HTL1193B
User manual
Page 2
Contents
1 Important 2
Help and support 2
Safety 2
Care for your product 3
Care of the environment 3
Compliance 4
2 Your product 4
Main unit 4
Remote control 5
Connectors 6
3 Connect 6
Placement 6
Connect audio from TV and other devices 7
4 Use your product 8
Adjust the volume 8
Choose your sound 8
MP3 player 8
USB storage devices 9
Play music via Bluetooth 9
Auto standby 10
Apply factory settings 10
Radio 10
5 Update software 11
Check software version 11
Update software via USB 11
6 Wall mount 12
7 Productspecications 13
8 Troubleshooting 14
1EN
Page 3
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.
Help and support
For extensive online support, visit
www.philips.com/support to:
• download the user manual and the quick
start guide
• watch video tutorials (available only for
selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select
your language, and then enter your product
model number.
Alternatively, you can contact Consumer Care
in your country. Before you contact, note down
the model number and serial number of your
product. You can nd this information on the
back or bottom of your product.
Safety
Riskofelectricshockorre!
• Before you make or change any
connections, make sure that all devices are
disconnected from the power outlet.
• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Consumer Care to
have the product checked before use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Batteries (battery pack or batteries
installed) shall not be exposed to excessive
heat such as sunshine, re or the like.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Riskofshortcircuitorre!
• For identication and supply ratings, see
the type plate at the back or bottom of
the product.
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.
Riskofinjuryordamagetothisproduct!
• For wall mounting, this product must be
securely attached to the wall in accordance
with the installation instructions. Use
only the supplied wall mount bracket (if
available). Improper wall mounting may
result in accident, injury or damage. If you
have any query, contact Consumer Care in
your country.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.
2 EN
Page 4
Riskofoverheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Riskofcontamination!
• Do not mix batteries (old and new or
carbon and alkaine, etc.).
• Danger of explosion if batteries are
incorrectly replaced. Replace only with the
same or equivalent type.
• Remove batteries if they are exhausted or
if the remote control is not to be used for
a long time.
• Batteries contain chemical substances, they
should be disposed of properly.
Riskofswallowingbatteries!
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compar tment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
This is CLASS II apparatus with double
insulation, and no protective earth provided.
Care for your product
Use only microber cloth to clean the product.
Care of the environment
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.
Removing the disposable batteries
To remove the disposable batteries, see battery
installation section.
3EN
Page 5
Compliance
2 Your product
This product complies with the radio
interference requirements of the European
Community.
Hereby, Gibson Innovations declares that
this product is in compliance with the
essential requirements and other relevant
provisions of Directive 2014/53/EU. You
can nd the Declaration of Conformity on
www.p4c.philips.com.
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Main unit
This section includes an overview of the main
unit.
ab c d
4 EN
a
Switch this product on or to standby.
b SOURCE
Select an input source for this product.
c Volume+/-
Increase or decrease volume.
d Display panel
Page 6
Remote control
a
b
b
b
c
d
f
e
g
h
i
j
This section includes an overview of the
remote control.
a (Standby-On)
Switch the main unit on or to standby.
b Source buttons
• COAX / OPTICAL: Switch your audio
source to the coaxial connection, or to
the optical connection.
• RADIO: Switch to radio mode.
• AUX: Switch your audio source to the
AUX connection.
• AUDIO IN: Switch your audio source
to the MP3 connection (3.5mm jack).
•
: Switch to Bluetooth mode.
• USB: Switch your audio source to the
USB connection.
c VOL +/-
• Increase or decrease volume.
d
Mute or restore volume.
e BASS +/-
Increase or decrease bass.
f NIGHT / PROGRAM
• Turn night mode on or off.
• In radio mode, press and hold for
three seconds to reinstall the radio
stations.
g TREBLE +/-
Increase or decrease treble.
h SURR
Toggle between stereo and virtual
surround sound.
i AUDIO DELAY +/-
Applicable to COAXIAL (COAX) and
OPTICAL (OPT) sources only. Increase or
decrease audio delay.
j For USB and Bluetooth mode
•
: Star t, pause or resume play.
•
/ : Skip to the previous or next
track.
For radio mode
• Press
the current preset number and
frequency.
• When the preset number is displayed,
press
station.
• When the radio frequency is displayed,
press and hold
radio station, or press briey
ne tune a radio frequency.
to toggle display between
/ to select a preset radio
/ to search a
/ to
5EN
Page 7
Connectors
h
g
3 Connect
This section includes an overview of the
connectors available on this product.
a
b
c
d
e
f
a DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
b AUX
Connect to an analog audio output on the
TV or an analog device.
c COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
d FM antenna
Extend the FM antenna for better
reception.
e
Connect to a USB storage device for audio
media play.
f AUDIO IN
Audio input from, for example, an
MP3 player (3.5mm jack).
g SUBWOOFER
Connect to the supplied subwoofer.
h AC MAINS~
Connect to the power supply.
This section helps you connect this product to a
TV and other devices.
For information about the basic connections of
this product and accessories, see the quick start
guide.
Note
For identication and supply ratings, see the type plate
•
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Placement
Place the subwoofer at least 1 meter (3 feet)
away from this product, and ten centimeters
away from the wall.
For best results, place your subwoofer as shown
below.
6 EN
Page 8
Connect audio from TV and other devices
Play audio from TV or other devices through
this product.
Use the best quality connection available on
your TV and other devices.
Option 1: Connect audio through a
digital optical cable
Best quality audio
TV
1 Using an optical cable, connect the
OPTICAL connector on this product to
the OPTICAL OUT connector on the TV
or other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
Option 3: Connect audio through
analog audio cables
Basic quality audio
DVD
1 Using an analog cable, connect the AUX
connectors on this product to the AUDIO
OUT connectors on the TV or other
device.
Option 2: Connect audio through a
digital coaxial cable
Best quality audio
1 Using a coaxial cable, connect the
COAXIAL connector on this product to
the COAXIAL/DIGITAL OUT connector
on the TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.
7EN
Page 9
4 Use your
1 Press TREBLE +/- or BASS +/- to change
the treble or bass.
product
This section helps you use this product to play
audio from connected devices.
Before you start
• Make the necessary connections
described in the Quick Start Guide
or download the User Manual from
www.philips.com/support.
• Switch this product to the correct source
for other devices.
Adjust the volume
Press VOL +/- to increase or decrease a
1
volume level.
• To mute sound, press
• To restore the sound, press
press VOL +/-.
Choose your sound
This section helps you choose the ideal sound
for your video or music.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SURR to toggle between virtual
surround and stereo.
» When virtual surround is turned on,
ON SURR scrolls on the display panel.
» When stereo sound is turned on, OFF
SURR scrolls on the display panel.
.
again or
Synchronize video and sound
If the audio and video are not synchronized,
delay the audio to match the video.
1 Press AUDIO DELAY +/- to synchronize
the audio with the video.
• AUDIO DELAY + increases the sound
delay, and AUDIO DELAY - decreases
the sound delay.
Note
This feature is only applicable to COAXIAL (COAX)
•
and OPTICAL (OPT) sources.
Night mode
For quiet listening, night mode decreases the
volume of loud sounds when audio is played.
Night mode is only available for Dolby Digital
soundtracks.
1 Press NIGHT to turn night mode on or
off.
» When night mode is turned on, ON
NIGHT scrolls on the display panel.
» When night mode is turned off, , OFF
NIGHT scrolls on the display panel.
MP3 player
Connect your MP3 player to play your audio
les or music.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
Equalizer
Change the high frequency (treble) and low
frequency (bass) settings of this product.
8 EN
1 Using the 3.5mm stereo audio cable,
connect the MP3 player to the AUDIO IN
connector on this product.
2 Press AUDIO IN.
Page 10
3 Press the buttons on the MP3 player to
select and play audio les or music.
• On the MP3 player, it is recommended
to set the volume in the range of 80%
maximum volume.
USB storage devices
Enjoy audio on a USB storage device, such as an
MP3 player and USB ash memory, etc.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies
with the Mass Storage Class.
• An MP3 le on a USB storage device
1 Connect a USB storage device to this product.
2 Press USB on the remote control.
3 Use the remote control to control play.
Button Action
Start or pause or resume play.
/ Skip to the previous or next track.
USB During play, press to toggle: repeat
one track and repeat off.
• If repeat mode is turned on, ONE
RPT scrolls on the display panel.
• If repeat mode is turned off, OFF
RPT scrolls on the display panel.
Note
This product may not be compatible with certain types
•
of USB storage device.
• If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
• Digital camera PTP and MTP protocols are not
supported.
• Do not remove the USB storage device while it is
being read.
• DRM-protected music les (MP3) are not supported.
• Support a USB por t: 5V , 1A.
Play music via Bluetooth
Through Bluetooth, connect your product with
a Bluetooth device (such as an iPad, iPhone,
iPod touch, Android phone, or laptop), and then
you can listen to the audio les stored on the
device through the speakers of this product.
What you need
• A Bluetooth device which supports
Bluetooth prole A2DP, and with Bluetooth
version as 2.1.
• The operational range between the
main unit and a Bluetooth device is
approximately 10 meters (30 feet).
1 Press on the remote control to switch
this product to Bluetooth mode.
» BT is displayed on the display panel,
blinking.
2 On the Bluetooth device, switch on
Bluetooth, search for and select Philips
HTL1193B to start connection (see the
user manual of the Bluetooth device on
how to enable Bluetooth).
» During connection, BT on the display
panel blinks.
3 Wait until this product beeps.
» When the Bluetooth connection
succeeds, BT is displayed on the display
panel.
» If the connection fails, BT on the
display panel blinks continuously.
4 Select and play audio les or music on
your Bluetooth device.
• During play, if a call is coming, music
play is paused.
• If your Bluetooth device supports
AVRCP prole, on the remote control
you can press
or press
/ to skip to a track,
to pause/resume play.
5 To exit Bluetooth, select other source.
• When your switch back to Bluetooth
mode, Bluetooth connection remains
active.
9EN
Page 11
Note
The music streaming may be interrupted by obstacles
•
between the device and this product, such as wall,
metallic casing that covers the device, or other devices
nearby that operate in the same frequency.
• If you want to connect this product with another
Bluetooth device, press and hold
control to break the current Bluetooth connection.
on the remote
Auto standby
When playing media from a connected device,
this product automatically switches to standby
after 15 minutes of button inactivity and no
audio play from a connected device.
Auto install radio stations
1 Press RADIO to switch to radio source.
» If you have not installed any radio
stations, the message AUTO INSTALL
(auto install) scrolls on the display
panel.
2 Press to install radio stations.
» RADIO INSTALL (radio install) scrolls
on the display panel.
» This product automatically stores radio
stations with sufcient signal strength.
• To clear all the existing radio stations,
press and hold PROGRAM for
3 seconds to reinstall the radio stations.
Select a preset radio station
Apply factory settings
You can reset this product to the default setting
mode.
1 In mute mode, quickly press AUX two
times.
» The factory settings is restored.
Radio
Listen to FM radio on this product, and store up
to 40 radio stations.
Note
Position the antenna as far as possible from TV or other
•
sources of radiation.
• For optimal reception, fully extend and adjust the
position of the antenna.
• AM and digital radio are not supported.
• If no stereo signal is detected, you are prompted to
install the radio stations again.
1 In radio mode, display a preset number
(press
).
2 Press / to select a preset number.
• Press RADIO to toggle between the
stereo and mono sound.
Tune to a radio station
1 In radio mode, display a radio frequency
(press
).
2 Press and hold / for more than
2 seconds.
» The radio tunes to a station
with strong reception reception
automatically.
3 Repeat step 2 to tune to more stations.
• To ne tune a radio frequency, press
briey
/ .
Program radio stations manually
1 Tune to a radio station.
2 Display the current radio frequency (press
).
10 EN
Page 12
3 Press briey PROGRAM.
» a number blinks on the display panel.
4 Press / to allocate a number to this
ration station.
5 Press to conrm.
6 Repeat the above steps to program other
stations.
Delete a preset station
1 In radio mode, display a preset number
(press
).
2 Press PROGRAM.
3 Press / to select a preset number.
4 Press to delete the radio station.
» When the radio station is deleted, DEL
is displayed briey.
Tuning grid
In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz.
1 Press RADIO to switch to radio source.
2 Press and hold to toggle between
50 kHz or 100 kHz.
5 Update software
To get the best features and support, update
your product with the latest software.
Check software version
In mute mode (press ), quickly press AUX
twice.
» The current software of this product is
displayed for 3 seconds, and then the
factory setting is restored.
Update software via USB
1
Check the latest software version on
www.philips.com/support.
• Search for your model and click on
"Software and drivers".
2 Download the software into a USB ash
drive.
a Unzip the download if zipped, and
makesurethattheunzippedleis
named "HTL1193.BIN".
b Putthe"HTL1193.BIN"leinthe
rootdirectoryoftheUSBashdrive.
3 Switch this product to AUDIO IN source
(press AUDIO IN).
4 Connect the USB storage device to the
(USB) connector on this product.
5 Switch this product to AUX source, and
then switch this product to USB source.
6 Wait until the update starts and completes.
» When the update starts, "UPG"
(upgrade) is displayed on the display
panel.
» If the update is complete, this product
automatically turns off and on again.
11EN
Page 13
Caution
3.0-3.5mm/0.12”-0.14”
Do not turn off the power or remove the USB storage
•
device when the software update is in progress because
you might damage this product.
6 Wall mount
Note
Before wall mounting, make sure the wall can suppor t
•
the weight of this product.
• For wall mounting, this product must be securely
attached to the wall in accordance with the installation
instructions. Improper wall mounting may result in
accident, injury or damage. If you have any query,
contact Consumer Care in your country.
Screw length/diameter
Depending on the type of wall mounting this
product, make sure that you use screws of a
suitable length and diameter.
4mm/
0.16”
>25mm/0.98”
See the illustration in the quick start guide on
how to wall mount this product.
1) Drill two holes on the wall.
2) Secure the dowels and screws in the holes.
3) Hang this product on the fastening screws.
12 EN
Page 14
7 Product
specifications
Note
Specications and design are subject to change without
•
notice.
Amplier
• RMS total output power:
80W RMS (+/- 0.5 dB, 10% THD)
• Frequency response:
40 Hz-20 kHz / +/-3 dB
• Signal-to-noise ratio:
> 65 dB (CCIR) / (A-weighted)
• Total Harmonic Distortion: <1%
• Input sensitivity:
• AUX: 2Vrms +/- 100mV
• AUDIO IN: 1Vrms +/- 100mV
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz,
22 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz
• Constant bit rate:
• MP3: 8 kbps-320 kbps
Radio
• Tuning range: FM 87.5-108 MHz
(50/100 kHz)
• Tuning grid: 50/100 kHz
• Sensitivity
• Mono, 26dB S/N Ratio: ≤ 22 dBf
• Stereo, 46dB S/N Ratio: ≥ 48 dBf
• Search Selectivity: ≤ 32 dBf
• Total Harmonic Distortion: <3%
• Signal to Noise Ratio: ≥ 45 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Supports MP3 le formats
Bluetooth
• Bluetooth proles: A2DP, AVRCP
• Bluetooth version: 2.1
• Frequency band/Output power:
2400 - 2483.5 MHz / ≤ 20 dBm
Main unit
• Power supply: 100-240 V~, 50/60 Hz
• Power consumption: 35 W
• Standby power consumption: ≤ 0.5 W
• Dimensions (W x H x D):
865 x 67.8 x 85.5 mm
• Weight: 1.8 kg
• Built-in speakers: 4 x full range
(54.5 mm/2", 6 ohm)
Subwoofer
• Impedance: 6 ohm
• Speaker drivers: 1 x 134 mm (5.25") woofer
• Dimensions (W x H x D):
160 x 228 x 295 mm
• Weight: 2.5 kg
Remote control batteries
• 1 x AAA-R03-1.5 V
Standby information
• When the product remains inactive for
15 minutes, it automatically switches to
standby or networked standby.
• The power consumption in standby or
networked standby is less than 0.5W.
• To deactivate Bluetooth connection, press
and hold the Bluetooth button on the
remote control.
• To activate Bluetooth connection, enable
Bluetooth connection on your Bluetooth
device, or enable Bluetooth connection via
the NFC tag (if available).
13EN
Page 15
8 Troubleshooting
Warning
•
Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem, get support at
www.philips.com/support.
Main unit
The buttons on this proudct do not work.
• Disconnect this product from the power
supply for a few minutes, then reconnect.
Sound
No sound from the speakers of this product.
• Connect the audio cable from this product
to your TV or other devices.
• Make sure that you connect the audio
input on this product to the audio output
on your TV or other devices.
• Reset this product to its factory settings.
• On the remote control, select the correct
audio input.
• Make sure that this product is not muted.
Audio and video are not synchronized.
• Press AUDIO DELAY +/- to synchronize
the audio with the video.
Distorted sound or echo.
• If you play audio from the TV through this
product, make sure that the TV is muted.
Bluetooth
A device cannot connect with this product.
• The device does not support the
compatible proles required for this
product.
• You have not enabled the Bluetooth
function of the device. See the user manual
of the device on how to enable the
function.
• The device is not correctly connected.
Connect the device correctly. (see ‘Play
music via Bluetooth’ on page 9)
• This product is already connected with
another Bluetooth device. Disconnect the
connected device, then try again.
Quality of audio play from a connected
Bluetooth device is poor.
• The Bluetooth reception is poor. Move the
device closer to this product, or remove
any obstacle between the device and this
product.
The connected Bluetooth device connects and
disconnects constantly.
• The Bluetooth reception is poor. Move the
device closer to this product, or remove
any obstacle between the device and this
product.
• Turn off Wi-Fi function on the Bluetooth
device to avoid interference.
• For some Bluetooth, the Bluetooth
connection can be deactivated
automatically to save power. This does not
indicate any malfunction of this product.
14 EN
Page 16
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
Innovations Limited is under license. Other
trademarks and trade names are those of their
respective owners.
15
Page 17
Specifications are subject to change without notice
Copyright © 2015 Gibson Innovations Limited. Revised Edition © 2017
This product has been manufactured by, and is sold under the responsibility of Gibson Innovations Ltd., and Gibson
Innovations Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used under license.
HTL1193B_98_UM_V4.0
Loading...
