PHILIPS HI838 User Manual [fr]

Aquazur

HI845, HI838, HI835

DE G HFCBA

CALC CLEAN

ENGLISH 6

DEUTSCH 16

FRANÇAIS 26

NEDERLANDS 36

ITALIANO 46

HI845, HI838, HI835

General description

A Shot-of-steam button B Steam control C Spray button D Temperature pilot light E Steam trigger F Temperature dial G Soft-touch handgrip H Connecting cord/supply hose I Spray nozzle J Internal reservoir K Calc-clean button L Anti-calc cassette M Filling opening N Cassette release button O Suspension hook P Mains cord Q Water tank R Rubber mat

Important

Read these instructions for use carefully before using the appliance and save them for future reference.

◗ Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗ Only connect the appliance to an earthed wall socket. ◗ Do not use the appliance if the plug, the cord,the supply hose or

the appliance itself shows visible damage, or if the appliance has been dropped or is leaking.

◗ Check the cord and the supply hose regularly for possible

damage.

◗ If the mains cord or the supply hose is damaged, it must be

replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.

◗ Never leave the appliance unattended when it is connected to the

mains.

◗ Never immerse the iron or the steam tank in water. ◗ Keep the appliance out of the reach of children. ◗ The iron stand and the soleplate of the iron can become

extremely hot and may cause burns if touched.If you want to move the steam tank, do not touch the stand.

◗ Do not allow the mains cord and supply hose to come into

contact with the soleplate when it is hot.

◗ When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave the iron even for a short while:set the steam control to position O,put the iron on its heel and remove the mains plug from the wall socket.

ENGLISH6

ENGLISH 7

◗ Only use this iron with the stand supplied. ◗ Always place and use the iron and the steam tank on a stable,

level and horizontal surface. Do not put the steam tank on the soft part of the ironing board.

◗ Do not put perfume, vinegar, starch,descaling agents, ironing aids

or other chemicals in the water tank.

◗ This appliance is intended for household use only.

Before first use

1 Press the cassette release button and remove the anti-calc

cassette from the water tank. Enter the current date (day/month/year) on the sticker on the cassette. Reinsert the cassette into the water tank.

2 Fill the water tank with tap water (using a jar/bottle) up to the

MAX indication.

3 Set the temperature dial to MAX.

4 Set the steam control to position 4.

The temperature pilot light goes on.

. X

ENGLISH8

5 When the pilot light goes out, squeeze the steam trigger under

the handgrip continuously.

The iron starts producing steam after about 2 minutes.

6 Pass the iron over a piece of damp cloth for several minutes to

remove any residues from the soleplate.

The iron may give off some smoke when you use it for the first time.This will cease after a short while.

Preparing for use

How to use the rubber mat and the suspension hook

The rubber mat allows you to put down the hot iron during ironing. The suspension hook allows you to suspend the water tank from the ironing board.

◗ The rubber mat can be placed either on the water tank or on the

ironing board.

◗ If you want to put the iron on the water tank,always put the

rubber mat on the water tank.

◗ Never put the iron on the water tank without the rubber mat.

◗ The water tank can be suspended from the metal tray of most

ironing boards by means of the suspension hook.Pull the suspension hook out the water tank and attach it to the metal tray of the ironing board.

Remove the rubber mat from the water tank and place it on the ironing board before suspending the water tank from the suspension hook. Do not place the rubber mat on a table or any other surface that may be damaged by heat.

X A M

MAX.

ENGLISH 9

Filling the water tank

Never immerse the iron in water.

1 Unplug the appliance and make sure you don't squeeze the

steam trigger.

◗ If the water tank is in horizontal position, fill the it up to the MAX

level indicated on the side or in the filling opening.

◗ If the water tank is in vertical position, fill it up to the MAX

indication on the side. Do not exceed this level.

Do not put perfume, vinegar, starch, descaling agents, ironing additives chemically descaled water or other chemicals in the water tank.

Setting the temperature

1 Put the iron on the rubber mat.

2 Set the required ironing temperature by turning the

temperature dial to the appropriate position.

Check the laundry care label for the required ironing temperature:

- 1 Synthetic fabrics (e.g. acrylic, nylon, polyamide, polyester)

- 1 Silk

- 2 Wool

- 3 Cotton, linen

If you do not know what kind(s) of fabric(s) an article is made of, determine the right ironing temperature by ironing a part that will not be visible when you wear or use the article.

Silk, woollen and synthetic materials: iron the reverse side of the fabric to prevent shiny patches.Avoid using the spray function to prevent stains.

Start ironing the articles that require the lowest ironing temperature, such as those made of synthetic fibres.

3 Put the mains plug in an earthed wall socket.

4 When the amber temperature pilot light has gone out, wait a

while before you start ironing.

The amber pilot light will go on from time to time during ironing.

. X A

MAX.

Using the appliance

Steam ironing

1 Make sure that there is enough water in the water tank.

2 Put the iron on the rubber mat.

3 Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

4 Select the appropriate steam setting. Make sure that the steam

setting you select is suitable for the ironing temperature selected:

- 1 - 2 for moderate steam (temperature settings 2 to 3)

- 3 - 4 for maximum steam (temperature settings 3 to MAX)

The iron will start steaming as soon as the set temperature has been reached.

Just before the water tank is empty, the iron will normally produce a burst of steam and some minor spitting may occur.This is a normal phenomenon related to the electrical pump.

Ironing without steam

1 Select the recommended ironing temperature (see chapter

'Preparing for use', section 'Setting the temperature').

Do not squeeze the steam trigger.

Features

Spray function

You can use the spray function to remove stubborn creases at any temperature.

1 Make sure that there is enough water in the water tank.

2 Press the spray button several times to moisten the article to

be ironed.

When the internal reservoir is empty, squeeze the steam trigger for about one minute to refill it. Refilling is complete when you see or hear steam coming out from the steam vents in the soleplate.

◗ The internal reservoir must be filled at a temperature setting

between 2 and MAX. It is not possible to fill the internal reservoir at a temperature setting below 2.

ENGLISH10

Shot of steam

A powerful shot of concentrated steam helps remove stubborn creases. The shot-of-steam function can only be used at temperature settings between 2 and MAX at 5-second intervals.

1 Press and release the shot-of-steam button.

Vertical shot of steam

1 The shot-of-steam function can also be used when you hold

the iron in vertical position.

This is useful for removing creases from hanging clothes, curtains etc.

Never direct the steam towards people.

Drip stop

This iron is equipped with a drip-stop function: the iron automatically stops producing steam when the temperature is too low to prevent water from dripping out of the soleplate. When this happens you may hear a sound.

1 Set the temperature dial to a position that is suitable for steam

ironing (2 to MAX). Make sure that the steam setting you select is suitable for the ironing temperature selected (see 'Steam ironing' in chapter 'Using the appliance').

The iron will start steaming as soon as the set temperature has been reached.

Cleaning and maintenance

After ironing

1 Remove the mains plug from the wall socket and let the iron

cool down.

2 Wipe flakes and any other deposits off the soleplate with a

damp cloth and a non-abrasive (liquid) cleaning agent.

To keep the soleplate smooth, you should avoid hard contact with metal objects. Never use a scouring pad, vinegar or other chemicals to clean the soleplate.

ENGLISH 11

3 Clean the upper part of the iron with a damp cloth.

4 Regularly rinse the water tank with water. Empty the water

tank after cleaning.

Calc-clean function

You can use the calc-clean function to remove scale and impurities.

◗ Use the calc-clean function once every two weeks. If the water in

your area is very hard (i.e. when flakes come out of the soleplate during ironing), the calc-clean function should be used more frequently.

1 Make sure the appliance is unplugged.

2 Fill the water tank until it is half full.

Do not put vinegar or other descaling agents in the water tank.

3 Put the plug in the wall socket.

4 Set the temperature dial to the calc-clean position. Set steam

control to position 4.

5 Hold the iron over the sink,press and hold the calc-clean

button and gently shake the iron to and fro.

Steam and boiling water will come out of the soleplate. Impurities and flakes (if any) will be flushed out.

6 Release the calc-clean button as soon as the water in the tank

has been used up.

Repeat the calc-clean process if the iron still contains a lot of impurities.

After the calc-clean process

- Put the plug in the wall socket, set the temperature dial to position 2 and let the iron heat up to allow the soleplate to dry.

- Unplug the iron when it has reached the set ironing temperature.

- Move the hot iron gently over a piece of used cloth to remove any water stains that may have formed on the soleplate.

- Let the iron cool down before you store it.

ENGLISH12

Storage

1 Make sure the appliance is unplugged.

2 Empty the water tank.

3 Put the iron on the rubber mat and let it cool down sufficiently

before you store it.

Replacement

The Philips Aquazur has a disposable anti-calc cassette that filters the water in the water tank. After some time the cassette will be saturated and should be replaced by a new one. How often the cassette should be replaced depends on the water hardness in your area and how often you use the iron.

- If the water is very hard, replace the cassette every 3 months.

- If the water is moderately hard, replace the cassette every 9 months.

Turn to your local water board for information about the water hardness in your area.

To replace the cassette:

1 Press the cassette release button and remove the cassette.

2 Empty the water tank and the cassette compartment.

3 Enter the current date on the new cassette and insert it into

the water tank.

4 Fill the water tank with water.

5 Set the temperature dial to 3 and set the steam control to

position 4.

6 Squeeze the steam trigger for about one minute.The new

cassette is now filled with water.

You can resume ironing.

ENGLISH 13

. X

Environment

◗ Do not throw the appliance away with the normal household

waste at the end of its life, but hand it in at an official collection point for recycling. By doing this you will help to preserve the environment.

Guarantee & service

If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Customer Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, turn to your local Philips dealer or contact the Service Department of Philips Domestic Appliances and Personal Care BV.

Troubleshooting

This chapter summarises the most common problems you could encounter with your iron. Please read the different sections for more details. If you are unable to solve the problem, contact the Customer Care Centre in your country.

ENGLISH14

ENGLISH 15

Solution

Check the mains cord, the plug and the wall socket.

Set the temperature dial to the required position.

Fill the water tank to the MAX indication, insert the anti-calc cassette (push it down properly) and/or set the temperature dial to a temperature above 2.

Fill the water tank (see chapter 'Preparing for use'). Set the temperature dial to a position between 2 and MAX and squeeze the steam trigger for about 1 minute.

Select an ironing temperature that is suitable for steam ironing (2 to MAX).Wait until the amber pilot light has gone out before you start ironing.

Fill the water tank (see chapter 'Preparing for use'). Set the temperature dial to a position between 2 and MAX and squeeze the steam trigger for about 1 minute.

Select an ironing temperature that is suitable for steam ironing (2 to MAX).Wait until the amber pilot light has gone out before you start ironing.

Rinse the water tank and do not put any additive in the water tank.

Use the calc-clean function a few times (see chapter 'Cleaning and maintenance').

Possible cause(s)

There is a connection problem.

The temperature dial has been set to MIN.

The water level is too low, the anticalc cassette has not been properly inserted and/or the temperature has been set to a position below 2.

There is not enough water in the water tank or in the internal reservoir.

The iron is not hot enough and/or the drip-stop function has been activated.

There is not enough water in the water tank or in the internal reservoir.

The iron is not hot enough.

An additive has been poured into the water tank.

Hard water forms flakes inside the soleplate.

Problem

The iron is plugged in but the soleplate is cold.

The iron does not produce steam and the water tank produces a loud noise.

No spray.

No steam.

No shot of steam or no vertical shot of steam.

Water droplets drip onto the fabric.

Flakes and impurities come out of the soleplate during ironing.

Allgemeine Beschreibung

A Dampfstoß-Taste B Dampfregler C Sprühtaste D Temperaturkontrolllampe E Dampftaste F Temperaturregler G Soft Touch-Handgriff H Verbindungskabel/Dampfzufuhrschlauch I Spraydüse J Innerer Wasserbehälter K Calc-Clean Taste L Anti-Kalk-Kassette M Einfüllöffnung N Kassetten-Entriegelung O Aufhängevorrichtung P Netzkabel Q Wassertank R Gummiunterlage

Wichtig

Lesen Sie diese Bedienungsanleitung vor dem ersten Gebrauch des Geräts sorgfältig durch und bewahren Sie sie zur späteren Einsichtnahme auf.

◗ Überprüfen Sie, ob die auf dem Typenschild angegebene

Betriebsspannung mit der örtlichen Netzspannung übereinstimmt, bevor Sie das Gerät anschließen.

◗ Verwenden Sie das Gerät ausschließlich an einer

Schukosteckdose.

◗ Benutzen Sie das Gerät nicht, wenn Schäden am Stecker, am

Kabel, am Verbindungsschlauch oder am Gerät selbst erkennbar sind, oder wenn das Gerät herunter gefallen oder undicht ist.

◗ Überprüfen Sie das Netzkabel und den Verbindungsschlauch

regelmäßig auf Unversehrtheit.

◗ Wenn das Netzkabel oder der Verbindungsschlauch defekt oder

beschädigt ist, darf es/er nur von einem Philips Service-Center oder einer von Philips autorisierten Werkstatt durch ein OriginalErsatzteil ausgetauscht werden, um Gefährdungen zu vermeiden.

◗ Lassen Sie das Gerät nicht unbeaufsichtigt, solange es am

Stromnetz angeschlossen ist.

◗ Tauchen Sie das Bügeleisen und den Boiler niemals in Wasser. ◗ Halten Sie das Gerät außer Reichweite von Kindern. ◗ Die Abstellfläche und die Bügelsohle können sehr heiß werden

und bei Berührung Brandwunden verursachen. Berühren Sie keinesfalls die Abstellfläche, wenn Sie den Boiler bewegen.

◗ Lassen Sie das Netzkabel und den Verbindungsschlauch nicht in

Berührung mit der heißen Bügelsohle kommen.

DEUTSCH16

◗ Wenn Sie das Bügeln beenden, das Gerät reinigen, den

Wasserbehälter füllen oder leeren oder den Raum nur kurz verlassen, stellen Sie stets den Dampfregler auf Position 0, stellen Sie das Bügeleisen aufrecht und ziehen Sie den Netzstecker aus der Steckdose.

◗ Benutzen Sie dieses Bügeleisen nur mit der dazugehörigen

Ladestation.

◗ Platzieren und benutzen Sie das Bügeleisen und den Boiler stets

auf einer stabilen, ebenen und waagerechten Unterlage. Stellen Sie den Boiler nicht auf die weiche, gepolsterte Fläche des Bügelbretts.

◗ Geben Sie niemals Parfüm, Essig, Stärke, Entkalker,Bügelhilfen oder

andere Chemikalien in den Wasserbehälter.

◗ Dieses Gerät ist nur für den Gebrauch im Haushalt bestimmt.

Vor dem ersten Gebrauch

1 Drücken Sie die Kassetten-Entriegelungstaste und nehmen Sie

die Anti-Kalk-Kassette aus dem Wassertank.Tragen Sie das aktuelle Datum (Tag/Monat/Jahr) auf dem Aufkleber der Kassette ein und setzen Sie die Kassette zurück in den Wassertank.

2 Füllen Sie mit einem Krug oder einer Flasche Leitungswasser

bis zur MAX-Markierung in den Wassertank.

3 Stellen Sie den Temperaturregler auf MAX.

DEUTSCH 17

. X

4 Stellen Sie den Dampfregler auf 4.

Die Temperaturkontrolllampe leuchtet.

5 Wenn die Kontrolllampe erlischt,halten Sie die Dampftaste

unterhalb des Handgriffs gedrückt.

Nach ca. 2 Minuten produziert das Gerät Dampf.

6 Führen Sie das Bügeleisen einige Minuten lang auf einem

feuchten Tuch hin und her, um eventuell vorhandene Ablagerungen von der Bügelsohle zu entfernen.

Beim ersten Gebrauch gibt das Gerät möglicherweise etwas Rauch ab. Dies geht nach kurzer Zeit vorüber.

Vorbereitung zum Gebrauch

Der Gebrauch von Gummiunterlage und Hängevorrichtung

Sie können das heiße Bügeleisen zwischendurch auf die Gummimatte stellen. Mit der Hängevorrichtung können Sie den Wassertank am Bügeltisch aufhängen.

◗ Sie können die Gummiunterlage wahlweise auf den Wassertank

oder den Bügeltisch legen.

◗ Wenn Sie das Bügeleisen auf dem Wassertank abstellen möchten,

legen Sie stets die Gummiunterlage auf den Wassertank.

◗ Stellen Sie das Bügeleisen keinesfalls ohne die Gummiunterlage auf

den Wassertank.

DEUTSCH18

+ 40 hidden pages
