Philips HD7832 User Manual

HD7832, HD7830 Coffee Machine

ENGLISH2

IMPORTANT

SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

Read all instructions before using the appliance.

1. Do not touch hot surfaces. Use handles or knobs. Care must be taken to prevent burns which can occur from touching hot parts or spilling hot liquids.

2. To protect against fire, electrical shock and injury to persons, do not immerse cord, plug, or appliance in water or other liquid.

3. Close supervision is necessary when any appliance is used by or near children.

4. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning appliance.

5. Do not operate this appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Return the Coffee Machine to the Philips Norelco Service Location for examination, repair or adjustment.

6. Use this appliance only for its intended purpose as described in this manual. Do not use accessor y attachments not recommended by Philips Electronics North America Corporation as they may result in fire, electric shock or injury to persons.

7. Do not use outdoors.

8. Do not let cord hang over edge of table or counter or touch hot surfaces. Operate on a flat, stable surface away from edge of counter to prevent accidental tipping.

9. Do not place Coffee Machine on or near a hot gas or electric burner, or in a microwave or heated oven.

10. This appliance is intended for household use ONLY; it is not for commercial or industrial use.

11. Any service to the Coffee Machine should be performed by the Philips Norelco Service Location.

12. To disconnect Coffee Machine, press power button then remove plug from electrical outlet. Remove plug by gripping plug body and pulling it from the outlet. Never yank or twist cord to unplug.

13. Do not use Coffee Machine if lid has a cracked, loose, weakened or damaged lever.

14. This appliance does not work at temperatures below 50ºF/10ºC.

15. Do not use this appliance at altitudes higher than 6800 ft. / 2200 m above sea level.

16. Flush the Coffee Machine with fresh water before using it for the first time (See ‘Preparing the machine for use’). This will cause the boiler to fill with water; which is essential for the machine to work properly.

3 to ‘OFF’,

ENGLISH 3

17. To prevent scalds and/or property damage, always make sure Coffee Machine lid is securely in place and properly locked before you start using the machine and during brew cycle. Do not force when opening or closing lid.

18. Do not open lid until Coffee Machine has finished brew cycle. Hot steam or hot water trapped under lid cover could burn your fingers.

19. Warning: To reduce the risk of fire or electric shock, do not remove the bottom cover. No user serviceable parts are inside. Return the Coffee Machine to the Philips Norelco Service Location for examination, repair or adjustment.

SAVE THESE

INSTRUCTIONS

SPECIAL INSTRUCTIONS

This Coffee Machine has a short cord to reduce the hazards of becoming entangled in or tripping over a longer cord. An extension cord may be used if the rating is equal to or greater than the rating of the Coffee Machine. Use an extension cord rated 13 amperes or greater. Care must be taken to arrange extension cord so that it does not hang over the edge of counter top or table top, where it can be pulled on by children or tripped over unintentionally. Operating the Coffee Machine and another appliance at the same time from the same electrical circuit could cause an electrical overload, which would blow the fuse or trip the circuit breaker.

SPECIAL POLARIZED PLUG INSTRUCTIONS

This Philips Coffee Machine has a polarized plug (one blade is wider than the other) as an added safety feature. To reduce the risk of electric shock:

- Plug will fit into polarized outlet only one way.

- If plug does not properly fit into outlet at first, reverse it.

- If plug still does not fit, contact a qualified electrician.

DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE IN ANY WAY.

ENGLISH4

WARNING:

- To avoid risk of personal injury or damage to property as a result

of overflow, be sure that the cup or mug is centered under the coffee outflow unit during the brew cycle.

- Brewed coffee and coffee pods are very hot. Handle with care to

avoid scalding.

- If coffee coffee spout overflows or fails to drain into cup/mug

during brewing cycle, do not open lid or handle coffee spout or coffee pod holder(s). Unplug Coffee Machine and wait for contents to cool before handling.

- Do not remove any part of Coffee Machine or cup/mug during

the brew cycle as scalding could occur.

- Use only fresh, cool water in this appliance. Do not put any other

liquids in this appliance except as instructed in the ‘Descaling’ section. Do not refill the water reservoir with hot water or coffee.

- DO NOT attempt to move an appliance containing hot liquids or

during the brewing process. Allow appliance to cool completely before moving.

- Keep appliance at least 4 inches away from walls or other objects

while operating. Do not place any object on top of coffee machine while operating.

PLEASE READ AND SAVE THIS

INSTRUCTION BOOKLET

TABLE OF CONTENTS

General description

Introduction 7

Preparing the machine for use 7

Brewing coffee 9

Cleaning 13

Descaling 16

Storage 17

Assistance 17

Troubleshooting 18

Warranty 23

RQO

General description (Fig. 1)

A Display

1 Heat-up indication 2 Coffee volume indication 3 Water rell indication 4 Descaling indication

B Volume select button C Outow valve D Water reservoir E Grip area F Sealing ring G Water distribution disc H 1-cup pod holder q I 2-cup pod holder qq J Cover of coffee spout K Coffee spout L Coffee collector M Cup tray N Drip tray O 1-cup button q P Water level light rings Q On/off button with indicator light R 2-cup button qq/w

Introduction

With Douwe Egberts SENSEO\ coffee pods, you can enjoy a perfect cup of coffee at any time of the day. Every cup is freshly brewed to give you that smooth and full taste. Using more than 250 years of coffee expertise, Douwe Egber ts has roasted and ground specially selected coffee beans that, when prepared using a special brewing method co-developed with Philips, ensure a full, smooth taste and delicious foam layer. This joint creation, known as the SENSEO\ coffee pod system, consists of the Philips SENSEO\ coffee machine and specially developed Douwe Egberts SENSEO\ coffee pods. Only when used together will you be rewarded with a sensational cup of SENSEO\ coffee with the delicious SENSEO\ foam layer. To ensure a smooth and full coffee taste, you should keep the following things in mind:

Fresh water

Use fresh water every day. If you have not used the coffee machine for

three days, you have to ush it with fresh water before you use it again

(see section ‘Flushing’ in chapter ‘Cleaning’).

Fresh coffee pods

Use the SENSEO\ coffee pods that have been specially developed by Douwe Egberts for your SENSEO\ coffee machine for a full, round taste. The Douwe Egberts SENSEO\ coffee pods will stay fresh longer if you store them in an airtight storage container.

A clean machine

Clean and descale your Philips SENSEO\ coffee machine regularly (see chapters ‘Cleaning’ and ‘Descaling’). Remove used coffee pods after brewing. If a used pod has been left in the coffee machine and you have not used

the machine for some time, ush the machine before you use it again (see

section ‘Flushing’ in chapter ‘Cleaning’).

Preparing the machine for use

USE THIS SENSEO\ COFFEE MACHINE FOR ITS INTENDED HOUSEHOLD USE AS DESCRIBED IN THIS MANUAL. YOU CANNOT BREW COFFEE IF YOU HAVE NOT FLUSHED THE SENSEO\ COFFEE MACHINE FIRST! Note that the display will not

work until you have ushed the machine.

The ushing cycle causes the boiler to be lled with water. After this the

coffee machine is ready for use. Flush the machine in the following way:

1 Remove the water reservoir.

2 Fill the water reservoir with cold water up to the MAX indication

and put it back onto the machine.

3 Release the lid by moving the lever upwards.

4 Open the lid.

5 Put the 1-cup pod holder q or the 2-cup pod holder qq in the

machine without pod(s).

6 Close the lid and lock the lever.

Note: Make sure the lever is properly locked by pushing it down until it snaps home with a click.

Note: Never ush the machine with the lid open. The lid must be properly

locked.

7 Put the plug into a grounded 120V AC electrical outlet.
