Philips HQ6095, HQ6090 User Guide

ENGLISH 4

简体中文 14

HQ6095, HQ6090

4

ENGLISH

Important

Read this user manual carefully before you use the
appliance and save it for future reference.

This appliance is not intended for use by persons

­(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they

­do not play with the appliance.
Only use the powerplug supplied.

­The powerplug transforms 100-240 volts to a safe

­low voltage of less than 24 volts.
The powerplug contains a transformer. Do not cut

­off the powerplug to replace it with another plug,
as this causes a hazardous situation.
Do not use a damaged powerplug.

­If the powerplug is damaged, always have it

­replaced with one of the original type in order to
avoid a hazard.
Charge and store the shaver at a temperature

­between 5°C and 35°C.
Do not recharge the shaver in a closed pouch.

­Make sure the powerplug does not get wet.

­Always unplug the shaver before cleaning it under

­the tap.

The appliance complies with the internationally

­approved IEC safety regulations and can be safely
cleaned under the tap.

Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.

ENGLISH 5

Electromagnetic elds (EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this
user manual, the appliance is safe to use based on

scientic evidence available today.

Charging

Make sure the appliance is switched off before you
start to charge it.

When you charge the shaver for the rst time or

after a long period of disuse, let it charge for 4 hours.
Charging normally takes approx. 1 hour.
You can also shave without charging by connecting
the shaver to the mains.

Do not leave the appliance connected to the mains
for more than 24 hours.

Charge indications

Charging

When you start charging the empty shaver, the

,

green power symbol starts burning.

Battery fully charged

When the battery is fully charged, the green

,

power symbol starts to ash.

Battery running low

When the battery is running low, the red battery

,

symbol starts burning. When you switch the

shaver off, the red battery symbol starts to ash.

ENGLISH6

Charging the appliance

Charge the appliance when the red power symbol

burns or ashes or when the motor stops or starts

to run slower.

1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

3 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver
when the battery has been fully charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time of
up to 40 minutes.

Using the appliance

Shaving

1 Press the on/off button once to switch on the

shaver.

The light ring goes on.

2 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed
to the Philips shaving system.

3 Press the on/off button once to switch off the

shaver.

ENGLISH 7

4 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is
running.

Cleaning and maintenance

Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
chamber with hot water every time you have used
the appliance.

Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.

Every day: shaving unit and hair chamber

1 Switch off the shaver, remove the powerplug

from the wall socket and pull the appliance plug
out of the shaver.

ENGLISH8

2 Press the release button (1) and open the

shaving unit (2).

3 Clean the shaving unit and the hair chamber by

rinsing them under a hot tap for some time.

Make sure the inside of the shaving unit and the hair
chamber have been cleaned properly.

4 Rinse the outside of the appliance.

5 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.

6 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water
by using the brush supplied.

Every six months: shaving heads

1 Open the shaving unit and pull it off the shaver.

You can also leave the shaving unit attached to the
shaver.

ENGLISH 9

2 Remove the retaining frame.

3 Clean the cutters and guards with the brush

supplied.

Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.

4 Put the shaving heads back into the shaving unit

and then put the retaining frame back into the
shaving unit.

Make sure that the projections of the shaving heads

t into the recesses.

5 Put the shaving unit back onto the shaver by

inserting the hinge into the slot in the rim of
the hair chamber and pushing it home until it
locks into place (‘click’).

6 Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1 Switch off the shaver, remove the powerplug

from the wall socket and pull the appliance plug
out of the shaver.

ENGLISH10

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Storage

Put the protection cap on the shaver to prevent

,

damage.
Store the appliance in the pouch.

,

Replacement

Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ8
Precise Cutting System Shaving Heads only.

1 Switch off the shaver, remove the powerplug

from the wall socket and pull the appliance plug
out of the shaver.

2 Open the shaving unit and pull it off the shaver.

You can also leave the shaving unit attached to the
shaver.

ENGLISH 11

3 Remove the retaining frame.

4 Remove the shaving heads and place new ones

in the shaving unit. Put the shaving heads back
into the shaving unit and then put the retaining
frame back into the shaving unit.

Make sure that the projections of the shaving heads

t into the recesses.

5 Put the shaving unit back onto the shaver by

inserting the hinge into the slot in the rim of
the hair chamber and pushing it home until it
locks into place (‘click’).

6 Close the shaving unit.

Accessories

The following accessories are available:

HQ8500/HQ8000 powerplug

­HQ8 Precise Cutting System Shaving Heads

­HQ110 Philips Shaving Head Cleaning Spray (not

­available in China)

Environment

Do not throw away the appliance with the normal

­household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.
The built-in rechargeable shaver battery contains

­substances that may pollute the environment.

ENGLISH12

Always remove the battery before you discard

and hand in the shaver at an ofcial collection
point. Dispose of the battery at an ofcial

collection point for batteries. If you have trouble
removing the battery, you can also take the shaver
to a Philips service centre. The staff of this centre
will remove the battery for you and will dispose of
it in an environmentally safe way.

Disposal of the battery

Only remove the battery if it is completely empty.

1 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver.

2 Let the shaver run until it stops, undo the

screws and open the shaver.

3 Remove the battery.

Do not connect the shaver to the mains again after
the battery has been removed.

Guarantee & service

If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre

in your country (you nd its phone number in
the worldwide guarantee leaet). If there is no

Customer Care Centre in your country, go to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.

Guarantee restrictions

The shaving heads (cutters and guards) are not
covered by the terms of the international guarantee
because they are subject to wear.

Frequently asked questions

Question Answer

ENGLISH 13

Why doesn’t the
shaver shave as
well as it used to?

Why doesn’t the
shaver switch
on when I press
the on/off button?

The shaving unit
has come off
the shaver. What
should I do?

You may not have cleaned the appliance properly.
Clean the shaving heads thoroughly (see chapter
‘Cleaning and maintenance’).

Long hairs may be obstructing the shaving heads.
Clean the cutters and guards properly with
the brush supplied (see chapter ‘Cleaning and
maintenance’).

The shaving heads may be damaged or worn.
Replace the shaving heads (see chapter
‘Replacement’).

The battery may be empty. Recharge the battery
(see chapter ‘Charging’) or put the powerplug in
the wall socket to shave directly from the mains.

Simply reattach the shaving unit by pressing it onto
the shaver (see chapter ‘Replacement’, item 5).

14

简体中文

注意事项

使用产品之前，请仔细阅读本使用
说明书，并妥善保管以备日后参
考。

本产品不打算由肢体不健全、感

-

觉或精神上有障碍或缺乏相关
经验和知识的人（包括儿童）使
用，除非有负责他们安全的人对
他们使用本产品进行监督或指
导。
应照看好儿童，确保他们不玩耍

-

这些产品。
只能使用产品随附的电源插头。

-

电源插头可将 100-240 伏的电压

-

转换为 24 伏以下的安全低电压。
电源插头中含有一个变压器。切

-

勿将其剪断，而用另一个插头代
替，否则将导致严重后果。
不要使用已经损坏的电源插头。

-

电源软线不能更换，如果软线损

-

坏，此器具（电源适配器）应废
弃。如果电源插头已损坏，则必
须用原装型号替换，以免发生危
险。
必须在 5 摄氏度至 35 摄氏度之间

-

的温度下充电和存放剃须刀。

简体中文 15

不要将剃须刀放在软袋里充电。

-

确保电源插头干燥。

-

在自来水龙头下清洗剃须刀之

-

前，务必拔掉其电源插头。
此产品符合国际认可的 IEC 安全

-

标准，可放心在自来水龙头下清
洗。

使用热水时一定要小心。切记先检
查水温是否太高，以防烫手。

电磁场 (EMF)

这款飞利浦产品符合关于电磁场 (EMF) 的所有
相关标准。据目前的科学证明，如果正确使用
并按照本用户手册中的说明进行操作，本产品
是安全的。

充电

开始充电之前确保产品电源已关闭。
如果是首次充电，或长期未使用后的首次充
电，则应连续充电 4 小时。
充电通常需要约 1 小时。
您也可以不充电而将剃须刀插上电源后使用。

不要将本产品与电源接通超过 24
小时。

充电指示
充电

为没有电量的剃须刀充电时，绿色电源指示

,

灯开始亮起。

简体中文16

电池已完全充满

电池完全充满电时，绿色电源指示灯开始闪

,

烁。

电池电量不足

当电池电量不足时，红色电池指示灯开始亮

,

起。当关闭剃须刀时，红色电池指示灯开始
闪烁。

为产品充电

当红色电源指示灯亮起或闪烁，或者当马达停
止或运行开始变慢时，请为产品充电。

1 将产品插头插入剃须刀。
2 将电源插头插入壁装插座。
3 电池充满后，从壁装式插座中拔下电源插

头，并从剃须刀上拔下产品插头。

不接电源的剃须时间

完全充电的剃须刀在不连接电源的情况下最长
可使用达 40 分钟。

使用本产品

剃毛

1 按一下开/关按钮打开剃须刀。

光环亮起。

2 将剃须刀头在皮肤上快速移动，作直线和迂

回动作。

在干爽的面部剃须效果最佳。
您的皮肤可能需要 2 到 3 周才能适应飞利浦剃
须系统。

简体中文 17

3 按一下开/关按钮关闭剃须刀电源。
4 每次使用后，盖上剃须刀保护盖，以防受

损。

修剪

用于修剪鬓角和小胡子。

1 向上推动滑块来打开修发器。

当马达运转时，修发器便可以启动。

清洁和维护

为保证更好的剃须效果，剃须刀必须定期清
洗。
最简单和最卫生的清洁方法是每次使用完本产
品之后，用热水冲洗剃须刀头部件和胡茬储藏
室。

使用热水时一定要小心。切记先检
查水温是否太高，以防烫手。

每天：剃须刀头部件和胡茬储藏室

1 关闭剃须刀电源，从壁装式电源插座中拔下

电源插头，并从剃须刀上拔下产品插头。

2 按下释放钮 (1) ，打开剃须刀头部件 (2)。

简体中文18

3 在热水龙头下，冲洗剃须刀头部件和胡茬储

藏室一段时间。

确保剃须刀头部件和胡茬储藏室的内部已彻底
清洁。

4 冲洗产品表面。
5 关闭剃须刀头部件并甩掉多余的水份。

不要用毛巾或纸巾擦拭剃须刀头部
件，因为这样可能会损坏剃须刀
头。

6 再次打开剃须刀头部件，使它保持打开状

态，让产品完全晾干。

除了冲洗方式外，您还可以使用随附的刷子清
洁胡茬储藏室。

每 6 个月：剃须刀头

1 打开剃须刀头部件并将它从剃须刀上拔下。

您还可以让剃须刀头部件继续留在剃须刀上。

2 取下固定架。

3 用随附的刷子清洁刀片和网罩。

不要同时清洁多组刀片和网罩，因为它们都是
相互匹配的。如果不小心将刀片和网罩弄混，

简体中文 19

则需要数周时间才能恢复产品的最佳剃须性
能。

4 将剃须刀头放回剃须刀头部件，然后将固定

架放回剃须刀头部件。

确保剃须刀头凸起部位正好插入凹陷部位。

5 将剃须刀头部件装回剃须刀。方法是将铰链

插入胡茬储藏室边的槽中，将其推到位，直
到锁定到位（可听到“咔嗒”声）。

6 关闭剃须刀头部件。

修发器

每次使用后都要清洁修发器。

1 关闭剃须刀电源，从壁装式电源插座中拔下

电源插头，并从剃须刀上拔下产品插头。

2 用随附的刷子清洁修发器。

3 每六个月用一滴缝纫机油润滑修发器齿。

简体中文20

存放

盖上剃须刀保护盖，以防受损。

,

将产品存放在软袋中。

,

更换

每两年更换一次刀头以获得最佳的剃须效果。
损坏或磨损的剃须刀头只能用 HQ8 剃须刀头
更换。

1 关闭剃须刀电源，从壁装式电源插座中拔下

电源插头，并从剃须刀上拔下产品插头。

2 打开剃须刀头部件并将它从剃须刀上拔下。

您还可以让剃须刀头部件继续留在剃须刀上。

3 取下固定架。

4 取下剃须刀头，在剃须刀头部件上装上新刀

头。将剃须刀头放回剃须刀头部件，然后将
固定架放回剃须刀头部件。

确保剃须刀头凸起部位正好插入凹陷部位。

5 将剃须刀头部件装回剃须刀。方法是将铰链

插入胡茬储藏室边的槽中，将其推到位，直
到锁定到位（可听到“咔嗒”声）。

6 关闭剃须刀头部件。

简体中文 21

附件

可选配以下附件：

HQ8500/HQ8000 电源插头

-

HQ8 剃须刀头

-

环保

弃置产品时，请不要将其与一般生活垃圾堆

-

放在一起；应将其交给官方指定的回收中
心。这样做有利于环保。
内置充电电池含有可能会污染环境的物质。

-

丢弃剃须刀时，一定要将电池取出，并将剃
须刀送到官方指定的回收站。到官方指定的
电池回收站处理电池。如果您在取出电池时
遇到问题，您也可以将剃须刀送至飞利浦维
修中心。维修中心的员工会帮您取出电池，
并以环保的方式处理它。

处理电池

仅在电池电量完全耗尽后方可取出
电池。

1 从壁装式插座中拔下电源插头，并从剃须刀

上拔下产品插头。

2 让剃须刀运转直到停止，拧下螺钉并打开剃

须刀。

3 取出电池。

取出电池后，不要再将剃须刀与电
源连接在一起。

简体中文22

保修与服务

如果您需要详细信息或有任何问题，请浏览飞
利浦网站，地址为 www.philips.com。您也可
以与本国的飞利浦顾客服务中心联系（您可以
从全球保修卡中找到电话号码）。如果本国没
有飞利浦顾客服务中心，请与当地的飞利浦经
销商或与飞利浦家庭小电器的维修中心联系。

保修限制

由于剃须刀头（刀片和网罩）属于易磨损物
品，因此不在国际保修条款的涵盖范围之列。

常见问题

问题 回答

为什么剃须刀的剃
须效果没有以前
好？

按下开/关钮时，为
什么无法打开剃须
刀？

剃须刀头部件从剃
须刀上脱落。该怎
样处理？

您可能没有正确清洁本产品。请彻底清洁
剃须刀头（见“清洁和保养”一章）。

过长的胡须可能堵塞了剃须刀头。请使用
随附的刷子正确清洁刀片和网罩（见“清
洁和保养”一章）。

剃须刀头可能已损坏或磨损。请更换剃须
刀头（见“更换”一章）。

电池可能没电。为电池充电（见“充
电”一章）或者将电源插头插入壁装插
座，直接通过电源剃须。

只需重新安装剃须刀头部件，将其按到剃
须刀上（见“更换”一章，第 5 节）。

简体中文 23

2008/07/09

HQ6095,
HQ6090

24

25

26

4222.002.5093.1
