Page 1

www.philips.com/welcome

HD4747, HD4745

EN User manual 3

MS-MY Manual pengguna 19

TH คู่มือผู้ใช้ 35

ZH-TW Ԛʹ˫ 51

ZH-CN Ⴌ߀൱Ҭ 67

Page 2

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

• Never immerse the main body of the rice cooker in water, nor rinse it under the tap.

Warning

• Check if the voltage indicated on the appliance corresponds to the local power voltage before you connect the appliance.

• Only connect the appliance to an earthed power outlet. Always make sure that the plug is inserted  rmly into the power outlet.

• Do not use the appliance if the plug, the power cord, the inner pot, the sealing ring, or the main body is damaged.

• Make sure that the damaged power cord is replaced by Philips, a service center authorized by Philips or similarly quali ed persons in order to avoid a hazard.

• This appliance is not intended for use by persons (including children) with reduced physical,sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to make sure that they do not play with the appliance.

• Keep the power cord out of the reach of children. Do not let the power cord hang over the edge of the table or worktop on which the appliance stands.

• Make sure the heating element, the temperature sensor, and the outside of the inner pot are clean and dry before you put the plug in the power outlet.

• Do not plug in the appliance or press any of the buttons on the control panel with wet hands.

• Never connect this appliance to an external timer switch in order to avoid a hazardous situation.

Caution

• Never use any accessories or parts from other manufacturers or that Philips does not speci cally recommend. If you use such accessories or parts, your guarantee becomes invalid.

• Do not expose the appliance to high temperatures, nor place it on a working or still hot stove or cooker.

• Do not expose the appliance to direct sunlight.

• Place the appliance on a stable, horizontal, and level surface.

• Always put the inner pot in the appliance before you put the plug in the power outlet and switch it on.

• Do not place the inner pot directly over an open  re to cook rice.

• Do not use the inner pot if it is deformed.

• The accessible surfaces may become hot when the appliance is operating. Only touch the control panel and lid open button.

• Beware of hot steam coming out of the steam vent during cooking or out of the rice cooker when you open the lid. Keep hands and face away from the rice cooker to avoid the steam.

• The inner pot, steam basket, and resealable cups, during and after cooking process, may be hot and heavy.

Page 3

• Do not lift and move the rice cooker while it is operating.

• Do not exceed the maximum water level indicated in the inner pot to prevent over ow.

• Do not place the cooking utensils inside the pot while cooking, keeping warm or reheating rice.

• Only use the cooking utensils provided. Avoid using sharp utensils.

• Do not use the cooking utensils provided by the rice cooker on open  ame.

• To avoid scratches, it is not recommended to cook ingredients with crustaceans and shell sh. Remove the hard shells before cooking.

• Do not insert metallic objects or alien substances into the steam vent.

• Do not place a magnetic substance on the lid. Do not use the appliance near a magnetic substance.

• Always let the appliance cool down before you clean or move it.

• Always clean the appliance after use. Do not clean the appliance in the dishwasher.

• Always unplug the appliance if not used for a longer period.

• This appliance is intended to be used in household and similar applications such as:

» Staff kitchen areas in shops, of ces, and other working environments;

» Farm houses;

» By clients in hotels, motels and other residential type environments;

» Bed and breakfast type environments.

• If the appliance is used improperly or for professional or semi-professional purposes or if it is not used according to the instructions in this user manual, the guarantee becomes invalid and Philips refuses liability for any damage caused.

Electromagnetic  elds (EMF)

This appliance complies with all standards regarding electromagnetic  elds (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scienti c evidence available today.

Power failure backup function

This appliance has a backup function that remembers the status before a power failure, provided the power supply is resumed within two hours. If the power failure occurs during a cooking process, the countdown of the cooking time continues where it left off when the power supply resumes.

If the power failure lasts longer than two hours and the failure occurs during a cooking process, it will shown “E5” in the display, the appliance automatically resets to standby mode when the power supply resumes. Open the rice cooker, remove its contents, and start all over again.

If you have set the timer and the preset cooking process has not yet started when a power failure occurs, the process starts when the power supply resumes.

Environment

Do not throw away the appliance with the normal household waste at the end of its life, but hand it in at an of cial collection point for recycling. By doing this, you help to preserve the environment.

Guarantee and service

If you need service or information or if you have a problem, visit the Philips website at www.philips.com or contact the Philips Customer Care Center in your country (you  nd its phone number in the worldwide guarantee lea et). If there is no Consumer Care Center in your country, go to your local Philips dealer.

Page 4

Product Overview

Detachable steam vent cap

Outer lid

Detachable

inner lid

Sealing ring

Cooker handle

Display screen

Control knob

Main body

Heating

element

Inner pot

Water level indications

Lid release button

Mounting brackets (left and right)

Accessories

Measuring cup

Rice scoop

Soup ladle

Mains plug

Steam basket

Mains cord holder

Scoop holder

Page 5

Control knob

Turn the control knob to select

menus or adjust cooking time.

Turn the control knob and hold

to fast forward or backward.

make soup

steam food

stew food

make congee

This means indication light is on

This means number or indication light blinks

cook rice

cook rice with shorter time

cook rice for sushi

make cake

Page 6

For the first time use

1 2 3

Take out all the accessories from inner pot.

Wipe the cooker with soft cloth.

Clean the inner pot and inner lid with STEAM menu.

• Fill half pot of water in the inner pot. Close the outer lid and connect the mains plug to power supply.

• Turn the control knob to STEAM, and then press OK.

• Cooking time blinks. Press OK to confirm.

• The cooker starts steaming.

• After the cooker beeps, press CANCEL button.

• Pour the water out of the pot after it cools.

Wash all the accessories with dish washing liquid and soft sponge. Then use a soft cloth to dry inside and outside of

the pot and the accessories.

Attach the scoop holder and mains cord holder to the mounting brackets.

Set the clock.

Hold

Time blinks

Scoop holder Mains cord holder

Turn left or right to

adjust time

Page 7

RICE, QUICK, and SUSHI

(1)

Measure the rice with the measuring cup supplied.

Rinse rice, put the washed rice in the inner pot, and fill in water.

For example, if you’re

cooking 6 cups of rice, add

water to scale 6.

The supplied measuring cup is approx 180ml.

You can cook 2 to 10 cups of rice each time.

Each cup of uncooked rice normally gives two servings of cooked rice.

Do not rinse rice in the inner pot, for that may scratch off the non-sticky coating of the inner pot.

Add water to the level indicated on the scale inside the inner pot that corresponds to the number of cups and type of rice used.

Wipe off water outside of the inner pot and put it into the main body.

Wipe with dry cloth

Click!

Page 8

RICE, QUICK, and SUSHI

(2)

Select the menu you need and confirm.

Turn the knob to the

menu you need

When the cooking is finished, the rice cooker beeps and turns into warm keeping automatically.

MIN

Press OK to confirm

MIN

Starts cooking and the

time needed is displayed

MIN

Keep warm

MIN

The rice cooker remains at warm keeping for 12 hours, after that it beeps and cease warm keeping process.

Press CANCEL to cease warm keeping, and unplug the power.

Keep warm

MIN

Cooking time (for reference)

Rice about 35 minutes

Quick about 25 minutes

Sushi about 35 minutes

Page 9

SOUP, STEW

1 2

Put ingredients into the inner pot, add water as needed, and stir a little bit

Wipe off the water outside of the inner pot and put it into the main body.

Select the menu you need and confirm.

You can adjust cooking time for SOUP, STEAM, STEW, and CONGEE menus.

Turn the knob to

Press OK to confirm

SOUP or STEW

The time suggested for the

cooking is displayed

Starts cooking and the

time needed is displayed

When the cooking is finished, the rice cooker beeps and turns into warm keeping automatically.

The rice cooker remains at warm keeping for 12 hours, after that it beeps and cease warm keeping process.

Press CANCEL to cease warm keeping, and unplug the power.

Press OK to confirm

Adjust the time as

needed with the knob

Page 10

CAKE

1 2

Whisk the ingredients for cake well.

Coat the inner pot with some butter and then pour the cake mixture into it.

Wipe off water outside of the inner pot and put it into the main body.

Select CAKE and confirm.

Turn the knob to CAKE Press OK to confirm

MIN

Starts cooking and the

time needed is displayed

When the cooking is finished, the rice cooker beeps.

Unplug the power.

Recipes (HD4745/HD4747)

Ingredients

Pre-made cake mix  o u r

Butter 65g

Egg 1 big pc

Water/milk 100 ml

250g

Procedure:

1 Mix the cake mix  our, water or milk, butter, and egg in a large bowl.

Whisk with an electric mixer at low speed for 1 minute, and then

at medium speed for another 3 minutes.

Coat the inner pot with some butter, and then pour the cake

mixture into it.

Start the cake menu.

When the cooking process is  nished, let the cake cool down.

Then turn the inner pot upside down to let the cake slip out of the inner pot onto a plate.

Page 11

CONGEE

Put ingredients for the congee into the inner pot and add water according to the scale

HD4745 HD4747

in the inner pot.

Wipe off the water outside

cup

1 cup

~60 minutes

of the inner pot and put it

1+½ cup

~90 minutes

into the main body.

*Cooking time (for reference)

Select CONGEE and confirm.

Turn the knob to

Press OK to confirm

CONGEE

The time suggested for the

cooking is displayed

Starts cooking and the

time needed is displayed

When the cooking is finished, the rice cooker beeps and turns into warm keeping automatically.

The rice cooker remains at warm keeping for 12 hours, after that it beeps and cease warm keeping process.

Press CANCEL to cease warm keeping, and unplug the power.

Press OK to confirm

Adjust the time as

needed with the knob

Page 12

STEAM

1 2

3 4

Put 5 cups of water into the inner pot (you can adjust water level as needed).

Put the steam basket into the inner pot.

Put the food into the steam basket, and close the outer lid.

Select STEAM and confirm.

MIN

Turn the knob to

Press OK to confirm

STEAM

The time suggested for the

cooking is displayed

MIN

Starts cooking and the

time needed is displayed

Press OK to confirm

Adjust the time as

needed with the knob

When the cooking is finished, the rice cooker beeps.

There’s no warm keeping process for STEAM menu.

Page 13

Preset time for delayed cooking

You can preset the ready time for RICE, QUICK, SUSHI, SOUP, STEW, STEAM and CONGEE menus.

Preset timer is available up to 24 hours.

Turn the knob to the

menu you need

Press PRESET

Turn the knob to

set the ready time

Press OK to confirm

Current clock time

is displayed

MIN

The time needed for

cooking is displayed

To check the preset

ready time, press

PRESET again

Press OK to confirm

The cooking process

starts at preset clock time,

and the remaining cooking

time is displayed

Page 14

Heating

element

Reheat

Loosen the cooled rice and evenly distribute it in the inner pot.

To make sure the rice heat up

thoroughly, put less amount than

“RICE” water level 4

Pour water onto the rice to prevent it from becoming too dry. The quantity of the water depends on the amount of rice.

For example: add ½ cup (with the measuring cup supplied) of water to reheat the amount of rice up to “RICE” water level 4.

Press and hold REHEAT to start the reheating process.

MIN

Reheat

Hold

MIN

Reheat

When the reheating process complete, the cooker beeps and turns to warm keeping automatically.

Page 15

Cleaning

Inside of the outer lid and the main body:

Wipe with wrung out and damp cloth. Make sure to remove all the food residues stuck to the rice cooker.

Surface of the outer lid and outside of

Heating Heating

Heating

elementelement

element

the main body: Wipe with a cloth damped with soap water. ONLY use soft and dry cloth to wipe the control panel. Make sure to remove all the food residues around the control buttons.

Heating element:

Wipe with wrung out and damp cloth. Remove food residues with wrung out and damp cloth or toothpicks.

Rice scoop, soup ladle, inner pot, mains cord holder, scoop holder, steam basket, steam vent cap, and inner lid:

Soak in hot water and clean with sponge.

Page 16

Troubleshooting

If you encounter problems when using this cooker, check the following points before requesting service. If you cannot solve the problem, contact the Philips Consumer Care Center in your country.

Problem Possible cause Solution

The light on the buttons does not go on.

The display does not function.

The rice is not cooked. Not enough water has been added. Add water according to the scale

There is a connection problem. Check if the power cord is

connected to the cooker properly and if the plug is inserted  rmly into the power outlet.

The light is defective. Take the appliance to your

Philips dealer or a service center authorized by Philips.

The cooker is not connected to power supply.

The battery that supplies power to the display is empty.

If there is no power supply, the power failure backup function does not work and the display does not function.

Take the appliance to your Philips dealer or a service center authorized by Philips to have the battery replaced.

on the inside of the inner pot.

The cooker does not switch to keep-warm mode automatically.

The cooking process has not started.

The inner pot is not properly in contact with the heating element.

The heating element is damaged, or the inner pot is deformed.

You are using STEAM or CAKE menu.

The temperature control is defective.

You did not press OK button.

Make sure that there is no foreign residue on the heating element and the outside of the inner pot before switching the rice cooker on.

Take the cooker to your Philips dealer or a service center authorized by Philips.

The automatic keep-warm mode only applies to other 5 menus.

Take the appliance to your Philips dealer or a service center authorized by Philips.

Page 17

Problem Possible cause Solution

The rice is scorched. You have not rinsed the rice

properly.

Water spills out of the appliance during cooking.

Rice smells bad after cooking.

You added too much water to the rice.

Inner pot is not well cleaned and leftover from previous cooking contaminates the rice.

Can’t get to the desired

You did not turn the knob. Turn the knob slowly to the left or

cooking function.

Rinse the rice until the water runs clear.

Make sure that you add water to the level indicated on the scale inside the inner pot that corresponds to the number of cups of rice used.

Make sure the water does not exceed the next level on the scale, as this may cause the appliance to over ow during cooking.

Clean the inner pot with some washing detergent and warm water.

After cooking, make sure the steam vent cap, inner lid and inner pot is cleaned thoroughly.

to the right to the desired function as shown by the LED light.

It takes a long time to turn the knob to set the clock or preset the time for cooking.

The knob’s surrounding light is blinking.

Error message E5 appears on the display.

Making soup/making congee, water spoil out.

You turn the knob and allow it to bounce back.

Keep turning the knob to the right for a longer period of time, as it allows the time to move faster, until the time has reaches closed to the desired time. Then turn the knob slowly to reach the exact time needed.

This is normal. This shows that the rice cooker is

switched to keep-warm mode.

There has been a power failure during cooking or in the keep-warm mode that lasted longer than 2 hours.

Too much water when making soup/congee (exceed water level markings).

Too much rice or too much ingredients.

When the power supply resumes, press the Stop/Cancel button to reset the appliance.

Add water according to the indication on water level markings.

Do not add too much rice when making congee, with maximum of 1.5 cup of rice, then add water up to the water level marking of

1.5 cup congee.

Page 18

HD4747_HD4745_Asean_UM_V2.0

www.philips.com

3140 035 25132
