HTS5593

User manual

1 Help and support 2

Use onscreen help (user manual) 2 Navigate onscreen help 2

2 Important 3

Safety 3 Care for your product 4 Care of the environment 4 3D health warning 4

3 Your home theater 6

Remote control 6 Main unit 7 Connectors 8

4 Connect and set up 10

Connect speakers 10 Connect to TV 11 Connect digital devices through HDMI 12 Connect audio from TV and other

devices 13 Set up speakers 14 Set up EasyLink (HDMI-CEC control) 14 Connect and set up a home network 15

5 Use your home theater 17

Access the home menu 17 Discs 17

Data les 19

USB storage devices 20 Audio, video, and picture options 20 Radio 22 MP3 player 22 iPod or iPhone 23 Smartphone control 23 Browse Smart TV 25 Browse PC through DLNA 26 Karaoke 28 Choose sound 29

6 Change settings 31

Language settings 31 Picture and video settings 31 Audio settings 31 Parental control settings 32 Display settings 32 Energy saving settings 32 Speaker settings 32 Restore default settings 33

7 Update software 34

Check software version 34 Update software through USB 34 Update software through the Internet 35 Update the onscreen help 35

8 Productspecications 37

9 Troubleshooting 41

10 Notice 44

Pacic and China only) 44

Compliance 45 Trademarks 45

11 Language code 47

12 Index 48

1EN

1 Help and

the content, scroll down the page to see

Use onscreen help (user manual)

For easy access, the onscreen help (user manual) is stored on your home theater. The onscreen help has two panels.

• The left panel contains two tabs -

Contents and Index. Navigate the Contents or Index to select a topic. The

legends used to display the Contents are as follows:

• : Press OK to expand the subtopics.

• : Press OK to collapse the subtopics,

or press Navigation buttons (up/ down) to select a topic.

• To move between the left and right panel, press Navigation buttons (left/right).

• The right panel contains the content of the selected topic. For additional help on

Use the home theater remote control to select and navigate the onscreen help (see 'Navigate onscreen help' on page 2).

Navigate onscreen help

Press a button on your remote control to use onscreen help.

Button Action

HELP Access or exit onscreen help.

Display the selected page, or

expand subtopics in Contents.

Navigation buttons

BACK Move up in the Contents or

(Previous)

(Next) Display the next page from

Up: Scroll up or move to the previous page. Down: Scroll down or move to the next page. Right: Navigate to the right panel or next index entry. Left: Navigate to the left panel or previous index entry.

Index. From the right panel, move to the Contents on the left panel.

Display the last viewed page in history.

history.

2 EN

2 Important

Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories to rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Philips Consumer Care to have the product checked before use.

• Never place the product and accessories near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation slots or other openings on the product.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• Batteries (battery pack or batteries installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord, always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the product. Never connect the product to the power outlet if the voltage is different.

Riskofinjuryordamagetothehometheater!

• For wall-mountable products, use only the supplied wall mount bracket. Secure the

wall mount to a wall that can support the combined weight of the product and the wall mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper wall mounting that results in accident, injury or damage.

• For speakers with stands, use only the supplied stands. Secure the stands to the speakers tightly. Place the assembled stands

on at, level surfaces that can support the

combined weight of the speaker and stand.

• Never place the product or any objects on power cords or on other electrical equipment.

• If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet.

• Visible and invisible laser radiation when open. Avoid exposure to beam.

• Do not touch the disc optical lens inside the disc compartment.

• Parts of this product can be made of glass. Handle with care to avoid injury and damage.

Riskofoverheating!

• Never install this product in a conned

space. Always leave a space of at least four inches around the product for ventilation. Ensure curtains or other objects never cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or carbon and alkaine, etc.).

• Danger of explosion if batteries are incorrectly replaced. Replace only with the same or equivalent type.

• Remove batteries if they are exhausted or if the remote control is not to be used for a long time.

• Batteries contain chemical substances, they should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach

3EN

of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention.

• When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery.

• If the battery compar tment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer.

This is CLASS II apparatus with double insulation, and no protective earth provided.

Care for your product

• Do not insert any objects other than discs into the disc compartment.

• Do not insert warped or cracked discs into the disc compartment.

• Remove discs from the disc compartment if you are not using the product for an extended period of time.

• Use only microber cloth to clean the

product.

Care of the environment

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/ EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

3D health warning

If you or your family has a history of epilepsy or photosensitive seizures, consult a medical

professional before exposing yourself to ashing

light sources, rapid image sequences or 3D viewing. To avoid discomfort such as dizziness, headache or disorientation, we recommend not watching 3D for extended periods of time. If you experience any discomfort, stop watching 3D and do not immediately engage in any potentially hazardous activity (for example driving a car) until your symptoms have disappeared. If symptoms persist, do not resume watching 3D without consulting a medical

professional rst.

4 EN

Parents should monitor their children during 3D viewing and ensure they do not experience any discomfort as mentioned above. Watching 3D is not recommended for children under six years of age as their visual system is not fully developed yet.

5EN

3 Your home

theater

Congratulations on your purchase, and

welcome to Philips! To fully benet from the support that Philips offers(e.g. notication

of product software upgrade), register your product at www.philips.com/welcome.

Access the main menu of a video disc.

Remote control

This section includes an overview of the remote control.

a (Standby-On)

• Switch the home theater on or to

standby.

• When EasyLink is enabled, press

and hold for at least three seconds to switch all connected HDMI CEC compliant devices to standby.

b (Home)

Access the home menu.

c Source buttons

• DISC/POP-UP MENU: Access or exit

the disc menu when you play a disc.

• RADIO: Switch to FM radio.

• AUDIO SOURCE: Select an audio

input source.

d TOP MENU

a BACK

• Return to a previous menu screen.

• In radio mode, press and hold to erase

the current preset radio stations.

b Navigation buttons

• Navigate menus.

• In radio mode, press left or right to

start auto search.

• In radio mode, press up or down to tune the radio frequency.

c OPTIONS

• Access more play options while playing a disc or a USB storage device.

• In radio mode, set a radio station.

d OK

Conrm an entry or selection.

a (Stop) / (Eject/Open/Close)

• Stop play.

6 EN

• Press and hold for three seconds to open or close the disc compartment, or eject the disc.

b (Play)

Start or resume play.

c / (Previous/Next)

• Skip to the previous or next track, chapter or le.

• In radio mode, select a preset radio

station.

d (Pause)

Pause play.

e / (Fast Backward/Fast Forward)

Search backwards or forward. Press repeatedly to change the search speed.

a +/- (Volume)

Increase or decrease volume.

b SOUND SETTINGS

Access or exit sound options.

c (Mute)

Mute or restore volume.

d AUDIO

Select an audio language or channel.

a Alphanumeric buttons

Enter values or letters (using SMS style entry).

b REPEAT

Select or turn off repeat mode.

c DOCK for iPod

Switch to Philips dock for iPod or iPhone.

d SUBTITLE

Select subtitle language for video.

e Color buttons

Select tasks or options for Blu-ray discs.

f HELP

Access the onscreen help.

Main unit

This section includes an overview of the main unit.

a (Standby-On)

Switch the home theater on or to standby.

b (Play/Pause)

7EN

Start, pause or resume play.

c (Stop)

• Stop play.

• In radio mode, press and hold to erase

the current preset radio stations.

d SOURCE

Select an audio or video source for the home theater.

e +/-

Increase or decrease volume.

f (Open/Close)

Open or close the disc compartment, or eject the disc.

g Display panel h Disc compartment

Rear left

a AC MAINS~

Connect to the power supply.

b SPEAKERS

Connect to the supplied speakers and subwoofer.

Connectors

This section includes an overview of the connectors available on your home theater.

Front connectors

a MUSIC iLINK / MIC (MIC is available only

in selected models)

Audio input from an MP3 player or a microphone. Audio input from a microphone. (Available only in selected models)

b (USB)

Audio, video or picture input from a USB storage device.

Rear center

a Wireless Rear Audio

Connect to a Philips wireless module. (Model: Philips RWSS5512, sold separately)

b DIGITAL IN-COAXIAL

Connect to a coaxial audio output on the TV or a digital device.

c DIGITAL IN-OPTICAL

Connect to an optical audio output on the TV or a digital device.

d DOCK for iPod

Connect to a Philips dock for iPod or iPhone.(Model: Philips DCK306x)

8 EN

e AUDIO IN-AUX

Connect to an analog audio output on the TV or an analog device.

f ANTENNA FM 75

Connect the supplied antenna for radio reception.

g LAN

Connect to the LAN input on a broadband modem or router.

Rear right

a SD CARD FOR VOD/BD-LIVE ONLY

Slot for SD card. The SD card is used to rent online videos and access BD-Live.

b VIDEO-VIDEO OUT

Connect to the composite video input on the TV.

c HDMI IN1 / HDMI IN2

Connect to the HDMI output on a digital device.

d USB

Audio, video or picture input from a USB storage device.

e HDMI OUT (ARC)TO TV

Connect to the HDMI input on the TV.

9EN

4 Connect and set

This section helps you connect your home theater to a TV and other devices, and then set it up. For information about the basic connections of your home theater and accessories, see the quick start guide.

Note

• For identication and supply ratings, see the type plate

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Connect speakers

The speaker cables are color-coded for easy connection. To connect a speaker to your home theater, match the color on the speaker cable to the color on the connector.

Speaker position plays a critical role in setting up a surround sound effect. For best effect, position all the speakers towards the seating position and place them close to your ear level (seated).

Note

• Surround sound depends on factors such as room

shape and size, type of wall and ceiling, windows and

reective surfaces, and speaker acoustics. Experiment with the speaker positions to nd the optimum setting

for you.

Follow these general guidelines for speakers placement.

1 Seating position:

This is the center of your listening area.

2 FRONT CENTER (front center) speaker :

Place the center speaker directly in front of the seating position, either above or below your TV.

3 FRONT LEFT (front left) and FRONT

RIGHT (front right) speakers:

Place the left and right speakers in the front, and at equal distance from the center speaker. Make sure that the left, right, and the center speakers are at equal distance from your seating position.

4 REAR LEFT (rear left) and REAR RIGHT

(rear right) speakers: Place the rear surround speakers to the left and right side of your seating position, either in line with it or slightly behind it.

5 SUBWOOFER (subwoofer):

10 EN

Place the subwoofer at least one meter to the left or right of the TV. Leave about 10-centimeter clearance from the wall.

Make your rear speakers wireless

Connect the rear speakers to your home theater wirelessly using a wireless module accessory. For details, see the wireless module user manual.

What you need

• A Philips wireless module. (Model: Philips RWSS5512, sold separately)

1 Connect the wireless transmitter to the

Wireless Rear Audio connector on your

home theater.

2 Connect the rear speakers to the wireless

receiver.

3 Connect the wireless receiver to the

power supply.

Connect to TV

Connect your home theater to a TV to watch videos. You can listen to the TV audio through your home theater speakers. Use the best quality connection available on your home theater and TV.

Option 1: Connect to TV through HDMI (ARC)

Best quality video

Your home theater supports HDMI version with Audio Return Channel (ARC). If your TV is HDMI ARC compliant, you can hear the TV audio through your home theater by using a single HDMI cable.

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your home theater to the HDMI ARC connector on the TV.

• The HDMI ARC connector on the TV might be labeled differently. For details, see the TV user manual.

2 On your TV, turn on HDMI-CEC

operations. For details, see the TV user manual.

• HDMI-CEC is a feature that enables CEC compliant devices that are connected through HDMI to be controlled by a single remote control, such as volume control for both the TV and the home theater. (see 'Set up EasyLink (HDMI-CEC control)' on page 14)

3 If you cannot hear the TV audio through

your home theater, set up the audio manually. (see 'Set up the audio' on page

15)

11EN

Option 2: Connect to TV through standard HDMI

Best quality video

If your TV is not HDMI ARC compliant, connect your home theater to the TV through a standard HDMI connection.

Option 3: Connect to the TV through composite video

Basic quality video

If your TV does not have HDMI connectors, use a composite video connection. A composite

connection does not support high-denition

video.

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your home theater to the HDMI connector on the TV.

2 Connect an audio cable to hear the TV

audio through your home theater (see 'Connect audio from TV and other devices' on page 13).

3 On your TV, turn on HDMI-CEC

operations. For details, see the TV user manual.

4 If you cannot hear the TV audio through

your home theater, set up the audio manually. (see 'Set up the audio' on page

15)

Note

• If your TV has a DVI connector, you can use an HDMI/

DVI adapter to connect to TV. However, some of the features may not be available.

1 Using a composite video cable, connect

the VIDEO OUT connector on your home theater to the VIDEO IN connector on the TV.

• The composite video connector might be labeled AV IN, COMPOSITE, or

BASEBAND.

2 Connect an audio cable to hear the TV

audio through your home theater (see 'Connect audio from TV and other devices' on page 13).

3 When you watch TV programs, press

SOURCE on your home theater

repeatedly to select the correct audio input.

4 When you watch videos, switch your TV to

the correct video input. For details, see the TV user manual.

Connect digital devices through HDMI

Connect a digital device such as a set-top box, games console, or camcorder to your home theater through a single HDMI connection. When you connect the devices in this way and

play a le or game, the

12 EN

• video is automatically displayed on your TV, and

• audio is automatically played on your home theater.

1 Using a High Speed HDMI cable, connect

the HDMI OUT connector on your digital device to the HDMI IN 1/2 on your home theater.

2 Connect your home theater to TV through

HDMI OUT (ARC).

• If the TV is not HDMI CEC compliant,

select the correct video input on your TV.

3 On the connected device, turn on HDMI-

CEC operations. For details, see the user manual of the device.

• If you cannot hear the digital device

audio through your home theater, set up the audio manually. (see 'Set up the audio' on page 15)

• You can also press SOURCE on your

home theater repeatedly to select the correct HDMI input.

Option 1: Connect audio through a digital optical cable

Best quality audio

1 Using an optical cable, connect the

OPTICAL connector on your home

theater to the OPTICAL OUT connector on the TV or other device.

• The digital optical connector might be labeled SPDIF or SPDIF OUT.

Option 2: Connect audio through a digital coaxial cable

Best quality audio

Connect audio from TV and other devices

Play audio from TV or other devices through your home theater speakers. Use the best quality connection available on your TV, home theater, and other devices.

Note

• When your home theater and TV are connected

through HDMI ARC, an audio connection is not required (see 'Option 1: Connect to TV through HDMI (ARC)' on page 11).

1 Using a coaxial cable, connect the

COAXIAL connector on your home

theater to the COAXIAL/DIGITAL OUT connector on the TV or other device.

• The digital coaxial connector might be labeled DIGITAL AUDIO OUT.

13EN

Option 3: Connect audio through analog audio cables

compliant devices that are connected through HDMI can be controlled by a single remote control.

Basic quality audio

1 Using an analog cable, connect the AUX

connectors on your home theater to the AUDIO OUT connectors on the TV or other device.

VCR

Set up speakers

Set up the speakers manually to experience customized surround sound.

Before you start

Make the necessary connections described in the quick start guide, and then switch the TV to the correct source for your home theater.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Audio] > [Speaker setup] 4 Enter the distance for each speaker, and

then listen to the test tones and change the volume. Experiment with the speaker

positions to nd the ideal setting.

Set up EasyLink (HDMI-CEC control)

This home theater supports Philips EasyLink, which uses the HDMI-CEC (Consumer Electronics Control) protocol. EasyLink-

Note

• Depending on the manufacturer, HDMI-CEC is known

by many names. For information on your device, see the user manual of the device.

• Philips does not guarantee 100% interoperability with

all HDMI-CEC devices.

Before you start

• Connect your home theater to the HDMICEC compliant device through HDMI connection.

• Make the necessary connections described in the quick start guide, and then switch the TV to the correct source for your home theater.

Enable EasyLink

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [EasyLink] > [EasyLink] > [On] . 4 On your TV and other connected devices,

turn on HDMI-CEC control. For details, see the user manual of the TV or other devices.

• On your TV, set the audio output to

'Amplier' (instead of TV speakers).

For details, see the TV user manual.

EasyLink controls

With EasyLink, you can control your home theater, TV, and other connected HDMI-CEC compliant devices with a single remote control.

• [One Touch Play] (One-touch play): When a video disc is in the disc compartment, press

(Play) to wake up the TV from

standby, and then play a disc.

• [One Touch Standby] (One-touch standby): If one-touch standby is enabled, your home theater can switch to standby

14 EN

with the remote control of the TV or other HDMI-CEC devices.

• [System Audio Control] (System audio control): If system audio control is enabled, the audio of the connected device is output through your home theater speakers automatically when you play the device.

• [Audio Input Mapping] (Audio input mapping):If system audio control does not work, map the connected device to the correct audio input connector on your home theater. (see 'Set up the audio' on page 15)

Note

• To change the EasyLink control settings, press

(Home), select [Setup] > [EasyLink].

Set up the audio

If you cannot hear the audio output of a connected device through your home theater speakers, do the following:

• Check that you have enabled EasyLink on all the devices, (see 'Set up EasyLink (HDMI-CEC control)' on page 14) and

• on your TV, set the audio output to "Amplier" (instead of TV speakers). For

details, see the TV user manual, and

• setup the EasyLink audio control.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [EasyLink] > [System Audio

Control] > [On].

• To play the audio from the TV

speakers, select [Off], and skip the following steps.

4 Select [EasyLink] > [Audio Input

Mapping].

5 Follow the onscreen instructions to map

the connected device to the audio inputs on your home theater.

• If you connect your home theater to the TV through an HDMI ARC connection, make sure that the TV audio is mapped to the ARC input on your home theater.

Connect and set up a home network

Connect your home theater to a network router for a network setup, and enjoy:

• Streamed multimedia content (see 'Browse PC through DLNA' on page 26)

• Smartphone control (see 'Smartphone control' on page 23)

• Smar t TV (see 'Browse Smart TV' on page

25)

• BD Live applications (see 'BD-Live on Bluray' on page 18)

• Software update (see 'Update software through the Internet' on page 35)

Caution

• Familiarize yourself with the network router, media

server software and networking principles. If necessary, read documentation that accompanies the network components. Philips is not responsible for lost, damaged, or corrupt data.

Before you start

• For Smart TV and software updates, make sure that the network router has access to the Internet with high-speed connection

and is not restricted by rewalls or other

security systems.

• Make the necessary connections described in the quick start guide, and then switch the TV to the correct source for your home theater.

Set up the wired network

What you need

• A network cable (RJ45 straight cable).

15EN

+ 37 hidden pages
