Page 1
features:
Travelling light
Travelling bright
X-lite
S-lite
technical specifications
800 ANSI lumens 800 ANSI lumens
XGA resolution SVGA resolution
Compact design - < 2 dm
3
Ultra lightweight just 1.3 kg
Easy plug&play
Digital picture enhancement
•
Dimensions;227 x 48 x 177 mm (WxHxD)
3
< 2 dm
Net weight 1.3 kg; ca 2.86 lbs
•
Advanced compatibility for both data and
•
video input; compatible with main notebook
computers
High contrast ratio; 800:1 (Full on/off)
•
Digital picture enhance technologies;
•
Digital Zoom (x10), Digital Freeze,Digital
Keystone correction
Intuitive Graphic User Interface (GUI) for
•
ease of use
Auto voltage for safe usage around the
•
world
Robust,reliable technical design
•
Suitable for meeting rooms for 2 to 20
•
people
Kensington lock
•
Free support:
• First Choice* support
• Free toll-free technical support*
DMD™ 1x 0.67" DMD™
Brightness 800 ANSI lumens
Contrast 800:1 (Full on/off)
Lamp New 130 W UHP lamp
Lens F3.0 ; f= 20.3 mm
Digital features Digital Zoom (x10), Digital Freeze, Digital Keystone correction
Input signals
Video
Data PC and Mac compatible, Multi scan VGA,SVGA,XGA, SXGA via high
Power in 110 - 120 V / 220 - 240 V (Full range); 50/60 Hz; 180 W
Input connections
Video
Data Mini sub-D data (15 pin)/PC Stereo Audio (M3.5 stereo jack) /
Mains Mains input socket (3 pin)
Specialities 48 mm Ultra Thin Profile
Dimensions 227x 48 x 177 mm (WxHxD); <2 dm3
Net weight 1,3 kg; ca 2,86 lbs
Package UGO LC5141/LC5131
Executions LC 5141/00 Global product in native XGA
Optional acc. New 130 W UHP lamp
LC5141 786,432 pixels,Time sequential (1024x768)
LC5131 480,000 pixels,Time sequential (800x600)
End user replaceable
1000 hours
Fixed Focal length; Manual Focus
Proj.Dist. 1,2 - 5,8m; Diagonal (42 - 200)"
NTSC 3.85, 4.43 /PAL -,N, M /Secam in 4:3 and 16:9 formats
advanced scaling technology.Auto image control
Hor. scan rate:15 - 91 kHz;Vert.Refresh rate 50 - 85 Hz.
S-Video (Y/C DIN)/Video (RCA)/ Stereo Audio (2x RCA)/ YCbCr
Serial mouse (9pin Mini DIN);USB port / PS/2
800 : 1 Contrast Ratio
Advanced compression technology for full automatic adjust multi scan
data input handling,VGA up to SXGA resolutions to full screen
Intuitive Graphic User Interface (GUI) for ease of use
Full plug&play compatible (DCC 1 / 2b)
Full Mirror function
Acoustical Noise <39 dBA
Remote Control + 2x AAA batteries
Power cord (1,8m) (2 cords,Continental Europe and USA)
VGA Cable (1m)
PC Audio cable
Mouse cable set; 1m, PS/2 ;1m,USB
Audio/Video RCA Cable (1m,Video/Audio stereo)
S-Video cable (1m)
Soft carrying bag
User Guide (8 languages - CD-Rom,plus Quick Reference Guide)
LC5131/00 Global product in native SVGA
Image diagonal size Projection distance
[inch] [meters] [inch] [meters]
37
60
80
100
120
150
200
0,94
1,52
2,03
2,54
3,05
3,81
5,08
47
79
106
134
161
201
268
1,2
2,0
2,7
3,4
4,1
5,1
6,8
3122 435 64820
Design and specifications are subject to change without notice
* Available in the US,Western Europe. Check with your dealer for similar coverage in other regions.
More information
www.pcstuff.philips.com/projectors
