Page 1
Philips GoSure GPS
module
Compatible with ADR620
and ADR820
Your reliable witness on the road
Precise GPS location
Upgrade your dash cam
GPS02XM
Automatically capture your journey in vivid detail
In addition to a date and time stamp, the Philips GoSure GPS module (for ADR620,
ADR820) provides geolocation. Capture accurate evidence for accident reporting while
supporting and speeding up the insurance claim process.
GPS module to upgrade your dash cam
• Upgrade your dash cam with GPS location
Easy to install
• Plug-and-play GPS module
Page 2
GPS02XM
Compatible with ADR620 and ADR820
Precise GPS location Upgrade your dash cam
Specifications
Product description
• Designation: GPS20 GPS02
• Technology: Automotive Driving Recorder
• Acceleration: 4g
• Acquisition Channel: 48
• Acquisition Sensitivity: -148 dBm, typical
• C/A Code: 1.023 MHz chip rate
• Datum: Default WGS-84
• Dynamic Condition Altitude: 18000 m(Max)
•Jerk: 1g/s
• Position: 2 m CEP
•Time: 1 PPS <20 ns resolution
• Tracking Channel: 12
• Tracking Sensitivity: -165 dBm, typical
•TTFF — Hot Start: <2 sec average
• TTFF — Cold Start: <35 average
• TTFF — Warm Start: <32 average
•Velocity: 0.1 m/s
• Frequency: L1, 1575.42 MHz
•Velocity: 515 m/s(Max)
Weight and dimensions
• Product weight (g): 100
• Box weight (incl. product) (g): 220
•Height (cm): 6.5
• Length (cm): 16.5
• Width (cm): 10.3
Marketing specifications
• Expected benefits: Your driving safety guardian
• Product highlight: FHD & Optional GPS module
Logistic data
• Quantity in box: 1
• Reference: GPS02XM
• EAN1: 8727900340402
• EAN3: 8727900340419
• Ordering code: 34040230
Ordering information
•Order entry: GPS02XM
• Ordering code: 34040230
•
Highlights
Upgrade your dash cam
Did you know that the Philips GoSure ADR620 and
ADR820 can be upgraded with a GPS location
function? Simply replace the normal suction mount
provided in your ADR box with this GPS module.
Plug the GPS suction mount into your dash cam and
it will keep a record of your GPS location on all
recordings. You'll be able to capture accurate
evidence for accident reporting, while supporting
and speeding up the insurance claim process.
Plug-and-play GPS module
The Philips GoSure GPS suction mount module is
really easy to install. It takes only three steps. Simply
replace the normal suction mount provided in your
ADR box with this GPS module. Then plug the
power cable from the GPS mount into the power
socket of your car. And last but not least, plug the
cable of your dash cam into your GPS suction mount.
Issue date 2018-06-10
Version: 2.1.1
12 NC: 8670 001 53913
© 2018 Philips Lighting Holding B.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Philips Lighting Holding
B.V. or their respective owners.
