User guide
SMART. VERY SMART.
MAS65
MP3 MINI HI-FI SYSTEM
1
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
ATENCIÓN
El uso de mando o ajustes o la
ejecucción de métodos que no sean
los aquí descritos puede ocasionar
peligro de exposición a radiación.
Cuidado
A utilização de comandos ou ajustes
ou a execução de procedimentos
diferentes dos descritos neste manual
podem provocar uma exposição a
radiações perigosas ou outras
operações inseguras.
2
PUSH
1
#
@
!
0
9
STANDBY-ON
2
3
4
5
6
7
8
3
4
Index
English ------------------------------------------------ 6
Español --------------------------------------------- 25
Português ------------------------------------------ 46
5
Contents
English
General Information
Supplied accessories ............................................ 7
Environmental information ................................ 7
Maintenance .......................................................... 7
Safety information ................................................ 7
Controls
Controls on the system ...................................... 8
Remote control .................................................... 9
Installation
Rear connections ......................................... 10-11
Speakers connection
Antennas connection
Connecting an additional appliance
Using AC power ................................................. 11
Inserting batteries into the remote control. 12
Setting the clock ................................................. 12
Basic Functions
Switching on/to standby and
selecting functions .............................................. 13
Volume control ................................................... 13
MUTE .................................................................... 13
Sound control ..................................................... 13
DSC (Digital Sound Control)
DBB (Dynamic Bass Boost)
Ta pe Operation/Recording
Loading tapes ...................................................... 19
Playing tapes ........................................................ 19
To playback a selected tape
Continuous playback of two tapes
General information on recording ................. 19
Preparation for recording ................................ 19
One touch recording......................................... 20
Sychro start CD recording .............................. 20
Dubbing tapes ..................................................... 20
AUX/SLEEP/RESET
AUX(Listening to an external source) .......... 21
SLEEP .................................................................... 21
RESET ............................................................. 21
Specifications ........................................... 22
Tr oubleshooting .............................. 23-24
Disc Operation
Discs for playback .............................................. 14
About MP3
Playing discs ......................................................... 14
Selecting and searching ..................................... 15
Selecting a different track
Finding a passage within a track
Programming tracks ........................................... 15
To review the program
Erasing the program
Different play modes: REPEAT, SHUFFLE ...... 16
Display information............................................ 16
Radio Reception
Tuning to radio stations .................................... 17
Changing AM tuning grid .................................. 17
Storing preset radio stations ..................... 17-18
To listen to a preset station
6
General Information
Supplied accessories
–2 speaker boxes
– remote control
– AM loop antenna
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Maintenance
Cleaning the Cabinet
● Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
● When a disc becomes dir ty,
clean it with a cleaning cloth.
Wipe the disc from the center
out.
● Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic
spray intended for analog records.
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
Cleaning the Heads and the Tape Paths
● To ensure good recording and playback quality,
clean the heads A and B, the capstan(s) C,
and pressure roller(s) D after every 50 hours
of tape operation.
● Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
● You can also clean the heads by playing a
cleaning tape once.
Demagnetizing the heads
● Use a demagnetizing tape available at your
dealer.
Safety information
● Place the system on a flat, hard and stable
surface.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers table-cloths, curtains, etc.
● The apparatus shall not be exposed to dripping
or splashing.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
7
Controls (illustrations on page 3)
English
Controls on the system (Top and
front panels)
1
0PUSH
– push to open the disc door.
2 REMOTE SENSOR
– sensor for the infrared remote control
Helpful hints: Always point the remote control
towards this sensor.
3 DSC (DIGITAL SOUND CONTROL)
– selects predefined sound settings: ROCK,
JAZZ, POP, CLASSIC.
4 DBB (Dynamic Bass Boost)
– turns the bass enhancement on/off
5 VOLUME rotary
– adjusts the volume
6 4 / ¢
CD/MP3: ............ skips or searches tracks/passage
backward/forward.
TUNER: .............. tunes to radio stations.
CLOCK: .............. sets the hour/minute.
Ç
CD/MP3: ............ stops playback; erase a program
SHUFFLE/PRESET -
CD/MP3: ............ plays a disc in random order
TUNER: .............. selects a preset radio station
REPEAT/PRESET +
CD/MP3: ............. repeat a track, disc or a program
TUNER: .............. selects a preset radio station (up)
PROGRAM/CLOCK
CD/MP3: ............ programs tracks and reviews the
TUNER: .............. programs preset radio stations
CLOCK: .............. sets the clock time
(down)
program
7 Ta p e deck 1/2
8 Tape deck keys
RECORDâ starts recording (for TAPE 1
only)
PLAY £ ......... star ts playback
REWà / F. FWD á ..... fast rewinds/
........................ winds a tape
STOP•OPEN 70 ............ stops playback; opens
........................................................... the tape holder
PA USEÅ
TAPE 1: interrupts playback or recording
TAPE 2: interrupts playback
8
nn
9
n
nn
– 3.5 mm headphone socket
Helpful hints:
– Adjust the volume to a moderate level
before you plug in the headphones.
– Connecting headphones will switch off the
speakers.
0 SLEEP
– adjusts/switches off the sleep timer
! STEREO/MONO
– selects stereo or mono FM reception
@ Source buttons
AUX
– selects the input from an additional connected
appliance
TUNER (FM•AM)
–select tuner source and toggles between the
wavebands : FM or AM(MW)
CD /ÉÅ
– selects CD/MP3 source; starts or pauses CD/
MP3 playback
TAPE
– selects tape source
DISPLAY
– MP3 only: displays disc information
# STANDBY-ON
– switches the system on or to standby mode.
– switches off the sleep timer.
Controls
Remote control
AUX
1
2
STANDBY-ON
TUNER
MUTE
TAPE
CD/
#
@
3
4
5
6
7
SHUFFLE
PRESET
ALBUM
1
4
7
9
REPEAT
PROG
CLOCK
DSC
2
3
6
5
8
VOL
0
!
0
9
8
1 STANDBY-ON
– switches the system on or to standby mode
2 Source buttons
TUNER (FM•AM)
–select tuner source and toggles between the
wavebands : FM or AM(MW)
CD /ÉÅ
– select CD/MP3 source; starts or pauses CD/MP3
playback
TAPE
– selects tape source
3 4 / ¢
– CD/MP3: skips or searches tracks/passage
backward/forward
– TUNER: tunes to radio stations
– CLOCK: sets the hour/minute
4 SHUFFLE/PRESET -
– CD/MP3: plays a disc in random order
– TUNER: selects a preset radio station (down)
5 REPEAT/PRESET +
– CD/MP3: repeat a track, disc or a program
– TUNER: selects a preset radio station (up)
6 ALBUM 5 / ∞
– MP3: selects albums (up, down)
7 DIGITS 0 - 9
– CD/MP3: selects a track/album number
– TUNER: selects a preset station
8 VOL 5 / ∞
– adjusts the volume
9 DSC
– selects predefined sound settings: ROCK,
JAZZ, POP, CLASSIC
0 PROG/CLOCK
– CD/MP3: programs tracks and reviews the
program
–Tuner: programs preset radio stations
– CLOCK: sets the clock time
! Ç
– CD/MP3: stops playback; erase a program
@ AUX
– selects the input from an additional connected
appliance
# MUTE
– switches the sound off temporarily
9
Installation
1
2
English
FM wire antenna
AM loop antenna
Speaker
(right)
Rear connections
Warning:
Never make or change connections with
the mains supply switched on.
A Speakers connection
Use the supplied speakers only. Using other
speakers can damage the set or the sound
quality will be negatively affected.
● Connect the cables of the left speaker to L (red
and black) and the cables of the right speaker to
R (red and black) as follows:
Speaker
(left)
AC power cord
Open the clip of the black terminal and fully
insert the stripped portion of the black (or
unmarked) speaker cable into the socket, then
close the clip.
B Antennas Connection
AM (MW) antenna
1 Unfold the loop antenna and if necessar y, use
screws (not supplied)to fix it to a flat, hard and
stable place:
Open the clip of the red terminal and fully
insert the stripped por tion of the coloured (or
marked) speaker cable into the socket, then
close the clip.
10
2 Fit the plug of the loop antenna to AM
ANTENNA as shown below.
3 Adjust the antenna for optimal reception
(as far as possible from a TV, VCR or radiation
sources)
Installation
FM antenna
1 Extend the wire antenna and move the antenna
in different positions for optimal reception (as far
away as possible from the TV, VCR or other
radiation sources).
2 Fix the antenna’s end to the wall.
C Connecting an additional appliance
It is possible to use an additional appliance, e.g.
TV, VCR, Laser Disc player, DVD player or CD
recorder, with the system.
1 Insert the red plug of the red/white audio cables
(not supplied) to the red socket AUX IN R and
the white plug to the white socket AUX IN L.
2 Connect the other end of the audio cables to
the AUDIO OUT terminals of the additional
appliance.
Helpful hints:
– If the connected device has only a single audio
out terminal, connect it to the AUX IN left terminal.
Alternatively, you can use a “single to double” cinch
cable, but the output sound still remain mono.
– Always refer to the owner’s manual of other
equipment for complete connection.
Using AC power
1 If your system is equipped with a VOLTAGE
SELECTOR, set this selector
to your local power voltage if
necessary.
2 Make sure all connections
have been made before
switching on the power supply.
3 Connect the power cable supplied to
AC MAINS ~ and to the wall socket. This
switches on the power supply.
When the system is switched to standby, it is still
consuming some power. To disconnect the
system from the power supply completely,
remove the power plug from the wall
socket.
The type plate is located on the rear of the
set.
11
Installation
English
Inserting batteries into the
remote control
Insert two batteries type R03 or AAA into the
remote control with the correct polarity as
indicated by the "+" and "-" symbols inside
the battery compar tment.
1
2
3
CAUTION!
– Remove batteries if they are
exhausted or will not be used for a long
time.
– Do not use old and new or different
types of batteries in combination.
– Batteries contain chemical substances,
so they should be disposed off properly.
Setting the clock
The time is displayed using the 24-hour clock.
1 Check the system is switched to standby mode.
(see Basic Functions, Switch on/to
standby)
➜ 0: 00 flashes by default if the clock is not set.
2 Press and hold PROGRAM/CLOCK for more
than 2 seconds.
➜ The hour digit star ts flashing.
3 Hold down or press 4 or ¢ repeatedly to
set the hour. Release 4 or ¢ when you
have reached the correct setting.
4 Press PROGRAM/CLOCK to confirm the
setting.
➜ The minute digit star ts flashing.
5 Repeat step 3 to set the minute.
6 Press PROGRAM/CLOCK to confirm the
setting.
➜ The clock shows the set time.
12
STANDBY-ON
TUNER
SHUFFLE
AUX
CD/
PRESET
REPEAT
ALBUM
MUTE
TAPE
PROG
CLOCK
DSC
Helpful hints:
–You may lose your clock setting when the power
cord is disconnected or power failure occurs.
Basic Functions
STANDBY-ON
Switching on/to standby and
selecting functions
1 Press STANDBY-ON to switch on.
➜ The display lights up blue.
➜ The system switches to the last source
selected.
2 To select your function, press TUNER.
CD /ÉÅ or TA P E .
3 Press STANDBY-ON to switch the system to
standby.
➜ The clock is displayed.
STANDBY-ON
TUNER
AUX MUTE
CD/
TAPE
IMPORTANT!
– Adjust the volume to a moderate level
before you switch the system to standby
mode.
Helpful hints:
– In the standby mode, the tone, sound settings,
tuner presets, and the volume level will be
retained in the system’s memory.
Volume control
1 Check the system is switched on.
2 Adjust the volume with VOLUME rotary (on
the remote control, press VOL 5/∞).
➜ Display shows and a number from 01 -
39 ( : the lowest volume and : the
highest volume)
IMPORTANT!
– Adjust the volume to a moderate level
before you switch the system to standby
mode or plug in the headphones.
MUTE
During playback, you can temporarily switch off
the sound without switching off the set.
1 On the remote control, press MUTE to
switch off the sound.
➜ Display shows MUTE.
Playback continues without sound.
2 To switch on the sound, press MUTE again or
adjust the volume with VOLUME rotary (on
the remote control, press VOL 5/∞).
AUX
PRESET
ALBUM
MUTE
TAPE
CD/
PROG
CLOCK
REPE AT
DSC
2
3
6
5
8
VOL
0
STANDBY-ON
TUNER
SHUFFLE
1
4
7
9
Sound control
DSC (Digital Sound Control)
Digital Sound Control enables you to select
predefined sound settings.
● Press DSC repeatedly to select your desired
sound setting:.
➜ ROCK, JAZZ, POP or CLASSIC is
displayed.
DBB (Dynamic Bass Boost)
● On the system, press DBB once or more to
turn bass enhancement on or off .
➜ DBB appears when DBB is activated.
Helpful hints:
– Some discs or tapes might be recorded in high
modulation, which causes a distortion at high
volume. If this occurs, switch off DBB or reduce the
volume.
13
PUSH
Disc Operation
English
Discs for playback
With this system, you can play
– all pre-recorded audio CDs (CDDA)
– all finalized audio CD-Rs and CD-RWs
– MP3-CDs (CD-Rs/CD-RWs with MP3 files)
IMPORTANT!
– This system is designed for regular
discs. Therefore, do not use any
accessories such as disc stabilizer rings or
disc treatment sheets, etc.
– CDs encoded with copyright
protection technologies by some record
companies may be unplayable by this
system.
About MP3
The music compression technology MP3
(MPEG1 Audio Layer 3) significantly reduces the
digital data of an audio CD while maintaining CD
quality sound.
● Getting MP3 files: you can either download
legal music files from the Internet to your
computer hard disc, or create such files by
converting audio CD files in your computer
through appropriate encoder software.
● Creating a MP3 CD: burn the music files
from your computer hard disc on a CD-R or
CD-RW using your CD burner.
IMPORTANT!
– Make sure that the file names of MP3
files end with .mp3.
– For a disc with CD Audio tracks and
MP3 files, only the CD Audio tracks will
be played.
– Some MP3 files may be unplayable,
depending on the encoding software.
Playing discs
1 Press STANDBY-ON to on, then press CD /
ÉÅ to select CD.
2 Press 0PUSH to open the disc door.
➜ Display shows .
3 Insert a CD/CD-R(W) with the printed side
facing up and press the CD door gently close.
➜ is displayed as the player scans
the contents of a disc.
– MP3-CDs may take more than 10 seconds to
read.
➜Audio CD: the total number of tracks and
the total playing time are displayed.
MP3-CD: the total numbers of albums and
tracks are displayed.
Supported formats:
– Disc format ISO9660, and single-session CDs.
– Max. albums: 25; Max. titles/tracks: 255
– Directory nesting up to a maximum of 8 levels
– Bit rate: 128 kbps bit is recommended
The system will not play or support the
following:
– Empty albums: an empty album is an album
that does not contain MP3 files
– Recordings created on Package Writing.
14
4 Press CD /ÉÅ to start playback.
➜Audio CD: current track number and
elapsed playing time.
MP3-CD: the display shows briefly current
album and track number, and then current track
number and elapsed playing time.
Disc Operation
5 To pause playback, press CD /ÉÅ.
Press CD /ÉÅ to resume playback.
6 To stop playback, press STOPÇ.
Helpful hints: CD playback will also stop when:
– you open the CD compartment;
– you select TUNER or TAPE;
– the CD has reached the end.
Selecting and searching
Selecting a different track
Audio CD:
● Either briefly press 4 or ¢ once or several
times to skip to the beginning of the current,
previous or subsequent track.
or
Use the digit keys on the remote control to
select the track number directly. e.g.
Tr ack 3: Press 0 and then, 3
Tr ack 10: Press 1 and then, 0
● In the pause/stop position, press CD /ÉÅ to
start playback.
MP3-CD:
1 On the remote control, first press ALBUM 5 /
∞ once or more to find your album.
2 Briefly press 4 or ¢ once or several times
to skip to the beginning of the current, previous
or subsequent track.
To use the digit keys on the remote
control:
1 In the stop position, press 0 on the remote
control.
➜ Display shows . -- flashes for you to
enter the desired album number.
2 Use the digit keys on the remote control to
select the album number directly. e.g.
Album 3: Press 0 and then, 3
Album 10: Press 1 and then, 0
➜ Playback starts from the 1st track in the
selected album.
3 To select a track in the album, press 0 again on
the remote control.
➜ Display shows . -- flashes for you to
enter the desired track number.
4 Use the digit keys on the remote control to
select the track number directly.
Finding a passage within a track
1 During playback, press and hold 4 or ¢.
➜ The CD plays at a high speed.
2 When you recognize the passage you want,
release 4 or ¢.
➜ Normal playback resumes.
Helpful hints:
– In SHUFFLE mode, press
beginning of current track.
4
to return to the
Programming tracks
You may store up to 32 tracks in the desired
sequence. If you like, store any track more than
once.
1 In the stop position, press PROGRAM/
CLOCK to activate programming.
➜ Display shows PR:01, indicating the star t of
the program. PROG appears.
2 Press 4 or ¢ to select your desired track.
MP3-CD only:
On the remote control, first press ALBUM 5 /
∞ once or more to find your album.
3 Press PROGRAM/CLOCK to store the
desired track number.
➜ Display shows PR:02 (up to 32 in sequence),
indicating the next program location available.
4 Repeat steps 2 to 3 to select and store all
desired tracks in this way.
➜ Display shows FULL if you try to program
more than 32 tracks.
5 To play your program, press CD /ÉÅ.
To review the program
● In the stop position, press repeatedly
PROGRAM/CLOCK to see your stored track
numbers.
➜ Display first shows the number of program
location and then, track/album number stored
here.
15
Disc Operation
English
Erasing the program
● You can erase the contents of the memory by:
– Opening the CD door;
– Pressing STOPÇtwice during playback and
once in the stop position.
➜ Display shows , PROG disappears.
STANDBY-ON
AUX MUTE
TUNER
PRESET
SHUFFLE
ALBUM
CD/
REPEAT
TAPE
PROG
CLOCK
DSC
Different play modes: REPEAT,
SHUFFLE
You can select and change the various play
modes before or during playback, and combine
the REPEAT modes with PROG.
REPEAT – plays the current track continuously.
REPEAT ALL – repeats the entire disc/
program.
SHUFFLE – tracks of the entire disc are played
in random order.
SHUFFLE REPEAT ALL – repeats the entire
disc in random order.
3 To return to normal playback, press REPEAT/
PRESET + or SHUFFLE/PRESET -
repeatedly until the various modes are no longer
displayed.
➜ You can also open the CD door to cancel
your play mode.
Helpful hints:
– In PROG mode, you will exit the program by
pressing SHUFFLE. To return to the program, press
PROGRAM/CLOCK in the stop position.
– SHUFFLE mode is cancelled if you press
PROGRAM/CLOCK in the stop position.
– In SHUFFLE mode, use of the digital keys
is void (e.g. 0, 3 on the remote control).
Display information
(MP3-CD only)
The ID3 tag is part of an MP3 file and contains
various track information such as the track’s title
or the artist’s name.
● During playback, press repeatedly DISPLAY on
the system to view ID3 tag information or
select your display mode.
1 To select play modes, press once or more
REPEAT/PRESET + or/ and SHUFFLE/
PRESET -.
2 Press CD /ÉÅ to star t playback if in the stop
position.
16
Helpful hints:
– Complete the ID3 tag information with your
MP3 encoder software before burning the
MP3-CD.
Radio Reception
Tuning to radio stations
1 Press STANDBY-ON to on, then press
TUNER to select TUNER mode.
➜ Display shows: the waveband and radio
station frequency
➜ If programmed, the display interchangeably
shows the program location and the waveband/
radio station frequency. PROG appears.
2 Press TUNER once or more to select your
waveband: FM or AM (MW).
3 Press and hold 4 or ¢ until the frequency
in the display starts running.
➜ The radio automatically tunes to a station of
sufficient reception.
➜ If a FM station is received in stereo,
STEREO is shown.
4 Repeat step 3 if necessary until you find the
desired radio station.
● To tune to a weak station, press 4 or ¢
briefly and repeatedly until optimal reception is
found.
● To tune to a weak FM station, press STEREO/
MONO on the system once or more until
STEREO disappears.
Changing AM tuning grid
In North and South America the frequency step
between adjacent channels in the AM band are
10 KHz. In the rest of the world this step is
9 KHz. Usually the frequency step has been
preset in the factory for your area if not :
1 Check the system is switched to standby mode.
(see Basic Functions, Switch on/to
standby)
2 Press and hold STANDBY-ON until the display
shows10 kHz or 9 kHz.
Helpful hints:
– All preset AM stations will be lost and need to be
reprogrammed.
Storing preset radio stations
You can store up to 40 preset r adio stations in
the memory (24 FM and 16AM).
1 Tune to your desired radio station (see “Tuning
to radio stations”).
2 Press PROGRAM/CLOCK to activate
programming.
➜ Display shows: PROG and current radio
frequency. -- -- flashes for you to enter a preset
number.
STANDBY-ON
17
Radio Reception
English
3 Press REPEAT/PRESET + or SHUFFLE/
PRESET - to select a preset number.
Or
Press digits 0 - 9 on remote control to select a
preset number e.g.
Preset 3: Press 0 and then, 3
Preset 10: Press 1 and then, 0
4 Press PROGRAM/CLOCK to confirm.
5 Repeat steps 1-4 to store other stations.
Helpful hints:
–You can erase a preset station by storing
another frequency in its place.
To listen to a preset station
● Press REPEAT/PRESET + or SHUFFLE/
PRESET - once or more until the desired
preset station is displayed.
Or
Press digits 0 - 9 on remote control to select
the desired preset station. e.g.
Preset 3: Press 0 and then, 3
Preset 10: Press 1 and then, 0
18
Ta pe Operation / Recording
IMPORTANT!
– Before playing a tape, check and
tighten slack tape with a pencil. Slack
tape may jam or burst in the mechanism.
– C-120 tape is extremely thin and is
easily deformed or damaged. It is not
recommended for use in this system.
– Store the tapes at room temperature
and do not put them too close to a
magnetic field (for example, a
transformer, TV or speaker).
Loading tapes
1 Press STANDBY-ON to on, then press TAPE
to select TAPE mode.
➜ Display: shows TAPE.
2 Press STOP•OPEN 70 to open the tape
deck door.
3 Load the tape with the open side downward and
full spool to the left.
4 Close the tape deck door.
Playing tapes
To playback a selected tape
● Press PLAY £ on tape deck 1 or 2.
➜ The tape will stop at the end of playback..
Helpful hints:
– During playback, the keys are automatically
released at the end of a tape and the set is
switched off (unless PAUSEÅ has been activated).
– During fast forwarding/rewinding, the keys will
not be released at the end of a tape. To stop fast
winding, press STOP•OPEN 70.
General information on
recording
● For recording, use only tape of IEC type I
(normal tape).
● The recording level is set automatically, regardless
of the position of the Volume, DBB, DSC and so
for th.
● The tape is secured at both ends with leader
tape. At the beginning and end of the tape,
nothing will be recorded for six to seven
seconds.
● To prevent accidental recording, break out the
tab on the left shoulder of the tape side you
want to protect.
Continuous playback of two tapes
1 Load the tapes in tape deck 2 and 1.
2 Press PLAY £ on tape deck 2.
3 On tape deck 1, press PA USEÅ and then,
PLAY £.
➜ Playback will begin from tape deck 2 and
continue with tape deck 1. It will stop at the end
of tape deck 1.
4 To pause playback, press PA USEÅ. To resume
playback, press PA USEÅ again.
5 By pressing REWà / F. FWD á , fast
winding of the tape is possible in both directions.
6 To stop the tape, press STOP•OPEN 70.
IMPORTANT!
– Recording is permissible if copyright
or other rights of third parties are not
infringed upon.
– Recording is possible only on tape
deck 1.
19
Ta pe Operation / Recording
English
Preparation for recording
1 Load a recordable tape into tape deck 1 with full
spool to the left.
2 Prepare the source to be recorded.
CD – load a disc.
TUNER – tune to the desired radio station.
TAPE – load the prerecorded tape into tape
deck 2 with the full spool to the left.
AUX – connect an external audio appliance.
One touch recording
1 Press CD, TUNER or AUX to select the
source.
2 Start playback of the selected source.
3 Press RECORDâ on tape deck 1 to start
recording.
To stop recording
● Press STOP•OPEN 70 on tape deck 1.
Helpful hints:
– When recording from AM (MW) radio stations,
adjust BEAT CANCEL to 1 or 2, if necessary, to
reduce interference.
Synchro start CD recording
1 Press CD source and if necessary, stop CD
playback.
● If desired, program track numbers.
2 Press RECORDâon tape deck 1 to start
recording.
➜ Playing of the CD/program star ts
automatically from the beginning. It is not
necessary to star t the CD player separately.
To stop recording
● Press 70 on tape deck 1
Dubbing tapes
1 Load the prerecorded tape in tape deck 2.
● Make sure both tapes have their full spool to the
left.
2 On tape deck 1, press PAUSEÅ and then,
RECORDâ.
3 Press PLAY £ on tape deck 2.
➜ Recording star ts.
● Dubbing of tapes is possible on one side of the
tape only. To continue recording on the rever se
side, at the end of side A, flip the tape to side B
and repeat steps 1-3.
20
To stop dubbing
● Press 70 on tape deck 1 and 2.
Helpful hints:
–To ensure good dubbing, use tapes of the same
length.
AUX/ SLEEP/RESET
STANDBY-ON
AUX ((Listening to an external
source)
You can listen to the sound of the connected
external device through your system’s speakers.
1 Check the external device has been properly
connected. (See Installation, Connecting an
additional appliance)
2 Press STANDBY-ON to on, then press AUX
to select AUX mode.
➜ Display shows:
3 To avoid noise distortion, turn down the volume
on your external device.
4 Press the PLAY key on the connected device to
start playback.
5 To adjust the sound and volume, use the sound
controls on your external equipment and the
MAS 65.
SLEEP
You can set a cer tain period of time after which
the system will switch to standby.
● On the system, press SLEEP repeatedly to
select the desired time period options (in
minutes):
➜ Display shows in sequence: SLEEP: 10, 20,
30, 40, 50, 60, 70, 80, 90, 00.
➜ Display shows the selected option briefly and
returns to its previous status.
To deactivate the sleep timer, press SLEEP until
SLEEP 00 is display or press STANDBY-ON
to switch the system to standby.
Reset
If desired, you can restore your system to its
default setting.
1 Check the system is switched on or to standby
mode (see Basic Functions, Switch on/to
standby)
2 Use a ballpoint pen to press the RESET.
➜ 0: 00 flashes.
➜ The system is restored to its default setting.
RESET
21
Specifications
English
AMPLIFIER
Output power ....................................... 2 x 20 W RMS
Signal-to-noise ratio .......................... ≥ 67 dBA (IEC)
Frequency response .......................... 50 – 15000 Hz
Impedance loudspeakers ......................................... 6 Ω
Impedance headphones ....................32 Ω -1000 Ω
(1) (6Ω, 60 Hz – 12.5 kHz, 10% THD)
CD PLAYER
Number of programmable tracks ......................... 32
Frequency range .................................. 20 – 20000 Hz
Signal-to-noise ratio ....................................... ≥ 50 dBA
Channel separation ........................... ≥ 25dB (1 kHz)
Total harmonic distortion ..................................... < 3%
TUNER
FM wave range ......................... 87.50 – 108.00 MHz
AM (MW)wave range .................... 520 – 1710 kHz
(tuning grid: 9K).................................. 531 – 1602 kHz
(tuning grid: 10K) ............................... 530 – 1710 kHz
Number of presets ........................................................ 40
Antenna
FM ............................................................. Wire antenna
AM............................................................ Loop antenna
TAPE DECK
Frequency response
Normal tape (type I) ...... 50 – 10000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) ................................ ≥ 48 dBA
Wow and flutter .......................................≤ 0.35% DIN
GENERAL INFORMATION
Material ..............................................................Polystyrene
AC Power ........................... 110 -127 V / 220 - 240 V
60 / 50 Hz switchable
Power Consumption
Active ......................................................................... 50 W
Standby .....................................................................≤ 7 W
Dimensions (w x h x d)
...................................................... 10.5 x 11.7 x 10 (inch)
...................................................... 267 x 298 x 254 (mm)
Weight (without speakers).................. 10.8 pounds
............................................................................................ 4.9 kg
Specifications and external appearance are
subject to change without notice.
SPEAKERS
System .................................... double por t bass reflex
Impedance ........................................................................ 6 Ω
Woofer .................................................... 1 x 4" full range
Dimensions (w x h x d)
........................................................ 7.2 x 11.3 x 9.7 (inch)
...................................................... 193 x 286 x 246 (mm)
Weight..................................................... 6.4 pounds each
................................................................................ 2.9 kg each
22
Tr oubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will
invalidate the warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If
you are unable to remedy a problem by following these hints, consult your dealer or
Philips for help.
Problem
is displayed
The disc cannot be read
Sound cannot be heard or is of poor
quality.
The left and right sound outputs are
reversed.
The disc skips tracks
Sound skips during MP3 playback
Solution
✔ Insert a suitable disc.
✔ Check if the disc is inserted upside down.
✔ Wait until the moisture condensation at the lens
has cleared.
✔ Replace or clean the disc, see “Maintenance”.
✔ Use a finalized CD-RW or CD-R.
Note:
– Make sure the CD is not encoded with Copyright
protection technologies, as some do not conform to
the Compact Disc standard.
–A CD badly scratch or dirty may result in
improper operation.
✔ Adjust the volume.
✔ Disconnect the headphones.
✔ Check that the speakers are connected correctly.
✔ Check if the stripped speaker wire is clamped.
✔ Switch off MUTE.
✔ Check the speaker connections and location.
✔ Replace or clean disc
✔ Switch off SHUFFLE/PROG.
Note: For a disc with CD Audio tracks and MP3
files, only the CD Audio tracks will be played.
✔ MP3 file made at compression level exceeding
320kbps. Use a lower compression level to
record CD tracks into MP3 format.
✔ Replace or clean disc.
Radio reception is poor
✔ If the signal is too weak, adjust the antenna or
connect an external antenna for better
reception.
✔ Increase the distance between the Mini HiFi
System and your TV or VCR.
23
Troubleshooting
English
Poor cassette sound quality/ Recording
cannot be made.
The system does not react when buttons
are pressed.
The remote control does not function
properly.
The Clock setting is erased.
✔ Clean deck parts, see “Maintenance”.
✔ Use only NORMAL (IEC I) tape.
✔ Apply a piece of adhesive tape over the missing
tab space.
✔ Reset the system (see RESET chapter),
✔ Reduce the distance between the remote
control and the system.
✔ Insert the batteries with their polarities
(+/– signs) aligned as indicated.
✔ Replace the batteries.
✔ Point the remote control directly towards the IR
sensor.
✔ Power has been interrupted or the power cord
has been disconnected. Reset the clock/timer.
24
Loading...
