Page 1
HL22M
Head light
Up to 300 lumens of brightness
Motion-sensing
Rechargeable
Impact-resistant casing
LPL74X1
See better, work better
Rechargeable motion-sensing LED headlamp
The lightweight Philips HL22M headlamp provides bright white light where you need it. Variable output, two
preset modes of up to 150 and 300 lumens, an integrated flash function plus the motion sensor make it a
versatile, hands-free tool.
Variable light output
Clear white 6500 K light
From 50 to 300 lumens
Two preset modes
Enhanced versatility
Motion-sensor mode
Rotating light module
Fast-charge, long-life battery
Rechargeable via micro USB
Top-quality finish
Comfortable headband
IK07 impact-resistant casing
IP67 splash and dust protected
Page 2
HL22M
LPL74X1
Highlights
Clear white 6500 K light
The Philips HL22M features a powerful white
light with a 110° beam angle. It i lluminates as
far as 70 metres ahead at up to 300 lumens in
Boost mode. The 6500 K light is easy on the
eye, i mproving visual comfort and reducing eye
strain for fatigue-free working.
From 50 to 300 lumens
Turn the side-mounted control to gradually
vary the output between 50 and 300 lumens.
This unique feature of the Phi lips HL22M
allows you to light every detail with pinpoint
precision, wherever you're working.
Two preset modes
Match the light intensity to your work needs by
turning the side-mounted knob or selecting
one of the two presets. If you want the
balanced mode, press the "M" button once and
enjoy 150 lumens of stable light. Press twice
for the Boost mode of 300 lumens. You also
can use the integrated flashing-li ght function
by pressing it for the third time.
Motion-sensor mode
The Philips HL22M comes with a motion-
sensor mode for hands-free use. This means
you can control the headlamp by waving your
hand in front of the sensor. To activate the
sensor mode, turn on your lamp, press the
motion-sensing button until the blue li ght on
the top-left corner illuminates and enjoy
hands-free control.
Rotating light module
The Philips HL22M headlight features a 45°
rotating light module to direct the light exactly
where you need i t and get the job done.
Fast-charge, long-life battery
The Philips HL22M headlight takes less than
three hours to fully charge. Wi th a battery
designed to last from 3 to 12 hours, it lets you
work a full day without interruption. Then
recharge overnight, ready to go again the next
day.
Rechargeable via micro USB
The Philips HL22M headlamp can be charged
by micro USB cable (included in the pack).
Comfortable headband
The Philips HL22M boasts an anti-slip elastic
headband which fi ts comfortably around your
head. The headband is easily adjustable and
comes with extra colour clips to ai d
identification when several head torches are in
use.
IK07 impact-resistant casing
We designed our Philips HL22M with a rubber
coating material for better grip and enhanced
durability. Conforming to international i mpact-
resistance standard IK07, the robust Phili ps
HL22M headlamp is built to withstand the
toughest working environments.
IP67 splash and dust protected
The Philips HL22M conforms to international
splash- and dust-resistance rating IP67. Built
to rigorous manufacturing standards with
multiple seali ng processes, your headlamp is
resistant to splashed water and protected from
dust.
Page 3
HL22M
LPL74X1
Specifications
Ordering information
Order entry: LPL74X1
Ordering code: 00824431
Electrical characteristics
Battery capacity: 1400 mAh
Wattage: 3 W
Battery run time (eco): up to 6 H at 150 lm,
12 H at 50 lm
Battery type: Li -ion battery
Charging cable type: 1 m Micro USB cable
Plug type: N ot included
Battery charging time: 2.8 hours
Power Source: 3.7 V, 1400 mAh
Voltage: 3.7 V (Battery)
Battery run time (boost): up to 3 H at 300 lm
Light characteristics
Beam angle: 110° degree
Colour temperature: 6500 K
LED lifetime: >10000 hrs
Light intensity (boost): 450 lux at 0.5 m
Light intensity (eco): 220 lux and 70 lux at
0.5 m
Light output (eco): 150 lumens and 50 lumens
Light output: 300 lumens
Outer pack information
Gross weight per piece: 1300 g
Height: 10.7 cm
Length: 19.8 cm
Width: 17 cm
Packaging Data
EAN1: 8719018008244
EAN3: 8719018008251
Packed product information
Height: 4.8 cm
Length: 9.5 cm
Pack Quantity / MOQ: 6
Weight with cable: 170 g
Width: 9.5 cm
Weight without batteries: 115 g
Size: Compact
Cable length: 1 m
Product description
Impact protection rating (IK): IK07
Ingress protection rating (IP): IP67
Magnet: No
Materials and finishing: Rubber
Operating Temperature: 0°C to 50 °C
Orientable light: 45° rotatable headlamp
Resistant to: grease, oil, workshop solvents
Technology: LE D
Range: Headlamp
Headband: Soft and anti-slip headband
Marketing specifications
Product highlight: Motion sensing headlamp
Expected benefits: See better, Work better
© 20 22 Philips Lig hting Holding B.V.
All Right s reser ved.
Specifications are subject to change
without notice. Trademarks are the
property of Philips Lig hting Holding
B.V. or their respective owner s.
Issue date 202 2‑0 3‑3 0
Version: 5.0.1
12 NC: 8670 001 71672
www.phili ps.com
