Page 1
USER MANUAL
Type HD8966
Read carefully before using the machine.
02
English
EN
02
Register your product and get support at
www.saeco.com/welcome
Page 2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons do not immerse
cord, plugs, or appliance in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Save these instructions.
SAVE THESE INSTRUCTIONS
Page 3
CAUTION
This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.
1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2. Never use warm or hot water to fill the water tank. Use cold water only.
3. Keep your hands and the cord away from hot parts of the appliance during
operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6. Do not use caramelized or flavored coffee beans.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available
and may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children or tripped
over.
Page 4
2
ENGLISH
Congratulations on your purchase of a Saeco GranBaristo full automatic co ee machine!
To fully bene t from the support that Saeco o ers, please register your product at
www.saeco.com/welcome.
This user manual applies to HD8966.
The machine is suitable for preparing espresso co ee using whole co ee beans, and
it is supplied with a milk carafe so that you can prepare a perfect Cappuccino or Latte
Macchiato in a quick and easy way. In this user manual you will nd all the information you need to install, use, clean and descale your machine.
CONTENTS
IMPORTANT..................................................................................................... 4
Safety Instructions ...............................................................................................................................4
Warnings .............................................................................................................................................4
Cautions ..............................................................................................................................................6
Electromagnetic Fields ........................................................................................................................ 7
Disposal ...............................................................................................................................................7
INSTALLATION ................................................................................................. 8
Product Overview ................................................................................................................................8
General Description .............................................................................................................................9
PREPARING FOR USE .......................................................................................10
Machine Packaging............................................................................................................................10
Machine Installation ..........................................................................................................................10
Demo Mode Function ........................................................................................................................12
USING THE MACHINE FOR THE FIRST TIME ........................................................13
Language Selection ...........................................................................................................................13
Automatic Rinse/Cleaning Cycle ........................................................................................................14
Manual Rinse Cycle ............................................................................................................................ 15
Measuring and Programming Water Hardness .................................................................................. 18
“INTENZA+” Water Filter Installation ................................................................................................. 20
Replacing the “INTENZA+” Water Filter..............................................................................................24
CHANGING COFFEE BEANS ...............................................................................25
Removing the Co ee Bean Hopper ....................................................................................................25
Inserting the Co ee Bean Hopper ......................................................................................................26
Co ee Emptying Cycle .......................................................................................................................27
Pro le Selection ................................................................................................................................30
ADJUSTMENTS ................................................................................................31
Co ee Pro le .....................................................................................................................................31
Enabling a New Pro le ...................................................................................................................... 31
Disabling a User Pro le ......................................................................................................................32
Saeco Adapting System .....................................................................................................................34
Adjusting the Ceramic Co ee Grinder ...............................................................................................34
Adjusting the Aroma (Co ee Strength) .............................................................................................. 35
Adjusting the Dispensing Spout ......................................................................................................... 36
Adjusting the Co ee Quantity ...........................................................................................................38
BREWING COFFEE ...........................................................................................39
Co ee Brewing Using Co ee Beans ................................................................................................... 39
Co ee Brewing Using Pre-Ground Co ee ........................................................................................... 40
Page 5
ENGLISH
MILK CARAFE..................................................................................................42
Filling the Milk Carafe ........................................................................................................................42
Inserting the Milk Carafe ...................................................................................................................43
Removing the Milk Carafe .................................................................................................................. 43
Emptying the Milk Carafe ..................................................................................................................44
BREWING MILK-BASED BEVERAGES .................................................................45
Quick Carafe AUTO CLEAN Cycle ..........................................................................................................48
Adjusting the Milk-Based Product Length .........................................................................................49
SPECIAL BEVERAGES .......................................................................................51
Hot Water ..........................................................................................................................................51
Adjusting Hot Water Dispensing ........................................................................................................53
“Special Beverages” Menu for Brewing Other Beverages ...................................................................54
Adjusting the Quantity of Other Beverages for the “Special Beverages” Menu ...................................55
BEVERAGE PROGRAMMING .............................................................................56
Aroma ................................................................................................................................................57
Co ee Amount ................................................................................................................................... 57
Temperature ...................................................................................................................................... 57
Taste ..................................................................................................................................................58
Milk Amount ...................................................................................................................................... 58
HOT WATER PROGRAMMING ............................................................................58
Water Amount ...................................................................................................................................58
Temperature ...................................................................................................................................... 59
RESTORING BEVERAGE PARAMETERS ...............................................................59
MACHINE PROGRAMMING ...............................................................................60
Water settings ...................................................................................................................................60
Language Settings .............................................................................................................................61
Stand-by Settings .............................................................................................................................. 61
Button Sound ....................................................................................................................................62
Factory Settings .................................................................................................................................62
STATISTICS .....................................................................................................62
MAINTENANCE ...............................................................................................63
Descaling ........................................................................................................................................... 63
Brew Group Cleaning Cycle ................................................................................................................ 63
Carafe Cleaning..................................................................................................................................64
Co ee Circuit Cleaning .......................................................................................................................64
CLEANING AND MAINTENANCE ........................................................................65
Daily Cleaning of the Machine ...........................................................................................................65
Daily Cleaning of the Water Tank........................................................................................................67
Daily Cleaning of the Milk Carafe .......................................................................................................67
Weekly Cleaning of the Milk Carafe....................................................................................................70
Weekly Cleaning of the Brew Group ...................................................................................................74
Weekly Cleaning of the Co ee Bean Hopper, Tray and Co ee Compartment ......................................78
Monthly Cleaning of the Milk Carafe .................................................................................................. 80
Monthly Lubrication of the Brew Group ............................................................................................. 84
Monthly Cleaning of the Brew Group with “Co ee Oil Remover” ........................................................ 85
DESCALING .....................................................................................................88
ACCIDENTAL INTERRUPTION OF THE DESCALING CYCLE .....................................93
DISPLAY MESSAGES ........................................................................................94
TROUBLESHOOTING ........................................................................................96
ENERGY SAVING ..............................................................................................99
Stand-by ............................................................................................................................................99
TECHNICAL SPECIFICATIONS .......................................................................... 100
WARRANTY AND SERVICE ..............................................................................100
Warranty .........................................................................................................................................100
Service ............................................................................................................................................. 100
ORDERING MAINTENANCE PRODUCTS ............................................................101
MACHINE ACCESSORIES ................................................................................. 102
3
Page 6
4
ENGLISH
IMPORTANT
Safety Instructions
This machine is equipped with safety devices. Nevertheless,
read and follow the safety instructions carefully and only use
the machine properly as described in these instructions to
avoid accidental injury or damage due to improper use of the
machine. Keep this user manual for future reference.
The term WARNING and this icon warn against possible
severe injuries, danger to life and/or damage to the machine.
The term CAUTION and this icon warn against slight
injuries and/or damage to the machine.
This icon requests you to read carefully this instruction
manual, before any use or maintenance operation.
Warnings
• Connect the machine to a wall socket with a voltage
matching the technical speci cations of the machine.
• Connect the machine to an earthed wall socket.
• Do not let the power cord hang over the edge of a table or
counter, or touch hot surfaces.
• Never immerse the machine, the mains plug or power cord
in water: Danger of electrical shock!
• Do not pour liquids on the power cord connector.
• Never direct the hot water jet towards body parts: Danger
of burning!
Page 7
ENGLISH
• Do not touch hot surfaces. Use handles and knobs.
• After switching o the machine by pressing the power
button on the back of the machine, remove the mains plug
from the wall socket:
- if a malfunction occurs;
- if the machine will not be used for a long time;
- before cleaning the machine.
• Pull on the mains plug, not on the power cord.
• Do not touch the mains plug with wet hands.
• Do not use the machine if the mains plug, the power cord
or the machine itself is damaged.
• Do not make any modi cations to the machine or its
power cord. Only have repairs carried out by a service
centre authorised by Philips to avoid any hazard.
• The machine should not be used by children younger than
8 years old.
5
5
• The machine can be used by children of 8 years and upwards
if they have previously been instructed on the correct use of
the machine and made aware of the associated dangers or if
they are supervised by an adult.
• Cleaning and maintenance should not be carried out by
children unless they are more than 8 years old and supervised by an adult.
• Keep the machine and its power cord out of reach of children under 8 years old.
• The machine may be used by persons with reduced physical, sensory or mental capabilities or lacking su cient
experience and/or skills if they have previously been
instructed on the correct use of the machine and made
Page 8
6
ENGLISH
aware of the associated dangers or if they are supervised
by an adult.
• Children should be supervised to ensure that they do not
play with the machine.
• Never insert ngers or other objects into the co ee
grinder.
Cautions
• The machine is for household use only. It is not intended
for use in environments such as canteens, sta kitchens of
shops, o ces, factories or other work environments.
• Always put the machine on a at and stable surface.
• Do not place the machine on hot surfaces, directly next to
a hot oven, heater units or similar sources of heat.
• Only put roasted co ee beans into the co ee bean hopper.
If ground co ee, instant co ee, raw co ee or any other
substance is put in the co ee bean hopper, it may damage
the machine.
• Let the machine cool down before inserting or removing
any parts. The heating surfaces may retain residual heat
after use.
• Never use warm or hot water to ll the water tank. Use
only cold non-sparkling drinking water.
• Never clean with scrubbing powders or harsh cleaners.
Simply use a soft cloth dampened with water.
• Descale your machine regularly. Not doing this will make
your appliance stop working properly. In this case repair is
not covered under your warranty!
Page 9
ENGLISH
7
7
• Do not keep the machine at temperature below 0 °C.
Residue water in the heating system may freeze and cause
damage.
• Do not leave water in the water tank if the machine is
not used over a long period of time. The water can get
contaminated. Use fresh water every time you use the
machine.
Electromagnetic Fields
This appliance complies with all the applicable standards and
regulations relating to the exposure to electromagnetic elds.
Disposal
This symbol on a product indicates that the product is covered
by EU Directive 2012/19/EU. Please inform yourself about the
local separate collection system for electrical and electronic
products. Follow local regulations and do not dispose of
the product as household waste. Appropriate disposal of
old products helps prevent negative consequences for the
environment and human health.
Page 10
8
INSTALLATION
Product Overview
4
1c
1b
1a
2
3
5
6
7
8
14
10 119
18
12
13
15
16
45
17
22
44
19
23
24 25 26
2120
33323130292827
46
47
43424136 37 4038 393534
Page 11
ENGLISH
General Description
1a. Co ee bean hopper
1b. Co ee bean hopper tray
1c. Co ee bean hopper lid
2. Cup-warming surface
3. Water tank + lid
4. Co ee bean hopper locking/removal selector switch
5. Pre-ground co ee compartment
6. Service door button
7. Control panel
8. Removable co ee dispensing spout
9. Service door
10. Brew group locking/removal handle
11. Drip tray (internal)
12. Co ee grounds drawer
13. Brew group
14. Full drip tray indicator
15. Cup holder grill
16. Drip tray (external)
17. Protection lid
18. Water dispensing spout (removable)
19. Milk carafe
20. Power cord socket
21. Power button
22. Pre-ground co ee measuring scoop / grinder adjustment key
23. Power cord
24. Cleaning brush (optional)
25. Grease for brew group (optional)
26. Water hardness test strip
27. Espresso Macchiato button
28. Cappuccino button
29. "ESC" button
30. LCD Display
31. "UP" button
32. Espresso button
33. Long Espresso button
34. Latte Macchiato button
35. Hot Milk button
36. "MENU" button
37. "OK" button
38. “Special beverages” button
39. "Aroma" - Pre-ground co ee button
40. "DOWN" button
41. Stand-by button
42. Co ee button
43. American Co ee button
44. Protection cover (optional)
45. Co ee oil remover (optional)
46. Descaling solution (optional)
47. "INTENZA+" water lter (optional)
9
9
Page 12
10
ENGLISH
PREPARING FOR USE
Machine Packaging
The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.
Machine Installation
Remove the drip tray with grill and the carafe from the packaging.
1
Remove the machine from the packaging.
2
For best use, it is recommended to:
3
• Choose a safe, level surface where there will be no danger of overturning the machine or being injured.
• Choose a location that is su ciently well-lit, clean and near an easily reachable socket.
• Allow for a minimum distance from the sides of the machine as
shown in the gure.
Insert the drip tray (external) with grill all the way into the machine.
4
Make sure that it is correctly placed; a "CLICK" will con rm that it is
locked into place.
Note:
The drip tray collects the water that comes out of the dispensing spout
during each rinse/self-cleaning cycle, as well as any co ee that might be
spilled during beverage brewing. Empty and wash the drip tray daily and
each time the full drip tray indicator is raised.
Caution:
NEVER remove the drip tray when the machine has just been turned
on. Wait a couple of minutes for the machine to carry out a rinse/selfcleaning cycle.
Page 13
ENGLISH
Lift the left outer lid.
5
Remove the water tank by using the handle incorporated on the inner
6
lid.
Rinse the water tank with fresh water.
7
Fill the water tank with fresh drinking water up to the MAX level and
8
put it back into the machine. Make sure it is fully inserted.
11
11
Caution:
Never ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.
Remove the co ee bean hopper lid. Slowly pour in the co ee beans.
9
Note:
The co ee bean hopper contains a tray that vibrates during grinding and
conveys the beans into the co ee grinder.
Caution:
Only co ee beans must be put into the co ee bean hopper. Ground
co ee, instant co ee, caramelized co ee or any other object may
damage the machine.
Put the lid back on the co ee bean hopper.
10
Page 14
12
ENGLISH
Insert the plug into the socket located on the back of the machine.
11
Insert the plug on the other end of the power cord into a wall socket
12
with suitable power voltage.
Switch the power button on the back of the machine to “I” to turn on
13
the machine.
Press the button to turn on the machine.
14
DEMO MODE ON
Demo Mode Function
The machine is equipped with an operation simulating function.
By keeping the “
chine enters the demo mode. To exit the demo, disconnect the power cord
and turn the machine back on.
” button pressed for more than 8 seconds, the ma-
Page 15
LINGUA
ITALIANO
ENGLISH
DEUTSCH
FRANÇAIS
LINGUA
ITALIANO
ENGLISH
DEUTSCH
FRANÇAIS
ENGLISH
USING THE MACHINE FOR THE FIRST TIME
When using the machine for the rst time, the following activities need to
happen:
1) You have to select the language.
2) The machine will perform an automatic rinse/cleaning cycle.
3) You need to perform a manual rinse cycle.
Language Selection
At rst start up, the language must be selected.
The following display is shown. Select the desired language by press-
1
ing the “
Press the “ ” button to con rm.
2
” or “ ” scrolling button.
13
13
HEATING UP…
WATER CIRCUIT
PRIMING
The machine is in warm-up phase.
3
Once warm-up has been completed, the machine automatically per-
4
forms the water circuit priming.
Page 16
14
ENGLISH
RINSING
Automatic Rinse/Cleaning Cycle
When warm-up has been completed, the machine automatically performs
a rinse/self-cleaning cycle of the internal circuits with fresh water. This
takes less than a minute.
Place a container under the co ee dispensing spout to catch the small
1
amount of water which will be dispensed.
The following display is shown. Wait for the cycle to nish automati-
2
cally.
Note:
To stop dispensing, press the “
” button.
PROFILE SAECO
When the operations described above have been completed, the ma-
3
chine shows the following display. You can now perform the manual
rinse cycle.
Page 17
PROFILE SAECO
REGULAR
ENGLISH
Manual Rinse Cycle
You need to perform a rinse cycle when using the machine for the rst
time. During this process, the co ee brewing cycle is activated and fresh
water ows through the dispensing spout. This takes a few minutes.
Place a container under the co ee dispensing spout.
1
Check that the machine shows the following display.
2
Press the " " button to access the aroma selection menu.
3
15
15
GROUND COFFEE
FFEE
To select the pre-ground co ee brewing function, press the “ ” or “ ”
4
scrolling button until the “
” icon is displayed.
Note:
Do not add pre-ground co ee into the compartment.
Press the “ ” button.
5
Page 18
16
E
ENGLISH
PREGROUND COFFE
AND PRESS OK
INSERT
When choosing the product, the machine asks you to con rm that
6
ground co ee has been inserted.
Press the “
” button. The machine will start dispensing water from the
co ee dispensing spout. When dispensing has been completed, empty
the container.
Remove the protection cover.
7
Note:
Store the cover with care.
Slightly tilt the water dispensing spout and insert it all the way into
8
the guides of the machine. Push the water dispensing spout towards
the bottom while rotating it at the same time, until it is locked into the
machine as shown in the gure.
PROFILE SAECO
Place an empty container under the hot water dispensing spout.
9
Press the “ ” button.
10
Page 19
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
HOT WATER
INSERT
WATER SPOUT
ENGLISH
Press the “ ” button.
11
Press the “ ” button. At the end of the warm-up phase, the machine
12
starts dispensing water.
After dispensing water, remove and empty the container.
13
Repeat the operations from step 10 to 13 until the water tank is empty,
14
then continue with step 15.
17
17
PROFILE SAECO
At the end, ll the water tank again up to the MAX level. Now the ma-
15
chine is ready to brew co ee.
This icon will be displayed.
Note:
When you have not used the machine for 2 or more weeks, the machine
will automatically perform an automatic rinse/self-cleaning cycle after
you turn it on. Following this, you need to perform a manual rinse cycle as
described above.
The automatic rinse/self-cleaning cycle also starts when the machine has
been in stand-by mode, or turned o , for more than 15 minutes.
At the end of the cycle, you can brew products.
Page 20
18
ENGLISH
C
B
Measuring and Programming Water Hardness
Water hardness measuring is very important in order to de ne the machine
descaling frequency and to install the “INTENZA+” water lter (for more
details on the water lter, see next chapter).
To measure the water hardness follow the steps below:
Immerse the water hardness test strip (supplied with the machine) in
1
water for 1 second.
Note:
The test strip can only be used for one single measurement.
Wait for one minute.
2
Check how many squares have changed to red, then consult this table.
3
Note:
The numbers on the water hardness test strip correspond to the water
hardness adjustment settings.
More precisely:
1 = 1 (very soft water)
2 = 2 (soft water)
3 = 3 (hard water)
4 = 4 (very hard water)
Intenza Aroma System
A
PROFILE SAECO
23 4
Machine Water Hardness Setting
1
The letters correspond to the references that are located at the base of the
“INTENZA+” water lter (see next chapter).
Press the “ ” button to access the machine main menu.
4
Page 21
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
ENGLISH
Press the “ ” button to select “SETTINGS”.
5
Press “ ” to con rm.
6
Press “ ” to con rm the “WATER” selection.
7
Press “ ” to con rm the “HARDNESS” selection.
8
Note:
The machine is supplied with a standard water hardness setting, suitable
for most types of water.
19
19
HARDNESS
1
2
3
4
PROFILE SAECO
Press the “ ” button to increase the value or the “ ” button to
9
decrease the value.
Press the “ ” button to con rm the setting.
10
Press the “ ” button to exit the programming menu. Now the ma-
11
chine is ready for brewing.
Page 22
20
ENGLISH
“INTENZA+” Water Filter Installation
We recommend that you install the “INTENZA+” water lter as this prevents
limescale build-up in your machine and preserves a more intense aroma of
your co ee.
Water is a crucial part of every co ee, so it is very important to always have
it professionally ltered. Using the “INTENZA+” water lter will prevent
mineral deposits from building up and improve your water quality.
Remove the “INTENZA+” water lter from its packaging, immerse it ver-
1
tically (with the opening positioned upwards) in cold water and gently
press the sides so as to let the air bubbles out.
Set the “INTENZA+” water lter according to the measurements per-
2
formed (see previous chapter) and indicated on the base of the lter:
A = soft water – equals 1 or 2 on the test strip
B = hard water (standard) – equals 3 on the test strip
C = very hard water – equals 4 on the test strip
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
PROFILE SAECO
Press the “ ” button to access the machine main menu.
3
Press the “ ” button to select “SETTINGS”.
4
Page 23
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
Press “ ” to con rm.
5
Press “ ” to con rm the “WATER” selection.
6
Press the “ ” button to select “ACTIVATE FILTER”.
7
Press “ ” to con rm.
8
ENGLISH
21
21
ACTIVATE FILTER
ACTIVATE FILTER?
(~ 2 MINUTES)
Press “ ” to con rm.
9
Note:
To exit activation, press the "
Remove the small white lter from the water tank and store it in a dry
10
" button.
place.
Page 24
22
ENGLISH
ACTIVATE FILTER
INSERT FILTER.
FILL WATER TANK
Put the “INTENZA+” water lter into the empty water tank. Press it
11
down until it cannot move any further.
Fill the water tank with fresh water up to the MAX level and put it back
12
into the machine.
Press “ ” to con rm.
13
Check that the water dispensing spout is correctly installed.
14
ACTIVATE FILTER
INSERT
WATER SPOUT
Press “ ” to con rm.
15
Place a container under the hot water dispensing spout.
16
Page 25
ACTIVATE FILTER
PLACE A CONTAINER
UNDER THE
WATER SPOUT
ACTIVATE FILTER
PROFILE SAECO
ENGLISH
Press “ ” to con rm.
17
The machine starts dispensing water. This screen will be displayed.
18
When the machine stops dispensing, remove and empty the container.
19
Now the machine is ready for brewing.
23
23
In this way the machine has been programmed to inform the user of
the need to replace the “INTENZA+” water lter.
Page 26
24
ENGLISH
CHANGE FILTER
Replacing the “INTENZA+” Water Filter
When the “INTENZA+” water lter needs to be replaced with a new one, the
following icon is displayed.
Replace the lter as described in the previous chapter.
1
The machine is now programmed to manage a new lter.
2
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
Note:
If the lter is already installed and you want to remove, but not replace it,
select the “ENABLE FILTER” option and set it on OFF.
If there is no “INTENZA+” water lter installed, insert the small white lter
previously removed into the water tank.
Page 27
ENGLISH
25
25
CHANGING COFFEE BEANS
The machine comes with a removable co ee bean hopper so you can
easily switch from one type of co ee bean to another and enjoy a di erent
co ee taste.
Note:
You can buy an additional co ee bean hopper as an accessory (CA6807).
To preserve their taste, you can store co ee beans in the co ee bean hopper in the refrigerator.
Removing the Co ee Bean Hopper
To remove the co ee bean hopper follow the steps below:
Move the selector switch to the “ ” position.
1
Caution:
It may happen that the selector switch cannot be moved to the desired
position as it is blocked by co ee beans. In this case, move the selector
switch back and forth repeatedly until the beans are released.
Lift the sides of the co ee bean hopper with both hands as shown in
2
the gure.
Caution:
Do not remove the co ee bean hopper in a di erent way to avoid spilling co ee beans.
Page 28
26
ENGLISH
After removing it, put the protection cover (if any) on the machine to
3
keep it dust-free.
INSERT
BEAN CONTAINER
Note:
If a co ee product is requested without the co ee bean hopper inserted,
the following icon will appear. You need to insert the co ee bean hopper
rst.
Inserting the Co ee Bean Hopper
To insert the co ee bean hopper follow the steps below:
Remove the protection cover from the machine (if any).
1
Move the selector switch to the “ ” position.
2
Remove any beans from the co ee bean hopper compartment.
3
Page 29
ENGLISH
Insert the co ee bean hopper into its compartment as shown in the
4
gure.
Move the selector switch to the “ ” position.
5
Warning:
Please be aware that when you change co ee beans and switch to
deca einated co ee, some ca eine traces might still be present even
after performing an emptying cycle.
27
27
PROFILE SAECO
Co ee Emptying Cycle
When you switch from a type of co ee beans to another by changing the
co ee bean hopper, it is recommended to clean the co ee duct in order to
fully taste the new blend aroma. For this, follow the steps below:
Fill the co ee bean hopper or replace it with a new hopper.
1
Press the “ ” button to access the machine main menu.
2
Page 30
28
ENGLISH
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
EDIT PROFILES
MAINTENANCE
MAINTENANCE
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
MENU
SETTINGS
STATISTICS
DESCALING
Press the “ ” button to select “MAINTENANCE”.
3
Press “ ” to con rm.
4
Press the " " button to select “COFFEE EMPTYING’”.
5
Press “ ” to con rm.
6
COFFEE EMPTYING
START COFFEE
EMPTYING CYCLE?
Press “ ” to con rm.
7
Page 31
COFFEE EMPTYING
PROFILE SAECO
ENGLISH
The machine performs a grinding cycle without brewing co ee.
8
Now the machine is ready for brewing.
9
Note:
If you have not emptied the co ee duct and grinder, you need to brew at
least two cups of co ee before you can taste the new co ee beans.
Warning:
Please be aware that when you change co ee beans and switch to
deca einated co ee, some ca eine traces might still be present even
after performing a cleaning cycle.
29
29
Page 32
30
ENGLISH
PROFILE SAECO
Pro le Selection
This function allows you to optimize product brewing according to the coffee blend just inserted into the machine or personal preferences.
Press the “ ” button or the “ ” button to select the pro les saved in
1
the machine.
You can choose between 3 co ee pro les, optimized according to the
beans used:
PROFILE SAECO
PROFILE ROBUSTA
PROFILE ARABICA
- The SAECO Blend pro le, optimized for an Arabica and Robusta blend.
- The Robusta pro le, optimized for Robusta co ee beans.
- The Arabica pro le, optimized for Arabica co ee beans.
Note:
The machine also allows you to create 3 additional user pro les to customise the beverages according to personal preferences. Refer to the “Ena-
bling a New Pro le” chapter.
Page 33
PROFILE SAECO
PROFILE SAECO
ENGLISH
ADJUSTMENTS
The machine allows for certain adjustments so that you can brew the best
tasting co ee possible.
Co ee Pro le
The machine can accommodate the individual preferences and settings of
up to 6 di erent pro les.
The machine has 3 preset pro les, modelled on the various types of co ee
on the market. The default one is indicated by the icon on the left.
You can create 3 additional pro les, which can be entirely customised. For
a quick reference, users are represented by a unique icon, which has to be
selected during programming.
Enabling a New Pro le
Press the “ ” button to access the machine main menu.
1
31
31
EDIT PROFILES
MAINTENANCE
STATISTICS
EDIT PROFILES
PROFILE SAECO
PROFILE ARABICA
PROFILE ROBUSTA
ENABLE NEW PROFILE
MENU
SETTINGS
Press “ ” to con rm.
2
Press the “ ” button to select “ENABLE NEW PROFILE”.
3
Page 34
32
ENGLISH
ENABLE NEW PROFILE
EDIT PROFILES
PROFILE SAECO
PROFILE ARABICA
PROFILE ROBUSTA
ENABLE NEW PROFILE
PROFILE 1
PROFILE 2
PROFILE 3
PROFILE 1
ESPRESSO
ESPRESSO LUNGO
COFFEE
AMERICAN COFFEE
Press “ ” to con rm.
4
Press the “ ” button or the “ ” button to select the desired pro le,
5
which will be represented by a unique icon.
Note:
When a pro le has already been enabled, it is not displayed in the possible
options.
Press “ ” to con rm.
6
You can now customise beverages (see the “Beverage Programming”
7
chapter).
PROFILE SAECO
Disabling a User Pro le
You can disable an already enabled user pro le, but not the preset pro les.
Note:
In this case, all the pro le settings are kept in the memory but are not displayed. The respective icon is now available again in the enabling options.
To enable the pro le again, refer to the “Enabling a New Pro le” section.
Press the “ ” button to access the machine main menu.
1
Page 35
EDIT PROFILES
MAINTENANCE
STATISTICS
EDIT PROFILES
PROFILE ROBUSTA
PROFILE 1
ENABLE NEW PROFILE
DISABLE PROFILE
DISABLE PROFILE
PROFILE 1
MENU
SETTINGS
ENGLISH
Press “ ” to con rm.
2
Press the “ ” button to select “DISABLE PROFILE”.
3
Press the " " button to select the pro le to disable. Press the " "
4
button to con rm. The pro le is now disabled.
Note:
In this display all the pro les enabled earlier on will be shown. Only the
selected pro le will be disabled.
33
33
EDIT PROFILES
PROFILE SAECO
PROFILE ARABICA
PROFILE ROBUSTA
ENABLE NEW PROFILE
PROFILE SAECO
The following display is shown.
5
Press the “ ” button to exit the programming menu. Now the ma-
6
chine is ready for brewing.
Page 36
34
ENGLISH
Saeco Adapting System
Co ee is a natural product and its characteristics may change according to
its origin, blend and roast. The machine is equipped with a self-adjusting
system that allows the use of all types of co ee beans available on the
market except for caramelized and avoured co ee beans.
The machine automatically adjusts itself after brewing several cups of coffee to optimize co ee extraction.
Adjusting the Ceramic Co ee Grinder
Ceramic co ee grinders always guarantee an accurate and perfect grinding
and a speci c coarseness for every co ee speciality.
This technology provides full aroma preservation, delivering the truly Italian taste in every cup.
Warning:
The ceramic co ee grinder contains moving parts that may be dangerous. Do not insert ngers or other objects. Only adjust the ceramic
co ee grinder using the grinder adjustment key.
You can adjust the ceramic grinders to set the co ee grinding to your
personal taste.
Remove the co ee bean hopper as shown in the “Removing the Co ee
1
Bean Hopper” section.
Press and turn the grinder adjustment knob under the co ee bean
2
hopper one notch at a time. Use the co ee grinder adjustment key
provided with the machine. You will taste the di erence after brewing
2-3 cups of co ee.
Warning:
Do not turn the co ee grinder more than one notch at the time to
prevent damage.
Page 37
ENGLISH
The reference marks in the co ee bean hopper compartment indicate
3
the grind setting. There are 5 di erent grind settings to choose from,
from position 1 for coarse grind - lighter taste to position 2 for ne
grind - stronger taste.
35
35
1
VERY STRONG
2
When you adjust the ceramic co ee grinder to a ner setting, your co ee
will taste stronger. For a lighter co ee taste, adjust the ceramic co ee
grinder to a coarser setting.
Adjusting the Aroma (Co ee Strength)
The machine allows you to adjust the right quantity of ground co ee for
each product. The standard adjustment for each product can be set in the
“EDIT PROFILES” (see the “Beverage Programming” chapter, “STRENGTH”
option).
To temporarily change the quantity of ground co ee, press the
1
button on the control panel.
Note:
Selection must be made prior to selecting co ee.
Press
the “ ” or “ ” scrolling button
2
played. Then select the beverage.
= very mild aroma
= mild aroma
= regular aroma
= strong aroma
= very strong aroma
= extra strong aroma
= ground co ee
until the
desired aroma is dis-
“ ”
Note:
This function remains active for 30 seconds. Then the machine resets the
selection and goes back to the earlier status.
Note:
You cannot choose the aroma for the “Energy co ee”, “Espresso Intense”
and “Espresso Mild” Special products.
Page 38
36
ENGLISH
Adjusting the Dispensing Spout
The height of the co ee dispensing spout can be adjusted to better t the
dimensions of the cups that you wish to use.
Move the co ee dispensing spout up or down with your ngers to adjust
its height as shown in the gure.
Note:
when removing the dispensing spout to use large containers or for cleaning, make sure to insert it in the right direction during assembly. If you can
see this triangle, the dispensing spout was assembled incorrectly.
The recommended positions are:
For the use of small cups.
For the use of large cups.
Page 39
ENGLISH
For the use of glasses for the Latte Macchiato.
Note:
This is possible by moving the dispensing spout towards the machine.
Two cups can be placed under the co ee dispensing spout to brew two
co ees at the same time.
37
37
Page 40
38
MEMO
ENGLISH
Adjusting the Co ee Quantity
The machine allows you to adjust the amount of brewed co ee or milk according to your taste and the size of your cups.
Each time the Espresso “
the American Co ee “
”, the Café Crème “ ”, the Co ee “ ” and
” buttons are pressed, the machine brews a preset
amount of product. Each button may be individually programmed for a
speci c brew setting.
The following procedure describes the Espresso “ ” button programming.
Place a cup under the co ee dispensing spout.
1
Press and hold the Espresso “ ” button until the “MEMO” icon
2
appears on the display, then release the button. The machine is now in
programming mode.
The machine starts brewing co ee.
MEMO
Press the Espresso “ ” button as soon as the desired amount of cof-
3
fee is reached.
Now the Espresso “
” button is programmed; each time it is pressed,
the machine will brew the same amount of espresso that was just programmed.
Note:
Follow the same procedure for programming the Café Crème “
” and American Co ee “ ” buttons.
“
”, Co ee
Once the desired amount is reached, press the selected brew button again
to stop brewing.
You can also adjust the beverage length in the “EDIT PROFILES” (see the
“Beverage Programming” chapter, “COFFEE AMOUNT” option).
Page 41
ENGLISH
39
39
BREWING COFFEE
Before brewing co ee, make sure that there are no warnings shown on the
display, and that the water tank and co ee bean hopper are lled.
Co ee Brewing Using Co ee Beans
Place 1 or 2 cups under the co ee dispensing spout.
1
Press the “ ” button for an Espresso, the “ ” button for a Café
O
2
Crème, the “
” button for a Co ee or the “ ” button for an Ameri-
can Co ee.
To brew 1 cup of co ee, press the desired button once. The following
ESPRESSO
3
display is shown.
ESPRESSO
2 x ESPRESSO
To brew 2 cups of co ee, press the desired button twice consecutively.
4
The following display is shown.
Note:
In this operating mode, the machine automatically grinds and doses the
proper amount of co ee.
After the prebrewing cycle, co ee begins to pour out of the co ee
5
dispensing spout.
Co ee brewing automatically stops when the preset level is reached;
6
you can stop it earlier by pressing the same button that you pressed to
start brewing.
Page 42
40
ENGLISH
Co ee Brewing Using Pre-Ground Co ee
This function allows you to use pre-ground and deca einated co ee.
With the pre-ground co ee function you can only brew one co ee at a
time.
Place a cup under the co ee dispensing spout.
1
GROUND COFFEE
O
PREGROUND COFFEE
AND PRESS OK
REGULAR
INSERT
Press the " " button to access the aroma selection menu.
2
To select the pre-ground co ee brewing function, press the “ ” or “ ”
3
scrolling button until the “
Press the “ ” button for an Espresso, the “ ” button for a Café
4
” icon is displayed.
Crème or the “ ” button for a Co ee.
When choosing the product, the machine asks you to con rm that
5
ground co ee has been inserted.
Page 43
ENGLISH
Open the pre-ground co ee compartment lid.
6
Add one measuring scoop of pre-ground co ee into the compartment.
7
41
41
Use only the measuring scoop supplied with the machine. Then close
the pre-ground co ee compartment lid.
Warning:
Add only pre-ground co ee into the pre-ground co ee compartment.
Other substances and objects may cause severe damage to the machine. This repair is not covered by your warranty!
Press the “ ” button. After the prebrewing cycle, co ee begins to pour
8
out of the co ee dispensing spout.
INSERT
PREGROUND COFFE
AND PRESS OK
Co ee brewing automatically stops when the preset level is reached;
O
9
press the same selected beverage button again to stop it earlier.
PROFILE SAECO
After brewing, the machine returns to the main menu.
Repeat the steps described above to brew more co ees using pre-ground
co ee.
Note:
If no pre-ground co ee is poured into the compartment, only water will be
dispensed.
If the dose is excessive or if 2 or more measuring scoops have been added,
the machine will discharge the excess pre-ground co ee into the co ee
grounds drawer. The brewing length cannot be saved for pre-ground coffee.
Note:
This function remains active for 30 seconds. Then the machine resets the
selection and goes back to the earlier status.
Page 44
42
ENGLISH
MILK CARAFE
This chapter explains how to use the milk carafe to prepare milk-based
beverages.
Note:
Before using the milk carafe, clean it thoroughly as described in the “Cleaning and Maintenance” chapter.
We recommend lling it with cold milk (approx. 5°C).
Warning:
Fill the carafe with milk for brewing beverages and with water for
cleaning only.
Filling the Milk Carafe
The milk carafe can be lled before or during use.
Lift the carafe lid as shown in the gure.
1
Pour milk into the milk carafe: the milk level must be between the
2
minimum (MIN) and maximum (MAX) level indicators shown on the
milk carafe. Put the carafe lid back on.
The milk carafe is now ready for use.
3
Page 45
ENGLISH
Inserting the Milk Carafe
If installed, remove the water dispensing spout as shown in the gure:
1
- Press the two buttons on the side to unlock it and lift it slightly;
- Pull the hot water dispensing spout to remove it.
43
43
1
2
Slightly tilt the milk carafe. Insert it all the way into the guides of the
2
machine.
Push the carafe towards the bottom while rotating it at the same time,
3
until it is locked onto the drip tray.
Do not force the carafe while inserting it.
Removing the Milk Carafe
Rotate the carafe upwards until it is released from the insert in the drip
1
tray. Then remove it.
Page 46
44
1
ENGLISH
Emptying the Milk Carafe
A
B
Press one of the release buttons to remove the top of the carafe as
1
shown in the gures (A or B).
1
Lift the top of the carafe. Empty the milk carafe and clean it properly.
2
Note:
After each use, clean the milk carafe as described in the “Cleaning and
Maintenance” chapter.
Page 47
ENGLISH
BREWING MILKBASED BEVERAGES
Warning:
Danger of burning! Dispensing may be preceded by jets of milk and
steam. Wait until the end of the cycle before removing the milk carafe.
45
45
The buttons to automatically prepare an Espresso Macchiato “
puccino “
the control panel.
The procedure for brewing a Cappuccino “
Fill the milk carafe with milk. The milk level must be between the mini-
1
mum (MIN) and maximum (MAX) level indicators shown on the milk
carafe. Put the carafe lid back on.
Use cold (~5 °C / 41°F) milk with a protein content of at least 3% to ensure
optimum results when preparing a cappuccino. Whole milk or skimmed
milk may be used depending on individual taste.
Insert the carafe into the machine.
2
”, a Latte Macchiato “ ” and a Hot Milk “ ” are displayed on
” is shown as an example.
Note:
”, a Cap-
Pull out the carafe dispenser to the right up to the “ ” icon. Make sure
3
that the dispensing spout handle is perfectly aligned to the “
” icon.
Page 48
46
CLICK!
E
ENGLISH
PROFIL
When the carafe dispenser is correctly positioned you will hear a CLICK!
4
Note:
If the carafe dispenser has not been pulled all the way out, steam may
escape and milk may not be properly frothed.
Place a cup under the carafe dispenser.
5
Press the Cappuccino “ ” button to start brewing.
6
PLACE MILK CARAFE
AND OPEN SPOUT
CAPPUCCINO
Note:
When dispensing milk-based beverages, the brewing cycle can be ended
by pressing the “
The machine reminds you to insert the carafe and pull out the carafe
7
” ESC button.
dispenser.
The machine grinds the prede ned quantity of co ee.
8
Page 49
CAPPUCCINO
CAPPUCCINO
CAPPUCCINO
ENGLISH
The following screen is displayed during the preheating time required
9
by the machine.
The machine starts dispensing milk. To stop the dispensing process,
10
press the same selected beverage button that you pressed previously.
Dispensing will stop in a few seconds.
Once frothed milk has been dispensed, the machine brews co ee.
11
To stop brewing, press the same selected beverage button that you
pressed previously.
47
47
When brewing has been completed, if you do not wish to perform an
12
automatic carafe rinse cycle, close the carafe dispenser by sliding it to the
” icon.
“
Note:
After using the milk carafe, clean it as described in the "Cleaning and Maintenance" chapter.
Note:
Follow the same steps to prepare an Espresso Macchiato “
”, a Latte
Macchiato “ ” or a Hot Milk “ ”. When you reach step 5, press the desired
product button.
Page 50
48
ENGLISH
CARAFE AUTO CLEAN
START CARAFE
AUTO CLEAN?
Quick Carafe AUTO CLEAN Cycle
After one or more milk-based products have been prepared, the machine
allows for a quick cleaning of the carafe ducts.
The following screen is displayed for 20 seconds. Press the “ ” button
1
to start the cycle.
20
Note:
If you wish to prepare another milk-based beverage or do not wish to
perform the rinse cycle, press the “
Pull out the carafe dispenser to the right up to the “ ” icon. Place a
2
” button.
container under the carafe dispenser.
CARAFE AUTO CLEAN
OPEN MILK CARAFE SPOUT.
MACHINE WILL DISPENSE
HOT WATER
CARAFE AUTO CLEAN
PLACE CONTAINER
UNDER THE CARAFE
DISPENSING SPOUT
CARAFE AUTO CLEAN
Press the “ ” button.
3
The display shows that the cycle is being performed. Once the cycle
4
has been completed,
close the carafe dispenser by sliding it to the “ ”
icon and empty the container.
Page 51
ENGLISH
E
Adjusting the Milk-Based Product Length
Every time the Espresso Macchiato “ ”, the Cappuccino “ ”, the Latte
Macchiato “
brews a preset amount of selected beverage into the cup.
The machine allows you to adjust the amount of each beverage according
to your taste and the size of your cups.
” and the Hot Milk “ ” buttons are pressed, the machine
49
49
PLACE MILK CARAFE
AND OPEN SPOUT
PROFIL
The procedure for programming a Cappuccino “
” is shown as an exam-
ple.
Fill the carafe with milk and insert it into the machine.
1
Pull out the carafe dispenser to the right up to the “ ” icon.
2
Place a cup under the carafe dispenser.
Press and hold the Cappuccino “ ” button until the following display
3
is shown, then release the button. The machine reminds you to insert
the carafe and pull out the carafe dispenser. The machine is now in
programming mode.
MEMO
The machine grinds the prede ned quantity of co ee.
4
Page 52
50
ENGLISH
CAPPUCCINO
MEMO
This icon is displayed during the preheating time required by the
5
machine.
When this icon is shown, the machine starts dispensing frothed milk
6
into the cup. Once the desired amount of frothed milk is reached,
press the same selected beverage button that you pressed previously.
Dispensing will stop in a few seconds.
Note:
If you are dispensing a Hot Milk “
”, the dispensing process ends with step
six.
CAPPUCCINO
Once frothed milk has been dispensed, the machine starts brewing
7
co ee. When the desired quantity is reached, press the same selected
beverage button that you pressed previously.
Now the Cappuccino “
” button is programmed. Every time it is pressed,
the machine will brew the same amount of cappuccino that was programmed.
Note:
Follow the same steps to prepare an Espresso Macchiato “
”, a Latte
Macchiato “ ” or a Hot Milk “ ”. When you get to step 3, press the desired
product button.
Page 53
PROFILE SAECO
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
ENGLISH
SPECIAL BEVERAGES
The machine is designed to brew more products than those described so
far. For this, follow the steps below:
Press the “ ” button to access the “SPECIAL BEVERAGES” menu.
1
Select the beverage by pressing the “ ” button or the “ ” button.
2
Then press the “
To stop the beverage brewing, press the Special Beverages “ ” but-
3
ton again or press the “
” button to start brewing.
” button.
51
51
Note:
If you press the Special Beverages “
” button without choosing any
product, the machine returns to the main menu after 3 minutes.
With the special beverages function you can only brew one beverage at a
time. To brew more beverages, repeat the procedure.
Hot Water
Warning:
Danger of burning! Dispensing may be preceded by small jets of hot
water and steam. Wait until the end of the cycle before removing the
water dispensing spout.
Remove the milk carafe, if inserted. Slightly tilt the water dispensing
1
spout and insert it all the way into the guides of the machine.
Page 54
52
ENGLISH
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
Push the water dispensing spout towards the bottom while rotating
2
it at the same time, until it is locked into the machine as shown in the
gure.
Place a container under the hot water dispensing spout.
3
Press the “ ” button to access the “SPECIAL BEVERAGES” menu.
4
Press the “ ” button to start brewing.
5
HOT WATER
INSERT
WATER SPOUT
HOT WATER
This icon is displayed. The machine reminds you to install the water
6
dispensing spout. Check that the water dispensing spout is correctly
installed. Press “
” to con rm. The machine will start dispensing hot
water.
This icon is displayed during the preheating time required by the
7
machine.
Dispense the desired amount of hot water.
8
To stop dispensing hot water, press the “
” button.
Page 55
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
HOT WATER
INSERT
WATER SPOUT
ENGLISH
Adjusting Hot Water Dispensing
Warning:
Danger of burning! Dispensing may be preceded by small jets of hot
water and steam. Wait until the end of the cycle before removing the
water dispensing spout.
Make sure that the machine is ready for the hot water dispensing.
1
Press the “ ” button to access the “SPECIAL BEVERAGES” menu.
2
Press the “ ” button until this display is shown, then release the but-
3
ton.
Press “ ” to con rm. The machine will start dispensing hot water.
4
53
53
MEMO
This icon is displayed during the preheating time required by the
5
machine.
Dispense the desired amount of hot water.
6
To stop the hot water dispensing, press the Special Beverages “
button again.
The amount of water to dispense is now programmed. Every time it is
selected, the machine will dispense the same amount of hot water that
was programmed.
”
Page 56
54
ENGLISH
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
“Special Beverages” Menu for Brewing Other Beverages
The menu allows you to brew other beverages, according to your personal
taste.
The procedure for brewing a strong co ee is shown as an example.
Note:
Follow the same steps to brew the other menu beverages. Only when you
are brewing a “Flat white” you need to prepare the machine as for brewing
a Cappuccino.
Place 1 cup under the co ee dispensing spout.
1
Press the “ ” button to access the “SPECIAL BEVERAGES” menu.
2
Select the beverage by pressing the “ ” button until you reach the
3
“RISTRETTO” option.
Press the “ ” button to start brewing.
4
Co ee brewing automatically stops when the preset level is reached;
5
press the “Special beverages” “
” button again to stop it earlier.
Page 57
SPECIAL BEVERAGES
HOT WATER
RISTRETTO
ESPRESSO MILD
ESPRESSO INTENSE
MEMO
ENGLISH
Adjusting the Quantity of Other Beverages for the “Special Beverages” Menu
This procedure allows you to adjust the quantity of the other beverages
displayed on the menu, according to personal taste.
The procedure for brewing a strong co ee is shown as an example.
Note:
Follow the same steps to brew the other menu beverages. Only when you
are brewing a “Flat white” you need to prepare the machine as for brewing
a Cappuccino.
Place 1 cup under the co ee dispensing spout.
1
Press the “ ” button to access the “SPECIAL BEVERAGES” menu.
2
Select the beverage by pressing the “ ” button until you reach the
3
“RISTRETTO” option.
Press and hold the “ ” button until the "MEMO" icon appears on the
4
display, then release the button. The machine is now in programming
mode.
The machine starts brewing co ee.
Press the “ ” button as soon as the desired amount of co ee is
5
reached.
55
55
Now the beverage is programmed; each time it is selected, the machine
will brew the same amount that was just programmed.
Note:
Only when you are brewing a “Flat white” you need to program the amount
of milk and co ee separately, as shown for brewing a Cappuccino.
Page 58
56
PROFILE ARABICA
PROFILE ROBUSTA
ENGLISH
PROFILE SAECO
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
EDIT PROFILES
PROFILE SAECO
PROFILE 1
BEVERAGE PROGRAMMING
The machine allows you to customise every beverage according to your
personal taste and to save the preferences in your personal pro le.
Press the “ ” button to access the machine main menu.
1
Press “ ” to con rm.
2
Press the “ ” button to select the enabled pro le in which you wish
3
to program the beverage.
EDIT PROFILES
PROFILE SAECO
PROFILE ARABICA
PROFILE ROBUSTA
PROFILE 1
COFFEE
AMERICAN COFFEE
CAPPUCCINO
LATTE MACCHIATO
PROFILE 1
Press “ ” to con rm.
4
Note:
The parameters to adjust for brewing a cappuccino are shown as an example. Follow the same steps to adjust other beverages. The milk parameters
are not available for the co ee-only beverages.
Press the “ ” button to select “CAPPUCCINO”.
5
Press “ ” to con rm.
6
Page 59
ENGLISH
57
57
CAPPUCCINO
STRENGTH
COFFEE AMOUNT
TEMPERATURE
TASTE
STRENGTH
VERY STRONG
The parameters to adjust are displayed.
To select them, press the “
To access, press the “
To return to the previous screen, press the "
To return to the initial screen, press the "
” or “ ” scrolling button.
” button.
" button.
" button.
Aroma
This setting adjusts the amount of co ee to be ground.
= very mild aroma
= mild aroma
= regular aroma
= strong aroma
= very strong aroma
= extra strong aroma
= ground co ee
Press the “
” or “ ” scrolling button to select, then press the “ ” button
to con rm.
COFFEE AMOUNT
30ML 170ML
TEMPERATURE
HIGH
NORMAL
LOW
Co ee Amount
By adjusting the bar on the display with the “ ” or “ ” scrolling button,
you can choose the amount of water used for co ee brewing.
Press "
" to con rm the adjustment.
Temperature
This setting allows you to adjust the co ee temperature.
LOW : low temperature.
NORMAL : medium temperature.
HIGH : high temperature.
Press the “
” or “ ” scrolling button to select, then press the “ ” button
to con rm.
Page 60
58
ENGLISH
TASTE
DELICATE
BALANCED
FULL BODY
MILK AMOUNT
10 SEC 50 SEC
Taste
This setting enables the prebrewing function. During prebrewing, the coffee is slightly dampened to bring out the aroma in full.
DELICATE: prebrewing function is not performed.
BALANCED: prebrewing function is enabled.
FULL BODY: prebrewing function lasts longer to enhance the co ee
taste.
Press the “ ” or “ ” scrolling button to select, then press the “ ” button
to con rm.
Milk Amount
By adjusting the bar on the display with the “ ” or “ ” scrolling button,
you can choose the quantity of milk to use for the selected beverage. Press
" to con rm the adjustment.
"
Note:
The milk adjusting options are displayed only for the milk-based beverages.
PROFILE 1
ESPRESSO MACCHIATO
FROTHED MILK
HOT WATER
RISTRETTO
WATER AMOUNT
50ML 450ML
HOT WATER PROGRAMMING
The following procedure describes the programming of hot water.
Press the “ ” button to select “HOT WATER”.
1
Press “ ” to con rm.
2
Water Amount
By adjusting the bar on the display with the “ ” or “ ” scrolling button,
you can choose the quantity of water to be dispensed.
Press "
" to con rm the adjustment.
Page 61
TEMPERATURE
HIGH
NORMAL
LOW
Temperature
This setting allows you to adjust the co ee temperature.
LOW : low temperature.
NORMAL : standard temperature.
HIGH : high temperature.
ENGLISH
59
59
PROFILE 1
ESPRESSO INTENSE
ENERGY COFFEE
FLAT WHITE
RESTORE TO DEFAULT
Press the “
” or “ ” scrolling button to select, then press the “ ” button
to con rm.
RESTORING BEVERAGE PARAMETERS
The factory settings of every beverage can be restored for each pro le.
Press the “ ” button to select “RESTORE TO DEFAULT”.
1
Press “ ” twice to con rm. All the parameters are restored to factory
2
settings.
Note:
Through this option all the customised settings programmed by the user
are deleted.
CAPPUCCINO
TEMPERATURE
TASTE
MILK AMOUNT
RESTORE TO DEFAULT
The factory settings of every beverage can be restored for each parameter.
When the desired beverage has been selected, press the " " button
1
to select “RESTORE TO DEFAULT”.
Press “ ” twice to con rm. All the parameters are restored to factory
2
settings.
Note:
Through this option all the customised settings programmed by the user
for the selected product are deleted.
Page 62
60
ENGLISH
PROFILE SAECO
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
EDIT PROFILES
MAINTENANCE
MENU
SETTINGS
STATISTICS
MACHINE PROGRAMMING
The machine allows you to customise the operating settings. These settings are applied to all user pro les.
Press the “ ” button to access the machine main menu.
1
Press the “ ” button to select “SETTINGS”.
2
Press “ ” to con rm.
3
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
The parameters to adjust are displayed here.
To select them, press the “
To access, press the “
To return to the previous screen, press the "
To return to the initial screen, press the "
” or “ ” scrolling button.
” button.
" button.
" button.
Water settings
The WATER SETTINGS option allows you to adjust the water parameters
for an optimal co ee.
Page 63
ENGLISH
61
61
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
WATER
HARDNESS
ENABLE FILTER
ACTIVATE FILTER
Under HARDNESS you can set the water hardness level.
For water hardness measuring, refer to the “Measuring and Programming
Water Hardness” chapter.
Under ENABLE FILTER the machine noti es the user when the water lter
needs to be replaced.
OFF: Filter and warning disabled. (Default value) By setting the value
on OFF you disable the lter and the replacement warning.
ON: Filter and warning enabled (this warning is automatically set when
the lter is activated).
Under ACTIVATE FILTER you activate the lter after its installation or
replacement. Refer to the “INTENZA+ Water Filter Installation” chapter.
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
SETTINGS
WATER
LANGUAGE
STAND-BY TIME
BUTTON SOUND
Language Settings
This setting is important to automatically adjust the machine parameters
according to the user's country.
Stand-by Settings
The STAND-BY sets the time lapse for the machine to go into stand-by
mode after the last brewing. The stand-by time ranges among 15, 30, 60
and 180 minutes.
The default time value is 15 minutes.
Page 64
62
ENGLISH
STAND-BY TIME
BUTTON SOUND
RESTORE TO DEFAULT
STAND-BY TIME
BUTTON SOUND
RESTORE TO DEFAULT
SETTINGS
LANGUAGE
SETTINGS
LANGUAGE
Button Sound
This setting allows the machine to produce a sound each time a button is
pressed.
OFF: Tone deactivated
ON: Tone activated
Factory Settings
Activating the RESTORE TO DEFAULT option will restore all machine set-
tings to their default values. In this case all customised parameters will be
deleted.
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
PROFILE SAECO
STATISTICS
The machine allows you to see how many beverages have been brewed.
This allows you to schedule the various maintenance operations indicated
in the instruction manual.
Press the “ ” button to access the machine main menu.
1
Press the “ ” button to select “STATISTICS”.
2
Press “ ” to con rm.
3
The amount of brewed beverages, divided for each option, will be displayed.
Page 65
PROFILE SAECO
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
ENGLISH
MAINTENANCE
In this menu you can manage all the automatic cycles necessary for the
correct maintenance of the machine.
Press the “ ” button to access the machine main menu.
1
Press the “ ” button to select “MAINTENANCE”.
2
Press “ ” to con rm.
3
Press the “ ” or “ ” button to select the cycle to activate.
4
The various cycles to activate are displayed here.
63
63
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
Descaling
The DESCALING function activates the descaling cycle (see the “Descaling”
chapter).
Brew Group Cleaning Cycle
The BREW GROUP CLEANING function enables the brew group monthly
cleaning (see the “Monthly Cleaning of the Brew Group” chapter).
Page 66
64
ENGLISH
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
Carafe Cleaning
The CARAFE CLEANING menu allows you to manage the carafe cleaning.
CARAFE CLEANING
ON/OFF AUTO CLEAN
START FULL CLEAN
CARAFE CLEANING
ON/OFF AUTO CLEAN
START FULL CLEAN
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
In ON/OFF AUTO CLEAN you nd the options to manage the “Quick
Rinse Cycle” displayed after dispensing a milk-based beverage.
OFF: Cycle deactivated.
ON: Cycle activated.
In START FULL CLEAN you can start the milk carafe cleaning (see the
“Monthly Cleaning of the Milk Carafe” chapter).
Co ee Circuit Cleaning
The COFFEE EMPTYING function enables the co ee circuit cleaning (see
the “Co ee Emptying Cycle” chapter).
Page 67
ENGLISH
CLEANING AND MAINTENANCE
Daily Cleaning of the Machine
Caution:
Timely cleaning and maintenance of your machine is very important
as it prolongs the life of your machine. The machine is continuously
exposed to humidity, co ee and limescale!
The activities you need to perform and their frequency are described
in detail in this chapter. Not doing this will ultimately make your machine stop working properly. This repair is NOT covered by warranty!
Note:
- Use a soft, dampened cloth to clean the machine.
- Only the cup holder grill, the internal drip tray, the co ee grounds
drawer and any parts of the carafe described in the "Weekly Cleaning
of the Milk Carafe" section can be washed in the dishwasher. Any other
components must be washed with lukewarm water.
- Do not immerse the machine in water.
- Do not use alcohol, solvents, and/or abrasive objects to clean the
machine.
- Do not dry the machine and/or its components using a microwave
and/or standard oven.
Empty and clean the co ee grounds drawer and the drip tray (internal)
every day with the machine turned on. Please follow the steps below:
65
65
Press the button in the frame and open the service door.
1
Remove the drip tray (internal) and co ee grounds drawer.
2
Page 68
66
ENGLISH
Empty the co ee grounds drawer and wash it with fresh water.
3
Empty the drip tray (internal) and the lid and wash them with fresh
4
water.
Correctly reinstall all the components.
5
Insert the drip tray and the co ee grounds drawer and close the ser-
6
vice door.
Press the lever on the bottom and remove the drip tray (external),
7
empty it and wash it.
Page 69
ENGLISH
Note:
Perform this operation also when the full drip tray indicator is raised.
Daily Cleaning of the Water Tank
Remove the small white lter or the INTENZA+ water lter (if installed)
1
from the water tank and wash both with fresh water.
Put the small white lter or the INTENZA+ water lter (if installed) back
2
in its housing by gently pressing and turning it at the same time.
Fill the water tank with fresh water.
3
67
67
Daily Cleaning of the Milk Carafe
In addition to the quick carafe rinse cycle, we recommend that you also
clean the carafe daily as described below. This preserves hygiene and
ensures a perfect frothed milk consistency.
1
A
B
Press one of the release buttons to remove the top of the carafe as
1
shown in the gures (A or B).
1
Page 70
68
ENGLISH
A
Remove the lid.
2
Lift the carafe dispenser to remove it from the top of the carafe.
3
Remove the suction tube with the tting (A) from the milk frother.
4
Wash the suction tube with the tting thoroughly with fresh water.
5
After installing the suction tube with the tting, insert the carafe dis-
6
penser on the top of the carafe.
Page 71
ENGLISH
69
69
A
B
Note:
If you cannot install the dispenser on the top of the carafe, the pin is in the
wrong position (B). Before installing the dispenser, manually push the pin
to the (A) position.
Insert the lid.
7
Place the top of the carafe back in position.
8
Page 72
70
1
ENGLISH
Weekly Cleaning of the Milk Carafe
The weekly cleaning is more thorough since all milk residues are removed
from the dispenser.
A
B
Press one of the release buttons to remove the top of the carafe as
1
shown in the gures (A or B).
1
Remove the lid.
2
Lift the carafe dispenser to remove it from the top of the carafe. The
3
carafe dispenser is made up of six parts that must be disassembled.
Each part is indicated by a capital letter (A, B, C, D, E, F).
Remove the suction tube with the tting (A) from the milk frother.
4
A
Page 73
71
71
Remove the tting (B) from the suction tube.
5
ENGLISH
B
Detach the lid (C) from the milk carafe dispenser by slightly pressing on
6
C
the sides while pushing downwards.
Remove the milk frothing device (D) from the support (E).
7
D
E
Remove the tting (F) from the milk frothing device by pulling it out-
8
wards.
F
Clean all the parts thoroughly with lukewarm water.
9
Note:
You can also clean these parts in the dishwasher.
Page 74
72
ENGLISH
D
Insert the tting (F) into the milk frothing device by pressing it up to its
10
limit.
F
Insert the milk frothing device (D) into the support (E).
11
E
Attach the top (C) to the carafe dispenser.
12
C
Insert the tting (B) into the suction tube.
13
B
Insert the suction tube with the tting (A) into the milk frother.
14
A
Page 75
Insert the dispenser on the top of the carafe.
15
ENGLISH
73
73
A
B
Note:
If you cannot install the dispenser on the top of the carafe, the pin is in the
wrong position (B). Before installing the dispenser, manually push the pin
to the (A) position.
Insert the lid.
16
Attach the top of the milk carafe, ensuring it is locked into place.
17
Page 76
74
ENGLISH
Weekly Cleaning of the Brew Group
The brew group should be cleaned every time the co ee bean hopper is
lled or at least once a week.
Turn o the machine by pressing the “ ” button and remove the plug
1
from the socket.
Open the pre-ground co ee compartment lid.
2
Thoroughly clean the pre-ground co ee compartment with the clean-
3
ing brush, making sure that there are no more co ee residues in the
duct.
Press the button in the frame and open the service door.
4
Remove the drip tray (internal) and co ee grounds drawer and clean
5
them.
Page 77
Open the brew group unlocking lever.
6
Seize the brew group handle and pull it outwards.
7
While pulling the lever, remove the brew group.
8
ENGLISH
75
75
Thoroughly wash the brew group with lukewarm water and carefully
9
clean the brew group lter.
Caution:
Do not use detergent or soap to clean the brew group.
Let the brew group air-dry thoroughly.
10
Thoroughly clean the inside of the machine using a soft, dampened
11
cloth.
Page 78
76
ENGLISH
Thoroughly clean the upper screen using a non-abrasive cloth to
12
remove any co ee grounds.
Warning:
Danger of burning! The upper screen is a hot component. Make sure
that the machine has cooled down, before cleaning. Perform the operation when the machine has been turned o for at least one hour.
Make sure that the brew group is in the o position; the two reference
13
marks must match. If they do not match, proceed as described in steps
(14 and 15).
Turn the brew group back to the o position by manually turning the
14
pin on the base, as shown in this gure. Turn it until it locks into the
position described in the following step.
When you reach the position shown in this gure, check that the two
15
reference signs match and that the brew group is locked into position.
Page 79
ENGLISH
Insert the brew group back into its seat by sliding it along the guides
16
until it locks into place.
Close the brew group locking lever to lock it into position.
17
Insert the drip tray (internal) and co ee grounds drawer.
18
77
77
Close the service door.
19
Page 80
78
ENGLISH
Weekly Cleaning of the Co ee Bean Hopper, Tray and Co ee Compartment
Clean the co ee bean hopper, tray and co ee compartment once a week
with a cloth to remove any co ee residues and dust.
Remove the co ee bean hopper as shown in the “Removing the Co ee
1
Bean Hopper” section.
Clean the co ee compartment with a cloth to remove any co ee resi-
2
dues and dust.
Empty any beans out of the co ee bean hopper.
3
To remove the tray, press on the hooks on the bottom of the co ee
4
bean hopper as shown in the gure on the left.
Page 81
ENGLISH
Remove the tray. Clean the tray and the co ee bean hopper with a wet
5
cloth.
After cleaning and drying the tray, insert it back into the co ee bean
6
hopper. Insert the tray hooks into their seats on the co ee bean hopper.
Insert the co ee bean hopper into the compartment.
7
79
79
Slowly pour in the co ee beans. Place the lid.
8
Page 82
80
ENGLISH
PROFILE SAECO
Monthly Cleaning of the Milk Carafe
For the monthly cleaning cycle we recommend using the “Saeco Milk
Circuit Cleaner” to keep the entire circuit clean of milk residues. The “Saeco
Milk Circuit Cleaner” can be purchased separately. Please refer to the maintenance products page for further details.
Warning:
Danger of burning! Dispensing may be preceded by small jets of hot
water and steam. Danger of burning! Wait until the end of the cycle
before removing the milk carafe.
Press the “ ” button to access the machine main menu.
1
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
CARAFE CLEANING
ON/OFF AUTO CLEAN
START FULL CLEAN
Press the “ ” button to select “MAINTENANCE”.
2
Press “ ” to con rm.
3
Press the " " button to select “CARAFE CLEANING’”.
4
Press “ ” to con rm.
5
Press the " " button to select “START FULL CLEAN”.
6
Press “ ” to con rm.
7
Page 83
ENGLISH
81
81
CARAFE CLEANING
START CARAFE
FULL CLEAN?
(~ 5 MINUTES)
CARAFE CLEANING
REFILL
WATER TANK
CARAFE CLEANING
POUR DETERGENT
INTO CARAFE & FILL
WITH WATER
Press “ ” to con rm or “ ” to return to the previous menu.
8
Fill the water tank with fresh water up to the MAX level. Press the " "
9
button to con rm.
Pour one milk cleaner bag into the milk carafe. Fill the milk carafe with
10
fresh drinking water up to the MAX level and then let the milk cleaner
bag dissolve completely.
CARAFE CLEANING
PLACE MILK CARAFE
AND OPEN SPOUT
Insert the carafe into the machine.
11
up to the “
Press “ ” to con rm.
12
” icon.
Press the " " button to con rm.
Slide the carafe dispenser to the right
Page 84
82
ENGLISH
CARAFE CLEANING
PLACE CONTAINER
UNDER THE CARAFE
DISPENSING SPOUT
CARAFE CLEANING
Place a large container (1.5l) under the dispensing spout.
13
Press the "
" button to con rm. The machine starts dispensing the
solution through the milk dispensing spout.
The following display shows the cycle progress.
14
Warning:
Never drink the solution dispensed during this step.
CARAFE RINSING
REFILL
WATER TANK
CARAFE RINSING
FILL CARAFE
WITH FRESH WATER
When the machine stops dispensing, ll the tank with fresh water up to
15
the MAX level. Press the "
Remove the milk carafe and the container from the machine.
16
Rinse thoroughly the milk carafe and ll it with fresh drinking water up
17
" button to con rm.
to the MAX level. Insert the milk carafe into the machine.
Press the "
" button to con rm.
Page 85
CARAFE RINSING
PLACE MILK CARAFE
AND OPEN SPOUT
CARAFE RINSING
PLACE CONTAINER
UNDER THE CARAFE
DISPENSING SPOUT
ENGLISH
Empty the container and place it back under the co ee dispensing
18
spout. Press the "
Press “ ” to con rm.
19
" button to con rm.
83
83
CARAFE RINSING
The machine will start dispensing water from the milk dispensing
20
spout. The following display is shown.
At the end of the cycle, the machine is ready to brew products.
21
Disassemble and wash the milk carafe as described in the “Weekly
22
Cleaning of the Milk Carafe” chapter.
Page 86
84
ENGLISH
Monthly Lubrication of the Brew Group
Lubricate the brew group after approximately 500 cups of co ee or once a
month.
You can purchase the Saeco grease to lubricate the brew group separately.
For further details, please refer to the maintenance products page in this
user manual.
Caution:
Before lubricating the brew group, clean it with fresh water and dry it
as described in the “Weekly Cleaning of the Brew Group” chapter.
Apply the lubricant evenly on both side guides.
1
Lubricate also the piston, as shown in the gure.
2
Page 87
ENGLISH
Lubricate the internal guides positioned on both sides of the brew
3
group.
Insert the brew group into its seat until it locks into place (see the
4
“Weekly Cleaning of the Brew Group” chapter).
Insert the drip tray (internal) and the co ee grounds drawer and close
5
the service door.
85
85
PROFILE SAECO
Monthly Cleaning of the Brew Group with “Co ee Oil Remover”
Besides weekly cleaning, we recommend performing a cleaning cycle
with “Co ee Oil Remover” after approximately 500 cups of co ee or once
a month. This operation completes the maintenance process for the brew
group.
You can purchase the “Co ee Oil Remover” and the “Maintenance Kit” separately. Please refer to the maintenance products page for further details.
Caution:
The “Co ee Oil Remover” tablets are to be used for cleaning only and
do not have a descaling function. For the descaling procedure use the
Saeco descaling solution and follow the procedure described in the
“Descaling” chapter.
Press the “ ” button to access the machine main menu.
1
Page 88
86
ENGLISH
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
Press the “ ” button to select “MAINTENANCE”.
2
Press “ ” to con rm.
3
Press the " " button to select “BREW GROUP CLEANING’”.
4
Press “ ” to con rm.
5
BREW GROUP CLEANING
PERFORM BREW
GROUP CLEANING?
(~ 5 MINUTES)
BREW GROUP CLEANING
WATER TANK EMPTY
ADD WATER
BREW GROUP CLEANING
INSERT GROUP
CLEAN TAB
Press “ ” to con rm or “ ” to return to the previous menu.
6
Fill the water tank with fresh water up to the MAX level. Press the “ ”
7
button.
Put a “Co ee Oil Remover” tablet in the pre-ground co ee compart-
8
ment. Press the “
” button.
Page 89
BREW GROUP CLEANING
PLACE A CONTAINER
UNDER THE
DISPENSING SPOUT
BREW GROUP CLEANING
Place a container (1.5 l) under the co ee dispensing spout.
9
Press the “
” button to start the cleaning cycle.
Warning:
Never drink the solution dispensed during this step.
This icon is displayed. The display shows the cycle progress.
10
ENGLISH
87
87
When the machine stops dispensing, remove and empty the container.
11
Clean the brew group as described in the “Weekly Cleaning of the Brew
12
Group” chapter.
Page 90
88
ENGLISH
DESCALING
When the " " icon is displayed, you need to descale the machine.
The descaling cycle takes approx. 30 minutes.
DESCALE
Caution:
Not doing this will ultimately make your machine stop working properly. In this case, repair is NOT covered by warranty.
Warning:
Use the Saeco descaling solution only. Its formula has been
designed to ensure better machine performance. The use of other
products may damage the machine and leave residues in the water.
The Saeco descaling solution can be purchased separately. For further
details, please refer to the maintenance products page in this user manual.
Warning:
Never drink the descaling solution or any products dispensed
until the cycle has been carried out to the end. Never use vinegar as a
descaling solution.
Note:
Do not remove the brew group during the descaling process.
MENU
EDIT PROFILES
MAINTENANCE
SETTINGS
STATISTICS
PROFILE SAECO
To perform the descaling cycle, follow the steps below:
Press the “ ” button to access the machine main menu.
1
Press the “ ” button to select “MAINTENANCE”.
2
Press “ ” to con rm.
3
Page 91
MAINTENANCE
DESCALING
BREW GROUP CLEANING
CARAFE CLEANING
COFFEE EMPTYING
DESCALING
START DESCALING?
(~ 30 MINUTES)
DESCALING
POUR DESCALING SOLUTION
AND WATER INTO THE TANK UP
TO THE CALC-CLEAN LEVEL
ENGLISH
Press “ ” to con rm the “DESCALING” selection.
4
Note:
If the "
"button is pressed by mistake, press the " " button to quit.
Press the “ ” button to con rm.
5
Remove the water tank and the “INTENZA+” water lter (if installed)
6
and insert the small white lter supplied with the machine. Pour the
entire content of the Saeco descaling solution.
89
89
DESCALING
EMPTY INTERNAL
DRIP TRAY
Fill the water tank with fresh water up to the CALC CLEAN level.
7
Put the water tank back into the machine. Press the
Remove the internal and external drip tray and co ee grounds drawer.
8
Press the “
” button.
“ ”
button.
Page 92
90
ENGLISH
DESCALING
FILL HALF CARAFE
WITH WATER. INSERT
IN BREWING POSITION
DESCALING
PLACE A CONTAINER
UNDER THE
DISPENSING SPOUT
Fill half the carafe with water and insert it into the machine.
9
Slide the carafe dispenser to the right up to the “ ” icon.
Press the
Place a large container (1.5l) under both the milk carafe dispenser and
10
the co ee dispensing spout.
“ ” button.
Press the
“ ” button.
DESCALING
DESCALING
START
RINSE WATER TANK &
FILL WITH WATER
RINSING
The machine starts dispensing the descaling solution at regular inter-
11
vals. The display shows the cycle progress.
Note:
To empty the container during the process and to pause the descaling
cycle, press the “
The message indicates the end of the rst step. The water tank needs
12
” button. To resume the cycle, press the “ ” button.
to be rinsed. Fill the water tank with fresh water up to the MAX
level. Press the “
” button.
Page 93
RINSING
EMPTY INTERNAL
DRIP TRAY
RINSING
FILL HALF CARAFE
WITH WATER. INSERT
IN BREWING POSITION
ENGLISH
Note:
The circuit must be cleaned with a preset quantity of water.
If the water tank is not lled up to the MAX level, the machine may require
several re lls for rinsing.
Empty the drip tray (internal) and place it back. Then press the “ ”
13
button.
Empty the milk carafe and ll half of it with fresh water. Insert it back
14
into the machine with the dispensing spout open. Press the “
ton.
” but-
91
91
RINSING
PLACE A CONTAINER
UNDER THE
DISPENSING SPOUT
RINSING
Empty the container and place it back
15
penser and the co ee dispensing spout.
The rinse cycle starts. The bar shows the progress status of the process.
16
under both the milk carafe dis-
Press the “ ” button.
Note:
To empty the container during the process and to pause the rinse cycle,
press the “
” button. To resume the cycle, press the “ ” button.
Page 94
92
ENGLISH
Note:
The rinse cycle is performed in order to have the circuit cleaned with a preset amount of water to ensure proper machine performance. If the water
tank is not lled up to the MAX level, the machine might require more than
one cycle.
When the amount of water needed for the rinse cycle has been
17
completely dispensed, the machine automatically ends the descaling
process.
At the end of the descaling process, the machine performs an auto-
18
matic rinse cycle. Wait until it is over before removing and emptying
the container.
Disassemble and wash the milk carafe as described in the “Weekly
19
Cleaning of the Milk Carafe” chapter.
Empty the drip tray (internal) and place it back.
20
Remove the small white lter and place back the “INTENZA+” water
21
lter into the water tank if it was installed.
Note:
At the end of the descaling cycle, wash the brew group as described in the
“Weekly Cleaning of the Brew Group” chapter.
Page 95
ENGLISH
ACCIDENTAL INTERRUPTION OF THE DESCALING CYCLE
Once the descaling process has started, it must be completed; do not turn
o the machine mid-cycle.
If the descaling process is accidentally interrupted (power failure or accidental disconnection of the power cord), follow the steps below.
Check that the power button is set to "I".
93
93
DESCALING
POUR DESCALING SOLUTION
AND WATER INTO THE TANK UP
TO THE CALC-CLEAN LEVEL
RINSING
RINSE WATER TANK &
FILL WITH WATER
Press the "
" button to turn on the machine.
If the cycle was interrupted during the descaling phase, it will be resumed
from step 6 of the "Descaling" chapter. Press the “
” button to restart the
cycle.
If the cycle was interrupted during the rinse phase, it will be resumed from
step 12 of the "Descaling" chapter.
Press the “
” button to restart the cycle.
Page 96
94
ENGLISH
DISPLAY MESSAGES
Displayed message Meaning of the message
BEANS CONTAINER EMPTY
ADD COFFEE BEANS
Fill the co ee bean hopper.
INSERT BREW GROUP
INSERT COFFEE
GROUNDS DRAWER
EMPTY COFFEE
GROUNDS DRAWER
CLOSE
FRONT DOOR
WATER TANK EMPTY
ADD WATER
The brew group must be inserted into the machine.
Insert the co ee grounds drawer and the internal drip tray.
Empty the co ee grounds drawer.
Note:
The co ee grounds drawer must be emptied only when the machine
requires it and with the machine on. If the drawer is emptied with the
machine turned o , the machine will not record the emptying operation.
Close the service door.
Remove the water tank and ll it. You can ll the water tank also
through the dedicated hole on the lid.
EMPTY INTERNAL
DRIP TRAY
INSERT
BEAN CONTAINER
Open the service door and empty the internal drip tray.
Note:
If this operation is performed when the machine is on, it will record the
co ee grounds drawer emptying and will reset the counter; therefore,
you need to empty the co ee grounds as well.
Insert the co ee bean hopper and/or beans lid.
Page 97
Displayed message Meaning of the message
CLOSE BEAN
CONTAINER LID
Insert the co ee bean hopper lid and/or beans lid.
ENGLISH
95
95
HOT WATER
INSERT
WATER SPOUT
PLACE MILK CARAFE
AND OPEN SPOUT
DESCALE
CHANGE FILTER
WATER CIRCUIT
PRIMING
Insert the water dispensing spout to start dispensing. Press "ESC" to exit.
Before dispensing, insert the milk carafe with the dispensing spout
open.
You need to descale the machine. Follow the steps described in the “Descaling” chapter of this manual.
Please note that not descaling your machine will ultimately make it stop
working properly. In this case repair is NOT covered under your warranty.
The machine needs the “INTENZA+” water lter to be replaced.
The machine is priming the water circuit. Wait for this operation to be
over.
The red light ashes. Press any button to exit the stand-by mode.
RESTART TO SOLVE
Take note of the code (E xx) shown on the display at the bottom.
Turn o the machine. Turn it back on after 30 seconds. Repeat the
procedure 2 or 3 times.
If the machine does not start, contact the Philips SAECO hotline in your
country and quote the code shown on the display. Contact details can
be found in the warranty booklet packed separately or at www.philips.
com/support.
Page 98
96
ENGLISH
TROUBLESHOOTING
This chapter summarizes the most common problems you could encounter with your machine.
If you are unable to solve the problem with the information below, visit
www.saeco.com/support for a list of frequently asked questions or contact the Philips Saeco hotline in your country.
Contact details can be found in the warranty booklet packed separately or
at www.saeco.com/support.
Machine actions Causes Solutions
The machine does not turn
on.
The machine is not connected to the
electric network.
The power button is on position "0". Check that the power button is set to "I".
Connect the machine to the electric
network.
The drip tray gets lled although no water is drained.
Co ee is not hot enough. The cups/mugs are cold. Preheat the cups/mugs with hot water or
No hot water is dispensed. The steam/hot water dispensing
The machine does not ll
the cup/mug.
Co ee does not have
enough crema
(see note).
Milk does not froth.
Water is sometimes drained automatically by the machine into the
drip tray to manage the rinsing of
the circuits and ensure optimum
machine performance.
The beverage temperature in the
programming menu is set on Low.
You added cold milk to the co ee. Cold milk lowers the temperature of the
spout is clogged or dirty.
The machine has not been programmed.
The blend is unsuitable, co ee is not
freshly roasted or the grind is too
coarse.
The co ee beans or the pre-ground
co ee are too old.
The milk dispensing spout has not
been pulled out.
The carafe has not been correctly
reassembled or with all its components.
This is a normal behaviour of the machine.
use the hot water dispensing spout.
Make sure that the temperature in the
programming menu is set on Normal or
High.
nal product. Preheat milk before adding
it to the beverage.
Clean the hot water dispensing spout.
Inspect the steam spout to check that the
dispensing spout is not clogged. Make
a hole in the limescale using a pin or a
needle.
Access the beverage programming menu
and adjust the co ee length setting according to your personal taste for each
type of beverage.
Change co ee blend or adjust grinding as
explained in the “Adjusting the Ceramic
Co ee Grinder” chapter.
Make sure that you use fresh co ee beans
or pre-ground co ee.
Check that the milk dispensing spout has been
pulled out correctly up to the “ ” icon.
Make sure the tube is correctly inserted.
All its components have to be correctly
reassembled, as described in the “Weekly
cleaning of the Milk Carafe” section.
Page 99
Machine actions Causes Solutions
The machine takes a long
time to warm up or the
amount of water dispensed
from the wand is too little.
The brew group cannot be
removed.
There is too much ground
co ee under or over the
brew group.
The machine produces too
humid or too dry co ee
grounds.
The machine grinds co ee
beans but no co ee comes
out (see note).
Co ee is too weak
(see note).
The machine circuit is clogged by
limescale.
The brew group is out of place. Turn on the machine. Close the service
The co ee grounds drawer is
inserted.
The co ee used may not be suitable
for automatic machines.
The machine is adjusting the co ee
grinder for a new kind of co ee
beans or pre-ground co ee.
Adjust the co ee grinder. Adjusting the ceramic co ee grinder af-
There is no water. Fill the water tank and prime the circuit
The brew group is dirty. Clean the brew group (see the "Weekly
This might occur when the machine
is automatically adjusting the dose.
The dispensing spout is dirty. Clean the dispensing spout.
This might occur when the machine
is automatically adjusting the dose.
The ground co ee is too coarse. Change co ee blend or adjust grinding as
The co ee bean hopper selector
switch has been shifted.
Descale the machine.
door. The brew group automatically
returns to the initial position.
Remove the co ee grounds drawer
before removing the brew group.
It may be necessary to change the type
of co ee or the co ee grinder settings
(see the “Adjusting the Ceramic Co ee
Grinder” chapter).
The machine automatically adjusts itself
after brewing several cups of co ee to
optimise the extraction in relation to the
compactness of the ground co ee.
It may be necessary to brew 2 or 3
products to adjust the co ee grinder
completely.
This is not a malfunction of the machine.
fects the quality of residues.
If the residues are too humid, set a coarser
grind.
If the residues are too dry, set a ner
grind.
Refer to the “Adjusting the Ceramic Co ee
Grinder” chapter.
(see the "Manual Rinse Cycle" chapter).
Cleaning of the Brew Group" chapter).
Brew some cups of co ee as described in
the “Saeco Adapting System” chapter.
Brew some cups of co ee as described in
the “Saeco Adapting System” chapter.
explained in the “Adjusting the Ceramic
Co ee Grinder” chapter.
Move the selector switch to the “
position.
ENGLISH
97
97
”
Page 100
98
ENGLISH
Machine actions Causes Solutions
Co ee is brewed slowly
(see note).
Co ee leaks out of the
dispensing spout.
The dispenser cannot
be installed on the milk
carafe.
The ground co ee is too ne. Change co ee blend or adjust grinding as
Circuits clogged. Perform a descaling cycle.
The brew group is dirty. Clean the brew group (see the “Weekly
The dispensing spout is clogged or
not correctly inserted.
explained in the “Adjusting the Ceramic
Co ee Grinder” chapter.
Cleaning of the Brew Group” chapter).
Clean the dispensing spout and its holes
and insert it back correctly.
The pin is in the wrong position. Manually push the pin to the correct
position and insert the carafe dispenser.
Note:
These problems can be considered normal if the co ee blend has been
changed or if the machine has just been installed. In this case, wait until
the machine performs a self-adjusting operation as described in the “Saeco
Adapting System” chapter.
Loading...
