Page 1

Fidelio

Soundbar FB1

User manual

www.philips.com/support

Page 2

Contents

1 Important safety instructions 3

Safety 3 Care for your product 4 Care of the environment 4 Declaration of conformity 5 Help and support 5 FCC information 6

2 Your Soundbar 7

What’s in the box 7 Main unit 7 Connectors 8 Remote control 9 Prepare the remote control 10 Placement 11 Wall mount 11

3 Connect 12

Dolby Atmos® 12 Connect to HDMI Socket 12 Connect to Optical Socket 13 Connect the IR pass-through cable 13 Connect to Power 14 Pairing with Subwoofer (FW1) via proprietary RF link 14 Connect to Wi-Fi (Wireless Operation) 14 Connect the soundbar to Philips

Play- enabled TV 17

5 Product specications 26

6 Troubleshooting 28

Trademarks: 30

4 Use your Soundbar 18

Turn ON and OFF 18

Select Modes 18

Adjust the Volume 18

Enjoy Dolby Atmos sound 18 Choose your Sound 19 Setup Menu 21 Play from Bluetooth devices 23 Listen to an external device 24 Play audio through USB 24 Listen to Spotify 25 Factory Reset 25

2 EN

Page 3

1 Important

safety instructions

Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply.

Safety

Know these safety symbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This is CLASS II apparatus with

double insulation, and no protective earth provided.

AC voltage

Follow the instructions in the user

manual!

WARNING!

Warning: Risk of electric shock!

The exclamatory mark is intended

to alert the user to the presence of important operating instructions.

Risk of electric shock or re!

• Before you make or change any connections, make sure that all devices are disconnected from the power outlet.

• Never expose the product and accessories to rain or water. Never

place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it

from the power outlet immediately. Contact Consumer Care to have the product checked before use.

• Never place the product and accessories near naked ames or other

heat sources, including direct sunlight.

• Never insert objects into the

ventilation slots or other openings on the product.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• Battery (battery pack or batteries installed) shall not be exposed to

excessive heat such as sunshine, re

or the like.

• Disconnect the product from the power outlet before lightning storms.

• When you disconnect the power cord, always pull the plug, never the cable.

• Use the product in tropical and/or moderate climates.

Risk of short circuit or re!

• For identication and supply ratings,

see the type plate at the back or bottom of the product.

• Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the

product. Never connect the product

to the power outlet if the voltage is

dierent.

Risk of injury or damage to this

product!

• For wall mounting, this product must be securely attached to the wall in accordance with the installation instructions. Use only the supplied wall mount bracket (if available). Improper wall mounting may result in accident, injury or damage. If you have any query, contact Consumer Care in your country.

3EN

Page 4

• Never place the product or any

objects on power cords or on other electrical equipment.

• If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet.

• Parts of this product can be made of glass. Handle with care to avoid injury and damage.

Risk of overheating!

• Never install this product in a conned space. Always leave a

space of at least four inches around the product for ventilation. Ensure curtains or other objects never cover the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new or carbon and alkaine, etc.).

• CAUTION: Danger of explosion if

batteries are incorrectly replaced. Replace only with the same or equivalent type.

• Remove batteries if they are exhausted or if the remote control is not to be used for a long time.

• Batteries contain chemical substances, they should be disposed of properly.

Note

•

The rating label is pasted on the bottom or back

of the equipment.

Care for your product

Use only microber cloth to clean the

product.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

This symbol on a product means

that the product is covered by European Directive 2012/19/EU.

This symbol means that the

product contains batteries covered by European Directive 2013/56/EU which cannot be disposed of with normal household waste.

Inform yourself about the local separate collection system for electrical and electronic products and batteries. Follow local rules and never dispose of the product and batteries with normal household waste. Correct disposal of old products and batteries helps prevent negative consequences for the environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see

battery installation section.

4 EN

Page 5

For 5G Wi-Fi Device

The device for operation in the

band 5150–5350 MHz is only for indoor use to reduce the potential for harmful interference to cochannel mobile satellite systems.

Pour un appareil Wi-Fi 5G

les dispositifs fonctionnant dans la bande 5150-5350 MHz sont réservés uniquement pour une

utilisation à l’intérieur an de

réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.

Declaration of conformity

This product complies with the radio

interference requirements of the European community.

Hereby, MMD Hong Kong Holding

Limited declares that the product is in compliance with the essential requirements and other relevant provisions of RED Directive 2014/53/EU

and UK Radio Equipment Regulations SI 2017 No 1206. You can nd the

Declaration of Conformity on www.philips.com/support.

Help and support

For extensive online support, visit

www.philips.com/support to:

• download the user manual and the quick start guide

• watch video tutorials (available only for selected models)

• nd answers to frequently answered questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select your language, and then enter your product model number.

Alternatively, you can contact Consumer Care in your country. Before you contact, note down the model number and serial

number of your product. You can nd

this information on the back or bottom of your product.

5EN

Page 6

FCC information

NOTE: This equipment has been tested

and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to

try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an

outlet on a circuit dierent from that

to which the receiver is connected.

• Consult the dealer or an experienced

radio / TV technician for help.

FCC&IC Warning:

• This equipment should be installed

and operated with minimum distance 20cm between the radiator & your body.

• Changes or modications to this unit

not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

et votre corps. Cet transmetteur ne doit pas être co-situé ou opérant en liaison avec toute autre antenne ou transmetteur.

• Des câbles blindés doivent être utilisés avec cet apparei l pour assurer la conformité avec les limites de la classe B de la FCC. fonctionnement de I’appareil.

IC-Canada: CAN ICES-003(B)/NMB003(B)

This device contains licence-exempt

transmitter(s) / receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the

following two conditions:

1 This device may not cause

interference.

2 This device must accept any

interference, including interference that may cause undesired operation of the device.

Avis d’Industrie Canada: CAN ICES003(B)/NMB-003(B)

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est

conforme aux CNR d’Innovation, Sciences

et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée

aux deux conditions suivantes :

1 L’appareil ne doit pas produire de

brouillage;

2 L’appareil doit accepter tout

brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

FCC & IC Attention

• Cet appareil est conforme à FCC et

IC l’exposition aux rayonnements

limites xées pour un environnement

non contrôlé. Cet appareil doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur

6 EN

Page 7

2 Your Soundbar

FB1/96 FB1/37 FB1/10 FB1/98

FB1/93

Congratulations on your purchase,

and welcome to Philips! To fully benet from the support that Philips oers, register your soundbar at

www.philips.com/support.

What’s in the box

Check and identify the items in the

package:

• Soundbar x 1

• IR pass-through Cable x 1

• Remote control x 1

(AAA batteries x 2)

• Microphone x 1

• Power cord * x 1

• Wall mount kit x 1

(Brackets x2 / Bracket screw x2 / Wall mounting screws x2 / Wall anchors x2)

• Quick start guide / Warranty card /

Safety sheet / Wall mount template x 1

ATM

Remote control

(AAA batteries x 2)

CCC

Soundbar

Wall mount kit x1

(brackets x2/bracket screw x2/

wall mounting screws x2/

wall anchors x2)

BSMI

2 X

VDEBS

IR pass-through

er S

N T C

Quick start guide

VDEBSSAA

Mic

e n o

h p

ead

es i

Cable

atio

rm fo n I

y t

Safe

Warranty card/Safety sheet

Wall mount template

• Images, illustrations and drawings shown on this User Manual are for reference only, actual product may vary in appearance.

Main unit

This section includes an overview of the

main unit.

1 2 3 4 5

ATM O

- (Volume) button

Decrease the volume.

+ (Volume) button

Increase the volume.

(Play/Pause) button

Start, pause or resume play.

(Source)/Bluetooth pairing button

• Press to select an input source for

soundbar.

• In BT mode, press and hold for 3

seconds to disconnect from current

BT connected devices and enter the

Bluetooth pairing mode.

for China

for Taiwan

for US/Canada

for Europe/UK

• Power cord quantity and plug type vary by regions.

for Asia

7EN

Page 8

(Standby-On) button

Power State

On Follow source state

Semi Standby

Eco Standby

Remote control sensor /

Action Function

Press the button once

Press and hold

seconds

• Wi-Fi is connected.

• It supports Play-

and Airplay2 Chromecast, Spotify connect, work with Alexa.

• Wi-Fi is o.

• The product enters

the lower power consumption mode.

• Restarting the system will take a relatively longer time.

Display panel

Audio light ring (White)

When the height channel (such as Dolby Atmos) audio output is detected, the audio light ring will

turn on for 10 seconds and turn o.

If you want the audio light ring to

be ON or OFF, it can be dened by

“LIGHT” in the setup menu.

Power LED

Turns white when in Eco standby

(network disconnected).

Wi-Fi LED indicator (Yellow)

LED State Status

Blink Wi-Fi Access Point (AP)

Double blink Wi-Fi Protected Setup

Constant on Connected / Pairing

8 EN

mode

(WPS) mode

successful

Connectors

This section includes an overview of the

connectors available on your soundbar.

Mic in

IR out

1 2 3 4 5 6 7

(Wi-Fi Setup) button

• Trigger Wi-Fi setup for Play-.

• Press and hold the button for 3

seconds to active the Wps mode.

• Press and hold the button for 8 seconds to active the AP mode.

Mic in

Microphone input for auto room calibration.

IR out

IR pass-through cable connector.

USB

• Connect to a USB storage device for

audio media play.

• Upgrade software of this product.

Optical

Connect to an optical audio output

on the TV or a digital device.

HDMI out (eARC/ARC) Socket

Connect to the HDMI (eARC/ARC)

input on the TV.

HDMI in Socket

Connect to the HDMI source devices,

such as a DVD player, Blu-ray Disc™

player, or gaming console.

AC Socket

Connect to the power supply.

Wall bracket slot

Page 9

Remote control

This section includes an overview of the

remote control.

4 5 6

(Standby-On) button

Power State

On Follow source state

Semi Standby

Eco Standby

Action Function

Press the button once

Press and hold

seconds

• Wi-Fi is connected.

• It supports Play-

and Airplay2 Chromecast, Spotify connect, work with Alexa.

• Wi-Fi is o.

• The product enters

the lower power consumption mode.

• Restarting the system will take a relatively longer time.

(Source)

• Press to select an input source for

soundbar.

• In BT mode, press and hold for 3

seconds to disconnect from current

BT connected devices and enter the

Bluetooth pairing mode.

Navigation buttons

/ (Left/Right)

• Skip to the previous or next track in

USB/BT/Play- mode.

• Navigate left/right in menu

structure.

/ (Up/Down)

• Navigate up/down in menu

structure.

• Increase/decrease the volume.

(Center)

• Start, pause or resume play in USB/

BT/Play- mode.

• Conrm a selection.

(MENU)

Enter setup menu.

(EQ)

Select Equalizer (EQ) Eect. (Movie/ Music/Voice/Stadium/Custom)

Select a height eect level for Dolby

Atmos.

(Sound)

Sound enhancement settings.

(SURR/DRC/IMAX/NEURALX/DTS DLG/BASS/TREB/SYNC/CALIBRATE).

(Exit)

• Exit menu.

• Press and hold the button for 10

seconds to reset the Wi-Fi module of soundbar to factory settings.

(Mute)

Mute or restore volume.

9EN

Page 10

Prepare the remote control

• The provided remote control allows the

unit to be operated from a distance.

• Even if the remote control is

operated within the eective range

19.7 feet (6m), remote control operation may be impossible if there are any obstacles between the unit and the remote control.

• If the remote control is operated near other products which generate infrared rays, or if other remote control devices using infra-red rays are used near the unit, it may operate incorrectly. Conversely, the other products may operate incorrectly.

Replace the remote control battery

Slide to remove the battery compartment cover, insert 2 AAA

batteries (1.5V) with correct polarity,

then slide the battery compartment cover back into position.

• Make sure the (+) and (–) ends of the batteries match the (+) and (–) ends indicated in the battery compartment.

Precautions Concerning Batteries

• Be sure to insert the batteries with

correct positive “” and negative “” polarities.

• Use batteries of the same type.

Never use dierent types of batteries

together.

• Either rechargeable or nonrechargeable batteries can be used. Refer to the precautions on their labels.

• Be aware of your ngernails when

removing the battery cover and the battery.

• Do not drop the remote control.

• Do not allow anything to impact the

remote control.

• Do not spill water or any liquid on the remote control.

• Do not place the remote control on a wet object.

• Do not place the remote control under direct sunlight or near sources of excessive heat.

• Remove the battery from the remote control when not in use for a long period of time, as corrosion or battery leakage may occur and result in physical injury, and/or property

damage, and/or re.

• Do not use any batteries other than

those specied.

• Do not mix new batteries with old ones.

• Never recharge a battery unless it is conrmed to be a rechargeable type.

10 EN

Page 11

Placement

3.5-4mm/0.14 -0.16"

>32mm/1.26"

For best results, place your Soundbar as shown below.

WARNING!

•

To prevent injury, this apparatus must be securely attached to the oor/wall in

accordance with the installation instructions.

• Suggested wall mounting height: ≤ 1.5 meters.

• You are recommended to install the TV rst

before wall mounting the soundbar. With

a TV preinstalled, wall mount the soundbar 50mm/2.0’’ in distance from the bottom of the TV.

Wall mount

Note

• Improper wall mounting may result in accident,

injury or damage. If you have any query, contact Consumer Care in your country.

• Before wall mounting, make sure the wall can

support the weight of your soundbar.

• Before wall mount, you need not remove the

rubber feet at the bottom of the soundbar,

otherwise the rubber feet cannot be xed back.

• Depending on the type of wall mounting your

soundbar, make sure that you use screws of a suitable length and diameter.

• Please check whether the USB port on the

back of the soundbar is connected to a USB device. If it is found that the connected USB

device aects the wall-mount, you need to use

another USB device of the appropriate size.

Screw length/diameter

4mm/

0.16"

~50mm/2.0"

743mm / 29.2”

3.5-4mm/0.14 -0.16"

4mm/

0.16"

>32mm/1.26"

1 Drill 2 parallel holes (Diameter 3-8mm

each according to wall type) on the wall.

» The distance between the holes

are: 743mm / 29.2”

» You can use the wall mount

template provided for helping the drilling holes position on the wall.

2 Secure the dowels and screws in the

holes.

» Be sure to leave a 3.5-4mm gap

between the wall and the screw’s head.

3 Attach the wall brackets (x2) into on

the unit.

4 Hang the soundbar on the fastening

screws.

11EN

Page 12

3 Connect

This section helps you connect your soundbar to a TV and other devices, and

then set it up.

Note

• For identication and supply ratings, see the

type plate at the back or bottom of the product.

• Before you make or change any connections,

make sure that all devices are disconnected from the power outlet.

Dolby Atmos®

Dolby Atmos gives you Immersive listening experience by delivering sound in three dimensional space, and all the richness, clarity, and power of Dolby sound.

For more information, please visit dolby.com/technologies/dolby-atmos

For using Dolby Atmos®

Dolby Atmos® is available in HDMI mode. For the details of the connection, please refer to “HDMI Connection”.

1 To use Dolby Atmos® in HDMI in/

HDMI eARC/ARC mode.

2 Make sure that “No Encoding” is

selected for bitstream in the digital audio output of the connected

external device (e.g. Blu-ray DVD player, TV etc.).

3 While entering Dolby Atmos / Dolby

Digital / PCM format, the soundbar

will show DOLBY ATMOS / DOLBY

AUDIO / PCM AUDIO / DOLBY

SURROUND.

12 EN

Note

The full Dolby Atmos experience is only

•

available when the soundbar is connected to the source via a HDMI 2.0 cable.

• The soundbar will still function when connected

via other methods (such as a Digital Optical cable) but they are unable to support all of the

Dolby features. Given this, our recommendation

is to connect via HDMI, in order to ensure full Dolby support.

Connect to HDMI Socket

Some 4K HDR TVs require the HDMI

input or picture settings to be set for HDR content reception. For further setup details on HDR display, please refer to

the instruction manual of your TV.

Option 1:

HDMI eARC/ARC (Enhance Audio Return Channel)

Your soundbar supports HDMI with eARC/ARC (Enhance Audio Return

Channel). If your TV is HDMI eARC/ARC compliant, you can hear the TV audio

through your soundbar by using a single HDMI cable.

HDMI out

(eARC/ARC)

HDMI (eARC/ARC)

1 On your TV, turn on HDMI-CEC

operations. For details, see the TV

user manual.

• The HDMI ARC connector on the

TV might be labeled dierently. For details, see the TV user

manual.

Page 13

2 Using a high speed HDMI cable,

HDMI in

HDMI out

Blu-ray Player/DVD Player

/Recorder/Set-top Box...

HDMI out

(eARC/ARC)

HDMI in

TV Sensor

connect the HDMI out (eARC/ARC) To TV connector on your soundbar to the HDMI ARC connector on the TV.

Optical

Note

Your TV must support the HDMI-CEC and ARC

•

function. HDMI-CEC and ARC must be set to On.

• The setting method of HDMI-CEC and ARC may

dier depending on the TV. For details about ARC function, please refer to your TV owner’s

manual.

• Make sure to use the HDMI cables can support

the ARC function.

Option 2: Standard HDMI

If your TV is not HDMI ARC-compliant, connect your soundbar to the TV

through a standard HDMI connection.

1 Use an HDMI cable to connect

the soundbar’s HDMI in socket to your external devices (e.g. games

consoles, DVD players and Blu-ray).

2 Use an HDMI cable to connect the

soundbar’s HDMI out (eARC/ARC) socket to the TV’s HDMI in socket.

Optical out

• The digital optical connector might

be labeled Spdif or Spdif out.

Connect the IR passthrough cable

If the soundbar blocks the IR receiver of

the TV when placing directly in front of it, you can connect the soundbar and TV

with the supplied IR pass-through cable so that it can receive signal from the

remote control of your TV.

Micin

IRout

IR out

1 Connect the 2.5mm end of the IR

pass-through cable to the IR OUT

connector on your soundbar.

2 Then, place the other end with the IR

blaster close to the TV sensor.

For information, check the user

manual of your TV.

Connect to Optical Socket

1 Using an optical cable, connect the

Optical connector on your soundbar to the Optical out connector on the

TV or other device.

Note

• Before you start using IR pass-through, make sure

the TV’s remote sensing area is completely blocked.

• If you nd that the TV’s remote control receiver

is not blocked and still works, you can cancel the connection of the IR pass-through cable.

13EN

Page 14

Connect to Power

WARNING!

Risk of product damage! Make sure that the

•

power supply voltage corresponds to the voltage printed on the back or the underside of the product.

• Risk of electric shock! When you unplug the

power cord, always pull the plug from the

socket. Never pull the cord.

• Before connecting the AC power cord, ensure

you have completed all other connections.

Connect the mains cable to the AC Socket of the unit and then into a mains socket.

2 Both soundbar and subwoofer are on.

The soundbar will discover and pair

with the subwoofer in pairing mode.

» If pairing succeeds, soundbar

display shows “PAIRED”.

» If pairing fails, soundbar display

shows “CHECK SUBWOOFER”.

Manual pairing

If pairing fails, To perform manual pairing of soundbar and subwoofer:

1 Unplug the subwoofer from the

power outlet and power it up again.

2 Goto soundbar settings menu.

» Press

Then press

the subwoofer pairing mode.

> select “SUB PAIR” >

(Enter) to conrm

• Power cord quantity and plug type vary by regions.

Pairing with Subwoofer (FW1) via proprietary RF link

FB1 soundbar can pair with FW1 (not supplied) Play-Fi wireless subwoofer.

Automatic pairing

1 Switch FW1 subwoofer source to

Play-/RF link source.

14 EN

FB1 SoundBar

3 The soundbar will discover and pair

with the subwoofer in pairing mode.

Connect to Wi-Fi (Wireless Operation)

(For iOS and Android version)

By connecting this unit and mobile phones, tablets (such as iPad, iPhone, iPod touch, Android phones, etc.) to the same Wi-Fi network, you can then use the Philips Sound

app powered by DTS Play- to control the soundbar to listen to audio les.

Page 15

1 Download and install the Philips

Sound app powered by DTS Play- on

a phone or tablet.

slowly, it indicates that the speaker is entering the Wi-Fi setup mode.

Fast blink Slow pulse

Philips Sound

• Make sure your router is turned on and working properly.

Note

Depending on the device version, the operation

•

screen and the way to perform operations may vary.

2 Connect your phone or tablet to the

same Wi-Fi network that you want to connect your soundbar.

Wi-Fi

3 Press and hold (Wi-Fi) button

located at the back cabinet for 8 seconds to trigger the Wi-Fi connection.

5 Launch the Philips Sound app

instructions in the app to connect this product to your Wi-Fi network.

Philips Sound

Return to this app to continue setup.

Ready?

Go To Wi-Fi Settings

Your Home Router

Your Play-Fi device is connecting to

Your Home Router

When the Wi-Fi light on the device stops blinking and becomes solid the device is

setup and ready to be used.

Settings

SETUP

Setup Play-Fi Device

PlayFiDevice 1234

Wi-Fi Password

1234567890I

Enter the password for the network Your Home Router

Show Password.

Select Name

Bedroom

>8 sec

» Until the speaker make a second

tone and then release the button.

Two tone

4 Wait until the Wi-Fi light indicator on

the front cabinet goes from a fast blink to a slow pulse. When it begins pulsing

6 After successful Wi-Fi connection, the

Wi-Fi light indicator will stop pulsing and turn solid. Once you set up this product on your Wi-Fi network, you can control it from any smartphone or tablet on the same network.

7 After connection, you can change

the device name. There are several

names to choose from or create your

own by choosing Custom Name at

the end of the name list. Otherwise, it follows the default name.

15EN

Page 16

8 After connection, this product may

perform a software update. Upgrade to the latest software

when it is your rst time set up. The software upgrade may take

several minutes. Do not unplug your

speaker, turn o your device, or leave

the network during the update.

» Select the Play-Fi device in the

Airplay set up.

» Press “Done” when set up

complete

Note

• After connection, the product may perform

a software update. Upgrade is required after initial set up. Without the upgrade, not all product features can be available.

• When the rst time set up is not successful, hold

down the Wi-Fi button on the soundbar for 8 seconds until the second tone can be heard and the Wi-Fi light is changed to a slow pulse. Reset the Wi-Fi connection, restart the app and start the set up again.

• If you want to change from one network to

another, you need to set up the connection again. Press hold down the the soundbar for 8 seconds to reset the Wi-Fi connection.

(Wi-Fi) button on

• When the rst time set up is not successful, please

close the Philips Sound app powered by DTS Play-. Restart the app and try the setup again.

AirPlay setup

Use AirPlay to set up the Wi-Fi connection of iOS device (iOS7 or later) and soundbar.

1 iOS device: Settings > Wi-Fi > select

home network [Play-Fi Device (xxxxxx) ]

» Go to the Wi-Fi set up. The Play-Fi

device name displays around in 5 seconds.

» After successful Wi-Fi connection,

the Wi-Fi light indicator will stop pulsing and turn solid.

Solid

2 Return to Philips Sound App to name

the device.

3 After connection, you can change

the device name. There are several

names to choose from or create your

own by choosing Custom Name at

the end of the name list. Otherwise, it follows the default name.

16 EN

Settings

Page 17

The home theater speakers are now

independent speakers.

Two

One

WPS mode

If your router has Wi-Fi Protected Setup (WPS), you can set up the connection without entering a password.

1 Press and hold the

(Wi-Fi) button for 3 seconds on the soundbar. You will hear a tone and the Wi-Fi light will begin double blink.

2 Press the WPS button on your router.

The button is normally marked with

this WPS logo.

WPS

3 After successful Wi-Fi connection,

the Wi-Fi light indicator will stop pulsing and turn solid.

Surround sound Setup

Follow the on-screen setup.

Note

• WPS is not a standard feature on all routers.

If your router does not have WPS then use Standard Wi-Fi Setup.

• Press the

exit the WPS mode or it will automatically exit after 2 minutes.

(Wi-Fi) button once if you want to

Connect the soundbar to

Philips Play- enabled TV

1 Power up your DTS Play- TV

connected to the internet.

» TV sound is muted.

2 Enter the Settings menu on TV.

» Settings > Sound > DTS Play-

TV Audio Setup

You can also stream the TV’s audio to

your home speakers wirelessly. Follow the on-screen setup.

DTS Play-Fi TV Audio

Stream this TV's audio to wireless speakes throughout your home.

Learn more about DTS Play-Fi enabled

speakers at play-.com

Connect Speakers

DTS Play-Fi TV Audio

Play-Fi Speaker

Connect Speakers

Select Speakers

Volume

FB1

3FB1

17EN

Page 18

4 Use your

Select Modes

Soundbar

This section helps you use the soundbar

to play audio from connected devices.

Before you start

• Make the necessary connections

described in the quick start guide and the user manual.

• Switch the soundbar to the correct source for other devices.

Turn ON and OFF

• When you rst connect the unit to

the main socket, the unit will be

in STANDBY mode. The STANDBY

indicator will light up.

Power State

Power On

Semi Standby

Eco Standby

Action Function

Follow source state

Press the button once

Press and hold

seconds

• Wi-Fi is connected.

• It supports Play-

and Airplay2, Chromecast, Spotify connect, work with Alexa.

• Wi-Fi is o.

• The product enters

the lower power consumption mode.

• Restarting the system will take a relatively longer time.

Press the button repeatedly on the unit or on the remote control to select the Optical, HDMI in, HDMI eARC/ARC,

BT, USB mode.

» The selected mode will show on

the display.

Display Status

USB

BT NO BT

OPT E-ARC

ARC HD I

Tips

Play- is not an optional source. Play- needs to

•

be directly controlled by APP.

BT (Bluetooth)

• Connected

• Not connected

Optical

HDMI eARC HDMI ARC

HDMI in

Adjust the Volume

Press +/－ (Volume) buttons to increase

or decrease a volume level.

• To mute sound, press

• To restore the sound, press

(Mute) again or press

(Mute).

+/－.

Enjoy Dolby Atmos sound

18 EN

Press button to select a

height surround eects level to best suit

your personal taste according to your environment.

Page 19

• ATMOS 00: Minimal eect.

• ATMOS 01: Small height eect.

• ATMOS 02: Medium height eect.

• ATMOS 03: Big height eect.

2 Then press the / (Left / Right)

navigation buttons change the settings.

Display

Description

Note

• For non-HDMI connections (such as use of USB,

Bluetooth, OPTICAL or AUDIO IN), only limited height surround eects are generated.

Choose your Sound

This section helps you choose the ideal

sound for your video or music.

Select Equalizer (EQ) Eect

Press button on the remote control

to select predened sound modes to suit your video or music: MOVIE, MUSIC,

VOICE, STADIUM, CUSTOM.

• MOVIE: Create a surround listening

experience. Ideal for watching movies.

• MUSIC: Create two-channel or multi-channel stereo sound. Ideal for listening to music.

• VOICE: Create sound eect which

makes human voice more clear and outstanding for listening.

• STADIUM: Create an atmosphere as if watching a sports game in a stadium.

• CUSTOM: Customize the sound based on your preferences.

» By default, the EQ is set to

MOVIE.

Sound enhancement settings

1 Repeatedly press to select:

SURR / DRC / IMAX / NEURALX / DTS DLG / BASS / TREB / SYNC / CALIBRATE.

URR

DRC XX

I A XX

NEURALX

DT DLG X

BA XX

TREXX

YNCXX

CALIBRATE

Select audio 7.1.2/Standard/ Ai Surround options

Dynamic Range Control

IMAX mode Auto or O

Neural:X On or O

Adjust Dialogue Level

Adjust the Bass Level

Adjust the Treble Level

Set the Audio Delay

Set the Auto Calibration

(Only displayed when microphone input)

Surround

Select surround audio options.

• 7.1.2: Make sure that all speakers are utilized for contents less than 5.1.2 or 7.1.2 speaker

conguration.

• STANDARD: Original sound.

• AI SURR: The media intelligence

function of Dolby Atmos for home audio is utilized to drive the vocal

enhancement or surround eects.

» By default, the audio upmix is set

to 7.1.2.

Note

• Display shall show the speaker channels

according with dierent speaker congurations, such as:

7.1.2: soundbar

7.1.4: soundbar + surround speakers

7.1.4: soundbar + surround speakers + subwoofer

7.2.2: soundbar + 2x subwoofer

7.2.4: soundbar + surround speakers + 2x subwoofer

19EN

Page 20

Dynamic Range Control (DRC)

You can apply dynamic range control to Dolby Digital tracks.

• ON : Optimization the dynamic

range

• OFF : Turn o dynamic range

adjustment

• AUTO : Dynamic range is

automatically adjusted

» By default, the DRC mode is set

to AUTO.

Note

• DRC is not available in USB/BT/Play- mode.

IMAX

Set IMAX mode auto or o.

• AUTO: Set to IMAX mode on

• OFF: Set to IMAX mode o

» By default, the IMAX mode is set

to AUTO.

Neural:X

DTS:X® technologies provide users with

virtual multi-channel virtual surround

eects, creating an immersive audio

volume.

• ON: Set to Neural:X mode on

• OFF: Set to Neural:X mode o

» By default, the Neural:X mode is

set to ON.

Dialogue mode

Dialogue mode improves the clarity

of dialogue and vocals in movies, TV

programs and podcasts by adjusting the tonal balance of this product.

• DLG 0 ~ DLG 6

» By default, the dialogue mode is

set to 0.

Tips

•

The related level value can be adjusted only when playing DTS format source. Otherwise it

cannot be adjusted.

SYNC

Set the audio delay.

Video image processing, sometimes

longer than the time required to process

the audio signal. This is called “delayed.”

Audio Delay feature is designed to remedy this delay.

• S 00~S 200

» By default, the audio delay is set

to 00.

Calibration

Auto calibration setup.

Tips

•

If calibration is never done before, If MIC is inserted, navigate to the calibration item shall always display “CALIBRATE – PRESS PLAY”.

BASS/TREBLE

Change the low frequency (bass) and high frequency (treble) settings of this product.

• BAS -5 ~ BAS +5

• TRE -5 ~ TRE +5

» By default, the Bass/Treble is set

to 0.

20 EN

To start auto calibration:

1 Turn on the soundbar. 2 Insert MIC to MIC IN at the rear of

FB1.

» Display “CALIBRATE – PRESS PLAY”

Page 21

IRou t

Mici n

Mic in

Insert Mic

Audio settings

Set calibration

Point the microphone up and place it where the viewer's head is when seated facing the screen. (Don't place it too low, or too close to the speakers, and it shouldn't be placed upside down on the headrest of a sofa (the fabric absorbs some sound waves and can distort the measurements).

3 Upon press to start calibration,

test tones will be played according to

dierent congurations.

» Once calibration is done, display

“DONE – REMOVE MIC”.

4 When a full auto calibration

setup process has completed, the calibrated parameters can be enabled/disabled via menu.

• ON: The last calibrated

• OFF: All calibrated parameters

Exit Auto Calibration Setup

Auto calibration setup can be cancelled

via 2 ways:

• Unplug MIC from MIC IN.

• While MIC is still inserted, Press

(Exit) on the remote control. Stop playing back test tones for each channel.

parameters shall be applied

shall be disabled. The last

parameters shall be remembered.

Setup Menu

The unit allows you to congure

advanced settings to provide you with an even better experience.

1 Press the

remote control to open the menu.

2 Select the content with

Up) on the remote controller.

3 Press

selection.

4 Change the initial values for each

of the settings with the cursors (Left / Right).

5 Press

• To return to the previous screen/

exit the settings, press

• If no button is pressed within 10 seconds, the system will automatically exit the menu.

Display Description

FL XX

FR XX

CT XX

L XX

R XX

DI P XX

LIGHT

TNBY XX

BT PAIR

UB PAIR

UPGRADE

(MENU) button on the

/ (Down /

(Enter) to conrm your

(Enter) to confirm your selection.

(Exit).

Front Left Speaker

Front Right Speaker

Subwoofer

Center Speaker

Side Left Speaker

Side Right Speaker

Set display and light ring brightness

Auto turn o display

ATMOS Light ring control

Auto-standby ON/OFF

Start Bluetooth pairing

(Only in BT mode)

Start Subwoofer pairing

Update rmware via USB

21EN

Page 22

Adjust speaker level

• Front Left : FL -5 ~ FL +5

• Front Right : FR -5 ~ FR +5

• Subwoofer : SW-5 ~ SW +5

• Center : CT -5 ~ CT +5

• Side Left : SL -5 ~ SL +5

• Side Right : SR -5 ~ SR +5

» By default, the speaker level is set

to 00.

Standby

The unit automatically turns to Standby mode after about 15 minutes if the TV or the external unit is disconnected (or USB, BT function bit playback pause), switched o.

• STNBY IN 15M: Turn on the

Auto-Standby.

• STNBY OFF: Turn o the Auto-

Standby.

» By default, the setting is set to o.

DIM

Set display brightness.

• DIM HIGH, DIM MID, DIM LOW

» By default, the dimmer is set to

DIM MID.

DISPLAY

Set to turn o the display automatically

(except the Wi-Fi LED indicator) after 10 seconds of idle when no user operation.

• ON: Set to display on

• OFF: Set to display o

» By default, the display is set to

ON.

LIGHT

Audio light ring control.

• AUTO : When the Dolby Atmos

format is detected, the audio light ring will turn on for 10

seconds and turn o.

• ON: When Dolby Atmos format is

detected, the halo light stays on following the audio.

• OFF: Set to Audio light ring o

» By default, the LIGHT is set to AUTO.

Note

To switch the unit o completely, remove the

•

mains plug from the mains socket.

• Please turn the unit o completely to save

energy when not in use.

BT PAIR

Enter the Bluetooth pairing mode.

• If you want to connect your soundbar with another Bluetooth device, you can activation the pairing in the menu (BT PAIR) to disconnect

from current BT connected devices

and enter the Bluetooth pairing mode. » Press

press Bluetooth pairing mode.

• Follow step 2-3 in “Play from Bluetooth devices“ above to pair

your Bluetooth device.

Tips

• The “BT PAIR” menu will only be displayed

when the current signal source is in “BT” mode

> select “BT PAIR” > Then

(Enter) to conrm the

Note

•

The brightness should follow DIM setting.

22 EN

Page 23

SUB PAIR

FB1 soundbar can pair with FW1 (not supplied) Play-Fi wireless subwoofer.

» Press

Then press

the subwoofer pairing mode.

» Follow step in “Pairing

with Subwoofer (FW1) via proprietary RF link”.

> select “SUB PAIR” >

(Enter) to conrm

Update rmware via USB

Check if there is the latest rmware

version on www.philips.com/support. Search for your model and click on “Software and drivers”.

Copy the software update les into USB ash drive, insert USB ash drive on the

unit.

» Press

“PLAY TO START”

» Then press » Upgrade nished and restart.

> select “UPGRADE” >

(Enter) to conrm.

Play from Bluetooth devices

Through Bluetooth, connect the

soundbar with your Bluetooth device (such as an iPad, iPhone, iPod touch, Android phone, or laptop), and then you

can listen to the audio les stored on the

device through your soundbar speakers.

1 Press the

unit or on the remote control to switch the soundbar to Bluetooth mode.

» BT is displayed on the display

panel.

2 On the Bluetooth device, switch

on Bluetooth, search for and select “Philips Fidelio FB1” to start connection (see the user manual of the Bluetooth device on how to enable Bluetooth).

button repeatedly on the

3 Wait until you hear the voice prompt

from the soundbar.

» If the successfully connected,

CONNECTED is displayed on the display panel.

4 Select and play audio les or music

on your Bluetooth device.

• During play, if a call is coming,

music play is paused. Play resumes when the call ends.

• If your Bluetooth device supports

AVRCP prole, on the remote

control you can press to skip to a track, or press button to pause/resume play.

/ button

To disconnect and pair a new Bluetooth device

1 In Bluetooth mode, press > select

“BT PAIR” > Then press disconnect from current connected

BT devices and enter the Bluetooth

pairing mode.

• Alternatively directly press and hold soundbar to disconnect from current

connected BT devices and enter the

Bluetooth pairing mode. » The display will ashing “PAIR“.

button for 3 seconds on the

(Enter) to

2 Follow step 2-3 in “Play from

Bluetooth devices“ above to pair

your Bluetooth device.

Note

•

In an open space without obstructions.

The maximum operational range between

the soundbar and a Bluetooth device is approximately 10 meters (30 feet).

• Compatibility with all Bluetooth devices is not

guaranteed.

• The music streaming may be interrupted by

obstacles between the device and soundbar, such as wall, metallic casing that covers the device, or other devices nearby that operate in the same frequency.

23EN

Page 24

Multi-point control

The product support multi-point feature,

and can connect two Bluetooth devices at same time (such as an iPad, iPhone, iPod touch, Android phone, or laptop).

• There is audio prompt when the

second Bluetooth device connect the soundbar.

• When the second Bluetooth device stream its audio to soundbar, the

rst Bluetooth device will pause the

playback.

• Incoming call has priority over music

playback regardless from rst or

second devices.

Listen to an external device

Ensure that the unit is connected to the

TV or audio device.

1 Press the

the unit or on the remote control to select the Optical, HDMI ARC, HDMI in mode.

2 Operate your audio device directly

for playback features.

3 Press the VOL +/– buttons to adjust

the volume to your desired level.

Audio (abbreviation) Display

LPCM 2ch PCM AUDIO

LPCM 5.1ch PCM AUDIO

LPCM 7.1ch PCM AUDIO

Dolby Digital Dolby AUDIO

Dolby TrueHD Dolby Surround

Dolby Digital Plus Dolby Surround

Dolby Atmos -

Dolby TrueHD

button repeatedly on

Dolby Atmos

Dolby Atmos Dolby Digital Plus

DTS DTS

DTS Discrete Surround DTS

DTS-ES 6.1 Matrix DTS

DTS-ES 6.1 Discrete DTS

DTS 96/24 DTS

DTS 96/24 ES Matrix DTS

DTS Express DTS

DTS-ES 8-Channel

Discrete

DTS-HD High

Resolution

DTS-HD Master Audio DTS-HD

DTS:X DTS:X

DTS:X Master Audio DTS:X

Note

•

The unit may not be able to decode all digital

audio formats from the input source. In this

case, the unit will mute. This is NOT a defect.

Ensure that the audio setting of the input

source (e.g. TV, game console, DVD player, etc.)

is set to PCM or Dolby Digital (Refer to the user manual of the input source device for its audio setting details) with HDMI in / HDMI ARC / Optical input.

Dolby Atmos

DTS

DTS-HD

Play audio through USB

Enjoy audio on a USB storage device,

such as an MP3 player and USB ash

memory, etc.

1 Insert the USB device.

24 EN

Page 25

2 Press the button repeatedly on

the unit or on the remote control to select the USB mode.

» USB is displayed on the display

panel.

3 During playback:

Button Action

Start, pause or resume play.

/ Skip to the previous or next track.

Tips

•

This product may not be compatible with

certain types of USB storage devices.

• If you use a USB extension cable, USB hub,

or USB Multifunctional card reader, the USB storage device may not be recognized.

• Do not remove the USB storage device while

reading les.

• The unit can support USB devices with up to 32

GB of memory.

• This unit can play MP3 / WAV / FLAC.

• Support a USB port: 5V

500mA.

Listen to Spotify

Use your phone, tablet or computer as a

remote control for Spotify. Go to spotify.

com/connect to learn how.

Factory Reset

Reset device to default setting.

• Turn on the soundbar, press and hold

the

and buttons at the same

time for 8 seconds.

» Display shows “RESET” for 5

seconds.

» While system reboot, display

shows “REBOOT”

25EN

Page 26

5 Product

specifications

Note

• Specications and design are subject to change

without notice.

Speakers impedance 8Ω

Dimension (W x H x D )

1200 x 73 x 125 mm

Weight 7.2 kg

Operating temperature

0°C - 45°C

Bluetooth / Wireless

Bluetooth proles A2DP, AVRCP

Bluetooth version V 5.0

Bluetooth frequency

range / Transmitter

power (EIRP)

5.8G Wireless frequency range / Transmitter

power (EIRP)

2402~2480 MHz

≤ 5dBm

5742~5852 MHz

≤ 10dBm

Network supported

WiFi IEEE 802.11a/b/g/n/ac Wireless frequency band (Wi-Fi) /Radio frequency power transmitted (EIRP)

2.4G Wi-Fi 2400 ~ 2483.5 MHz / ≤ 20dBm

5150 ~ 5350 MHz / ≤ 20dBm

5.G Wi-Fi

5470 ~ 5725 MHz / ≤ 27dBm 5725 ~ 5850 MHz / ≤ 14dBm

Soundbar

USB

USB direct version 2.0 Full Speed

USB 5V

Extension Codec Sample Rate Bitrate

.mp3

.wav

.ac

MPEG 1

Layer 1

MPEG 1

Layer 2

MPEG 1

Layer 3

MPEG 2 / MPEG 2.5

Layer 1

MPEG 2 / MPEG 2.5

Layer 2

MPEG 2/ MPEG 2.5

Layer 3

WAV 16 ~ 48 kHz

FLAC

16 ~ 48 kHz 32 ~ 448 kbps

16 ~ 48 kHz 8 ~ 384 kbps

16 ~ 48 kHz 8 ~ 320 kbps

16 ~ 48 kHz 8 ~ 256 kbps

16 ~ 48 kHz 8 ~160 kbps

16 ~ 48 kHz 8 ~ 160 kbps

Up to 48 kHz / 16 bit

500mA

Up to 1536 kbps

Power supply

RMS output power MAX output power

100-240V~

50/60Hz

310W

620W (1% THD )

Power consumption 50 W

Standby consumption

< 0.5 W

Frequency response 40Hz - 20KHz

26 EN

Remote control

Distance/Angle 6m/30°

Battery type AAA (1.5V X 2)

Page 27

Supported audio formats

Format Function

HDMI Input HDMI eARC HDMI ARC OPTICAL

LPCM 2ch √ √ √ √

LPCM 5.1ch √ √ √ √

LPCM 7.1ch √ √ -- --

Dolby Digital √ √ √ √

Dolby Digital Plus √ √ √ --

Dolby TrueHD √ √ -- --

Dolby MAT √ √ -- --

Dolby Atmos - Dolby Digital Plus √ √ √ --

Dolby Atmos - Dolby TrueHD √ √ -- --

Dolby Atmos - Dolby MAT √ √ -- --

DTS √ √ √ √

DTS-ES Discrete 6.1 √ √ √ √

DTS-ES Matrix 6.1 √ √ √ √

DTS 96/24 √ √ √ √

DTS-HD High Resolution Audio √ √ -- --

DTS-HD Master Audio √ √ -- --

DTS-HD LBR √ √ -- --

DTS:X √ √ -- --

√ : Supported format. -- : Unsupported format.

The product shall comply with Dolby indication mandatory requirements marked below

Input Signal

Dolby Digital

Dolby Digital Plus

Dolby

TrueHD

Dolby MAT

Audio format

Channel-based

Object-based - √

Channel-based

Object-based - √

Channel-based

Object-based - √

Channel-based

Dolby Virtualizer

Dolby Atmos1Dolby Surround1Dolby Audio

O √

On √

O √

On √

O √

On √

O √

On √

Format Indication

27EN

Page 28

6 Troubleshooting

Warning

Risk of electric shock. Never remove the casing

•

of the product.

To keep the warranty valid, never try to

repair the product yourself. If you have problems using this

product, check the following points before you request service. If you still have a problem, get support at www.philips.com/support.

Main unit

The buttons on the main unit do not work.

• Disconnect form the power supply for a few minutes,then connect again.

No power

• Ensure that the AC cord is properly connected.

• Ensure that there is power at the AC outlet.

• Press remote control or soundbar to turn the soundbar on.

Sound

No sound from the soundbar speaker.

• Connect the audio cable from

your soundbar to your TV or other

devices. However, you do not need a

separate audio connection when:

- the soundbar and TV are connected

- a device is connected to the HDMI

• On the remote control, select the correct audio input.

• Make sure that the soundbar is not muted.

(standby) button on the

through HDMl ARC connection, or

in connector on your soundbar.

• Reset this product to its factory settings (see ‘Apply factory settings). Or power down the product completely and start over again.

• When the playback freezes and there is no sound in Wi-Fi mode, please check whether your home network is normal.

Distorted sound or echo.

• If you play audio from TV through this product, make sure that the TV

is muted.

Audio and video are not synchronized.

•

Press SYNC’ to synchronize the audio with the video.

enter setting menu, select ‘AV

Bluetooth

A device cannot connect with the soundbar.

• The device does not support the compatible proles required for the

soundbar.

• You have not enabled the Bluetooth function of the device. See the user manual of the device on how to enable the function.

• The device is not correctly connected.

Connect the device correctly.

• The soundbar is already connected

with another Bluetooth device. Disconnect the connected device, then try again.

Quality of audio play from a connected Bluetooth device is poor.

• The Bluetooth reception is poor.

Move the device closer to the soundbar, or remove any obstacle between the device and the soundbar.

28 EN

Page 29

I can’t nd the Bluetooth name of this

unit on my Bluetooth device

• Ensure the Bluetooth function is activated on your Bluetooth device.

• Re-pair the unit with your Bluetooth device.

Wi-Fi

Wi-Fi Connection cannot be established.

• Check the availability of WLAN

network on the router.

• Place the Wi-Fi router closer to the unit.

• Make sure the password is correct.

• Check the WLAN function or reboot

the modem and Wi-Fi router.

• When the speaker was set as Stereo Pairs or Surround Sound, the speaker need to be disconnected in the App before use separately.

Remote control does not work

• Before you press any playback

control button, rst select the correct

source.

• Reduce the distance between the remote control and the unit.

• Insert the battery with its polarities (+/-) aligned as indicated.

• Replace the battery.

• Aim the remote control directly at

the sensor on the front of the unit.

Dolby Atmos

Cannot achieve outstanding Dolby

Atmos eects.

• For non-HDMI connections (such as use of USB, Bluetooth, Optical or

AUDIO IN), limited height surround eects are generated. See the

section of ‘Dolby Atmos’ about how

to achieve best Dolby Atmos eects.

Play-

Cannot discover the Play- supported

devices from the app.

• Make sure the device is connected to the Wi-Fi.

Cannot play Play- music.

• Certain network service or contents available through the device may not be accessible in case the service provider terminates its service.

• When the rst time set up is not

successful, close the Philips Sound

app powered by DTS Play-. Restart

the app.

This is a 15 mins power o

function, one of the ERPII standard requirement for saving power

• When the unit’s external input

signal level is too low, the unit will

be turned o automatically in 15

minutes. Please increase the volume level of your external device.

29EN

Page 30

Trademarks:

Play-Fi and Play-Fi logos are registered trademarks or

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. (for companies headquartered in the U.S./Japan/Taiwan) or under license from DTS Licensing Limited (for all other companies). DTS, DTS:X, and the DTS:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries. © 2021 DTS, Inc. ALL RIGHTS RESERVED.

Manufactured under license from IMAX Corporation. IMAX® is a registered trademark of IMAX Corporation in

the United States and/or other countries. For DTS patents, see http:// patents.dts.com. Manufactured under license from DTS, Inc. (for companies headquartered in the U.S./Japan/Taiwan) or under license from DTS Licensing Limited (for all other companies). DTS and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries. © 2020 DTS, Inc. ALL RIGHTS RESERVED.

To control this AirPlay 2 -enabled speaker, iOS 11.

4 or later is required. Use of the Works with Apple badge means that an accessory has been designed

to work specically with technology identied in the badge and has been certied by trademarks of

Apply Inc. , registered in the U. S. and other countries. Apple® and AirPlay® are trademarks of Apple Inc.,

registered in the U.S. and other countries.

The Spotify Software is subject to third party licenses found here: www.spotify.com/connect/third-party-

licenses

The terms HDMI, HDMI High-Denition Multimedia

Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Dolby, Dolby Vision, Dolby Atmos, and the double-D

symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Manufactured

under license from Dolby Laboratories. Condential

The Wi-Fi CERTIFIED™ Logo is a registered trademark

of Wi-Fi Alliance®.

Google, Google Play and Chromecast built-in are trademark of Google LLC. Google Assistant is not

available in certain languages and countries.

30 EN

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by MMD Hong Kong Holding Limited

is under license. Other trademarks and trade names are those of their respective owners.

Roku, the Roku logo, Roku TV, Roku TV Ready, and the Roku TV Ready logo are trademarks and/or registered trademarks of Roku, Inc. This product is Roku TV

Ready-supported in the United States, Canada, United

Kingdom, Mexico and Brazil. Countries are subject to

change. For the most current list of countries in which

this product is Roku TV Ready-supported, please email

rokutvready@roku.com.

Page 31

Specications are subject to change without notice. Please visit www.Philips.com/support for the latest updates and documents.

Philips and the Philips Shield Emblem are registered trademarks of

Koninklijke Philips N.V. and are used under license.

This product has been manufactured by and is sold under the responsibility of MMD Hong Kong Holding Limited. or one of its aliates, and MMD Hong Kong Holding Limited. is the warrantor in relation to this product.

TAFB1RE_UM_EN_V1.0_20220606

Philips Fidelio FB1 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual
