Philips DVP5140K 03 User Manual

DVD VIDEO PLAYER

User manual

Thank you for choosing Philips.

Need help fast?

Read your User’s Manual first for quick tips that make using your Philips product more enjoyable. If you have read your instructions and still need assistance, you may access our online help at www.philips.com/support

DVP5140K

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:23 AM1

General Information

Environmental Information

All unnecessary packaging has been omitted. The packaging has been made easy to separate into two materials: cardboard (box, buffer) and polyethylene (bags, protective foam sheet).

Your DVD player consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

DivX Ultra Certified products: "DivX", DivX Ultra Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

Laser safety

This unit employs a laser. Due to possible eye injury, only a qualified service person should remove the cover or attempt to service this device.

NOTE: PICTURES SHOWN MAYBE DIFFERENT BETWEEN COUNTRIES.

CAUTION (WARNING LOCATION: ON THE BACKPLATE OF THE SET)

NEVER MAKE OR CHANGE CONNECTIONS WITH THE POWER SWITCHED ON.

Important Note: Due to the numerous versions of new CD-Audio copy protection or enhanced CD-Audio protection recently available on certain discs, Philips is unable to guarantee that this DVD Player is fully compatible with such new discs. Should you have difficulty playing any such CD-Audio discs, kindly refer them to your CDAudio disc retailer.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:23 AM2

Index

Manufactured under license from Dolby Laboratories, "Dolby", "Pro Logic" and the double-D symbol are trademarks of Dolby Laboratories.

English ------------------------------------------- 6

English

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by

acrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by

acrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by

acrovision Corporation. Reverse engineering or disassembly is prohibited.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM3

Due to the inconsistency of disc formats provided by various disc manufacturers, your DVD system may require a playability enhancement or upgrade. As DVD technology advances, these enhancements will become common and will be easy to complete.

Go to www.philips.com/support for software upgrade.

The apparatus shall not be exposed to dripping

or splashing and that no objects filled with

liquids, such as vases, shall be placed on

apparatus.

For Customer Use:

Read carefully the information located at the rear of your DVD VIDEO player and enter below the Serial No. Retain this information for future reference.

Model No. DVP 5140K Serial No. _______________

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM4

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

LASER

Type Semiconductor laser

GaAlAs

Wave length 650 nm (DVD)

780 nm (VCD/CD)

Output Power 7 mW (DVD)

10 mW (VCD/CD)

Beam divergence 60 degree

Language Code

Abkhazian 6566

Afar 6565

Afrikaans 6570

Amharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Avestan 6569

Aymara 6589

Azerhaijani 6590

Bahasa Melayu 7783

Bashkir 6665

Belarusian 6669

Bengali 6678

Bihari 6672

Bislama 6673

Bokmål, Norwegian 7866

Bosanski 6683

Brezhoneg 6682

Bulgarian 6671

Burmese 7789

Castellano, Español 6983

Catalán 6765

Chamorro 6772

Chechen 6769

Chewa; Chichewa; Nyanja 7889

9072

Chuang; Zhuang 9065

Church Slavic; Slavonic 6785

Chuvash 6786

Corsican 6779

Česky 6783

Dansk 6865

Deutsch 6869

Dzongkha 6890

English 6978

Esperanto 6979

Estonian 6984

Euskara 6985

 6976

Faroese 7079

Français 7082

Frysk 7089

Fijian 7074

Gaelic; Scottish Gaelic 7168

Gallegan 7176

Georgian 7565

Gikuyu; Kikuyu 7573

Guarani 7178

Gujarati 7185

Hausa 7265

Herero 7290

Hindi 7273

Hiri Motu 7279

Hrwatski 6779

Ido 7379

Interlingua (International)7365

Interlingue 7365

Inuktitut 7385

Inupiaq 7375 Irish 7165 Íslenska 7383 Italiano 7384 Ivrit 7269 Japanese 7465 Javanese 7486 Kalaallisut 7576 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kernewek 7587 Khmer 7577 Kinyarwanda 8287 Kirghiz 7589 Komi 7586 Korean 7579 Kuanyama; Kwanyama 7574 Kurdish 7585 Lao 7679 Latina 7665 Latvian 7686 Letzeburgesch; 7666 Limburgan; Limburger 7673 Lingala 7678 Lithuanian 7684 Luxembourgish; 7666 Macedonian 7775 Malagasy 7771 Magyar 7285 Malayalam 7776 Maltese 7784 Manx 7186 Maori 7773 Marathi 7782 Marshallese 7772 Moldavian 7779 Mongolian 7778 Nauru 7865 Navaho; Navajo 7886 Ndebele, North 7868 Ndebele, South 7882 Ndonga 7871 Nederlands 7876 Nepali 7869 Norsk 7879 Northern Sami 8369 North Ndebele 7868 Norwegian Nynorsk; 7878 Occitan; Provencal 7967 Old Bulgarian; Old Slavonic 6785 Oriya 7982 Oromo 7977 Ossetian; Ossetic 7983 Pali 8073 Panjabi 8065 Persian 7065 Polski 8076 Português 8084

Pushto 8083 Russian 8285 Quechua 8185 Raeto-Romance 8277 Romanian 8279 Rundi 8278 Samoan 8377 Sango 8371 Sanskrit 8365 Sardinian 8367 Serbian 8382 Shona 8378 Shqip 8381 Sindhi 8368 Sinhalese 8373 Slovensky 8373 Slovenian 8376 Somali 8379 Sotho; Southern 8384 South Ndebele 7882 Sundanese 8385 Suomi 7073 Swahili 8387 Swati 8383 Svenska 8386 Tagalog 8476 Tahitian 8489 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 Tonga (Tonga Islands) 8479 Tsonga 8483 Tswana 8478 Türkçe 8482 Turkmen 8475 Twi 8487 Uighur 8571 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapuk 8679 Walloon 8765 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 8973 Yoruba 8979 Zulu 9085

English

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM5

Contents

English

Language Code................................................... 5

Introduction

Supplied accessories ....................................... 8

Cleaning discs ................................................... 8

Setup ................................................................... 8

Connections

Connecting TV ............................................ 9-10

Using Composite Video jacks (CVBS) ........ 9

Using Component Video jacks (Pr Pb Y) ... 9

Using an accessory RF modulator ............ 10

Connecting the power cord........................ 10

Optional : Connecting to a Stereo System ..

........................................................................... 11

Stereo system has Dolby Pro Logic or Right

/ Left Audio In jack ....................................... 11

Optional: Connecting Digital AV Receiver ...

........................................................................... 11

Receiver has a PCM, Dolby Digital, or

MPEG2 decoder ............................................ 11

Functional Overview

Front and Rear Panels .................................. 12

Remote Control ............................................ 13

Getting Started

Step 1: Inserting batteries into the

Remote Control ............................................ 14

Using the Remote Control to operate the

Player ............................................................... 14

Step 2: Setting up the TV ........................ 14-16

Setting up Progressive Scan feature (for

Progressive Scan TV only) ........................... 15

Selecting the color system that corresponds

to your TV ...................................................... 16

Step 3: Setting language preference ........... 17

Setting the OSD Language .......................... 17

Setting the Audio, Subtitle and Disc menu

language .......................................................... 17

Disc Operations

Playable Discs ................................................. 18

Region Codes ................................................. 18

Playing discs..................................................... 19

Basic playback controls................................. 19

Operations for video playback ................... 20

Using the Disc Menu.................................... 20

Zooming in ..................................................... 20

Resuming playback from the last stopped

point ................................................................ 20

Slow motion................................................... 20

Forward / Reverse Searching ..................... 20

OSD (On-Screen Display) (DVD/VCD/

SVCD) ........................................................ 21-22

Using the OSD menu .................................. 21

Title/Chapter/Track selection .................... 21

Time Search ................................................... 21

Audio/Subtitle ................................................ 21

Angle ................................................................ 21

Repeat ............................................................. 22

Repeat A-B ..................................................... 22

Preview Function .......................................... 22

OSD (On-Screen Display) Audio CD . 22-23

Disc Go To/Track Go To/ Track Selection . 23

Repeat ............................................................. 23

Special DVD Features ................................... 23

Playing a Title ................................................. 23

Changing the Audio Language .................... 23

Subtitles .......................................................... 23

Special VCD & SVCD Features ................... 24

Playback Control (PBC) .............................. 24

Playing DivX disc ........................................... 24

Playing MP3/WMA/JPEG/Kodak Picture CD

..................................................................... 25-26

General Operation ....................................... 25

Playback selection ......................................... 25

Zoom picture (JPEG) ................................... 25

Playback with multi-angles (JPEG)............. 25

Preview Function (JPEG) ............................. 26

Playing MP3/WMA music and JPEG picture

simultaneously ............................................... 26

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM6

Karaoke Operations

Playing Karaoke discs .................................... 27

General Operation ....................................... 27

Vocal ................................................................ 27

Karaoke........................................................... 27

DVD Setup Menu Options

General Setup menu ............................... 28-29

Locking/Unlocking the disc for viewing ... 28

Dimming system’s display screen .............. 28

Programming disc tracks ....................... 28-29

OSD Language ............................................... 29

Sleep ................................................................ 29

DivX VOD registration code ..................... 29

Audio Setup Menu ................................... 30-32

Analog output ................................................ 30

Digital Audio Setup ....................................... 30

Sound Mode ................................................... 31

CD Upsampling ............................................. 31

Night Mode - turning on/off ....................... 32

Video Setup Menu ................................... 32-34

TV Type ........................................................... 32

Setting the TV Display ................................. 33

Progressive - turning on/off........................ 33

Picture Setting ............................................... 34

Preference Page........................................ 35-37

Audio, Subtitle, Disc Menu.......................... 35

Restricting playback by Parental Control .....

.................................................................. 35-36

PBC .................................................................. 36

MP3/JPEG Menu - turning on/off ............... 36

Changing the Password ............................... 37

Setting the DivX Subtitle ............................ 37

Restoring to original settings ..................... 37

Contents

English

Troubleshooting .......................... 38-39

Specifications ......................................40

Glossary ......................................................................41

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM7

Introduction

English

Supplied accessories

Composite video cable (yellow)

Auido cable (white, red)

Remote Control and two AAA batteries

Cleaning discs

To clean a disc, use a micro fibre cleaning cloth and wipe the disc from the center to the edge in a straight line.

CAUTION!

Do not use solvents such as benzene, thinner, commercially available cleaners, or anti-static sprays intended for discs.

Since the optical unit (laser) of the DVD system operates at a higher power than regular DVD or CD players, cleaning CDs intended for DVD or CD players may damage the optical unit (laser). Therefore, refrain from using a cleaning CD.

Setup

Finding a suitable location

– Place the set on a flat, hard and stable surface. Do not place the set on a carpet. – Do not position the set on top of other equipment that might heat it up (e.g., receiver or amplifier). – Do not put anything under the set (e.g., CDs, magazines). – Install this system near the AC outlet and where the AC power plug can be reached easily.

Space for ventilation

– Place the apparatus in a location with adequate ventilation to prevent internal heat build up. Allow at least 10 cm (4.0”) clearance from the rear and the top of the set and 5cm (2.0”) from the left and right to prevent overheating.

5cm (2.0")

10cm (4.0")

5cm (2.0")

Avoid high temperatures, moisture, water and dust

– Apparatus shall not be exposed to dripping or splashing. – Do not place any sources of danger on the apparatus (e.g., liquid filled objects, lighted candles).

10cm (4.0")

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM8

Connecting TV

AUDIO

V (Pr/Cr)

U (Pb/Cb)

S-VIDEO

VIDEO IN

COMPONENT

VIDEO IN

AUDIO OUT

V (Pr/Cr)

U (Pb/Cb)

S-VIDEO IN

VIDEO IN

COMPONENT VIDEO IN

COMPONENT

VIDEO IN S-VIDEO IN

V (Pr/Cr)

AUDIO OUT

U (Pb/Cb)

VIDEO IN

S-VIDEO

VIDEO IN

Connections

English

COMPONENT

VIDEO IN

V (Pr/Cr)

AUDIO

U (Pb/Cb)

IMPORTANT! – You only need to make

one video connection from the following options, depending on the capabilities of your TV system. – Connect the DVD system directly to the TV.

Using Composite Video jacks (CVBS)

1 Use the composite video cable (yellow) to

connect the DVD Player’s CVBS (VIDEO) jack to the video input jack (or labeled as A/V In, Video In, Composite or Baseband) on the TV (cable supplied).

2 To hear the sound of this DVD Player

through your TV, use the audio cables (white/red) to connect AUDIO OUT (L/ R) jacks of the DVD Player to the corresponding AUDIO IN jacks on the TV (cable supplied).

IMPORTANT! – The progressive scan video quality is only possible when using Y Pb Pr and a progressive scan TV is required.

Using Component Video jacks (Y Pb Pr)

1 Use the component video cables (red/

blue/green) to connect the DVD system’s Y Pb Pr jacks to the corresponding Component video input jacks (or labeled as Y Pb Pr) on the TV (cable not supplied).

2 To hear the sound of this DVD Player

through your TV, use the audio cables (white/red) to connect AUDIO OUT (L/ R) jacks of the DVD Player to the corresponding AUDIO IN jacks on the TV (cable supplied).

3 Proceed to page 15 for detailed

Progressive Scan set up.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM9

Connections

~ AC MAINS

AUDIO OUT

V (Pr/Cr)

U (Pb/Cb)

S-VIDEO

VIDEO IN

COMPONENT

VIDEO IN

English

RF coaxial cable to TV

Back of RF Modulator

(example only)

AUDIO IN

TO TVINT IN

VIDEO

R L

CH3 CH4

Antenna or

Cable TV signal

IMPORTANT! – If your TV only has a single Antenna In jack (or labeled as 75 ohm or RF In,) you will need an RF modulator in order to view the DVD playback on the TV. See your electronics retailer or contact Philips for details on RF modulator availability and operations.

Using an accessory RF modulator

1 Use the composite video cable (yellow) to

connect the DVD Player’s CVBS jack to the video input jack on the RF modulator.

2 Use the RF coaxial cable (not supplied) to

connect the RF modulator to your TV’s RF jack.

Connecting the power cord

After everything is connected properly, plug in the AC power cord to the power outlet.

Never make or change any connections with the power switched on.

When no disc is loaded, press

STANDBY ON on the DVD Player front panel, “NO DISC” may appear on the display panel.

NO DISC

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM10

Connections

AUDIO

DIGITAL

AV Receiver

Optional: Connecting to a Stereo System

STEREO

Stereo system has Dolby Pro Logic or Right / Left Audio In jack

OPTICAL

AUDIO

DIGITAL

1 Select one of the video connections

(CVBS VIDEO IN or COMPONENT VIDEO IN) depending on the options available on your TV.

2 Use the audio cables (white/red) to

connect AUDIO OUT (L/R) jacks of the DVD Player to the corresponding AUDIO IN jacks on the stereo system (cable supplied).

Optional: Connecting Digital AV Receiver

English

Receiver has a PCM, Dolby Digital, or MPEG2 decoder

1 Select one of the video connections

(CVBS VIDEO IN or COMPONENT VIDEO IN) depending on the options available on your TV.

2 Connect the COAXIAL jack of the DVD

Player to the corresponding Digital Audio In jack on your Receiver (cable not supplied).

3 Set the DVD Player’s Digital Output to

PCM-ONLY or ALL depending on the capabilities of your Receiver (see page 30

“Digital Output”).

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM11

Helpful Hints: – If the audio format of the Digital Output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

Functional Overview

English

Front and Rear Panels

STANDBY-ON B

– Turns the player on or switches it to

standby mode

Disc tray

OPEN/CLOSE /

– Opens or closes the disc tray

Display

– Shows information about the current

status of the DVD Player

– For connecting microphone

– Microphone volume control

9 STOP

– Stops playback

2; PLAY/PAUSE

– Starts or pauses playback

SMART PICTURE

– To toggle between Standard, Vivid, Cool

and Personal

IR Sensor

– Point the remote control towards this

sensor

MIC

LEVEL

Mains (AC Power Cord)

– Connect to a standard AC outlet

CVBS (VIDEO Out)

– Connect to CVBS Video input of a TV

YPbPr (Component Video Out)

– Connect to YPbPr input of a TV

– Connect to coaxial AUDIO input of a

Audio Out (Left/Right)

– Connect to AUDIO inputs of an

amplifier, receiver or stereo system

COAXIAL (Digital audio out)

Caution: Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM12

digital audio equipment

Remote Control

Functional Overview

– Enters or exits the disc contents

DISC MENU

– Switches on or off the playback

control mode (for VCD version

2.0 only)

RETURN / TITLE

– To go back to previous menu /

show title menu

PREV ( ¡ )

– Skips to the previous title/chapter/

track

NEXT ( ™ )

– Skips to the next title/chapter/

track

STOP ( 9 )

– Stops playback

PLAY/PAUSE ( 2; )

– Starts or pauses playback

MUTE ( H)

– Disables or enables sound output

SUBTITLE

– Selects a DVD subtitle language

ZOOM

– Enlarge a picture on the TV

screen

VOCAL

– Choose audio channels or

karaoke methods

KARAOKE

– To toggle between ‘Mic’, ‘Vol’,

‘Echo’ or ‘Key’.

– Turns the player on or switches

it to standby mode

DISPLAY

– Displays information on TV

screen during playback

1 2

– Cursor buttons for moving to

the left or right, do a forward/ reverse search

3 4

– Cursor buttons for moving up/

down, do a slow forward/ backward

– Confirms an entry or selection

SETUP

– Enters or exits system setup

menu.

Alphanumeric keypad 0-9

– Selects numbered items in a

AUDIO

– Selects an audio language

(DVD/VCD) or audio channels.

English

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM13

Helpful Hint: Press “STOP” for about 2 seconds to OPEN or CLOSE disc tray.

Getting Started

English

Step 1: Inserting batteries into the Remote Control

1 Open the battery compartment. 2 Insert two batteries type R03 or AAA,

following the indications (+-) inside the compartment.

3 Close the cover.

Using the Remote Control to operate the Player

1 Aim the Remote Control

directly at the remote sensor (IR) on the front panel.

2 Do not put any objects

between the Remote Control and the DVD Player while operating the DVD Player.

Step 2: Setting up the TV

IMPORTANT!

Make sure you have completed all the necessary connections. (See pages 9-10 “Connecting TV”).

1 Turn on the TV and set to the correct

video-in channel. You should see the DVD background screen on the TV.

2 Usually these channels are between the

lowest and highest channels and may be called FRONT, A/V IN, or VIDEO. See your TV manual for more details.

➜ Or, you may go to channel 1 on your

TV, then press the Channel down button repeatedly until you see the Video In channel.

➜ Or, the TV Remote Control may have a

button or switch that chooses different video modes.

➜ Or, set the TV to channel 3 or 4 if you

are using an RF modulator.

3 If you are using external equipment, (eg.

audio system or receiver), turn it on and select the appropriate input source for the DVD player output. Refer to the equipment owner’s manual for detail.

CAUTION! – Remove batteries if they are exhausted or if the Remote Control is not being used for a long time. – Do not use old and new or different types of batteries in combination. – Batteries contain chemical substances, so they should be disposed properly.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM14

Getting Started

Setting up Progressive Scan feature (for Progressive Scan TV only)

The progressive scan display twice the number of frames per seconds than interlaced scanning (ordinary normal TV system). With nearly double the number of lines, progressive scan offers higher picture resolution and quality.

IMPORTANT! Before enabling the progressive scan feature, you must ensure:

1) Your TV can accept progressive signals, a progressive scan TV is required.

2) You have connected the DVD player to your TV using Y Pb Pr (see page 9.)

1 Turn on your TV. 2 Turn off your TV progressive scan mode

or turn on interlaced mode (refer to your TV user manual.)

3 Press POWER (B) on the remote

control to turn on the DVD player.

4 Select the correct Video Input channel.

(See page 14).

➜ The DVD background screen appears

on the TV.

5 Press SETUP. 6 Press 2 to select {VIDEO SETUP PAGE}.

- - Video Setup Page - -

TV Type

TV Display

Progressive On

Picture Setting Off

Set P-SCAN On/Off

7 Select {PROGRESSIVE} to {ON}, then OK

to confirm.

➜ The instruction menu appears on the

TV.

ACTIVATING PROGRESSIVE SCAN:

1. ENSURE YOUR TV HAS PROGRESSIVE SCAN.

2. CONNECT USING YPBPR (GBR) VIDEO CABLE.

3. IF THERE IS A DISTORTED PICTURE, WAIT

15 SECONDS FOR AUTO RECOVERY.

8 Press 1 to highlight

Cancel

in the menu

and press OK to confirm.

There will be a distorted picture on your TV at this state until you turn on the progressive scan mode on your TV.

9 Turn on your TV progressive scan mode

(refer to your TV user manual.)

➜ The below menu appears on the TV.

CONFIRM AGAIN TO USE PROGRESSIVE

SCAN. IF PICTURE IS GOOD,

PRESS OK BUTTON ON REMOTE.

0 Press 1 to highlight

Cancel

in the menu

and press OK to confirm.

➜ The set up is complete now and you

can start enjoy the high quality picture.

To deactivate Progressive manually:

● Wait for 15 seconds for auto recovery.

1 Press OPEN CLOSE 0 on the DVD

player to open the disc tray.

2 Press numeric keypad ‘1’ on the

remote control for few seconds.

➜ The DVD background screen appears

on the TV.

Helpful Hint: – There are some progressive scan TV and High-Definition TV sets that are not fully compatible with this DVD system, resulting in the unnatural picture when playing back a DVD VIDEO disc in the progressive scan mode. In such a case, turn off the progressive scan feature on both the DVD player and your TV set.

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM15

Getting Started

English

Selecting the color system that corresponds to your TV

This DVD Player is compatible with both NTSC and PAL. In order for a DVD disc to play on this Player, the color system of the Disc, the TV and the DVD Player should match.

- - Video Setup Page - -

TV Type PAL

TV Display Multi

Progressive NTSC

Picture Setting

NTSC TV

1 Press SETUP. 2 Press 2 to select {VIDEO SETUP PAGE}. 3 Press 3 4 to highlight {TV TYPE}, then

press 2.

4 Press 3 4 to highlight one of the options

below:

PAL – Select this if the connected TV is PAL system. It will change the video signal of a NTSC disc and output in PAL format.

NTSC – Select this if the connected TV is NTSC system. It will change the video signal of a PAL disc and output in NTSC format.

Multi – Select this if the connected TV is compatible with both NTSC and PAL (multi-system). The output format will be in accordance with the video signal of the disc.

5 Select an item and press OK.

➜ Follow the instructions shown on the

TV to confirm the selection (if any).

Helpful Hints: – Before changing the current TV Standard setting, ensure that your TV supports the ‘selected TV Type’ system. – If there is no proper picture on your TV, wait for 15 seconds for auto recovery.

CHANGING PAL TO NTSC:

1. ENSURE THAT YOUR TV SUPPORTS NTSC STANDARD.

2. IF THERE IS A DISTORTED PICTURE DISPLAYED ON THE TV, WAIT 15 SECONDS FOR AUTO RECOVERY.

CANCELOK

CONFIRM AGAIN TO USE NEW TV TYPE SETTING.

CANCELOK

To reset to default TV color system manually:

● Wait for 15 seconds for auto recovery.

1 Press OPEN CLOSE 0 on the DVD

player to open the disc tray.

2 Press numeric keypad ‘3’ on the

remote control for few seconds.

➜ The DVD background screen appears

on the TV.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM16

Getting Started

Step 3: Setting language preference

The language options are different depending on your country or region. It may not correspond to the illustrations shown on the user manual.

Setting the OSD Language

The On-screen language for the system menu will remain as you set it, regardless of various disc languages.

- - General Setup Page - -

Disc Lock

Display Dim

Program ENGLISH

OSD Language

Sleep

DIVX(R) Vod Code

Melayu

Set OSD Language English

1 Press SETUP. 2 Press 2 to select {GENERAL SETUP

PAGE}.

3 Press 3 4 to highlight {OSD

LANGUAGE}, then press 2.

4 Press 3 4 to select a language and press

OK.

Setting the Audio, Subtitle and Disc menu language

You can choose your own preferred language or soundtrack from audio, subtitles and disc menu languages. If the language selected is not available on the disc, the disc’s default language will be used instead.

- - Preference Page - -

Audio English

Subtitle Chinese Disc Menu French Parental Spanish PBC Portuguese Mp3/Jpeg nav Polish Password Italian

Set Preference To English

1 Press STOP twice then, press SETUP. 2 Press 2 to select {PREFERENCE PAGE}. 3 Press 3 4 to highlight one of the options

below at a time, then press 2. – ‘Audio’ (disc’s soundtrack) – ‘Subtitle’ (disc’s subtitles) – ‘Disc Menu’ (disc’s menu)

4 Press 3 4 to select a language and press

OK.

If the language you want is not in the list, then select {OTHERS},

then use the numeric keypad (0-9) on the remote to enter the 4-digit language code ‘XXXX’ (see page 5 “Language Code”) and press OK.

5 Repeat steps 3~4 for other language

settings.

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM17

Disc Operations

ALL

English

IMPORTANT! – If the inhibit icon (ø) appears on the TV screen when a button is pressed, it means the function is not available on the current disc or at the current time. – Depending on the DVD or VIDEO CD, some operations may be different or restricted. – Do not push on the disc tray or put any objects other than disc on the disc tray. Doing so may cause the disc player malfunction.

Playable Discs

Your DVD Player will play:

– Digital Video Discs (DVDs) – Video CDs (VCDs) – Super Video CDs (SVCDs) – Digital Video Discs +

Recordable[Rewritable] (DVD+R[W])

– Compact Discs (CDs) – MP3 discs, picture (Kodak, JPEG) files

on CD-R(W).

– JPEG/ISO 9660 format – Maximum 30 characters display. – Supported sampling frequencies :

32 kHz, 44.1 kHz, 48 kHz (MPEG-1) 16 kHz, 22.05 kHz, 24 kHz (MPEG-2)

– Supported Bit-rates : 32~256 kbps

(MPEG-1), 8~160 kbps (MPEG-2) variable bitrates

– WMA files on CD-R(W).

– Supported Bit-rates : 32~192 kbps

– DivX disc on CD-R[W]/DVD+R[W]:

– DivX 3.11, 4.x, 5.x and 6.x – Q-pel accurate motion compensation – Global Motion Compensation (GMC)

playback

– DivX Ultra on CD-R[W]/DVD+R[W]:

Region Codes

This DVD player is designed to support the Region Management System. Check the regional code number on the disc package. If the number does not match the player’s region number (see table below), the player may be unable to playback the disc.

Helpful Hints: – It may not be possible to play CD-R/RW or DVD-R/RW in all cases due to the type of disc or condition of the recording. – If you are having trouble playing a certain disc, remove the disc and try a different one. Improper formatted disc will not play on this DVD player.

Discs that can

Region

U.S.A. and Canada regions

U.K and Europe regions

Asia Pacific,Taiwan, Korea

Australia, New Zealand, Latin America

Russia and India regions

China, Calcos Islands, Walls and Futuna Islands

be played

(Example)

SUPER VIDEO

TIPS:

The operating features described here might not be possible for certain discs. Always refer to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM18

Disc Operations

Playing discs

1 Connect the power cords of the DVD

Player and TV (and any optional stereo or AV receiver) to a power outlet.

2 Turn on the TV power and set to the

correct Video In channel. (See page 14 “Setting up the TV”).

3 Press STANDBY-ON to turn on the

DVD player.

➜ The DVD background screen appears

on the TV.

4 Press OPEN/CLOSE 0 on the front of

the DVD player.

● You can also hold down the STOP Ç

button on the remote control to open and close the disc tray.

5 Place a disc into the disc tray with the

lable facing up, then press OPEN/CLOSE

➜ For double-sided discs, load the side

you want to play facing up.

6 Playback will start automatically. If not

press PLAY/PAUSE 2; .

➜ If a disc menu appears on the TV, see

page 20 “Using the Disc Menu”.

➜ If the disc is locked by parental control,

you must enter your six-digit password. (See page 35-36).

● For more playback features, see pages 19–

23.

Basic playback controls

Unless otherwise stated, all operations described are based on Remote Control use.

Pausing playback

1 During playback, press PLAY/PAUSE 2;

to pause playback and display a still picture.

➜ Sound will be muted.

2 To resume normal playback, press

PLAY/PAUSE 2; again.

Selecting track/chapter

● Press PREV ¡ / NEXT ™ to go to the

previous or next track/chapter.

● In STOP mode, press DISPLAY to

display the disc information text line for title/chapter/track (example - 00/08).

● Use alphanumeric keypad (0-9) to

enter valid title/chapter/track number, then press OK.

➜ The playback skips to the selected

title/chapter/track.

Stopping playback

● Press STOPÇ.

Helpful hints: – Screen saver will start automatically if the disc playback is stopped/paused for 5 minutes. – The player will automatically switch to Power Standby mode if you do not press any buttons for 15 minutes after the disc has stopped playing.

English

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM19

Disc Operations

English

Operations for video playback (DVD/VCD/SVCD)

Using the Disc Menu

Depending on the disc, a menu may appear on the TV screen once you load in the disc.

To select a playback feature or item

● Use 1 2 3 4 keys or numeric keypad

(0-9) on the remote, then press OK to

start playback.

To access or remove the menu

● Press DISC MENU on the remote.

Zooming in

This function allows you to enlarge the picture on the TV screen and to pan through the enlarged picture.

1 During playback, press ZOOM

repeatedly to display the picture with different scales.

➜ Use 1 2 3 4 keys to pan through the

enlarged picture.

➜ Playback will continue.

2 Press ZOOM repeatedly to return to

the original size.

Resuming playback from the last stopped point

Resume playback of the last 5 discs is possible, even if the disc was ejected or the power switched off.

● Load one of the last 5 discs. ➜ “LOADING” appears.

● During loading mode, press PLAY/

PAUSE 2; and the disc will be played back from the last point.

To cancel resume mode

● In stop mode, press STOP 9 again.

Helpful Hint: – This function is not possible on CD/MP3 disc.

Slow Motion

1 Press 3 4 during playback to select the

required speed: 1/2, 1/4, 1/8 or 1/16 (forward {DVD/SVCD/VCD} or backward {DVD}).

➜ Sound will be muted.

2 To return to normal speed, press

PLAY/PAUSE 2; .

Forward / Reverse Searching

1 Press 1 2 during playback to select the

required speed: 2X, 4X, 8X , 16X or 32X (backward or forward).

➜ Sound will be muted (DVD/VCD) or

intermittent (CD).

2 To return to normal speed, press PLAY/

PAUSE 2;.

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM20

Disc Operations

OSD (On-Screen Display) (DVD/ VCD/SVCD)

Using the OSD menu

OSD menu shows the disc playback information (for example, title or chapter number, elapsed playing time, audio/ subtitle language), a number of operations can be done without interrupting disc playback.

● During playback, press DISPLAY. ➜ A list of available disc information

appears on the TV screen.

Title 01/01 Chapter 09/12 Audio 2CH Chinese Subtitle Off

Bitrate 61 Title Remain 0:48:59

Track 01/01 Disc Time 0:48:53 Track Time 0:48:53 Repeat AB Repeat Off

Bitrate 71 Total Elapsed 0:01:32

(DVD)

(VCD)

Title/Chapter/Track selection

1 Press 3 4 to highlight {Title} / {Chapter}

or {Track}, then press 2 to access.

2 Use the numeric keypad (0-9) to enter

a valid number (e.g. 04/05).

3 Press OK to confirm.

➜ The playback skips to the selected

title/chapter/track.

Time Search

1 Press 3 4 to highlight {Time Disp.} (Time

Display), then press 2 to access.

➜ The following display types appears on

the TV, depending on the disc in the player.

For DVD discs:

TT Elapsed - elapsed playing time of current Title; TT Remain - remaining playing time of current Title; CH Elapsed - elapsed playing time of current Chapter; CH Remain - remaining playing time of current Chapter;

For VCD/SVCD discs:

Total Elapsed - elapsed playing time of current Disc; Total Remain - remaining playing time of current Disc; Single Elapsed - elapsed playing time of current Track; Single Remain - remaining playing time of current Track;

2 Press 3 4 to highlight {TT Time} / {CH

Time} / {Disc Time} or {Track Time}, then press 2 to access.

3 Use the numeric keypad (0-9) to input

the valid time (e.g. 0:34:27).

4 Press OK to confirm.

➜ The playback skips to the chosen time.

English

TIPS:

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM21

The operating features described here might not be possible for certain discs. Always refer to the instructions supplied with the discs.

Disc Operations

English

Audio/Subtitle

1 Press 3 4 to highlight {Audio} or

{Subtitle}, then press 2 to access.

➜ Audio or Subtitle menu appears on the

TV.

2 Press 3 4 to select one language, then

press OK to confirm.

➜ Current audio or subtitle language will

be changed to the selected language.

Angle

1 Press 3 4 to highlight {Angle}, then press

2 to access.

2 Use the numeric keypad (0-9) to key in

a valid number.

3 Press OK to confirm.

➜ Playback will go to the selected angle.

Repeat

1 Press 3 4 to highlight {Repeat}, then

press 2 to access.

➜ Repeat menu appears on the TV.

2 Press 3 4 to highlight one of following

mode.

For DVD

– Chapter – Title (currently playing title) – All (entire disc) – Off (cancel)

For Video CD

– Track – All (entire disc) – Off (cancel)

For MP3

– Repeat One – Repeat Folder (all files in selected folder) – Folder (playing all files in one folder once) – Shuffle (all files in current folder at random

– Single (currently playing file once)

(currently playing chapter)

(currently playing track)

(currently playing file)

playback)

For JPEG, DivX

In STOP mode, – Repeat One

(currently playing file)

– Repeat Folder (all files in selected folder) – Folder (playing all files in one folder once) – Shuffle (all files in current folder at random

playback)

– Single (currently playing file once)

In PLAY mode, Press DISPLAY during playback, 12 thumbnail pictures will appear on the TV screen. See “Preview Function (JPEG)”.

Helpful Hint: – For MP3 disc, press DISPLAY repeatedly to switch between different repeat mode.

Repeat A-B

1 Press 3 4 to highlight {Repeat A-B}. 2 Press OK to mark the starting point ‘A’. 3 Press OK again to mark the ending point

‘B’.

➜ The playback from point ‘A’ to ‘B’ is

repeated.

4 Press OK third time to exit.

Preview Function

The preview function allows you to reduce the picture of 6 tracks enough to display in a full screen.

1 Press 3 4 to highlight {Preview} , then

press 2 to access.

➜ The preview menu appears on the TV

screen.

Select Digest Type:

Title Diges

Chapter Digest

Title Interval

Chapter Interval

(DVD example)

Select Digest Type:

Track Diges

Disc Interval

Track Interval

(Video CD example)

2 Press 3 4 to select the PREVIEW type,

then press OK.

➜ The picture of each segment will

appear on the screen.

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM22

Disc Operations

02 03

ABC

DEF

(example for 6 thumbnail pictures display)

3 Press 3 4 1 2 to select a track or input

your selected track number using the numeric keypad (0-9), then press OK.

➜ Playback will start automatically on the

selected track.

OSD (On-Screen Display) (Audio CD)

This function displays disc information on the TV screen during playback.

● During playback, press DISPLAY. ➜ A list of available disc information

appears on the TV screen.

Disc Go To/Track Go To/ Track Selection

1 Press DISPLAY repeatedly to select an

option.

2 Enter minutes and seconds from left to

right in the time edit box using remote control alpha numerical keypad.

➜ Playback will change to the chosen

time or to the selected track.

For Audio CD

➜ {Disc Go To: XX:XX}: enable to select

any part within the disc.

➜ {Track Go To: XX:XX}: enable to select

any part within the current track.

➜ {Select Track: XX:TT}: enable to select

any track.

Repeat

1 Press DISPLAY repeatedly to select

‘Repeat’ information.

2 Press 1 2 to switch between the

following repeat mode.

For Audio CD

(currently playing track)

– Track –All (entire disc) – Shuffle (random playback) – Off (cancel)

Special DVD Features

Playing a Title

1 Press DISC MENU.

➜ The disc title menu appears on the TV

screen.

2 Use 3 4 1 2 keys or numeric keypad

(0-9) to select a play option.

3 Press OK key to confirm.

Changing the Audio Language

For DVD

● Press AUDIO repeatedly to select

different audio languages.

Changing the Audio Channel

For VCD

● Press AUDIO to select the available

audio channels provided by the disc (MONO LEFT, MONO RIGHT, MIXMONO, STEREO).

Subtitles

● Press SUBTITLE repeatedly to select

different subtitle languages.

English

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM23

Disc Operations

English

Special VCD & SVCD Features

Playback Control (PBC)

For VCD with Playback Control (PBC) feature (version 2.0 only)

● Press DISC MENU to toggle between

‘PBC ON’ and ‘PBC OFF’.

➜ If you select ‘PBC ON’, the disc menu

(if available) will appear on the TV.

➜ Use the PREV ¡ / NEXT ™ or the

numeric keypad (0-9) to select a play option.

● During playback, pressing RETURN/

TITLE will return to the menu screen (if

PBC is on).

If you want to skip the index menu and playback directly from the beginning,

● Press DISC MENU key on the remote

control to switch to PBC off.

Playing a DivX disc

This DVD player supports the DivX movie playback that you download from your computer onto a CD-R/RW or DVD±R/RW (see page 29 for more information).

1 Load a DivX disc.

➜ Playback will start automatically. If not

press PLAY/PAUSE 2;.

2 Pressing SUBTITLE on the remote

control will turn on or off the subtitle.

● If multilingual subtitles are embedded on

the DivX disc, pressing SUBTITLE will change the subtitle language during playback.

Helpful Hints: – Subtitle files with the following filename extensions (.srt, .smi, .sub, .ssa, .ass) are supported but do not appear on the file navigation menu. – The subtitle filename have to be the same as the filename of the movie.

Advance features of the DivX Ultra

● XSUB™ subtitles let you author

movies with multiple language subtitle sets.

● Interactive video menus offer

unprecedented convenience and control so you can quickly navigate between various scenes or bonus features, and select from audio track and subtitle options.

● Alternate audio tracks enable audio

tracks in multiple language versions or separate audio tracks for specific speaker configurations

● Chapter points provide flexibility,

allowing you to jump straight to the scene you want to watch from anywhere within the video.

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM24

Disc Operations

Playing MP3/WMA/JPEG/Kodak Picture CD

IMPORTANT!

You have to turn on your TV and set to the correct Video In channel. (See page 14 “Setting up the TV”).

General Operation

1 Load a disc.

➜ The disc reading time may exceed 30

seconds due to the complexity of the directory/file configuration.

➜ The data disc menu appears on the TV

screen.

01:42 04:40 128kbps 001/020

Coco Lee

MP3

Coco - Before

Coco - I love

MP3

Coco - Jazz

Before

- - - - - -

ALBUM - - - - - -

2002

2 Press 3 4 to select the folder and press

OK to open the folder.

3 Press 3 4 to select a track/file. 4 Press PREV ¡ / NEXT ™ to go to

previous/next page.

5 Press OK to confirm.

Playback selection

During playback, you can;

● Press PREV ¡ / NEXT ™ to select the

previous/next track/file in the current folder.

● Press 1 23 4 on the remote to rotate/

flip the picture files.

● Press PLAY/PAUSE 2; repeatedly to

pause/resume playback.

Zoom picture (JPEG)

● During playback, press ZOOM

repeatedly to display the picture with different scales.

● Use

3 4 1 2 to view the zoomed picture.

Playback with multi-angles (JPEG)

● During playback, press 3 4 1 2 to rotate

the picture on the TV screen.

3: flip the picture vertically by 180˚ 4: flip the picture horizontally by 180˚ 1: rotate the picture counter-clockwise by 90˚ 2: rotate the picture clockwise by 90˚

Helpful Hints: – It may not be possible to play certain MP3/JPEG disc due to the configuration and characteristics of the disc or condition of the recording.

– It is normal to experience an occasional “skip” while listening to your MP3 disc. – For multi-session discs with different

formats, only the first session will be available. – When playback MP3/Windows Media™ Audio disc, DISPLAY function is not available.

English

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM25

Disc Operations

English

Preview Function (JPEG)

This function shows the content of the current folder or the whole disc.

1 Press DISPLAY during playback.

➜ 12 thumbnail pictures will appear on

the TV screen.

S T

2 Press PREV ¡ / NEXT ™ to display the

other pictures on the previous/next page.

3 Press 1 23 4 on highlight one of the

picture and press OK to start playback.

4 Press DISC MENU to return to Picture

CD menu.

Playing MP3/WMA music and JPEG picture simultaneously

1 Load a disc that contains music and

picture.

➜ The disc menu appears on the TV

screen.

2 Select an MP3/WMA track. 3 During MP3/WMA music playback, select

a picture from the TV screen and press PLAY/PAUSE 2;.

➜ The picture files will be played back

one after another until end of the folder.

4 To quit simultaneous playback, press Ç.

Helpful Hint: – Some files on Kodak or JPEG disc may be distorted during playback due to the configuration and characteristics of the disc.

TIPS:

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM26

The operating features described here might not be possible for certain discs. Always refer to the instructions supplied with the discs.

Karaoke Operations

Playing Karaoke discs

IMPORTANT!

You have to turn on your TV and set to the correct Video In channel. (See page 14 “Setting up the TV”).

General Operation

1 Connect a microphone (not supplied) to

MIC on the side panel of the DVD player.

2 Press KARAOKE repeatedly to access

karaoke menu MIC ON/OFF.

➜ ‘MIC ON/OFF’ appears on the TV

screen.

➜ Press 1 2 key to turn On or Off the

microphone.

3 Load a karaoke disc and press PLAY/

PAUSE 2; .

4 Adjust the microphone volume using MIC

LEVEL button on the side panel of the

DVD player.

Helpful Hint: – Before connecting the microphone, set the microphone volume to the minimum level to prevent howling.

Vocal

● You can fade out the original vocal from a

karaoke disc.

● Press VOCAL repeatedly to choose

different audio modes.

Helpful Hint: – This function and on screen display depends on the availability of the disc.

Karaoke

● Press KARAOKE repeatedly to toggle

between ‘Mic’, ‘Vol’, ‘Echo’ or ‘Key’.

1 When ‘Mic’ is selected, press 1 2 to set

Mic On/Off.

2 When ‘Vol’ is selected, press 1 2 to adjust

the vocal value between 0 and 20.

3 When ‘Echo’ is selected, press 1 2 to

adjust the echo value between 0 and 20.

4 When ‘Key’ is selected, press 1 2 to

adjust the pitch value between -16 and 16. This function allows you to adjust the key tone level to match with your vocal.

English

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM27

DVD Setup Menu Options

1 04

2 10

4 __ 9 __

8 __

7 __

6 __

5 __

10 __

3 11

Exit START NEXT

Programme : Track (01 - 17)

English

This DVD Player setup is carried out via the TV, enabling you to customise the DVD Player to suit your particular requirements.

General Setup menu

1 In disc mode, press SETUP. 2 Press 1 2 to select ‘General Setup’ icon. 3 Press OK to confirm.

- - General Setup Page - -

Disc Lock

Display Dim

Program

OSD Language

Sleep

DIVX(R) Vod Code

Go to General Setup Page

Locking/Unlocking the disc for viewing

Not all discs are rated or coded by the disc maker. You can prevent a specific disc from playing by locking the disc. Up to 40 discs can be locked.

1 In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DISC LOCK}, then press 2.

LOCK

Select this to block the playback of the current disc. Subsequent access to a locked disc requires six-digit password. The default password is ‘136 900’ (see page 37 “Changing the password”).

UNLOCK

Select this to unlock the disc and allow future playback.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Dimming player’s display panel

You can select different levels of brightness for the display screen.

1 In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DISPLAY DIM}, then press 2.

100% – Select this for full brightness.

70% – Select this for medium brightness.

40% – Select this for dimming the display.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Programming disc tracks (not for Picture CD/MP3/WMA/DivX)

You can play the contents of the disc in the order you want by programming the tracks to be played. Up to 20 tracks can be stored.

1 In ‘GENERAL SETUP PAGE’, press 3 4

to highlight {PROGRAM}, then press 2 to select {INPUT MENU}.

2 Press OK to confirm.

To input your favorite tracks/chapter

3 Use the numeric keypad (0-9) to enter

a valid track/chapter number.

4 Use 1 2 3 4 keys to move the cursor to

the next position.

➜ If the track number is more than ten,

press NEXT ™ to open the next page and proceed with programming or,

➜ Use 1 2 3 4 keys to highlight {NEXT}

on the program menu, then press OK.

5 Repeat steps 3~4 to input another

track/chapter number.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM28

DVD Setup Menu Options

If you want to remove a track

6 Use 1 2 3 4 keys to move the cursor to

the track you want to remove.

7 Press OK to remove this track from the

program menu.

To start program playback

8 Use 1 2 3 4 keys to highlight {START}

on the program menu, then press OK.

➜ Playback will start with the selected

tracks under the programmed sequence.

To exit program playback

9 Use 1 2 3 4 keys to highlight {EXIT} on

the program menu, then press OK.

OSD Language

This menu contains various language options for display language on the screen. For details, see page 17.

Sleep

Sleep function allows you to turn off the DVD Player automatically after a preset time.

1 In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {SLEEP}, then press 2.

15 Mins

Turn off the DVD Player after 15 minutes.

30 Mins

Turn off the DVD Player after 30 minutes.

45 Mins

Turn off the DVD Player after 45 minutes.

60 Mins

Turn off the DVD Player after 60 minutes.

OFF

Turn off the sleep function.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

DivX(R) VOD registration code

DivX® VOD (Video On Demand) registration code allows you to rent and purchase videos using the DivX service from the internet. For more information, visit us at http//:vod.divx.com

VOD

1 In ‘GENERAL SETUP PAGE’, press 3 4 to

highlight {DIVX(R) VOD CODE}, then press 2.

➜ The registration code will appear.

2 Press OK to exit. 3 Use the registration code to purchase or

rent the videos from DivX at http//:vod.divx.com. Follow the instructions and download the video onto a CD-R for playback on this DVD player.

Helpful Hints: – All the downloaded videos from DivX VOD can only be played back on this DVD player. – Time search feature is not available during DivX movie playback.

VOD service

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM29

DVD Setup Menu Options

English

Audio Setup Menu

1 In disc mode, press SETUP. 2 Press 1 2 to select ‘Audio Setup’ icon. 3 Press OK to confirm.

- - Audio Setup Page - -

Analog Output

Digital Audio Setup

Sound Mode

CD Upsampling

Night Mode

Go to Audio Setup Page

Analog Output

This options allows you to set the stereo analog output of your DVD Player.

1 In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {ANALOG OUTPUT}, then press 2.

Stereo

Select this option when output delivers sound from only the two front speakers.

LT / RT

Select this option if your DVD Player is connected to a Dolby Pro Logic decoder.

V SURR

Allows the DVD player to use virtual surround sound effects.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Digital Audio Setup

The options included in Digital Audio Setup are: ‘Digital Output’ and ‘LPCM Output’.

1 In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {DIGITAL AUDIO SETUP}, then press 2.

2 Press the 3 4 keys to highlight an option. 3 Enter its submenu by pressing 2. 4 Press 3 4 to select a setting, then press

OK to confirm your selection.

Digital Output

Set the Digital output according to your optional audio equipment connection.

➜ Off: Turn off the digital output.

All: If you have connected your

➜

DIGITAL AUDIO OUT to a multi-channel decoder/receiver.

➜ PCM Only: Only if your receiver is

not capable of decoding multi-channel audio.

Helpful Hints: – If DIGITAL OUTPUT is set to ‘All’, all audio settings except MUTE are invalid.

LPCM Output

If you connect the DVD Player to a PCM compatible receiver via the digital terminals, such as coaxial or optical etc, you may need to adjust ‘LPCM Output’. Discs are recorded at a certain sampling rate. The higher the sampling rate, the better the sound quality.

48K: Playback a disc recorded at the

➜

sampling rate of 48kHz.

➜ 96K: Playback a disc recorded at the

sampling rate of 96kHz that can only be achieved in Stereo-Classic (Flat) mode.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM30

DVD Setup Menu Options

Sound Mode

The options included in Sound Mode Setup are: ‘3D’, ‘Movie Mode’ and ‘Music Mode’.

1 In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {SOUND MODE}, then press 2.

2 Press the 3 4 keys to highlight an option. 3 Enter its submenu by pressing 2. 4 Press 3 4 to select a setting, then press

OK to confirm your selection.

This function provides a virtual surround sound experience using just two speakers.

Off, Living Room, Hall, Arena and

➜

Church

Movie Mode

Select a Sound Mode that matches the type of music you are playing. These preset Sound Modes adjust the frequency bands of the video to enhance your favorite movie sound track.

Off, Sci-Fic, Action, Drama and

➜

Concert

Music Mode

Select a Sound Mode that matches the type of music you are playing. These preset Sound Modes adjust the frequency bands of the audio to enhance your favorite music.

Off, Digital, Rock, Classic and Jazz

➜

CD Upsampling

This feature allows you to convert your music CD to a higher sampling rate using sophisticated digital signal processing for better sound quality. If you have activated the upsampling, the player will automatically switch to stereo mode.

1 In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {CD UPSAMPLING}, then press 2.

OFF

Select this to disable CD-upsampling.

88.2 kHz (X2)

Select this to convert the sampling rate of the CDs twice higher than the original.

176.4 kHz (X4)

Select this to convert the sampling rate of the CDs four times higher than the original.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Helpful Hint: – CD upsampling feature is only applicable to stereo output setting.

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:24 AM31

DVD Setup Menu Options

English

Night Mode - turning on/off

In this mode, the high volume outputs are softened. It is useful for watching your favorite action movie without disturbing others at night.

1 In ‘AUDIO SETUP PAGE’, press 3 4 to

highlight {NIGHT MODE}, then press 2.

Select this to level out the volume. This feature is only available for movies with Dolby Digital mode.

OFF

Select this when you want to enjoy the surround sound with its full dynamic range.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Video Setup Menu

1 In disc mode, press SETUP. 2 Press 1 2 to select ‘Video Setup’ icon. 3 Press OK to confirm.

- - Video Setup Page - -

TV Type

TV Display

Progressive

Picture Setting

Go To Video Setup Page

TV Type

This menu contains the options for selecting the color system that matches the connected TV. For details, see page

16.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM32

DVD Setup Menu Options

Setting the TV Display

Set the aspect ratio of the DVD Player according to the TV you have connected. The format you select must be available on the disc. If it is not, the setting for TV display will not affect the picture during playback.

1 In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {TV DISPLAY}, then press 2.

2 Press 3 4 to highlight one of the options

below:

4:3 PAN SCAN –

Select this if you have a normal TV and want both sides of the picture to be trimmed or formatted to fit your TV screen.

4:3 LETTER BOX – Select this if you have a normal TV. In this case, a wide picture with black bands on the upper and lower portions of the TV screen will be displayed.

16:9 – Select this if you have a widescreen TV.

Progressive - turning on/off

In the progressive scan mode, you can enjoy the high quality picture with less flickers. It only works when you have connected the DVD player’s Y Pb Pr jacks to your TV that supports the progressive video input. Otherwise, a distorted picture will appear on the TV. For proper progressive scan set up, see page 15.

1 In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {PROGRESSIVE}, then press 2.

OFF

To disable Progressive Scan function.

To enable Progressive Scan function.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

➜ Follow the instructions shown on the

TV to confirm the selection (if any).

➜ If a distorted picture appears on the TV

screen, wait for 15 seconds for auto recovery.

English

3 Select an item and press OK.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM33

DVD Setup Menu Options

English

Picture Setting

This DVD Player provides three predefined sets of picture color settings and one personal setting which you can define yourself.

● You can also press SMART PICTURE

on the DVD player’s front panel to directly access to the picture color settings.

1 In ‘VIDEO SETUP PAGE’, press 3 4 to

highlight {PICTURE SETTING}, then press

STANDARD

Select this for standard picture setting.

VIVID

Select this to make the TV picture brighter.

COOL

Select this to make the TV picture softer.

PERSONAL

Select this to personalise your picture color by adjusting the brightness, contrast, tint and color (saturation).

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

3 If you select {PERSONAL}, then proceed

to steps

➜ The ‘personal picture setup’ menu

appears.

4~7.

Personal Picture Setup

4 Press 3 4 to highlight one of the

following options.

BRIGHTNESS

Increase the value to brighten the picture or vice versa. Choose zero (0) for average setting.

CONTRAST

Increase the value to sharpen the picture or vice versa. Choose zero (0) to balance the contrast.

TINT

Increase the value to darken the picture or vice versa. Choose zero (0) for average setting.

COLOR

Increase the value to enhance the color in your picture or vice versa. Choose zero (0) to balance the color.

5 Press 1 2 to adjust the setting that best

suits your personal preference.

6 Repeat steps 4~5 for adjusting other

color features.

7 Press OK to confirm.

Brightness

Contrast

Tint

Color

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM34

DVD Setup Menu Options

Preference Page

1 Press Ç twice to stop playback (if any),

then press SETUP.

2 Press 1 2 to select the ‘Pr eference Page’

icon.

3 Press OK to confirm.

- - Preference Page - -

Audio Subtitle Disc Menu Parental PBC Mp3 / Jpeg Nav Password

Go To Preference Page

Audio, Subtitle, Disc Menu

These menus contain various language options for audio, subtitle and disc menu which may be recorded on the DVD. For details, see page 17.

Restricting playback by Parental Control

Some DVDs may have a parental level assigned to the complete disc or to certain scenes on the disc. This feature lets you set a playback limitation level. The rating levels are from 1 to 8 and are country dependent. You can prohibit the playing of certain discs that are not suitable for your children or have certain discs played with alternative scenes.

1 In ‘PREFERENCE PAGE’, press 3 4 to

highlight {PARENTAL}, then press 2.

- - Preference Page - -

Audio 1 KID SAFE Subtitle 2 G Disc Menu 3 PG

Parental 4 PG 13

PBC 5 PGR Mp3 / Jpeg Nav 6 R Password 7 NC17

Set KID SAFE

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM35

DVD Setup Menu Options

English

Restricting playback by Parental Control

2 Press 3 4 to highlight a rating level for

the disc inserted and press OK.

➜ To disable Parental controls and have

all Discs play, select {8 ADULT}.

3 Use the numeric keypad (0-9) to enter

the six-digit password (see page 37 “Changing the password”).

➜ DVDs that are rated above the level

you selected will not play unless you enter your six-digit password.

Helpful Hints: – VCD, SVCD, CD have no level indication, so parental control function has no effect on these type of discs. This applies to most illegal DVD discs. – Some DVDs are not encoded with a rating though the movie rating may be printed on the Disc cover. The rating level feature does not work for such Discs.

PBC

You can set the PBC to ON or OFF. This feature is available only on Video CD 2.0 with playback control (PBC) feature. For details, see page 23.

MP3/JPEG Menu - turning on/off

MP3/JPEG Navigator can be set only if the disc is recorded with menu. It allows you to select different display menus for easy navigation.

1 In ‘PREFERENCE PAGE’, press 3 4 to

highlight {MP3/JPEG NAV}, then press 2.

WITHOUT MENU

Select this to display all the files contained in the MP3/Picture CD.

WITH MENU

Select this to display only the folder menu of the MP3/Picture CD.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM36

DVD Setup Menu Options

Changing the Password

The same password is used for both Parental Control and Disc Lock. Enter your six-digit password when prompted on the screen. The default password is

136900.

1 In ‘PREFERENCE PAGE’, press 3 4 to

highlight {PASSWORD}, then press 2 to select {CHANGE}.

2 Press OK and the menu appears.

Old Password

New Password

Confirm PWD

3 Use the numeric keypad (0-9) to enter

your old six-digit password.

➜ When doing this for the first time, key

136900’.

in ‘

➜ If you forget your old six-digit

password, key in ‘

136900’.

4 Enter the new six-digit password. 5 Enter the new six-digit password a second

time to confirm.

➜ The new six-digit password will now

take effect.

6 Press OK to confirm.

Setting the DivX Subtitle font

You can set the font type that supports the recorded DivX subtitle.

1 In ‘PREFERENCE PAGE’, press 3 4 to

highlight {DivX SUBTITLE}, then press 2.

Standard

Albanian, Danish, Dutch, English, Finnish, French, Gaelic, German, Italian, Kurdish (Latin), Norwegian, Portuguese, Spanish, Swedish and Turkish.

2 Press 3 4 to select a setting, then press

OK to confirm your selection.

Restoring to original settings

Setting the DEFAULT function will reset all options and your personal settings to the factory defaults, except your password for Parental Control and Disc Lock.

1 In ‘PREFERENCE PAGE’, press 34 to

highlight {DEFAULT}, then press 2 to select {RESET}.

2 Press OK to confirm.

➜ All settings will now reset to factory

defaults.

English

TIPS: The underlined option is the factory default setting.

Press 1 to go back to the previous menu item. Press SETUP to exit the menu item.

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM37

Troubleshooting

English

WARNING Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty. Do not open the system as there is a risk of electric shock.

If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to remedy a problem by following these hints, consult your dealer or Philips for help.

Problem Solution

No power – Check if the AC power cord is properly connected.

– Press the STANDBY ON on the front of the DVD

system to turn on the power.

No picture – Refer to your TV’s manual for correct Video In

channel selection. Change the TV channel until you

see the DVD screen. – Check if the TV is switched on. – If the progressive scan feature is activated but the

connected TV does not suppor t progressive signals

or the cables are not connected accordingly, see

page 15 for proper progressive scan set up or

deactivate the progressive scan feature as below:

1) Turn off your TV progressive scan mode or turn on

to interlaced mode.

2) Press OPEN/CLOSE to open the disc tray.

3) Press numeric keypad ‘1’ on the remote control for

few seconds.

Distorted picture – Sometimes a small amount of picture distortion may

appear depending on the disc being played back. This

is not a malfunction.

Completely distorted picture or – Connect DVD Player directly to the TV. black/white picture with DVD – Make sure the disc is compatible with the DVD/

Player. – Ensure that the DVD Player’s TV Type is set to match

that of the Disc and your TV.

No sound or distorted sound – Adjust the volume.

– Check that the speakers are connected correctly.

No audio at digital output – Check the digital connections.

– Check if your receiver can decode MPEG-2 and if

not, please make sure the digital output is set to

PCM. – Check if the audio format of the selected audio

language matches your receiver capabilities.

–

Visit us at www.philips.com/support for service support

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM38

Troubleshooting

Problem Solution

Disc can’t be played – The DVD+R/CD-R must be finalized.

– Ensure the disc label is facing up. – Check if the disc is defective by trying another disc. – Region code incorrect.

Picture freezes momentarily – Check the disc for fingerprints/scratches and during playback clean with a soft cloth wiping from center to edge.

No return to start-up screen when – Reset the unit by switching the player off, then on disc is removed again.

The player does not respond to – Aim the Remote Control directly at the sensor the Remote Control on the front of the player.

– Reduce the distance to the player. – Replace the batteries in the Remote Control. – Re-insert the batteries with their polarities (+/–

signs) as indicated.

Buttons do not work – To completely reset the player, unplug the AC

cord from the AC outlet for 5-10 seconds.

Player does not respond to some – Operations may not be permitted by the disc. operating commands during playback. Refer to the instructions of the disc jacket.

DVD Player cannot read – Use a commonly available cleaning CD/DVD to CDs/DVDs clean the lens before sending the DVD Player for

repair.

Menu items cannot be selected – Press STOP twice before selecting System Menu.

– Depending on the disc availability, some menu items

cannot be selected.

Unable to play DivX movies – Check that the DivX file is encoded in ‘Home

Theater’ mode with DivX 5.x encoder.

Unable to select Progressive Scan on/off – Check that the output of the video signal is switch to

‘YUV’.

No sound during DivX movies playback – The audio codec may not be supported by the DVD

player.

An DivX movies does not repeat – Check that file size of the movies does not exceed

the file size of the CD disc during burning.

English

Visit us at www.philips.com/support for service support

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM39

Specifications

TV STANDARD (PAL/50Hz) (NTSC/60Hz)

English

Number of lines 625 525 Playback Multistandard (PAL/NTSC)

VIDEO PERFORMANCE

Video DAC 12 bit, 108mHz YPbPr 0.7 Vpp — 75 ohm Video Output 1Vpp — 75 ohm RGB (SCART) 0.7 Vpp — 75 ohm

VIDEO FORMAT

Digital Compression MPEG 2 for DVD,SVCD

DVD 50Hz 60Hz

Horiz. resolution 720 pixels 720 pixels Vertical resolution 576 lines 480 lines

VCD 50Hz 60Hz

Horiz. resolution 352 pixels 352 pixels Vertical resolution 288 lines 240 lines

MPEG 1 for VCD DivX

AUDIO FORMAT

Digital MPEG/ AC-3/ compressed Digital

MP3(ISO 9660) 96, 112, 128, 256

Analog Sound Stereo Dolby Surround compatible downmix from Dolby Digital multi-channel sound

PCM 16, 20, 24 bits

fs, 44.1, 48, 96 kHz

kbps & variable bit rate fs, 32, 44.1, 48 kHz

AUDIO PERFORMANCE

DA Converter 24 bit, 192 kHz

DVD fs 96 kHz 4Hz- 44kHz

fs 48 kHz 4Hz- 22kHz

SVCD fs 48 kHz 4Hz- 22kHz

fs 44.1kHz 4Hz- 20kHz CD/VCD fs 44.1kHz 4Hz- 20kHz Signal-Noise (1kHz) > 90 dB Dynamic range(1kHz) > 80 dB Crosstalk (1kHz) > 70 dB Distortion/noise (1kHz) > 65 dB MPEG MP3 MPEG Audio L3

CONNECTIONS

Scart Output Euroconnector YPbPr Output Cinch 3x Video Output Cinch (yellow) Audio Output(L+R) Cinch (white/red) Digital Output 1 coaxial

IEC60958 for CDDA / LPCM

IEC61937 for MPEG 1/2,

Dolby Digital

CABINET

Dimensions (w x h x d) 435 x 37 x 235 mm Weight Approximately 2.0 kg

POWER CONSUMPTION

Power Supply Rating 110V – 220V;

50/60 Hz Power consumption < 10 W Power consumption in Standby mode < 0.8 W

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM40

Specifications subject to change without prior notice

Glossary

Analog: Sound that has not been turned into

numbers. Analog sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. Aspect ratio: The ratio of vertical and horizontal sizes of a displayed image. The horizontal vs. vertical ratio of conventional TVs. is 4:3, and that of widescreens is 16:9. AUDIO OUT Jacks: Jacks on the back of the DVD System that send audio to another system (TV, Stereo, etc.). Bit Rate: The amount of data used to hold a given length of music; measured in kilobits per seconds, or kbps. Or, the speed at which you record. Generally, the higher the bit rate, or the higher the recording speed, the better the sound quality. However, higher bit rates use more space on a Disc. Chapter: Sections of a picture or a music piece on a DVD that are smaller than titles. A title is composed of several chapters. Each chapter is assigned a chapter number enabling you to locate the chapter you want. Component Video Out Jacks: Jacks on the back of the DVD System that send high-quality video to a TV that has Component Video In jacks (R/G/B, Y/Pb/Pr, etc.). Disc menu: A screen display prepared for allowing selection of images, sounds, subtitles, multi-angles, etc recorded on a DVD. Digital: Sound that has been converted into numerical values. Digital sound is available when you use the DIGITAL AUDIO OUT COAXIAL or OPTICAL jacks. These jacks send audio through multiple channels, instead of just two channels as analog does. DivX 3.11/4.x/5.x: The DivX codec is a patentpending, MPEG-4 based video compression technology, developed by DivXNetworks, Inc., that can shrink digital video to sizes small enough to be transported over the internet, while maintaining high

visual quality.

Dolby Digital: A surround sound system developed

by Dolby Laboratories containing up to six channels of digital audio (front left and right, surround left and right, center and subwoofer). DTS: Digital Theatre Systems. This is a surround sound system, but it is different from Dolby Digital. The formats were developed by different companies. JPEG: A very common digital still picture format. A still-picture data compression system proposed by the Joint Photographic Expert Group, which features small decrease in image quality in spite of its high compression ratio. MP3: A file format with a sound data compression

system. “MP3” is the abbreviation of Motion Picture Experts Group 1 (or MPEG-1) Audio Layer 3. By using MP3 format. one CD-R or CD-RW can contain about 10 times as much data volume as a regular CD can. Multichannel: DVD is specified to have each sound track constitute one sound field. Multichannel refers to a structure of sound tracks having three or more channels. Parental Control: A function of the DVD to limit playback of the disc by the age of the users according to the limitation level in each country. The limitation varies from disc to disc; when it is activated, playback will be prohibited if the software’s level is higher than the user-set level. PCM (Pulse Code Modulation): A system for converting analog sound signal to digital signal for later processing, with no data compression used in conversion. Playback control (PBC): Refers to the signal recorded on video CDs or SVCDs for controlling reproduction. By using menu screens recorded on a Video CD or SVCD that supports PBC, you can enjoy interactive-type software as well as software having a search function. Progressive Scan: It displays all the horizontal lines of a picture at one time, as a signal frame. This system can convert the interlaced video from DVD into progressive format for connection to a progressive display. It dramatically increases the vertical resolution. Region code: A system for allowing discs to be played back only in the region designated beforehand. This unit will only play discs that have compatible region codes. You can find the region code of your unit by looking on the product label. Some discs are compatible with more than one region (or ALL regions). Surround: A system for creating realistic threedimensional sound fields full of realism by arranging multiple speakers around the listener. Title: The longest section of a picture or music feature on DVD, music, etc., in video software, or the entire album in audio software. Each title is assigned a title number enabling you to locate the title you want. VIDEO OUT jack: Jack on the back of the DVD System that sends video to a TV.

English

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM41

English

Meet Philips at the Internet

http://www.philips.com

01-42 DVP5140K_03_eng_RC3 04/07/06, 10:25 AM42

DVP 5140K

CLASS 1

LASER PRODUCT

Sgp-SL-0626/03-2_RC3

Philips DVP5140K 03 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
