Philips DVP3000-69, DVP3005-69 User Manual
DVD VIDEO PLAYER
User manual
Thank you for choosing Philips.
Need help fast?
Read your User’s Manual first for quick tips that make using
your Philips product more enjoyable.
If you have read your instructions and still need assistance,
you may access our online help at www.philips.com/support
DVP3005
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM1
DVP3005&3000/69_1
General Information
Environmental Information
All unnecessary packaging has been
omitted. The packaging has been made
easy to separate into two materials:
cardboard (box, buffer) and polyethylene
(bags, protective foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialised company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips Electronics
N.V. or their respective owners.
The apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids,
such as vases, shall be placed on apparatus.
Laser safety
This unit employs a laser. Due to possible
eye injury, only a qualified service person
should remove the cover or attempt to
service this device.
NOTE:
PICTURES SHOWN MAYBE
DIFFERENT BETWEEN
COUNTRIES.
CAUTION
(WARNING LOCATION: ON THE
BACKPLATE OF THE SET)
NEVER MAKE OR CHANGE
CONNECTIONS WITH THE
POWER SWITCHED ON.
Important Note:
Due to the numerous versions of new
CD-Audio copy protection or
enhanced CD-Audio protection
recently available on certain discs,
Philips is unable to guarantee that
this DVD Player is fully compatible
with such new discs. Should you have
difficulty playing any such CD-Audio
discs, kindly refer them to your CDAudio disc retailer.
For Customer Use:
Read carefully the information located at
the rear of your DVD VIDEO player and
enter below the Serial No. Retain this
information for future reference.
Model No. DVP3005
Serial No. _______________
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM2
LASER
Type Semiconductor laser
GaAlAs
Wave length 650 nm (DVD)
780 nm (VCD/CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degree
DVP3005&3000/69_1
Index
English --------------------------------------- 6
-------------------------------- 32
-------------------------------- 60
Bahasa Melayu --------------------------- 88
English
Bahasa Melayu
This product incorporates copyright
protection technology that is protected by
method claims of certain U.S. patents and
other intellectual property rights owned by
Macrovision Corporation and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, and is intended
for home and other limited viewing uses
only unless otherwise authorized by
Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM3
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro-Logic” and the
double-D symbol are trademarks of
Dolby Laboratories.
Manufactured under license from Digital
Due to the inconsistency of disc formats
Theater Systems, Inc. U.S. Pat. Nois.
provided by various disc manufacturers, your
5,451,942; 5,956,674; 5,974,380;
DVD system may require a playability
5,978,762; 6,226,616; 6,487,535 and
enhancement or upgrade. As DVD technology
other U.S. and world-wide patents issued
advances, these enhancements will become
and pending. "DTS" and "DTS Digital
common and will be easy to complete.
Surround" are registered trademarks
Go to www.philips.com/support for
of Digital Theater Systems, Inc.
software upgrade.
All Right Reserved.
DVP3005&3000/69_1
3
Contents
English
Introduction
Supplied accessories ....................................... 6
Care and safety information.......................... 6
Connections
Connecting TV .............................................. 7-8
Using Composite Video jacks (CVBS) ........ 7
Using Component Video jacks (Pr Pb Y) ... 7
Using an accessory RF modulator .............. 8
Connecting the power cord.......................... 8
Optional : Connecting to an Audio System .
............................................................................. 9
Stereo system has Dolby Pro Logic or Right
/ Left Audio In jack ......................................... 9
Optional: Connecting Digital AV Receiver ...
............................................................................. 9
Receiver has a PCM, Dolby Digital, or
MPEG2 decoder .............................................. 9
Functional Overview
Front Panels .................................................... 10
Rear Panel ....................................................... 11
Remote Control ............................................ 12
Getting Started
Step 1: Inserting batteries into the
Remote Control ............................................ 13
Using the Remote Control to operate the
Player ............................................................... 13
Step 2: Setting up the TV ........................ 13-15
Setting up Progressive Scan feature (for
Progressive Scan TV only) ........................... 14
To deactivate Progressive manually .......... 15
Selecting the colour system that
corresponds to your TV .............................. 15
Step 3: Setting language preference ...........16
Setting the OSD Language .......................... 16
Setting the Audio, Subtitle and Disc menu
language .......................................................... 16
Disc Operations
Playable Discs ................................................. 17
Region Codes ................................................. 17
Playing discs..................................................... 17
Basic playback controls................................. 18
Selecting various repeat/shuffle functions 18
Repeat play mode ......................................... 18
Repeating a section within a chapter/track .
.........................................................................
Operations for video playback ................... 19
Using the Disc Menu.................................... 19
Zooming in ..................................................... 19
Resuming playback from the last stopped
point ................................................................ 19
OSD (On-Screen Display) .......................... 19
Special DVD features ....................................20
Playing a Title ................................................. 20
Camera Angle ................................................ 20
Changing the Audio Language .................... 20
Subtitles .......................................................... 20
Special VCD & SVCD Features ................... 20
Playback Control (PBC) .............................. 20
Playing MP3/JPEG (Kodak) Picture CD ..... 21
General Operation ....................................... 21
Playback selection ......................................... 21
Repeat ............................................................. 21
Fast Forward/Reverse (MP3) ..................... 21
18
4
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM4
DVP3005&3000/69_1
DVD Menu Options
General Setup menu ..................................... 22
Dimming system’s display screen .............. 22
OSD Language ............................................... 22
Sleep ................................................................ 22
Screen Saver - turning on/off ..................... 22
Audio Setup Menu ......................................... 23
Setting the Downmix ................................... 23
Digital Audio Setup ....................................... 23
Video Setup Menu ................................... 24-25
TV Type ........................................................... 24
Setting the TV Display ................................. 24
Progressive - turning on/off........................ 25
Sharpness ........................................................ 25
Brightness/Contrast ..................................... 25
Preference Page........................................ 26-27
Audio, Subtitle, Disc Menu .......................... 26
Restricting playback by Parental Control .....
......................................................................... 26
Changing the Password ............................... 27
Restoring to original settings ..................... 27
Troubleshooting ......................... 28–29
Specifications ......................................30
Contents
English
Glossary ......................................................................31
Language Code............................................ 116
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM5
5
DVP3005&3000/69_1
Introduction
PREVIEW
MUTE
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
PHILIPS
English
Supplied accessories
Video cable
(yellow)
Audio cable
(white, red)
Remote Control
and
two AA batteries
Care and safety information
● Power consumption
– When the system is switched to
Standby mode, it is still consuming power.
To disconnect the system from the power
supply completely, remove the AC power
plug from the wall jack.
● Avoid high temperatures, moisture,
water and dust
– Do not expose the player, batteries or
discs to humidity, rain, sand or excessive
heat (caused by heating equipment or
direct sunlight.)
● Avoid condensation problem
– The lens may cloud over when the
player is suddenly moved from cold to
warm surroundings, making it impossible
to play a disc. Leave the player in the
warm environment until the moisture
evaporates.
● Do not block the vents
– Do not operate the DVD Player in an
enclosed cabinet, allow about 10 cm (4
inches) of free space all around the player
for adequate ventilation.
● Care of the cabinet
– Use a soft cloth slightly moistened with
PREVIEW
MUTE
a mild detergent solution. Do not use a
solution containing alcohol, spirits,
ammonia or abrasives.
● Finding a suitable location
– Place the player on a flat, hard, and
stable surface.
● Disc handling
– To clean a CD, wipe it in a
straight line from the center
towards the edge using a soft,
lint-free cloth. A cleaning
agent may damage the disc!
– Write only on the printed
side of a CDR(W) and only with a soft felttipped pen.
– Handle the disc by its edge, do not
touch the surface.
6
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM6
DVP3005&3000/69_1
Connecting TV
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
2
1
COMPONENT
VIDEO IN
S-VIDEO
IN
V (Pr/Cr)
AUDIO
OUT
U (Pb/Cb)
VIDEO IN
Y
S-VIDEO
VIDEO IN
Connections
English
COMPONENT
VIDEO IN
IN
V (Pr/Cr)
AUDIO
IN
U (Pb/Cb)
Y
1
2
IMPORTANT!
– You only need to make
one video
connection from the following
options, depending on the
capabilities of your TV system.
– Connect the DVD Player directly
to the TV.
Using Composite Video jacks
(CVBS)
1 Use the composite video cable (yellow) to
connect the DVD Player’s CVBS (VIDEO)
jack to the video input jack (or labeled as
A/V In, Video In, Composite or Baseband)
on the TV (cable supplied).
2 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable supplied).
IMPORTANT!
– The progressive scan video
quality is only possible when using Y
Pb Pr and a progressive scan TV is
required.
Using Component Video jacks
(Y Pb Pr)
1 Use the component video cables (red/
blue/green) to connect the DVD system’s
Y Pb Pr jacks to the corresponding
Component video input jacks (or labeled
as Y Pb Pr) on the TV (cable not supplied).
2 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable supplied).
3 Proceed to page 13 for detailed
Progressive Scan set up.
7
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM7
DVP3005&3000/69_1
Connections
~ AC MAINS
AUDIO
OUT
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
English
RF coaxial cable to TV
2
Back of RF Modulator
(example only)
AUDIO IN
TO TVINT IN
VIDEO
IN
R L
CH3 CH4
Antenna or
Cable TV signal
1
IMPORTANT!
– If your TV only has a single
Antenna In jack (or labeled as 75
ohm or RF In,) you will need an RF
modulator in order to view the DVD
playback on the TV. See your
electronics retailer or contact
Philips for details on RF modulator
availability and operations.
Using an accessory RF modulator
1 Use the composite video cable (yellow) to
connect the DVD Player’s CVBS jack to
the video input jack on the RF modulator.
2 Use the RF coaxial cable (not supplied) to
connect the RF modulator to your TV’s
RF jack.
Connecting the power cord
After everything is connected
properly, plug in the AC power cord
to the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded, press
STANDBY ON on the DVD Player
front panel,
“NO DISC” may appear on the
display panel.
NO DISC
8
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM8
DVP3005&3000/69_1
Connections
AUDIO
IN
DIGITAL
AV Receiver
Optional: Connecting to an
Audio System
STEREO
AUDIO
IN
DIGITAL
Stereo system has Dolby Pro Logic
or Right / Left Audio In jack
1 Select one of the video connections
(CVBS VIDEO IN, SCART or
COMPONENT VIDEO IN) depending on
the options available on your TV.
2 Use the audio cables (white/red) to
connect AUDIO OUT (L/R) jacks of
the DVD Player to the corresponding
AUDIO IN jacks on the stereo system
(cable supplied).
Optional: Connecting Digital AV
Receiver
English
Receiver has a PCM, Dolby Digital,
or MPEG2 decoder
1 Select one of the video connections
(CVBS VIDEO IN, SCART or
COMPONENT VIDEO IN) depending on
the options available on your TV.
2 Connect the COAXIAL jack of the DVD
Player to the corresponding Digital Audio
In jack on your Receiver (cable not
supplied).
3 Set the DVD Player’s Digital Output to
PCM-ONLY or ALL depending on the
capabilities of your Receiver (see page 23
“Digital Output”).
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM9
Helpful Hint:
– If the audio format of the Digital Output
does not match the capabilities of your
receiver, the receiver will produce a strong,
distorted sound or no sound at all.
9
DVP3005&3000/69_1
Functional Overview
English
Front Panel
STANDBY-ON B
– To switch the DVD Player to Standby
mode or ON
Disc tray
OPEN/CLOSE /
– Open/Close the disc tray
Display
– Shows the current status of the DVD
Player
– To search or select next chapter or track
T NEXT
IR Sensor
– Point the remote control towards this
sensor
9 STOP
– To stop playback
2; PLAY
– To start or interrupt playback
PREV S
– To search or select previous chapter or
track
10
01-31 DVP3005_Eng_692 14/03/05, 11:02 AM10
DVP3005&3000/69_1
Loading...
