Philips HDD082, GoGearHDD082, GoGear HDD082/07 Specifications

For preview purpose only

Philips GoGear
Micro jukebox

2GB*

HDD082

My music, my way

Easiest-to-enjoy jukebox on the go

Enjoy your favorite MP3 and WMA music with the easy-to-use GoGear Micro Jukebox
HDD082. It's small enough to hide behind a credit card! Find your music fast with
SuperScroll navigation and make voice recordings with one button press.

Experience music - anytime, anyplace

• 2GB* to store up to 1000 songs

• Enjoy MP3 and WMA playback

• Enjoy more music with built-in FM tuner

• Small and wearable - weighing just 45 grams

• Large backlit display for comfortable viewing anywhere

Easy, intuitive music experience on the go

• SuperScroll™ navigation finds songs in a simple, fast way

• SuperPlay™ provides hassle-free one-touch jukebox playback

• Easily create and edit playlists on the go

Music and beyond

• Make voice recordings

• Firmware upgradeable

• Auto-synch with Windows Media Player

• PlaysForSure* with Windows XP only

For preview purpose only

Micro jukebox

2GB*

Technical specifications Product highlights

Picture/Display

• Backlight

• Backlight color: White

• Indications: Battery status, DBB

• Lines of text: 4

• Resolution: 96 x 64 pixels

• Type: LCD

Sound

• Bass enhancement: Digital Bass Boost

• Equalizer: 5-bands

• Equalizer customizable

• Equalizer settings: Classic, Jazz, Funk, Techno,
Hip Hop

• Frequency response: 20 - 20 000 Hz

• Sensitivity: < 100dB

• THD: 0.01-0.1%

• Output Power: 2x5mW (16 Ohm)

• Battery low indication

• Function: Keypad lock

• Language support:
Eng,Fr,Spa,NL,Ge,Port,Swe+more

• Superscroll

Accessories

• AC/DC Adaptor/Charger: Multi-voltage
(AY4108)

• CD-ROM: with installer, PC SW, manuals

• Headphones: SHE775

• Neck strap: AY4215

• Pouch: AY4232

• USB cable: AY3911

• User Guide on CD-ROM:
Eng,Fr,Spa,NL,Ge,Port,Swe

• Warranty Card

Green Specifications

Audio Playback

• Buffer memory: 16 MB

• Compression format: MP3, Windows Media™
Audio, WAV

• ID3 Tag support: Album indication, Album title
and artist name, Genre title, Track title and artist
name

• ID3-tag support

• MP3 bit rates: 8-320 kbps and VBR

• WMA bit rates: 32-192 kbps

• WMA sample rates:
8,11.025,16,22.050,32,44.1,48

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording

Storage Media

• Built-in memory type: Hard disk

• Hard Disk Capacity: 2* GB

• Mass storage class compliant

• Music memory capacity: Up to 1000 songs*

Connectivity

• Computer support: PC

• Connector: 3.5 mm stereo

• DC in: 5V

• Front / Side connections: DC-in, Headphone
out, USB type B port

• Headphone: 3.5 mm

• Internet connection options: Upgradeable

• USB: USB 2.0

• Lead-free soldered product

System Requirements

•CD-ROM drive

• Hard disk space: 100 MB

• PC OS: Windows XP (SP1 or above)

• Processor: Pentium II or better

• RAM memory: 64 MB

•Sound card

•Video card

Dimensions

• Box dimensions (W x H x D):
252 x 93 x 153 mm

• Master carton dimensions: 198 x 168 x 266 mm

• Master carton quantity: 2

• Product dimensions (W x H x D): 53 mm x 86
mm x 16.7 mm mm

• Product weight: 0.078 kg

• Packaging type: D-box

Power

• Adaptor type: 100 - 240 V

• Battery capacity: 610 mAh

• Battery Type: Li-ion

• Charging time: 4 hrs full charge hr

• Rechargeable

• Removable/ replaceable

Software

• Windows Media Player 10

• Device manager

Tuner/Reception/Transmission

Convenience

• Battery charging indication

• Battery full indication

• Frequency range: 87.5 - 108 MHz

• Station presets: 10

• Tuner Bands: FM

•

HDD082/07

SuperScroll™ navigation

Double action search keys allow easy speed control
when scrolling through large libraries. You can choose
to move through your playlist one song at a time or just
press and hold down a little harder to SuperScroll™
swiftly to your desired track.

SuperPlay™

SuperPlay™ lets you start enjoying your music quickly
without the hassle of first selecting playlists or individual
tracks. You can listen to all the music under top-level
music library categories, such as Artists or Albums, by
simply highlighting the category and pressing the Play
bu tt on. Th e j ukeb ox play s a ll th e m usic ac cordi ng to th e
category sort order. You can also combine SuperPlay™
with Shuffle and Repeat to further enhance your music
enjoyment.

PlaysForSure*

Enjoying your GoGear device is simple with PlaysForSure
which ensures compatibility with Windows Media Player
10 and Windows XP. Using Windows Media player
you can easily manage music on your GoGear digital
audio player and auto-synchronize your PC music
collection. Also, enjoy the widest online shopping
selection by simply looking for the PlaysForSure logo at
your choice of online store. Then rest assured knowing
any music you purchase there will work with your
GoGear player.

Date of issue 2006-06-28

Version: 1.0

12 NC: 9073 101 02546
UPC: 6 09585 11179 0

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.

www.philips.com
