SA1OPS08

SA1OPS16

SA1OPS32

www.philips.com/welcome

EN User manual

English

Contents

1 Important safety information 3

General maintenance 3 Recycling the product 4

2 Your new GoGear Opus 6

What’s in the box 6

3 Getting started 7

Overview of the controls and

connections 7 Overview of the main menu 7 Install software 8 Connect and charge 8

Connect GoGear Opus to a

computer 8 Battery level indication 8 Battery level indication 9 Disconnect GoGear Opus safely 9

Turn GoGear Opus on and off 9

Automatic standby and shut-down 9

4 UseGoGearOpustocarryles 10

5 Windows Media Player 11

(WMP11) 11

Install Windows Media Player 11

(WMP11) 11

Transfer music and picture les to

WMP11 library 11

Switch between music and pictures

library in WMP and GoGear Opus 12 Rip songs from a CD 12 Buy music online 13 Sync your Windows Media content to

GoGear Opus 13

Set up GoGear Opus for WMP11 14 Switch between automatic and

manual sync 14

Select and prioritize what syncs

automatically 14

Select les and playlists for manual

sync 15

Copy les from GoGear Opus to your

computer 16

WMP11 playlists 16

Create a regular playlist 16 Create an auto playlist 16 Edit playlist 17 Transfer playlists to GoGear Opus 17

Search for music or pictures with

WMP11 17

Delete les and playlists from WMP11

library 17

Delete les and playlists from GoGear

Opus 18 Edit song information with WMP11 18 Format GoGear Opus with WMP11 19

6 Music 20

Listen to music 20 Find your music 20 Delete music tracks 20

7 Audiobooks 21

Add audiobooks to GoGear Opus 21 Audiobook controls 21 Select audiobook by book title 21 Adjust audiobook play speed 22 Add a bookmark in an audiobook 22 Find a bookmark in an audiobook 22 Delete a bookmark in an audiobook 22

8 Video 23

Download, convert and transfer

videos 23 Play videos 23 Delete videos 23

9 Pictures 24

View pictures 24 View slideshow 24 Add pictures to GoGear Opus 24 Delete pictures 24

Need help?

Please visit

www.philips.com/welcome

where you can access a full set of supporting materials such as the user manual, the latest software updates, and answers to frequently asked questions.

10 Radio 25

Listen to FM radio 25 Manually tune a radio station 25 Auto-tune preset radio station 25 Play a preset radio station 25

11 Recordings 26

Record from FM radio 26 Record audio/voices 26 Listen to FM recordings 26 Listen to voice/audio recordings 26 Upload your recordings to a computer 26 Delete recordings 27

12 Settings 28

13 Update GoGear Opus 30

Manually verify / update rmware 30

14 Troubleshooting 31

15 Technical data 32

System requirements 32

Supported music le formats 32 Supported video le formats 33 Supported picture le formats 33

16 Glossary 34

Hearing Safety

Listen at a moderate volume:

Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss. Sound can be deceiving. Over time your hearing ‘comfort level’ adapts to higher volumes of sound. So after prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there. To establish a safe volume level: Set your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and clearly, without distortion. Listen for reasonable periods of time: Prolonged exposure to sound, even at normally ‘safe’ levels, can also cause hearing loss. Be sure to use your equipment reasonably and take appropriate breaks. Be sure to observe the following guidelines when using your headphones. Listen at reasonable volumes for reasonable periods of time. Be careful not to adjust the volume as your hearing adapts. Do not turn up the volume so high that you can’t hear what’s around you. You should use caution or temporarily discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it

may create a trafc hazard and is illegal in many

areas.

1 Important safety

information

General maintenance

Caution

To avoid damage or malfunction: • Do not expose the product to excessive heat • caused by heating equipment or direct sunlight. Do not drop the product or allow objects to

•

fall on your player. Do not allow the product to be submerged

•

in water. Do not expose headphone socket or battery compartment to water, as water entering the set may cause major damage. Active mobile phones in the vicinity may cause

•

interference.

Back up your les. Ensure that you retain the

•

original les you have downloaded to your

device. Philips is not responsible for any loss of data if the product becomes damaged or not readable / legible.

Manage (transfer, delete, etc.) your music les

•

only with the supplied music software to avoid problems. Do not use any cleaning agents containing

•

alcohol, ammonia, benzene, or abrasives as these may harm the product.

About operating and storage temperatures

Operate in a place where temperature is • always between 0 and 35ºC (32 to 95ºF) Store in a place where temperature is • always between -20 and 45ºC (-4 to 113º F). Battery life may be shortened in low • temperature conditions.

Replacement parts/accessories:

Visit www.philips.com/support to order replacement par ts/accessories.

English

Video streams may include copy protection technology that prohibits further copying. For such situations the recording function will not

work and you will be notied with a message.

Data logging

Philips is committed to improving the quality of your product and enhancing the Philips user

experience. To understand the usage prole of

this device, this device logs some info / data to the non-volatile memory region of the device. These data are used to identify and detect any failures or problems you as a user may experience while using the device. The data stored, for example, will be the duration of playback in music mode, duration of playback in turner mode, how many times battery low was encountered, etc. The data stored do not reveal the content or media used on the device or the source of downloads. The data stored on the device are retrieved and used ONLY if the user returns the device to the Philips service center and ONLY to simplify error detection and prevention. The data stored shall be made

available to user on user’s rst request.

Recycling the product

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When you see the crossed-out wheel bin symbol attached to a product, it means the product is covered by the European Directive 2002/96/EC:

Never dispose of your product with other household waste. Please inform yourself about

Modications

Modications not authorized by the

manufacturer may void user’s authority to operate the product.

All other brands and product names are trademarks of their respective companies or organizations. Unauthorized duplication of any recordings whether downloaded from the Internet or made from audio CDs is a violation of copyright laws and international treaties. The making of unauthorized copies of copyprotected material, including computer

programs, les, broadcasts and sound recordings,

may be an infringement of copyrights and constitute a criminal offenseThis equipment should not be used for such purposes. The Windows Media and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries.

Be responsible! Respect copyrights.

Philips respects the intellectual property of others, and we ask our users to do the same. Multimedia content on the internet may have been created and/or distributed without the original copyright owner’s authorization. Copying or distributing unauthorized content may violate copyright laws in various countries including yours. Compliance with copyright laws remains your responsibility. The recording and transfer to the portable player of video streams downloaded to your computer is intended only for use with public domain or properly licensed content. You may only use such content for your private, non-commercial use and shall respect eventual copyright instructions provided by the copyright owner of the work. Such instruction may state that no further copies shall be made.

Notice for the European Union

This product complies with the radio interference requirements of the European Union.

the local rules on the separate collection of electrical and electronic products. The correct disposal of your old product helps prevent potentially negative consequences on the environment and human health.

Caution

Removal of the built-in battery invalidate the • warranty and may destroy the product. The following instructions are disposal instructions at the end of the product’s life.

Your product contains a built-in rechargeable battery covered by the European Directive 2006/66/EC, which cannot be disposed of with normal household waste. To safeguard the functionality and safety of your product, take

your product to an ofcial collection point or

service centre where a professional can remove or replace the battery as shown:

Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.

English

Quick start guide

CD-ROM

Note

The images serve as reference only. Philips • reserves the right to change color/design without notice.

Philips GoGear audio player

Quick start guide

2 Your new

GoGear Opus

GoGear Opus allows you to

play WMV and MPEG4 (.avi) video les• play MP3, WMA and FLAC audio les•

display album art• view pictures• listen to audiobooks• listen to FM radio• make recordings• view folders•

What’s in the box

Check that you have received the following items: Player

Earphones

USB cable

Caution

Listening to loud sounds for longer than a • moment can be harmful to the listener.

You can set the volume level of GoGear Opus to limit the maximum volume output.

1 From the main menu, select

[Settings]>[Sound settings] > [Volume limit].

2 Press the / volume controls to adjust

the level.

3 Press to conrm.

When you set a volume limit, GoGear » Opus can no longer exceed the set volume, even if you press the volume

button.

To enable maximum volume again:

1 Select [Settings] > [Sound settings]

>[Volume limit].

2 Set the volume limit to maximum. 3 Press to conrm.

Overview of the main menu

Menu Mode To

Music play music tracks Video play videos Pictures view pictures FM radio listen to FM radio Recording create or listen to

recordings

Folder view

view les in folders

Settings customize the settings

of GoGear Opus

Now playing / Last played

in play mode: show current play screen in stop mode: resume play

3 Getting started

Overview of the controls and connections

display

/ press: scroll up/down

press and hold: scroll up/ down at high speed

OPTIONS view available options

VOL press: increase/decrease the

volume press and hold: increase/ decrease fast

MIC microphone

press: skip to next press and hold: scan forwards at high speed

/ press: play/pause

press and hold: turn GoGear Opus on/off

press: skip to previous press and hold: scan backwards at high speed

press: back one level press and hold: back to main

headphone jack

USB connection jack

RESET press: reset GoGear Opus

slide: lock/unlock all buttons except

VOL

English

Connect and charge

GoGear Opus has a built-in battery that can be charged through the USB port of a computer (USB cable included).

Note

For rst-time use, allow GoGear Opus to •

charge for 3 hours. The charging animation stops and the

•

icon is displayed when the charging process is completed.

Connect GoGear Opus to a computer

1 Connect the USB plug of the supplied

USB cable to a spare USB port on your computer.

2 Connect the small USB plug of the USB

cable to the small USB jack on GoGear Opus.

3 Turn on your computer.

GoGear Opus charges. »

Battery level indication

The display indicates the approximate levels of the battery status as follows:

100% 75% 50% 25% 0%

A ashing battery screen indicates that » the battery is low. The player saves all settings and switches off within 60 seconds.

Install software

GoGear Opus comes with the following software:

• Philips Device Manager (helps you get rmware updates for GoGear Opus)

• Media Converter for Philips (helps you conver t and transfer video les for

GoGear Opus)

• Windows Media Player(helps you convert and transver music and picture

les for GoGear Opus)

Important:

Remember to install the software provided in the supplied CD-ROM for music and/or video transfer. Important: Before installing the software, check that your computer meets the requirements (see section System

requirements in this user manual).

1 Connect GoGear Opus to your

computer.

2 Inser t the CD that comes with GoGear

Opus into the CD-ROM drive of your computer.

3 Follow the on-screen instructions to

complete the installation of the software.

If the installation program fails to start automatically:

1 Browse the CD contents with Internet

Explorer.

2 Double click on the le ending with ‘.exe’.

Automatic standby and shut-down

GoGear Opus has an automatic standby and shut-down feature that can save battery power. After 10 minutes in idle mode (no music plays, no button is pressed), GoGear Opus turns off.

1 Press and hold for approximately 2

seconds to turn GoGear Opus on again.

GoGear Opus has a lock switch to prevent accidental operation.

1 To lock the buttons when you play, move

the slider to position

All buttons except the volume keys are » locked and the display shows a lock icon.

2 To unlock the buttons again, move the

slider to the center position.

Battery level indication

Note

Rechargeable batteries have a limited number • of charge cycles. Battery life and number of charge cycles vary by use and settings. The charging animation stops and the

•

icon is displayed when the charging process is completed.

Tip

You can conserve battery power and increase • the play time of GoGear Opus: Go to the Settings menu and set Backlight to the shor test time setting.

Disconnect GoGear Opus safely

To avoid data loss, disconnect GoGear Opus from your computer as follows:

1 On your computer, exit all applications

that are working with GoGear Opus.

2 Click in the task tray of your computer. 3 Wait for the conrmation that GoGear

Opus can be safely removed, then disconnect GoGear Opus from the USB port.

Turn GoGear Opus on and off

To toggle between modes on and off,

press and hold

for approximately 2

seconds.

English

4 Use GoGear

Opus to carry files

GoGear Opus allows you to carry les in

Windows Explorer.

1 With GoGear Opus connected to

the USB port of the computer, open

Windows Explorer.

2 Create folders in GoGear Opus. 3 Use drag and drop actions to sor t your

les into the folders.

3 Click << Advanced Options to expand

the dialog box.

4 Click Add....

Add folder dialog box appears. »

5 Select a folder that contains your music

or picture les, then click OK.

6 WM P11 starts scanning the folder and

adds available music or picture les to the

library.

7 Click Close when done.

Tip

•

WMP11 is congured to skip audio les that are smaller than 100 KB. To include les

smaller than 100 KB, you can change the default settings within the Add to library dialog box.

5 Windows

Media Player 11 (WMP11)

Install Windows Media Player 11 (WMP11)

Inser t the supplied CD into the CD-ROM

drive of your computer.

2 Follow the on-screen instructions to

complete the installation of WM P11.

Transfer music and picture

lestoWMP11library

By default, WMP11 automatically loads all the

music and picture les that are stored in your computer. The new les are also automatically

added to the WMP11 library. The following steps show how you can add music and

picture les that are stored elsewhere on your

computer or computer network:

1 Select Start > All Programs > Windows

Media Player to launch the WMP11

program.

2 Click the down arrow beneath the

Library tab, then select Add to Library....

Add to Library dialog box appears. »

English

4 Click on the down arrow beneath the Rip

tab and select the Bit Rate.

5 Inser t the audio CD into the CD drive of

the computer.

All the tracks from the CD are listed. »

By default, WMP11 starts to rip all the songs from the CD.

Switch between music and pictures library in WMP and GoGear Opus

Click the arrow on the top left of

WMP11,then select the category.

Rip songs from a CD

You can transfer music from a CD to GoGear Opus. The transfer requires that you create a

digital copy of the music on your computer rst.

This is called ripping.

1 Ensure that the computer is connected to

the Internet.

2 Start WM P11. 3 Click the down arrow beneath the Rip

tab and select the Format.

You can nd the albums or songs you » purchase in the WMP11 library.

Sync your Windows Media content to GoGear Opus

You can sync your music and pictures to GoGear Opus using WMP11. When you connect GoGear Opus to the computer for the rst time, WMP11 automatically selects the sync method (automatic or manual) that works best for GoGear Opus.

Automatic: If GoGear Opus has sufcient

storage space (at least 4GB of free space) and

your entire media library can t on GoGear

Opus, your entire media library is automatically copied to GoGear Opus when connected to the computer. Manual: If your entire media library cannot

t on GoGear Opus, you are prompted to manually select les or playlists for transfer to

GoGear Opus.

To modify this option, click the down » arrow beneath the Rip tab and select Rip CD Automatically When Inserted > Never.

6 Click on the check boxes to select the

songs that you want to rip.

7 Click Start Rip.

The selected tracks are converted and » added to the WMP11 library.

Buy music online

You can select a music store and buy music online.

1 Start WM P11. 2 Click the down arrow beneath the Media

Guide tab and select Browse all Online Stores.

3 Choose a store and follow the on-screen

instructions.

English

Select and prioritize what syncs automatically

If WMP11 selects to sync GoGear Opus automatically, you can choose not to sync your entire media library. You can choose what to sync from existing playlists or create new playlists. The playlists you select sync to GoGear Opus every time you connect GoGear Opus to the computer.

1 Click the down arrow beneath the Sync

tab and select Philips GoGear Opus > Set Up Sync.

The Device Setup dialog box appears. »

2 In the Available playlists pane, select the

existing playlists you want to sync, then click Add.

3 To create a playlist, click New Auto

Playlist, then follow the steps on the

screen to specify criteria. (See also section Create an Auto Playlist).

4 To remove a playlist, click the playlist

in the list of Playlists to sync, then click Remove.

5 In the Playlist to sync pane, select the

Priority arrows to arrange them in the

order that you want them to sync.

Set up GoGear Opus for WMP11

Caution

Do not disconnect GoGear Opus while • transfer is in progress. If you disconnect GoGear Opus, the transfer is incomplete and Windows may not be able to recognize GoGear Opus afterwards.

1 Start WM P11. 2 Turn on GoGear Opus. 3 Connect GoGear Opus to the computer. 4 Set up sync:

If you are prompted: select the • option to sync GoGear Opus using WMP11. If • WMP11 selects to sync GoGear Opus automatically: click Finish. Your entire library syncs to GoGear • Opus. Thereafter, GoGear Opus syncs automatically when connected to the computer. You can also choose what syncs • automatically (see section Select and prioritize what syncs automatically). If • WMP11 selects to sync GoGear Opus manually, click Finish. You are required to click the • Sync

tab and manually select the les and

playlists for sync (see section Select lesandplaylistsformanualsync).

Switch between automatic and manual sync

After the rst sync setup, you can switch

between automatic and manual sync:

1 Click the down arrow beneath the Sync

tab, then select PhilipsGoGear Opus > Set Up Sync.

2 Select or deselect the Sync this device

automatically check box.

6 In the Sync List pane, verify that the items

you have selected to sync can all t on

GoGear Opus.

If necessary, remove items from the • list.

7 To remove items, right click on the item

in the Sync List pane, then select Remove from List.

8 Click Start Sync button to transfer the

Sync List items to GoGear Opus.

The progress is displayed on the » bottom right of WMP11.

Click » Stop Sync to stop the transfer.

Tip

If the tracks to sync are protected, you are • prompted to upgrade the security components on your computer. When this happens, you can play the track in WMP11 and when prompted, follow the steps on the screen to upgrade the security components. After you have upgraded your security components, you

can sync the le to GoGear Opus.

If GoGear Opus is full before sync is »

complete, the les and playlists that are

lower in priority on the list are omitted from sync.

Tip

If your media library is too large to t on •

GoGear Opus, you can select the Shufewhat

syncs check box, to shufe the les that are in the playlists to sync. Thereafter, the les on

GoGear Opus are replaced with a new set of

les (from the Playlists to sync pane) whenever

GoGear Opus is connected to the computer.

Selectlesandplaylistsformanual

sync

If you want to sync manually, you are required

to a list of les and playlists you want to sync. You can also shufe which les from your

playlists to sync to GoGear Opus.

1 Start WM P11. 2 Turn on GoGear Opus. 3 Connect GoGear Opus to the computer. 4 Click the Sync tab. 5 Drag the les and playlists that you want

to sync from the Contents pane to the Sync List pane.

You can also click on the le or •

playlist and select Add to ‘Sync List’.

English

4 When you have nished adding items to

the playlist, click Save Playlist.

Create an auto playlist

WMP11 can automatically generate playlists

based on various criteria.

1 Click the down arrow beneath the

Library tab, then select Create Auto Playlist.

A New Auto Playlist dialog box » appears.

2 Enter a name for the auto playlist.

3 Click the rst green plus sign and select

your rst criteria from the pull-down list.

4 Click on the underlined words to rene

your criteria.

5 Click the second and third green plus

signs to select and dene more criteria

for your auto playlist.

CopylesfromGoGear

Opus to your computer

GoGear Opus supports reverse sync, which

lets you copy les from GoGear Opus to your

computer with WMP11.

1 Start WM P11. 2 Turn on GoGear Opus. 3 Connect GoGear Opus to the computer. 4 Click on Philips GoGear Opus in the left

Navigation pane.

The content on GoGear Opus is listed » in the Contents pane.

5 Navigate to the le or playlist you want

to copy from GoGear Opus to the computer.

6 Right click on the le or playlist, then

select Copy from Device.

WMP11 playlists

Playlists allow you to mix any combination of songs or pictures you want. You can create regular or auto playlists in WMP11. These playlists can contain songs, pictures, or both.

Create a regular playlist

1 Click the down arrow beneath the

Library tab and select Create Playlist.

Untitled Playlist appears on the List » pane.

2 Click on Untitled Playlist and enter a new

name for the playlist.

3 To add items to your playlist, drag them

from the Contents pane to the List pane. (Your playlist can contain both songs and pictures.)

To add a new item to the playlist, select it from the library and drag it to the List pane.

When you have nished editing the playlist,

click the Save Playlist button.

Transfer playlists to GoGear Opus

The section Selectlesandplaylistsfor manual sync in this user manual shows how to transfer of playlists to GoGear Opus.

Search for music or pictures with WMP11

Click the Library tab.

2 Click the arrow on the top left of

WMP11, then select Music or Pictures to

search.

3 Type a few keywords of the le, such as

song title or artist in the search box.

The search results appear in the » Contents pane as you type. Results are updated as you enter each new letter

4 To rene your search results, enter more

keywords.

Deletelesandplaylistsfrom

WMP11 library

Click the Library tab.

2 Click the arrow on the top left of

WMP11, then select Music or Pictures for deletion.

3 Navigate to the le or playlist you want to

delete.

4 Right click on the le or playlist, then

select Delete.

5 Select Delete from library only or

Delete from library and my computer, then click OK.

6 Click OK button when done.

Edit playlist

You can edit your existing playlists at any time.

1 In the left Navigation pane, click on

Playlists.

All your playlists are displayed in the » Contents pane.

Right click on the playlist you want to edit, then select Edit in List Pane from the pop-up menu.

The content in the playlist appears in » the List pane.

To remove an item from the playlist, right click on the item, then select Remove from List.

To change the order of the items in the playlist, click and drag any item to a new position within the List pane.

English

Edit song information with WMP11

Click the Library tab.

2 Navigate to the song you want to edit. 3 Right click on the song, then select

Advanced Tag Editor from the pop-up

menu.

The advanced Tag Editor dialog box » appears.

4 Select the appropriate tab, then enter or

edit the information.

5 Click OK to save your changes.

Deletelesandplaylistsfrom

GoGear Opus

You can use WMP11 to manage the les stored on GoGear Opus. When you connect GoGear Opus to the computer, the contents on GoGear Opus is displayed in WMP11. You can

delete les or playlists, just like any other les

displayed in WMP11.

1 In the left Navigation pane, click on

Philips GoGear Opus.

2 You can browse the contents of GoGear

Opus in a variety of views, such as Recently Added or Artists.

3 The contents on GoGear Opus is listed in

the Contents pane.

4 To delete music or picture les, click the

arrow on the top left of WM P 11, then select Music or Pictures.

5 Navigate to the le or playlist you want to

delete.

6 Right click on the le or playlist, then

select Delete.

7 Click OK.

Format GoGear Opus with WMP11

Caution

This procedure reformats the storage on • GoGear Opus and erases all data.

1 Start WM P11. 2 Turn on GoGear Opus. 3 Connect GoGear Opus to the computer. 4 Click the down arrow beneath the Sync

tab, then select Philips GoGear Opus > Format.

English

Delete music tracks

From the main menu, select .

2 Press / to locate a track. 3 Press OPTIONS to view options menu. 4 Select the delete option to delete the

track.

6 Music

Listen to music

From the main menu, select to enter

music mode.

2 Navigate the sub-menus to select your

music.

3 Press to play.

Press •

to toggle between pause

and play.

Find your music

From the main menu, select to enter music mode. GoGear Opus offers the following menu options:

[All songs]

Alphabetically listed tracks•

[Artists]

Alphabetically listed ar tists• Alphabetically listed albums• Tracks listed in album order•

[Album art]

Alphanumerically listed album art•

[Albums]

Alphanumerically listed albums• Tracks listed in album order•

[Playlists]

• [Playlist-on-the-go]

Tracks listed in playlist order•

Note

Alternatively, you can select • from the main menu and nd your les in folder view.

Audiobook controls

GoGear Opus offers the following audiobook mode controls:

Goal Action

Play / pause Press Skip forward to beginning of

new section / chapter

Press

Skip back to beginning of current section / chapter

Press

Fast skip forwards through audiobook

Press and hold

Fast skip backwards through audiobook

Press and hold

Access options menu Press

OPTIONS

Return to browsing menu Press Increase / decrease volume Press VOL

Tip

You can resume play after navigating away • from audiobooks (see section Resume play in this user manual).

Select audiobook by book title

From the main menu, select to enter

music mode.

2 Press or , then to select

Audiobooks.

3 Press or , then to select option

Book titles or Authors.

4 Press or , then to make further

selections.

5 Press or to select title, then to play.

To exit, press »

7 Audiobooks

GoGear Opus supports books in audio format. The use of this feature requires that you download the AudibleManager from audible. com. With the AudibleManager you can manage the digital contents of your audiobooks. Visit audible.com and register. The onscreen instructions guide you through the

AudibleManager software download process.

Add audiobooks to GoGear Opus

• Important: GoGear Opus supports audiobook format 4.

1 On your computer, launch

AudibleManager.

2 Follow the online instructions to

download your audiobooks in format 4.

3 Follow the AudibleManager on-screen

instructions to activate GoGear Opus for your audiobooks.

4 Follow the AudibleManager on-screen

instructions to transfer your audiobooks to GoGear Opus.

Note

GoGear Opus can only play audiobooks in • format 4. GoGear Opus can only play audiobooks for

•

which it is activated.

English

Delete a bookmark in an audiobook

In audiobook play mode, press OPTIONS. Press

or , then to select Bookmarks.

Press

or , then to select Delete bookmark. Press

or to select the bookmark in the list. Press

to delete the selected bookmark.

To exit, press •

Adjust audiobook play speed

In audiobook play mode, press

OPTIONS.

2 Press or , then to select Playback

speed.

3 Press or , then to select Slower,

Normal, or Faster.

To exit, press •

Add a bookmark in an audiobook

In audiobook play mode, press

OPTIONS.

2 Press or , then to select

Bookmarks.

3 Press or , then to select Add

bookmark.

The display shows a conrmation » screen.

To exit, press »

Find a bookmark in an audiobook

In audiobook play mode, press Press

or , then to select Bookmarks.

Press

or , then to select Go to bookmarks. Press

or to select the bookmark in the list. Press

to go to the selected bookmark.

To exit, press

Delete videos

From the main menu, select .

2 Press / to locate a video. 3 Press OPTIONS to view options menu. 4 Select the delete option to delete the

video.

Note

Alternatively, you can select • from the main menu and nd your les in folder view.

8 Video

Download, convert and transfer videos

MediaConverter™ for Philips enables you to

download videos from the Internet to • your PC at the click of a button.

convert video les on your PC to the •

correct screen size of GoGear Opus. transfer conver ted videos from your PC • to GoGear Opus.

Note

Video conversion and transfer can take a long • time, depending on your PC conguration.

Play videos

From the main menu, select to enter

video mode.

2 Navigate the sub-menus to select your

video.

3 Press to play.

Press •

to toggle between pause

and play.

1 During video play, press and hold / to

scan fast forward / backward.

Press •

to resume play.

English

Delete pictures

From the main menu, select to enter

picture mode.

2 Press / to locate a picture. 3 Press OPTIONS to view options menu. 4 Select the delete option to delete the

picture.

Note

Alternatively, you can select • from the main menu and nd your les in folder view.

9 Pictures

View pictures

GoGear Opus supports a range of picture formats (see section Supported formats in this user manual).

1 From the main menu, select to enter

picture mode.

2 Press / to move to next / previous

picture.

View slideshow

While in mode, you can view your pictures as a slideshow:

1 Press to start the slideshow.

Tip

The menu • Settings offers various slideshow settings.

Add pictures to GoGear Opus

With GoGear Opus connected to

the USB port of the computer, open

Windows® Explorer.

2 Create folders in GoGear Opus. 3 Use drag and drop actions to sor t your

pictures into the folders.

Play a preset radio station

In mode, you can play previously set

radio stations (presets):

2 Press OPTIONS to view options menu. 3 Select preset. 4 Press / to change to another preset. 5 To search for the next stronger signal,

press and hold

/ for 2 seconds.

To exit radio, press and hold •

for

2 seconds.

Note

You can play presets only after you have • stored radio stations under presets. (See

Auto-tune preset radio stations or Manually tune a radio station in this user manual.)

10 Radio

Listen to FM radio

From the main menu, select to enter

radio mode.

The earphones cable acts as FM • antenna.

Manually tune a radio station

While in mode, you can manually tune to a radio station:

1 To search for the next stronger signal,

press and hold

/ .

2 To ne tune the frequency, briey press

/ .

Auto-tune preset radio station

The auto-tune feature of GoGear Opus helps

you nd radio stations and save them under the

preset numbers.

1 While in mode, select [Do you want to

auto-tune the presets?] > [Ye s].

The radio automatically tunes radio » stations and saves the frequencies to presets.

There are 20 presets available. » To stop auto tuning, press »

To exit radio, press and hold »

for 2

seconds.

English

4 Press / to select [ Yes] / [No]. 5 Press to save the recording.

Recordings are saved on the player. » (Filename format: VOICEXXX.MP3, where XXX is the recording number that is generated automatically.)

Tip

You can nd your recordings under •

[Recordings library] > [Voice].

Listen to FM recordings

From the main menu, select to enter

recordings mode.

2 Select [Recordings library] > [FM radio]. 3 Select a recording. 4 Press to play.

Listen to voice/audio recordings

From the menu select [Recordings

library] > [Voice].

2 Select a recording. 3 Press to play your recording.

Upload your recordings to a computer

Connect GoGear Opus to the computer

(see section Connect and charge in this user manual).

2 On the computer, in Windows®

Explorer select GoGear Opus.

3 Select Recordings > Voice or FM radio. 4 Copy and paste the recordings to any

location on the computer.

11 Recordings

Record from FM radio

From the main menu, select to enter

radio mode.

2 Select radio station (preset). 3 Press OPTIONS to view options menu. 4 Select [Start FM radio recording].

Press •

to toggle between pause

and record.

5 Press to stop.

The screen prompts you to save the » recording.

6 Press / to select [ Yes] / [No]. 7 Press to conrm.

Recordings are saved on the player. » (Filename format: FM_XX_XX_ XX.##, where XX_XX_XX is the recording date and ## is the recording number that is generated automatically.)

Tip

You can nd your recordings under •

[Recordings library] > [FM radio].

Record audio/voices

This is how you can record audio/voices with the built-in microphone (see section Overview for location of built-in microphone):

1 From the main menu, select to enter

recordings mode.

2 Select [Start voice recording].

Press •

to toggle between pause

and record.

3 Press to stop.

The screen prompts you to save the » recording.

Delete recordings

Use a computer to delete recordings from GoGear Opus:

1 Connect GoGear Opus to the computer

(for instructions see section Connect).

2 On the computer, in Windows®

Explorer select GoGear Opus.

3 Select Recordings > Voice or FM radio. 4 Select the recordings you want to delete. 5 On the computer, press Delete.

The selected recordings are deleted. »

English

12 Settings

This is how you customize GoGear Opus: From the main menu, select

to enter settings mode. In the

menu, navigate as follows:

1 Press / to select an option. 2 Press to conrm a selection and go to

the next level (when available).

3 Press to return to the previous level. 4 Press and hold to exit the menu.

In the

menu, the following options are

available:

Settings Options menu Sub-options menu [Play mode] [Shufe] • [Shufeoff] (default)

• [Shufeall]

[Repeat] • [Repeat off] (default)

• [Repeat 1]

• [Repeat all]

[Sound settings] [FullSound] • [FullSound equalizer setting enabled!] (default)

• [FullSound equalizer setting disabled!]

[Volume limit] Horizontal bar indicator. Press •

VOL to

adjust volume limit, then press

to conrm.

[Equalizer] • [Off] (default)

• [Rock]

• [Pop]

• [Jazz]

• [Classical]

• [Dance]

• [Electronica]

• [Lounge]

• [R&B]

• [Hip hop]

• [Spoken word]

• [Custom]

[Backlight] • [Always on]

• [[x] seconds]

[Brightness] Vertical bar indicator. Press

or to adjust brightness, then press to

conrm.

[Sleep timer] • [Off] (default)

xx • [mins]

[Language] • [English] (default)

French• German• Spanish• Italian• Portuguese (Brazilian)• Portuguese• Dutch•

Swedish• Norwegian• Finnish• Hungarian• Polish• Russian• Tur k ish• Czech•

Slovak•

Simplied Chinese•

Traditional Chinese• Japanese• Korean• Thai (97 version only)•

[Connect PC preference]

• [MSC]

• [MTP](default)

[Screensaver] • [Off] (default)

• [Clock]

[Date and time] [Time settings] • [Set time format]

• [Set time]

[Date settings] • [Set date format]

• [Set date]

[Show time in header]

[Skins] • [Dark] (default)

• [Red]

• [Light]

[Factory settings] [Restore factory

settings? (Files transferred to player will not be affected.)]

• [ Ye s]

• [No]

[Information] • [Capacity:]

• [Free space:]

• [Firmware version:]

• [Model:]

• [Support site:]

English

13 Update GoGear

Opus

GoGear Opus is controlled by an internal

program called rmware. Newer versions of the rmware may have been released after you

have purchased GoGear Opus. The software program called Philips Device Manager can use your computer to check for

rmware updates that are available on the

Internet. Install Philips Device Manager on your computer from GoGear Opus or download the latest version from www.philips.com/support.

Note

Your music les are not affected by a rmware •

update.

Manually verify / update

rmware

Ensure that your computer is connected

to the Internet.

2 Connect GoGear Opus to the computer

(see section Connect and charge for instructions).

3 On your computer, click Start >

Programs > Philips Digital Audio Player > Opus Device Manager to launch Philips Device Manager.

4 Click Update

» Philips GoGear Opus Device Manager

checks for updates and installs new

rmware from the Internet, if available.

5 When the display shows Update

completed, click OK.

6 Disconnect GoGear Opus from the

computer.

The display of GoGear Opus shows »

Updatingrmware

GoGear Opus restarts after the »

rmware is updated and is ready for

use again.

14 Troubleshooting

If GoGear Opus is not working properly or the display freezes, you can reset it without losing data:

How do I reset GoGear Opus?

Insert a pen tip or other object into • the reset hole located at the bottom of GoGear Opus. Hold until the player shuts down. If the reset option is unsuccessful, follow • the steps how to recover GoGear Opus with the Philips Device Manager:

1 On your computer, select Start >

Programs > Philips Digital Audio Player > Opus Device Manager > Philips Device Manager to launch the Philips Device Manager.

2 Turn off GoGear Opus before you

continue.

3 Press and hold the volume button

while you connect GoGear Opus to your computer.

4 Keep holding the key until the Philips

Device Manager acknowledges GoGear

Opus and enters the recovery mode.

5 On the computer, click the Repair

button and follow the instructions of the Philips Device Manager to complete the recovery process.

6 When the recovery is completed,

disconnect GoGear Opus from your computer.

7 Restart GoGear Opus.

English

Storage media

Built-in memory capacity²: SA1OPS08 8GB NAND Flash SA1OPS16 16GB NAND Flash SA1OPS32 32GB NAND Flash

Video transfer³ Drag and drop in Windows Explorer

Music transfer³ With Media Converter for Philips

Data transfer

Drag and drop in Windows Explorer

Display

Color LCD 320 x 240 pixels 262K colors

Note

¹ Rechargeable batteries have a limited number • of charge cycles. Battery life and number of charge cycles vary by use and settings. ² 1GB = 1 billion bytes; available storage

•

capacity is less. Full memory capacity may not be available as some memory is reserved for the player. Storage capacity is based on 4 minutes per song and 128 kbps MP3 encoding. ³ Transfer speed depends on operating system

•

and software conguration.

System requirements

Windows® XP (SP2 or above) / Vista• Pentium III 800 MHz processor or higher• 512 MB RAM• 500 MB hard disk space• Internet connection• Windows® Internet Explorer 6.0 or later• CD-ROM drive• USB port•

15 Technical data

Power

Power supply: 880 mAh Li-ion polymer internal rechargeable battery Play time¹ (music): 30 hours

Software on CD-ROM

Windows Media Player Philips Device Manager Media Converter for Philips

Connectivity

Headphone 3.5 mm USB 2.0 High speed

Sound

Channel separation: 45 dB Frequency Response: 20 Hz - 18 kHz Output power (RMS): 2 x 2.4 mW Signal to noise ratio: > 84 dB

Audio playback

Compression format: MP3 bit rates: 8 - 320 kps and VBR MP3 sample rates: 8, 11.025, 16, 22.050, 24, 32, 44.1, 48 kHz WMA bit rates: 5 - 192 kbps VBR WMA sample rates: 8, 11.025, 16, 22.050, 24, 32, 44.1, 48 kHz ID3-tag support Audible format suppor t

Video playback

MPEG4 SP: Up to 640 kbps, 320 x 240 pixels, 30 fps (other formats to be supported by provided Media Converter for Philips) WMV9: Up to 512 kbps, 320 x 240 pixels, 30 fps (other formats to be supported by provided Media Converter for Philips) Play time¹ (video): 6 hours

Recording

Audio capturing: Built-in microphoone (mono) FM radio

Supportedmusicleformats

GoGear Opus supports the following music formats:

MP3• PCM• ADPCM• Audible• WMA• M4A• FLAC•

Supportedvideoleformats

GoGear Opus supports the following video formats:

AVI• WMV (requires supplied • Windows Media Player)

Supportedpicturele

formats

GoGear Opus supports the following picture formats:

JPEG• PNG• GIF• BMP•

English

Analog sound can only be transmitted through two channels.

FLAC [Free Lossless Audio Codec]

An audio format similar to MP3, but lossless, meaning that audio is compressed in FLAC without loss in quality.

FM (Frequency Modulation)

In radio broadcasting: a method of modulation in which the frequency of the carrier voltage is varied with the frequency of the modulation voltage.

FullSound

FullSound™ is an innovative technology designed by Philips. FullSound™ faithfully restores sonic details to compressed music, enhancing it to provide a full sound experience without any distortion.

JPEG

A very common digital still picture format. A still-picture data compression system proposed by the Joint Photographic Expert Group, which features small decrease in image quality in spite of its high compression ratio.

Files are recognized by their le extension

‘.jpg’ or ‘.jpeg.’

Kbps

Kilobits per second. A digital-data-rate measurement system which is often used with highly compressed formats such as AAC, DAB, MP3 etc. The higher the amount, the better the quality generally is.

16 Glossary

Album art

Vorbis is a free and open source, lossy audio codec project and is intended to serve as a replacement for MP3. It is most commonly used in conjunction with the Ogg container and is therefore called Ogg Vorbis.

Album art

Album art is a feature that displays the artwork (cover picture) of a music album. This display enables the user to quickly identify

a music album. The artwork les for music

albums can be downloaded from the Internet.

APE

A lossless audio le compression format by

Monkey’s Audio that makes bit-for-bit copies

without sacricing quality.

Compression

In audio terms, this is a process of temporarily or permanently reducing audio data for more

efcient storage or transmission. A temporary reduction in le size is called ‘non-lossy’

compression, and no information is lost. A

permanent reduction in le size (such as with MP3 les) is called ‘lossy’ compression, and

involves discarding unnecessary information which is irretrievably lost.

Decibel (dB)

A unit of measure used to express relative difference in power or intensity of sound.

Digital Audio

Digital Audio is a sound signal that has been converted into numerical values. Digital sound can be transmitted through multiple channels.

SMV [SigmaTel Motion Video Format]

A partially compressed video format by SigmaTel that allows conversion of common

PC motion video les for play on a portable

multimedia player.

Stereo

Literally means solid. Usually taken to refer to two channel stereo, though developments in digital audio facilitate multichannel stereo.

SuperPlay

SuperPlay™ is a special feature of the GoGear Opus, which enables the listener to play all the music under a top-level library category, such as ar tists or albums, without having to select playlist items.

SuperScroll

SuperScroll™ is a navigation feature of the double-action search keys of the GoGear Opus. SuperScroll™ allows easy speed control when scrolling through large libraries to swiftly

nd items within large libraries. Longer press

of the button results in faster scroll speed.

Thumbnail

A thumbnail is reduced-size versions of a picture that is used to make it easier to recognize an them. Thumbnails serve the same role for images as a normal text index does for words.

Volume

Volume is the most common word used to specify the control of relative loudness of sounds. It also pertains to the function on many electronic devices that is used to control the loudness.

LCD (Liquid Crystal Display)

Probably the most common way to show visual information on non-computer electronic equipment.

MHz (Mega Hertz)

One million cycles per second.

MP3

A le format with a sound data compression

system. MP3 is the abbreviation of Motion Picture Experts Group 1 (or MPEG-1) Audio Layer 3. With the MP3 format, one CD-R or CD-RW can contain about 10 times more data than a regular CD.

Napster

Napster, Inc. (NASDAQ: NAPS, formerly Roxio, Inc.) is an online music service offering a variety of purchase and subscription models.

PCM (Pulse Code Modulation)

Pioneering form of digital recording.

PlaysForSure*

PlaysForSure* is a Philips GoGear feature that ensures compatibility with Windows Media Player 10 and Windows XP. The PlaysForSure* logo assures the consumer that the music purchased at an online shop with this logo is compatible with the Philips GoGear player.

Shufe

A feature that plays audio les (tracks) in

random order.

English

WAV

A format for sound les developed jointly by

Microsoft and IBM. Built into Windows 95 to XP, which made it the de facto standard

for sound on PCs. WAV sound les end with

a ‘.wav’ extension and works with nearly all Windows applications that support sound.

WMA (Windows Media Audio)

An audio format owned by Microsoft, is a part of Microsoft Windows Media technology. Includes Microsoft Digital Rights Management tools, Windows Media Video encoding technology, and Windows Media Audio encoding technology.

WMV [Windows Media Video]

Refers to a video compression technology developed by Microsoft Corporation. WMV content can be encoded by using Windows Media® Encoder 9 series. Files are recognised

by their le extension ‘.wmv’.

Alle rettigheder forbeholdes.

wk9303

SA1OPS_00_UM_V2.1

Philips GoGear SA1OPS08, SA1OPS08K/37, SA1OPS08K, GoGear SA1OPS16, GoGear SA1OPS32 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
