Philips HP4688-00 User Manual

SalonStraight

HP4688/00

English 6

Bahasa Melayu 20

TiếngViệt 32

HP4688/00

English

Introduction

The new Philips SalonStraight DUO is specially designed to give you perfect straight results and to prevent hair damage at the same time. That’s because this straightener has two sets of plates next to each other, which give the hair a dual treatment in one single stroke. First, the ceramic straightening plates with professional styling temperatures glide over the hair to give perfect results. Immediately after that, the white marble protection plates softly glide over the hair to neutralise damaging excess heat within seconds.

General description (Fig. 1)

ACeramic-coated straightening plates

BWhite marble protection plates

CPower-on light

DHeat setting selector

EEasy-access on/off switch

FEasy-lock system

GSwivel cord

Important

Read this user manual carefully before you use the appliance and save it for future reference.

-Check if the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.

-Check the condition of the mains cord regularly. Do not use the

appliance if the plug, the cord or the appliance itself is damaged.

-If the mains cord is damaged, you must have it replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.

-Keep this appliance away from water. Do not use it near or over water contained in baths, washbasins, sinks etc.When you use the appliance in a bathroom, unplug it after use.The proximity of water presents a risk, even when the appliance is switched off.

-For additional protection, we advise you to install a residual current device (RCD) in the electrical circuit that supplies the bathroom.

English

This RCD must have a rated residual operating current not higher than 30mA. Ask your installer for advice.

-Keep the appliance out of the reach of children.

-The straightening plates and the plastic parts near the plates become hot during use. Prevent the hot surfaces of the appliance from coming into contact with your skin.

-Do not use the appliance on wet hair.

-Do not straighten artificial hair.

-Do not leave the plates in your hair for more than a few seconds at a time as this may cause damage to your hair.

-Keep the appliance away from non-heat-resistant surfaces and never cover the appliance with anything (e.g. a towel or clothing) when it is hot.

-Keep the appliance away from flammable items.

-Never leave the appliance unattended when it is plugged in.

-Always unplug the appliance after use.

-Do not wind the mains cord round the appliance.

-Wait until the appliance has cooled down before you store it.

-Keep the plates clean and free of dust, dirt and styling products such as mousse, spray and gel. Never use the appliance in combination with styling products.

-Always return the appliance to a service centre authorised by Philips for examination or repair. Do not attempt to repair the appliance yourself, otherwise your guarantee becomes invalid.

-The straightening plates have a ceramic coating.This coating slowly wears away over time.This does not affect the performance of the appliance.

-If the appliance is used on colour-treated hair, the marble plates may stain.This does not affect the performance of the appliance.

Electromagnetic fields (EMF)

This Philips appliance complies with all standards regarding electromagnetic fields (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientific evidence available today.

English

Preparing for use

Washing

The straightener gives the best results on well-washed hair.We advise you to follow the washing tips below:

1Wet your hair thoroughly for 30-60 seconds.

2Pour some shampoo into the palm of your hand. Spread it between your hands and distribute it evenly through the hair.

3Gently massage your hair and scalp. Do not rough up the hair or pull up long hair onto the scalp, as this may cause tangles.

4Massage your scalp with your fingertips.This stimulates blood circulation and is gentler to the hair cuticles.

5Rinse your hair thoroughly, as poor rinsing can result in dull hair. Finish with a cold rinse for extra shine.

Drying

To get super-smooth results, it is essential to prepare your hair for straightening. Dry you hair properly with a hairdryer to ensure a professional, smooth finish.

1After washing, squeeze excess water out of the hair with your hands and then towel-dry the hair. Use a comb to disentangle hair gently from the roots to the tips.

2Divide the hair into sections using clips. Start at the back.

3To dry each section,pull a straightening brush down the hair length. Follow the brush with the hairdryer, with its nozzle pointing towards the hair ends.

4When you have finished drying each section,set the hairdryer to the cool setting for a final cool shot.This closes the cuticles and adds shine to the hair.

English

Note: Philips SalonPro hairdryers have a lower drying temperature and a stronger airflow than regular dryers.Thanks to this combination,they dry just as quickly as regular hairdryers but in a gentler way.

Using the appliance

Never leave the appliance unattended when it is plugged in.

Always put the appliance on a heat-resistant surface when it is heating up and when it is hot.

Straightening

Straighteners are powerful styling tools and must always be used with care.

Always follow the instructions below to select the right heat setting for your hair type:

-Always select a low heat setting when you use the straightener for the first time.

-For coarse, curly or hard-to-straighten hair, select a heat setting between 13 and 25 (155°C-210°C).

-For fine, medium-textured or softly waved hair, select a heat setting between 1 and 12 (100°C-150°C).

1Insert the plug into the wall socket.

2Set the on/off switch to ‘on’.

,The power-on light goes on.

,The straightening plates heat up rapidly and are ready for use within

60 seconds.

Some condensation may develop on the inside of the window near the marble plate.This is normal and does not affect hte performance of the appliance.

3Set the heat setting selector to the preferred heat setting (1-25) (Fig. 2).

4Comb or brush your hair so that it is disentangled and smooth. (Fig. 3)

10 English

Use a comb to divide the hair into sections. Do not put too much hair in one section.

Tip:It is better to section off the crown area and to straighten the hair underneath first,followed by the top area.

5Take a section that is approximately 3-4cm wide.

6Hold the straightener in such a way that the marble protection plates point upward and the hot straightening plates point downwards (Fig. 4).

-Look at the symbol on the appliance. (Fig. 5)

If the hot straightening plates point in the wrong direction, turn the appliance around.When you slide the straightener down the hair, the hot straightening plates must touch the hair before the marble protection plates.

7Press the handles of the appliance firmly together.

8Slide the straightener down the lock of hair in 5 seconds, from root to hair end, without stopping (Fig. 6).

9Repeat this process after 20 seconds until you have achieved the desired look.

10Let your hair cool down. Do not comb or brush it before it has cooled down, as this would ruin the hairstyle you have just created.

Cleaning

1Make sure the appliance is switched off and unplugged.

2Let the appliance cool down completely on a heat-resistant surface.

3Clean the appliance with a damp cloth.

Storage

Never wind the mains cord round the appliance.

1 Make sure the appliance is switched off and unplugged.

English 11

2Let the appliance cool down on a heat-resistant surface before you store it.

3Use the easy-lock system to lock the two halves of the appliance together before you store it.

Environment

-Do not throw away the appliance with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment (Fig. 7).

Guarantee & service

If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Customer Care

Centre in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, go to your local Philips dealer or contact the Service Department of Philips Domestic Appliances and Personal Care BV.

Frequently asked questions

This chapter lists the questions most frequently asked about the

Question	Answer

Why doesn’t	Perhaps there is a power failure or the socket is not
the appliance	live. Check if the power supply works. If it works,
work?	plug another appliance into the socket to check
	whether the socket is live.
	Perhaps the mains cord is damaged. If the mains cord
	is damaged, you must have it replaced by Philips, a
	service centre authorised by Philips or similarly
	qualified persons in order to avoid a hazard.

12 English

Question	Answer

	Perhaps the appliance is switched off. Set the on/off
	switch to ‘on’.
Why doesn’t	Perhaps you have selected a low heat setting. Set the
the appliance	heat setting selector to a higher heat setting.
heat up
sufficiently?

DUO .2 , .,.

( 1)

-, .

-., . ..

-(RCD). RCD

30mA ..

-..

-, , , ..

-. ,.

-..

- 있습니다. .

EMF( )

EMF( ). .

머리

1 30-60 .

3.,.

4. .

5...

요합니다. .

1 제거하십시오..

2 시오.

3 십시오. ,.

4 마무리하십시오..

: . .

- 택하십시오.

13~25(155°C-210°C)

-,1~12(100°C-150°C).

1 .

2‘on( )’ .

,60.

3(1-25) ( 2).

4. ( 3)

: .

5 3-4cm .

6( 4).

-. ( 5)

,. .

7 .

85 ( 6).

920 .

10 ..

1 . 2 . 3 .

1 .
