Philips HTS9520/51 User guide

www.philips.com/welcome

HTS9520

Contents

1 Important 2

Safety 2 Product care 2 Disposal of your old product and batteries 3 3D health warning 3

5 Change settings 19

Access the setup menu 19 Change video settings 19 Change audio settings 20 Set up network 20 Set up EasyLink 20 Change preference settings 21 Change advanced settings 21

English

2 Your home theater 4

Main unit 4 Remote control 4

3 Connect your home theater 7

Connectors 7 Connect to the TV 8 Connect audio from TV or other devices 9

Connect to a computer network and the

Internet 10 Connect a Wi-Fi USB adapter 11 Connect a wireless module 11

4 Use your home theater 11

Before you start 11 Access the home menu 11 Choose your sound 12 Play a disc 13 Use Bonus View on Blu-ray 13 Access BD-Live on Blu-ray 14 Play 3D video 14 Play from a USB storage device 14 More play features for disc or USB 15 Play from PC (DLNA) 16 Browse Net TV 17 Play from radio 17 Play audio from TV or other devices 18 Play from an MP3 player 18 Play from an iPod or iPhone 18 Use Philips EasyLink 18

6 Update software 22

Check software version 22 Update software from the network 22 Update software from a USB 23 Update electronic user manual 23

7 Product specications 24

8 Troubleshooting 25

Main unit 25 Picture 25 Sound 26 Play 26 Network 27

9 Index 27

1 Important

Read and understand all instructions before you use your home theater. If damage is caused by

failure to follow instructions, the warranty does

not apply.

Safety

Risk of electric shock or re!

• Never expose the product and accessories

to rain or water. Never place liquid

containers, such as vases, near the product. If liquids are spilt on or into the product,

disconnect it from the power outlet immediately. Contact Philips Consumer Care to have the product checked before use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never inser t objects into the ventilation

slots or other openings on the product.

• Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily operable.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

Risk of short circuit or re!

• Before you connect the product to the

power outlet, ensure that the power

voltage matches the value printed on the back or bottom of the product. Never connect the product to the power outlet if the voltage is different.

Risk of injury or damage to the home theater!

• For wall-mountable products, use only the

supplied wall mount bracket. Secure the wall mount to a wall that can suppor t the combined weight of the product and the wall mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper

wall mounting that results in accident, injury

or damage.

• For speakers with stands, use only the

supplied stands. Secure the stands to the

speakers tightly. Place the assembled stands

on at, level surfaces that can support the

combined weight of the speaker and stand.

• Never place the product or any objects

on power cords or on other electrical equipment.

• If the produc t is transpor ted in

temperatures below 5°C, unpack the

product and wait until its temperature matches room temperature before connecting it to the power outlet.

• Visible and invisible laser radiation when

open. Avoid exposure to beam.

• Do not touch the disc optical lens inside the

disc compartment.

Risk of overheating!

• Never install this product in a conned

space. Always leave a space of at least four inches around the product for ventilation. Ensure cur tains or other objects never cover the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries if they are exhausted or

if the remote control is not to be used for a long time.

• Batteries contain chemical substances, they

should be disposed of properly.

Product care

• Do not insert any objects other than discs

into the disc compar tment.

• Do not insert warped or cracked discs into

the disc compartment.

• Remove discs from the disc compartment

if you are not using the product for an extended period of time.

• Only use microber cloth to clean the

product.

Disposal of your old product and batteries

Your product is designed and manufactured with

high quality materials and components, which can

be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/ EC. Please inform yourself about the local separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with your normal household waste.

Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the

European Directive 2006/66/EC, which cannot be

disposed with normal household waste. Please inform yourself about the local rules on

separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

3D health warning

If you or your family has a history of epilepsy

or photosensitive seizures, consult a medical professional before exposing yourself to ashing light sources, rapid image sequences or 3D

viewing.

To avoid discomfor t such as dizziness, headache or disorientation, we recommend not watching

3D for ex tended periods of time. If you

experience any discomfor t, stop watching 3D

and do not immediately engage in any potentially hazardous activity (for example driving a car) until your symptoms have disappeared. If

symptoms persist, do not resume watching 3D without consulting a medical professional rst.

Parents should monitor their children during 3D viewing and ensure they do not experience any discomfort as mentioned above. Watching 3D is not recommended for children under six years of age as their visual system is not fully developed yet.

English

3 4

2 Your home theater

Congratulations on your purchase, and welcome to Philips! To fully benet from the support that Philips offers, register your home theater at www.

philips.com/welcome.

Main unit

Remote control - A

a +/- (Volume)

Increases or decreases volume.

b SOURCE

Selects an audio/video source for the home theater.

c (Standby-On)

Switches on the home theater or switches to standby mode.

d (Play/Pause)

Star ts, pauses or resumes play.

e (Stop)

Stops play.

f (Open/Close)

Opens or closes the disc compar tment.

g Display panel h Disc compartment

Remote control

Note

• Your home theater is supplied with one of the

following remote controls.

a (Standby-On)

• Switches the home theater on or to

st andby.

• When EasyLink is enabled, press

and hold for at least three seconds to switch all connected HDMI CEC compliant devices to standby.

b (Home)

Accesses the home menu.

c SOUND SETTINGS

Accesses or exits various sound options.

d Navigation buttons

• Navigates menus.

• In radio mode, press lef t or right to

start auto search.

e OK

• Conrms an entry or selection.

f OPTIONS

• Accesses more play options during

playback.

• In radio mode, programs radio stations.

g +/- (Volume)

Increases or decreases volume.

h (Play)

Star ts or resumes play.

i (Pause)

Pauses play.

j / (Fast Backward/Fast Forward)

Fast backwards or fast forwards. Press repeatedly to change the search speed.

k Alphanumeric buttons

Enters values or letters (using SMS style entry).

l SUBTITLE

Selects subtitle language for video.

m TOP MENU

Accesses the main menu of a video disc.

n / (Previous/Next)

• Skips to the previous or next track,

chapter or le.

• In radio mode, selects a preset radio

station.

o (Stop) / (Eject / Open/Close)

• Stops play.

• Press and hold to eject the disc or

open the disc compartment.

• In radio mode, erases the current

preset radio station.

p (Mute)

Mutes or restores volume.

q BACK

Returns to a previous menu screen.

r POP-UP MENU/DISC MENU

Accesses or exits the disc menu.

s Source buttons

• Color buttons (for Blu-ray discs):

Selects tasks or options.

• DISC: Switches to disc source.

• RADIO: Switches to FM radio.

• DOCK for iPod: Switches to Philips

Dock for iPod/iPhone.

• SOURCE: Selects an audio input

source.

English

Remote control - B

7 8 9

a (Standby-On)

• Switches the home theater on or to

st andby.

• When EasyLink is enabled, press

and hold for at least three seconds to switch all connected HDMI CEC compliant devices to standby.

b (Home)

Accesses the home menu.

c (Disc menu)

Accesses or exits the disc menu.

d Navigation buttons

• Navigates menus.

• In radio mode, press lef t or right to

start auto search.

e / (Previous/Next)

• Skips to the previous or next track,

f OK

g (Sound options)

h (Options)

i (Play)

j +/- (Volume)

k (Pause)

l Source buttons / Color buttons

m Alphanumeric buttons

chapter or le.

• In radio mode, selects a preset radio

station.

Conrms an entry or selection.

Accesses or exits various sound options.

• Accesses more play options during

playback.

• In radio mode, programs radio stations.

Star ts or resumes play.

Increases or decreases volume.

Pauses play.

• Blu-ray discs: Selects tasks or options.

• AUDIO SOURCE: Selects an audio

input source.

• DOCK for iPod: Switches to Philips

Dock for iPod/iPhone.

• RADIO: Switches to FM radio.

• DISC: Switches to disc source.

Enters values or letters (using SMS style entry).

( )

n TOP MENU

Accesses the main menu of a video disc.

o SUBTITLE

Selects subtitle language for video.

p (Stop)

• Stops play.

• Press and hold to eject the disc or

open the disc compartment.

• In radio mode, erases the current

preset radio station.

q / (Fast Backward/Fast Forward)

Fast backwards or fast forwards. Press repeatedly to change the search speed.

r (Back)

Returns to a previous menu screen.

3 Connect your home

theater

English

This section helps you connect your home theater to a TV and other devices. The basic connections of the home theater with its accessories are provided in the Quick Start. For a comprehensive

interactive guide, see www.connectivityguide.

philips.com.

Note

• Refer to the type plate at the back or bot tom

of the produc t for identication and supply

ratings.

• Before you make or change any connections,

ensure that all devices are disconnec ted from the power outlet.

Connectors

Connect other devices to your home theater.

Front connectors

a (USB)

Audio, video or picture input from a USB

storage device.

b MP3 LINK

Audio input from an MP3 player.

Back connectors

Component Video Out

Component Video In

a AC MAINS~

Connects to the power supply.

b AUDIO IN-AUX 1/AUX 2

Connects to the analog audio output on the TV or an analog device.

c Wi-Fi

Connects to a Wi-Fi USB adapter.(Model:

Philips WUB1110, sold separately.)

d SUBWOOFER

Connects to the supplied subwoofer.

e LAN

Connects to the L AN input on a broadband modem or router.

f HDMI OUT (ARC)

Connects to the HDMI input on the TV.

g VIDEO OUT

Connects to the video input on the TV.

h ANTENNA FM 75

Signal input from an antenna, cable or

satellite.

i DIGITAL IN-OPTICAL

Connects to the optical audio output on the TV or a digital device.

j DIGITAL IN-COAXIAL

Connects to the coaxial audio output on the TV or a digital device.

k DOCK for iPod

Connects to a Philips Dock for iPod/iPhone. (Model: Philips DCK3060)

l Wireless Rear Audio

Connects to a Philips wireless module.

(Model: Philips RWSS9500, sold separately.)

m SPEAKERS

Connects to the supplied speakers.

Option 1: Connect to the TV through HDMI

Note

• The HDMI connector on the T V might be

labeled HDMI IN or HDMI ARC.

• If the TV supports HDMI Audio Return

Channel (ARC), you can use it to output digital

audio to the home theater.

• If the HDTV has a DVI connector, connect

using an HDMI/DVI adapter.

• If the TV supports EasyLink HDMI CEC,

control the home theater and TV with one remote control (see ‘Use Philips EasyLink’ on page 18).

Option 2: Connect to the TV through YPbPr (component video)

Note

• The component video cable or connector

might be labeled Y Cb Cr or YUV.

(Cable not supplied)

Connect to the TV

Connect your home theater directly to a TV through one of the following connectors (from highest to basic quality video):

a HDMI b Component video c Composite video
