Philips
DVD Recorder/Hard Disk
DVDR520H
DVD Recorder/Hard Disk
Record today on Hard Disk and preserve for life
Record anything without having to worry ever again where to store it. Keep what you like
in lasting digital quality on DVD
Preserve your favorite memories on DVD
• i.LINK digital input for perfect digital camcorder copies
Share your favorite recordings
• Your DVDs will play on existing DVD players and drives
• Always compatible recordings: with DVD+R/RW discs
Page 2
DVD Recorder/Hard Disk
Highlights
DVDR520H/69
i.LINK digital input
Also known as IEEE 1394 and FireWire, i.Link
carrie
s all audio and video signals via a single
cable digitally, with no loss in picture and sound
quality. With i.Link digital video input, you can
copy your home videos in their original digital
picture quality.
Two-Way Compatibility
DVD Recorders can play regular DVD-Video
discs, but equal
ly important is that DVD+R and
DVD+RW discs recorded on them can be
played on existing DVD-Video players.
Always compatible recordings
Always compatible recordings: with DVD+R/
RW dis
cs
Page 3
DVD Recorder/Hard Disk
Specifications
DVDR520H/69
Picture/Display
• Aspect ratio: 4:3, 16:9
• D/A converter: 10 bit, 54 MHz
• A/D converter: 10 bit, 54 MHz
• Picture enhancement
: Progressive scan
Sound
• D/A converter: 24
• A/D converter: 24 bit, 96 kHz
• Signal to noise ratio: 90
• Distortion and Noise (1kHz): 65 dB
• Crosstalk (1kHz): 110 dB
• Dynamic Range (1kHz): 80 dB
Video Recording
• Recording system: PAL
• Compression formats: MPEG2
• Recording Modes: M1: 60 minutes, M2: 120
tes, M2x: 150 minutes, M3: 180 minutes, M4:
minu
240 minutes, M6: 360 minutes
• Recording enhancements: Chapter Marker
nsertion, Divide, Erase, Manual Chapter Marking,
I
One Touch Record (OTR)
• Audio compression: Dolby Digital
Video Playback
• Playback Media: MP3-CD, DVD-Video, CD-R/CD-
RW, Video CD/SVCD, DVD+R/+RW, DVD-R/RW
• Compression formats: MPEG2, MPEG1
• Video disc playback system: NTSC, PAL
Audio Playback
• Playback Media: MP3-CD, CD, CD-R, CD-RW
• Compression format: Dolby Digital, DTS, MP3,
2 Multichannel, PCM
MPEG
• MP3 bit rates: 32 - 256 kbps
Still Picture Playback
• Playback Media: Picture CD
• Picture Compression Format: JPEG
• Picture Enhancement: R
•Slide show
otate, Flip photos
Still Picture Recording
• Functions: copying from CD
Storage Media
• Recording media: DVD+R, DVD+RW
• HDD recording enhancements: Instant Replay,
ime Shift Buffer
T
• Extra Hard Disk Technology: Pause Live TV
• HDD to DVD copying: high-speed (direct copy)
Tuner/Reception/Transmission
• TV system: NTSC
• Aerial Input: 75 ohm coaxial (IEC75)
Connectivity
• Front / Side connections: i.LINK DV in (IEEE1394,
4-pin), S-video in, Video in, Audio L/R in
• Other connections: Antenna, ComponentVideo
t Progressive, Analog audio Left/Right out,
ou
Composite video (CVBS) out, S-Video in, S-Video
out, Digital coaxial out, Digital optical out
Convenience
• Programming/Timer Enhancements: Daily/Weekly
Repeat Program, Manual Timer, One Touch
Recording
• Child Protection: Parental Control
Power
• Power supply: 200-240 V, 50Hz
• Power consumption: 45 W
• Standby power consumption: 3
Accessories
• Included accessories: AC Power Cord, Coax RF
antenna cable, Quick start guide, User Manual,
Remote Control, Audio/Video cable, Batteries for
remote control
Dimensions
• Set weight: 4.3 kg
•Set dimensions (W x H x D): 430 x 66 x 285 mm
• Packaging dimensions (W x H x D):
6 x 111 x 415 mm
48
• Weight incl. Packaging: 4.5 kg
•
Issue date 2014-02-10
Version: 3.0.5
12 NC: 8622 810 12506
EAN: 87 10895 89518 7
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
