Philips
Portable MP3-CD Player
EXP2561
Magic ESP
Enjoy skip-free MP3 music
With touch screen LCD
Slip into urban action with the compact MP3-CD player eXp2561 and enjoy up to 50
hours of non-stop MP3 and WMA music on the go. Stay in control with intuitive music
access thanks to its innovative LCD touch screen display.
Your complete MP3-CD experience
• Enjoy MP3 and WMA playback
• Plays CD, CD-R and CD-RW discs
• Savor up to 50-hour music playback*
Jogproof
• 200-second Magic ESP™
Designed for urban action
• Round and compact design
• LCD touch screen display for intuitive music access
Enhanced bass performance
• Digital Dynamic Bass Boost for optimized bass at any volume
Page 2
For preview purpose only
Portable MP3-CD Player
Technical specifications Product highlights
Sound
• D/A converter: 1-bit
• Frequency response: 20 - 20 000 Hz
• Signal to noise ratio: > 85dB
• Sound Enhancement: Dynamic Bass Boost
• Output Power: 2 x 4mW RMS
• Volume Control: digital
• Acoustic Feedback
Audio Playback
• Playback Media: MP3-CD, CD, CD-R, CDRW, WMA
• Disc Playback Modes: 50-Track
Programmable, Hold, Next/Previous Album
Search, Next/Previous Track Search, Repeat
one/album/all, Shuffle album/all
• Electronic Skip Protection(CD): 45 seconds
• File systems supported: ISO-9660, Jolliet
• Magic ESP (MP3-CD): 100 seconds
• MP3 bit rates: 32 - 320 kbps
• WMA bit rates: 32 - 192 kbps
Convenience
• Display Type: LCD
• Indications: album number, battery status,
Cd functions, DBB, ESP, time, track
Accessories
• Headphones: AY3806 earphones
• Included Accessories: User Manual
Dimensions
• Master carton dimensions:
205x345x244mm
• Master carton weight: 1.7 kg
• Master carton quantity: 3
• Packaging dimensions (WxHxD):
208x309x60mm
• Product dimensions (WxDxH):
140x140x29mm
• Product weight: 0.2 kg
• Packaging type: Clamshell
Power
Connectivity
• DC in: 4.0 mm, 4.5V, centre +
• Headphone: 3.5 mm
• Line-out: 3,5 mm
• Battery type: AA, LR6, UM3
•
EXP2561/17
200-second Magic ESP™
Magic Electronic Skip Protection™ is a convenient
feature that ensures skip-free music even when your
MP3-CD player is subjected to knocks and jolts while you
are jogging or on the move. Devices with Magic Electronic
Skip Protection™ have an intelligent electronic buffer
that can store different digital music formats such as
MP3, WMA and CDDA. The buffer adjusts both its
contents and laser spin speeds automatically to guarantee
uninterrupted music listening.
LCD touch screen control
To uc h Screen Co ntrol al lo ws you to control your dev ic e by
simply pressing on-screen buttons rather than physical
buttons on the device. Simply power up the device and the
touch screen user interface will show up on the LCD
display with all the control options for the device. Touch
Screen Control combines LCD display technology with
pressure sensors and a powerful digital micro processor.
Wh en yo u pre ss on a spe cif ic ar ea of the s cree n wi th yo ur
finger, the relevant signal is sent to the processor and the
command is immediately executed.
Digital Dynamic Bass Boost
Digital Dynamic Bass Boost is an intelligent bass booster
that delivers maximum bass enhancement at high
volumes without sound distortion and at low volumes
without compromising on bottom-end bass frequencies.
Technologically advanced electronics constantly monitor
volume and bass levels, precisely calibrating both to
prevent sound distortion, thus producing optimized bass.
Digital Dynamic Bass Boost enables the enjoyment of
superb bass performance - regardless of the chosen
volume level.
Date of issue 2006-07-28
Version: 2.0
12 NC: 9073 101 02385
UPC: 6 09585 11083 0
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
* Battery life varies by use and settings.
* Windows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United
States and/or other countries.
* Based on 64 kbps WMA encoding.
