Page 1
EN Executive edition Click here 2
FR Executive edition Cliquez ici X
DE Executive edition Hier klicken X
ES Executive edition Haga clic aquí X
NL Executive edition Hier clicken X
IT Executive edition Fare clic qui X
PR Executive edition Clique aqui X
RU Executive edition
фВОНМЛЪ Á‰ÂÒ¸
X
FMXXFD10B/00
Register your product and get support at
www.philips.com/welcome
USB Flash Drive
Page 2
1 Important
Note:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• onsult the dealer or an experienced radio/TV technician for help.
The shielded interface cable and connectors must be used in order to
comply with the limits for digital device pursuant to subpart B of Part
15 of FCC Rules.
Electric-, Magnetic- and Electromagnetic Fields (EMF)
Philips Royal Electronics manufactures and sells many products
targeted at consumers, which, like any electronic apparatus,in
general have the ability to emit and receive electro magnetic
signals.
One of Philips’ leading Business Principles is to take all necessary
health and safety measures for our products,to comply with all
applicable legal requirements and to stay well within the EMF
standards applicable at the time of producing products.
Philips is committed to develop,produce and market products that
cause no adverse health effects.
Philips confirms that if its products are handled properly for their
intended use, they are safe to use according to scientific evidence
available today.
Philips plays an active role in the development of international EMF
and safety standards, enabling Philips to anticipate further
developments in standardization for early integration in its
products.
Note: Keep this detailed user manual for future reference.
Warning
• To prevent fire or shock hazard, do not expose the unit to rain or
moisture.
• To avoid electric shock,do not open the cabinet. Refer servicing to
qualified personal only.
• Keep away from children. If swallowed, promptly see a doctor.
5
4
3
2
1
2
ENGLISH
Page 3
Note
Data is safe in the following environments:In X-ray security systems at
airports and in magnetic fields with strengths not exeeding 3,500 Oe.
For customers in the U.S.A.
Changes or modifications made to this equipment not expressly
approved by company may void the FCC authorization to operate this
equipment.
Operation is subject to the following two conditions:
this device my not cause harmful interference, and
this device must accept any interference received,including
interference that may cause undesired operation.
Caution
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
For customers in Canada
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with Part 15 of the FCC Rules and with RSS-210
of Industry Canada.
For customers in Europe
This product conforms to the following European Directives:
89/336/EEC, 2006/95/EEC (safety directive) and 93/68/ECC (EC
Marking Directive).This product complies with EN55022 Class B and
EN55024 for use in the following areas;residential, commercial, and
light-industrial.
Notes on Use
• The USB flash drive may not function correctly if it is connected to
the computer when the computer is started up, restarted, or
restored from sleep mode.Always disconnect the USB flash drive
from the computer before performing any of these operations.
• Do not place the drive in locations that are:
– extremely hot or cold;
– vibrating;
– exposed to corrosive gases;
– dusty or dirty;
– very humid;
– exposed to direct sunlight.
• Microsoft and Windows are registered trademarks of Microsoft
Corporation in the United States and other countries.
• Mac and Macintosh are trademarks of Apple Computer,Inc.,
registered in the U.S.and other countries.
• Other system names and product names that appear in this manual
are registered trademarks or trademarks of their respective
owners. Note that the ™ and ®symbols are not used in this
manual.
• Power consumption in standby mode:< 100 mA.
•
To help maintain the luster and beauty of your Active Crystals piece
of time, carefully polish the product with soft, lint-free cloth.
Avoid contact with harsh cleansers.
• The Company cannot accept any liability for financial damages,lost
profits, claims from third parties, etc.,arising from the use of the
software provided with this unit.
• The software specifications may be subject to change without
notice.
• For detailed warranty instructions, please refer to the printed
certificate booklet.
2
1
3
ENGLISH
Page 4
• Our product warranty is limited only to the USB flash drive itself,
when used normally in accordance with these operating instructions
and with the accessories that were included with this unit in the
specified or recommended system environment.Services provided
by the Company, such as user support,are also subject to these
restrictions.
• The Company cannot accept liability for damage or loss resulting
from the use of this unit, or for any claim from a third party.
• The Company cannot accept any liability for: problems with your
computer or other hardware arising from the use of this product;
the suitability of this product for specific hardware,software, or
peripherals; operating conflicts with other installed software; data
loss; or other accidental or unavoidable damage.
• The Company cannot accept any liability for financial damages,lost
profits, claims from third parties, etc.,arising from the use of the
software provided with this unit.
• The software specifications may be subject to change without
notice.
Environmental information
Disposal of your old product
Your product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for
electrical and electronic products.Please act according to your local
rules and do not dispose of your old products with your normal
household waste.The correct disposal of your old product will help
prevent potential negative consequences for the environment and
human health.
The making of unauthorized copies of copy-protected material,
including computer programmes, files, broadcasts and sound
recordings, may be an infringement of copyrights and constitute a
criminal offence. 186
This equipment should not be used for such purposes.
4
ENGLISH
Page 5
2 Your USB flash drive
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers, register your
product at www.philips.com/welcome.
3 Install
Microsoft®Windows Vista,XP,2000, ME, MAC OS 9.0 or
higher:
• The device driver is installed automatically when the drive is
connected to a USB port of the computer. However, with some USB
2.0 cards or boards, you may need to initiate installation manually. In
this case, follow the on-screen instructions to search for a suitable
driver. Refer to the operating system's Help file if you need any
help.
Note
Do not remove USB flash drive from the computer USB port as long
as the download process is in progress.
Be sure that the write
protection switch (fig. 2) is in the unprotected (left) position
during installation.
Windows 98/98SE:
Download the device driver at
http://www.philips.com/storage.
Remove the protective cap from the USB connector and turn
it backwards (fig. 1).
Insert the flash drive USB connector into one of the computer’s
USB ports (fig. 2).
> The New Hardware wizard starts and the drive’s LED lights up.
The light intensity of the LED will gradually increase and then
diminish again.This will continue for as long as the drive is
connected to the computer.
Click the Next button.
4
3
2
1
5
ENGLISH
②
①
1
2
Page 6
Click Search for the best driver for your device.Then click
the Next button.
Click Specify a location.Then click the Browse button.
When the dialog box appears,specify the folder where the
installation program is stored.
Click the OK button to close the dialog box.Then click the
Next button.
Click the Next button.
Click the Finish button.
> Installation of the driver starts.
> Once the installation process is complete, a drive icon for the
USB flash drive appears in the My Computer window.
After confirming that the drive is in standby mode you can remove
the drive from the computer’s
USB port.
Note
Do not remove the drive from the computer USB port as long as
the download process is in progress. Be sure that the write protection
switch (fig. 2) is in the unprotected (left) position
during installation.
4 Connect
Connecting the USB flash drive to your computer
Note
If the USB por
t of your computer is not easily accessible,You can use a
USB extension cable or an optional USB hub to connect the USB flash
drive to your computer.
Remove the protective cap from the USB connector and turn
it backwards (fig. 1).
1
11
10
9
8
7
6
5
6
ENGLISH
②
①
1
Page 7
Insert the USB flash drive’s USB connector into one of the
computer’s USB ports (fig. 2).
> The USB flash drive’s LED lights up.The light intensity of the
LED will gradually increase and then diminish again.This will
continue for as long as the drive is connected to the computer.
5 Enjoy
Operating the USB flash drive
• Once the USB flash drive is connected to the USB port of the
computer:
– a software package will automatically start up enabling you to
activate various applications. See the software help file for futher
instructions.
Visit our website www.philips.com/storage for software related
questions and software updates.
– the drive icon for the USB flash drive will appear.You can now
copy and save data on the drive by dragging files and folders on
the drive icon, just like when you copy data to a hard disk,
CD-ROM,DVD or floppy disk.
> When copying data the LED’s light intensity will quickly
increase and diminish.
Windows ReadyBoost
Windows ReadyBoost is a Microsoft Windows Vista™ feature that
expands memory size for your Windows Operating system and
improves the performance of your computer by utilizing the capacity
of an unused flash memory device, such as a USB flash drive.
The Flash memory serves as an additional memory cache.This is a
memory area where frequently accessed data can be stored for rapid
access.
2
7
ENGLISH
2
Page 8
To be able to use Windows ReadyBoost your computer must have:
– Windows Vista™ installed;
– a USB 2.0 port;
– access to a flash memory device with at least 1GB available storage.
Using Windows ReadyBoost
• Insert the flash drive USB connector into one of the computer’s
USB ports (fig. 2).
> Windows Vista now checks to see if the flash drive’s
performance is fast enough to work with Windows ReadyBoost.
If so, you are asked if you want to use the flash drive to speed up
system performance: the Windows Vista AutoPlay dialog box will
offer the option of using the device for ReadyBoost.
• You can choose to allocate part of the flash drive’s memory to
speed up performance and use the remainder to store files.
Once a flash drive has been assigned as the ReadyBoost flash drive
you can no longer use it to save files, play music or retrieve video
and pictures.
Notes
• Do not remove the USB flash drive from the computer USB port
while copying and saving data otherwise the drive will no longer be
recognized by your system.
• When operating under Windows the drive name varies, depending
on your Windows version.
Disconnecting the USB flash drive from your computer
Windows®98/
98SE
• After confirming that the USB flash drive is in standby mode you can
remove the flash drive from the computer’s USB port.
Windows®ME and Windows®2000
Double-click the Unplug or eject hardware icon in the task bar
in the lower right part of the screen.
In the window that appears, select the name of the device that is to
be removed,then click the STOP button.
When the Stop a hardware device screen appears, make sure
the correct information is displayed, then click the OK button.
When a message appears, indicating that the USB flash drive can be
safely removed,remove the USB flash drive from the computer’s
USB port.
Windows®Vista, XP
Double-click the Safely Remove Hardware icon in the task bar
in the lower right part of the screen.
In the window that appears, select the name of the device that is
to be removed,then click the STOP button.
When the Stop a hardware device screen appears, make sure
the correct information is displayed, then click the OK button.
When the message Safe to Remove Hardware appears, remove
the the USB flash drive from the computer’s USB port.
4
3
2
1
4
3
2
1
8
FRANÇAIS
Page 9
Mac OS 9.0 and higher
Drag the drive icon to the Trash.
After confirming that the the USB flash drive is in standby mode,
remove the the USB flash drive from the computer’s USB port.
6 Technical specifications
Interface
• High-Speed USB 2.0 (backwards compatible with USB 1.1)
Transfer rate
• Read: max. 25MB per second / Write: max. 15MB per second (High-
speed USB 2.0 port required to achieve maximum speed)
Compatible OSs
• Microsoft® Windows®Vista, XP, 2000,ME and 98SE (with driver)
• Mac OS 9.0 or later
• Linux 2.4.0 or later
7 Need help?
Online help: www.philips.com/support
For interactive help and frequently asked questions.
For software updates and support: www.philips.com/storage.
2
1
9
ENGLISH
Page 10
© 2007 Koninklijke Philips Electronics N.V.
All rights reserved. Reproduction in whole or in part is prohibited
without the prior written consent of the copyright owner.
The information presented in this document does not form part of any
quotation or contract,is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the
publisher for any consequence of its use. Publication there of does not
convey nor imply any license under patent- or other industrial or
intellectual property rights.
3222 xxx xxxx
June 2007
www.philips.com NMW/RR/RD/2507
Loading...
