Page 1
Compressor
Nebuliser System
InnoSpire Deluxe
Robust home use device
Treatment in under 5 minutes*
*Using a 2.5ml Salbutamol dose
HH1350/00
Reliable therapy with built-in convenience
InnoSpire Deluxe is an easy to use and reliable compressor nebuliser system that includes built-in storage to
keep all your therapy accessories and supplies organised and handy.
For use in hospital and home
Desi gned for continuous use
Short treatment times
Treatment delivered in under 5 mi nutes*
Designed for convenience
Sturdy handle for easy transportation
Everything you need in one place
For commonly prescribed medications
Compatible with commonly prescribed nebulizer medications
Page 2
Compressor Nebuliser System
HH1350/00
Highlights Specifications
Convenience meets reliability
InnoSpire Deluxe is designed to make your
nebuliser treatment convenient and easy, with
added built-in storage to house all your
accessories.
For home use
Robust enough for continuous use in both a
clinical and family enviroment, InnoSpire
Elegance provides consistent and reliable
nebulizer therapy.
Robust Design
Weighing just 4.4 lbs, InnoSpire Deluxe is li ght
enough to pick up and move from room to room
at home. With your supplies stored neatly
away within the device, your nebulizer
equipment stays safely together in one place.
Treatment time
Combined with our reusable SideStream
nebulizer, i t is designed to provide fast drug
delivery and short treatment times.
Versatility
Capable of nebulizing a wide variety of
medications that are routinely used to treat
various respiratory conditions.
Thermal overload protector
Warranty
Service
Warranty: 3 years
Design
Convenient storage compartment: 2.0 kg (4.4
lbs)
Operating parameters
Maximum flow rate: 9.8 lpm
Maximum pressure: 360 kPA (52 psi)
Electricity supply: 230V / 50Hz, 1 Amp
Flow rate: 7 lpm @ 10 psi
Thermal overload protector: Resettable
thermal fuse
Product details
Weight: 2.2 kg
Size: 380 x 170 x 110 mm
Warranty: 3 years
Noise level: 58 ±3 dBA
Treatment ti me (under 5 min*): * 2.5ml
Salbutamol dose
SideStream Plus performance
MMAD: 3.42µm
Fine particle fraction: 67%
Time (2.5mL Salbutamol): 3.68 min
SideStream Reusable
MMAD: 2.93µm
Fine particle fraction: 76.3%
Time (2.5mL Salbutamol): 4.12 min
* * Using 2.5ml Salbutamol
© 20 21 Koninklijke Philips N.V.
All Right s reserved.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips N.V. or
their respective owners.
Issue date 2021‑03‑ 02
Version: 1.0.2
EAN: 69 46159 50202 3
www.phili ps.com
