Philips HMP7100/05 user manual

Always there to help you

Question?

Contact

Philips

Question?

Contact

Philips

Register your product and get support at

www.philips.com/welcome

HMP7100

User manual

1EN

Switch on

HDMI

AC IN

AV
HDMI 1
HDMI 2
HDMI 3
Side HDMI
Side AV

SOURCE

HDMI IN

TV

Press to switch on. The
power indicator lights up
white.
Press again to switch off.
The power indicator lights
up red.

2 EN

On the remote control of
the TV, use the source button
to select the HDMI input
connector of HMP7100.

Setup: Connect to your home network

The network wizard helps
you to connect the device

Wired (Ethernet)

to the internet.

Please select the type of

Wireless (Wi-Fi)

network setup

Cancel

HDMI

Select the type of
Wi-Fi connection.

Wi-Fi Protected Setup (WPS)

Scan

Cancel

3,13%&6WDQGDUG

SPACE

DONE

.!@

DEF

$%&

#

Connect through Wi-Fi

On the screen of initial setup, select
[Wireless (Wi-Fi)]. Select [Scan] to
search for networks in range. Select a
network. Follow onscreen instructions
to complete Wi-Fi connection.

• Ifyouselect[Standard], enter the
password to your network.
On the remote control, press
to select an input mode. To enter
text, press to select
a key on the onscreen keyboard.
To complete text entry, select
DONE on the onscreen keyboard.

www.

.com

.net

.org +

ௗၿ

WWW

3EN

Setup: Connect to your home network

The network wizard helps
you to connect the device

Wired (Ethernet)

to the internet.

Please select the type of

Wireless (Wi-Fi)

network setup

Cancel

Connect through an Ethernet cable

On the screen of initial setup, select Wired
(Ethernet).

WWW

4 EN

SmartTV: Play from online services

HDMI

Next time you switch
on HMP7100, HMP7100
connects to the previously

6PDUW79+RPHQHWZRUN86%

connected network. On

6HWXS

the Home screen,
changes to . Select .

Play from a USB storage device

6PDUW79+RPHQHWZRUN86%

6HWXS

From the Home screen, select .

HDMI

5EN

Play from a PC

6HWXS

PC that runs the software of
DLNA media server

1 Connect your PC to the same network as HMP7100.
2 On HMP7100, select .

6PDUW79+RPHQHWZRUN86%

6 EN

SimplyShare: Play from an iOS or Philips Android
device

Make sure that you

HDMI

SimplyShare

SimplyShare

have connected
your iOS or Philips
Android device to
the same network as
HMP7100.

From App Store
or Google Play,
download the Philips
MyRemote app to
your device.

MyRemote

7EN

SimplyShare: Play from an iOS or Philips Android
device

In MyRemote,
select SimplyShare.
Select the source
of media, and then,

selectamediale

to start play.

To use your iOS or
Android device as
remote control, select
Control.

8 EN

Contents

1 Trademark notice 11

2 Safety and notice 12

Safety 12

Compliance 14

Copyright 15

Care of the environment 15

Warranty 16

3 Basics 17

Connect 17

Switch on or off 17

Use the remote control 19

Enter text 20

4 First-time setup 21

Connect to your home network 21

5 Play 25

Play from online services 25

Play from your home network 27

Play from a USB storage device 31

9EN

6 Setup 33

Video 34

Audio 34

Network 35

Preference 35

Advanced 35

7 EasyLink 36

8 UpdatethermwareofHMP7100 37

Updatethermwareonline 37

UpdatethermwarethroughaUSBstoragedevice 38

9 Troubleshooting 39

10Specication 40

11 Written Offer 41

10 EN

1 Trademark notice

®

ThetermsHDMIandHDMIHigh-DenitionMultimediaInterface,andtheHDMI

Logo are trademarks or registered trademar ks of HDMI Licensing LLC in the
United States and other countries.

DivX®,DivXCertied®,DivXPlus®HDandassociatedlogosaretrademarksof

Rovi Corporation or its subsidiaries and are used under license.
ABOUT DIVX PLUS® HD: DivX® is a digital video format created by DivX, Inc.

ThisisanofcialDivXCertied®devicethatplaysDivXvideo,includingDivX®

Plus HD video (H.264/.MKV) up to 1080p and premium content. Visit www.divx.

comformoreinformationandsoftwaretoolstoconvertyourlesintoDivX

video.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a

subsidiaryofRoviCorporation.ThisisanofcialDivXCer tied®devicethatplays

DivX video. Visit divx.com for more information and software tools to convert

yourlesintoDivXvideos.
ABOUTDIVXVIDEO-ON-DEMAND:ThisDivXCertied®devicemustbe

registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete your
registration.

Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.

11EN

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535
& other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS
and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a
trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

2 Safety and notice

Read and understand all instructions before you use this product. If damage is
caused by failure to follow the instructions, the warranty does not apply.

Safety

Important notes for users in the U.K.

Mains fuse

This information applies only to products with a UK mains plug.

Thisproductisttedwithanapprovednon-moldedplug.Ifyoureplacethefuse,

use one with:

• the ratings shown on the plug,

• a BS 1362 approval, and

• the ASTA approval mark.

Contact your dealer if you are not sure about what type of fuse to use.
Caution: To conform with the EMC directive (2004/108/EC), do not detach the
plug from the power cord.

How to connect a plug

12 EN

The wires in the power cord are colored as follows: blue = neutral (N), brown =
live (L).
If the colors do not correspond with the colors on your plug, identify the terminals
in your plug as follows:

1 Connect the blue wire to the terminal marked N or colored black.
2 Connect the brown wire to the terminal marked L or colored red.
3 Do not connect either wire to the earth terminal in the plug, marked E (or

e) or colored green (or green and yellow).
Before you replace the plug cover, make sure that the cord grip is clamped over
the sheath of the cable and not just over the two wires in the cable.

This 'bolt of lightning' indicates uninsulated material within the device may cause
an electrical shock. For the safety of everyone in your household, please do not
remove the covering.

The 'exclamation mark' calls attention to features for which you should read the
enclosed literature closely to prevent operating and maintenance problems.

WARNING:Toreducetheriskofreorelectricshock,thedeviceshouldnotbe
exposedtorainormoistureandobjectslledwithliquids,suchasvases,should

not be placed on the device.
CAUTION: To prevent electric shock, fully insert the plug. (For regions with
polarized plugs: To prevent electric shock, match wide blade to wide slot.)

• Onlyuseattachments/accessoriesspeciedbythemanufacturer.

• Use only power supplies listed in the user manual.

• The product shall not be exposed to dripping or splashing.

• Donotplaceanysourcesofdangerontheproduct(e.g.liquidlledobjects,

lighted candles).

• Batteries (battery pack or batteries installed) shall not be exposed to

excessiveheatsuchassunshine,reorthelike.

• Danger of explosion if battery is incorrectly replaced. Replace only with the

sameorequivalenttype.

13EN

0700

ModicationoftheproductcouldresultinhazardousradiationofEMCor

other unsafe operation.

Warning

• Never remove the casing of this product.

• Never lubricate any par t of this product.

• Neverplacethisproductonotherelectricalequipment.

• Keepthisproductawayfromdirectsunlight,nakedamesorheat.

• Ensure that you always have easy access to the power cord, plug or adaptor to disconnect the

product from the power.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect

device shall remain readily operable.

Compliance

ThisproductcomplieswiththeradiointerferencerequirementsoftheEuropean

Community.

Thisproductcomplieswiththerequirementofthe1999/5/ECdirective.

Class II equipment symbol:

CLASS II apparatus with double insulation, and no protective earth provided.

Anychangesormodicationsmadetothisproductthatarenotexpressly

approved by Philips Consumer Lifestyle may void the user’s authority to operate
the equipment.

14 EN

Note

• The type plate is located on the bottom of the product.

Copyright

This item incorporates copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.

Copyright in the U.K.

• Recordingandplaybackofmaterialmayrequireconsent.SeeCopyrightAct

1956 and The Performer’s Protection Acts 1958 to 1972.

Specicationsaresubjecttochangewithoutnotice.Trademarksaretheproperty

of Koninklijke Philips Electronics N.V or their respective owners. Philips reserves
the right to change products at any time without being obliged to adjust earlier
supplies accordingly.

Care of the environment

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging
easy to separate into three materials: cardboard (box), polystyrene foam (buffer)
and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations

regardingthedisposalofpackagingmaterials,andoldequipment.

15EN
