Philips HD8862/01 user manual
USER MANUAL
Type HD8762, HD8780, HD8862, HD8865
Read carefully before using the machine.
02
English
EN
02
Register your product and get support at
www.saeco.com/welcome
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons do not immerse
cord, plugs, or appliance in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Save these instructions.
SAVE THESE INSTRUCTIONS
CAUTION
This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.
1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2. Never use warm or hot water to fill the water tank. Use cold water only.
3. Keep your hands and the cord away from hot parts of the appliance during
operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6. Do not use caramelized or flavored coffee beans.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available
and may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children or tripped
over.
2
ENGLISH
Congratulations on your purchase of a Saeco Minuto Automatic Milk Frother fully automatic co ee machine!
To fully bene t from the support that Saeco o ers, please
register your product at www.saeco.com/welcome.
The machine is made for preparing espresso co ee using
whole co ee beans and for dispensing steam and hot water.
In this user manual you will nd all the information you need
to install, use, clean and descale your machine.
ENGLISH
CONTENTS
IMPORTANT..................................................................................................... 4
Safety Instructions ....................................................................................................................................4
Warnings ...................................................................................................................................................4
Cautions ....................................................................................................................................................6
Electromagnetic Fields .............................................................................................................................7
Disposal ....................................................................................................................................................7
INSTALLATION ................................................................................................. 8
Product Overview ......................................................................................................................................8
General Description ...................................................................................................................................9
PREPARING FOR USE .......................................................................................10
Machine Packaging ................................................................................................................................. 10
Machine Installation ...............................................................................................................................10
USING THE MACHINE FOR THE FIRST TIME ........................................................13
Circuit Priming ........................................................................................................................................13
Automatic Rinse/Self-Cleaning Cycle.......................................................................................................14
Manual Rinse Cycle..................................................................................................................................15
Measuring and Programming Water Hardness ........................................................................................ 17
“INTENZA+” Water Filter Installation ......................................................................................................19
Replacing the “INTENZA+” Water Filter ...................................................................................................21
ADJUSTMENTS ................................................................................................22
Saeco Adapting System ...........................................................................................................................22
Adjusting the Ceramic Co ee Grinder ......................................................................................................22
Adjusting the Aroma (Co ee Strength) ...................................................................................................23
Adjusting the Co ee Dispensing Spout ................................................................................................... 24
Adjusting the Co ee Length ...................................................................................................................25
BREWING ESPRESSO AND COFFEE ....................................................................26
Brewing Espresso and Co ee Using Co ee Beans ....................................................................................26
Brewing Espresso and Co ee Using Pre-Ground Co ee ...........................................................................27
FROTHING MILK/BREWING CAPPUCCINO ..........................................................28
Frothing milk ..........................................................................................................................................28
Brewing a Cappuccino .............................................................................................................................31
HOT WATER DISPENSING .................................................................................31
CLEANING AND MAINTENANCE ........................................................................33
Daily Cleaning of the Machine .................................................................................................................33
Daily Cleaning of the Water Tank ............................................................................................................. 34
Daily Cleaning of the Automatic Milk Frother ..........................................................................................35
Weekly Cleaning of the Machine ............................................................................................................. 36
Weekly Cleaning of the Brew Group ........................................................................................................36
Monthly Cleaning of the Automatic Milk Frother.....................................................................................40
Monthly Lubrication of the Brew Group ..................................................................................................46
Monthly Cleaning of the Brew Group with “Co ee Oil Remover” .............................................................47
Monthly Cleaning of the Co ee Bean Hopper ..........................................................................................49
DESCALING .....................................................................................................50
ACCIDENTAL INTERRUPTION OF THE DESCALING CYCLE .....................................56
PROGRAMMING ..............................................................................................57
The following settings can be adjusted ................................................................................................... 57
How to Program the Machine .................................................................................................................58
MEANING OF THE DISPLAY ICONS .....................................................................60
TROUBLESHOOTING ........................................................................................64
ENERGY SAVING ..............................................................................................67
Stand-by .................................................................................................................................................67
TECHNICAL SPECIFICATIONS ............................................................................68
WARRANTY AND SERVICE ................................................................................68
Warranty .................................................................................................................................................68
Service .................................................................................................................................................... 68
ORDERING MAINTENANCE PRODUCTS ..............................................................69
3
4
ENGLISH
IMPORTANT
Safety Instructions
This machine is equipped with safety devices. Nevertheless,
read and follow the safety instructions carefully and only use
the machine properly as described in these instructions to
avoid accidental injury or damage due to improper use of the
machine. Keep this user manual for future reference.
The term WARNING and this icon warn against possible
severe injuries, danger to life and/or damage to the machine.
The term CAUTION and this icon warn against slight
injuries and/or damage to the machine.
Warnings
• Connect the machine to a wall socket with a voltage matching the technical speci cations of the machine.
• Connect the machine to an earthed wall socket.
• Do not let the power cord hang over the edge of a table or
counter, or touch hot surfaces.
• Never immerse the machine, the mains plug or power cord
in water: Danger of electrical shock!
• Do not pour liquids on the power cord connector.
• Never direct the hot water jet towards body parts: Danger
of burning!
• Do not touch hot surfaces. Use handles and knobs.
• After switching o the machine by pressing the power button on the back of the machine, remove the mains plug
from the wall socket:
- if a malfunction occurs;
ENGLISH
5
5
- if the machine will not be used for a long time;
- before cleaning the machine.
• Pull on the mains plug, not on the power cord.
• Do not touch the mains plug with wet hands.
• Do not use the machine if the mains plug, the power cord or
the machine itself is damaged.
• Do not make any modi cations to the machine or its power
cord. Only have repairs carried out by a service centre authorised by Philips to avoid any hazard.
• The machine should not be used by children younger than
8 years old.
• The machine can be used by children of 8 years and upwards if
they have previously been instructed on the correct use of the
machine and made aware of the associated dangers or if they
are supervised by an adult.
• Cleaning and maintenance should not be carried out by
children unless they are more than 8 years old and supervised by an adult.
• Keep the machine and its power cord out of reach of children under 8 years old.
• The machine may be used by persons with reduced physical,
sensory or mental capabilities or lacking su cient experience and/or skills if they have previously been instructed
on the correct use of the machine and made aware of the
associated dangers or if they are supervised by an adult.
• Children should be supervised to ensure that they do not
play with the machine.
• Never insert ngers or other objects into the co ee grinder.
6
ENGLISH
Cautions
• The machine is for household use only. It is not intended
for use in environments such as canteens, sta kitchens of
shops, o ces, factories or other work environments.
• Always put the machine on a at and stable surface.
• Do not place the machine on hot surfaces, directly next to a
hot oven, heater units or similar sources of heat.
• Only put roasted co ee beans into the co ee bean hopper.
If ground co ee, instant co ee, raw co ee or any other
substance is put in the co ee bean hopper, it may damage
the machine.
• Let the machine cool down before inserting or removing
any parts. The heating surfaces may retain residual heat
after use.
• Never use warm or hot water to ll the water tank. Use only
cold non-sparkling drinking water.
• Never clean with scrubbing powders or harsh cleaners.
Simply use a soft cloth dampened with water.
• Descale your machine regularly. Not doing this will make
your appliance stop working properly. In this case repair is
not covered under your warranty!
• Do not keep the machine at temperature below 0 °C. Residue water in the heating system may freeze and cause
damage.
• Do not leave water in the water tank if the machine is not
used over a long period of time. The water can get contaminated. Use fresh water every time you use the machine.
ENGLISH
7
7
Electromagnetic Fields
This appliance complies with all the applicable standards and
regulations relating to the exposure to electromagnetic elds.
Disposal
This symbol on a product indicates that the product is covered
by EU Directive 2012/19/EU. Please inform yourself about the
local separate collection system for electrical and electronic
products. Follow local regulations and do not dispose of
the product as household waste. Appropriate disposal of
old products helps prevent negative consequences for the
environment and human health.
8
INSTALLATION
Product Overview
123
21
14
15
10
34
31
5
6
7
8
9
4
11 12 13
32
18
16
17
19
20
24 27
25 28
26 29
30
23
22
ENGLISH
General Description
1. Grinder adjustment knob
2. Co ee bean hopper
3. Pre-ground co ee compartment
4. Water tank + Lid
5. Co ee bean hopper lid
6. Control panel
7. Co ee dispensing spout
8. Full drip tray indicator
9. Cup holder grill
10. Drip tray
11. Co ee grounds drawer
12. Brew group
13. Service door
14. Grease for brew group
15. Power cord
16. Automatic Milk Frother
17. Suction tube for Automatic Milk Frother
18. Co ee grinder adjustment key + Pre-ground co ee measuring scoop
19. Power cord socket
20. Power button
21. Water hardness test strip
22. Cleaning brush
23. ON/OFF button
24. Espresso brew button
25. Co ee brew button
26. "Aroma" - Pre-ground co ee button
27. Steam button
28. Hot water button
29. Menu button
30. Descaling solution - to be purchased separately
31. Rubber tting
32. Co ee residues drawer
34. Chrome cover
(optional)
(optional)
9
9
10
ENGLISH
PREPARING FOR USE
Machine Packaging
The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.
Machine Installation
Remove the machine from the packaging.
1
For best use, it is recommended to:
2
• Choose a safe, level surface where there will be no danger of overturning the machine or being injured.
• Choose a location that is su ciently well-lit, clean and near an easily reachable socket.
• Allow for a minimum distance from the sides of the machine as
shown in the gure.
Open the water tank lid.
3
Remove the water tank by using the handle.
4
ENGLISH
Rinse the water tank with fresh water.
5
Fill the water tank with fresh water up to the MAX level and reinsert it
6
into the machine. Make sure it is fully inserted.
Caution:
Never ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.
Lift the co ee bean hopper lid.
7
Slowly pour the co ee beans into the co ee bean hopper.
8
11
11
Note:
Do not pour too many co ee beans into the co ee bean hopper as this will
reduce the grinding performance of the machine.
Caution:
Only co ee beans must be put into the co ee bean hopper. If ground
co ee, instant co ee, caramelized co ee, raw co ee beans or any
other substance is put in the co ee bean hopper, it may damage the
machine.
Put the lid back on the co ee bean hopper.
9
Insert the plug into the socket located on the back of the machine.
10
1
Insert the plug at the other end of the power cord into a wall socket
11
with suitable power voltage.
2
12
ENGLISH
Switch the power button to “I”.
12
13
By keeping the button pressed for more than 8 seconds, the machine
enters the demo mode. To exit the demo, disconnect the power cord and
turn the machine back on.
" button ashes.
The "
To turn on the machine, simply press the " " button.
Note:
The control panel indicates that the circuit must be primed.
14
Yellow
ENGLISH
USING THE MACHINE FOR THE FIRST TIME
When using the machine for the rst time, the following activities need to
happen:
1) You need to prime the circuit;
2) The machine will perform an automatic rinse/ self-cleaning cycle;
3) you need to perform a manual rinse cycle.
Circuit Priming
During this process, fresh water ows through the internal circuit of the
machine and the machine warms up. This takes a few minutes.
Place a container under the steam wand.
1
13
13
Yellow
Yellow
Yellow
Press the “ ” button to start the cycle. The machine starts the auto-
2
matic priming of the circuit by dispensing some water through the
steam wand.
The bar under the icon shows the operation progress. When the pro-
3
cess has been completed, the machine stops dispensing automatically.
The control panel now shows the machine warm-up icon.
4
14
ENGLISH
Automatic Rinse/Self-Cleaning Cycle
When warm-up has been completed, the machine automatically performs
a rinse/self-cleaning cycle of the internal circuits with fresh water. This
takes less than a minute.
Place a container under the co ee dispensing spout to catch the small
5
amount of water which will be dispensed.
The machine shows this display. Wait for the cycle to nish automati-
6
cally.
YellowGreen
Note:
You can stop dispensing by pressing the “
” button.
When the operations described above have been completed, the ma-
7
chine shows this display. You can now perform the manual rinse cycle.
Manual Rinse Cycle
During this process the co ee brewing cycle is activated and fresh water
ows through the water circuit. This takes a few minutes.
Place a container under the co ee dispensing spout.
1
Check that the machine shows this display.
2
Green
Select the pre-ground co ee brewing function by pressing the “ ”
3
button. The machine shows this display.
Green
ENGLISH
15
15
Note:
Do not add any pre-ground co ee into the compartment.
Press the “ ” button. The machine starts dispensing water.
4
When dispensing has nished, empty the container. Repeat the opera-
5
tions from step 1 to step 4 twice, then continue with step 6.
Place a container under the steam wand.
6
16
ENGLISH
Press the “ ” button to start dispensing hot water.
7
Dispense water until the no water icon appears.
8
Note:
The manual rinse cycle can be stopped by pressing the “
” button.
At the end of this operation, ll the water tank again up to the MAX
9
level. Now the machine is ready to brew co ee.
The display on the left will be shown.
Green Red
Note:
The automatic rinse/self-cleaning cycle starts when the machine has been
in stand-by mode, or turned o , for more than 15 minutes.
When you have not used the machine for 2 or more weeks, you will also
need to perform a manual rinse cycle.
At the end of the cycle, you can brew a co ee.
ENGLISH
17
17
Measuring and Programming Water Hardness
Water hardness measuring is very important in order to de ne the descaling frequency and to install the “INTENZA+” water lter (for more details on
the water lter, see next chapter).
To measure the water hardness follow the steps below:
Immerse the water hardness test strip (supplied with the machine) in
1
water for 1 second.
Note:
The test strip can only be used for one single measurement.
Wait for one minute.
2
Intenza Aroma System
Check how many squares have changed colour to red and then refer to
3
C
B
A
23 4
Machine Water Hardness Setting
1
the table.
Note:
The numbers on the water hardness test strip correspond to the water
hardness adjustment settings.
More precisely:
1 = 1 (very soft water)
2 = 2 (soft water)
3 = 3 (hard water)
4 = 4 (very hard water)
The letters correspond to the references that are located at the base of the
“INTENZA+” water lter (see next chapter).
18
ENGLISH
Press the “ ” button and scroll through the options by pressing the “ ”
4
button until this icon is displayed.
Yellow
Yellow
Green
Note:
The machine is supplied with a standard water hardness setting, suitable
for most types of water.
Press the ““ ” button to increase the value and the “ ” button to
5
decrease the value.
Press the “ ” button to con rm the setting.
6
Press the ““ ” button to exit the programming MENU. The machine
7
shows this display and is ready to brew.
ENGLISH
19
19
“INTENZA+” Water Filter Installation
We recommend you to install the “INTENZA+” water lter as this prevents
limescale build-up in your machine and preserves a more intense aroma of
your co ee.
The “INTENZA+” water lter can be purchased separately. For further details, please refer to the maintenance products page in this user manual.
Water is a crucial part of every co ee, so it is very important to always have
it professionally ltered. Using the “INTENZA+” water lter will prevent
mineral deposits from building up and improve your water quality.
Remove the small white lter from the water tank and store it in a dry
1
place.
Remove the “INTENZA+” water lter from its packaging, immerse it ver-
2
tically (with the opening positioned upwards) in cold water and gently
press the sides so as to let the air bubbles out.
Set the “INTENZA+” water lter according to the measurements per-
3
formed (see previous chapter) and indicated on the base of the lter:
A = soft water – equals 1 or 2 on the test strip
B = hard water (standard) – equals 3 on the test strip
C = very hard water – equals 4 on the test strip
20
ENGLISH
Yellow
YellowGreen
Put the “INTENZA+” water lter into the empty water tank. Press it
4
down until it cannot move any further.
Fill the water tank with fresh water and put it into the machine.
5
Dispense all the water in the water tank by using the hot water func-
6
tion (see the “Dispensing Hot Water” chapter).
Fill the water tank again.
7
Press the “ ” button and scroll the options by pressing the “ ” button
8
until this display is shown.
Press the “ ” button to select “ON” and press the “ ” button to con-
9
rm.
To exit, press the “ ” button. The machine shows this display and is
10
ready to brew.
The machine is now programmed to inform the user of the need to replace
the "INTENZA+" water lter.
Replacing the “INTENZA+” Water Filter
When the “INTENZA+” water lter needs to be replaced with a new one,
this icon is displayed.
Replace the “INTENZA+” water lter as described in the previous chap-
1
ter.
Yellow
Press the “ ” button and scroll through the options by pressing the “ ”
2
button until this icon is displayed.
YellowYellowGreen
Select the “RESET” option. Press the " " button to con rm.
3
ENGLISH
21
21
To exit, press the “ ” button. The machine shows this display and is
4
ready to brew.
The machine is now programmed to manage a new “INTENZA+” water
lter.
Note:
If the “INTENZA+” water lter is already installed and you want to remove,
Yellow
but not replace it, select the “OFF” option instead.
If there is no “INTENZA+” water lter installed, insert the small white lter
previously removed into the water tank.
Loading...
