Page 1
Philips
DVD recorder/VCR
DVDR3545V
Simply record to DVD and VHS
with SDTV tuner
Introducing the all-in-one player that plays and records on both DVDs and VHS tapes.
With i.Link, you can now copy your favorite camcorder tapes in perfect digital picture and
sound quality onto DVDs.
Bring video to life
• Progressive Scan component video for optimized image quality
• 1080p HDMI upconverts to high definition for sharper images
Easy to use
• Direct Dubbing for 2-way transfer of videos from VCR to DVD
• HDMI digital output for easy connection with only one cable
• Built-in SDTV Tuner for digital television reception
Records and plays all your movies and music
• Dual Media conveniently records on both DVD+R/RW & DVD-R/RW
• Plays DivX, MP3, WMA and JPEG digital camera photos
• i.LINK digital input for perfect digital camcorder copies
Page 2
DVD recorder/VCR
Highlights
DVDR3545V/F7
Dual Media
Philips DVD Recorders support ‘dual media’
record
ing – the ability to create recordings on
DVD+R/RW and DVD-R/RW discs. Now you
can buy any disc and your Philips recorder will
always create fully compatible recordings,
which can be played on any DVD player.
Plays it all
Play virtually any media format you want w
hether they be DivX, MP3s, WMA or JPEGs.
Experience the unbeatable convenience of
great playability, and the luxury of sharing
media files on your TV or home theater system
- in the comfort of your living room.
HDMI for simple AV connection
HDMI stands for High Definition Multimedia
Interface. It is a
can carry digital HD video as well as digital
multichannel audio. By eliminating the
conversion to analog signals it delivers perfect
picture and sound quality, completely free
from noise. HDMI is fully backward-compatible
with (Digital Video Interface) DVI.
i.LINK digital input
Also known as IEEE 1394 and FireWire, i.Link
carrie
s all audio and video signals via a single
cable digitally, with no loss in picture and sound
direct digital connection that
quality. With i.Link digital video input, you can
copy your home videos in their original digital
picture quality.
Progressive Scan
Progressive Scan doubles the vertical
resoluti
on of the image resulting in a noticeably
sharper picture. Instead of sending a field
comprising the odd lines to the screen first,
followed by the field with the even lines, both
fields are written at one time. A full image is
created instantaneously, using the maximum
resolution. At such a speed, your eye perceives
a sharper picture with no line structure.
STANDARD DEFINITION TELEVISION
TUNER
Page 3
DVD recorder/VCR
Specifications
DVDR3545V/F7
Picture/Display
• Picture enhancement: Progressive scan
Video Playback
• Playback Media: CD-R/CD-RW, DVD-R/-RW,
DVD+R/+RW, DVD-Video, Video CD/SVCD,
VHS Tapes
• Compression formats: MPE
DivX 4.x, DivX 5.x, DivX 6.0
• Video disc playback system: NTSC
G1, MPEG2, DivX 3.11,
Audio Playback
• Playback Media: Audio CD, CD-R/RW
• Compression format: MP3, WMA, Dolby Digital
Still Picture Playback
• Playback Media: CD-R/RW, DVD+R/+RW, DVDR/-RW
• Picture Compression Format: JPEG
• Picture Enhancement: Flip p
hotos, Rotate, Zoom
Connectivity
•Front / Side connections: Audio L/R in, CVBS in,
i.LINK DV in (IEEE1394, 4-pin), S-video in
• Rear Connections: Analog audio Le
Component Video output, Composite video
(CVBS) output, Digital coaxial out, HDMI output,
S-Video out, Analog audio Left/Right in, Composite
video (CVBS) input, RF antenna in / TV out, SVideo in
ft/Right out,
Convenience
• Programming/Timer Enhancements: Daily/Weekly
Repeat Program, Manual Timer, One Touch
Recording
Power
• Power supply: 120V, 60Hz
Accessories
• Included accessories: 2 x AAA Batteries, Audio/
Video cable, Quick start guide, Remote Control,
User Manual, Warranty Leaflet
Tuner/Reception/Transmission
• TV system: ATSC, NTSC
Video Recording
• Audio compression: Dolby Digital
•Compression formats: MPEG2
• Recording enhancements: Auto Chapter Marking,
Chapter Mar
Chapter Marking, One Touch Record (OTR), Safe
Record, Selectable Index Pictures
• Recording Media: DVD
VHS Tapes
• Recording Modes: Extended Play (EP), High Quality
(HQ), Long Play
Play Plus (SPP), Super Long Play (SLP)
• Recording system: NTSC
•
ker Insertion, Divide, Erase, Manual
+R/+RW, DVD-R/-RW,
(LP), Standard Play (SP), Standard
Issue date 2014-03-14
Version: 2.0.3
12 NC: 8670 000 53023
UPC: 6 09585 17190 9
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
