Philips GoGear SA5285BT, GoGear SA5285BT/37 Specifications

Download

Page 1

Philips GoGear Portable video player with FullSound™ and SuperScroll™

8GB

High-definition headphones

SA5285BT

Entertainment in superb sound

with FullSound and premium earphones

The Philips GoGear digital audio/ video player SA5285BT featuring Philips patented FullSound technology brings you superb audio quality. Bluetooth technology ensures the ultimate wireless entertainment on the go.

Experience music and video - anytime, anyplace

• Enjoy MP3, WMA and AAC music plus FM radio

• Rhapsody® for online music subscription service

• Playback WMV videos purchased online or from your library

• Bluetooth wireless technology for stereo audio output

• High-definition headphones for precise sound

Enjoy straight away

• 2.8" QVGA LCD color display for superb video enjoyment

• Control playpack while browsing your library

• SuperScroll™ to find what you want in a fast, simple way

• Easy and intuitive user interface with album art display

All your entertainment on the go

• Fullsound™ to bring your MP3 music to life

• Charge directly from your PC via USB

• Up to 25-hour music or 5-hour video playback*

Page 2

Portable video player with FullSound™ and SuperScroll™

8GB High-definition headphones

Highlights

SA5285BT/37

Rhapsody® for online music

Instantly access millions of full-length, CDquality tracks through the Rhapsody online music service. Join one of the Rhapsody membership plans then pick the songs you want from their catalog. Choose from rock, hip-hop, country, jazz and more - from new releases to old favorites. Download the songs onto your PC and then copy them over to your GoGear player to enjoy in superb sound. Rhapsody lets you discover loads of music with guides and recommendations, and a channel feature that makes it easy to tune in and enjoy different musical genres and themes, or you can customize your own channel.

FullSound™

Philips' innovative FullSound technology faithfully restores sonic details to compressed MP3 music, dramatically enriching and enhancing it, so you can experience CD music without any distortion. Based on an audio post-processing algorithm, FullSound combines Philips' renowned expertise in music reproduction with the power of the latest generation Digital Signal Processor (DSP). The result is fuller bass with more depth and impact, boosted voice and instrument clarity, and rich detail. Rediscover your compressed MP3 music in true-to-life sound that will touch your soul and move your feet.

High-definition headphones

Designed according to the curvature of the human canals, these ergonomically designed headphones with exceptional noise isolation feature precisely direct soundwaves from the speaker to your ear drums with highest definition.

SuperScroll™

Double action search keys allow easy speed control when scrolling through large libraries. You can choose to move through your playlist one song or video at a time or just press and hold down a little harder to SuperScroll™ swiftly to your desired file.

Page 3

Portable video player with FullSound™ and SuperScroll™

8GB High-definition headphones

Specifications

SA5285BT/37

Picture/Display

•Backlight

• Diagonal screen size (inch): 2.8 inch

• Lines of text: 7

• Resolution: QVGA, 320 x 240 pixels, 65K colours

•Type: LCD

Sound

• Equalizer customizable

• Equalizer settings: Classic, Dance, Electronica, Hip azz, Lounge, Pop, RnB, Rock, Spoken word

Hop, J

• Frequency response: 20 - 18k Hz

• Output Power: 2 x 2.4mW

• Signal to noise ratio: > 84 dB

• THD: 0.05% at 1kHz

• Channel separation: 45 dB

• Sound Enhancement: FullSound

Audio Playback

• Compression format: MP3, WMA, AAC

• ID3 Tag support: Album title and artist name

• MP3 bit rates: 8-320 kbps and VBR

• WMA bit rates: 5-192 kbps VBR

• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,

48 k

• MP3 sample rates: 16, 32, 44.1, 48, 11.025, 22.050,

24, 8 kHz

• Digital Rights Management: Windows Media DRM

r Portable Devices, Supports download &

fo subscription music services

Still Picture Playback

• Picture Compression Format: JPEG

•Slide show

Storage Media

• Built-in memory type: NAND Flash

• Built-in memory capacity: 8 GB

Connectivity

• Headphone: 3.5 mm

•USB: High speed USB 2.0

•Bluetooth

• Bluetooth profiles: A2DP, AVRCP

• Bluetooth version: 2.0+EDR

Convenience

• Battery charging indication: On User Interface

• Battery low indication

• Function: Keypad lock

• Superscroll

• Volume control

• Firmware upgradeable

Accessories

• CD-ROM: Yes , with IFU, Device Manager, Media

Issue date 2009-12-17

Version: 3.0.6

12 NC: 8670 000 38929 UPC: 6 09585 15331 8

converter & Windows Media Player

• Headphones: AY3817

• USB cable: AY3930

• Quick start guide

• Pouch: AY4255

Software

• Device manager: to restore and upgrade

• Media Converter for Philips: Converts following formats to playe

r : AVI(Microsoft video1 format),MOV,WMV,RM etc. Needs Quicktime (for MOV), Realplayer (for RM) and WMP10 or above (for WMV) installations.

Green Specifications

• Lead-free soldered product

System Requirements

•CD-ROM drive

• PC OS: Windows XP (SP2) or Windows Vista

• Internet connection: Yes (for access to updated pport documents, manuals, future firmware and

su PC software upgrades)

• USB: Free USB port

Power

• Battery capacity: 880mAh

•Battery Type: LI-Polymer

• Playtime on internal battery

: Up to 30 hours audio

or 6 hours video

• Rechargeable: Yes, via USB

Dimensions

• Blister dimensions (WxDxH): 196 x 30 x 214 mm

• Packaging type: Clamshell

• Product weight: 0.095 kg

• Product dimensions (WxDxH): 106 x 9.9 x 58 mm

Tuner/Reception/Transmission

• Station presets: 20

•Tuner Bands: FM

Video Playback

• MPEG4 SP: Upto 640kbps in avi format, 320x240 ,

30fps (Other formats supported by using provided converter software)

• WMV9: Upto 512kbps, 320x240 , 30fps (Other rmats supported by using provided converter

fo software)

• Digital Rights Management

: Windows XP (SP2) or

Windows Vista

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording: ADPCM

•

Specifications are subject t Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

o change without notice.

* 1GB = 1 billion bytes; available storage capacity will be less. * Rechargeable batteries have a limited number of charge cycles and may

ntually need to be replaced. Battery life and number of charge

eve cycles vary by use and settings.

* Windows Media and the Windows logo ar

trademarks of Microsoft Corporation in the United States and/or other countries.

* Actual transfer speed may vary based on your operating system and

software configuration.

* Supports download and subscription services compatible with WMA

DRM10

* The free Rhapsody offer is available to new customers and cannot be

used with a current Rhapsody account or with any other special offers. User must accept standard terms and conditions of use found at www.rhapsody.com/terms. Offers valid for US residents only.

* Rhapsody and the Rhapsody logo are trademarks or registered

rademarks of RealNetworks, Inc.

* From Philips

e trademarks, or registered
