Important

Read these instructions for use carefully before
using the appliance and save them for future
reference.

◗ Only use the HQ8000 powerplug and the

charging stand supplied to charge the shaver.

◗ The powerplug is suitable for mains voltages

ranging from 100 to 240 volts.

◗ The powerplug contains a transformer. Do

not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.

◗ The powerplug transforms 100-240 volts to

12 volts.

C

◗ Make sure the HQ8000 powerplug and the

charging stand do not get wet.

C

◗ The shaver runs at a safe low voltage of

12 volts. It is watertight and can be cleaned
under the tap. Do not rinse the shaver with
water hotter than 80cC.

◗ For the best shaving results,shaving emulsion

should be pumped up frequently.

◗ If the mains cord of this appliance is damaged,

it must always be replaced by Philips or a
service centre authorised by Philips in order
to avoid hazardous situations.

◗ Noise level:

- Shaver + shaving unit: Lc = 61-65 dB(A)

- Shaver + trimmer: Lc = 60-64 dB(A)

ENGLISH4

Charge indications

C

◗ As soon as you start charging the empty

shaver, the green pilot light goes on.

◗ When the batteries have been fully charged,

the green pilot light starts blinking.

◗ The red pilot light blinks when the batteries

are almost empty.

◗ When the batteries are almost empty, the red

pilot light blinks a few times after the shaver
has been switched off.

Charging

Recharge, store and use the appliance at a
temperature between 5cC and 35cC.

1 Insert the small plug into the charging

stand and put the powerplug in the wall
socket.

C

2 Place the shaver in the charging stand.

C

3 Press until you hear a click.

The shaver automatically switches off when
placed in the charging stand.

4 When charging for the first time or after a

long period of disuse: leave the shaver to
charge continuously for 4 hours.

Charging normally takes approx. 1 hour.

A fully charged shaver has a cordless shaving time
of up to approx. 55 minutes.

ENGLISH 5

Inserting cartridges

The cartridges with moisturising NIVEA FOR
MEN shaving emulsion are available in boxes
containing five cartridges and one small plastic
pump. Do not throw the pump away: you will
need it for all five cartridges!

Use only Philishave NIVEA FOR MEN Cool Skin
(HQ160 or HQ161) cartridges.

For hygienic reasons, we advise you to insert a
new pump when you start using a new set of five
cartridges.

Inserting the first cartridge

C

1 Take one cartridge from the box.Take the

pump (supplied in the same box) out of its
bag and push it into the cartridge until it
locks into position with a click.

C

2 Move the release slide downwards and

open the cover of the cartridge
compartment.

C

3 Slide the cartridge with the pump into the

shaver. It only fits properly if the white side
of the pump is pointing upwards. Close the
cover.

ENGLISH6

2

1

4 Press the yellow pump button a few times

until the NIVEA FOR MEN shaving
emulsion appears.The shaver is now ready
for use.

Do not throw the pump away when you replace
an empty cartridge.You will need it for the other
cartridges.

The NIVEA FOR MEN shaving emulsion in this
cartridge will keep when stored at temperatures
between 0cC and +40cC.

Shaving

1 Switch the shaver on by pressing the on/off

button once.

C

2 Press the yellow pump button to apply

NIVEA FOR MEN shaving emulsion to
your skin. Move the shaver over your skin,
making both straight and circular
movements.

3 While shaving, press the pump button

frequently to apply more NIVEA FOR
MEN shaving emulsion so that the shaver
keeps gliding smoothly over your face.

Do not press the shaver too hard against your
skin while shaving.
If you prefer, you can wet your face first.

ENGLISH 7

◗ When you have run out of shaving emulsion,

you can also use the shaver without it on a
dry face.

◗ Your skin may need 2-3 weeks to get

accustomed to the Philishave system.

4 Switch the shaver off.

C

5 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Remove the cartridge and clean the shaver if you
are not going to use the appliance for more than
one week. Rinse the shaver after each shave.

Trimming

The shaver has a separate trimmer for grooming
sideburns and moustache.

1 Switch the shaver off.

Clean the shaver before you attach the trimmer.

C

2 Press the release button to open the

shaving unit and pull the shaving unit off
the shaver.

C

3 Tilt the trimmer slightly backwards and fit

it onto the shaver.

4 Remove the trimmer by pressing the

release button again and pulling the
trimmer off the shaver.

ENGLISH8

2

1

Cleaning

Shaving unit

Rinse the shaving unit and the hair chamber with
hot water (60cC - 80cC) after every use.

1 Switch the shaver off.

C

2 Press the release button to open the

shaving unit.

C

3 Clean the shaving unit and the hair

chamber by rinsing them under a hot tap
for some time.

Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.

C

4 Rinse the outside of the shaver.

Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly. Close
the shaving unit and shake off excess water.

Charging stand

1 Unplug the charging stand.

2 Clean the charging stand with a moist

cloth.

ENGLISH 9

Trimmer

1 Clean the outside of the trimmer with the

brush supplied after every use.

C

2 Open the trimmer to clean it on the

inside.

C

3 Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Replacing the shaving heads

Replace the shaving heads every two years for
optimal shaving results.

1 Switch the shaver off.

C

2 Press the release button to open the

shaving unit.

C

3 Turn the wheel anticlockwise and remove

the retaining frame.

C

4 Remove the shaving heads and place the

new ones in the shaving unit.

ENGLISH10

OIL

2

1

1

C

5 Put the retaining frame back into the

shaving unit, press the wheel and turn it
clockwise.

Replace damaged or worn shaving heads with
Philishave HQ167 Cool Skin shaving heads only.

Storage

C

◗ After cleaning, the wet shaver can be placed in

the charging stand.

◗ The appliance and the trimmer can be stored

in the pouch or cassette supplied.Whether
you have a pouch or a cassette depends on
your type of shaver.

Disposal of batteries

The built-in rechargeable batteries contain
substances that may pollute the environment.

Remove the batteries when you discard the
shaver. Do not throw the batteries away with the
normal household waste, but hand them in at an
official collection point.You can also take the
appliance to a Philips service centre, which will
remove them for you and will dispose of them in
an environmentally safe way.

Only remove the batteries if they are completely
empty.

C

1 Let the shaver run until it stops,undo the

screws and open the shaver.

ENGLISH 11

1

1

2 Remove the batteries.

Do not put the shaver back into the charging
stand after the batteries have been removed.

Tip

◗ The shaver comes with two different kinds of

shaving emulsion:an emulsion for sensitive
skin and a fresh gel.This gives you the
opportunity to try them out and discover
which one suits your skin type best.

Troubleshooting

1 The shaving heads do not move smoothly

over the skin.

B

Cause: not enough shaving emulsion has been
applied.

◗ Press the pump button a few times until a

sufficient amount of NIVEA FOR MEN shaving
emulsion has been released to allow the
shaving heads to move smoothly over your
face again.

2 Reduced shaving performance:

B

Cause 1: the shaving heads are dirty. The shaver
has not been cleaned immediately after use
and/or has not been rinsed long enough and/or
the water used to rinse the shaver was not hot
enough.

ENGLISH12

◗ Clean the shaver thoroughly before you

continue shaving (see 'Cleaning').

B

Cause 2: long hairs are obstructing the shaving
heads.

C

◗ Remove the retaining frame.

C

◗ Clean the cutters and guards.

Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
could take several weeks before optimal shaving
performance is restored.

◗ Remove the hairs.
◗ Put the shaving heads back into the shaving

unit. Put the retaining frame back into the
shaving unit, press the wheel and turn it
clockwise.

B

Cause 3: the shaving heads are damaged or worn.

◗ Remove the retaining frame.
◗ Remove the old shaving heads from the

shaving unit and replace them with new ones.

Damaged or worn shaving heads (cutters and
guards) must only be replaced with the original
Philishave HQ167 Cool Skin shaving heads.

◗ Put the retaining frame back into the shaving

unit, press the wheel and turn it clockwise.

ENGLISH 13

2

1

1

3 Shaver does not work when the on/off

button is pressed:

B

Cause: the batteries are empty

◗ Recharge the batteries.

4 The cover of the cartridge compartment

cannot be closed.

B

Cause 1: the cartridge has not been inserted
correctly.

◗ Insert the cartridge correctly. It only fits

properly into the shaver if the white side of
the pump is pointing upwards.

B

Cause 2: the cartridge has not been pushed far
enough into the shaver.

◗ Press the cartridge until it is properly seated.

5 The NIVEA FOR MEN shaving emulsion

has changed colour or has turned watery.

B

Cause: the NIVEA FOR MEN shaving emulsion
has not been stored at the right temperature.

◗ Insert a new cartridge.

6 Skin irritation occurs.

B

Cause 1: your skin has not yet become
accustomed to this shaving system.

ENGLISH14

◗ Allow 2-3 weeks for your skin to get

accustomed to this shaving system.

B

Cause 2: the shaving emulsion irritates your skin.

◗ Try the other type of shaving emulsion.
◗ Wet your face before shaving with the shaving

emulsion.

If the irritation does not disappear within 24
hours, we advise you to stop using the shaving
emulsion and to contact your doctor.

7 In case of other problems:

◗ See 'Guarantee & service'

Accessories

The following accessories are available:

- HQ167 Philishave Cool Skin shaving heads.

- HQ160 NIVEA FOR MEN Cool Skin
moisturising shaving emulsion.

- HQ161 NIVEA FOR MEN Cool Skin
moisturising fresh shaving gel.

- HQ8000 powerplug.

- HQ100 Philishave Action Clean (shaving head
cleaner).

- HQ101 Philishave Action Clean refill (shaving
head cleaning liquid).

- HQ110 Philishave shaving head cleaner (shaving
head cleaning spray).

ENGLISH 15

Guarantee & service

If you need information or if you have a problem,
please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Depar tment of Philips
Domestic Appliances and Personal Care BV.

◗ Keep these instructions for future reference.

ENGLISH16

Wichtig

Lesen Sie diese Bedienungsanleitung vor der
ersten Benutzung des Geräts gründlich durch.
Bewahren Sie die Bedienungsanleitung zur
späteren Einsichtnahme auf.

◗ Verwenden Sie zum Laden des Rasierers nur

das mitgelieferte Netzteil HQ8000 sowie die
mitgelieferte Ladestation.

◗ Das Netzteil ist für Netzspannungen zwischen

100 und 240 Volt geeignet.

◗ Das Netzteil enthält einen Transformator.

Ersetzen Sie das Netzteil keinesfalls durch
einen anderen Stecker, da dies den Benutzer
gefährdet.

◗ Das Netzteil wandelt Netzspannungen von

100 bis 240 Volt in eine Betriebsspannung von
12 Volt um.

C

◗ Achten Sie darauf, dass das Netzteil und die

Ladestation nicht nass werden.

C

◗ Der Rasierer arbeitet mit einer ungefährlichen

Niedrigspannung von 12 Volt. Er ist
wasserdicht und kann unter fließendem
Wasser gereinigt werden. Spülen Sie den
Rasierer nicht mit Wasser ab,das heißer als
80c C ist.

◗ Pumpen Sie regelmäßig Rasieremulsion nach,

um optimale Resultate erzielen.

◗ Wenn das Netzkabel des Geräts beschädigt

ist, muss es von Philips oder einem Philips
Service Center ausgetauscht werden, um
Gefährdungen des Benutzers zu vermeiden.

DEUTSCH 17

Ladeanzeige

C

◗ Sobald Sie mit dem Aufladen der Akkus

beginnen, leuchtet die grüne Kontrolllampe.

◗ Sobald die Akkus vollständig geladen sind,

blinkt die grüne Kontrolllampe.

◗ Die rote Kontrolllampe blinkt, wenn die Akkus

fast leer sind.

◗ Sind die Akkus fast leer, blinkt die rote

Kontrolllampe noch einige Male, nachdem der
Rasierer ausgeschaltet wurde.

Aufladen

Laden, benutzen und lagern Sie das Gerät bei
Temperaturen zwischen5cC und 35cC.

1 Führen Sie den kleinen Stecker in die

Ladestation ein und stecken Sie das
Netzteil in die Steckdose.

C

2 Setzen Sie den Rasierer in die Ladestation.

C

3 Der Rasierer muss hörbar einrasten.

Der Rasierer schaltet sich automatisch aus, wenn
Sie ihn in die Ladestation stellen.

4 Beim erstmaligen Laden, und wenn der

Rasierer für einen längeren Zeitraum nicht
benutzt wurde, beträgt die Ladedauer 4
Stunden.

DEUTSCH18

Normalerweise ist der Akku nach ungefähr 1
Stunde aufgeladen.

Mit voll aufgeladenen Akkus können Sie sich ca.
55 Minuten kabelfrei rasieren.

Patronen einsetzen

NIVEA FOR MEN Rasieremulsion ist in
Packungen von 5 Kartuschen mit einer kleinen
Kunststoffpumpe erhältlich. Bewahren Sie die
Pumpe auf: Sie brauchen sie für jede der fünf
Kartuschen!

Verwenden Sie ausschließlich Philishave NIVEA
FOR MEN Cool Skin-Kartuschen (Typ HQ160
oder HQ161).

Verwenden Sie aus hygienischen Gründen die
neue Pumpe, wenn Sie eine neue Packung mit 5
Patronen anbrechen.

Die erste Patrone einsetzen

C

1 Nehmen Sie eine Kartusche aus der

Schachtel. Nehmen Sie die beiliegende
Kunststoffpumpe aus der Hülle und setzen
Sie sie bis zum Anschlag fest auf die
Kartusche, bis sie hörbar einrastet.

DEUTSCH 19
