Page 1
The LTC 0330 Series are compact,
rugged, 1/3-inch image format
monochrome CCD cameras.Their
high sensitivity and reliability provide
optimal performance in all
environments.
Both the CCIR and EIA RS-170
versions are available for direct mains
voltage supply and ac/dc low voltage
supply. Each offering wide power
supply voltage range allowing flexible
installation. These cameras are
provided with a standard CS-mount
for use with a wide variety of lenses.
They can be used with fixed iris lenses,
manual iris lenses, DC-iris lenses, and
video-iris lenses.
Their excellent scene reproduction is
supported by back-light compensation.
With user selectable backlight
compensation, the camera responds to
the average content of the entire video
signal, or can be activated to establish
a central area for automatic light
control. If an object falls within this
area, the camera will automatically
adjust to set optimum contrast. This is
particularly useful in applications having
bright light such as doorways, loading
docks, windows, and ATMs (automatic
teller machines).
Enhanced picture quality and
outstanding reliability make them an
excellent choice for professional,
commercial, and industrial surveillance
systems in both indoor and outdoor
applications.
LTC 0330/x1 Series
Monochrome Cameras
■■
1/3-inch Format CCD
Imager
■■
High Sensitivity
■■
Standard Resolution
■■
Backlight Compensation
■■
Electronic Shutter
■■
Video and DC Iris
Control
■■
Line Lock With External
Phase Adjustment
■■
Models for mains supply
and AC/DC low voltage
Lens optional
Page 2
9498 962 32212 99-10
Ó
1999 Philips Electronics N.V.
Printed In U.S.A.
Ó
1999 Philips Communication & Security Systems Inc.
All Rights Reserved. Philips ñis a registered trademark of
Philips Electronics N.V.
Data subject to change without notice
SPECIFICATIONS
Electrical
Model No. Rated Voltage Voltage Range
CCIR Model
LTC 0330/11 24 VAC, 50 Hz 12 to 24 VAC
12 VDC 10.8 to 33 VDC
LTC 0330/51 230 VAC, 50 Hz 85 to 264 VAC
EIA RS-170 Model
LTC 0330/21 24 VAC, 60 Hz 12 to 28 VAC
12 VDC 10.8 to 39 VDC
LTC 0330/61 120 VAC 85 to 132 VAC
Power dissipation: <2.5 W for all models.
All /11 and /21 models operate on AC or DC.
Imager: Interline transfer CCD; 1/3-inch image format.
Active Picture Elements:
CCIR Models: 512 H x 582 V
EIA RS-170 Models: 512 H x 492 V.
Horizontal Resolution: 380 TVL.
Sensitivity (3200 K):
Usable Full
Picture (501RE) Video
Scene illumination1fc 0.015 0.05
lx 0.15 0.5
Imager illumination fc 0.002 0.007
lx 0.02 0.07
1. For f/1.2 lens,75% scene reflectance.
Signal-to-Noise: >50 dB minimum.
Electronic Shutter: Automatic, 1/60 to 1/100000.
AGC: 30 dB.
Backlight Compensation: Center window weighting for
AGC, electronic shutter and DC-iris.
Aperture Correction: Horizontal.
Video Output: 1.0 Vp-p, 75 ohm.
Synchronization:
Line-Lock (When powered by AC): Synchronizes camera to
power line zero crossing for roll-free vertical interval
switching.Vertical phase delay can be externally adjusted
to allow vertical synchronization in multiphase power
installations.
Free Running, when powered by DC.
Controls:
Phase Adjust Range: 300° (when powered by AC).
Backlight Compensation: On/Off.
Back-Focus: External adjustment.
Iris: DC/Video.
DC Iris Level: Low/High.
Automatic Electronic Shutter: On/Off.
Connectors:
Video Out: BNC.
Iris: 4-pin connector.
Power:
/11 and /21: Screw terminals, power supply input terminals
are isolated from video output terminals.
/51: Mains lead with 2-pin EURO connector
/61: Mains lead with 2-pin USA type connector.
Mechanical
Lens Mount: CS.
Camera Mounts: 1/4"-20 UNC, top and bottom.
Finish/Case: Mushroom/metal housing.
Dimensions:
Housing size: 121 L x 68 W x 49 H mm (4.76 x 2.68 x
1.93 in).
Including connectors and mounting block:: 130 L x 68 W x
59 H mm (5.12 x 2.68 x 2.32 in)
Weight: 0.49 kg (1.1 lb).
Environmental
Operating Temperature: -20 °C to +55 °C (-4 °F to
+131 °F).
Electromagnetic Compatibility
EMC Requirements:
CCIR Models: 89/336/EEC.
Immunity: EN50130-4.
Emission: EN50081-1 Class B.
EIA RS-170 Models: U.S.A. and Canada.
FCC Part 15, Class B.
ICES-003.
Safety:
CCIR Models: CE.
EIA RS-170 Models: UL & cUL.
Accessories
Lenses:
DC Voltage Control Iris:
LTC 3314/20: 2.8 mm, F1.2 to 90.
LTC 3334/20: 4 mm, F1.2 to 90.
LTC 3344/20: 8 mm, F1.2 to 90.
LTC 3364/20: 2.8-6 mm, F1.2 to close
LTC 3364/30: 3.5-8 mm, F1.4 to close.
Manual Iris:
LTC 3311/20: 2.8 mm, F1.2 to close.
LTC 3331/20: 4 mm, F1.2 to close.
LTC 3341/20: 8 mm, F1.2 to close.
LTC 3361/20: 2.8-6 mm, F1.2 to close
LTC 3361/30: 3.5-8 mm, F1.4 to close.
Power Transformers and Power Supplies:
Model No. Rated Input Rated Output
TC1323 120 VAC, 60 Hz 24 VAC, 10 VA
TC1334 120 VAC, 60 Hz 24 VAC, 30 VA
TC120PS 120 VAC, 50/60 Hz 15 VDC, 9 VA
TC220PS 220-240 VAC, 50/60 Hz 15 VDC, 9 VA
TC220PSX-24 220-240 VAC, 50/60 Hz 24 VAC, 20 VA
LDH 4466/11 230 VAC, 50 Hz 18 VAC, 10 VA
