Information about choosing items will appear on-screen. This is to familiarize
you with using the Arrow buttons to highlight a link.
Use the Arrow buttons to highlight a link. Press the GO button to choose the
link. Use the Arrow buttons to highlight CONTINUE, then press the GO but­ton.

Signing Up for WebTV

2

3

4

The FIRST NAME box will be highlighted. Press the GO button. The on-screen
keyboard will appear.
Use the Arrow buttons and the GO button to enter your name. When you
finish, use the Arrow buttons to highlight CONTINUE or RETURN, then press
the GO button.
CONTINUE will be highlighted on-screen.
Press the GO button again.

5

The LAST NAME box will be highlighted. Press the GO button.
The on-screen keyboard will appear.
Enter your last name. When you finish, use the Arrow buttons on the remote
to highlight CONTINUE or RETURN, then press the GO button.
CONTINUE will be highlighted on screen. Press the GO button again.

Signing up for the WebTV Network is an easy process that asks you to pro­vide your name, billing address, phone number, credit card information, and an
Internet name (which acts as your e-mail address). When you complete the
last sign-up page, you will be given the opportunity to correct mistakes. Once
the information is correct, the WebTV Home Page will appear. You are ready
to begin your Internet experience. If you have any difficulty signing up, please
call 1-800-GOWEBTV.

6

The PHONE BOX will be highlighted. Press the GO button. The on-screen
keyboard will appear.
Enter your area code and phone number. You don’t have to insert spaces or
hyphens for the phone number information. When you finish, use the Arrow
buttons to highlight CONTINUE or RETURN, then press the GO button.
CONTINUE will be highlighted on-screen. Press the GO button again.

19

Signing Up for WebTV (cont’d)

7

The STREET box will be highlighted. Press the GO button. The on-screen key­board will appear.
Enter your street address. When you finish, use the Arrow buttons to highlight
CONTINUE or RETURN.

The CITY box will be highlighted. Enter your city name. When you finish, high­light CONTINUE or RETURN, then press the GO button.

8

9

The STATE box will be highlighted. Enter your state’s postal abbreviation. When
you finish, highlight CONTINUE or RETURN, then press the GO button.

The ZIP box will be highlighted. Enter your zip code. When you finish, highlight
CONTINUE or RETURN, then press the GO button.

10

CONTINUE will be highlighted on-screen. Press the GO button again.

11

Information about WebTV billing procedures will appear. CONTINUE will be
highlighted. Press the GO button.

12

You will be asked to identify the type of credit card you will use. Use the
Arrow buttons to highlight the type of credit card you will use, then press the
GO button.

13

The NUMBER box will be highlighted. Press the GO button. The on-screen
keyboard will appear. Enter your credit card number. You don’t have to insert
spaces or hyphens for the credit card information. When you finish, use the
Arrow buttons to highlight CONTINUE.

The EXPIRES box is highlighted. Enter your credit card’s expiration date.
When you finish, highlight CONTINUE, then press the GO button.

14

15

◆ The sign-up pages will reappear each time you turn on your Internet

Terminal until you complete the sign-up process.

◆ If you go back a page, you will erase the information on the current

page.

◆ If you enter a name that has already been chosen by another WebTV
member, you will be asked to enter a different name. If you receive this message
three times, WebTV will suggest a name for you. You can use it, or you can contin­ue trying to find one on your own.

◆ The first time you connect to the WebTV Network, your Internet Terminal takes
a minute or more to make the connection.

NOTES

20
Signing Up for WebTV (cont’d)

CONTINUE will be highlighted. Press the GO button again.
The Internet name box will be highlighted. Press the GO button. The on­screen keyboard will appear. Type in your Internet name. Your Internet name
acts as your e-mail address. It can contain letters and numbers, but must start
with a letter. For example, T42 is okay, 24T is not. It must contain at least
three characters, and no more than 15. It cannot contain spaces or punctua­tion marks.
If you enter a name that has already been chosen by another WebTV member,
you will be asked to enter a different name. If you receive this message three
times, WebTV will suggest a name for you. You can use it, or you can continue
trying to find one on your own.
When you finish, highlight CONTINUE, then press the GO button.

When you complete the last sign-up page, WebTV displays a page that contains
all the information you have entered.

◆ If you make a mistake, press the BACK button until the incorrect

page appears. Going back deletes the information on the current page.
Make the correction, then continue as instructed.

NOTES

16

17

1

Highlight the text box that contains the information you wish to change and press
the GO button. The page on which you originally entered the information
appears.

See "Erasing or changing a character" on page 17 for details on how to make a
correction.

Highlight CONTINUE and press the GO button to return to the sign-up infor­mation page. You may need to repeat this step more than once to reach the
sign-up information page.

2

3

Correcting a mistake on a previous sign up page:

1

Highlight CORRECT on the sign-up information page and press the GO button.
The WebTV Home Page will appear soon.

Completing the sign-up process

21

Connecting to the Home Page

◆ If you take your Internet Terminal to a new location, for example, to show it
to a friend, you may see the message: “Your Internet Terminal was unplugged
or the electricity went out. If you are at a different phone number now, choose
New Number. Otherwise, choose Same.”

If you are at the same phone number, highlight Same and press the GO but­ton. If you are at a different phone number, highlight New Number and press the GO but­ton. Follow the instructions on-screen.

◆ If more than one user is registered for your unit, you must enter your user name and
password. Then, the Home Page will appear. The Mail, Favorites and Options will be set for
the designated user. See Setup on page 30 for details.

Connecting to WebTV screen

NOTES

Exploring the Internet on WebTV

This chapter explains how to access various pages on the Internet from the WebTV
Home Page. Because the Internet is constantly changing, the Home Page will also occa­sionally change. When you see new icons, explore! WebTV will provide help for using
new icons through the INSTRUCTIONS icon.

1

Turn on your television.

2

Press the POWER button on the remote to turn on the Internet Terminal. The
Connecting to WebTV screen will appear.

In one to two minutes, the WebTV Home Page will appear.
If the Internet Terminal is having trouble connecting to WebTV, you may see a mes­sage on-screen. Follow the on-screen directions carefully. If you need to check your
Dialing Options, see page 31 for more details.

3

1

To Activate a Home Page Icon

Highlight an icon on the Home Page using the Arrow buttons on the remote control.

To connect to the Home Page

Press the GO button on the remote.

2

Go to a page from the EXPLORE page

Highlight any icon on the EXPLORE page and press the GO button on the
remote control. The icons either lead to more selections or directly to a page.

22
Explore

EXPLORE is designed to make your exploration of the Internet easy and fun.
When you enter the EXPLORE area, you’ll find links to some of the most
exciting and useful pages on the Internet. WebTV will continuously update
EXPLORE.

1

Instructions

1

2

The INSTRUCTIONS area contains help for using the remote control and vari­ous WebTV features, such as the Home Page areas.

Highlight the INSTRUCTIONS icon and press the GO button.

Highlight any topic on the INSTRUCTIONS page and press the GO button on
the remote control. The instructions for that topic will appear.

◆ To exit the Instructions at any time, press the HOME button to
return to the Home Page.

NOTES

Read the Instructions

23

Search

◆ At the end of the listings, you may have the option to highlight NEXT

DOCUMENT or PREVIOUS DOCUMENT. Next and previous documents

are continuations of listings pertaining to your topic. Highlight NEXT

DOCUMENT or PREVIOUS DOCUMENT, then press the GO button to

see additional listings.

◆ You may press the SEARCH button at any time to go directly to the

SEARCH page.

SEARCH links you to the SEARCH page, which enables you to search the
Internet for information on both general and specific topics.

To search for specific information:

Highlight SEARCH on the Home Page and press the GO button.

Type a topic in the text box. You can enter one word, many words, or even a
question.

3

Highlight the SEARCH command and press the GO button. A list appears on
your screen.

2

4

Highlight an item on the list using the Arrow buttons on the remote control
and press the GO button. The page will appear soon.

Note

Press the BACK button or the RECENT button on the remote control to return to the
list if the page does not contain what you are looking for.

NOTES

1

24
Mail

The MAIL icon links you to your MAILBOX, which lists the e-mail messages
you have received. To read a message, simply highlight a message on the list
and press the GO button.

The MAILBOX page contains the following icons:

◆ write

◆ storage

◆ setup

◆ names

◆ discard

Note: When you have unread messages in your MAILBOX, the red MESSAGE light on
the front of your Internet Terminal is illuminated. If you receive a message while you are
connected to the WebTV™ Network, the red MESSAGE light will flash.

Highlight WRITE to open the WRITE A NEW MESSAGE page, where you can
address, create, and send e-mail messages.

You can send the same e-mail message to more than one address at a time by enter­ing more than one address in the TO text box. Separate addresses with a comma
and a space.

The STORAGE icon links you to the STORED MAIL page, where you can view
messages you have saved.

The SETUP icon allows you to:

◆ Choose whether your MAILBOX displays your oldest or newest messages
at the top.

◆ Type a signature that is automatically added to the end of each e-mail mes­sage you send.

◆ Include a carbon copy. (The CC text box on your WRITE A NEW MES­SAGE page allows you to send a copy of your message to one or more
addresses.)

25

Mail (cont’d)

To open and read an e-mail message

Highlight an e-mail message on the MAILBOX page and press the GO button.
The contents of the message appear on your screen.

1

Open a message from your MAILBOX page.

Highlight SAVE and press the GO button.

To read saved messages

2

1

Highlight STORAGE on the MAILBOX page and press the GO button. A list of
saved messages appears.

Highlight a message and press the GO button. The contents of the saved mes­sage appear.

2

To reply to an e-mail message

1

With a message open on your screen, highlight REPLY and press the GObut­ton. The REPLY TO A MESSAGE page appears with the address and subject
entered in the appropriate boxes for you.

Type your reply.

2

Highlight SEND and press the GO button. A message appears indicating that
your e-mail is being sent.

3

To save or store a message

The NAMES icon links to your NAMES page, which allows you to store and
edit e-mail addresses. You can automatically address messages from your list of
names.

The DISCARD icon allows you to discard messages from your MAILBOX.

To return to the MAILBOX page

Highlight MAILBOX and press the GO button.

26
Mail (cont’d)

Highlight SEND and press the GO button. A message appears, indicating that
your e-mail is being sent.

To resend an e-mail message

1

With a message open on your screen, highlight RESEND and press the GO
button. The RESEND A MESSAGE page appears with the subject entered for
you.

Type one or more e-mail addresses in the TO text box. Separate addresses by
a comma and a space if you type more than one address.

Type a message to add to the forwarded message in the text box on the bot­tom of the page (optional).

2

3

4

Highlight SEND and press the GO button. A message appears indicating that
your e-mail is being sent.

5

123

To send an e-mail message

Highlight WRITE and press the GO button. The WRITE A NEW MESSAGE
page appears.

Type one or more e-mail addresses in the TO text box. Separate addresses by
a comma and a space if you type more than one address.

Use the Arrow buttons on the remote control to move to the next text box.
Type your message.

Use the Arrow buttons on the remote control to move the vertical line to the
SUBJECT text box. Type a subject (optional).

123

To discard a message

Highlight DISCARD and press the GO button. A list of e-mail messages
appears.

Highlight a message and press the GO button. Repeat to discard more than
one message at a time.

Highlight DISCARD and press the GO button. WebTV discards the highlighted
messages from the list.

4

1

Delete a name on the NAMES page

Highlight NAMES on the MAILBOX page and press the GO button. The
NAMES page appears.

2

Highlight the name you wish to delete and press the GO button.

Highlight DISCARD and press the GO button. WebTV deletes the name from
your list.

312

3

Use your list of NAMES

Highlight NAMES on the WRITE A NEW MESSAGE page and press the GO
button. The NAMES panel appears.

Highlight the name of the person to whom you want to send a message and
press the GO button. Repeat to send the same message to more than one
person at a time.

Highlight CONTINUE and press the GO button. The highlighted name or names
will appear in the TO text box.

27

Mail (cont’d)

123

Add a name to your NAMES page

Highlight NAMES on the MAILBOX page and press the GO button. The
NAMES page appears.

Highlight NEW and press the GO button.

Type the appropriate information in the text boxes, then highlight ADD and
press the GO button.

28
Favorites

1

2

3

Save a page to your FAVORITES list

Go to a page you wish to visit frequently and press the OPTIONS button on
the remote control. The OPTIONS panel appears at the bottom of the screen.

Highlight SAVE on the OPTIONS panel and press the GO button. A panel that
displays the SAVE PAGE command appears.

Highlight the SAVE PAGE command and press the GO button. The page is
saved in your personal FAVORITES list.

1

2

Open a page from your FAVORITES list

Highlight FAVORITES on the Home Page and press the GO button. Your
FAVORITES list appears on the screen.

Highlight a title or an icon on the list and press the GO button. The page
appears.

1

2

3

Delete a page from your FAVORITES list

Open your FAVORITES list and highlight EDIT, then press the GO button.

In the EDIT FAVORITES screen, highlight the REMOVE box next to the page
you wish to delete, then press the GO button.

Highlight DONE and press the GO button.

◆ You may go to your FAVORITES page at any time by pressing the
FAVORITES button on the remote control.

NOTES

29

Setup

Enter the SETUP area to display options that allow you to:

◆ Restrict access to pages on the Internet that contain mature material.

(Different users can have different access settings.)

◆ Choose whether your on-screen keyboard displays the letter keys in alpha-

betical order or standard typewriter order (QWERTY).

◆ Make the text that appears on your screen smaller or larger.

◆ Update your sign-up information.

◆ Turn off WebTV sounds.

◆ Turn off Call Waiting interruptions.

◆ Display/hide ADVANCED OPTIONS (HANG UP and RELOAD) on the

OPTIONS panel. See Advanced Options on page 35.

◆ Create separate accounts with private MAILBOXES and FAVORITES lists

for each member of your household.

◆ Change your Internet name or password (except the primary user).

You must create and use a password to access a separate account. Passwords
can contain all numbers, or letters and numbers, and must contain a minimum
of four characters. Do not use spaces or punctuation marks.
For security reasons, your password will be displayed as a row of dots on the
screen. WebTV will ask you to type your password twice to ensure accuracy.

30
Setup (cont’d)

Create separate accounts and set access restrictions (WebTV users)

Highlight WEBTV USERS and press the GO button.

Highlight ADD A USER and press the GO button.

Enter an Internet name, then highlight CONTINUE and press the GO button.

Enter a password and select CONTINUE.
Different access options will appear. Follow the on-screen instructions to set
the desired level of access restriction.

Highlight the check box next to an option and press the GO button. A red
check mark means the option is turned on. Press the GO button again to
remove the check mark.

Select CONTINUE and then select DONE to return to the SETUP page.

1

2

3

4

5

6

Highlight DONE and press the GO button.

1

2

3

Customize your keyboard

Highlight KEYBOARD and press the GO button.

Highlight ALPHABETICAL or QWERTY and press the GO button.

Highlight DONE and press the GO button to return to the SETUP page.

Change sign-up information

1

2

3

Highlight WEBTV USERS and press the GO button. Choose the user whose
information you would like to change, then press the GO button.

Enter new information in the appropriate text boxes.

1

2

3

Customize your WebTV screen

Highlight TEXT SIZE and press the GO button.

Highlight DONE, then press the GO button to return to the SETUP page.

Make your selection.

31

Setup (cont’d)

1

Display Advanced Options

Highlight ADVANCED OPTIONS and press the GO button.
The ADVANCED OPTIONS appear on your OPTIONS panel if you choose
this setting.
The ADVANCED OPTIONS allow you to:
RELOAD: Update the version of the page you are visiting currently.
HANG UP: Temporarily disconnect from the WebTV Network to make a
phone call. To reconnect, press the GO button on the remote. WebTV recon­nects you to the same location you were visiting when you disconnected.

1

2

Highlight SOUND AND MUSIC and press the GO button.

Highlight the appropriate check box and press the GO button. A red check
mark means you will not hear the sounds or music. Press the GO button again
to remove the check mark.

1

2

3

Highlight DIALING OPTIONS and press the GO button. A list of options
appears:
CALL WAITING: Choose whether your Internet Terminal disconnects from
the WebTV Network when a call comes in.
BASIC: Enter a prefix for dialing out; choose tone dialing.
ADVANCED: Set a dialing speed.
ACCESS: Enter an access number for WebTV.

Highlight the box next to a desired option and press the GO button. A red
check mark means the dialing option is turned on. Press the GO button again
to remove the check mark.

Highlight DONE and press the GO button to return to the SETUP page.

Select Dialing Options

Customize your MAIL area

3

Highlight DONE and press the GO button to return to the SETUP page.

Turn off WebTV sounds and music

See SETUP on page 24 for details.

The INFO option displays the title and address of the page currently on the
screen, as well as the most recent time the page was updated.

Displaying the INFO panel

Highlight INFO on the OPTIONS panel and press the GO button.

1

32
Options Panel

The OPTIONS panel offers several features that enable you to navigate your
way through WebTV and to perform other functions easily and efficiently.

Using the OPTIONS panel

Press the OPTIONS button on the remote control. The OPTIONS panel slides
onto the bottom of your screen.

Highlight an option and press the GO button.

Each option brings up a different panel. The following sections describe the
various options, and how to use each option’s features.

The WebTV option returns you to the WebTV Home Page.

The FIND option helps you find a specific word or phrase on the current page;
it also lets you scroll to the top or bottom of a page.

To find a specific word or phrase on a page, type a word or phrase in the text
box on the FIND panel.

Highlight FIND and press the GO button. WebTV highlights the requested
text on the page.

121

2

33

Options Panel (cont’d)

Find a new word or phrase

Highlight CLEAR and press the GO button.

Type a new word or phrase in the text box, then highlight FIND and press the
GO button.

Scroll to the top or the bottom of a page

Highlight SCROLL TO TOP or SCROLL TO BOTTOM and press the GO but­ton.

121

The GO TO option allows you to go directly to a page by typing in an Internet
address.

Go directly to a page

Highlight GO TO on the panel and press the GO button.

Type the Internet address in the text box. For example: http://webtv.net

Highlight the GO TO PAGE command and press the GO button. The page
appears on your screen.

Display addresses

Highlight SHOW CURRENT and press the GO button to display the address of
the currently displayed page.

Highlight SHOW LAST and press the GO button to display the most recent
address you entered on the GO TO panel.

112

2

3

34
Options Panel (cont’d)

The SAVE option allows you to save the currently displayed page on your
FAVORITES list.

Save a currently displayed page

Highlight SAVE and press the GO button.

Highlight SAVE PAGE and press the GO button.

The SEND option allows you to send an e-mail message that contains a link to
the currently displayed page.

Send a page by e-mail

Open the page you want to send, then press the OPTIONS button on the
remote control.

Highlight the SEND option and press the GO button.

In the text box labeled TO, type the e-mail address of the person to whom
you want to send the page. Highlight EDIT MESSAGE and press the GO button
to add a message.

Highlight the SEND PAGE command and press the GO button. The page link
will appear when the recipient opens the e-mail message.

121

2

3

4

35

Advanced Options

See Display Advanced Options on page 31 for details on how to display the
ADVANCED OPTIONS on your OPTIONS panel.

The RELOAD option loads an updated version of the page you are currently
visiting. Use this option when the page you are viewing contains information
that is updated frequently, such as sports scores or stock quotes.

Reload a page

Open a page, then highlight the RELOAD option and press the GO button.

The HANG UP option allows you to temporarily disconnect from the WebTV
Network to make a telephone call, then reconnect to the page you were visit­ing when you disconnected.

Use the HANG UP option

Highlight the HANG UP option and press the GO button. The WebTV connec­tion indicator on the title bar turns red and becomes a straight line.

Make a telephone call the way you normally do.

Press the GO button to reconnect to the WebTV Network.

1

2

3

1

36
Using a Computer Keyboard

You may connect a personal computer keyboard (wired) to the Internet Terminal.
This will allow you to type information into the text boxes which appear on-screen.
The keyboard must have a PS/2 (6-pin) type connector, and it must be an AT type.
Connect the keyboard to the KEYBOARD jack on the back of the Internet Terminal.
The function keys on a PC keyboard will have different operations once the keyboard
is connected to the Internet Terminal. The keys will have the following functions.

F1 Power
F2 Favorites
F3 Search
F4 Mail
F5 Find
F6 Information
F7 Go To
F8 Save
F9 Send
F10 Recent
F11 Options
F12 No function

Other keyboard keys operate as follows:
Insert Edit text
Home To go back to the WebTV Home Page
Page Up Scroll up in a document
Page Down Scroll down in a document
End To go back to the previous page

Other PC-specific keys have no function when the keyboard is connected to the
Internet Terminal.
You may choose to make a template for your keyboard, identifying the uses of these
keys when connected to WebTV.

Connect the keyboard to the KEY­BOARD jack on the back of the
Internet Terminal.

37

Specifications

Terminals

◆ Video Output

◆ Audio Outputs (right and left)

◆ S-Video Output

◆ Telephone line Input

◆ RFU DC Output

◆ Keyboard (PS/2 style keyboard connector)

◆ WebTV port (96 pin)

Dimensions

280mm x 49.2mm x 214.7mm
(11 1/8" x 2" x 8 1/4")

Weight

1.3kg (2lbs 14 oz)

Power requirements

AC 120V

Power consumption

15W maximum
5W standby

Supplied Accessories

◆ Remote Control

◆ Two AAA Batteries

◆ AC Power Cord

◆ Phone Cable

◆ Video Cable (yellow)

◆ Audio Cables (red and white)

◆ Telephone-splitter (RJ-11 Y adapter or T-splitter)

◆ Wireless Keyboard

Optional Accessories

◆ EXT channel 3/4 RFU Adapter

◆ S-Video Cable

Designs and specifications are subject to change without notice.

WHO IS COVERED?

You must have proof of purchase to receive warranty service. A sales
receipt or other document showing that you purchased the product is
considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you purchase your product. For 90
days from the date of purchase, the Internet Terminal will be replaced
with a new, repaired, renewed or comparable product (whichever is
deemed necessary) if it becomes defective or inoperative. This
exchange is done without charge to you.

From 90 days to one year from the date of purchase, your Internet
Terminal will be replaced with a new, repaired, renewed, or compara­ble product (whichever is deemed necessary) if it becomes defective
or inoperative. You will be responsible for all labor costs. Contact
Philips Service Solutions Group at 1-888-813-7069 to obtain your cost
(labor costs) for exchange.

All products, including replacement products, are covered only for the
original warranty period. When the warranty on the original product
expires, the warranty on the replacement product also expires.

After one year from the date of purchase, you pay for the replacement
of all parts, and for all labor charges.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product.

• installation, performance of, or repair of audio/video cabling, tele-

phone line, or accessory attachments used in accessory ports out­side of the product.

• product replacement because of misuse, accident, lightning damage,

unauthorized repair, or other cause not within the control of
Philips Consumer Electronics Company.

• incidental or consequential damages resulting from the product.

(Some states do not allow the exclusion of incidental or consequen­tial damages, so the above exclusion may not apply to you.)

• reception transmission problems caused by signal conditions, tele-

phone line, or cable or antenna systems outside the unit.

• a product that requires modification or adaptation to enable it to

operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of
products damaged by these modifications.

• a product used for commercial or institutional purposes.

Philips makes no warranty that the access connection will be a local
(not long distance) call, or that international dialing connection(s)
may be required for usage of the product outside the United States.
WebTV service is separate and distinct from this product (hard­ware) warranty.

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of
purchase. Attach it to this owner’s manual and keep both nearby.
Also keep the original box and packing material in case you need to
return your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service.
Adjustments of the controls discussed there may save you a service
call.

TO GET WARRANTY SERVICE...

Warranty service will be provided by Philips Consumer Electronics
Company. If you believe you need service for your Internet Terminal,
contact Philips Service Solutions Group at 1-888-813-7069. A repre­sentative will go through a diagnostic checklist with you. If it is deter­mined that the product needs to be exchanged, you will receive a
return authorization number.
The representative will give you complete shipping details.

PHILIPS MAGNAVOX SERVICE CONTRACT

Enjoy peace of mind, even after your product’s warranty expires. A
Philips Magnavox Service Contract protects you from unexpected (and
unwelcome) expenses by fully covering the cost of both parts and
labor, should a repair be necessary. And, we’re there when you need
us-you’ll receive fast, convenient service with a single phone call, seven
days a week.
Receiving this protection is simple. Complete and mail your warranty
registration card or, if you’d like more information, call 1-888-813­7069 today.

TO GET OUT-OF-WARRANTY SERVICE...

Out-of-warranty service can be obtained at a nominal cost for replace­ment and handling. To obtain out-of-warranty service:

1. Contact Philips Service Solutions Group at 1-888-813-7069 to
obtain the cost of out-of-warranty exchange for your product.

2. Pack the Internet Terminal in a carton suitable for safe shipment.

3. Ship the unit, freight prepaid, to:

Philips Service Solutions Group

112 Polk Street

Greeneville, Tennessee 37745
Make sure you write your complete return address on the outside of
the carton. Also, include a letter inside the carton describing the prob­lem. Be sure the letter includes your name, address, telephone num­ber, and product serial number. Enclose your money order in the
amount quoted to you by the Philips Service Solutions Group repre­sentative.

4. When your product is received, it will be replaced by a new,
repaired, renewed, or comparable product which meets Philips’ high
quality standards and returned to you by prepaid transportation. You
will be responsible for all transportation and shipping costs.

REMEMBER...

Record below the model and serial numbers found on the product.
Also, fill out and mail your warranty registration card promptly. It will
be easier for us to notify you if necessary. (The return of the warranty
registration card is not a condition for warranty coverage.)
MODEL # _____________________________________
SERIAL # _______________________________________

EL6176E002 / MAC 5972 / 08-98

This warranty gives you specific legal rights. You may have other rights which vary from state to state.

All implied warranties, including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this

express warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Philips Service Solutions Group, P.O. Box 555, Jefferson City, Tennessee 37760, [phone]

38
Limited Warranty

Internet Terminal

90 Days Free Labor

One Year Parts Exchange

39

Index

ac input jack . . . . . . . . . . . . . . . . .9

access restrictions setup . . . . . . .30

accessories . . . . . . . . . . . . . . . . .40

account setup . . . . . . . . . . . . . . .30

advanced options . . . . . . . . .31, 35

arrow buttons . . . . . . . . . . . . . .10

audio jacks . . . . . . . . . . . . . . . . . .9

back button . . . . . . . . . . . . .10, 23

battery installation . . . . . . . . . . . .8

connected indicator . . . . . . . . . . .9

connecting to the home page . . .21

connection indicator . . . . . . . . . .11

connections . . . . . . . . . . . . . .12-15

control panels . . . . . . . . . . . . . . . .9

correcting mistakes . . . . . . . . . .20

dialing options setup . . . . . . . . . .31

dimensions . . . . . . . . . . . . . . . . .37

discard icon . . . . . . . . . . . . .25, 26

exchange . . . . . . . . . . . . . . . . . . .38

explore . . . . . . . . . . . . . . . . . . . .22

favorites button . . . . . . . . . .10, 28

favorites list . . . . . . . . . . . . . . . .28

fcc information . . . . . . . . . . . . . . .6

find option . . . . . . . . . . . . . . .32-33

general information . . . . . . . . . . .11

getting started . . . . . . . . . . . . . . .8

go button . . . . . . . . . . . . . . . . . .10

go to option . . . . . . . . . . . . . . . .33

hang up option . . . . . . . . . . . . . .35

home button . . . . . . . . . . . .10, 22

image map . . . . . . . . . . . . . . . . .10

index . . . . . . . . . . . . . . . . . . . . .39

indicator arrows . . . . . . . . . . . . .11

info option . . . . . . . . . . . . . . . . .32

infrared sensor . . . . . . . . . . . . . . .9

instructions . . . . . . . . . . . . . . . . .22

introduction . . . . . . . . . . . . . . . . .7

keyboard (wired) connection . . .36

keyboard jack . . . . . . . . . . . . .9, 36

keyboard setup . . . . . . . . . . . . . .30

limited warranty . . . . . . . . . . . . .38

links . . . . . . . . . . . . . . . . . . . . . .10

mail . . . . . . . . . . . . . . . . . . . .24-27

mailbox . . . . . . . . . . . . . . . . .24-27

mailbox setup . . . . . . . . . . . . . .24

message indicator . . . . . . . . . .9, 24

messages . . . . . . . . . . . . . . . .24-27

names icon . . . . . . . . . . . . . .25, 27

on-screen keyboard . . . . . . . .16-17

options button . . . . . . . . . . . . . .10

options panel . . . . . . . . . . . . .32-34

package contents . . . . . . . . . . . . .8

page title . . . . . . . . . . . . . . . . . . .11

personal computer keyboard . . .36

power button . . . . . . . . . . . . . . .10

power consumption . . . . . . . . . .37

power indicator . . . . . . . . . . . . . .9

power requirements . . . . . . . . . .37

recent button . . . . . . . . . . . .10, 23

reload option . . . . . . . . . . . . . . .35

remote control . . . . . . . . . . . . . .10

reset button . . . . . . . . . . . . . . . . .9

rfu jack . . . . . . . . . . . . . . . . . . . . .9

safety information . . . . . . . . . . .3-4

save icon . . . . . . . . . . . . . . . . . . .25

save option . . . . . . . . . . . . . . . .34

scroll (up/down) buttons . . . . . .10

search . . . . . . . . . . . . . . . . . . . . .23

search button . . . . . . . . . . . .10, 23

send option . . . . . . . . . . . . . . . .34

setup icon . . . . . . . . . . . . . . . . . .24

setup options . . . . . . . . . . . . .29-31

signing up for webtv . . . . . . .18-20

sign-up information changes . . . .30

sounds and music setup . . . . . . .31

specifications . . . . . . . . . . . . . . .37

storage icon . . . . . . . . . . . . .24, 25

s-video out jack . . . . . . . . . . . . . .9

table of contents . . . . . . . . . . . . .7

tel(ephone) line jack . . . . . . . . . . .9

telephone line connections . . . . .12

text size setup . . . . . . . . . . . . . .30

title bar . . . . . . . . . . . . . . . . . . . .11

tv connections

audio/video jacks . . . . . . . . .15

rfu adapter . . . . . . . . . . . . . .14

s-video out jack . . . . . . . . . .13

vcr . . . . . . . . . . . . . . . . . . . .15

tv/web button . . . . . . . . . . . . . . .10

vertical sliding door . . . . . . . . . . .9

video out jack . . . . . . . . . . . . . . . .9

webtv port . . . . . . . . . . . . . . . . . .9

weight . . . . . . . . . . . . . . . . . . . . .37

write icon . . . . . . . . . . . . . . .24, 26

IB8078B001

ACCESSORIES

To order an accessory, write to:

Philips Service Solutions Group

P.O. Box 967

Greeneville, TN 37744-0967

Or, call 1-888-813-7069.

The following accessories are not included with your product, but are available from Philips Consumer
Electronics Company:

◆ EXT channel 3/4 RFU Adapter
Use this adapter when connecting the Internet Terminal to a television that does not have
Audio/Video jacks.
Model number MRF200BK

◆ S-Video Cable
Use this cable to connect the S-VIDEO OUT jack on the Internet Unit to the S-VIDEO IN jack
on your television.
Part number 4835 395 17322

To order these items, contact Philips Service Solutions Group at the address listed below.

The following accessories are packed with your Internet Terminal. These accessories are provided to
help you use or set up your Internet Terminal.
If any of these items are not included, or if you need to replace an accessory, contact Philips Service
Solutions Group at the address listed below.

◆ Remote Control
Part number 4835 220 37002

◆ Two AAA Batteries
Part number 4835 138 17001

◆ AC Power Cord
Part number 4835 220 37013

◆ Phone Cable
Part number 4835 220 37018

◆ Video Cable
Part number 4835 322 67002

◆ Audio Cables
Part number 4835 322 57002

◆ T-splitter
Part number 4835 220 37019

◆ Wireless Keyboard
MWK122
