Philips GoGEAR SA4DOT04, GoGEAR SA4DOT08 User Manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
SA4DOT02
SA4DOT04
SA4DOT08
GoGEAR
1EN
Contents
1 Important safety information 2
General maintenance 2
2 Your new player 5
What's in the box 5
PC software for the player 5 Files loaded on the player 5
Overview 5
Controls 5 LED indicator and audio feedback 6
3 Get started 7
Charge power 7 Switch the player on or off 7
Automatic standby and shut-down 7
4 Play music 8
Transfer music to the player 8 Play music 8
Search for a song 8 Change the volume level 8 Switch the random play on or off 8
5 Updatethermwarethrough
Philips Device Manager 9
6 Troubleshooting 11
7 Technical data 12
PC requirements 12
Need help?
Please visit
www.philips.com/welcome
where you can access a full set of supporting materials such as the user manual, the latest software updates, and answers to frequently asked questions.
2 EN
1 Important safety
information
General maintenance
The translation of this document is for reference only. In the event of any inconsistency between the English version and the translated version, the English version shall prevail.
Caution
• To avoid damage or malfunction:
• Use only power supplies listed in the user manual.
• Do not expose the product to excessive heat caused
by heating equipment or direct sunlight.
• Do not drop the product or allow objects to fall on
your player.
• Do not allow the product to be submerged in
water. Do not expose headphone socket or battery compartment to water, as water entering the set may cause major damage.
• Active mobile phones in the vicinity may cause
interference.
Back up your les. Ensure that you retain the original
les you have downloaded to your device. Philips is not
responsible for any loss of data if the product becomes damaged or not readable / legible.
Manage (transfer, delete, etc.) your music les only with
the supplied music software to avoid problems.
• Do not use any cleaning agents containing alcohol,
ammonia, benzene, or abrasives as these may harm the product.
• Batteries (battery pack or batteries installed) shall not
be exposed to excessive heat such as sunshine, re or
the like.
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
About operating and storage temperatures
Operate in a place where temperature is always between 0 and 45ºC (32 to 113ºF)
Store in a place where temperature is always between -20 and 45ºC (-4 to 113ºF).
Battery life may be shortened in low temperature conditions.
Replacement parts/accessories:
Visit www.philips.com/support to order replacement parts/accessories.
Hearing Safety
Listen at a moderate volume:
Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss. Sound can be deceiving. Over time your hearing 'comfort level' adapts to higher volumes of sound. So after prolonged listening, what sounds 'normal' can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there. To establish a safe volume level: Set your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and clearly, without distortion. Listen for reasonable periods of time: Prolonged exposure to sound, even at normally 'safe' levels, can also cause hearing loss. Be sure to use your equipment reasonably and take appropriate breaks. Be sure to observe the following guidelines when using your headphones. Listen at reasonable volumes for reasonable periods of time. Be careful not to adjust the volume as your hearing adapts. Do not turn up the volume so high that you can’t hear what’s around you.
3EN
You should use caution or temporarily discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it
may create a trafc hazard and is illegal in many
areas.
Modications
Modications not authorized by the
manufacturer may void user's authority to operate the product.
Copyright information
All other brands and product names are trademarks of their respective companies or organizations. Unauthorized duplication of any recordings whether downloaded from the Internet or made from audio CDs is a violation of copyright laws and international treaties. The making of unauthorized copies of copy­protected material, including computer
programs, les, broadcasts and sound
recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. The Windows Media and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries.
Be responsible! Respect copyrights.
Philips respects the intellectual property of others, and we ask our users to do the same. Multimedia content on the internet may have been created and/or distributed without the original copyright owner's authorization. Copying or distributing unauthorized content may violate copyright laws in various countries including yours.
Compliance with copyright laws remains your responsibility. The recording and transfer to the portable player of video streams downloaded to your computer is intended only for use with public domain or properly licensed content. You may only use such content for your private, non-commercial use and shall respect eventual copyright instructions provided by the copyright owner of the work. Such instruction may state that no further copies shall be made. Video streams may include copy protection technology that prohibits further copying. For such situations the recording function will not
work and you will be notied with a message.
Data logging
Philips is committed to improving the quality of your product and enhancing the Philips user
experience. To understand the usage prole of
this device, this device logs some info / data to the non-volatile memory region of the device. These data are used to identify and detect any failures or problems you as a user may experience while using the device. The data stored, for example, will be the duration of playback in music mode, duration of playback in turner mode, how many times battery low was encountered, etc. The data stored do not reveal the content or media used on the device or the source of downloads. The data stored on the device are retrieved and used ONLY if the user returns the device to the service center and ONLY to simplify error detection and prevention. The data stored shall be made
available to user on user’s rst request.
Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative
4 EN
consequences for the environmental and human health.
5EN
2 Your new player
What's in the box
Make sure that you have received the following items: Player
Earphones
Quick start guide
Safety and Warranty sheet
Note
• The images serve as reference only. Philips reser ves the
right to change color/design without notice.
Philips GoGear audio player
Quick start guide
Safety and Warranty
Before using your set: Check out details inside this booklet
PC software for the player
SOUNDDOT can work with the following PC
software:
Philips Device Manager (helps you get rmware updates and recover the player)
Files loaded on the player
The following les are loaded on SOUNDDOT:
User manual
Frequently asked questions
Overview
Controls
a
Press and hold: Switch the player on
or off
Press: Pause/ resume play
Press twice during play: Switch the
random play on or off
b /
Press: Decrease or increase the volume
Press and hold: Skip to the previous or
next song
c
a
d
e
g
f
b
6 EN
c USB connector for power charging and
data transfer
d Clip e RESET
Press the hole by using the tip of a ball pen when the player does not respond to the pressing of keys
f LED indicator g
3.5 mm-headphone connector
LED indicator and audio feedback
With the LED indicator and/ or audio feedback, you can know the status of the player.
BEEP
7EN
3 Get started
Charge power
SOUNDDOT has a built-in battery that can be
charged through the USB socket of a computer.
Rotate the USB connector to connect SOUNDDOT to a PC.
» During power charging, the indicator
changes its color to denote the battery level.
» When the battery is full, the green
indicator lights up.
Tip
When the battery level is lower than 15%, the red
indicator ashes and two beeps sound.
• Rechargeable batteries have a limited number of charge
cycles. Battery life and number of charge cycles var y by use and settings.
Switch the player on or off
Press and hold until the green or red indicator lights up.
» Power on: The green indicator lights
up. Music play starts.
» Power off: The red indicator lights up.
One beep sounds.
Automatic standby and shut-down
The player has an automatic standby and shut­down feature that can save battery power.
After ve minutes in idle mode (no play, no
button is pressed), the player switches off.
8 EN
4 Play music
Transfer music to the player
You can transfer music from your PC media library to SOUNDDOT in the following ways:
• Drag and drop music les in Windows
Explorer.
TodraganddropmusiclesinWindows
Explorer,
1 Connect SOUNDDOT to a PC. 2 On the PC, under My Computer or
Computer,
• drag and drop music les from the PC
to SOUNDDOT.
Play music
1 Make sure that you have switched on the
player (see 'Switch the player on or off' on page 7).
» The green indicator lights up. Music
play starts.
» During music play, the green indicator
ashes at intervals.
2 Press to pause or resume play.
Search for a song
Press and hold / to skip to the previous or next song.
» One beep sounds.
Change the volume level
Press / .
» During music play, you hear the change
of volume level.
Switch the random play on or off
1 During music play, press twice.
» You hear two beeps. The green
indicator ashes twice at intervals.
» Songs play in random.
2 To switch off the random play, press
twice again.
» You hear one beep. The green indicator
ashes once at intervals.
» Songs play in sequence.
9EN
5 Update the
firmware through Philips Device Manager
Install Philips Device Manager
1 Connect SOUNDDOT to a PC. 2 On the PC, select My Computer
(Windows XP / Windows 2000) / Computer (Windows Vista / Windows 7 / 8).
3 Right click on the Philips GoGear
SOUNDDOT icon. Select Install Philips Device Manager.
Alternatively, click the Philips GoGear SOUNDDOT icon. Double-click the installer.exe.
4 Follow the onscreen instructions to
complete the installation of the software.
Note
• The installation requires you to agree to the license
terms.
Checkforrmwareupdates
1 Make sure that you have connected your
PC to the Internet.
2 Launch Philips Device Manager.
» A dialog box is displayed.
3 Connect SOUNDDOT to your PC.
» When the device is connected,
"SA4DOTXX" is displayed on the text box.
» You can nd current rmware version
of the device.
4 To check for rmware updates,
a Close the dialog box of Philips Device
Manager.
b At the base of the PC screen, right
click and select Check for updates.
10 EN
» Philips SA4DOTXX Device
Manager checks for updates from
the Internet.
Updatethermware
1 When the rmware update is available,
follow the onscreen instructions to
download and install the rmware.
2 Disconnect SOUNDDOT from the PC.
» SOUNDDOT restarts after the
rmware is updated and is ready for
use again,
11EN
6 Troubleshooting
If SOUNDDOT is not working properly or the display freezes, you can reset it without losing data:
How do I reset SOUNDDOT?
Insert a pen tip or other object into the reset hole on SOUNDDOT. Hold until the player shuts down.
If the reset option is unsuccessful, recover
SOUNDDOT through Philips Device Manager:
1 On your PC, launch Philips Device
Manager.
2 Enter the recovery mode:
a Switch off SOUNDDOT. b Press and hold the volume button
, and then, connect SOUNDDOT
to your PC.
c Keep holding the button until
Philips Device Manager recognizes SOUNDDOT and enters the recovery mode.
3 Start the recovery process:
a On Philips Device Manager, click the
Repair button. Follow the onscreen instructions to complete the recovery process.
b When the recovery is completed,
disconnect SOUNDDOT from your PC.
4 Restart SOUNDDOT.
12 EN
7 Technical data
Power
Power supply: 110 mAh Li-ion polymer
internal rechargeable battery
Play time¹
Audio (.mp3): up to 6 hours
Fast charging: 6-minute charging for
60-minute play
Software
Philips Device Manager: To update the
rmware and recover the player
Connectivity
Headphone 3.5 mm
USB 2.0 High speed
Sound
Channel separation: 45 dB
Frequency Response: 20-18,000 Hz
Output power: 2 x 2.4 mW
Signal to noise ratio: > 84 dB
Audio playback
Supported formats:
MP3
Bitrate: 8-320 kbps and VBR Sampling rates: 8, 11.025, 16, 22.050, 32, 44.1, 48 kHz
WMA (unprotected)
Bitrate: 5-320 kbps Sampling rates: 8, 11.025, 16, 22.050, 32, 44.1, 48 kHz
WAV
Storage media
Built-in memory capacity²:
SA4DOT02 2 GB NAND Flash
SA4DOT04 4 GB NAND Flash
SA4DOT08 8 GB NAND Flash
Media transfer³
Windows Explorer (drag and drop)
Note
Specications are subject to change without notice.
• ¹ Rechargeable batteries have a limited number of
charge cycles. Battery life and number of charge cycles vary by use and settings.
• ² 1 GB = 1 billion bytes; available storage capacity is
less. Full memory capacity may not be available as some memory is reser ved for the player. Storage capacity is based on 4 minutes per song and 128-kbps MP3 encoding.
• ³ Transfer speed depends on operating system and
software conguration.
PC requirements
Windows® XP (SP3 or above) / Vista / 7
Pentium III 800 MHz processor or higher
512 MB RAM
500 MB hard disk space
Internet connection
Windows® Internet Explorer 6.0 or later
CD-ROM drive
USB port
2013 © WOOX Innovations Limited. All rights reserved. Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations Limited under license from Koninklijke Philips N.V. SA4DOT_93_97_UM_V3.0 wk1349.5
