Page 1

8VHUPDQXDO

Page 2

Page 3

Contents

4 Important Information

4 For your safety 4 Installation requirements 4 Need Help?

5 What’s in the box?

6 Your ID937

6 Overview of the handset 9 Overview of the base station 9 Main features of your ID937

11 Connect

12 Install

16 Call

20 Phonebook

25 Call log

27 SMS

35 Clock & Alarm

37 Personal Settings

42 Advanced Settings

48 Network Services

51 Games

52 Telephone Answering Machine (TAM)

58 Troubleshooting

61 Information

62 Index

Page 4

Important Information

For your safety

This equipment is not designed to make emergency calls in the event of a power failure. Alternative arrangements should be made for access to emergency calls.

To avoid damage or malfunction:

- Do not allow the product to come into contact with liquid.

- Do not open it as you could be exposed to high voltages.

- Never use any battery type other than the one supplied.

- Do not hold the handset too close to your ear when the phone is ringing or when activating the loudspeaker as it may damage your hearing.

- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.

- Do not drop your phone or allow objects to fall on your phone.

- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.

- Active mobile phones in the vicinity may cause interference.

About operating and storage temperatures:

- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).

- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).

- Battery life may be shortened in low temperature conditions.

Installation requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT installations defined in standard EN 60-950. In case of power failure, the communication can be lost.

The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical outlet is located close to the apparatus and is always easily accessible.

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the standard EN 60-950.

Need Help?

For more information on troubleshooting:

Troubleshooting: page 58

Please refer to the following website for more information on Philips web support:

Online Support

www.philips.com/support

Page 5

What’s in the box?

The following accessories are included with your ID937:

Handset

Splitter

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor to the line cord first before plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, chargers with power supply units and additional rechargeable batteries.

Base station

User Guide

Power supply for

base station

Quick Start

Guide

Line cord

Warranty card

2 AAA

rechargeable

batteries

Page 6

Your ID937

Overview of the handset

Event LED

(top of the handset)

LCD Screen

Left Soft key

Up/Down Navigation keys

Earpiece

Right Soft key

Talk key

Keypad lock key

Loudspeaker key

Microphone

Hang-up key

Alphanumeric keypad

Case key / Pause key / Ringer off key

Intercom key

Page 7

Handset keys

Press To

Enter the main menu from stand-by mode.

(Left soft key)

(Right soft key)

r e

Select the function displayed on the handset screen directly above it. Activate mute function during a call. Switch on the backlight.

Go to redial list from stand-by mode. Select the function displayed on the handset screen directly above it. Initiate a second call, consult phonebook, call transfer or activate/deactivate HD Sound

mode during a call.

Switch on the backlight.

Answer an incoming external or internal call. Insert R for operator services when on the line.

Hang up a call. Return to stand-by mode. Long press in stand-by mode to switch off the handset, short press to switch on the handset

again.

Access call log from stand-by mode. Scroll up a menu list or go to the previous phonebook or call log record. Increase earpiece volume during a call. Go to the previous character in editing mode.

Access phonebook from stand-by mode. Scroll down a menu list or go to the next phonebook or call log record. Decrease earpiece volume during a call. Go to the next character in editing mode.

Initiate an internal call.

Your ID937

Answer an incoming call in handsfree mode.

v #

Activate and deactivate the loudspeaker* during a call.

Dial # in stand-by mode.

Long press to mute the ringer in stand-by mode. Long press to insert a pause in dialling mode. Long press to switch between upper and lower case in editing mode.

Dial * in stand-by mode. Long press to activate and deactivate keypad lock.

Soft key

BACK

*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high

level. Make sure the handset is not too close to your ear.

Short press from menu browsing to return to the previous menu.

Page 8

Your ID937

Display icons & symbols

In stand-by mode, several icons & symbols may be displayed on the top row of the handset screen.

The handset is registered and within range of the base station. It blinks when the handset is out of range or is searching for a base.

Battery symbol indicating 3 different battery levels.

The ringer volume is set to zero.

The keypad is locked.

There is an external incoming call, an external call is connected or an external call is held.

HD Sound mode is activated.

There is an internal incoming call, an internal call is connected or an internal call is held.

The loudspeaker is ON.

Alarm clock is activated.

SMS reception is activated. It blinks when the memory for SMS is full.

Telephone answering machine (TAM) is activated. It blinks when the memory for answering machine messages is full.

Do not Disturb mode is activated.

When there are new events, such as new missed calls, new SMS, voicemail or answering machine messages received, the following icons, together with the number of occurrences are displayed in the middle of the handset screen.

If you have not subscribed to Caller Line Identification service, there will not be any alerts for the new events except for new messages recorded on the answering machine. Hence, no missed call, SMS, or voicemail event icons will appear in the middle of the handset screen.

There are new SMS messages received. The number of new SMS messages received is also displayed on the left of the icon.

There are new missed calls. The number of new missed calls is also displayed on the left of the icon.

There are new voicemail messages received. The number of new voicemail messages received is also displayed on the left of the icon.

There are new answering machine messages received. The number of new messages received is also displayed on the left of the icon.

Page 9

Your ID937

Overview of the base station

SIM card cover

Paging key

Main features of your ID937

The following is an overview of the menu options that are available in your ID937. For detailed explanation of the menu options, please refer to the corresponding sections in this User Guide.

Menu To Page

SMS Setup, write/read SMS, etc. 27

PHONEBOOK Add, edit, manage phonebook entries and copy phonebook

entries from SIM card.

CLOCK &

ALARM

PERSONAL SET Set Handset tone, Wallpaper, Contrast, Handset name, Auto

ADVANCED

SET

NET. SERVICE Set Call forwarding, Voice mail, Call back and Caller ID. 48

GAMES Play games 51

ANSWER

MACHINE

Set date and time, alarm, alarm tone and Do not Disturb mode.

Pick-up/Hang-up, Languages, Babysit mode, Backlight time and Theme Colour.

Set Recall time, Dial mode, Call barring, Baby call mode, Register/Unregister handset, Select Base, Change PIN, Reset phone, Auto prefix, Conference mode, HD Sound and Demo mode.

Setup, play, delete phone messages, record memo, etc. 52

Page 10

Your ID937

Menu navigation

The basic steps of navigating through the menus and options are as follows:

Task Action Illustration

Enter main menu/menu options Choose

directly below it (left soft key

• Go to a specific menu/option

• Confirm your selection

1. Press desired menu/option

2. Choose the key directly below it (left soft key

MENU by pressing the key

: key to scroll to your

SELECT by pressing

Philips 1

08-08

REDIAL

18:00

In this example, the alarm is On

Once.

• To change your selection

• To confirm your selection

• Return to previous menu level or stand-by screen

1. Press

2. Choose

3. Choose

: key to scroll to your

desired option

SELECT by pressing

the key directly below it (left

soft key

key directly below it (right soft

key

BACK by pressing the

Off On Once On Daily

SELECT

Alarm

 

BACK

Page 11

Connect

The location of your base station can have an effect on the range and performance of your ID937 (see TIP below).

Connecting the Base Station

1. Place the base station in a central location near the telephone line socket and electricity sockets.

Power supply

2. Connect the supplied splitter to the connector at the back of the base station and then plug the line cord and the power cable into the respective line jacks on the splitter.

3. Connect the other end of the line cord to the telephone line socket and the other end of the power cable to the electricity socket.

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor to the line cord first before plugging the line cord to the line socket.

TIP Avoid placing the base station too close to large metal objects such as filing cabinets, radiators or electrical appliances. This can impair the range and sound quality. Buildings with thick internal and external walls may impair transmission of signals to and from the base.

Line cord

Splitter

WARNING The base station does not have an ON/OFF switch. Power is applied when the power adaptor is plugged into the unit and connected to the electricity socket. The only way to power down the unit is to unplug the power adaptor from the electricity socket. Therefore, ensure that the electricity socket is easily accessible.

The power adaptor and telephone line cord have to be connected correctly, as incorrect connection could damage the unit.

Always use the telephone line cord supplied with the unit. Otherwise, you may not get a dial tone.

Page 12

Install

Install battery

Your ID937 is supplied with 2 rechargeable batteries allowing approximately up to 12 hours of talk-time and up to 150 hours stand-by time. Before using the handset, the batteries have to be installed and fully charged.

1. Use the coin or screwdriver to unlock the battery cover.

screw

charger contact

plate

Bottom View

2. Place the batteries as indicated and replace the cover.

Unlock

anticlockwise

3. Lock the battery cover.

screw

charger contact

plate

Bottom View

Please use a coin or screwdriver that is the right shape and size for the screw that is used. Otherwise you may damage the screw when tightening it.

Lock

clockwise

Charge battery

1. Place the handset on the charging cradle of the base station. A beep tone is emitted if the handset is placed correctly.

Page 13

Install

2. A charging animation on the handset indicates that the battery is charging.

18:00

REDIAL

Philips

08-08

3. Leave it there until the batteries are fully charged (at least 24 hours).

4. The handset is fully charged when the charging animation stops and is displayed.

The handset must be charged for at least 24 hours before using it for the first time.

Low battery warning

The battery level is shown at the top left of the handset screen. When the battery level becomes low, an empty battery icon is displayed on the screen.

If the battery level becomes exceedingly low, the phone automatically switches off and any function in progress will not be saved.

Out of range warning

The indoor and outdoor range of the phone is up to 50 metres and 300 metres respectively. When the handset moves beyond operation range, the antenna icon will blink.

Configure your ID937

Before you use your ID937, you need to configure it according to the country of use. After charging it for a few minutes, the word WELCOME appears in various languages. Follow these steps to configure your phone:

1. Scroll : to the word WELCOME in your preferred language and press mSELECT.

2. Scroll

3. Press

4. Scroll

5. Press

6. The default line settings and menu language for the selected country will be automatically configured.

: to your country.

mSELECT to confirm your selection.

: to your operator (if necessary).

mSELECT again to confirm your selection.

You cannot make outgoing calls or receive incoming calls without first defining your country selection.

Depending on your country, the WELCOME screen may not appear. In this case, you are not required to select your country/operator/language settings.

Page 14

Install

Set date and time

1. Press mMENU.

2. Scroll

3. Press

4. Enter current time (HH:MM) and current date (DD/MM/YY) and press

Now, you are ready to use your phone.

: to Clock & Alarm and press mSELECT.

mSELECT to enter Set Date/Time.

mOK.

WARNING If your phone is connected to an ISDN line through an adaptor, the date & time may be updated after each call. The availability of date & time update is dependent on your network provider. Please check the date & time settings in your ISDN system or contact your network provider.

Basic operations of your ID937

Make a call

Enter the phone number (maximum 20 digits) and press r to dial the number.

For details, please refer to "Make a call" on page 16.

Answer or end a call

Press r key to answer a call.

e key to end a call.

Press

For details, please refer to "Answer a call" on page 16 and "End a call" on page 17.

Switch the handset on/off

Press and hold e key for 3 seconds to switch off the handset in stand-by mode.

Short press

e key to switch on the handset again.j

Keypad lock/unlock

Press and hold * key for 2 seconds to lock or unlock the keypad in stand-by mode.

Paging

The paging feature enables you to locate a missing handset if the handset is in range and contains charged batteries.

Short press p key on the base. The handset starts to ring.

Once retrieved, press any key on the handset to end the paging.

Stand-by mode

If the handset is not used for 30 seconds in settings mode, review mode, edit mode, etc. it will automatically return to stand-by mode. It will also return to stand-by mode automatically when the handset is placed back on the base station.

Page 15

Install

Screen and keypad backlight

The backlight remains on for 20 seconds after each activation such as an incoming call, key presses, lifting up the handset off the base station, etc. The colour of the LCD and keypad backlight is WHITE.

For setup details, please refer to "Backlight time" on page 41.

Event LED

The event LED on your handset blinks when there is a new message recorded on your telephone answering machine. If you have subscribed to Caller Line Identification, the event LED also blinks when there is a new call, a new SMS or a new voice mail message.

Default settings

Ringer Volume Medium

Earpiece Volume Volume 3

Speaker Volume Volume 3

Key Beep On

Wallpaper

Contrast Level 2

Auto Pick-up Off

Auto Hang-up On

Babysit mode Off

Alarm clock Off

Barring mode Off

SMS reception On

Master PIN 0000

HD Sound mode On

Answering Machine

Answer Mode Answ. & Record

Ring delay 5

Outgoing Messages Predefined for Answ. & Record mode

Handset screening On

Remote access Deactivated

Page 16

Call

Make a call

Predialling

1. Enter the phone number (maximum 20 digits).

2. Press

r to dial the number.

Direct dialling

1. Press r or v to take the line.

2. Enter the phone number.

Call from redial list

1. Press >REDIAL in stand-by mode.

2. Scroll

3. Press

: to an entry in the redial list.

r to dial the number.

TIP The handset stores the last 7 numbers dialled. The last number dialled will appear first in the redial list. If the redial number matches a phonebook entry, the name will be displayed instead.

Call from the call log

1. Press u in stand-by mode.

2. Press

3. Scroll

4. Press

mSELECT to enter call list.

: to an entry in the call list.

r to dial the number.

You need to subscribe to Caller Line Identification service to be able to see the caller’s number or name in the call log. See "Call log" on page 25 for details.

Call from the phonebook

1. Press d in stand-by mode.

2. Scroll

3. Press

: to a phonebook entry.

r to dial the number.

TIP Instead of scrolling : to browse the phonebook entries, press the numeric key corresponding to the first letter of the entry you wish to locate. For example, pressing starting with A. Pressing

2 again will show the entries starting with B, etc...

2 will show the entries

Answer a call

When the phone rings, press r key.

Page 17

Call

Handsfree answering

When the phone rings, press v key.

Incoming call has priority over other events. Whenever there is an incoming call, other status in progress such as phone setting, menu navigation, etc will be aborted.

TIP If Auto Pick-up mode (see page 40) is activated, you can simply lift up the handset from its base station to answer the call. This feature is deactivated by default.

WARNING When the handset rings during an incoming call, please do not hold the handset too close to your ear as the volume of the ringing tone may damage your hearing.

End a call

Press e key.

The call duration will be displayed on the handset screen for about 5 seconds.

TIP If Auto Hang-up mode (see page 40) is activated, you can simply place the handset back to its

base station to end the call. This feature is activated by default.

Calls in-progress

The following options are available during a call:

Adjust earpiece volume

1. Press : to select from Volume 1 to Volume 5.

Mute/unmute the handset

1. During a call, press mMUTE to turn off the microphone so that your correspondent cannot hear you.

2. Press

Loudspeaker mode

1. Press v key to activate loudspeaker mode.

2. Press

mUNMUTE to turn on the microphone.

v key again to return to normal mode.

WARNING Activation of loudspeaker can suddenly increase the volume in the earpiece to a very high level. Make sure the handset is not too close to your ear.

Adjust loudspeaker volume

1. Press : key to select from Volume 1 to Volume 5.

Page 18

Call

Initiate a second call (subscription dependent)

1. Press >OPTION and select Init. 2ND Call to put the current call on hold and initiate a second external call.

Consult phonebook

1. Press >OPTION and select Phonebook to access and review phonebook entries.

2. Press

r on the selected phonebook entry, the corresponding number will be dialled.

Activate/deactivate HD Sound mode (see page 47)

1. Press >OPTION and select HD Sound On to activate.

2. To deactivate, press

>OPTION and select HD Sound Off.

Transfer call (subscription dependent)

1. Press >OPTION and select Call Transfer. The screen shows R4.

2. Enter the phone number that you want to transfer your incoming calls to.

Intercom

This feature is only available when there are at least 2 registered handsets. It allows you to make free internal calls, transfer external calls from one handset to another and use the conference option.

Intercom another handset

To be able to use intercommunication feature, you must have at least 2 handsets registered to your base station (see page 45 "To register an additional handset").

1. Press c key in stand-by mode.

2. Intercom is established immediately if there are only 2 registered handsets. If there are more than 2 registered handsets, the handset numbers which are available for intercom will be displayed. Scroll

Handsets and press

and press

mSELECT.

mSELECT to call all the handsets or scroll to the specific handset you want to call

: to All

If the handset does not belong to ID937 range, this function may not be available.

Transfer an external call to another handset

1. During the call, make a long press on c key to put the external call on hold (the caller can no longer hear you).

Handsets and press

and press

If there is no answer from the called handset, press c key to resume the external call.

3. Press

4. Press

mSELECT. The called handset rings.

r key on the called handset to answer the internal call, where both internal callers can talk. e key on the first handset to transfer the external call to the called handset.

mSELECT to call all the handsets or scroll to the specific handset you want to call

: to All

Page 19

Call

Switch between an internal and external call

1. Press c key once to switch between an internal call and external call.

Three-party conference call

The conference call feature allows one external call to be shared with two handsets (in intercom). The three parties can share the conversation and no network subscription is required.

1. Press and hold c to put the external call on hold and start the intercom procedure (the caller can no longer hear you).

2. Long press c to display the handset numbers which are available for intercom. Scroll : to All

Handsets and press

and press The called handset rings.

3. Press r key on the called handset to answer the internal call, where both internal callers can talk.

mSELECT.

mSELECT to call all the handsets or scroll to the specific handset you want to call

4. Press and hold

Conference is displayed on the screen.

TIP If Conference mode is activated (see page 47), a three-party conference call is automatically

established if the second handset takes the line when there is already an external call in progress.

c for 2 seconds on the first handset to start the three-party conference, whereby

Call waiting

If you have subscribed to Call Waiting service, the earpiece will emit a beep tone to inform you that there is a second incoming call. The number or name of the second caller will also be displayed if you have subscribed to Caller Line Identification service (CLI). Please contact your network provider for more information on this service

Press Operation

r + 2 r + 1 r + 0

Alternatively, you may press waiting. To confirm, scroll

The above operations may be different according to your network.

Put the current call on hold and answer the second call.

End the current call and answer the second call.

Reject the second call and continue with your current call.

mOPTION to select Accept & Hold, Accept & End or Reject CW during call

: to your desired option and press mOK.

Caller Line Identification

Caller Line Identification (CLI) is a special service that you may subscribe from your network operator. If you have subscribed to CLI service, the identity of the caller (caller’s number or name) will be displayed on your handset during an incoming call. If you have not subscribed to this service, or if the caller has chosen to withhold the number, the identity of the caller will not be displayed. Please contact your network provider for more information on this service.

Page 20

Phonebook

New Entry

List

Edit Entry

Delete Entry

Delete All

Direct Memory

Copy from SIM

Phbk transfer

Your ID937 can store up to 250 phonebook memories, including 10 direct access memories (0 to 9). Each phonebook entry can have a maximum of 20 digits for the phone number and 14 characters for name.

Access phonebook

1. Press d in stand-by mode or press mMENU, scroll : to Phonebook and press mSELECT, scroll

: to List and press mSELECT.

2. The phonebook entries will be listed in alphabetical order.

3. Press

: to browse the phonebook.

To view the details of a phonebook entry, press mVIEW.

To dial a number from the phonebook, scroll

TIP Instead of scrolling : to browse the phonebook entries, you can press the numeric key corresponding to the first letter of the entry you wish to locate. For example, pressing the entries starting with A. Pressing

2 again will show the entries starting with B, etc...

: to the phonebook entry and press r.

2 will show

Store a contact in the phonebook

1. Press mMENU, scroll : to Phonebook and press mSELECT, press mSELECT to enter New

Entry.

2. Enter the name of the contact (maximum 14 characters) and press mOK.

3. Enter the number (maximum 20 digits) and press

4. Enter the SMS Box number and press

mOK (only for UK).

mOK.

Page 21

Phonebook

5. Scroll : to choose a group (<No Group>, <Group A>, <Group B>, <Group C>) and press

mSELECT.

A validation tone is emitted.

You can assign individual contacts to specific groups of your choice. For example, Group A contains phone numbers of all your co-workers. You can also assign a specific ring melody to that group (see "Group Melody" on page 38). If you have subscribed to Caller Line Identification service from your network provider, every time someone from that group calls you, you will hear the designated ringtone for that group.

TIP You can store up to 250 phonebook entries. You cannot store a new phonebook entry when the memory is full. In this case, you have to delete existing entries to make space for new entries.

Edit a phonebook entry

1. Press mMENU, scroll : to Phonebook and press mSELECT, scroll : to Edit Entry and press

mSELECT.

2. Scroll

3. Press

4. Press

5. Enter the SMS box number and press

6. Scroll

: to the entry you wish to edit and press mSELECT. >CLEAR to erase the letters one by one, enter the name and press mOK. >CLEAR to erase the digits one by one, enter the phone number and press mOK.

mOK (only for UK).

: to choose a group (<No Group>, <Group A>, <Group B>, <Group C>) and press mSELECT.

A validation tone is emitted.

Delete a phonebook entry

1. Press mMENU, scroll : to Phonebook and press mSELECT, scroll : to Delete Entry and press

mSELECT.

2. Scroll to the entry you wish to delete and press

3. Press

mOK to confirm.

A validation tone is emitted.

mSELECT.

Delete all phonebook entries

1. Press mMENU, scroll : to Phonebook and press mSELECT, scroll : to Delete All and press

mSELECT.

2. Press

mOK to confirm.

A validation tone is emitted.

Page 22

Phonebook

Store direct access memory

You can store up to 10 direct access memories (Key 0 to 9). A long press on the keys in stand-by mode will automatically dial the stored phone number.

1. Press mMENU, scroll : to Phonebook and press mSELECT, scroll : to Direct Memory and

press

mSELECT.

2. Select a key (Key 0 to Key 9) and press

name will be displayed.

3. If there is no number stored for the selected key or if you want to change the number currently stored, press

mSELECT and press mSELECT again to select Add.

4. Scroll

5. Press

: to the entry you wish to store as direct access memory.

mOK to confirm.

A validation tone is emitted.

mVIEW. If there is a stored number in that key, the number/

Delete a direct access memory

1. Press mMENU, scroll : to Phonebook and press mSELECT, scroll : to Direct Memory and press

mSELECT.

2. Select a key (Key 0 to Key 9) and press

3. Press

4. Press

mSELECT and scroll : to Delete and press mSELECT. mOK to confirm.

A validation tone is emitted.

mVIEW.

Copy phonebook from SIM card

This feature allows you to copy the SIM card phonebook of your mobile phone to the phonebook of your handset.

1. Remove the SIM card cover as shown.

Remove SIM card cover

Page 23

Phonebook

2. Slide the SIM card between the retaining clips, microchip facing down, until it stops.

3. Slide the SIM card cover back on the base station until it latches.

4. On the handset, press

from SIM and press

5. Scroll

6. Press

7. Enter the PIN code of the SIM card (if required). The copy progress will be displayed on the screen.

8. A message Transferred! will be displayed upon successful completion.

9. You can now retrieve your SIM card and close back the SIM card cover.

: to Copy All or Select Entry. If you choose Copy All then all entries in the SIM card will be

copied to your phonebook. If you choose Select Entry, you can browse the SIM card entries and select the ones you wish to copy (the entries in your SIM card may not be shown in alphabetical order ).

mSELECT to confirm.

Your handset has the capacity to read the phonebook contents for standard SIM cards, including 3G SIM cards. If the handset is unable to read the SIM card, or no SIM card is detected, the screen will display an error message No SIM Card! and return to previous menu.

If the name on the SIM card is exactly the same as an existing name on the phonebook of your handset, you will be prompted whether or not to overwrite the phonebook entry.

TIP You can select >CANCEL anytime to abort the process.

mMENU, scroll : to Phonebook and press mSELECT, scroll : to Copy

mSELECT.

Transfer phonebook

This feature allows you to transfer the phonebook from one handset to another handset when there are at least 2 handsets registered to your base station.

1. Press

2. Scroll

mMENU, scroll : to Phonebook and press mSELECT, scroll : to Phbk transfer and press

mSELECT.

: to Copy All or Select Entry.

If you choose Copy All then all entries in the handset will be copied to the selected handsets. If the target phonebook contains a name that is exactly the same as the existing phonebook, you will be prompted whether or not to overwrite the phonebook entry.

Page 24

Phonebook

If you choose Select Entry, you can browse the phonebook entries and select the ones you wish to copy. For each selected entry, you will be prompted on the selected handsets whether or not to overwrite the phonebook entry in the target phonebook.

OVERWRITE? will be displayed on the selected handsets, press mYES to confirm or >NO to

cancel.

3. Press

4. The handset numbers which are available for transfer will be displayed. If there are more than 2 handsets,

5. Press

6. A message Completed! will be displayed upon successful completion.

mSELECT to confirm.

scroll

: to All Handsets or scroll : to select a specific handset.

The receiving handsets must be in stand-by or screensaver mode before the phonebook entries can be successfully transferred.

mSELECT to confirm. The copy progress will be displayed on the screen.

TIP You can select >BACK anytime to abort the process. You can only abort this process from the original handset which you are performing the phonebook transfer.

Page 25

Call log

The call log offers quick access to the Call List, Answ. Machine and SMS sub-menus. The Call List records the last 30 entries of your incoming calls. If you have subscribed to Caller Line Identification service, the identity of the caller (caller’s number or name) will be displayed together with the date and time of the call. The calls (missed and received) are displayed in chronological order with the most recent call at the top of the list. When the call list is empty, the screen displays List Empty.

If you have not subscribed to Caller Line Identification service, there will not be any information displayed in the call log.

Access call log

1. Press u in stand-by mode, scroll : to Call List, Answ. Machine or SMS and press mSELECT to enter the respective sub-menus.

Save call list entry to phonebook

1. Press u in stand-by mode, press mSELECT to enter Call List, scroll : to an entry and press

mMENU.

2. Press

3. Enter name and press

4. Edit number if necessary and press

5. Enter the SMS Box number and press

6. Scroll

mSELECT to Save number.

mOK.

mOK (only for UK).

: to choose a group (<No Group>, <Group A>, <Group B>, <Group C>) and press

mSELECT.

A validation tone is emitted.

Delete a call list entry

1. Press u in stand-by mode, press mSELECT to enter Call List, scroll : to an entry and press

mMENU.

2. Scroll

3. Press

: to Delete entry and press mSELECT to confirm.

mOK to confirm.

A validation tone is emitted.

Delete call list

1. Press u in stand-by mode, press mSELECT to enter Call List and press mMENU.

2. Scroll

: to Delete All and press mSELECT.

3. Press

mOK to confirm.

A validation tone is emitted.

Page 26

Call log

Access redial list

1. Press >REDIAL in stand-by mode and scroll : to view the entries.

View details of a redial list entry

1. Press >REDIAL in stand-by mode and scroll : to select an entry.

2. Press

mMENU and press mSELECT to View.

Save redial list entry to phonebook

1. Press >REDIAL in stand-by mode and scroll : to select an entry.

2. Press

3. Enter name and press

4. Edit number if necessary and press

5. Enter the SMS Box number and press

6. Scroll

mMENU, scroll : to Save number and press mSELECT.

mOK.

mOK (only for UK).

: to choose a group (<No Group>, <Group A>, <Group B>, <Group C>) and press mSELECT.

A validation tone is emitted.

Delete a number from redial list

1. Press >REDIAL in stand-by mode and scroll : to select an entry.

2. Press

3. Press

mMENU and scroll : to Delete and press mSELECT. mOK to confirm.

A validation tone is emitted.

Delete all redial list

1. Press >REDIAL in stand-by mode.

2. Press

3. Press

mMENU and scroll : to Delete All and press mSELECT. mOK to confirm.

A validation tone is emitted.

Page 27

SMS

Write a SMS

Inbox

Draft box

SMS Settings

SMS stands for Short Message Service. To benefit from this service, you must subscribe to Caller Line Identification Service (CLI) together with SMS service from your network provider. SMS messages can be exchanged with a phone (mobile or compatible fixed lines), provided the receiver has also subscribed to CLI and SMS services. The factory settings on your ID937 correspond to the main national operator. If you wish to send or receive SMS messages through another service provider, you must set the corresponding numbers (see page 33).

You can create up to 10 SMS boxes (Box 0 to Box 9) and protect each box with a password (only for UK). Your ID937 can store up to 50 SMS messages (40 SMS in the Inbox and 10 SMS in the Draft box) shared by all the SMS boxes and the maximum length of each message is 160 characters.

In order to send and receive SMS messages, there must be at least one SMS Box. Box 9 with empty password is created by default (only for UK). For more information, please refer to "SMS Box (only for UK)" on page 32.

Write and send new SMS

1. Press mMENU, press mSELECT to enter SMS, press mSELECT again to enter Write a SMS.

2. Scroll

3. Enter the PIN (if required) and press

Key Operation

>CLEAR

: to the desired SMS Box (Box 0 to Box 9) and press mSELECT (only for UK).

Otherwise, you may press Box.

mSELECT to go the next screen if you do not need to enter a specific SMS

mOK.

Press to move cursor left by 1 position.

Press and hold to jump to the 1st character/digit.

Press to move cursor right by 1 position.

Press and hold to jump to the last character/digit.

Press to erase the previous character/digit.

Press to return to the previous menu if there are no characters/digits on the input screen.

Long press to delete all characters/digits.

Long press to switch between upper and lower case.

Page 28

SMS

Key Operation

1 2 3 4 5 6 7 8 9

space 1 @ _ # = < > ( ) & £ $ ¥ [ ] { } ¤ §

a b c 2 à ä ç å æ

d e f 3 é è ∆ Φ

g h i 4 ì Γ

j k l 5 Λ

m n o 6 ñ ò ö

p q r s 7 β Π Θ Σ

t u v 8 ù ü

w x y z 9 ø Ω Ξ Ψ

€

0 *

4. Enter the text and press mOK.

You can enter up to 160 characters for an SMS.

If you receive a call while writing an SMS, the operation will be interrupted. When you go back to SMS editing, the message will be retrieved automatically.

5. Enter the destination phone number and press list to select a phone number, press

6. Enter the destination box number (0 to 9) directly and press Otherwise, you may press

By default, the destination box number is 9 (the default destination box is country-dependent).

If you are sending the SMS to a GSM mobile phone, the destination box number can be empty.

. 0 , / : ; " ’ ! ¡ ? ¿ . + - % \ ^ ~ |

mOK. Or press mPHBK to browse the phonebook

mSELECT and press mOK.

mOK (only for UK).

mOK to go the next screen if you do not need to enter a specific SMS Box.

Page 29

SMS

7. Press mSELECT to Send the message. The message will be sent immediately.

SMS Sent! will be displayed if the message has been sent successfully.

If the message cannot be sent successfully, the screen will display SMS not Sent! and the message will be saved in the SMS editor buffer.

WARNING When composing your SMS, if no keys are pressed for 30 seconds, the handset will return to stand-by mode. The edited message will be automatically saved in the SMS editor buffer.

Inbox

The messages in the Inbox are listed according to the time of receipt, with the newest message appearing first. The Inbox can store up to 40 messages (shared between Box 0 to Box 9). Each time an SMS is received, you will be alerted by a beep tone (see "SMS Tone" on page 38) and the screen displays the number of new messages received. The event LED will blink until the SMS has been reviewed.

WARNING When the message box is full, you will not be able to receive new messages. In this case, you need to delete some old messages in order to receive new ones.

View Inbox messages

1. Press mMENU, press mSELECT to enter SMS, scroll : to Inbox and press mSELECT.

2. Scroll

3. Enter the PIN and press

4. Browse the list of SMS messages and select the message you wish to read. The message list will be

5. Press

6. When viewing the message content, you can press

Reply Send a reply to the sender of the message

Edit Forward the message to another recipient

Save number Save the sender’s number to your phonebook

Delete Delete the selected message

Delete All Delete all messages in the Inbox

: to your desired box number and press mSELECT (only for UK).

TIP If there are unread new messages, the SMS box number will be highlighted in green.

mOK (PIN is not required for default user).

displayed with the sender’s phone number or corresponding name (if the number matches the phonebook record).

mVIEW to view the message content.

TIP While reading an SMS, press : to scroll to the next or previous row. At the end of the message, the sender’s phone number and the date and time of reception are shown.

mMENU to access the following options:

Press r while viewing the message content/sender number/date/time stamp will abort the SMS function and dial the sender’s phone number.

Press

e to return to Inbox message list.

Page 30

SMS

Reply to an Inbox message

1. While viewing the message content, press mMENU to display the Inbox menu options.

2. Scroll

3. After editing, press

4. Refer to steps 5 to 7 in "Write and send new SMS" on page 27 to send the message or steps 1 to 3 in

: to Reply and press mSELECT to start editing.

mOK to confirm the message.

"Save a message in the Draft box" on page 31 to save the message in the Draft box.

Forward an Inbox message

1. While viewing the message content, press mMENU to display the Inbox menu options.

2. Scroll

3. After editing, press

4. Refer to steps 5 to 7 in "Write and send new SMS" on page 27 to send the message or steps 1 to 3 in

: to Edit and press mSELECT to start editing it if you wish.

mOK to confirm the message.

"Save a message in the Draft box" on page 31 to save the message in the Draft box.

Save sender’s phone number to phonebook

1. While viewing the message content, press mMENU to display the Inbox menu options.

2. Scroll

3. Enter the name and press

4. To confirm the number, press

5. Enter the SMS Box number and press

6. Scroll

: to Save number and press mSELECT to enter a name for this new contact.

mOK to modify number.

mOK again.

mOK (only for UK).

: to select a group you wish to assign for this contact and press mSELECT.

A validation tone is emitted and the screen returns to display the message content.

Delete an Inbox message

1. While viewing the message content, press mMENU to display the Inbox menu options.

2. Scroll

: to Delete and press mSELECT to confirm deletion.

Delete all Inbox messages

1. While viewing the message content, press mMENU to display the Inbox menu options.

2. Scroll

3. Press

: to Delete All and press mSELECT.

mSELECT again to confirm deletion.

Page 31

SMS

Draft box

SMS messages that are saved as drafts will be automatically stored in the Draft box. The Draft box can store up to 10 messages.

Save a message in the Draft box

1. After writing the message, entering the phone number and the desired box, press mOK.

2. Scroll to Save as draft.

3. Press

mSELECT to confirm.

Review Draft messages

1. Press mMENU, press mSELECT to enter SMS, scroll : to Draft box and press mSELECT.

2. Scroll

3. Enter the PIN and press

4. Browse the list of SMS messages and select the message you wish to review.

5. Press

6. When viewing the message content, you can press

Edit Edit the message and send or save as draft

Send Send the message immediately

Delete Delete the message

Delete All Delete all messages in the Draft box

Edit a Draft message

1. While viewing the message content, press mMENU to display the Draft box menu options.

2. Press

3. After editing, press

: to your desired box number and press mSELECT (only for UK).

mOK (PIN is not required for default user).

mVIEW to view the message content.

mMENU to access the following options:

mSELECT to Edit the message.

mOK to confirm message.

4. Refer to steps 5 to 7 in "Write and send new SMS" on page 27 to send the message or steps 1 to 3 in "Save a message in the Draft box" on page 31 to save the message in the Draft box.

Send a message from Draft box

1. While viewing the message content, press mMENU to display the Draft box menu options.

2. Scroll

: to Send and press mSELECT. The message will be sent immediately.

SMS Sent! will be displayed if the message has been sent successfully.

Delete a Draft message

1. While viewing the message content, press mMENU to display the Draft box menu options.

2. Scroll

: to Delete and press mSELECT to confirm deletion.

Page 32

SMS

Delete all Draft messages

1. While viewing the message content, press mMENU to display the Draft box menu options.

2. Scroll

3. Press

: to Delete All and press mSELECT.

mSELECT again to confirm deletion.

SMS settings

This menu allows you to set up the server for sending and receiving SMS messages. Your ID937 can receive messages from 3 service centers.

Each service center consists of 2 numbers:

- Incoming number

- Outgoing number

The maximum length of an incoming/outgoing number is 20 digits.

The incoming and outgoing numbers of your ID937 are already set to work on your country network. We advise you not to modify these settings. For more details or in case of any problems, please contact your local network provider.

SMS reception

Your ID937 can receive SMS messages from another phone if you have subscribed to the CLI and SMS services from your network provider. By default, SMS reception is set to On so that you can receive SMS messages.

To activate or deactivate the reception of SMS

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, press

mSELECT to enter SMS Reception.

2. Scroll

: to On or Off and press mSELECT to confirm.

Even if SMS reception is Off, you can still send SMS messages.

SMS Box (only for UK)

In order to send and receive SMS messages, at least 1 SMS Box must be created. Box 9 with empty password is created by default.

You can add new SMS boxes (Box 0 to Box 9), and you can protect each SMS box with a password.

To create a new SMS Box (only for UK)

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to SMS Boxes and press mSELECT.

2. Press

3. Enter box name (maximum 14 characters) and press

4. Enter PIN (maximum 4 digits) and press

mMENU and press mSELECT to Add New Box.

mOK.

Page 33

SMS

5. Enter PIN again and press mOK.

You can choose to leave the PIN empty. If no PIN is required, simply press mOK when prompted to enter PIN.

6. Enter the SMS box number and press If the number entered already exist, an error tone is emitted. If the number entered is accepted, a validation tone is emitted and the screen returns to SMS boxes list.

mOK.

To change the password of an SMS Box (only for UK)

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to SMS Boxes and press mSELECT.

2. Scroll

3. Scroll

4. Enter old PIN and press

5. Enter new PIN, press

6. Press

: to the SMS box for which you wish to change password and press mSELECT. : to Change PIN and press mSELECT.

mOK.

mOK and enter the new PIN again for confirmation.

mOK to confirm PIN change.

To delete an SMS Box (only for UK)

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to SMS Boxes and press mSELECT.

2. Scroll

3. Scroll

4. Enter PIN (if needed) and press

: to the SMS box for which you wish to delete and press mSELECT. : to Delete Box and press mSELECT.

mOK to confirm box deletion.

To change the box number of an SMS Box (only for UK)

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to SMS Boxes and press mSELECT.

2. Scroll

3. Scroll

4. Enter the new box number and press

: to the SMS box for which you wish to change the box number and press mSELECT. : to Change Box Nr and press mSELECT.

mOK to confirm box number change.

To set outgoing number

1. Press

2. Press

3. Enter the number and press

mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT,

scroll

: to SMS Center 1, SMS Center 2 or SMS Center 3 and press mSELECT. mSELECT to enter Outgoing Nr..

mOK to confirm.

A validation tone is emitted.

The maximum length of an outgoing number is 20 digits.

Page 34

SMS

To set incoming number

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to SMS Center 1, SMS Center 2 or SMS Center 3 and press mSELECT.

2. Scroll

3. Enter the number and press

: to Incoming Nr. and press mSELECT.

mOK to confirm.

A validation tone is emitted.

The maximum length of an incoming number is 20 digits.

Default SMS center

The default SMS center number is 1.

To set default SMS center

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to Default Ctr. and press mSELECT.

2. Scroll

: to SMS Center that you wish to set as default center (SMS Center 1, SMS Center 2 or SMS

Center 3) and press

A validation tone is emitted.

mSELECT.

1st Ring

When this function is set to Off, the first ring from a voice call will not sound. This is particularly useful in countries where calling line identity is sent after the first ring, so no phones in the house would ring when a message arrives.

To set 1st Ring

1. Press mMENU, press mSELECT to enter SMS, scroll : to SMS Settings and press mSELECT, scroll

: to Set 1st Ring and press mSELECT.

2. Scroll

: to On or Off and press mSELECT to confirm.

Page 35

Clock & Alarm

Set Date/Time

Alarm

Alarm Tone

Do not Disturb

Set date and time

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, press mSELECT again to enter

Set Date/Time.

2. Enter the current time (HH:MM) and current date (DD/MM/YY) and press

Enter the date in Day/Month/Year format and the time in 24-hour format.

3. A validation tone is emitted and the screen returns to Clock & Alarm menu.

Once the date and time are set, there will be time & date recovery when the batteries are removed, or when there is a power failure.

mOK.

Set Alarm

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Alarm and press

mSELECT.

2. Scroll

3. If you select On Once or On Daily, enter the time for the alarm and press

: to Off, On Once or On Daily and press mSELECT.

mOK.

A validation tone is emitted and the screen returns to previous menu.

The alarm tone and alarm icon will only sound/blink for 1 minute when the alarm time is reached. To mute the alarm tone, simply press any key on the handset.

Alarm tone

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Alarm Tone and press

mSELECT.

2. Scroll

3. Press

: to the desired melody (Melody 1, Melody 2 or Melody 3) to play the melody.

mSELECT to set the alarm tone.

Page 36

Clock & Alarm

Do not Disturb mode

This feature is available only if you have subscribed to Caller Line Identification from your network provider. When Do not Disturb mode is activated, the phone will ring only when there are calls received from authorised groups. For all other callers, the phone will display an incoming call message or the backlight will be turned on, but it will not ring. If the telephone answering machine is activated, it will answer the call to allow the caller to leave a message.

To set Do not Disturb mode On/Off

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Do not Disturb and press

mSELECT.

2. Press

3. Scroll

4. Press

mSELECT again to enter Activation.

: to On or Off.

mSELECT to confirm.

By default, Do not Disturb mode is Off.

To set Day of Do not Disturb mode

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Do not Disturb and press

mSELECT, scroll : to Set Day and press mSELECT.

2. Scroll : to your desired option (

SELECT

3. If you select All Week or Weekday, press mSELECT again to confirm.

4. If you select Monday, Tuesday..... or Sunday, a “√” will appear at the beginning of the row to indicate your

selection. You can select more than 1 day.

5. After you have made your selection, scroll vious menu.

All Week,

Weekday,

Monday,

Tuesday

..... or

Sunday

) and press

: to OK and press mSELECT to confirm and return to pre-

To set Time of Do not Disturb mode

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Do not Disturb and press

mSELECT, scroll : to Set Time and press mSELECT.

2. Enter Start Time and Stop Time.

3. Press

mOK to confirm.

By default, Start Time is 00:00 and Stop Time is 00:00.

To set allowed caller

1. Press mMENU, scroll : to Clock & Alarm and press mSELECT, scroll : to Do not Disturb and press

mSELECT, scroll : to Allowed caller and press mSELECT.

2. Scroll to your desired option (Standard, Group A, Group B or Group C).

3. Press

mOK to confirm.

By default, no group is allowed when Do not Disturb mode is activated.

Page 37

Personal Settings

Handset Tones

Personal Set

Handset Tones

Wallpaper

Contrast

Handset Name

Auto Pick-up

Auto Hang-up

Language

Babysit Mode

Backlight Time

Theme Colour

Ring Volume

There are 5 ringer volume options (Silence, Low, Medium, High and Progressive). The default level is Medium.

To set ring volume

1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT to enter

Handset Tones and press

2. Scroll

: to your desired volume level and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

When Silence is activated, the icon is displayed on the screen.

WARNING When the handset rings during an incoming call, please do not hold the handset too close to your ear as the volume of the ringing tone may damage your hearing.

mSELECT again to enter Ring Volume.

Ring Melody

There are 16 ring melodies available on your handset.

To set Ring Melody

1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT to enter

Handset Tones, scroll

2. Scroll

: to your desired melody to play the melody.

: to Ring Melody and press mSELECT.

3. Press

mSELECT to set the ring melody.

A validation tone is emitted and the screen returns to previous menu.

Page 38

Personal Settings

Group Melody

To benefit from this feature, you must subscribe to the Caller Line ldentification service. See "Caller Line Identification" on page 19.

This menu enables you to select and set the melodies to be played when there is an external incoming call from a contact whose name is stored in your phonebook and is part of a group. You can associate 1 ring melody to each group.

There are three phonebook groups (Group A, B, C) available for you to organise your contacts. Each group can be assigned a unique melody.

To set Group Melody

1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT to enter

Handset Tones, scroll

2. Scroll

3. Scroll

: to the group for which you wish to set melody and press mSELECT. : to the desired melody to play the melody.

: to Group Melody and press mSELECT.

4. Press

mSELECT to set the group melody.

A validation tone is emitted and the screen returns to previous menu.

Key Beep

A single beep is emitted when a key is pressed. You can enable or disable the key beep. By default, the key beep is On.

To set key beep On/Off

1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT to enter

Handset Tones, scroll

2. Scroll

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

: to Key Beep and press mSELECT.

SMS Tone

A tone is emitted when a new SMS is received. You can enable or disable the SMS Tone. By default, SMS tone is On.

To set SMS tone On/Off

1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT to enter

Handset Tones, scroll

2. Scroll

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

: to SMS Tone and press mSELECT.

Page 39

Personal Settings

Wallpaper

This feature allows you to select the wallpaper to be displayed in stand-by mode. There are 6 wallpapers pre-installed on your handset. The 6th wallpaper is a blank wallpaper. Please see "Default settings" on page 15 for the default wallpaper.

To set wallpaper

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Wallpaper and press

mSELECT.

2. Scroll

: to your desired wallpaper and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Contrast level

There are 3 contrast level options (Level 1, Level 2 or Level 3). The default contrast level is Level 2.

To set contrast level

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Contrast and press

mSELECT.

2. Scroll

: to your desired contrast level (Level 1, Level 2 or Level 3) and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Handset Name

You can name the handset and display the handset name in stand-by mode. The default handset name of your handset is PHILIPS.

To rename the handset

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Handset Name and press

mSELECT.

2. Edit the handset name and press A validation tone is emitted and the screen returns to previous menu.

mOK to confirm.

Maximum length of the handset name is 14 characters and the default handset name is PHILIPS.

Page 40

Personal Settings

Auto Pick-up

This function enables you to answer a call automatically by simply lifting the handset from the base station. By default, the Auto Pick-up feature is Off and in this case you have to press the

To set Auto Pick-up mode

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Auto Pick-up and press

mSELECT.

r key to answer a call.

2. Scroll

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Auto Hang-up

This function enables you to end a call automatically by simply replacing the handset on the base station. By default, the Auto Hang-up feature is On.

To set Auto Hang-up mode

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Auto Hang-up and press

mSELECT.

2. Scroll

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Language

Your ID937 can support different display languages.

To change the language

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Language and press

mSELECT.

2. Scroll

: to your desired language and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Babysit mode

You must have at least 2 handsets registered to your base station to be able to use this feature (see page 45 "To register an additional handset").

This feature allows you to monitor, e.g. the baby’s room. Place the handset in the room to be monitored. If the sound level around the microphone of the handset exceeds a certain threshold, the handset can automatically call another handset registered on the same base station.

To use the Babysit feature you need to activate it (e.g. on handset 1) and enter the number of the handset to be called (e.g. handset 2) in the event that there are noises in the monitored room. Place the handset which is in Babysit mode (e.g. handset 1) in the room to be monitored. If this handset detects a sound level greater than a certain threshold, it will automatically initiate an internal call to the selected handset (e.g. handset 2).

Page 41

Personal Settings

To activate Babysit mode

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Babysit mode and press

mSELECT.

In Babysit mode, all keys are deactivated except for mMENU key. Babysit mode is displayed on the screen when this function is activated and the handset cannot perform any normal operation (making an outgoing call, receiving an incoming call, intercom another handset, paging, etc.)

2. Scroll through the list of handsets available and press

You can still perform all normal operations (making an outgoing call, receiving an incoming call, intercom another handset, paging, etc.) on the selected handset.

mSELECT to select the handset to be called.

To deactivate Babysit mode

1. Press mMENU, select Off and press mSELECT.

Backlight time

To set Backlight time

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Backlight Time and press

mSELECT.

2. Select 20s, 40s and 60s and press A validation tone is emitted.

Backlight is activated when there is an incoming call, new message, etc. The default backlight time is 20s.

mSELECT to confirm.

Theme Colour

To set theme colour

1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Theme Colour and press

mSELECT.

2. Scroll

: to Theme Colour 1, Theme Colour 2 or Theme Colour 3 and press mSELECT to confirm.

A validation tone is emitted.

Page 42

Advanced Settings

Advanced Set

Recall Time

Dial Mode

Call Barring

Baby call

Registration

Select Base

Unregistration

Change PIN

Reset

Auto prefix

Conference

HD Sound

Demo Mode

Recall Time

Recall time (or dial delay) is the time delay by which the line will be disconnected after you press r key. It can be set to short, medium or long.

The default value of recall time that is preset in your ID937 should be the best suited for your country network and therefore you should not need to change it.

To set recall time

1. Press mMENU, scroll : to Advanced Set and press mSELECT and press mSELECT to enter

Recall Time.

2. Scroll to select Short / Medium / Long and press A validation tone is emitted and the screen returns to previous menu.

This setting is useful when using network services. The use of some services accessed with [r +

1] , [r + 2] , [r + 3] (call waiting, call forward...) will depend on your recall time

setting. Please contact your network provider for more details on this feature.

mSELECT to confirm.

Page 43

Advanced Settings

Dial Mode

The default value for dial mode that is preset in your ID937 should be the best suited for your country network and therefore you should not need to change it.

There are 2 dial modes: Tone or Pulse

To set dial mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Dial Mode and press

mSELECT.

2. Scroll

: to Tone or Pulse and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

Call Barring

Call barring enables you to restrict selected handsets from dialling a phone number beginning with certain numbers. You can set up to 4 different barring numbers, with each number containing up to 4 digits.

To activate/deactivate Call Barring mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Call Barring and press

mSELECT.

2. Enter the Master PIN when prompted and press

The default Master PIN number is 0000.

3. Press

4. Scroll

mSELECT to enter Barring Mode.

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

To modify Call Barring number

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Call Barring and press

mSELECT.

mOK to confirm.

2. Enter the Master PIN when prompted and press

The default Master PIN number is 0000.

3. Scroll

4. Scroll

5. Enter a maximum of 4 digits and press

: to Barring Number and press mSELECT. : to Number 1, Number 2, Number 3 or Number 4 and press mSELECT.

A validation tone is emitted and the screen returns to previous menu.

If a restricted number is dialled, the call will not be connected. When this happens, the phone emits an error tone and returns to stand-by mode.

mOK to confirm.

Page 44

Advanced Settings

Baby Call

When activated, the Baby Call feature enables you to dial a number by pressing any key on your handset. This feature is very useful for direct access to emergency services.

You can enter up to 20 digits for baby call number.

To activate Baby Call mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Baby call and press

mSELECT.

2. Enter the Master PIN when prompted and press

The default Master PIN number is 0000.

3. Press

4. Scroll

5. Enter the Baby Call number and press

mSELECT to enter Mode.

: to On and press mSELECT to confirm.

mOK to confirm.

A validation tone is emitted.

mOK to confirm.

To deactivate Baby Call mode

1. Long press mMENU (when Baby Call mode has been activated before).

2. Scroll

: to Off and press mSELECT to confirm.

To change Baby Call number

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Baby call and press

mSELECT.

2. Enter the Master PIN when prompted and press

The default Master PIN number is 0000.

3. Scroll

4. The last stored Baby Call number is displayed (if any).

: to Number and press mSELECT.

mOK to confirm.

5. Enter the new Baby Call number and press A validation tone is emitted and the screen returns to previous menu.

Registration

The procedures described below are the procedures that you will find in your ID937 handset. The procedures may vary according to the handset you want to register. In this case, please refer to the manufacturer of the additional handset.

Additional handsets must be registered to the base unit before you can use them. Up to 6 handsets can be registered to one base station.

The Master PIN is required before you can register or unregister handsets. The default PIN is 0000.

mOK to confirm.

Page 45

Advanced Settings

To register an additional handset

1. On the base station, press and hold p for 3 seconds. After that, the registration procedure has to be done within 1 minute.

Within 1 minute, the base station is able to accept registration from a handset. If there is no action taken on the handset within 10 seconds, the registration procedure will be aborted.

2. At the same time, on the handset, press scroll

: to Registration and press mSELECT.

3. Press

4. Enter the Master PIN when prompted and press

: to select the Base to be registered to and press mOK to confirm.

If the PIN is incorrect, Incorrect PIN will be displayed and the handset returns to stand-by mode.

A validation tone is emitted to indicate successful registration and the screen returns to stand-by mode.

mMENU, scroll : to Advanced Set and press mSELECT,

mOK to start registration.

Select Base

One ID937 handset can be registered to up to 4 different ID937 Base stations. By default, the handset will register to BASE 1. If you select Best Base, the handset will register to the nearest base station.

To manually select best base station

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Select Base and press

mSELECT.

2. Scroll

3. The handset will start searching for the base station. If the selected base is found, a validation tone is emit-

: to the desired base station and press mOK to confirm.

ted.

Unregistration

To unregister a handset

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Unregistration and press

mSELECT.

2. Enter the Master PIN when prompted and press

3. Select in the list of handsets displayed, the handset that you wish to unregister. A validation tone is emitted to indicate successful unregistration and the screen shows Unregistered.

If no action is taken on the handset within 15 seconds, the unregistration procedure will be aborted and the handset returns to stand-by mode.

mOK to confirm.

Page 46

Advanced Settings

Change Master PIN

The Master PIN is used for setting call barring/baby call number, registration/unregistration of handsets and for accessing the answering machine remotely. The default Master PIN number is 0000. The length of the PIN is 4 digits. This PIN is also used to protect the settings of your handset. Your handset will prompt you whenever the PIN is required.

To change Master PIN

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Change PIN and press

mSELECT.

2. Enter the current Master PIN when prompted and press shown as asterisks (*) on the screen.

If an incorrect PIN is entered, the screen returns to previous menu.

3. Enter new PIN and press

4. Enter new PIN again and press A validation tone is emitted, the message New PIN Stored appears and the screen returns to previous menu.

mOK.

mOK to confirm PIN change.

mOK to confirm. The PIN entered will be

Reset

Reset to default settings

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Reset and press

mSELECT.

2. Scroll

: to Yes and press mSELECT.

A validation tone is emitted and the unit is reset to its default settings (Please see "Default settings" on page 15).

The WELCOME mode will appear again after master reset.

Auto Prefix

The maximum length of an auto prefix number is 5 digits. Once the number is set, it will be automatically inserted at the beginning of each number that will be dialled.

To set auto prefix number

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Auto prefix and press

mSELECT.

2. The last stored auto prefix number is displayed (if any).

3. Enter the number and press A validation tone is emitted and the screen returns to previous menu.

mOK to confirm.

Page 47

Advanced Settings

Conference Mode

When conference mode is activated, you can initiate a three-party conference call with a second handset registered to your base station automatically if the second handset takes the line when there is already an external call in progress. The default setting for this mode is Off.

To activate/deactivate Conference mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Conference and press

mSELECT.

2. Scroll

: to On or Off and press mSELECT to confirm.

A validation tone is emitted and the screen returns to previous menu.

HD Sound mode

The HD Sound mode is an exclusive feature making your phone conversations sounding just like real-life conversations. When activated, the HD Sound mode transmits with high fidelity all the emotions of the call as if your correspondent was talking next to you.

To activate/deactivate HD Sound mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to HD Sound and press

mSELECT.

2. Scroll

: to On or Off and press mSELECT to confirm.

During a call, you can also press >OPTION and select HD Sound On/HD Sound Off to activate/ deactivate HD Sound mode. When HD Sound mode is activated during a call, HD Sound On will appear on the screen for 2 seconds and the HD Sound icon (see "Display icons & symbols" on page 8) will also appear to indicate that the call is now in HD Sound mode. If HD Sound mode is deactivated during a call, HD Sound Off will appear on the screen for 2 seconds and the normal call connected icon (see "Display icons & symbols" on page 8) will appear to replace the HD Sound icon to indicate that the call is no longer in HD Sound mode.

Demo Mode

1. Press mMENU, scroll : to Advanced Set and press mSELECT, scroll : to Demo Mode and press

mSELECT.

2. Press

3. To exit from this mode, press

mSELECT to start the demo mode.

The demo mode begins.

Page 48

Network Services

Net. Service

Call Forward

Call Fwd Busy

Call Fwd UnAns

Voice Mail

Call Back

Cancel Call Bk

Withhold ID

This menu provides a convenient means for you to access, activate or deactivate some network services that are country/subscription dependent. Contact your network provider for more information about these services.

The default numbers and values that are preset in your ID937 should be the best suited for your country network and therefore you should not need to change them.

Call Forward

There are 3 call forwarding options available: Unconditional Call Forwarding, When Busy and When Unanswered.

Set up Call Forward number

1. Press mMENU, scroll : to Net. Service and press mSELECT.

2. Scroll

3. Scroll

4. Press

: to the type of call forwarding option you wish to set (Call Forward / Call Fwd Busy / Call Fwd

UnAns) and press

mSELECT.

: to Settings and press mSELECT to enter the number for forwarding.

mOK to confirm.

Activate Call Forward

1. Press mMENU, scroll : to Net. Service and press mSELECT.

2. Scroll to the type of call forwarding option you wish to set (Call Forward / Call Fwd Busy / Call Fwd

UnAns) and press

3. Press

4. The number for that selected service will be dialled.

5. When the number has been dialled, press

mSELECT to Activate.

When this feature is activated, depending on the call forwarding option you have set, your incoming calls will be forwarded to the number of your choice.

mSELECT.

e to return to stand-by mode.

Deactivate Call Forward

1. Press mMENU, scroll : to Net. Service and press mSELECT.

Page 49

Network Services

2. Scroll : to the type of call forwarding option you wish to set (Call Forward / Call Fwd Busy / Call Fwd

UnAns) and press

mSELECT.

3. Scroll

4. The number for that selected service will be dialled.

5. When the number has been dialled, press

: to Deactivate and press mSELECT to confirm.

e to return to stand-by mode.

Voice Mail

This feature allows the caller to leave a voice message when you are unable, or do not wish to take a call yourself. The availability of this feature is dependent on your country and your subscription with your network provider. Charges often apply for you to retrieve messages, as these are stored by the network rather than on the handset itself. Contact your network provider for more information about this feature.

Set up Voice Mail number

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Voice Mail and press

mSELECT.

2. Press

3. Scroll

4. Modify the voice mail number and press

Activate Voice Mail

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Voice Mail and press

2. Press

mSELECT to select Voice Mail 1.

: to Settings and press mSELECT.

mOK.

mSELECT.

mSELECT to select Voice Mail 1.

3. Press

4. The number for that selected service will be dialled.

5. When the number has been dialled, press

mSELECT to Activate.

e to return to stand-by mode.

Call Back

Setting

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Call Back and press

mSELECT.

2. Scroll

3. Enter the required number for call back and press

Activate Call Back

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Call Back and press

2. Press

3. The number for that selected service will be dialled.

4. When the number has been dialled, press

: to Settings and press mSELECT.

mOK.

mSELECT.

mSELECT to Activate.

e to return to stand-by mode.

Page 50

Network Services

Cancel Call Back

Setting

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Cancel Call Bk and

mSELECT.

press

2. Scroll

3. Enter the required number for cancelling of call back and press

Activate Cancel Call Back

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Cancel Call Bk and

2. Press

3. The number for that selected service will be dialled.

4. When the number has been dialled, press

Withhold ID

: to Settings and press mSELECT.

mSELECT.

press

mSELECT to Activate.

mOK.

e to return to stand-by mode.

Setting

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Withhold ID and press

mSELECT.

2. Scroll

3. Enter the required number for withholding ID and press

: to Settings and press mSELECT.

mOK.

Activate Withhold ID

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Withhold ID and press

mSELECT.

2. Press

3. The number for that selected service will be dialled.

4. When the number has been dialled, press

mSELECT to Activate.

e to return to stand-by mode.

Deactivate Withhold ID

1. Press mMENU, scroll : to Net. Service and press mSELECT, scroll : to Withhold ID and press

mSELECT.

2. Scroll

3. The number for that selected service will be dialled.

4. When the number has been dialled, press

: to Deactivate and press mSELECT to confirm.

e to return to stand-by mode.

Page 51

Games

Memory

Puzzle

Tetris

Memory

The objective of this game is to find and match different pairs of graphics in the shortest possible time using your memory. To win, you have to complete matching all 8 pairs of graphics in a 4x4 matrix.

To start the game

1. Press

2. An instruction screen is displayed.

, scroll : to

Press 2 / 4 / 6 / 8 keys to move up / left / right / down respectively. Press

5 to select.

Games

and press

SELECT

, press

SELECT

to enter

Memory

game.

3. Press

4. To exit from the game, press

mSELECT to start the game.

Puzzle

This is a picture game where you have to move around small pieces of jumbled up pictures and put them together in order to form a complete picture.

To start the game

1. Press

2. An instruction screen is displayed.

3. Press

4. To exit from the game, press

, scroll : to

Press 2 / 4 / 6 / 8 keys to move up / move left / move right / move down respectively.

mSELECT to start the game.

Games

and press

SELECT

, scroll : to

Puzzle

and press

SELECT

Tetris

You can rotate each shaped block as they fall such that they fit neatly into horizontal blocks. The more blocks you can gather within the same level, the more you will score.

To start the game

1. Press mMENU, scroll : to Games and press mSELECT, scroll : to Tetris and press

mSELECT.

2. An instruction screen is displayed.

Press 2 / 4 / 6 / 8 keys to rotate / move left / move right / move down respectively.

3. Press

4. To exit from the game, press

mSELECT to start the game.

Page 52

Telephone Answering Machine (TAM)

Answer Machine

Play

Delete All

Record Memo

Answ. Mode

Ans. On/Off

Ans. Settings

Your ID937 features an answering machine that records unanswered calls when it is activated.

The answering machine can store up to 99 messages within the maximum recording time of 15 minutes. The maximum recording time for each message is 3 minutes.

Play

Playback of new messages via handset

1. Press mMENU, scroll : to Answer Machine and press mSELECT, press mSELECT to Play.

2. The new messages will be played via the loudspeaker. During playback, you can:

Adjust volume Press Stop playback Press e to return to Play menu. Repeat Press mMENU, scroll : to Repeat and press mSELECT. Next message Press mMENU, scroll : to Next Message and press mSELECT.

Previous message Press Delete message Press mMENU, scroll : to Delete and press mSELECT.

Switch the playback to earpiece

TIP You can also playback messages by pressing u key in stand-by mode, scroll : to Answer

Machine and press

mSELECT, press mSELECT again to Play.

: key.

mMENU, scroll : to Prev. Message and press mSELECT.

v key.

Press

Playback of old messages via handset

Old messages can only be played if there are no new messages. The first recorded message will be played first and the next message will be played automatically until there are no more messages.

1. Press

Play.

, scroll : to Answer Machine and press mSELECT, press mSELECT to enter

2. Press mSELECT, the first recorded message will start to play until the last recorded message. During message playback, you can press available under "Playback of new messages via handset" on page 52).

to select the available options (please refer to the options

Page 53

Telephone Answering Machine (TAM)

Delete All

1. Press m press

2. Press

Unread messages will not be deleted.

, scroll : to Answer Machine and press mSELECT, scroll : to Delete All and

mSELECT. mOK to confirm deletion of all your messages.

Memo recording

You can record a reminder message for yourself or for anyone else who uses your answering machine. The answering machine treats a memo recording the same way it treats any incoming message, and the new message indicator will flash accordingly. To play the memo recording, please refer to "Play" on page 52.

1. Press

2. Press

3. Press

4. Press

, scroll : to Answer Machine and press mSELECT, scroll : to Record Memo and

press

mSELECT.

mSTART to start recording the memo. mSTOP to end the recording. >BACK at any time to return to the previous menu.

Answering machine mode

1. Press m press

mSELECT.

, scroll : to Answer Machine and press mSELECT, scroll : to Answ. Mode and

2. There are 3 answering modes available: Answer Only, Answ. & Record or VIP Mode. The current selected mode is highlighted.

3. To change the answering mode, scroll

If you select Answer Only mode, the answering machine will only pick up an incoming call after a certain number of rings but will not record any message. Your correspondent will be prompted to call back later.

: to your selection and press mSELECT.

Set Outgoing Messages (OGM)

1. If you set the answering mode as Answer Only or Answ. & Record, you can choose to set your outgoing message as Predefined or Personalised.

2. The current selected mode is highlighted.

3. To change it, scroll

: to your selection and press mSELECT.

Predefined Outgoing Messages

Press mSELECT to set your outgoing message as Predefined, you can press mSELECT again to play the outgoing message. The language of the predefined outgoing message can be changed in the Voice Language menu (see page 57).

Page 54

Telephone Answering Machine (TAM)

Personalised Outgoing Messages

If you set your outgoing message as Personalised, you can either play the existing outgoing message or record your own outgoing message.

Playing your Personalised Outgoing Message

1. Scroll : to Play message and press mSELECT.

2. The existing outgoing message will be played and the screen will return to previous menu once it has finished playing.

If there is no existing outgoing message, the predefined outgoing message is played.

Recording your Personalised Outgoing Message

1. Scroll : to Record message and press mSELECT.

The maximum length of an outgoing message is 2 minutes.

2. Press

mSTART to start recording and press mSTOP to end the recording.

The recorded message will be played and the screen will return to the previous menu once it has finished playing.

When you record an outgoing message, the previous one is overwritten automatically.

VIP mode

This feature is available only if you have subscribed to Caller Line Identification from your network provider. When VIP Mode is activated, the phone will play a personalised VIP greeting message for the members in the

VIP list when they call you.

VIP Mode is automatically activated if there is a number in the VIP list.

The following options are available in VIP Mode:

VIP List Add or delete numbers from the VIP list (maximum 6 numbers).

Answer Only Record and play the outgoing message for the VIP list in Answer Only mode.

Answ. & Record Record and play the outgoing message for the VIP list in Answ. & Record mode.

Add VIP numbers

1. Press m press

2. Scroll

, scroll : to Answer Machine and press mSELECT, scroll : to Answ. Mode and

mSELECT.

: to VIP Mode and press mSELECT.

3. Press

4. The numbers in the VIP list will be displayed. If it has not been set before, the screen will display Empty.

5. Scroll

6. Press

7. Scroll

mSELECT to enter the VIP List.

: to select an entry and press mSELECT.

mSELECT to select Add.

: to select a number from the phonebook and press mSELECT to add the entry into the VIP

list.

Page 55

Telephone Answering Machine (TAM)

8. You can then set the answering mode as Answer Only or Answ. & Record, and choose to set your outgoing message as Predefined or Personalised (special VIP message). Refer to "Predefined Outgoing Messages" and "Personalised Outgoing Messages" above for the steps to record and play your outgoing messages for the VIP list.

Delete VIP numbers

1. Press mSELECT to enter the VIP List.

2. The numbers in the VIP list will be displayed.

3. Scroll

4. Scroll

: to select an entry and press mSELECT. : to Delete and press mSELECT to delete.

Answer On/Off

Turn answering machine On/Off

1. Press m press

2. Scroll

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. On/Off and

mSELECT.

: to On or Off and press mSELECT to confirm.

Answering Machine settings

1. Press m press

Ring delay

This is the number of rings before the answering machine answers and starts playing your greeting message. You can set the answering machine to start playing your greeting message after 1 to 7 rings or Toll saver. The default ring delay is 5.

1. Press press

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. Settings and

mSELECT.

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. Settings and

mSELECT, press mSELECT to enter Ring delay.

2. Scroll

: to your desired ring delay setting (1 to 7 rings or Toll saver) and press mSELECT to confirm.

Toll saver mode can save you the cost of a long-distance call when you check your messages remotely. If there are new messages in your answering machine, the outgoing message will start playing after 3 rings. If there are no new messages, the outgoing message will be played after 5 rings. Hence, if you want to check if you have any messages without incurring call charges, you can hang up the call after the 4th ring.

Page 56

Telephone Answering Machine (TAM)

Remote control access

This feature lets you check your messages, or otherwise operate your answering machine, by calling the answering machine and entering a remote access code (which is the same as your Master PIN code) on a tone dialling phone. To prevent unauthorised access to your answering machine, your Master PIN code must be changed (see page 46).

Activate/Deactivate remote access

1. Press m press

2. The current selected option is highlighted.

3. Scroll

Remote access code is to prevent unauthorised access of the answering machine from external callers. The remote access code is the same as the Master PIN of the phone. Your Master PIN code must be changed (see page 46) before you can access this feature.

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. Settings and

mSELECT, scroll : to Remote access and press mSELECT.

: to Activated or Deactivated and press mSELECT to confirm.

Controlling the answering machine from an external call

1. From your external phone, dial home. The answering machine answers and starts playing your greeting message. Within 8 seconds, press # key.

2. Enter the remote access code (same as your Master PIN code). If the code is not correct, an error tone will be emitted. After the error tone is emitted, you can try to press the remote access code again until you enter the correct number.

The answer machine will drop the line immediately if there is no detection of the master PIN entry within 8 seconds.

3. If the access code is correct, a validation tone can be heard. If there are new messages, all the new messages will be played immediately and then stop when there are no more new messages. If there are no new messages, the answering machine will not play any messages.

The following table indicates how to access the below features during remote access procedure:

1 2 3 4 0

Replay current message or go to previous message.

Play old messages or stop them.

Go to next message.

Delete current message.

Turn the answering machine on/off.

Call screening

Handset call screening

If Handset Call screening is set to On, you may press v to switch between the loudspeaker and earpiece mode. If you decide to pick up the call, press automatically. If you press

e, the call will be cut off and the recording will be ignored.

r. Once the call has been picked up, the recording will stop

Page 57

Telephone Answering Machine (TAM)

Set Handset Call Screening

1. Press m press

2. The last selected option is highlighted.

3. Scroll

If you have multiple handsets, only 1 handset can enable handset call screening for each call.

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. Settings and

mSELECT, scroll : to HS Screening and press mSELECT.

: to On or Off and press mSELECT to confirm.

Voice Language

This menu allows you to change the language of the predefined outgoing message. The availability of this menu and the language options available are country dependent.

To set voice language

1. Press m press

2. The current selected language is highlighted.

3. Scroll A validation tone is emitted and the screen returns to previous menu.

, scroll : to Answer Machine and press mSELECT, scroll : to Ans. Settings and

mSELECT, scroll : to Voice Language and press mSELECT.

: to your preferred language and press mSELECT to confirm.

Page 58

Troubleshooting

Troubleshooting of the phone

Please refer to the following website for more information on Philips web support: www.philips.com/support

Problem Causes Solution

The icon is not blinking when the handset is placed on the base

No dialling tone • No power

Poor audio quality • You are too far from the base

• Bad battery contact

• Dirty contact

• Battery is full

• Batteries are empty

• You are too far from the base station

• Wrong line cable

• Line adaptor (when needed) is not connected to the line cord

station

• The base station is too close to electrical appliances, reinforced concrete walls or metal doorframes

• Move the handset slightly

• Clean the battery contact with a cloth moistened with alcohol

• No need to charge

• Check the connections. Reset the phone: unplug and plug back in the mains

• Charge the batteries for at least 24 hours

• Move closer to the base station

• Use the line cable provided

• Connect the line adaptor (when needed) to the line cord

• Move closer to the base station

• Move the base station at least one metre away from any electrical appliances

The icon is blinking • Handset is not registered to

The copy from my mobile phone SIM card to ID937 phonebook is not complete.

the base station

• You are too far from the base station

Only phonebook entries from your mobile phone SIM card will be transferred; the phonebook entries that are stored on your mobile phone memory will not be transferred.

• Register the handset to the base station

• Move closer to the base station

Transfer the phonebook entries that are on your mobile phone memory to your mobile phone SIM card and then to your ID937.

Page 59

Troubleshooting

Problem Causes Solution

The handset displays “not available”

• when attempting to add another handset to the base station

• when using a handset

Noise interference on your radio or television

Caller Line Identification (CLI) service does not work

No ring tone The ring tone is deactivated Increase the volume

A phonebook entry cannot be stored

• The procedure to add a handset has failed

• Maximum number of handsets (6) has been reached

• Base station is already busy with another handset

Your ID937 base station or mains power pack are too close to electrical appliances

The service is not activated Check your subscription with your

The phonebook is full Delete an entry to free memory

• Try again by disconnecting and connecting the base station power supply and follow the procedure to register a handset (see page 44)

• Remove and place back the handset batteries

• Unregister a handset so as to register the new handset

• Wait until it is available

Move the power pack or base station as far away as possible

network operator

Cannot receive new SMS • SMS storage space is full

• Wrong SMS settings

Cannot send or receive new SMS

• The outgoing or incoming SMS center numbers are not set or are wrong

• You have no subscription

• Another SMS-enabled phone is also on your line

• There is a problem of compatibility between operators

• The identity is withheld

• Delete old SMS

• Check your SMS settings (see page 32)

• See "SMS settings" on page 32

• Contact your provider for more information

• Deactivate the SMS reception mode on one of the device

• Contact your provider for more information

• Show identity (see "Withhold ID" on page 50)

Page 60

Troubleshooting

Troubleshooting of the Answering Machine

Problem Causes Solution

The answering machine does not record messages

Remote control access does not work

Cannot record outgoing message

The ID937 hangs up during remote access

The answering machine stops automatically

• Memory is full

• The ANSWER ONLY mode has been activated

• Remote control access has not been activated

• Memory is full • Delete old messages

• You have not changed your Master PIN code

• You have taken more than 8 seconds to enter the Master PIN code

• Memory is full

• Message exceeds 3 minutes

• Delete old messages

• Activate Answ. & Record mode

(see "Answering machine mode" on page 53)

• Activate Remote control access (see "Remote control access" on page 56)

• To prevent unauthorised access to your answering machine, your Master PIN code must be changed. To change PIN code, see page 46

• Enter the Master PIN code within 8 seconds

• Play and delete old messages

• Messages must not exceed 3 minutes

Page 61

Information

Electric, Magnetic and Electromagnetic Fields ("EMF")

1. Philips Royal Electronics manufactures and sells many consumer oriented products which usually, as with any electronic apparatus, have the ability to emit and receive electro magnetic signals.

2. One of Philips' leading Business Principles is to take all necessary health and safety precautions for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products.

3. Philips is committed to develop, produce and market products that cause no adverse health effects.

4. Philips confirms that if its products are handled properly for their intended use, they are safe to use according to scientific evidence available today.

5. Philips plays an active role in the development of international EMF and safety standards, enabling Philips to anticipate further developments in standardisation for early integration in its products.

Conformity

The Declaration of conformity is available on www.p4c.philips.com.

Hereby, Philips Consumer Electronics, BLC P&ACC, declares that the ID937x is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Recycling and disposal

Disposal instructions for old products

The WEEE Directive (Waste Electrical and Electronic Equipment: 2002/96/EC) has been put in place to ensure that products are recycled using best available treatment, recovery and recycling techniques to ensure human health and give utmost protection to the environment.

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

Do not dispose of your old product in your general household waste bin. Inform yourself about the local separate collection system for electrical and electronic products marked by this symbol:

Use one of the following disposal options:

1. Dispose of the complete product (including its cables, plugs and accessories) in the designated WEEE collection facilities

2. If you purchase a replacement product, return your old product, in its entirety, to the retailer. He should accept it as required by the WEEE Directive.

Philips has marked the packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste.

A financial contribution has been paid to the associated national recovery & recycling system.

The labelled packaging material is recyclable.

Page 62

Index

Accessories 5 Alarm 35 Alarm tone 35 Answer a call 14 Auto Hang-up 40 Auto Pick-up 40 Auto Prefix 46

Baby Call 44 Babysit mode 40 Backlight 15 Backlight time 41 Basic operations 11 Battery level 13 Battery life and range 13

Call 43 Call Back 49 Call Barring 43 Call Forward 48 Call log 16, 25 Caller Line Identification 19 Calls in-progress 17 Charge battery 12 Clock & Alarm 35 Conference Mode 47 Conference call 19 Conformity 61 Connect Base Station 11 Contrast 39 Copy phonebook from SIM card 22

Date & time 35 Date and time 14 Default SMS center 34 Delete call log 25 Delete phonebook 21 Direct access memory 22 Direct dialling 16 Do not Disturb Mode 36 Draft box 31

Earpiece volume 17 Edit Draft message 31 Edit phonebook 21 End a call 14, 17 Event LED 15

Forward SMS message 30

Group Melody 38

HD Sound mode 47 Handset Name 39 Handset Tones 37 Handset keys 7 Handsfree answering 17

Icons & symbols 8 Inbox 29 Incoming number 34 Install battery 12 Intercom 18

Key Beep 38 Keypad lock 14 Keypad lock/unlock 14 Keypad unlock 14

Language 40 Loudspeaker volume 17 Low battery warning 13

Main features 9 Make a call 14 Master PIN 46 Memory 51 Menu navigation 10 Mute 17 Mute handset 17

Noise interference 59

Other network services 50 Out of range 13 Outgoing number 33 Overview of the base station 9 Overview of the handset 6

Paging 14 Personalise 37 Phonebook 16, 20 Predialling 16

Recall Time 42 Recycling and disposal 61 Redial list 16, 26 Registration 44 Reply SMS message 30 Reset Unit 46 Ring Melody 37 Ring Volume 37

SMS 27 SMS Boxes 32 SMS Tone 38 SMS reception 32 SMS settings 32 Save redial list 26 Select Base 45 Send SMS 27 Stand-by mode 14 Store a contact 20 Switch handset on/off 14

Tetris 51 Theme Colour 41 Transfer an external call 18 Transfer phonebook 23

Unmute 17 Unregister 45

Voice Mail 49

Wallpaper 39 Withhold ID 50 Write a SMS 27

Page 63

Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

Specifications are subject to change without notice.

www.philips.com

3111 285 27241
