CBH52
Professional
32 high-quality LUXEON LEDs
Dual mode: cable and battery
1200 lm and 120° beam radius
Extends up to 2.08 metres
LPL73X1
See better, work better
Corded and cordless hybrid LED bonnet lamp
Mains or battery powered, the Philips CBH52 bonnet lamp offers three lighting levels up to 1200 lm, a 120° wide
beam radius, 360° rotatability and a mount extending up to 2.08 metres. Versatile, flexible bonnet lamp for cars,
trucks.
Powerful bright white light
32 top-quali ty LUXEON LE Ds
Three light-output options
Enhanced versatility
Telescopic extendable mount
Sliding light module
Extendable for all vehicles
Battery-status indicator
Long-lasting performance
120° wide beam angle
Long-life cordless battery
Enhanced durability
5 metres of robust cable
Robust aluminium housing
Water- and dust-protected
CBH52
LPL73X 1
Highlights
32 top-quality LUXEON LEDs
The Philips CBH52 hybrid professional bonnet
lamp features 32 powerful Lumileds LUXEON
LED s, providing an intense white li ght and a
bright wide beam in all conditions. Designed
to give you clear vision as you work, its natural
white light of up to 5500 Kelvin i s also gentle
on your eyes to prevent fatigue.
Three light-output options
The Philips CBH52 offers three useful power
modes. Boost mode gives you a powerful
1200 lumens of light, helping you spot even
the smallest of details. The balanced mode of
900 lumens allows you to see everything and
work comfortably for hours at a time. And if
you're using the lamp while unplugged for an
extended period, you can select the eco mode
to preserve battery life. At a reduced
500 lumens output you will still enjoy high-
quality bright light for up to 5 long hours.
Telescopic extendable mount
The Philips CBH52 is equipped with two
integrated telescopic hooks which are
extendable on both sides and can be rotated
through 360°. The hooks feature wider
openings and are covered with soft rubber for
easy attachment to the vehicle bonnet with no
worries about scratched paintwork.
Sliding light module
Thanks to the Philips CBH52 unique design,
you can slide the lighting module along the
mount to the area you want to illuminate. No
need to change the lamp angle when
repositioning the module.
Extendable for all vehicles
The Philips CBH52 bonnet lamp has a mount
that stretches from 1.1 to 2.08 metres, enabling
it to be used in a wide variety of locations.
Whether under the hood, roof or rear hatch of
any car, van or truck, this lamp has the
flexibility you need.
120° wide beam angle
See more with the Philips CBH52 's exceptional
120° wide beam angle. The broad beam of
bright light is distributed evenly across
the illuminated area, gi ving you the optimum
overview and lighting every detail with
pinpoint precision.
5 metres of robust cable
For extended periods of use, the Philips
CBH52 is equipped with a long, robust 5 metre
cable (100-240 V), providing continuous
lighting as you work. Just like the lamp itself,
the cable is built to survive tough workshop
environments and withstand chemicals such as
hydrocarbons.
Long-life cordless battery
Need to move around your workshop as you
work? No problem. Simply remove the cable
from the Phili ps CBH52. The long-life battery
provides you with up to 9 hours of continuous
cordless use in Eco mode (500 lumens).
Robust aluminium housing
Complying with international impact-
resistance standard IK07, the robust aluminium
housing of the Phili ps CBH52 is designed to
withstand tough working environments.
Because we know even the most careful
workers sometimes drop their tools.
Battery-status indicator
See when the battery needs charging. The
Phili ps CBH52 features a battery-status
indicator showing how long the work lamp can
function before the battery runs down
completely. Never again run out of power in
the middle of a job. The indicator also displays
the time remaining until the battery is fully
charged.
Water- and dust-protected
Phili ps CBH52 conforms to IP54 international
splash and dust resistance rating. Built to
rigorous manufacturing standards with multiple
sealing processes, your lamp is resistant to
splashed water and protected from dust.
CBH52
LPL73X 1
Specifications
Ordering information
Order entry: LPL73X1
Ordering code: 00521231
Electrical characteristics
Battery capacity: 5200 mAh
Wattage: 10 W
Voltage: 3.6 (Battery) V
Battery run time (eco): up to 4 h/ 9 00 lm and
5 h/500 lm
Battery type: Li -ion battery
Charging cable type: Cable and adapter
Plug type: 8.4 V 2 A output
Battery charging time: 3.2 hours
Power Source: 3.6 V, 5200 mAh
Battery run time (boost): up to 3 h/1200 lm
Light characteristics
Colour temperature: 5800 K
Light intensity (pointer): N/A
Light output (pointer): NA
Light intensity (boost): 1100 lux at 0.5 m
Light intensity (eco): 850 lux and 550 lux at
0.5 m,
LED lifetime: >10, 000 hours
Beam angle: 120°
Light output (eco): 900 lumens and
500 lumens
Light output: 1200 lumens
Beam angle (pointer): N/A
Outer pack information
Gross weight per piece: 1677 g
Height: 28.5 cm
Length: 119 cm
Width: 25 cm
Packaging Data
EAN1: 8719018005212
EAN3: 8719018005229
Packed product information
Cable length: 5 m
Diameter: NA cm
Pack Quantity / MOQ: 6
Weight with batteries: 940 g
Weight with cable: 1355 g
Weight without cable: 9 40 g
Size: Standard
Height: 11.8 cm
Length: 116 (folded), 208 (extended)
Width: 6 cm
Weight without batteries: NA
Product description
Hook: rotatable, 2 sides retractable
Impact protection rating (IK): IK07
Ingress protection rating (IP): IP54
Magnet: No
Materials and finishing: Aluminium plate
Number of LED s: 32 LUXEON LEDs
Resistant to: grease, oil, workshop solvents
Technology: LED
Headband: N/A
Operating Temperature: 0°C to 40°C
Range: CBH
Pointing light: NA
UV leak detector: No
Marketing specifications
Product highlight: Bonnet work lamp
Expected benefits: See better, Work better
Power consumption
Energy efficiency label: G
© 20 22 Philips Lighting Holding B.V.
All Right s reser ved.
Specifications are subject to change
without notice. Trademarks are the
property of Philips L ighting Holding
B.V. or their respective owne rs.
Issue date 202 2‑03 ‑24
Version: 9.0.1
12 NC: 8670 001 71771
