Philips HD4723, HD4738, HD4733, HD4728 User Manual [ja]

Rice Cooker

HD4738, HD4733, HD4728, HD4723

2

3

1

A X

M

B

C N

O

D

P

E

F Q R

G S

H

I T

J

K L

U

HD4728/HD4723

4

ENGLISH 6

11

HD4738, HD4733, HD4728, HD4723

6 ENGLISH

General description (fig. 1)

A Steam tray

B Water level indication

C Inner pot

D Steam vent

E Function selection switch (HD4738/HD4733 only)

F Release lever

G Rice light (HD4738/HD4733 only)

H Warm light (HD4738/HD4733 only)

I Congee light (HD4738/HD4733 only)

J Control lever

K Cook light (HD4728/HD4723 only)

L Warm light (HD4728/HD4723 only)

M Rice scoop

N Measuring cup

O Lid

P Detachable steam vent cap

Q Rice cooker handle

R Scoop holder

S Main body

T Heating element

U Mains cord connection

Important

Read these instructions for use carefully before using the appliance and save them for future reference.

Check if the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.

Only connect the appliance to an earthed wall socket.Always ensure the plug is inserted firmly into the wall socket.

If the mains cord is damaged, it must be replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.

Never use any accessories or parts from other manufacturers or which have not been specifically advised by Philips.Your guarantee will become invalid if such accessories or parts have been used.

Only use the rice scoop provided.Avoid using sharp utensils.

Never immerse the housing of the rice cooker in water, nor rinse it under the tap.

Do not expose the rice cooker to high temperatures, nor place it onto a working or still hot stove or cooker.

Make sure the heating element, the magnetic switch and the outside of the inner pot are clean and dry before switching the rice cooker on.

Do not switch the rice cooker on without having inserted the inner pot.

Always unplug the rice cooker and let it cool down before cleaning it.

Do not place the inner pot directly over an open fire to cook rice.

Do not cover the steam vent while the rice cooker is operating.

Keep the appliance out of the reach of children. Do not let the mains cord hang over the edge of the table or worktop on which the appliance is standing.

This appliance is intended for household use only. If the appliance is used improperly or for professional or semiprofessional purposes or if it is used in a way that is not in accordance with the instructions for use, the guarantee will become invalid and Philips will not accept liability for any damage caused.
