Philips HTL5110 Users manual
Always there to help you
Register your product and get support at www.philips.com/welcome
Question?
Contact
Philips
User manual
Contents
1 |
Important |
2 |
|
Help and support |
2 |
|
Important safety instructions |
2 |
|
Care for your product |
4 |
|
Care of the environment |
4 |
|
|
|
2 |
Your SoundBar |
5 |
|
Main unit |
5 |
|
Remote control |
5 |
|
Connectors |
7 |
|
|
|
3 |
Connect and set up |
8 |
|
Subwoofer |
8 |
|
Connect audio from TV and other devices 9 |
|
|
|
|
4 |
Use your SoundBar |
10 |
|
Adjust the volume |
10 |
|
Choose your sound |
10 |
|
MP3 player |
11 |
|
USB storage devices |
11 |
|
Play audio through Bluetooth |
11 |
|
Auto standby |
12 |
|
Apply factory settings |
12 |
|
|
|
5 |
Wall mount |
13 |
|
|
|
6 |
Product specifications |
14 |
|
|
|
7 |
Troubleshooting |
15 |
|
|
|
8 |
Notice |
16 |
|
Notice of compliance |
16 |
|
Trademarks |
16 |
EN 1
1 Important
Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply.
Help and support
Philips provides extensive online support.Visit our website at www.philips.com/support to:
•download the user manual and the quick start guide
•watch video tutorials (available only for selected models)
•find answers to frequently answered questions (FAQs)
•email us a question
•chat with our support representative. Follow the instructions on the website to select your language, and then enter your product model number.
Alternatively, you can contact Philips Consumer Care in your country. Before you contact Philips, note down the model number and serial number of your product.You can find this information on the back or bottom of your product.
Important safety instructions
•• Read these instructions.
•• Keep these instructions.
•• Heed all warnings.
•• Follow all instructions.
•• Do not use this apparatus near water.
•• Clean only with dry cloth.
•• Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
•• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
•• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong.The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
•• Only use attachments/accessories specified by the manufacturer.
•• Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
•• Unplug this apparatus during lightning storm or when unused for long periods of time.
•• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
•• Battery usage CAUTION - To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit:
•Install all batteries correctly, + and - as marked on the unit.
•Do not mix batteries (old and new or carbon and alkaline, etc.).
•Remove batteries when the unit is not used for a long time.
•The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
•Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/ hazardouswaste/perchlorate.
•The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion.
•If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention.
•When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery.
•If the battery compartment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer.
•• Apparatus shall not be exposed to dripping or splashing.
•• Do not place any sources of danger on the apparatus (for example. liquid filled objects, lighted candles).
•• This apparatus may contain lead and mercury. Dispose according to local, State or Federal laws. For disposal or recycling information, please contact your local authorities. For additional assistance on recycling options, please contact www. mygreenelectronics.com or www.eiae.org or www.recycle.philips.com.
•• Where the MAINS plug or an appliance coupler is used as the disconnect device,
the disconnect device shall remain readily operable.
•• Do not place this apparatus on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling apparatus can cause serious injury or even death.
•This apparatus should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around this apparatus.
Class II equipment symbol
This symbol indicates that the unit has a double insulation system.
This 'bolt of lightning' indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering.
The 'exclamation point' calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.
WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture and objects filled with liquids, such as vases, should not be placed on this apparatus.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
2 EN |
EN 3 |
Care for your product
Use only microfiber cloth to clean the product.
Care of the environment
Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Please visit www.recycle.philips.com for additional information on a recycling center in your area.
Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products and batteries. The correct disposal of these products helps prevent potentially negative consequences on the environment and human health.
The batteries supplied do not contain the heavy metals mercury and cadmium. Nevertheless,
in many areas batteries may not be disposed of with your household waste. Please ensure you dispose of batteries according to local regulations.
For perchlorate material, special handling may apply.Visit www.dtsc.ca.gov/hazardouswaste/ perchlorate.
2 Your SoundBar
Congratulations on your purchase, and welcome to Philips!To fully benefit from the support that Philips offers, register your SoundBar at www.philips.com/welcome.
Main unit
This section includes an overview of the main unit.
a bc |
de |
A
(Standby-On/Standby indicator)
•Switch the SoundBar on or to standby.
•When the SoundBar is in standby, the standby indicator turns red.
BVOLUME +-
Increase or decrease volume.
CSOURCE
Select an input source or Bluetooth mode for the SoundBar.
DSource indicators
•AUDIO IN: Lights up when you switch to AUDIO-IN source (3.5mm jack).
•BLUETOOTH: Lights up when you switch to Bluetooth mode and Bluetooth devices are paired. Blinks
when you switch to Bluetooth mode and Bluetooth devices are not paired.
•OPT/COAX: Lights up when you switch to coaxial or optical input source. Blinks when an unsupported audio format is detected.
•AUX: Lights up when you switch to AUX input source.
•USB: Lights up when you switch to USB mode.
ESURR
•Lights up when surround mode is selected.
•Off when stereo mode is selected.
•Blinks once when night mode/auto volume is enabled.
•Blinks twice when night mode/auto volume is disabled.
•Blinks twice when Dolby Digital audio is input.
Remote control
This section includes an overview of the remote control.
4 EN |
EN 5 |
