Philips FWM998X/78 instructions for use
Register your product and get support at
www.philips.com/welcome
EN User manual
Contents
1 Important 4
Safety 4
Notice 5
2 Your Mini Hi-Fi System 6
Introduction 6
What’s in the box 6
Overview of the main unit 7
Overview of the remote control 9
3 Connect 10
Connect FM antenna 10
Connect AM antenna 10
Connect speakers 11
Connect power 11
4 Get started 12
Prepare the remote control 12
Auto install radio stations 13
Set clock 13
Turn on 13
5 Play 14
Play disc 14
Play from a USB device 14
Play from an SD card 15
Play from an external device 15
6 Play options 16
Repeat and random play 16
Program tracks 16
Display play information 16
7 Adjust volume level and sound
effect 16
Adjust volume level 16
Mute sound 16
Boost loudness 16
Select a preset sound effect 17
Enhance bass 17
Virtual surround 17
Customize sound for room acoustics 17
8 Listen to radio 18
Tune to a radio station 18
Program radio stations automatically 18
Program radio stations manually 18
Select a preset radio station 18
9 USB/SD record 19
Record to a USB/SD device 19
Record CDDA contents to USB/SD
device with high speed 19
Record CDDA contents to a USB/SD
device at any playback time 20
Schedule radio-to-USB/SD record 20
10 Other features 21
Set the alarm timer 21
Set the sleep timer 21
Listen to an external device 21
Delete from a USB/SD device 22
Copy files between SD and USB device 22
Karaoke 22
11 Product information 23
Specifications 23
USB playability information 24
Supported MP3 disc formats 24
Maintenance 24
English
12 Troubleshooting 25
EN
3
1 Important
Safety
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
j Only use attachments/accessories
specified by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and - •
as marked on the unit.
Do not mix batteries (old and new •
or carbon and alkaline, etc.).
Remove batteries when the unit is •
not used for a long time.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
q This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
r Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain
readily operable.
4
EN
Warning
Never remove the casing of this apparatus. •
Never lubricate any par t of this apparatus. •
Never place this apparatus on other electrical •
equipment.
Keep this apparatus away from direct sunlight,
•
naked flames or heat.
Never look into the laser beam inside this
•
apparatus.
Ensure that you always have easy access to the
•
power cord, plug or adaptor to disconnect this
appar atus from the power.
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
packaging materials, exhausted batteries and
old equipment.
English
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
This apparatus includes this label:
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
EN
5
2 Your Mini Hi-Fi
What’s in the box
System
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.Philips.com/welcome.
Introduction
With this unit, you can enjoy audio from discs,
USB devices, iPod players, external devices, or
radio stations.
For your convenience, you can load up to three
discs at once.
To enrich sound, this unit offers you these
sound effects:
MAX sound for instant power boost•
Digital Sound Control (DSC)•
Dynamic Bass Boost (DBB)•
Incredible surround (IS)•
Virtual Ambience-based Control (VAC)•
The unit supports the following media formats:
Check and identify the contents of your
package:
Main unit x 1•
AC power cable x 1•
Power plug adaptor x 1•
Front speakers x 2•
Rear speakers x 2•
Subwoofers x 2•
Remote control with 2 AAA batteries•
FM wire antenna x 1•
AM loop antenna x 1•
MP3 link cable x 1•
Quick star t guide x 1•
User manual x 1•
6
EN
Overview of the main unit
n
English
a
b
c
d
e
f
g
h
i
j
k
l
m
o
p
q
€
~
}
|
{
z
y
x
w
k
v
m
u
t
s
p
q
r
a
Turn on the unit or switch to •
standby mode.
b DISPLAY
Select display information.•
c MODE
Select repeat play or random play.•
d Source selection keys
Select a source.•
e USB RECORD
Record to a USB device.•
f USB to SD
Copy audio files from a USB device •
to an SD card.
7
EN
g USB DELETE
Delete audio files stored on a USB •
device.
h VOLUME
Adjust volume.•
i DSC
Select a preset sound equalizer •
setting.
j DISC 1/2/3
Select a disc.•
k
/
Skip to the previous/next track.•
Search within a track/disc/USB/SD •
device/DOCK.
Tune to a radio station.•
Adjust time.•
l
Stop play or erase a program.•
m ALBUM/PRESET+/-
Skip to the previous/next album.•
Select a preset radio station.•
Adjust time.•
Select 12 hour or 24 hour format.•
n OPEN/CLOSE
Open or close the disc •
compartment.
o Disc compartment door
p MIC VOL
Adjust microphone volume.•
q Microphone port
Jack for a microphone.•
r
Jack for a USB mass storage device. •
s MP3 LINK
Audio input jack (3.5mm) for an •
external audio device.
t SD card slot
u DISC CHANGE
Change a disc.•
v
Star t or pause play.•
w MAX SOUND
Turn on or off instant power boost •
for sound.
x VAC
Select an ambiance-based equalizer •
setting.
y IS
Turn on or off incredible surround.•
z DBB
Turn on or off dynamic bass •
enhancement.
{ SD DELETE
Delete audio files stored on an SD •
device.
| SD RECORD
Record to an SD card.•
} SD to USB
Copy audio files from an SD card to •
a USB device.
~ PROG
Program tracks.•
Program radio stations.•
CLOCK
Set the clock/View the clock.•
€ LIGHT
Turn on or off the lighting effect.•
Display panel
Show status.•
8
EN
Overview of the remote
control
{
z
y
x
w
v
v
u
a
Turn on the unit or switch to •
standby mode.
b Source selection keys
Select a source.•
c SLEEP
Set the sleep timer.•
d MODE
Select repeat play or random play.•
e USB DELETE
Delete audio files stored on a USB •
device.
f MUTE
Mute volume.•
g USB RECORD
Record to a USB device.•
h
Star t or pause play.•
i
/
Skip to the previous/next track.•
j USB to SD
Copy audio files from a USB device •
to an SD card.
k ALBUM/PRESET+/-
Skip to the previous/next album.•
Select a preset radio station.•
Adjust time.•
Select 12 hour or 24 hour format.•
l Numeric keypad
Select a track from a disc directly.•
m PROG
Program tracks.•
Program radio stations.•
n MAX SOUND
Turn on or off instant power boost •
for sound.
o DSC
Select a preset sound equalizer •
setting.
English
EN
9
