Philips FWM185 User Manual

Mini Hi-Fi System

FWM185

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

2 1

4 ( 3

8 $

≤

™

¡ £ )

! ≤

™

Contents

English

General Information

Supplied accessories ............................................ 5

Environmental Information ................................ 5

Safety information ................................................ 5

Preparation

Rear connections ................................................. 6

Optional connection ........................................... 7

Inserting batteries into the remote control... 7

Controls

Controls on the system and remote

control .................................................................... 8

Basic Functions

Switching the system on ..................................... 9

Power-saving automatic standby ....................... 9

Adjusting volume and sound.............................. 9

CD/MP3/WMA Operation

Playing a disc ........................................................ 10

Selecting a different track ................................. 10

Finding a passage within a track ...................... 10

Playing an MP3/WMA disc ......................... 10-11

Discs for playback .............................................. 11

Different play modes: Shuffle and Repeat ..... 11

Programming track numbers ........................... 11

Erasing the programme ..................................... 11

Ta pe Operation/Recording

Ta pe playback ...................................................... 13

General information on recording ................. 13

Synchro start CD recording ............................ 13

Recording from the radio................................. 14

Recording from external sources................... 14

External Sources

Using a USB mass storage device ............. 15-16

Connecting external equipment ..................... 16

Clock/Timer

Setting the clock ................................................. 17

Setting the sleep timer ...................................... 17

Setting the timer ................................................. 18

Specifications ........................................... 19

Maintenance.............................................. 20

Tr oubleshooting .............................. 21-22

Radio Reception

Tuning to radio stations .................................... 12

General Information

Supplied accessories

–2 speaker boxes – remote control – MW loop antenna

Environmental Information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Safety Information

● Before operating the system, check that the

operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer.

● Place the system on a flat, hard and stable

surface.

● Place the system in a location with adequate

ventilation to prevent internal heat build-up in your system. Allow at least 10 cm (4 inches) clearance from the rear and the top of the unit and 5 cm (2 inches) from each side.

● The ventilation should not be impeded by

covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc.

● Do not expose the system, batteries or discs to

excessive moisture, rain, sand or heat sources caused by heating equipment or direct sunlight.

● No naked flame sources, such as lighted candles,

should be placed on the apparatus.

● No objects filled with liquids, such as vases, shall

be placed on the apparatus.

● The apparatus shall not be exposed to dripping

or splashing.

● Install this unit near the AC outlet and where the

AC power plug can be reached easily.

● If the system is brought directly from a cold to a

warm location, or is placed in a very damp room, moisture may condense on the lens of the disc unit inside the system. Should this occur, the CD player would not operate normally. Leave the power on for about one hour with no disc in the system until normal playback is possible.

● The mechanical par ts of the set contain self-

lubricating bearings and must not be oiled or lubricated.

● When the system is switched to Standby

mode, it is still consuming some power. To disconnect the system from the power supply completely, remove the AC power plug from the wall socket.

The making of unauthorized copies of copyprotected material, including computer programmes, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offence. This equipment should not be used for such purposes.

English

Preparations

English

FM ANT

LOOP ANT

LOW CH – +

HIGH CH

Rear connections

The type plate is located at the rear of the system.

A Pow er

– Before connecting the AC power cord to the wall outlet, ensure that all other connections have been made.

WARNING! –For optimal performance, use only the original power cable. –Never make or change any connections with the power switched on. – High voltage! Do not open.You run the risk of getting an electric shock. – The machine does not contain any userserviceable parts. – Modification of the product could result in hazardous radiation of EMC or other unsafe.

To avoid overheating of the system, a safety circuit has been built in. Therefore, your system may switch to Standby mode automatically under extreme conditions. If this happens, let the system cool down before reusing it (not available for all versions).

B Speakers Connection

Front Speakers

Connect the speaker wires to the SPEAKERS terminals, right speaker to "R" and left speaker to "L", red wires to "+" and black wires to "-" of the woofer connection terminals, blue wires to "+" and grey wires to "-" of the tweeter connection terminals.

● Fully insert the stripped portion of the speaker

wire into the terminal as shown.

Notes: –For optimal sound performance, use the supplied speakers. – Do not connect more than one speaker to any one pair of +/- speaker terminals. – Do not connect speakers with an impedance lower than the speakers supplied. Please refer to the SPECIFICATIONS section of this manual.

Preparations

C Antenna Connection

Connect the supplied MW loop antenna to the respective terminal. Adjust the position of the antenna for optimal reception.

MW Antenna

● Position the antenna as far as possible from a TV,

VCR or other radiation source.

Optional connection

The optional equipment and connecting cords are not supplied. Refer to the operating instructions of the connected equipment for details.

Connecting a USB device or memory card

By connecting a USB mass storage device (including USB flash memory, USB flash players or memory cards) to the Hi-Fi system, you can enjoy the device's stored music through the powerful speakers of Hi-Fi system.

● Inser t the USB device's USB plug into the

socket on the set.

2 Use a USB cable (not supplied) to connect the

card reader into the

Connecting a non-USB device

Use a cinch cable to connect MP3 PLAYER IN to the analogue audio out terminals of an

external equipment (TV, VCR, Laser Disc player, DVD player or CD Recorder).

socket on the set.

Inserting batteries into the remote control

Insert two batteries type R03 or AAA into the remote control with the correct polarity as indicated by the “+”and“-” symbols inside the battery compar tment.

CAUTION! – Remove batteries if they are exhausted or will not be used for a long time. – Do not use old and new or different types of batteries in combination. – Batteries contain chemical substances, so they should be disposed of properly.

English

For the devices with USB cables:

1 Insert one plug of the USB cable (not supplied)

to the socket on the set.

2 Insert the other plug of the USB cable to the

USB output terminal of the USB device.

For the memory card:

1 Insert the memory card into a card reader (not

supplied).

Controls (illustrations on page 3)

English

Controls on the system and remote control

1 LCD Display

– shows the status of the system.

2 iR SENSOR

– infrared sensor for remote control.

3 PROG

– programs CD tracks and reviews the program.

4 ECO POWER/STANDBY ON y

– switches the system on or to Eco power/normal

standby mode.

5 2;

– starts or pauses CD/USB playback.

6 ¡1 / 2™

– skips to the beginning of a current track/

previous/ next track.

– (press and hold) fast searches back and forward

within a track/disc.

7 Source (CD/ TAPE/TUNER/USB/MP3 IN)

– selects the respective sound source for CD/

TAPE/ TUNER/USB/MP3 IN.

8 CLOCK

– sets the clock.

9 BAND (MW/FM ST/FM MONO)

– selects waveband: MW, FM (stereo) or FM

(mono).

0 OPEN/CLOSE

– open/close the CD door.

! STOP 9

– stops CD/USB playback or erases a CD

program.

@ TUNING

– tunes to a radio station.

# USB DIRECT

– connects an external USB mass storage device.

$ DBB (Dynamic Bass Boost)

– enhances the bass.

% VOLUME 3/4

– adjusts the volume level.

– sets the hours and minutes for the clock and

timer.

^ MP3 PLAYER IN

– 3.5mm audio input jack.

& Ta pe Deck Operation

RECORD 0 ....... star ts recording.

PLAY 2 ................. starts playback.

REW à /F.FWD á fast rewinds/

forwards the tape.

STOP•OPEN 9/ stops the tape;

opens the tape compartment.

PAUSEÅ ............ pauses recording or playback.

* ALBUM +/-

– selects an album.

( MODE

– selects different play modes: e.g. REPEAT or

SHUFFLE (random order)

) TIMER/SLEEP

– activates/deactivates the timer

– activates/deactivates or selects the sleep time.

– views the remaining sleep time.

¡ MUTE

– switches playback sound off and on.

™ 5/6

– skips to the beginning of a current track/

previous/ next track (title).

– (press and hold) fast searches back and forward

within a track/disc

£ DSC (Digital Sound Control)

– selects sound characteristics: OPTIMAL, JAZZ,

ROCK or TECHNO.

≤ í/ë

– skips to the beginning of a current track/

previous/next track (title).
