Philips HTB5150K/93 Operation Manual

Always there to help you

Question?

Contact

Philips

Register your product and get support at

www.philips.com/support

HTB5150K

User manual

Contents

1 Help and support 2

Use onscreen help (user manual) 2
Navigate onscreen help 2

2 Important 3

Safety 3
Care for your product 4
Care of the environment 4
3D health warning 4

3 Your home theater 5

Remote control 5
Main unit 6
Connectors 7

4 Connect and set up 9

Placement 9
Connect to TV 9
Connect digital devices through HDMI 11
Connect audio from TV and other

devices 11
Set up EasyLink (HDMI-CEC control) 12
Connect and set up a home network 13

6 Change settings 25

Language settings 25
Picture and video settings 26
Audio settings 26
Parental control settings 26
Display settings 26
Energy saving settings 27
Speaker settings 27
Restore default settings 27

7 Update software 28

Check software version 28
Update software through USB 28
Update software through the Internet 29
Update the onscreen help 29

8 Productspecications 30

9 Troubleshooting 34

10 Notice 36

Copyright 36
Open source software 37

5 Use your home theater 15

Access the home menu 15
Discs 15

Data les 17

USB storage devices 18
Audio, video, and picture options 18
Radio 20
MP3 player 20
Smartphone control 21
Browse PC through DLNA 22
Choose sound 24

11 Language code 38

12 Index 39

1EN

1 Help and

support

Philips provides extensive online support. Visit
our website at www.philips.com/support to:

• download the complete user manual

• print the quick start guide

• watch video tutorials (available only for
selected models)

• nd answers to frequently answered
questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select
your language, and then enter your product
model number.
Alternatively, you can contact Philips Consumer
Care in your country. Before you contact
Philips, note down the model number and

serial number of your product. You can nd this

information on the back or bottom of your
product.

Use onscreen help (user manual)

For easy access, the onscreen help (user
manual) is stored on your home theater.
The onscreen help has two panels.

• The left panel contains two tabs -

Contents and Index. Navigate the
Contents or Index to select a topic. The

legends used to display the Contents are
as follows:

•

: Press to expand the subtopics.

•

: Press to collapse the subtopics,
or press Navigation buttons (up/
down) to select a topic.

• To move between the left and right panel,
press Navigation buttons (left/right).

• The right panel contains the content of
the selected topic. For additional help on
the content, scroll down the page to see
Related topics.

Use the home theater remote control to select
and navigate the onscreen help.

Navigate onscreen help

Press a button on your remote control to use
onscreen help.

Button Action

Access or exit onscreen help.
Display the selected page, or

expand subtopics in Contents.

Navigation
buttons

Move up in the Contents or

(Previous)

(Next) Display the next page from

Up: Scroll up or move to the
previous page.
Down: Scroll down or move to
the next page.
Right: Navigate to the right panel
or next index entry.
Left: Navigate to the left panel or
previous index entry.

Index.
From the right panel, move to the
Contents on the left panel.

Display the last viewed page in
history.

history.

2 EN

2 Important

Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the product checked before
use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation
slots or other openings on the product.

• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.

• Batteries (battery pack or batteries
installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• Disconnect the product from the power
outlet before lightning storms.

• When you disconnect the power cord,
always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.

Riskofinjuryordamagetothehometheater!

• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident,
injury or damage.

• For speakers with stands, use only the
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands

on at, level surfaces that can support the

combined weight of the speaker and stand.

• Never place the product or any objects
on power cords or on other electrical
equipment.

• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.

• Visible and invisible laser radiation when
open. Avoid exposure to beam.

• Do not touch the disc optical lens inside
the disc compartment.

• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.

Riskofoverheating!

• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or
carbon and alkaine, etc.).

• Danger of explosion if batteries are
incorrectly replaced. Replace only with the
same or equivalent type.

• Remove batteries if they are exhausted or
if the remote control is not to be used for
a long time.

• Batteries contain chemical substances, they
should be disposed of properly.

3EN

Riskofswallowingbatteries!

• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.

• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.

• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.

• If the battery compar tment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.

This is CLASS II apparatus with double
insulation, and no protective earth provided.

Care for your product

• Do not insert any objects other than discs
into the disc compartment.

• Do not insert warped or cracked discs into
the disc compartment.

• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.

• Use only microber cloth to clean the
product.

Care of the environment

Disposal of your old product

Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Do not throw away the product with the
normal household waste at the end of its life,

but hand it in at an ofcial collection point or

recycling. By doing this, you help to preserve the
environment.

3D health warning

If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical

professional before exposing yourself to ashing

light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache
or disorientation, we recommend not watching
3D for extended periods of time. If you
experience any discomfort, stop watching
3D and do not immediately engage in any
potentially hazardous activity (for example
driving a car) until your symptoms have
disappeared. If symptoms persist, do not resume
watching 3D without consulting a medical

professional rst.

Parents should monitor their children during
3D viewing and ensure they do not experience
any discomfort as mentioned above. Watching
3D is not recommended for children under six
years of age as their visual system is not fully
developed yet.

4 EN

3 Your home

theater

Congratulations on your purchase, and

welcome to Philips! To fully benet from the
support that Philips offers(e.g. notication

of product software upgrade), register your
product at www.philips.com/welcome.

Remote control

This section includes an overview of the
remote control.

a /

Access or exit the disc menu when you
play a disc.

b

• Return to a previous menu screen.

• In radio mode, press and hold to erase
the current preset radio stations.

c

Access or exit sound options.

d

• Access more play options while playing
a disc or a USB storage device.

• In radio mode, set a radio station.

a (Standby-On)

• Switch the home theater on or to
standby.

• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.

b Source buttons / Color buttons

• Color buttons: Select tasks or options
for Blu-ray discs.

•

: Switch to disc source.

•

•

•

c

(Home)

Access the home menu.

: This feature is not available on

this version.

: Access the onscreen help.

: Select an audio input source or

radio source.

a

Conrm an entry or selection.

b Navigation buttons

• Navigate menus.

• In radio mode, press left or right to
start auto search.

5EN

• In radio mode, press up or down to

abcd ef

tune the radio frequency.

• During network and password setup,
press left to delete a character.

c

(Mute)

Mute or restore volume.

d +/- (Volume)

Increase or decrease volume, or restore
volume when muted.

a (Stop) / (Open/Close)

• Stop play.

• Press and hold for three seconds to
open or close the disc compartment.

b

(Play)

Start or resume play.

c

/ (Previous/Next)

• Skip to the previous or next track,

chapter or le.

• In radio mode, select a preset radio
station.

d

(Pause)

Pause play.

e

/ (Fast Backward/Fast Forward)

Search backwards or forward. Press
repeatedly to change the search speed.

a Alphanumeric buttons

• Enter values or letters (using SMS style
entry).

• In radio mode, select a preset radio
station.

b

Access the main menu of a video disc.

c

Select subtitle language for video.

Main unit

This section includes an overview of the main
unit.

6 EN

a (Standby-On)

Switch the home theater on or to standby.

b

(Play/Pause)

Start, pause or resume play.

c (Stop)

• Stop play.

• In radio mode, press and hold to erase
the current preset radio stations.

d SOURCE

Select an audio or video source for the
home theater.

e

+/-

Increase or decrease volume.

f

(Open/Close)

Open or close the disc compartment.

• Slot for a USB storage device to access
BD-Live.

d COAX IN

Connect to a coaxial audio output on the
TV or a digital device.

e VIDEO

Connect to the composite video input on
the TV.

f AUX

Connect to an analog audio output on the
TV or an analog device.

Connectors

This section includes an overview of the
connectors available on your home theater.

Rear left

c

a

b

d

e

f

a AC MAINS~

Connect to the power supply.

b OPTICAL IN

Connect to an optical audio output on the
TV or a digital device.

c USB FOR VOD/BD-LIVE ONLY (VOD is

not available in China)

• Slot for a USB storage device to rent
online videos (Not available in China).

Rear right

d

ab

c

a HDMI OUT (ARC)

Connect to the HDMI input on the TV.

b HDMI IN1 / HDMI IN2

Connect to the HDMI output on a digital
device.

c LAN

Connect to the LAN input on a
broadband modem or router.

d TUNER

Signal input from an antenna, cable or
satellite.

e DOCK for iPod

This feature is not available on this version.

e

7EN

a

b

a (USB)

Audio, video or picture input from a USB
storage device.

b MUSIC iLINK / MIC (MIC is available only

in selected models)

• Audio input from an MP3 player or a
microphone.

• Audio input from a microphone
(Available only in selected models).

Subwoofer connectors

a

c Voltage selector (For some regions only)

Switch the voltage selector to the local
power line voltage.

d AC MAINS~

Connect to the power supply.

b

c

a LED

• When the power is on, the LED turns
on.

• During pair up for wireless connection
between the home theater and the
subwoofer, the LED blinks.

• When the wireless connection
succeeds, the LED turns on again.

b CONNECT

Press and hold to enter the pairing mode
for the home theater and the subwoofer.

8 EN

d

4 Connect and set

up

This section helps you connect your home
theater to a TV and other devices, and then set
it up.
For information about the basic connections
of your home theater and accessories, see the
quick start guide.

Note

For identication and supply ratings, see the type plate

•

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Placement

Place the subwoofer at least 1 meter (3
feet) away from your home theater, and ten
centimeters away from the wall.
For best results, place your subwoofer as shown
below.

Note

The home theater and the subwoofer automatically

•

pair up when you switch on the home theater and the
subwoofer.

Connect to TV

Connect your home theater to a TV to watch
videos. You can listen to the TV audio through
your home theater speakers.
Use the best quality connection available on
your home theater and TV.

Option 1: Connect to TV through
HDMI (ARC)

Best quality video

Your home theater supports HDMI version
with Audio Return Channel (ARC). If your TV
is HDMI ARC compliant, you can hear the TV
audio through your home theater by using a
single HDMI cable.

TV

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on
your home theater to the HDMI ARC
connector on the TV.

• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.

2 On your TV, turn on HDMI-CEC

operations. For details, see the TV user
manual.

• HDMI-CEC is a feature that enables
CEC compliant devices that are

9EN

connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 12)

3 If you cannot hear the TV audio through

your home theater, set up the audio
manually. (see 'Set up the audio' on page

13)

4 If you cannot hear the TV audio through

your home theater, set up the audio
manually. (see 'Set up the audio' on page

13)

Note

If your TV has a DVI connector, you can use an HDMI/

•

DVI adapter to connect to TV. However, some of the
features may not be available.

Option 2: Connect to TV through
standard HDMI

Best quality video

If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a
standard HDMI connection.

TV

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your
home theater to the HDMI connector on
the TV.

2 Connect an audio cable to hear the TV

audio through your home theater (see
'Connect audio from TV and other devices'
on page 11).

3 On your TV, turn on HDMI-CEC operations.

For details, see the TV user manual.

• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 12)

Option 3: Connect to the TV through
composite video

Basic quality video

If your TV does not have HDMI connectors, use
a composite video connection. A composite

connection does not support high-denition

video.

TV

1 Using a composite video cable, connect

the VIDEO OUT connector on your
home theater to the VIDEO IN connector
on the TV.

• The composite video connector might
be labeled AV IN, COMPOSITE, or

BASEBAND.

2 Connect an audio cable to hear the TV

audio through your home theater (see
'Connect audio from TV and other devices'
on page 11).

3 When you watch TV programs, press

on your home theater repeatedly to select
the correct audio input.

4 When you watch videos, switch your TV to

the correct video input. For details, see the
TV user manual.

10 EN

Connect digital devices through HDMI

Connect a digital device such as a set-top box,
games console, or camcorder to your home
theater through a single HDMI connection.
When you connect the devices in this way and

play a le or game, the

• video is automatically displayed on your
TV, and

• audio is automatically played on your home
theater.

1 Using a High Speed HDMI cable, connect

the HDMI OUT connector on your digital
device to the HDMI IN 1/2 on your home
theater.

2 Connect your home theater to TV through

HDMI OUT (ARC).

• If the TV is not HDMI CEC compliant,

select the correct video input on your
TV.

3 On the connected device, turn on HDMI-

CEC operations. For details, see the user
manual of the device.

• If you cannot hear the digital device

audio through your home theater, set
up the audio manually. (see 'Set up the
audio' on page 13)

• You can also press

home theater repeatedly to select the
correct HDMI input.

on your

Note

When your home theater and TV are connected

•

through HDMI ARC, an audio connection is not
required (see 'Option 1: Connect to TV through HDMI
(ARC)' on page 9).

Option 1: Connect audio through a
digital optical cable

Best quality audio

TV

1 Using an optical cable, connect the

OPTICAL connector on your home

theater to the OPTICAL OUT connector
on the TV or other device.

• The digital optical connector might be
labeled SPDIF or SPDIF OUT.

Option 2: Connect audio through a
digital coaxial cable

Good quality audio

Connect audio from TV and other devices

Play audio from TV or other devices through
your home theater speakers.
Use the best quality connection available on
your TV, home theater, and other devices.

1 Using a coaxial cable, connect the

COAXIAL connector on your home

theater to the COAXIAL/DIGITAL OUT
connector on the TV or other device.

• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.

11EN

Option 3: Connect audio through
analog audio cables

Basic quality audio

AUDIO IN- AUX

VCR

1 Using an analog cable, connect the AUX

connectors on your home theater to the
AUDIO OUT connectors on the TV or
other device.

Set up EasyLink (HDMI-CEC control)

This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer
Electronics Control) protocol. EasyLink­compliant devices that are connected through
HDMI can be controlled by a single remote
control.

Note

Depending on the manufacturer, HDMI-CEC is known

•

by many names. For information on your device, see
the user manual of the device.

• Philips does not guarantee 100% interoperability with

all HDMI-CEC devices.

Before you start

• Connect your home theater to the HDMI­CEC compliant device through HDMI
connection.

• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.

Enable EasyLink

1 Press (Home).
2 Select [Setup], and then press .
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,

turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.

• On your TV, set the audio output to

'Amplier' (instead of TV speakers).

For details, see the TV user manual.

EasyLink controls

With EasyLink, you can control your home
theater, TV, and other connected HDMI-CEC
compliant devices with a single remote control.

• [One Touch Play] (One-touch play): When
a video disc is in the disc compartment,
press

(Play) to wake up the TV from

standby, and then play a disc.

• [One Touch Standby] (One-touch
standby): If one-touch standby is enabled,
your home theater can switch to standby
with the remote control of the TV or other
HDMI-CEC devices.

• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is
output through your home theater
speakers automatically when you play the
device.

• [Audio Input Mapping] (Audio input
mapping):If system audio control does not
work, map the connected device to the
correct audio input connector on your
home theater. (see 'Set up the audio' on
page 13)

Note

To change the EasyLink control settings, press

•

(Home), select [Setup] > [EasyLink].

12 EN

Set up the audio

If you cannot hear the audio output of a
connected device through your home theater
speakers, do the following:

• Check that you have enabled EasyLink
on all the devices, (see 'Set up EasyLink
(HDMI-CEC control)' on page 12) and

• on your TV, set the audio output to

"Amplier" (instead of TV speakers). For

details, see the TV user manual, and

• setup the EasyLink audio control.

1 Press (Home).
2 Select [Setup], and then press .
3 Select [EasyLink] > [System Audio

Control] > [On].

• To play the audio from the TV

speakers, select [Off], and skip the
following steps.

4 Select [EasyLink] > [Audio Input

Mapping].

5 Follow the onscreen instructions to map

the connected device to the audio inputs
on your home theater.

• If you connect your home theater

to the TV through an HDMI ARC
connection, make sure that the TV
audio is mapped to the ARC input on
your home theater.

Caution

Familiarize yourself with the network router, media

•

server software and networking principles. If necessary,
read documentation that accompanies the network
components. Philips is not responsible for lost, damaged,
or corrupt data.

Before you start

• For software update, make sure that the
network router has access to the Internet
with high-speed connection and is not

restricted by rewalls or other security

systems.

• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.

Set up the wired network

What you need

• A network cable (RJ45 straight cable).

• A network router (with DHCP enabled).

LAN

Connect and set up a home network

Connect your home theater to a network
router through wired or wireless network
connection, and enjoy:

• Streamed multimedia content

• Smartphone control

• Software update (see 'Update software
through the Internet' on page 29)

www

1 Using a network cable, connect the LAN

connector on your home theater to the
network router.

2 Press (Home).
3 Select [Setup], and then press .
4 Select [Network] > [Network

installation] > [Wired (Ethernet)].

13EN

5 Follow the onscreen instructions to

complete the setup.

• If connection fails, select [Retry], and

then press

6 Select [Finish], and then press to exit.

• To view the network settings, select

[Setup] > [Network] > [View
network settings].

Set up the wireless network

Your home theater has a built-in Wi-Fi for easy
access to a wireless network.

What you need

• A network router (with DHCP enabled).
For best wireless performance, coverage,
and compatibility, use 802.11n router.

.

5 Select [Finish], and then press to exit.

• To view the network settings, select

[Setup] > [Network] > [View
wireless settings].

Personalize the network name

Name your home theater to easily identify it on
your home network.

1 Press (Home).
2 Select [Setup], and then press .
3 Select [Network] > [Name your

Product:].

4 Press the Alphanumeric buttons to enter

the name.

5 Select [Done], and then press to exit.

www

1 Press (Home).
2 Select [Setup], and then press .
3 Select [Network] > [Network

installation] > [Wireless (Wi-Fi)], and

then press

4 Follow the onscreen instructions to select

and set up the wireless network.

• If connection fails, select [Retry], and

then press

14 EN

.

.

5 Use your home

Discs

theater

This section helps you use the home theater to
play media from a wide range of sources.

Before you start

• Make the necessary connections described
in the quick start guide and the user manual.

• Complete the rst-time setup. First-time
setup appears when you turn on your

home theater for the rst time or if you do

not complete the setup.

• Switch the TV to the correct source for your
home theater (for example, HDMI, AV IN).

Access the home menu

The home menu provides easy access to
connected devices, setup and other useful
features in your home theater.

1 Press (Home).

» The home menu is displayed.

2 Press the Navigation buttons and to

select the following:

• [play Disc]: Start disc play.

• [browse USB]: Access the USB

content browser

• [browse iPod]: This feature is not

available on this version.

• [browse PC]: Access the computer

content browser.

• [HDMI 1]: Select the digital device

connected to HDMI IN 1 on your
home theater.

• [HDMI 2]: Select the digital device

connected to HDMI IN 2 on your
home theater.

• [Setup]: Access menus to change video,

audio and other settings.

• [Help]: Access onscreen user manual.

3 Press (Home) to exit.

Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that
you’ve made at home, such as CD-R discs of
photos, videos, and music.

1 Insert a disc into the home theater.
2 If the disc does not play automatically, press

DISC or select [play Disc] from the home

menu.

3 Use the remote control to control play

(see 'Play buttons' on page 15).

• It is normal to hear a little noise when
you play a Blu-ray disc. This does not
mean that your home theater is faulty.

Play buttons

Button Action

Navigation
buttons

(Play) Start or resume play.

/ Skip to the previous or next track,

/ Search fast backwards or forward.

Access the advanced options

Navigate menus.
Up/Down: Rotate the picture
clockwise or counter-clockwise.

Conrm an entry or selection.

Pause play.
Stop play.
Press and hold for three seconds

to open or close the disc
compartment.

chapter or le.

When a video is paused, search
slow backwards or forward.

Select subtitle language for video.

/ Access or exit the disc menu.

when you play your audio, video,

or media les (see 'Audio, video,

and picture options' on page 18).

15EN

Synchronize picture and sound

If the audio and video are not synchronized,
delay the audio to match the video.

1 Press .
2 Select AUD SYNC, and then press .
3 Press the Navigation buttons (up/down)

to synchronize the audio with the video.

4 Press to conrm.

Play Blu-ray 3D disc

Your home theater can play Blu-ray 3D video.
Read the 3D health warning before playing a
3D disc.

What you need

• A 3D TV

• A pair of 3D glasses that are compatible
with your 3D TV

• A 3D Blu-ray video

• A high speed HDMI cable

1 Using the high speed HDMI cable, connect

your home theater to a 3D compatible TV.

2 Make sure that the 3D video setting is

enabled. Press
[Video] > [Watch 3D video] > [Auto].

• To play 3D discs in 2D mode, select

[Off].

(Home), select [Setup] >

3 Play a Blu-ray 3D disc and put on the 3D

glasses.

• During video search and in certain play

modes, the video is displayed in 2D.
The video display returns to 3D when
you resume play.

Note

To avoid ickering, change the brightness of the display.

•

Bonus View on Blu-ray

On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known
as picture-in-picture.

1 Enable Bonus View in the Blu-ray disc

menu.

2 While you play the movie, press .

» The options menu is displayed.

3 Select [PIP selection] > [PIP].

• Depending on the video, PIP menu [1]
or [2] is displayed.

• To disable Bonus View, select [Off].

4 Select [2nd audio language] or [2nd

Subtitle Language].

5 Select the language, and then press .

BD-Live on Blu-ray

Access additional features on the Blu-ray discs
with BD-Live content, such as internet chats
with the director, the latest movie trailers,
games, wallpaper, and ringtones.
BD-Live services and content var y from disc to
disc.

What you need

• Blu-ray disc with BD-Live content

• a USB storage device, with at least 1 GB of
memory

1 Connect your home theater to a home

network with Internet access (see
'Connect and set up a home network' on
page 13).

2 Connect a USB storage device to your

home theater.

3 Press (Home) and select [Setup].
4 Select [Advanced] > [Local storage].
5 Select [USB].

• Use a USB storage device to store the

downloaded BD-Live content.

16 EN

6 Select [Advanced] > [BD-Live security] >

[Off] to enable BD-Live.

• To disable BD-Live, select [On].

7 Select the BD-Live icon in the disc menu,

and then press

» BD-Live starts to load. The loading

time depends on the disc and your
internet connection.

.

8 Press the Navigation buttons to navigate

BD-Live, and then press
option.

Note

To clear the memory on the storage device, press

•

(Home), select [Setup] > [Advanced] > [Clear

memory].

to select an

Datales

Your home theater can play pictures, audio and

video les contained in a disc or a USB storage
device. Before you play a le, check that the le

format is supported by your home theater (see
'File formats' on page 31).

1 Play the les from a disc or USB storage

device.

2 To stop play, press .

• To resume the video from where you
stopped, press

• To play the video from the start, press

.

Note

To play DivX DRM protected les, connect your home

•

theater to a TV through an HDMI cable.

(Play).

Note

Make sure that the subtitle le has the exact same

•

name as the video le. For example, if the video le is
named 'movie.avi', name the subtitle le as 'movie.sr t'

or 'movie.sub'.

• Your home theater supports the following le formats:

.srt, .sub, .txt, .ssa, .ass, smi, and .sami. If the subtitles do
not appear correctly, change the character set.

1 While playing video, press to select a

language.

2 For DivX videos, if the subtitles do not

appear correctly, continue the following
steps to change the character set.

3 Press .

» The options menu is displayed.

4 Select [Character set], and then select a

character set that supports the subtitle.

Europe, India, LATAM, and Russia

Character
Set

[Standard] English, Albanian, Danish,

[Central
Europe]

[Cyrillic] Bulgarian, Belorussian, English,

[Greek] Greek
[Baltic] Estonian, Latvian and Lithuanian

Asia Pacic and China

Language

Dutch, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese, Spanish,
Swedish and Turkish

Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Sorbian

Macedonian, Moldavian, Russian,
Serbian and Ukrainian

Subtitles

If your video has subtitles in multiple languages,
select a subtitle language.

Character
Set

[Chinese] Simplied Chinese

Language

17EN

Character
Set

[Standard] Albanian, Danish, Dutch, English,

[Chinese­Traditional]

[Korean] English and Korean

Language

Finnish, French, Gaelic, German,
Italian, Kurdish (Latin), Norwegian,
Portuguese, Spanish, Swedish,
Turkish

Traditional Chinese

2 Press (Home).
3 Select [browse USB], and then press .

» A content browser is displayed.

4 Select a le, and then press .
5 Press the play buttons to control play (see

'Play buttons' on page 15).

Audio, video, and picture options

VOD code for DivX

Before you purchase DivX videos and play
them on your home theater, register the home
theater on www.divx.com using the DivX VOD
code.

1 Press (Home).
2 Select [Setup], and then press .
3 Select [Advanced] > [DivX

» The DivX VOD registration code for

your home theater is displayed.

®

VOD Code].

USB storage devices

Enjoy pictures, audio, and video stored on a
USB storage device such as an MP4 player or
digital camera.

What you need

• A USB storage device that is formatted for

FAT or NTFS le systems, and complies

with the Mass Storage Class.

• A media le in one of the supported le
formats (see 'File formats' on page 31).

Note

If you use a USB extension cable, USB HUB, or USB

•

multi-reader, the USB storage device may not be
recognized.

1 Connect a USB storage device to the

(USB) connector on your home theater.

Use advanced features when you play pictures,

audio and video les from a disc or a USB

storage device.

Audio options

While playing audio, repeat an audio track, a
disc, or a folder.

1 Press repeatedly to cycle through

the following functions:

• RPT TRAC / RPT FILE: Repeat the

current track or le.

• RPT DISC / RPT FOLD: Repeat all the
tracks on the disc or the folder.

• RPT RAND: Play audio tracks in
random order.

• RPT OFF: Turn off the repeat mode.

Video options

While watching video, select options such
as subtitles, audio language, time search, and
picture settings. Depending on the video source,
some options are not available.

1 Press .

» The video options menu is displayed.

2 Press the Navigation buttons and to

select and change:

• [Audio language]: Select audio
language for video.

• [Subtitle Language]: Select subtitle
language for video.

18 EN

• [Subtitle shift]: Change the subtitle
position on the screen.

• [Info]: Display information about what
is playing.

• [Character set]: Select a character set
that supports the DivX subtitle.

• [Time search]: Skip to a specic part
of the video by entering the time of
the scene.

• [2nd audio language]: Select the
second audio language for Blu-ray
video.

• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray
video.

• [Titles]: Select a specic title.

• [Chapters]: Select a specic chapter.

• [Karaoke] (Available in selected model
and region): Change the karaoke
settings.

• [Angle list]: Select a different camera
angle.

• [Menus]: Display the disc menu.

• [PIP selection]: Display Picture-in­Picture window when playing a Blu-ray
disc that supports the Bonus View.

• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.

• [Repeat]: Repeat a chapter or title.

• [Repeat A-B]: Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.

• [Picture settings]: Select a predened
color setting.

• [Audio sync]: Delay the audio to
match the video.

• [2D to 3D]: Select 2D or 3D video.

2 Press the Navigation buttons and to

select and change the following settings:

• [Rotate +90]: Rotate the picture 90
degree clockwise.

• [Rotate -90]: Rotate the picture 90
degree counter-clockwise.

• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.

• [Info]: Display picture information.

• [Duration per slide]: Select the display
speed for each picture in a slide show.

• [Slide animation]: Select animation for
the slide show.

• [Picture settings]: Select a predened
color setting.

• [Repeat]: Repeat a selected folder.

• [2D to 3D]: View 2D or 3D photo
slideshow.

Musical slideshow

If the picture and audio les are from the same

disc or USB storage device, you can create a
musical slideshow.

1 Select an audio track, and then press .
2 Press , and go to the picture folder.
3 Select a picture, and then press (Play) to

start the slideshow.

4 Press to stop slideshow.
5 Press again to stop music.

Note

Make sure that the picture and audio formats are

•

supported by your home theater (see 'File formats' on
page 31).

Picture options

While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and
change the picture settings.

1 Press .

» The picture options menu appears.

19EN

Radio

Listen to FM radio on your home theater, and
store up to 40 radio stations.

Note

AM and digital radio are not supported.

•

• If no stereo signal is detected, or if fewer than ve

stations are found, you are prompted to install the
radio stations again.

1 Connect the FM antenna to the TUNER at

the back of your home theater.

• For the best reception, place the
antenna away from your TV or other
sources of radiation.

2 Press repeatedly until RADIO

appears on the display panel.

» If you have already installed the radio

stations, the last channel that you
listened to is played.

» If you have not installed any radio

stations, the message AUTO
INSTALL...PRESS PLAY appears on
the display panel. Press

(Play).

3 Use the remote control to listen or to

change radio stations.

Button Action

Manual:

1) Press

2) Press
preset.

3) Press
store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.

Toggle between the stereo
and mono sounds.

.
/ to select your

again to

Tuning grid

In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz. When you
switch the tuning grid, all preset radio stations
are erased.

1 Press repeatedly until RADIO

appears on the display panel.

2 Press .
3 Press and hold (Play) to toggle between

50 kHz or 100 kHz.

MP3 player

Play buttons

Button Action

/

or

Alphanumeric
buttons

Navigation
buttons

Press and hold to erase the

20 EN

Select a preset radio station.

Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.

Press to stop the installation
of radio stations.

preset radio station.

Connect a MP3 player to play audio les.

What you need

• An MP3 player.

• A 3.5mm stereo audio cable.

1 Using the 3.5mm stereo audio cable,

connect the MP3 player to the MUSIC
iLINK connector on your home theater.

• If you use 6.5mm stereo audio cable,
connect the MP3 player to your
home theater using a 3.5mm - 6.5mm
converter jack.

2 Press repeatedly until MUSIC I-LINK

appears on the display panel.

3 Press the buttons on the MP3 player to

select and play audio les.

Smartphone control

Use your mobile device such as iPhone (iOS

3.1.3 and above), Android phone (2.1 and
above), iPad, or tablet to:

• Control your home theater

• Browse a data disc or USB storage device

• Switch to FM radio

• Personalize your sound settings

• Stream and share content from the devices
on your home network

Before you start

• Connect your home theater, mobile device,
and other DLNA-compatible devices to
the same home network.

• For better video quality, use wired

connection whenever possible.

• Personalize the network name for your
home theater (see 'Personalize the
network name' on page 14).

• Download Philips MyRemote application
on your mobile device.

• For iPhone or iPad, search for the app

in App Store (App Store).

• For Android based phone or tablet,

search for the app in Market (Market).

Control your home theater

1 On the mobile device, access MyRemote

application.

2 Select your home theater (by its network

name) from the home screen.

» A browsing bar is displayed at the

bottom of the screen.

• If your home theater is not found,

check the network connection or tap
the Devices tab on your mobile device
to search again.

3 Select one of the following tabs to access

more options.

• To return to the previous screen, press
back button.

Option Action

App
Home

Media DISC: Browse and play a le stored

Remote Access the remote control on your

Sound MySound: Personalize the sound

Return to the home screen of your
device.

on a data disc.

USB: Browse and play a le stored

on a USB storage device.
FM radio: Switch to FM radio.

mobile device. Swipe the screen
to the left or right to access more
buttons. Only the relevant buttons
are enabled on your mobile device.
Some functions such as standby
and long press, are not available on
the mobile device.

setting to suit your preference.
Surround: Select a surround sound
setting.

4 Follow the onscreen instructions to select

an option or complete the set up.

Stream multimedia content
(SimplyShare)

Philips SimplyShare allows you to use your
smartphone to stream multimedia content

(such as pictures, audio and video les), and play

through your home theater or any DLNA­compatible device in the same home network.

Before you start

• Install a DLNA-compliant media server
application on your mobile device, such as
Twonky Media Server.

• Enable media sharing of les. For details,
check the user manual of the media server
software software.

1 On the mobile device, launch the media

server application. For iPhone or Android
phone, access MyRemote application.

21EN

2 From the menu of your mobile device,

select SimplyShare.

» Your home theater and other

devices on the home network are
automatically detected and displayed
on the screen.

3 Select a device on the network.

» The folders in the selected device are

displayed. Depending on the media
server, the folder names may vary.

• If you cannot see the folders, make
sure that you enable media sharing on
the selected device so that the content
is available for sharing.

4 Select a media le to play.
5 From the menu on your mobile device,

select the home theater to stream the

media le to your home theater.

• Some media les may not display
or play due to compatibility issues.
For your home theater, check the

supported le formats.

6 Use your mobile device to control play.

Browse PC through DLNA

Access and play the pictures, audio and video

les from a computer or media server on the

home network through your home theater.

Before you start

• Install a DLNA-compliant media server
application on your device. Make sure that
you download an application that works
best for you. For example,

• Windows Media Player 11 or higher

for PC

• Twonky Media Server for Mac or PC

• Enable media sharing of les. For ease of
use, we have included the steps for the
following applications:

• Windows Media Player 11 (see

'Microsoft Windows Media Player 11'
on page 22)

• Windows Media Player 12 (see
'Microsoft Windows Media Player 12'
on page 23)

• Twonky Media for Mac (see 'Macintosh
OS X Twonky Media (v4.4.2)' on page

23)

Note

For additional help on these applications or other

•

media servers, check the user manual of the media
server software software.

Set up media server software

To enable media sharing, set up the media
server software.

Before you start

• Connect your home theater to a home
network. For better video quality, use wired
connection whenever possible.

• Connect the computer and other DLNA­compatible devices to the same home
network.

• Make sure that your PC rewall allows
you to run Media Player programs (or

the rewall’s exemption list has the media

server software included).

• Switch on your computer and the router.

Microsoft Windows Media Player 11

1 Start Windows Media Player on your PC.
2 Click the Library tab, and then select

Media Sharing.

3 The rst time you select Media Sharing on

your PC,a pop-up screen appears. Check
the Share my media box and click OK.

» The Media Sharing screen is displayed.

4 In the Media Sharing screen, make sure

that you see a device marked as Unknown
Device.

» If you don't see an unknown device

after a minute or so, check that

your PC rewall is not blocking the

connection.

22 EN

5 Select the unknown device and click Allow.

» A green tick appears next to the

device.

6 By default, Windows Media Player shares

from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, select Library > Add to Library.

» The Add to Library screen is displayed.

• If necessary, select Advanced options
to display a list of monitored folders.

7 Select My folders and those of others I

can access, and then click Add.

8 Follow the onscreen instructions to add

the other folders that contain your media

les.

Microsoft Windows Media Player 12

1 Start Windows Media Player on your PC.
2 In Windows Media Player, click the Stream

tab, and then select Turn on media
streaming.

» The Media streaming options screen

is displayed.

3 Click Turn on media streaming.

» You return to Windows Media Player

screen.

4 Click the Stream tab and select More

streaming options.

» The Media streaming options screen

is displayed.

5 Make sure that you see a media program

in the Local network screen.

» If you don't see a media program,

check that your PC rewall is not

blocking the connection.

6 Select the media program and click Allowed.

» A green arrow appears next to the

media program.

7 By default, Windows Media Player shares

from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, click the Organize tab and select
Manage libraries > Music.

» The Music Library Locations screen is

displayed.

8 Follow the onscreen instructions to add the

other folders that contain your media les.

Macintosh OS X Twonky Media (v4.4.2)

1 Visit www.twonkymedia.com to purchase

the software, or download a free 30-day
trial to your Macintosh.

2 Start Twonky Media on the Macintosh.
3 In the Twonky Media Server screen, select

Basic Setup and First Steps.

» The First steps screen is displayed.

4 Type a name for your media server, and

then click Save changes.

5 Back in the Twonky Media screen, select

Basic Setup and Sharing.

» The Sharing screen is displayed.

6 Browse and select folders to share, and

then select Save Changes.

» Your Macintosh rescans the folders

automatically so that they are ready to
share.

PlaylesfromyourPC

Note

Before you play multimedia content from the computer,

•

make sure that the home theater is connected to
the home network, and the media server software is
properly set up.

1 Press (Home).
2 Select [browse PC], and then press .

» A content browser is displayed.

3 Select a device on the network.

» The folders in the selected device are

displayed. Depending on the media
server, the folder names may vary.

• If you cannot see the folders, check
that you have enabled media sharing
on the selected device so that the
content is available for sharing.

23EN

4 Select a le, and then press .

• Some media les may not play due

to compatibility issues. Check the le

formats supported by your home theater.

5 Press the play buttons to control play (see

'Play buttons' on page 15).

Choose sound

This section helps you choose the ideal sound
for your video or music.

1 Press .
2 Press the Navigation buttons (left/right) to

access the sound options on the display.

Sound options Description

SOUND Select a sound mode.
SURROUND Select surround sound or

stereo sound.

AUD SYNC Delay the audio to match the

video.

AUTO VOL Reduce sudden changes in

volume, for example, during
TV commercials.

3 Select an option, and then press .
4 Press to exit.

• If you do not press a button within a
minute, the menu exits automatically.

Surround sound mode

Experience an immersive audio experience with
surround sound modes.

1 Press .
2 Select SURROUND, and then press .
3 Press the Navigation buttons (up/down)

to select the following settings:

• AUTO: Surround sound based on the
audio stream.

• V SURR: Vir tual Surround.

• STEREO: Two-channel stereo sound.
Ideal for listening to music.

4 Press to conrm.

Sound mode

Select predened sound modes to suit your

video or music.

1 Make sure that audio post processing is

enabled at the speakers (see 'Speaker
settings' on page 27).

2 Press .
3 Select SOUND, and then press .
4 Press the Navigation buttons (up/down)

to select a setting on the display:

• AUTO:Intelligently select the best
sound setting based on the audio
played.

• BALANCED: Experience the original
sound of your movies and music,
without added sound effec ts.

• POWERFUL: Enjoy thrilling arcade
sounds, ideal for action-packed videos
and loud parties.

• BRIGHT: Spice up your dull movies
and music with added sound effects.

• CLEAR: Hear every detail in your
music and clear voices in your movies.

• WARM: Experience spoken words and
music vocals in comfort.

• PERSONAL: Personalize the sound
based on your preferences.

5 Press to conrm.

Equalizer

Change the high frequency (treble), mid
frequency (mid), and low frequency (bass)
settings of the home theater.

1 Press .
2 Select SOUND > PERSONAL, and then

press Navigation buttons (right).

3 Press the Navigation buttons (up/down)

to change bass, mid or treble frequency.

4 Press to conrm.

24 EN

Auto volume

Turn on auto volume to reduce sudden changes
in volume, for example, during TV commercials.

1 Press .
2 Select AUTO VOL, and then press .
3 Press the Navigation buttons (up/down)

to select ON or OFF.

4 Press to conrm.

6 Change settings

The home theater settings are already

congured for optimal performance. Unless

you have a reason to change a setting, we
recommend that you keep the default setting.

Note

You cannot change a setting that is grayed out.

•

• To return to the previous menu, press . To exit

the menu, press

Language settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Preference], and then press .
4 Press the Navigation buttons and to

select and change:

• [Menu language]: Select a display
language for menu.

• [Audio]: Select an audio language for
discs.

• [Subtitle]: Select a subtitle language
for discs.

• [Disc menu]: Select a menu language
for discs.

(Home).

Note

If your preferred disc language is not available, select

•

[Others] from the list, and enter the 4-digit language
code found at the end of this user manual (see
'Language code' on page 38).

• If you select a language that is not available on a disc,

the home theater uses the default language of the disc.

25EN

Picture and video settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Video], and then press .
4 Press the Navigation buttons and to

select and change:

• [TV display]: Select a picture format to

t the TV screen.

• [HDMI video]: Select the resolution of
video signal that is output from HDMI
OUT (ARC) on your home theater.
To enjoy the selected resolution,
make sure that your TV suppor ts the
selected resolution.

• [HDMI Deep Color]: Recreate the
natural world on your TV screen by
displaying vivid images using billion
colors. Your home theater must be
connected to a Deep Color enabled
TV through an HDMI cable.

• [Picture settings]: Select pre dened
color settings for the video display. Select
[User] to create your own setting.

• [Watch 3D video]: Set HDMI video to
support 3D or 2D video.

is only available in DVDs and Blu-ray
discs with Dolby Digital, Dolby Digital
Plus, and Dolby True HD soundtracks.

• [HDMI Audio]: Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.

• [Audio sync]: Set audio delay if audio
and video cannot be matched.

Parental control settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Preference], and then press .
4 Press the Navigation buttons and to

select and change:

• [Change Password]: Set or change
your password for parental control
access. If you do not have a password
or have forgotten your password, enter

0000.

• [Parental control]: Restrict access
to discs that are recorded with age
ratings. To play all discs, irrespective of
the ratings, select 8 or [Off].

Note

If you change a setting, make sure that the TV supports

•

the new setting.

Audio settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Audio], and then press .
4 Press the Navigation buttons and to

select and change:

• [Night mode]: For quiet listening,
decrease the volume of loud sounds
on your home theater. Night mode

26 EN

Display settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Preference], and then press .
4 Press the Navigation buttons and to

select and change:

• [Auto subtitle shift]: Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.

• [Display panel]: Set the brightness of
the home theater front panel display.

• [VCD PBC]: Enable or disable the
content menu navigation of VCD and
SVCD discs with Play Back Control
feature.

Energy saving settings

Restore default settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Preference], and then press .
4 Press the Navigation buttons and to

select and change:

• [Screen saver]: Switch the home
theater to screen saver mode after 10
minutes of inactivity.

• [Auto standby]: Switch the home
theater to standby after 30 minutes of
inactivity. This timer works only when a
disc or USB play is paused or stopped.

• [Sleep timer]: Set the duration of the
sleep timer so that the home theater is

switched to standby after the specied

period.

Speaker settings

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Advanced], and then press .
4 Press the Navigation buttons and to

select and change:

• [Enhanced audio]: Select [On] to
enable audio post processing at the
speaker and enable karaoke settings
(if your product supports Karaoke).
To play the original audio of the disc,
select [Off].

1

Press (Home).

2 Select [Setup], and then press .
3 Select [Advanced] > [Restore default

settings], and then press

.

4 Select [OK], and then press to

conrm.

» Your home theater is reset to its

default settings except for some
settings such as parental control and
DivX VOD registration code.

Tip

Enable audio post processing before you select a

•

predened sound mode (see 'Sound mode' on page

24).

27EN

7 Update software

Update software through USB

Philips continually tries to improve its products.
To get the best features and support, update
your home theater with the latest software.

Compare the version of your current
software with the latest version on
www.philips.com/support. If the current version
is lower than the latest version available on the
Philips support website, upgrade your home
theater with the latest software.

Caution

Do not install a lower version of software than the

•

current version installed on your product. Philips is not
liable for problems caused due to software downgrade.

Check software version

Check the version of the current software
installed on your home theater.

1 Press (Home).
2 Select [Setup], and then press .
3 Select [Advanced] > [Version

information].

» The software version is displayed.

• 'System SW' displayed indicates the
overall software version. 'Subsystem
SW' indicates the version of different
features. For example, if 'Subsystem
SW' is '35-00-00-05”, the last two
digits ('05') indicate the current version
of the onscreen help installed on your
home theater.

What you need

• A USB ash drive that is FAT or NTFS-
formatted, with at least 256MB of memory.
Do not use a USB hard drive.

• A computer with Internet access.

• An archive utility that supports the ZIP le
format.

Step 1: Download the latest software

1 Connect a USB ash drive to your

computer.

2 In your web browser, go to

www.philips.com/support.

3 At the Philips Support website, nd your

product and locate the Software and
drivers.

» The software update is available as a

zip le.

4 Save the zip le in the root directory of

your USB ash drive.

5 Use the archive utility to extract the

software update le in the root directory.

» The les are extracted under the UPG

folder of your USB ash drive.

6 Disconnect the USB ash drive from your

computer.

Step 2: Update the software

Caution

Do not switch off the home theater or remove the

•

USB ash drive during the update.

1 Connect the USB ash drive containing the

downloaded le to your home theater.

• Make sure that the disc compartment

is closed and no disc inside.

2 Press (Home).
3 Select [Setup], and then press .

28 EN

4 Select [Advanced] > [Software update]

> [USB].

5 Follow the onscreen instructions to

conrm the update.

» Update process takes about 5 minutes

to complete.

» Once complete, the home theater

automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.

Update software through the Internet

1 Connect your home theater to a home

network with a high-speed Internet access
(see 'Connect and set up a home network'
on page 13).

2 Press (Home).
3 Select [Setup], and then press .
4 Select [Advanced] > [Software update] >

[Network].

» If an upgrade media is detected, you

are prompted to start or cancel the
update.

» Downloading of the upgrading le may

take long, depending on your home
network condition.

5 Follow the onscreen instructions to

conrm the update.

» Update process takes about 5 minutes

to complete.

» Once complete, the home theater

automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.

Update the onscreen help

If the current version of the onscreen help
is lower than the latest version available on
www.philips.com/support, download and install
the latest onscreen help (see 'Check software
version' on page 28).

What you need

• A USB ash drive that is FAT or NTFS-
formatted, with at least 35MB of memory.
Do not use a USB hard drive.

• A computer with internet access.

• An archive utility that supports the ZIP le
format.

Step 1: Download the latest onscreen
help

1 Connect a USB ash drive to your

computer.

2 In your web browser, go to

www.philips.com/support.

3 At the Philips support website, nd your

product and click on User manuals, and
then locate the User Manual Upgrade
Software.

» The help update is available as a zip

le.

4 Save the zip le in the root directory of

your USB ash drive.

5 Use the archive utility to extract the help

update le in the root directory.

» A le named 'HTBxxxxeDFU.zip' is

extracted under the UPG folder of

your USB ash drive, 'xxxx' being the

model number of your home theater.

6 Disconnect the USB ash drive from your

computer.

29EN

Step 2: Update onscreen help

8 Product

Caution

Do not switch off the home theater or remove the

•

USB ash drive during the update.

1 Connect the USB ash drive containing the

downloaded le to your home theater.

• Make sure that no disc is inside the
disc compartment.

2 Press (Home).
3 Enter 338 on the remote control.
4 Follow the onscreen instructions to

conrm the update.

5 Disconnect the USB ash drive from the

home theater.

specifications

Note

Specications and design are subject to change without

•

notice.

Region codes

The type plate on the back or bottom of the
home theater shows which regions it supports.

Country

Europe,
United Kingdom

Asia Pacific, Taiwan,

Korea

New Zealand

DVD BD

AA

Latin America

AA

Australia,

Russia, India

CC

30 EN

China

CC

Media formats

• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture les, MP3 media,

WMA media, DivX Plus HD media, USB
storage device

File formats

• Audio:

• .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a,

.ac, .ogg

• Video:

• .avi, .divx, .mp4, .m4v, .mkv, .m2ts, .mpg,

.mpeg, .v, .3gp

• .asf, .wmv

• Picture: .jpg, .jpeg, .png

Video formats

If you have a high denition TV, your home

theater allows you to play your:

• video les with a resolution of 1920 x
1080 pixels (except DivX, which has a
resolution of 77220 x 576) and frame rate
of 6 ~ 30 frames per second.

• photo les with a resolution of 18 M pixels.

.avilesinAVIcontainer

Audio formats

Your home theater supports the following

audio les.

Extension Con-

.mp3 MP3 MP3 Upto 320 kbps
.wma ASF WMA Upto 192 kbps

.aac AAC AAC ,

.wav WAV PCM 27.648 Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648 Mbps

.ac FLAC FLAC Upto 24 bps
.ogg OGG Vorbis Variable bit rate,

Audio

tainer

codec

WMA Pro Upto 768 kbps

HE-AAC

Dolby
Digital

DTS core 1.54 Mbps
MPEG 912 kbps
MP3 Upto 320 kbps
WMA Upto 192 kbps
WMA Pro Upto 768 kbps
AAC ,

HE-AAC

FLAC Upto 24 bps
OGGPCM No limit
MP3 Upto 320 kbps

Bit rate

Upto 192 kbps

640 kbps

Upto 192 kbps

maximum block
size 4096

Audio codec Video codec Bit rate

PCM, Dolby
Digital, DTS
core, MP3,
WMA

.divxlesinAVIcontainer

Audio codec Video codec Bit rate

PCM, Dolby
Digital, MP3,
WMA

.mp4or.m4vlesinMP4container

Audio codec Video codec Bit rate

Dolby Digital,
MPEG, MP3,
AAC, HE­AAC, DD+

DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x

MPEG 1, MPEG 2 40 Mbps

MPEG 4 SP / ASP 38.4 Mbps

H.264/AVC upto
HiP@5.1

WMV9 45 Mbps

DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x

MPEG 1, MPEG 2 40 Mbps

MPEG 4 ASP 38.4 Mbps

H.264/AVC
HiP@5.1

10 Mbps
max

25 Mbps

10 Mbps
max

25 Mbps

31EN

.mkvlesinMKVcontainer

.mpgand.mpeglesinPScontainer

Audio codec Video codec Bit rate

PCM, Dolby
Digital, DTS
core, MPEG,
MP3, WMA,
AAC, HE­AAC, DD+

.m2tslesinMKVcontainer

Audio codec Video codec Bit rate

PCM, Dolby
Digital, DTS
core, MPEG,
MP3, WMA,
AAC, HE­AAC, DD+

.asfand.wmvlesinASFcontainer(Available
onlyinAsiaPacicandChina)

Audio codec Video codec Bit rate

Dolby Digital,
MP3, WMA,
DD+

DivX Plus HD 30 Mbps

MPEG 1, MPEG 2 40 Mbps

MPEG 4 ASP 38.4 Mbps

H.264/AVC
HiP@5.1

WMV9 45 Mbps

MPEG 1, MPEG 2 40 Mbps

MPEG 4 ASP 38.4 Mbps

H.264/AVC
HiP@5.1

WMV9 45 Mbps

MPEG 4 ASP 38.4 Mbps

H.264/AVC
HiP@5.1

WMV9 45 Mbps

25 Mbps

25 Mbps

25 Mbps

Audio codec Video codec Bit rate

PCM, DTS
core, MPEG,
MP3

.vlesinFLVcontainer

Audio codec Video codec Bit rate

MP3, AAC H.264/AVC upto

.3gplesin3GPcontainer

Audio codec Video codec Bit rate

AAC, HE­AAC

MPEG 1, MPEG 2 40 Mbps

25 Mbps

HiP@5.1

H.263 38.4 Mbps

On2 VP6 40 Mbps

MPEG 4 ASP 38.4 Mbps

H.264/AVC upto
HiP@5.1

25 Mbps
max

Amplier

• Total output power:

• 550W RMS (+/- 0.5 dB, 30% THD) /

440W RMS (+/- 0.5 dB, 10% THD)

• Frequency response: 20 Hz-20 kHz / ±3 dB

• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)

• Input sensitivity:

• AUX: 2 V

• Music iLink: 300 mV

Video

• Signal system: PAL / NTSC

• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24

32 EN

Audio

• S/PDIF Digital audio input:

• Optical: TOSLINK

• Sampling frequency:

• MP3: 32 kHz, 44.1 kHz, 48 kHz

• WMA: 44.1 kHz, 48 kHz

• Constant bit rate:

• MP3: 32 kbps - 320 kbps

• WMA: 48 kbps - 192 kbps

Radio

• Tuning range:

• Europe/Russia/China:
FM 87.5-108 MHz (50 kHz)

• Asia Pacic/Latin America:
FM 87.5-108 MHz (50/100 kHz)

• Signal-to-noise ratio: FM 50 dB

• Frequency response:
FM 180 Hz-12.5 kHz / ±3 dB

USB

• Compatibility: Hi-Speed USB (2.0)

• Class support: USB Mass Storage Class
(MSC)

• File system: FAT16, FAT32, NTFS

Main unit

• Power supply:

• Europe/China: 220-240 V~, 50 Hz

• Latin America/Asia Pacic:

110-127 V/220-240 V~, 50-60 Hz

• Russia/India: 220-240 V~, 50 Hz

• Satellite speakers: 4 x 2.5" speakers +
2 x 2.5" radiators

• Power consumption: 60 W

• Standby power consumption: 0.5 W

• Dimensions (WxHxD):
1060 x 83.1 x 194.8 mm

• Weight: 4.9 KG

• Operating temperature and humidity:
0°C to 40°C, 5% to 90% Humidity for all
climates

• Storage temperature and humidity: -40 °C
to 70 °C, 5% to 95%

Subwoofer

• Power supply:

• Europe/China: 220-240 V~, 50 Hz

• Latin America/Asia Pacic: 110-127
V/220-240 V~, 50-60 Hz

• Russia/India: 220-240 V~, 50 Hz

• Impedance: 3 ohm

• Speaker drivers: 1 x 6.5" woofer

• Power consumption: 50 W

• Standby power consumption: 0.5 W

• Dimensions (WxHxD):
195 x 298 x 410 mm

• Weight: 7.2 KG

Remote control batteries

• 2 x AAA-R03-1.5 V

Laser

• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)

• Wave length: 405 +7 nm/-7 nm (BD),
655 +10 nm/-10 nm (DVD),
790 +10 nm/-20 nm (CD)

• Output power (Max. ratings):
20 mW (BD), 6 mW (DVD), 7 mW (CD)

33EN

9 Troubleshooting

• Make sure that the TV supports high-

denition video.

• Use an HDMI cable to connect to the TV.

Warning

•

Risk of electric shock. Never remove the casing of the
product.

To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem, get support at
www.philips.com/support.

Main unit

The buttons on the home theater do not
work.

• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.


No picture.

• Make sure that the TV is switched to the
correct source for the home theater.

No picture on a TV connected through HDMI.

• Make sure that you use a High Speed
HDMI cable to connect the home theater
and TV. Some Standard HDMI cables do
not display properly for some images, 3D
video, or Deep Color.

• Make sure that the HDMI cable is not
faulty. If it is faulty, replace it with a new
cable.

• Press

• Change the HDMI video setting, or wait

Discdoesnotplayhigh-denitionvideo.

• Make sure that the disc contains high-

(Home) and then 731 on the
remote control to restore the default
picture resolution.

for 10 seconds for auto recovery (see
'Picture and video settings' on page 26).

denition video.

Sound

No sound from home theater speakers.

• Connect the audio cable from your home
theater to your TV or other devices.
However, you do not need a separate
audio connection when:

• the home theater and TV are

connected through an HDMI ARC
connection, or

• a device is connected to the HDMI IN

connector on your home theater.

• Set up the audio for the connected device.

• Reset your home theater to its factory
settings, and then switch it off and switch
on again.

• On your home theater, press
repeatedly to select the correct audio
input.

No sound from wireless subwoofer.

1 Switch off the home theater and then

switch it on again.

2 Switch the home theater to AUX source.
3 Press and hold CONNECT on the

subwoofer until the indicator on the back
of the subwoofer blinks.

4 Press and hold Navigation button (right)

for at least three seconds.

» When the wireless connection

succeeds, the indicator on the
subwoofer lights up.

» If the wireless pairing fails, repeat steps

1 to 4 to connect your subwoofer to
the SoundBar.

Distorted sound or echo.

• If you play audio from the TV through the
home theater, make sure that the TV is
muted.

• If the sound from the wireless subwoofer
is interrupted or distor ted, make that the

34 EN

subwoofer is far away from microwave
ovens, DECT phones, or other Wi-Fi
devices.

Audio and video are not synchronized.

• 1) Press

2) Press the Navigation buttons (left/right)
to select AUD SYNC, and then press

3) Press the Navigation buttons (up/
down) to synchronize the audio with the
video.

.

Play

Cannot play a disc.

• Clean the disc.

• Make sure that the home theater supports
the type of disc (see 'Media formats' on
page 30).

• Make sure that the home theater supports
the region code of the disc (see 'Region
codes' on page 30).

• If the disc is a DVD±RW or DVD±R disc,

make sure that it is nalized.

CannotplayaDivXle.

• Make sure that the DivX le is encoded
according to the 'Home Theater Prole'

with the DivX encoder.

• Make sure that the DivX le is complete.

DivX subtitles do not display correctly.

• Make sure that the subtitle le name is
the same as the movie le name (see

'Subtitles' on page 17).

• Select the correct character set:

1) Press .

2) Select [Character set].

3) Select the supported character set.

4) Press

Cannot read the contents of a USB storage
device.

• Make sure that the format of the USB
storage device is compatible with the
home theater.

• Make sure that the le system on the USB
storage device is supported by the home
theater.

.

'No entry' or 'x' sign appears on the TV.

• The operation is not possible.

EasyLink does not work.

• Make sure that the home theater is
connected to a Philips brand EasyLink TV,
and the EasyLink option is turned on (see

.

'Set up EasyLink (HDMI-CEC control)' on
page 12).

• For TVs from different manufacturers, the
HDMI CEC could be called differently.
Check theTV user manual on how to
enable it.

When you switch on the TV, the home theater
automatically switches on.

• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch
off EasyLink.

Cannot access BD-Live features.

• Make sure that the home theater is
connected to the network. Use a wired
network connection (see 'Set up the wired
network' on page 13), or wireless network
connection (see 'Set up the wireless
network' on page 14).

• Make sure that the network is set up.
Use a wired network installation (see 'Set
up the wired network' on page 13), or
wireless network installation (see 'Set up
the wireless network' on page 14).

• Make sure that the Blu-ray disc supports
BD-Live features.

• Clear memory storage (see 'BD-Live on
Blu-ray' on page 16).

My 3D video played in 2D mode.

• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.

• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on (see
'BD-Live on Blu-ray' on page 16).

35EN

TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.

• Make sure that the home theater is
connected to the TV through an HDMI cable.

• Switch to the correct HDMI source on
the TV.

10 Notice

This section contains the legal and trademark
notices.

Network

Wireless network distorted or not found.

• Make sure that the wireless network is
not disturbed by microwave ovens, DECT
phones, or other neighboring Wi-Fi devices.

• Place the wireless router and the home

theater within ve meters of each other.

• If the wireless network does not work
properly, try a wired network installation
(see 'Set up the wired network' on page 13).

Copyright

This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
This product incorporates proprietar y
technology under license from Verance
Corporation and is protected by U.S. Patent
7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright
and trade secret protection for certain aspects
of such technology. Cinavia is a trademark of
Verance Corporation. Copyright 2004-2010
Verance Corporation. All rights reserved by
Verance. Reverse engineering or disassembly is
prohibited.

Cinavia notice

This product uses Cinavia technology to
limit the use of unauthorized copies of some

commercially-produced lm and videos and

their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will
be displayed and playback or copying will be
interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com.
To request additional information about Cinavia
by mail, send a postcard with your mailing
address to: Cinavia Consumer Information
Center, P.O. Box 86851, San Diego, CA, 92138,
USA.

36 EN

Open source software

Philips Electronics Singapore hereby offers to
deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such delivery is requested by
the respective licenses. This offer is valid up to
three years after product purchase to anyone
in receipt of this information. To obtain source
code, please send your request in English with
product type to [e-mail]. If
you prefer not to use email or if you do not

receive conrmation receipt within 2 weeks

after mailing to this email address, please
write in English to “Open Source Team, Philips
Intellectual Property & Standards, P.O. Box 220,
5600 AE Eindhoven, The Netherlands”. If you do

not receive timely conrmation of your letter,

please email to the email address above. The
texts of the licenses and acknowledgements for
open source software used in this product are
included in the user manual.

37EN

11 Language code

Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072

Ё᭛

Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
 6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385

Inupiaq 7375
Irish 7165

Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Po

rtuguês 8084

Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
To nga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Tu rkmen 8475
Tw i 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yo ruba 8979
Zulu 9085

38 EN

12 Index

control buttons (USB) 15
copyright protection 36
customer support 2

2

2nd audio language 16
2nd subtitle language 16

3

3D disc in 2D mode 16
3D safety 4
3D video 16

A

advanced settings 27

amplier 32

audio connection (HDMI ARC) 9
audio formats 31
audio from other devices 11
audio language 25
audio options 18
audio post processing 27
audio settings 26
auto standby 27
auto subtitle shift 26
auto volume 25

B

batteries 33
BD-Live 16
Blu-ray 15
Bonus View 16
brightness 26

D

datales 17

deep color 26
default settings 27
device name 14
disc language 25
disc menu 25
display panel 26
disposal 4
DivX 17

E

Easylink (HDMI-CEC) 12
eject disc 6
enhanced audio 27
environment 4

F

factory settings 27
FAQs 2

leformats 31

H

HDMI ARC 9
HDMI audio 26
HDMI-CEC 12
home menu 15
home network 13

C

change password 26
character set 17
clear BD-Live memory 16
connect a digital device (HDMI) 11
connect to TV 9
connectors 7
control buttons (disc) 15

I

internet 13

L

language code 38

39EN

M

main unit 6
media formats 30
media sharing 22
menu language 25
musical slideshows 19

N

network 13
night mode 26

O

one-touch play 12
one-touch standby 12
options 18

P

parental control 26
PBC (play back control) 26
picture options 19
picture resolution 26
picture settings 26
picture-in-picture 16
play disc 15
play from PC 23
play radio 20
play USB storage device 18
power settings 27

predenedsoundmode 24

preference 25
program radio stations 20

R

radio 20
recycling 4
region codes 30
remote control 5
repeat 18

S

shufe 18

sleep timer 27
slide animation 19
software update 28
software version 28
sound 24

speakerspecications 30

subtitle language 25
subtitle position 26
surround sound 24
synchronize picture and sound 16

T

troubleshooting (network) 36
troubleshooting (picture) 34
troubleshooting (play) 35
troubleshooting (sound) 34
tune radio stations 20
tuning grid 20

U

update onscreen help (user manual) 29
update software (through Internet) 29
USB storage device 18
user manual 2

V

VCD 26
video connection (composite video) 10
video connection (HDMI ARC) 9
video connection (standard HDMI) 10
video formats 32
video options 18
video settings 26
VOD code (DivX) 18

W

watch 3D 16
wired network 13
wireless network 14

40 EN

“Blu-ray 3D” and “Blu-ray 3D” logo are
trademarks of Blu-ray Disc Association.

BONUSVIEW™
‘BD LIVE’ and ‘BONUSVIEW’ are trademarks of
Blu-ray Disc Association.

‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.

Oracle and Java are registered trademarks of

Oracle and/or its afliates. Other names may be

trademarks of their respective owners.

Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.

DivX , DivX Certied , DivX Plus HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used
under license.
ABOUT DIVX VIDEO: DivX
format created by DivX, LLC, a subsidiary

of Rovi Corporation. This is an ofcial DivX
Certied

divx.com for more information and software

tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This

DivX Certied

in order to play purchased DivX Video-on­Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.

device that plays DivX video. Visit

device must be registered

is a digital video

Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872
& other U.S. and worldwide patents issued
& pending. DTS-HD, the Symbol, & DTS­HD and the Symbol together are registered
trademarks & DTS-HD Master Audio | Essential
is a trademark of DTS, Inc. Product includes
software.

DTS, Inc. All Rights Reserved.

The terms HDMI and HDMI High-Denition

Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.

CLASS 1

LASER PRODUCT

41

部件名称

Name of the parts

Housing

外壳

DVD loader

光盒

DVD

Subwoofer

超重低音箱

Loudspeakers

喇叭单元

PWBs

电路板组件

Accessories (Remote
control & cables)

附件（遥控器，
电源线，连接线）

Batteries in Remote
Control (ZnC)

遥控器电池

产品中有害物质的名称及含量

Names and Contents of Hazardous Substances

有害物质

Hazardous Substance

铅

(Pb)

O O O O O O

X O O O O O

X O O O O O

O O O O O O

X O O O O O

X O O O O O

X O O O O O

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

本表格依据

SJ/T 11364

的规定编制。

The table is formulated according to SJ/T 11364.

： 表示该有害物质在该部件所有均质材料中的含量均在

O

GB/T 26572

规定的限量要求以下。

O： Indicates that this hazardous substance contained in all of the homogeneous materials

for this part is below the limit requirement in GB/T 26572.

×： 表示该有害物质至少在该部件的某一均质材料中的含量超出
×：

Indicates that this hazardous substance contained in at least one of the homogeneous

GB/T 26572

规定的限量要求。

materials used for this part is above the limit requirement in GB/T 26572.

10

环保使用期限

此标识指期限（十年），电子电气产品中的有害物质在正常使用的条件下不会发生外泄或突变，
用户使用该电子电气产品不会对环境造成严重污染或对其人身、财产造成严重损害的期限。

This logo refers to the period (10 years) during which the hazardous substances in electronic
and electrical products will not leak or mutate so that the use of these [substances] will not
result in any severe environmental pollution, any bodily injury or damage to any asset

42

Environmental Protection Use Period

s.

Specifications are subject to change without notice
© 2016 Koninklijke Philips N.V. All rights reserved.
Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

HTB5150K_93_UM_V2.0
