Philips HQ5715, HQ5710, HQ5705 User Manual
HQ5715, HQ5710, HQ5705
21
43
65
87
109
1211
1413
1615
1817
ENGLISH
4222.002.5088.1
2/3
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Use and store the appliance at a temperature
between 5°C and 35°C.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap. (Fig. 1)
Be careful with hot water. Always check if the water is not
too hot, to prevent your hands from getting burnt.
Remove the batteries if you are not going to use the
appliance for a month or more.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this user
manual, the appliance is safe to use based on scientic
evidence available today.
Preparing for use
The appliance runs on two R6 AA 1.5-volt batteries. We
strongly advise you to use Philips LR6 alkaline batteries.
They supply sufcient energy for approx. 60 minutes of
shaving.
Inserting batteries
1 Unlock the cap of the battery compartment (Fig. 2).
2 Remove the cap of the battery
compartment. (Fig. 3)
3 Put two batteries in the battery
compartment (Fig. 4).
Make sure your hands and the appliance are dry when
you insert the batteries.
Make sure the + and - poles of the batteries point
,
in the right direction
The appliance does not work if the batteries have been
placed incorrectly.
4 Push the cap of the battery compartment back
onto the appliance.
5 Lock the cap of the battery compartment (Fig. 5).
Optimising the lifetime of the battery
To avoid damage due to battery leakage:
Remove the batteries if you are not going to use the
appliance for a month or more.
Do not leave empty batteries in the appliance.
-
Using the appliance
1 Remove the protection cap.
2 Switch on the shaver by pushing the on/off slide
upwards (Fig. 6).
3 Move the shaving heads quickly over your
skin, making both straight and circular
movements. (Fig. 7)
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed to
the Philips shaving system.
4 Switch off the shaver by pushing the on/off slide
downwards.
5 Put the protection cap on the shaver every time
you have used it, to prevent damage (Fig. 8).
Cleaning
Regular cleaning guarantees better shaving performance.
The easiest and most hygienic way to clean the appliance
is to rinse the shaving unit and the hair chamber with hot
water every time you have used the appliance.
Never rinse the shaver when the battery compartment
is open. Always make sure the cap of the battery
compartment is in place and properly locked before you
start rinsing the shaver.
Be careful with hot water. Always check if the water is
not too hot, to prevent your hands from getting burnt.
Every day: shaving unit and hair chamber
1 Switch off the shaver.
2 Remove the shaving unit. (Fig. 9)
3 Rinse the outside of the shaving unit under a hot
tap for some time (Fig. 10).
4 Rinse the inside of the shaving unit under a hot tap
for some time. (Fig. 11)
5 Rinse the hair chamber under a hot tap for some
time. (Fig. 12)
6 Put the shaving unit back onto the shaver and shake
off excess water.
Never dry the shaving unit with a towel or tissue, as
this may damage the shaving heads.
Every six months: shaving heads
1 Switch off the shaver.
2 Remove the shaving unit (Fig. 9).
3 Turn the wheel anticlockwise (1) and remove the
retaining frame (2) (Fig. 13).
4 Remove the shaving heads from the shaving
unit. (Fig. 14)
5 Remove the guard from the cutter (Fig. 15).
6 Clean the cutters with the short-bristled side of
the brush. (Fig. 16)
Do not clean more than one cutter and guard at a time,
since they are all matching sets. If you accidentally mix up
the cutters and guards, it may take several weeks before
optimal shaving performance is restored.
7 Brush the guard. (Fig. 17)
8 Put the shaving heads back into the shaving unit. Put
the retaining frame back into the shaving unit, press
the wheel and turn it clockwise.
9 Put the shaving unit back onto the shaver.
Storage
Put the protection cap on the shaver to prevent
,
damage (Fig. 8).
Replacement
Replace the shaving heads every two years for optimal
shaving results.
Replace damaged or worn shaving heads with HQ64
Philips Double Action Super Lift & Cut Shaving Heads
(HQ5715) or HQ54 Philips Double Action Lift & Cut
Shaving Heads (HQ5710,5705).
1 Switch off the shaver.
2 Remove the shaving unit (Fig. 9).
3 Turn the wheel anticlockwise (1) and remove the
retaining frame (2) (Fig. 13).
4 Remove the shaving heads from the shaving unit
and replace them with new ones (Fig. 14).
5 Put the retaining frame back into the shaving unit,
press the wheel and turn it clockwise.
6 Put the shaving unit back onto the shaver.
Accessories
The following accessories are available:
HQ64 Philips Double Action Super Lift & Cut
Shaving Heads (HQ5715)
HQ54 Philips Double Action Lift & Cut Shaving
Heads (HQ5710/HQ5705)
HQ110 Philips Shaving Head Cleaning Spray (not
available in China)
Environment
Batteries contain substances that may pollute the
environment. Remove the batteries when they are
empty or when you discard the appliance. Do not
throw away the batteries with the normal household
waste, but hand them in at an ofcial collection point.
Do not throw the appliance away with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling.
By doing this you will help to preserve the
environment (Fig. 18).
Guarantee & service
If you need information or if you have a problem, please
visit the Philips website at www.philips.com or contact
the Philips Customer Care Centre in your country
(you nd its phone number in the worldwide guarantee
leaet). If there is no Customer Care Centre in your
country, go to your local Philips dealer or contact the
Service Depar tment of Philips Domestic Appliances and
Personal Care BV.
Guarantee restrictions
The shaving heads (cutters and guards) are not covered
by the terms of the international guarantee because they
are subject to wear.
Frequently asked questions
Question Answer
Why doesn’t the
shaver shave as well
as it used to?
Why doesn’t the
shaver switch on
when I push the on/
off button upwards?
You may not have cleaned
the appliance properly. Clean
the shaving heads thoroughly
see chapter ‘Cleaning and
maintenance’).
Long hairs may be obstructing
the shaving heads. Clean the
cutters and guards properly with
the brush supplied (see chapter
‘Cleaning and maintenance’).
The shaving heads may be
damaged or worn. Replace
the shaving heads (see chapter
‘Replacement’).
The batteries may be running
low. Replace the batteries (see
chapter ‘Preparing for use’).
The batteries may be empty.
Replace the batteries (see
chapter ‘Preparing for use’).
