Philips DVP3982, DVP3962 User Manual
Thank you for choosing Philips.
Need help fast?
Read your Quick Start Guide and/or
User Manual first for quick tips
that make using your Philips product
more enjoyable.
Register your product and
get support at
www.philips.com/welcome
or call
1-888-PHILIPS (744-5477)
while with your product
(and Model / Serial number)
S
T
O
P
Philips vous remercie de
votre confiance.
Besoin d'une aide
rapide?
Le Guide rapide de début et
Manuel de l'utilisateur regorgent
d'astuces destinées à simplifier
l'utilisation de votre produit Philips.
ou formez le
1-800-661-6162 (Francophone)
1-888-PHILIPS (744-5477)
(English speaking)
Veillez à avoir votre produit à
portée de main
(et model / serial nombre)
A
R
R
ÊT
Gracias por escoger Philips
Necesita ayuda
inmediata?
Lea primero la Guía rápida del
comienzo o el Manual del usuario,
en donde encontrará consejos que
le ayudarán a disfrutar plenamente
de su producto Philips.
o llame al teléfono
1-888-PHILIPS (744-5477)
y tenga a mano el producto
(y número de model / serial)
A
L
T
O
Enregistrez votre produit et
accédez à l'assistance sur
www.philips.com/welcome
Visite
www.philips.com/welcome
para registrar su producto y
obtener información de
contacto y asistencia.
Register your product and get support at
www.philips.com/welcome
DVP3962
DVP3982
EN DVD Video Player 6
FR CA Lecteur de DVD 54
ES LA Reproductor de video DVD 104
dvp3962_3982_37_eng1.indd 1 2008-05-05 2:17:38 PM
2
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out.
Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to
ensure:
Return your Product Registration Card or register online at
www.philips.com/welcome today to get the very most from your purchase.
Visit our World Wide Web Site at http://www.philips.com/welcome
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS.You’ve selected one of
the best-built, best-backed products available today.We’ll do everything in our power to keep you happy with your purchase for many
years to come.
As a member of the PHILIPS “family,” you’re entitled to protection
by one of the most comprehensive warranties and outstanding
service networks in the industry.What’s more, your purchase guarantees you’ll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient
home shopping network.
Most importantly, you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome - and thanks for investing
in a PHILIPS product.
P.S. To get the most from your PHILIPS purchase, be
sure to complete and return your Product Registration
Card at once,or register online at:
www.philips.com/welcome
For Customer Use
Enter below the Serial No. which is located on the rear of the cabinet. Retain this
information for future reference.
Model No.__________________________
Serial No. ________________________
Know these
safetysymbols
This “bolt of lightning” indicates unin-
sulated material within your unit may
cause an electrical shock. For the safety of
everyone in your household, please do not
remove product covering.
The “exclamation point” calls atten-
tion to features for which you should
read the enclosed literature closely to prevent operating and maintenance problems.
WARNING:To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects
filled with liquids, such as vases, should not
be placed on this apparatus.
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot, fully
insert.
ATTENTION: Pour éviter les choc électriques, introduire la lame la plus large de la
fiche dans la borne correspondante de la
prise et pousser jusqu’au fond.
CA U T I ON
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
*Proof of
Purchase
Returning the enclosed card guarantees
that your date of purchase will be on file,
so no additional paperwork will be
required from you to obtain warranty
service.
*Product Safety
Notification
By registering your product, you'll receive
notification - directly from the manufacturer - in the rare case of a product
recall or safety defect.
*Additional Benefits
Registering your product guarantees that
you'll receive all of the privileges to
which you're entitled, including special
money-saving offers.
Where the MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
dvp3962_3982_37_eng1.indd 2 2008-05-05 2:17:38 PM
3
1.
Read these instructions.
2. Keep these instructions.
3.
Heed all warnings.
4. Follow all instructions.
5.
Do not use this apparatus near
water.
6.
Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer´s instructions.
8.
Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the
safety purpose of the
polarized or
grounding-type plug.
A polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the provided plug
does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10.
Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11.
Only use attachments/accessories
specified by the manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer or sold with
the apparatus. When a car t is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13.
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14.
Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15.
Battery usage CAUTION – To
prevent battery leakage which may result in
bodily injury, property damage, or damage
to the unit:
Install all batteries correctly, + and - as
marked on the unit.
Do not mix batteries (old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not used
for a long time.
IMPORTANT SAFETY INSTRUCTIONS
AC Polarized
Plug
16. Apparatus shall not be exposed to
dripping or splashing.
17. Do not place any sources of danger
on the apparatus (e.g. liquid filled
objects, lighted candles).
18. This product may contain lead and mercury.
Disposal of these materials may be regulated
due to environmental considerations.
For disposal or recycling information,
please contact your local authorities
or the Electronic Industries Alliance :
www.eiae.org.
EL 6475-E005: 04/01
Class II equipment symbol
This symbol indicates that the unit has
a double insulation system
dvp3962_3982_37_eng1.indd 3 2008-05-05 2:17:40 PM
4
Canada
English:
This digital apparatus does not exceed
the Class B limits for radio noise
emissions from digital apparatus as set
out in the Radio Interference
Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies
with Canadian ICES-003.
Français:
Cet appareil numérique n’emet pas de
bruits radioélectriques dépassant les
limites applicables aux appareils
numériques de Class B prescrites dans
le Règlement sur le Brouillage
Radioélectrique édicté par le Ministère
des Communications du Canada.
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
This warning label is located on the rearside
and inside this laser product.
CAUTION
:
INVISIBLE
LASER RADIATION
WHEN OPEN.
DO NOT STARE INTO BEAM.
DANGER
:
INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
VARO!
AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTIINANAKYMATTOMAALLE LASERSATEILYLLE.ALA
KATSO SATEESEEN.
VARNING!
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD.
OCH SPARREN AR URKOPPLAD.BETRAKTA EJ STRÅLEN.
DANGER - Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
or
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
ATTENTION
L’utilisation des commandes ou réglages
ou le non-respect des procédures ciincluses
peuvent se traduire par une
exposition dangereuse à l’irradiation.
ATENCIÓN
El uso de mando o ajustes o la ejecucción
de métodos que no sean los aquí descritos
puede ocasionar peligro de exposición a
radiación.
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE
ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING OUR TV SET COMPATIBILITY WITH THIS
MODEL 525p AND 625p DVD PLAYER, PLEASE
CONTACT OUR CUSTOMER SERVICE CENTER.’
Declaration of Conformity
Model number: DVP3962, DVP3982
Trade Name: Philips
Responsible Party: Philips Consumer Electronics
A Division of Philips Electronics
North America Corp.
P. O. Box 671539
Marietta, GA 30006-0026
1-800-PHILIPS (744-5477)
LASER
Type Semiconductor laser
InGaAlP (DVD)
AIGaAs (CD)
Wave length 658 nm (DVD)
790 nm (CD)
Output Power 7.0 mW (DVD)
10.0 mW (VCD/CD)
Beam divergence 60 degrees
dvp3962_3982_37_eng1.indd 4 2008-05-05 2:17:41 PM
5
5
English ------------------------------------ 6
Français ---------------------------------- 54
Español -------------------------------- 104
Index
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
Manufactured under license from Dolby
Laboratories, Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Windows Media and the Windows logo are
trademarks, or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
DivX, DivX Ultra Certied, and associated
logos are trademarks of DivX, Inc. and are
used under license.
HDMI and HDMI logo and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing
LLC.
EnglishFrançaisEspañol
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and
other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reserve engineering or disassembly is prohibited.
dvp3962_3982_37_eng1.indd 5 2008-05-05 2:17:42 PM
Engl ish
6
Table of contents
General
General Information ........................................................................................................8
Setup precautions .................................................................................................................................................8
Accessories supplied ...........................................................................................................................................8
Cleaning discs ........................................................................................................................................................8
About recycling ..................................................................................................................................................... 8
Product Overview
Your DVD Player ............................................................................................................... 9
Remote Control .........................................................................................................10-12
Using the remote control ................................................................................................................................12
Connections
Basic Connections ..................................................................................................... 13-16
Step 1: Connecting to television ..............................................................................................................13-15
Option 1: Using Composite Video jacks (CVBS) ...............................................................................13
Option 2: Using Component Video jacks (Y Pb Pr) ..........................................................................13
Option 3: Using HDMI or DVI TV jack ................................................................................................14
Option 4: Using an accessory RF modulator ......................................................................................15
Step 2: Connecting the power cord ..............................................................................................................16
Optional Connections .................................................................................................... 17
Connecting to an Analog Stereo System .....................................................................................................17
Connecting to a Digital AV Amplier/Receiver .........................................................................................17
Basic Setup
Getting Started ..........................................................................................................18-20
Finding the correct viewing channel .............................................................................................................18
Setting language preferences .....................................................................................................................18-19
On-screen display (OSD) language ........................................................................................................18
Audio, Subtitle and Menu language for DVD playback .....................................................................19
Setting up Progressive Scan feature ............................................................................................................. 20
Disc Playback
Disc Operations .........................................................................................................21-31
Playable discs .......................................................................................................................................................21
Region codes for DVD discs ...........................................................................................................................21
Playing a disc ....................................................................................................................................................... 22
Basic playback controls .............................................................................................................................. 22-23
Selecting various repeat /shuf e functions ...................................................................................................23
Repeating a specic section (A-B) .................................................................................................................24
Other playback features for video discs ............................................................................................... 24-25
Using the Disc Menu ..................................................................................................................................24
Zooming........................................................................................................................................................ 25
Changing sound track language .............................................................................................................. 25
Changing subtitle language ...................................................................................................................... 25
Playback Control (VCD/SVCD) ............................................................................................................. 25
dvp3962_3982_37_eng1.indd 6 2008-05-05 2:17:42 PM
Engl ish
7
Table of contents
Using Display menu options ..................................................................................................................... 26-27
Selecting title/chapter/track .....................................................................................................................26
Searching by time ........................................................................................................................................26
Viewing playing time ...................................................................................................................................27
Switching camera angles (DVD only) ....................................................................................................27
Preview function (VCD/SVCD/DVD) ....................................................................................................27
Special Audio CD feature ............................................................................................................................... 28
Playing a DivX® disc ............................................................................................................................. 29
Playing a JPEG photo disc (slide show) ........................................................................................................ 30
Preview function ......................................................................................................................................... 30
Zooming........................................................................................................................................................ 30
Flip/Rotate picture ..................................................................................................................................... 30
Playing a MP3/ WMA disc ................................................................................................................................31
Playing music and photo les simultaneously .............................................................................................32
Setup Options
Setup Menu Options ................................................................................................. 33-44
Accessing the setup menu ................................................................................................................................33
General Setup Page ............................................................................................................................. 34-35
Audio Setup Page ................................................................................................................................. 36-38
Video Setup Page .................................................................................................................................. 39- 42
Preference Page .................................................................................................................................... 43-44
Others
Software upgrade ...........................................................................................................45
Installing the latest software .......................................................................................................................... 45
Troubleshooting ........................................................................................................46-48
Specications .................................................................................................................. 49
Glossary...................................................................................................................... 50-51
dvp3962_3982_37_eng1.indd 7 2008-05-05 2:17:42 PM
Engl ish
8
General Information
WARNING!
This unit does not contain any userserviceable parts. Please leave all
maintenance work to qualied
personnel.
Setup precautions
Finding a suitable location
– Place this unit on a at, hard and stable
surface. Never place the unit on a carpet.
– Never place this unit on top of other
equipment that might heat it up (e.g.,
receiver or amplier).
– Never put anything under this unit
(e.g., CDs, magazines).
– Install this unit near the AC outlet
where the AC power plug can be easily
reached.
Space for ventilation
– Place this unit in a location with
adequate ventilation to prevent internal
heat build up. Allow at least 10 cm (4”)
clearance from the rear and the top of
this unit and 5 cm (2”) from the left and
right to prevent overheating.
Avoid high temperature, moisture,
water and dust
– This unit must not be exposed to
dripping or splashing.
– Never place any object or items that
can damage this unit (e.g., liquid lled
objects, lighted candles).
Accessories supplied
– 1 remote control with batteries
– 1 audio/video cables (yellow/white/
red)
Cleaning discs
CAUTION!
Risk of damage to discs! Never use
solvents such as benzene, thinner,
cleaners available commercially, or antistatic sprays intended for discs.
l
Wipe the disc with a micro bre cleaning
cloth from the center to the edge in a
straight line movement.
About recycling
This user manual is printed on nonpolluting paper. This unit contains a large
number of materials that can be recycled.
If you are disposing an old equipment,
please take it to a recycling center.
Please observe the local regulations
regarding disposal of packaging materials,
exhausted batteries and old equipment.
dvp3962_3982_37_eng1.indd 8 2008-05-05 2:17:43 PM
Engl ish
9
Your DVD Player
a STANDBY-ON
– Turns on this unit or turns off to normal
standby mode.
b Disc tray
c OPEN/CLOSE ç
– Opens/closes the disc tray.
d Display panel
– Show information about the current
status of this unit.
e IR Sensor
– Point the remote control towards this
sensor.
f PLAY/PAUSE u
– Starts/pauses playback.
g STOP Ç
– Stops playback.
Front Panel View
dvp3962_3982_37_eng1.indd 9 2008-05-05 2:17:43 PM
Engl ish
10
Remote Control
4
3
6
7
9
8
1
5
2
a 2
– Turns on this unit or turns off to normal
standby mode.
b ç (Open/Close)
– Opens/closes the disc tray. Opens/closes the disc tray.
c DISPLAY
– Displays the current status or disc
information.
d
– : Move cursor to up or down.
: Press up or down for a slow : Press up or down for a slowress up or down for a slow
forward or backward search.backward search.ackward search.
– : Move cursor to left or right.Move cursor to left or right.
: Press left or right for fast forward
or backward search.
e SETUPSETUP
– Enters or exits the disc setup menu.
f u (Play/Pause)
– Starts or pauses playback.
g
Ç
(Stop)
– Exit an operation.
– Stops playback.
h Numeric keypad 0-9Numeric keypad 0-9
– Selects a track or title number of the
disc.
i AUDIOAUDIO
– Selects an audio language or channel.
dvp3962_3982_37_eng1.indd 10 2008-05-05 2:17:43 PM
Engl ish
11
10
16
17
11
12
15
13
14
j DISC MENU
– Enters or exits disc contents menu.
– For VCD 2.0 and SVCD, switches on or
off the playback control mode.
k OK
– Conrms an entry or selection.
l RETURN/TITLE
– Returns to the previous menu or shows
title menu.
m . / > (Previous/Next)
– Skips to the previous or next title/
chapter/track.
– Press and hold this button for fast
forward or backward search.
n (Mute)
– Mutes or restores the volume.
o SUBTITLESUBTITLE
– Selects a DVD subtitle language.
p ZOOMOOM
– Zoom the picture on the TV.
q REPEATREPEAT
– Selects various repeat modes.
– Turns off repeat mode.
REPEAT A-B
– Repeat a specic section of a disc.
Remote Control (continued)
dvp3962_3982_37_eng1.indd 11 2008-05-05 2:17:44 PM
Engl ish
12
Remote Control (continued)
Using the remote control
A Open the battery compartment.
B Insert two batteries type R03 or AAA,
following the indications (+-) inside
the compartment.
C Close the cover.
D Point the remote control directly at the
remote sensor (IR) on the front panel.
Note:
Never place any objects between the
remote control and this unit while
operating.
E Select the desired function (for example
u).
CAUTION!
– Remove batteries if they are
exhausted or if the remote control
is not to be used for a long time.
– Never mix batteries (old and new
or carbon and alkaline, etc.).
– Batteries contain chemical
substances; they should be disposed
of properly.
dvp3962_3982_37_eng1.indd 12 2008-05-05 2:17:44 PM
Engl ish
13
Basic Connections
Step 1: Connecting to
television
This connection enables you to view the
video playback from this unit. You only
need to choose one of the options below
to make the video connection.
– For a standard TV, follow option 1.
– For a progressive scan TV, follow
option 2.
– For a HDMI TV, follow option 3.
– For TV with only a single antenna
input jack, follow option 4.
Option 1: Using Composite Video
jacks (CVBS)
You can connect this unit to a TV
through the composite video cable which
provides good picture quality.
l
Connect the audio/video cables (supplied)
from the TV OUT and AUDIO OUT
L/R jacks on this unit to the video input
jack (yellow) and audio input jacks (red/
white) on your TV.
Option 2: Using Component Video
jacks (Y Pb Pr)
You can connect this unit to a TV
through the component video cables
which provides superior picture quality.
The progressive scan video quality is only
available when using Y Pb Pr connection
and a progressive scan TV is required.
A Connect the component video cables
(red/blue/green - not supplied) from the
Y Pb Pr jacks on this unit to the
corresponding component video input
jacks (or labeled as Y Pb/Cb Pr/Cr or
YUV) on your TV.
B Connect the audio/video cable (red/white
- supplied) from the AUDIO OUT L/R
jacks on this unit to the audio input jacks
(red/white) on your TV. Leave the yellow
video cable disconnected.
C Proceed to ‘Getting Started - Setting up
Progressive Scan feature’ for detailed
progressive feature setup.
TV
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
TV OUT
HDMI OUT
Pb
PrY
COMPONENT VIDEO OUT
AUDIO OUT
DIGITAL
OUT
COAXIAL
Video
(yellow cable)
Audio
(red/white cables)
TV OUT
HDMI OUT
Pb
PrY
COMPONENT VIDEO OUT
DIGITAL
OUT
COAXIAL
AUDIO OUT
TV
AUDIO
IN
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
1
2
Video
Audio
(red/white cables)
DVD player (rear)
dvp3962_3982_37_eng1.indd 13 2008-05-05 2:17:46 PM
Engl ish
14
Basic Connections (continued)
Option 3: Using HDMI or DVI TV
jack
HDMI (High Denition Multimedia
Interface) is a digital interface that allows
pure digital audio/video transmission
without the loss of image quality.
l
Connect a HDMI cable (not supplied)
from the HDMI OUT jack on this unit
to the HDMI input jack on a HDMIcompatible device (e.g., HDMI TV, HDCP
compliant DVI TV).
Note:
– This unit is EasyLink compatible. It
enables connected devices to control
each other over HDMI, see ‘Setup Menu
Options - { Video Setup > HDMI Setup >
EasyLink }’ for details.
– For HDCP compliant or DVI TV, you
need a HDMI-DVI adaptor cable (not
supplied) to connect the DVI input jack
from your TV to the HDMI OUT jack on
this unit.
Helpful Hint:
– The HDMI-DVI cable has only video
output capability. An audio connection is
required for audio output, see ‘Optional
Connections’ for details.
TV OUT
HDMI OUT
Pb
PrY
COMPONENT VIDEO OUT
DIGITAL
OUT
COAXIAL
AUDIO OUT
HDTV/
DVI TV
HDMI IN
OR
dvp3962_3982_37_eng1.indd 14 2008-05-05 2:17:46 PM
Engl ish
15
TV OUT
HDMI OUT
Pb
PrY
COMPONENT VIDEO OUT
DIGITAL
OUT
COAXIAL
AUDIO OUT
TV
Antenna
Option 4: Using an accessory
RF modulator
Use this connection if your TV has only a
single Antenna input jack (labeled as
75 ohm or RF In).
A Connect the audio/video cables (supplied)
from the TV OUT and AUDIO OUT
L/R jacks on this unit to the video input
jack (yellow) and audio input jacks (red/
white) on the RF modulator.
B Connect a RF coaxial cable (not supplied)
from the ANTENNA OUT or TO TV
jack on the RF modulator to the antenna
input jack on your TV.
C Connect the Antenna or Cable TV
service signal (not supplied) to the
antenna or RF input jack on the RF
modulator (not supplied). (It may have
been connected to your TV previously.
Disconnect it from the TV.)
Helpful Hint:
– See your electronics retailer for details
about RF modulator availability and
operations.
Back of RF Modulator
(Not supplied) (example only)
Basic Connections (continued)
dvp3962_3982_37_eng1.indd 15 2008-05-05 2:17:47 PM
Engl ish
16
Basic Connections (continued)
Step 2: Connecting the
power cord
After everything is connected
properly, plug the AC power cord
into the power outlet.
Never make or change any connections
with the power turned on.
Helpful Hint:
– Refer to the type plate at the rear or
bottom of the product for identication and
supply ratings.
TV OUT
HDMI OUT
Pb
PrY
COMPONENT VIDEO OUT
DIGITAL
OUT
COAXIAL
AUDIO OUT
dvp3962_3982_37_eng1.indd 16 2008-05-05 2:17:47 PM
Loading...
