Philips DVD727-98 User Manual

Download

Page 1

Digital Video Disc Player Owner's Manual

NEED HELP?CALL US!

HILIPS REPRESENTATIVES ARE READY TO HELP YOUWITH ANY QUESTIONS

ABOUT YOUR NEW PRODUCT

.WE CAN GUIDE YOU THROUGH

CONNECTIONS,FIRST-TIME SETUP,AND ANY OF THE FEATURES.WEWANT

YOU TO START ENJOYINGYOUR NEW PRODUCT RIGHT AWAY

ALL US BEFORE YOU CONSIDER

RETURNING THE PRODUCT

1-800-531-0039

R VISIT US ON THE WEB AT WWW.PHILIPS.COM

Important!

Return your

Warranty

Registration Card

within 10 days. See why inside.

DVD727

Page 2

Once your PHILIPS purchase is registered,you’re eligible to receive all the privileges of owning a PHILIPS product. So complete and return the Warranty Registration Card enclosed with your purchase at once.And take advantage of these important benefits.

Return your Warranty Registration card today to

ensure you receive all the

benefits

you’re entitled to.

For Customer Use

Enter below the Model No.and Serial No.,which are located on the rear of the cabinet.Retain this information for future reference.

Model No. ____________________ Serial No. ____________________

Congratulations on your purchase, and welcome to the “family!”

Dear PHILIPS product owner :

Thank you for your confidence in PHILIPS.You’ve selected one of the best-built,best-backed products available today.We’ll do everything in our power to keep you happy with your purchase for many years to come. As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network. Most importantly, you can count on our uncompromising commitment to your total satisfaction. All of this is our way of saying welcome - and thanks for investing in a PHILIPS product.

Sincerely,

Lawrence J.Blanford President and Chief Executive Officer

P.S. Remember,to get the most from your PHILIPS

product,you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

Know these

safetysymbols

This “bolt of lightning” indicates

uninsulated material within your unit may cause an electrical shock.For the safety of everyone in your household,please do not remove product covering.

The “exclamation point” calls attention to features for which

you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION:To prevent electric shock,match wide blade of plug to wide slot,fully insert.

ATTENTION:Pour éviter les choc électriques,introduire la lame la plus large de la fiche dans la borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your PHILIPS warranty.

Owner Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

Visit our World Wide Web Site at http://www.philips.com

Hurry!

Page 3

Contents 3

Getting Started

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-15

Quick Disc Playback

Quick Disc Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DVD Player Controls

Remote Control Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Disc Playback and Features

Title/Disc Menus,Chapter/Track Selection . . . . . . . . . . . . . . . . . . . . . . . 20

Slow Motion,Fast Forward and Fast Reverse . . . . . . . . . . . . . . . . . . . . . 21

Still Picture/Frame-by-Frame Playback,Time Search. . . . . . . . . . . . . . . . . 22

Zoom/Reduce, Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Repeat/Shuffle, Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

DVDAudio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

DVD Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

DVD Disc Menu Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Parental Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Disc Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Parental Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Preview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

JPEG and MP3 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

DVD Player Setup Options

TV Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Smart PictureTM,Picture Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-37

TV Type , Progressive Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Display Dim,Analog Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Digital Output,LPCM Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Sound Mode, 3D Sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Display Language,Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Screen Saver, DVD Player Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Setting the Remote to Operate Your TV . . . . . . . . . . . . . . . . . . . . . . 44-45

Information You May Need

Helpful Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46-47

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Specifications,Language Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50-51

Information Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Manufactured under license from Dolby Laboratories.“Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. SmartPictureTMis a trademark of Philips Consumer Electronics. Copyright 2003 Philips Consumer Electronics. All rights reserved.

Page 4

Safety Precautions

Warning:To prevent fire or shock hazard, do not expose this equipment to rain or moisture. Federal Communications Commission (FCC) Warning:Any unauthorized changes or modifications to this

equipment void the user’s authority to operate it.

Laser Safety

This unit employs a laser.Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury. CAUTION:USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. CAUTION:VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED.DO NOT STARE INTO BEAM.THE BEAM IS LOCATED INSIDE,NEAR THE DECK MECHANISM.

Special Information for Canadian Users

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Radio/TV Interference

This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and the receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

Unauthorized copying,broadcasting,public performance and lending of Discs are prohibited. This product incorporates copyright protection technology that is protected by method claims of certain U.S.patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Declaration of Conformity

Model Number: DVD727 Trade Name: Philips Responsible Party: Philips Consumer Electronics

P.O.Box 14810 Knoxville, TN 37914-1810 (865) 521-4316

4 Safety Information

Page 5

Safety Information (cont’d) 5

IMPORTANT SAFETY INSTRUCTIONS

1. Read instructions.Read all the safety and operating instructions before operating the product.

2. Retain instructions.Keep the safety and operating instructions for future reference.

3. Heed warnings. Adhere to all warnings on the product and in the operating instructions.

4. Follow instructions.Follow all operating and use instructions.

5. Cleaning – Unplug this product from the wall outlet before cleaning.Do not use liquid cleaners or aerosol cleaners.Use a damp cloth for cleaning.

6. Attachments – Do not use attachments not recommended by the product manufacturer as they may cause hazards.

7. Water and Moisture – Do not use this product near water for example, near a bathtub, washbowl, kitchen sink,or laundry tub, in a wet basement, near a swimming pool, etc.

8. Accessories – Do not place this product on an unstable cart, stand,tripod, bracket, or table .The product may fall,causing serious injury to a child or adult, and serious damage to the product.Use only with a cart, stand, tripod, bracket,or table recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer.

9. Move a product and cart combination with care. Quick

stops,excessive force,and uneven surfaces may cause the product and cart combination to overturn.

10. Ventilation – Slots and openings in the cabinet provide ventilation,ensure reliable operation of the product,and protect it from overheating. Do not block or cover these openings. The openings should never be blocked by placing the product on a bed,sofa,rug, or other similar surface . Do not place this product in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

11. Power Sources – This product should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply to your home, consult your product dealer or local power company.For products intended to operate from battery power, or other sources,refer to the operating instructions.

12. Grounding or Polarization – This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way.This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug.If the plug still fails to fit, contact your electrician to replace your obsolete outlet.Do not defeat the safety purpose of the polarized plug.

13.Power-Cord Protection – Route power supply cords so they are not likely to be walked on or pinched by items placed upon or against them,paying particular attention to cords at plugs,convenience receptacles,and the point where they exit from the product.

14. Outdoor Antenna Grounding – If an outside antenna or cable system is connected to the product,be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code,ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit,size of grounding conductors, location of antenna-discharge unit,connection to grounding electrodes,and requirements for the grounding electrode. See figure at right.

15. Lightning – For added protection for this product during a lightning storm,or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

16. Power Lines – An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits,or where it can fall into such power lines or circuits.When installing an outside antenna system,take extreme care to keep it from touching such power lines or circuits;contact with them might be fatal.

17. Overloading – Do not overload wall outlets,extension cords,or integral convenience receptacles.This can result in a risk of fire or electric shock.

18. Object and Liquid Entry – Never push objects of any kind into this product through openings;they may touch dangerous voltage points or short out parts,resulting in a fire or electric shock.Never spill liquid of any kind on the product.

19. Servicing – Do not attempt to service this product yourself. Opening or removing covers may expose you to dangerous voltage or other hazards.Refer all servicing to qualified service personnel.

20. Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the power supply cord or plug is damaged, b) If liquid has spilled or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions.Adjust only those controls covered by the operating instructions.An improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation, e) If the product has been dropped or damaged in any way, f) When the product exhibits a distinct change in performance. This indicates a need for ser vice .

21. Replacement Parts – When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or having the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock,or other hazards.

22. Safety Check – Upon completion of any service or repairs to this product,ask the service technician to perform safety checks to determine that the product is in proper operating condition.

23. Wall or Ceiling Mounting – Mount the product to a wall or ceiling only as recommended by the manufacturer.

24. Heat - Situate this product away from heat sources,such as radiators,heat registers, stoves,or other products (including amplifiers) that produce heat.

25. Battery usage CAUTION - To prevent battery leakage that may result in bodily injury,property damage, or damage to the unit:

• Install all batteries correctly,with + and - aligned as marked on the unit.

• Do not mix batteries (old/new, carbon/alkaline , etc.).

• Remove batteries when the unit is not used for a long time.

Example of Antenna Grounding

per National Electrical Code

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

(NEC SECTION 810-20)

Page 6

6 Introduction

Welcome!

This Digital Video Disc Player will allow you to enjoy better picture quality,clearer sound,and endless playback features on Digital Video Discs (DVDs).Expanding technolog y allows you to add options to your viewing - watch a director’s cut of a movie,listen to the producer’s comments,or play your favorite scene repeatedly.Hear a movie in different languages,or listen only to the soundtrack.The possibilities are limited only by your choices and the materials available on the DVD. We hope you enjoy this DVD Player and learn to use its features.To get the most from the DVD Player, read this manual carefully.It will describe how you can access these features.

Features

Package Contents

● DVD Player

● Universal Remote control with two AA batteries

● One set of audio cables (red and white)

● One video cable (yellow)

● This owner’s manual and registration materials

● Quick-Use Guide

Environmental Information

Your system has materials that can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials,exhausted batteries, and old equipment.

Safety Information

● Do not expose the system to excessive moisture,rain, sand, heat,or humidity.

● Place the DVD Player on a firm, flat surface .

● Keep the DVD Player away from domestic heating equipment and direct sunlight.

● When placing the DVD Player in a cabinet, allow about one inch of space all around the DVD Player for

ventilation.Leave enough room in front of the DVD Player for the disc tray to open completely.

● If the DVD Player is brought directly from a cold to a warm location,or is placed in a ver y damp room,

moisture may condense on the lens inside the DVD Player. If this occurs, the DVD Player will not operate normally.Leave the power on for about one hour with no disc in the DVD Player until normal playback is possible.

● The mechanical parts of the Player contain self-lubricating bearings and must not be oiled or lubricated.

● When the DVD Player is turned off, it is still consuming some power.To disconnect the system from

the power supply completely,remove the AC power plug from the power outlet.

● Always keep the disc tray closed to avoid dust on the lens.

Cleaning Discs

● When a Disc becomes dirty,clean it with a cleaning cloth.Wipe the Disc from the center to the edge

in a straight line.Do not wipe the Disc in a circular pattern.

● Do not use solvents such as benzine, thinner,commercially available cleaners,or anti-static spray

intended for analog discs.

● Closed Captions

● Disc Lock

● Language options for Audio,Subtitles, and Disc

Menus

● MP3 and JPEG file playback with menu

Navigator

● Parental controls

● Paused/Fast/Slow/Frame-by-

Frame/Zoomed/Reduced playback

● Preview (Video CDs)

● Programmed playback

● Repeat and Repeat A-B Playback

● Screen Saver

Page 7

Playable Discs 7

Region Codes and Color Systems

DVDs must meet the requirements for Region Codes and Color Systems before you can use them with the DVD Player. DVDs must be labeled for ALL regions or for Region 1 in order to play on this DVDPlayer.You cannot play Discs that are labeled for other regions. These symbols must appear on your DVDs, or you cannot play the DVD in this Player.

The number inside the globe refers to a region of the world. Region 1 represents the United States, Canada,upper regions of North America,Bermuda, the U.S.Virgin Islands, and small regions near Australia. Furthermore, recordings are made according to different color systems throughout the world.The most common color systems are NTSC (which is used primarily in the United States and North America),PAL,and SECAM. This DVD Player is compatible with NTSC and PAL.Make sure the Discs you play were recorded in NTSC or PAL and your TV is NTSC or PAL compatible. You must set the DVD Player’s TV TYPE to match your TV and your DVDs.Details are on page 38.The color system of the DVD may appear on the DVD or on the Disc case.

DVD Player Upgrades

If a DVD does not play properly,please contact Philips at 1-800-531-0039 for assistance. Due to the inconsistency of Disc formats provided by various Disc manufacturers, your DVD Player may require a playability enhancement.As DVD technology has advanced, these enhancements have become both common and easy to complete.

Playable Discs

This DVD Player will play various types of Discs.Look for these logos on your Discs to determine whether the Disc will play on this Player.

DVD (Digital Video Disc)

Audio CD (Compact Disc Digital Audio)

Video CD and Super Video CD

CD-R (CD-Recordable) and CD-RW (CD-Rewritable) Finalize CD-Rs when you record them.Otherwise,you cannot play them on this Player.

DVD+R (DVD + Recordable) and DVD+RW (DVD + Rewritable) Finalize these Discs when you record them.Otherwise,you cannot play them on this DVD Player.

Recordable

ReWritable

Page 8

8 General Information

Battery Installation

Remove the battery compartment lid on the rear of the

remote control by pressing in the tab, then lifting off the lid.

Place two AA batteries inside the battery compartment with their +and –ends aligned as indicated. Do not mix old

and new batteries or different types of batteries (standard,alkaline, etc.).

Replace the battery compartment lid.

Using the Remote Control

When using the remote control to operate the DVD Player, aim the remote toward the front of the Player (not toward the TV). This remote may operate some features of your television. When using the remote to work the TV, aim the remote at the TV. Details about TV

operations are on pages 17 and 44-45.

When referring to this manual,remember...

The feature is available on some Digital Video Discs. The feature is available on some Audio Compact Discs. The feature is available on some Video Compact Discs or

Super Video CDs.

DVD Disc Menus...

Some explanations in this manual describe the DVD Disc Menus, which vary among DVDs.Movie producers set these menus,and not all DVDs have menus.If the DVD has a menu,access the Disc Menu by pressing the DISC MENU button on the remote control.Details are on page 20.

DVD Player Menus...

Some instructions explain how to use the DVD Player’s Setup menu to set features of the Player or the Disc. You get to the Setup Menu by pressing SYSTEM MENU on the remote control.Even if a feature is set in the Player’s menu,it will not be available if the current Disc does not include that feature.

Available Disc Features...

Features in this manual may not be available on every Disc.If the feature is not available,you cannot use the DVD Player to make the feature available. The B will appear in the top left corner of the TV screen if you try to access a feature that is not available.For example,the feature may not be available at the present time.Some features are only available during playback,while other items can be accessed only when play is stopped.Try stopping or starting playback,then try the feature again.

DVD

AUDIO CD

VIDEO CD

Page 9

Hookups 9

Determining the best possible connection...

The capabilities of your existing equipment,especially your TV, will determine your connection possibilities. However, the following guidelines describe which options provide the best picture and sound quality.

.... Component Video provides the best picture quality. Details are on page 13.

If your TV accepts Progressive Scan through the Component Video connection, set PROGRESSIVE to ON at the Player. Details are on page 38.

... S-Video provides excellent picture quality.Details are on page 12. .. Composite Video (a yellow Video jack) provides good picture quality.Details are on page 11. .. Your TV may have only an RF-style jack, usually labeled Antenna In or 75 ohm or

RF In.You will need an RF modulator in order to view the DVD Player at your TV.

Details are on page 10.

.... Digital audio connections provide the clearest sound,but you must have a digital stereo

Connect the DVD Player’s COAXIAL or OPTICAL digital audio out jack to your Stereo for the best sound quality. Details are on page 15.

... If digital connections are not possible,connect the DVD Player’s red and white AUDIO OUT

jacks to the Audio In jacks of your Stereo,TV,or RF modulator. Details are on pages 10-14.

Before you begin...

● Refer to the manuals of your TV, Stereo,or other equipment as necessar y.Note the style of jacks and

connectors on the other equipment.Determine how to choose different Audio and Video In channels/sources on your other equipment so you can see and hear the DVD Player on the TV,Stereo, etc.

● Disconnect all equipment from the power outlets.Connect the equipment to the power outlets only

after you have finished hooking up everything. Never make or change connections with equipment connected to the power outlet.

Remember...

● Connect the DVD Player directly to the TV. For example, do not connect the DVD Player to a VCR,

then connect the VCR to a TV.This type of connection may distort the picture and sound. Also, your VCR might have the copy protection system,which could distort the DVD image or prevent playback of some Discs.

● Set the TV to the correct Video In channel. Such channels may be called AUX or AUXILIARYIN,

AUDIO/VIDEO or A/V IN,EXT1 or EXT2 or External In, etc .These channels are often near channel

00.See your TV manual for details.Go to your lowest TV channel (01 or 02) and change TV channels downward until you see the DVD screen saver on the TV. Or, your TV’s remote may have a button or switch that selects Video In channels. Check your TV manual for details. If you are using an RF modulator,set the TV to channel 3 or 4.

● Set the Stereo to the correct channel or “source” mode.

● Do not connect the DVDPlayer’s AUDIO OUT jacks to the PHONO IN jack of your Stereo.

● You only need one audio connection and one video connection between the DVD Player and your TV

and/or Stereo.So,you will not use all the jacks on the DVD Player.

Once you determine the best option, find your choice on pages 10-15. Follow the steps for the hookup you choose.

Page 10

Before you begin,make sure you have an RF modulator and extra RF coaxial cables. These are not supplied with the Player, but are available from Philips or most consumer electronics retailers.

Connect the supplied video cable (which has yellow markings) to the Player’s yellow VIDEO (VIDEO OUT) jack. Connect the other end of the cable to the VIDEO IN jack on the RF modulator. The VIDEO IN jack on the RF modulator is usually yellow and

might be labelled VIDEO,CVBS, COMPOSITE,or BASEB AND.

Connect the supplied audio cable (which has red and white markings) to the Player’s AUDIO OUT (left and right) jacks. Connect the other ends of the audio cable to the AUDIO IN jacks on the RF modulator. Audio jacks on the RF modulator usually are red (right) and white (left).Match the

cable colors to the jack colors.

You probably already have an Antenna or Cable TV signal connected to the ANTENNA IN jack on your TV. Disconnect it now from the TV. Reconnect the Antenna or Cable TV

signal to the ANTENNA IN jack on your RF modulator.

Connect an RF coaxial cable (not supplied) to the RF OUT,ANTENNA OUT, or TO TV jack on the RF modulator. The RF OUT jack may be labelled differently among different brands.Refer to the instructions provided with your RF modulator.Connect the other end of the same RF coaxial cable to the ANTENNA IN or RF IN jack on your Television.

Your RF Modulator should have a Channel 3/4 switch. The setting of this switch determines the TV channel on which you will watch materials playing on the DVD Player.

Set the RF Modulator’s Channel 3/4 switch to either 3 or 4, whichever TV channel is least used in your area.If your RF modulator has a Modulator/Antenna switch,set it

accordingly.Refer to the instructions that came with the RF Modulator.

Connect the power cords of all the equipment to a power outlet.

Turn on your TV and choose channel 3 or 4. Choose the same channel to which you set

the RF Modulator’s Channel 3/4 switch.

Turn on the DVD Player by pressing STANDBY-ON yy. You should see the Player’s blue

DVD screen on the TV.

10 Hookups (cont’d)

Connecting to a TV Only

TV has only a single Antenna In or RF In jack

Back of TV

(example only)

ANT IN

TO TV

AUDIO IN R L

VIDEO

CH3 CH4

Back of RF Modulator

(example only)

Antenna or Cable TV Signal

ANTENNA IN

RF IN

Page 11

Hookups (cont’d) 11

Connecting to a TV Only

TV has a yellow Video In jack

Back of TV

(example only)

LEFT AUDIO IN

VIDEO IN

RIGHT AUDIO IN

LEFT AUDIO IN

VIDEO IN

RIGHT AUDIO IN

Connect the yellow VIDEO (VIDEO OUT) jack of the DVD Player to the corresponding VIDEO IN jack on your TV.Use

the supplied video cable,which has yellow markings.

Connect the supplied audio cable to the red and white AUDIO OUT (left and right) jacks on the DVD Player and to the left/right AUDIO IN jacks on the TV. The supplied

audio cables have red and white markings. Match the cable colors to the jack colors.

Plug the power cords of the DVD Player and the TV into an active power outlet. Press STANDBY-ONyyon the front of the DVD Player to turn it on.

Turn on the TV. Set it to the correct Video In channel. See

your TV owner’s manual for details.Or,go to your lowest TV channel (01 or 02) and change channels downward until you see the blue DVD screen on the TV.

• On the TV, the Video In jack is usually yellow and might be labeled video,CVBS, composite, or baseband.

• If your TV has a single Audio In jack instead of separate left/right Audio In jacks,you will need a different audio cable. You need a “splitter” audio cable to go from the left/right AUDIO OUT jacks of the DVD Player to the single Audio In jack on your TV.See your electronics retailer for details.

Helpful Hints

Page 12

Connect an S-Video cable (not supplied) to the S-VIDEO (VIDEO OUT) jack of the DVD Player and to the TV’s S-VIDEO In jack.

Connect the supplied audio cable to the red and white AUDIO OUT (left and right) jacks on the DVD Player and to the left/right AUDIO IN jacks on the TV. The supplied

audio cable has red and white markings.Match the cable colors to the jack colors.

Plug the power cords of the DVD Player and the TV into an active power outlet. Press STANDBY-ONyyon the front of the DVD Player to turn it on.

Turn on the TV. Set it to the correct S-Video In channel. See

your TV owner’s manual for details.Or,go to your lowest TV channel (01 or 02) and change channels downward until you see the blue DVD screen on the TV.

12 Hookups (cont’d)

Connecting to a TV Only

TV has an S-Video In Jack

Back of TV

(example only)

LEFT AUDIO IN

S-VIDEO IN

RIGHT AUDIO IN

LEFT AUDIO IN

S-VIDEO IN

RIGHT AUDIO IN

• On the TV, the S-Video In jac k may be labeled Y/C , S-Video, or S-VHS (super video).

Helpful Hints

Page 13

Hookups (cont’d) 13

Connecting to a TV Only

TV has Component Video In Jacks (red, green, and blue)

Back of TV

(example only)

LEFT AUDIO IN

RIGHT AUDIO IN

Pr/Cr

Pb/Cb

LEFT AUDIO IN

RIGHT AUDIO IN

Pr/Cr

Pb/Cb

Connect the DVD Player’s Y Pb Pr (VIDEO OUT) jacks to the corresponding COMPONENT VIDEO IN jacks on the TV.Use component video cables (not supplied). The Component

Video jacks are red,green,and blue. On your TV,you may have additional Component Video In jacks that are specifically labelled Progressive Scan. If you use these instead, set PROGRESSIVE to ON at the Player.(See step 5.)

Connect the DVD Player’s red and white AUDIO OUT (left and right) jacks to the left/right AUDIO IN jacks on the TV.

Use the supplied audio cables,which have red and white markings. Match the cable colors to the jack colors.

Plug the power cords of the DVD Player and the TV into an active power outlet. Press STANDBY-ONyyon the front of the DVD Player to turn it on.

Turn on the TV. Set it to the correct Component Video In channel. See your TV owner’s manual for details.Or, go to your

lowest TV channel (01 or 02) and change channels downward until you see the blue DVD screen on the TV.

If your TV has Progressive Scan,set PROGRESSIVE to ON at the DVD Player.Details are on page 38.

Select Progressive Scan at your TV also if necessary. See your TV owner’s manual for details. Only set PROGRESSIVE to ON if you are certain your TVhas Progressive Scan.You will not see the DVD Player’s picture at the TV if PROGRESSIVE is set incorrectly.

•

On the TV,the component video in jacks may be labeled YUV or Pr/Cr Pb/Cb Y and may be green,blue, and red.

• You can deactivate Progressive Scan so you can use a different connection.For example you may want to change TVs later. To cancel Progressive Scan at the DVD Player,open the disc tray.Press 1 on the remote, then press MUTE.

Helpful Hints

Page 14

14 Hookups (cont’d)

Connecting to a TV and a two-channel Stereo

(Stereo has Dolby Pro Logic or right/left Audio In jacks)

Back of TV

(example only)

LEFT AUDIO IN

RIGHT AUDIO IN

Stereo

(example only)

VIDEO IN

Connect the supplied video cable to the yellow VIDEO (VIDEO OUT) jack of the DVD Player and to the TV’s VIDEO IN jack. The supplied video cable has yellow markings.

Connect the supplied audio cable to the red and white AUDIO OUT (left and right) jacks on the DVD Player and to the left/right AUDIO IN jacks on the Stereo.Match the

cable colors to the jack colors.

Plug the power cords of the DVD Player, Stereo,and TV into an active power outlet. Press STANDBY-ONyyon the front of the DVD Player to turn it on.

Turn on the Stereo and set it to the correct Audio In channel or sound source. Refer to the Stereo owner’s manual for

details.

Turn on the TV. Set it to the correct Video In channel. See

your TV owner’s manual for details.Or,go to your lowest TV channel (01 or 02) and change channels downward until you see the blue DVD screen on the TV.

• If you prefer or need to use the S-VIDEOor Y Pb Pr jac ks instead,see pages 12-13.You only need one video connection between the TV and the DVD Player.

Helpful Hint

Page 15

Hookups (cont’d) 15

Connecting to a TV and a Stereo

(Stereo has Dolby Digital

or MPEG2)

Back of TV

(example only)

COAXIAL DIGITAL AUDIO IN

Stereo

(example only)

VIDEO IN

Connect the Player’s COAXIAL jack or OPTICAL jack to the Stereo’s COAXIAL DIGITAL AUDIO IN jack or OPTICAL DIGITAL AUDIO IN jack. You only need to use one

of the jacks,not both. Use an appropriate digital audio cable (not supplied).See your electronics retailer for details and availability.

Connect the supplied video cable to the Player’s yellow VIDEO (VIDEO OUT) jack and to the TV’s VIDEO IN jack. The supplied video cable has yellow markings.

Plug the power cords of the DVD Player, Stereo,and TV into an active power outlet. Press STANDBY-ONyyon the front of the DVD Player to turn it on.

Turn on the Stereo and set it to the correct Audio In channel or sound source. Refer to the Stereo owner’s manual for

details.

Turn on the TV. Set it to the correct Video In channel. See

your TV owner’s manual for details.Or,go to your lowest TV channel (01 or 02) and change channels downward until you see the blue DVD screen on the TV.

• Set DIGITAL OUTPUT and LPCM OUTPUT accordingly. Details are on page 40.

• Your Stereo must support MPEG2 or Dolby Digital

Check the Stereo’s manual.

• If you prefer or need to use the S-VIDEOor Y Pb Pr jac ks instead,see pages 12-13.

Helpful Hints

Page 16

16 Quick Disc Playback

There are many playback features and options available on Discs.After familiarizing yourself with the DVD Player as described on pages 17-19,see pages 20 and following to try additional features.

Press STANDBY-ON yyor POWER yyto turn on the DVD Player. Turn on your TV. Set it to the correct Video In channel.You should see the blue DVD screen on the TV.

Press OPEN/CLOSE / to open the disc tray. Load your Disc in the tray,with the label facing up.If the Disc

(DVD) is two-sided, make sure the label of the side you want to play is facing up.

Press OPEN/CLOSE / again to close the tray.

Play may start automatically.If not:

• If you are playing a DVD,a Disc menu may appear.If the Title or Chapter selections are numbered,press a Number button to select an item.Or,press 341 2 to select an item,then press OK.Playback will begin.Or,follow the on-screen instructions as detailed in the DVDDisc menu.

• If you are playing an Audio CD,press PLAY 3 to start play.

• If a Video CD has Playback Control,press DISC MENU to access its menu while play is stopped.Or,press TITLE to see the menu during playback. Press the Previous 4,Next ¢, 3, 4,1, 2, or Number buttons to select an item,then press OK. Follow the instructions provided by the Video CD.Not all Video CDs have Playback Control.See the Disc case or menus for details.

To stop play at any time, press STOP 7.

If you press STOP 7 only once, play will resume at the same point if you press PLAY 3 later to restart play. This is known as the Resume feature. Resume applies to the last five Discs.Press PLAY 3 immediately after inserting the Disc in the Player (while LOADING shows on the TV screen).RESUME PLAY will appear on the TV screen briefly. If you press STOP 7 more than once to stop playback,play will start at the beginning of the Disc again if you press PLAY 3 later to restart playback.

• If the Disc is loc ked by Parental controls,you must enter your password or unlock the Disc. Details are on pages 28-30.

• DVDs have a region code.This Player will play only DVDs of Region 1 or ALL. Details are on page seven.

• If there is no activity at the Player or its remote for 15 minutes,the Player will turn itself off.Press STANDBY-ON

on the Player or POWER yor PLAY 2 on the remote to turn on the Player.

Helpful Hints

DVD

AUDIO CD VIDEO CD

2-3

Page 17

Remote Control Buttons 17

CANCEL Button

Press to clear items in a Program.

OPEN/CLOSE Button

Press to open or close the disc tray.

Number Buttons

Press to select numbered items in a

menu.Press to select a Chapter,Title, or

Track to play.Details are on page 20.

RETURN Button

Press during DVD playback to return to

the Disc’s Title menu.This option may

not be available with all Discs.

DISC MENU Button

Press during playback to access a DVD’s

menu.Details are on page 20.

4 Button

Press to go to the beginning of current

chapter or track or to the previous

Chapter or Track. Press and hold 2

second to search backward.Details are

on page 20-21.

STOP

7 Button

Press to stop Disc playback.

Press and

hold the STOP 7 button until OPEN

appears on the display panel to open the

disc tray.Press and hold STOP 7 while

the tray is open to close the disc tray.

PLAY

3 Button

Press to begin Disc playback.

SUBTITLE Button

Press during DVD play to select a

subtitle language.Details are on page 26.

ANGLE Button

Press to select a camera angle during

DVD play.Details are on page 23.

REPEAT Button

Press to play a Chapter,Title,Track,or

Disc repeatedly. Details are on page 24.

REPEAT A-B Button

Press to set up Repeat A-B playback,in

which a certain segment of the Disc

plays repeatedly.Details are on page 24.

SURROUND Button

Press to select a Sound mode quickly.

Details are on page 41.

TV VOL (volume) -/+ Buttons

Press to adjust the TV volume.

Aim the remote at the TV.

MUTE Button

Press to silence or restore the volume. If

the remote is in TV mode,aim the

remote at the TV to mute the TV

volume.If the remote is in DVD mode,

aim the remote at the Player to mute

the Player’s volume.

TV PROG (program) -/+ Buttons

Press to change channels at the TV.

Aim the remote at the TV.

POWER yyButton

Press to turn on or off (Standby) the power of the DVD Player.

DISPLAY Button

Press during playback to see current disc information on the TV screen.

Details are on pages 20 and 22.

DVD/TV Button

Press before using the remote to work your TV.Press again to use the remote for the Player. Details are on pages 44-45.

SEARCH Button

Press for a Time Search.

Details are on page 22.

SYSTEM MENU Button

Press to access or remove the Setup Menu of the DVD Player.

OK Button

Press to approve a menu selection.

341 2 Buttons

Press to select items in a menu.Press 1 or 2 for fast searching. Details are on page 21. Press 3 or 4 during DVD playback for slow motion.Details are on

page 21.

¢ Button

Press to skip to the next Chapter or Track.Press and hold for 2 second to search forward. Details are on page 20-

21.

PAUSE

8 Button

Press to pause play or to advance a paused picture one frame at a time.

Details are on page 22.

AUDIO Button

Press to select a different audio language or soundtrack during DVD playback.

Details are on page 25.

With some Video CDs, Super Video CDs,and Audio CDs,press AUDIO to choose an audio channel.

Details are on page 25.

ZOOM Button

Press to reduce or enlarge the picture during playback.Details are on page 23.

PREVIEW Button

Press to enter the Preview menu for a Video CD or Super Video CD.

Details are on page 32.

Or,press to play the first several seconds of each Track on an Audio CD (SCAN).Details are on page 20.

TITLE Button

Press to see a DVD’s Title menu.

Details are on page 20.

VOLUME-/+ Buttons

Press to adjust the volume from the Player. Aim the remote at the Player. To get the volume you want at the TV,use TV VOL -/+ to adjust the TV volume.

Page 18

18 Front Panel

Remote sensor

This sensor receives the commands from the DVD Player’s remote control.When using the Player’s remote to operate the Player, point the remote here (not toward your TV).

PAUSE 8 button

Press during playback to pause play;press again to resume play from the same point.

PLAY 3 button

Press to start playing a Disc.

STOP 7 button

Press once to stop Disc playback.Play will resume from the same point the next time you start playback.Details

are on page 16.

Or press STOP 7 twice to stop Disc playback. Play will resume from the beginning of the Disc the next time you start playback. You must stop playback by pressing STOP 7 twice in order to access PREFERENCE SETUP in the DVD Player’s Setup menu.

OPEN/CLOSE / button

Press to open or close the Disc tray.

STANDBY-ON

Button

Press to turn the DVD Player on or off (Standby).A red light will appear on the front of the Player when the power is off (Standby).

Disc Tray

Insert a Disc here. Load the Disc with the label facing up and the shiny side facing down.If the Disc is twosided,place the Disc in the tray with the label of the side you want to play facing up.Details are on page 16.

Display Panel

Current Disc details appear here,including the elapsed playing time of a Disc.SEARCH, PAUSE,STOP(play is stopped), MUTE (ON or OFF),OPEN, CLOSE,LOAD, OFF (power is turning off),ROOT,or Repeat messages also appear here to indicate the current status of the Player or Discs. To adjust the brightness of the display panel,set DISPLAY DIM.

Details are on page 39.

Page 19

Rear Panel 19

Y Pb Pr (VIDEO OUT) jacks

Connect component video cables (not supplied) here and to the Component Video In jacks of a TV. The jacks are usually green,blue,and red.Details are on page 13. If your TV has Progressive Scan,set PROGRESSIVE to ON at the Player for the best picture.

Details are on page 38.

COAXIAL jack

Connect a digital audio coaxial cable (not supplied) here and to the Digital Audio Coaxial In jack of a Stereo. Details are on page 15.

OPTICAL jack

Connect a digital audio optical cable here and to the digital audio optical In jack of a Stereo.Details are on

page 15.

AUDIO OUT (left/right) jacks

Connect the supplied audio cables (red and white) here and to the AUDIOIN jacks on your TV, Stereo, or RF Modulator.

Details are on pages 10-14.

AC Power cord

Connect to a standard AC power outlet after completing all other connections.

S-VIDEO (VIDEO OUT) jack

Use an S-video cable (not supplied) to connect this jack to the S-Video In jack of your TV. Details are on page 12.

VIDEO (VIDEO OUT) jack

Connect the supplied video cable (yellow) here and to the TV’s Video In jack. Details are on page 11. Or,connect this jack to an RF modulator (not supplied) if your TV does not have a Video In jack.

Details are on page 10.

• You only need one audio and one video connection between a TV and the Player,so you will not use all the jacks on the Player.

Helpful Hint

Page 20

20 Title/Disc Menus, Chapter/Track Selection

Title/Disc menus

Press DISC MENU during DVD playback.

The main Disc menu (or Root menu) will appear.The menu may list camera angles,spoken language and subtitle options,and Chapters for the Title.

Or, if the current Title has a specific Title menu, press the TITLE button to access the Title menu. Title menus are not

available on all Discs.

Press 341 2 to select items in the menu, then press OK.

Continue until you set up all the features you want or until playback begins.If Chapters or options are numbered,press the appropriate Number button to select the item.Some DVDs may not allow you to operate the Disc menu this way.Follow the instructions on the Disc.

Chapter/Track Selection

Press Next ¢ during playback to go to the next Track/Chapter. Press Previous 4 to go to the beginning of the current Tracks/Chapters,press Previous 4 again within two seconds to go to previous Tracks/Chapters.

To go directly to any Track/Chapter during playback,press the Number buttons to enter the Track/Chapter number.

Precede single-digit numbers with a zero. For example, for Track six, press 0,6. Play will resume from the beginning of the Track/Chapter you selected. If you enter an invalid number, the current Track/Chapter will continue to play.Make sure the Track/Chapter number you enter is available on the Disc.Make sure a Chapter is available within the current Title .

During DVD or Video CD play only,you can select a Track,Title , or Chapter in the display.Press DISPLAY, then press 44to select

TITLE, CHAPTER, or TRACK. Then press OK. Press the Number buttons to enter the Title , Chapter, or Track number you want. Precede single-digit numbers with a zero.(The

zero may be entered for you already in the display.) Play will resume at the beginning of the Title,Chapter, or Track you selected.Press DISPLAY again to remove the display.

DVD

AUDIO CD

VIDEO CDDVD

• To scan all the Tracks on an Audio CD,press PREVIEW. The first several seconds of each Track will play. After eac h Track is introduced,Disc play will start from the first Track. Or,to start play at a Track you find during scanning,press PREVIEW again. SCAN will appear in the top left corner of the TV screen during Track scanning.

• The Display method of Track selection is not available for Audio CDs.

• When DVD play is stopped, press the Number buttons, then OK,to select a Title to play.

Helpful Hints

DVD example

Page 21

Fast Forward and Fast Reverse

To fast forward a DVD or Video CD,press 2 repeatedly to select two,four,eight, 16, or 32 times the normal speed. Or, press and hold Next ¢ until the Fast Forward icon shows on the TV. Then, press and hold Next ¢ repeatedly to select different searching speeds.Sound will be mute.

Or, press 1 repeatedly to play the DVD or Video CD backward at two,four,eight,16, or 32 times the normal speed. Or,

press and hold Previous 4 untill the Fast Reverse icon shows on the TV. Press and hold Previous 4 repeatedly to select different searching speeds.The sound will be mute.

To fast forward an Audio CD at two,four,eight, 16, or 32 times the normal playback speed,press 2 repeatedly during playback.Or press and hold Next ¢ for two seconds to select a fast forward speed until the Fast Forward icon shows on the TV.Then press and hold Next ¢ to select different searching speeds.Sound will be intermittent.

To fast reverse an Audio CD at two,four, eight, 16, or 32 times the normal speed,press 1 repeatedly. Or press and hold Previous

4 for two seconds until the Fast Reverse icon shows on the TV.

Then press and hold Previous 4 to select different searching speeds.Sound will be intermittent.

To return to normal playback,press PLAY 3.

Slow Motion,Fast Forward and Fast Reverse 21

DVD

VIDEO CD

AUDIO CDDVD

Slow Motion

During Disc playback,press 4 to play the Disc forward at

1/2,1/4, 1/8,or 1/16 the normal speed. The sound will be mute during slow motion playback. Or, press 3 to play a DVD backward at 1/2,1/4, 1/8,or 1/16 the normal speed.Slow reverse is not possible on Video CDs.

To return to normal playback,press PLAY 3.

1 2

Page 22

22 Still Picture/Frame-by-Frame Playback, Time Search

Still Picture/Frame-by-Frame Playback

To pause a DVD or Video CD picture, press PAUSE 8 on the remote control during playback.

Press PAUSE 8 repeatedly to advance the still picture one frame at a time.

Press PLAY 3 to resume regular playback.

DVD

VIDEO CD

1,2

Time Search

Press DISPLAY or SEARCH during playback.Current

playback information will appear at the bottom of the TV screen.

DVD example

Press o or p to select TIME DISP.Press OK. Press o or p to highlight a display type (see Helpful Hints),then press OK. The display type and its counter will appear at the bottom of

the screen.

Press o or p to select TT TIME or CH TIME (DVD), or DISC TIME (Video CD), for example. This shows the total

amount of time that the Title,Chapter, or Disc contains.

Press OK to select the time counter beside TT TIME, CH TIME,TRACK TIME,or DISC TIME.

Press the Number buttons to enter the playing time at which you want to resume playback. (Press 1 to quit and reselect TT TIME, CH TIME,TRACK TIME,or DISC TIME.)

Enter the time in hours,minutes, and seconds. Play will start at that point.

Press DISPLAY or SEARCH to remove the information.

DVD

VIDEO CD

1,6

2-4

• If you pause a picture for more than five minutes, the screen saver will appear (if it is on).Details are on page 43.

• The following display types will be available, depending on the Disc in the Player.

CHAPTER ELAPSED - elapsed playing

time of current Chapter; CHAPTER REMAIN - remaining playing time of current Chapter; TITLE ELAPSED - elapsed playing time of current Title; TITLE REMAIN - remaining playing time of current Title; TOTAL ELAPSED - elapsed playing time of current Disc; TOTAL REMAIN - remaining playing time of current Disc.

SINGLE ELAPSED - elapsed playing time

of current Track;

SINGLE REMAIN - remaining playing

time of current Track.

• During the Audio CD play, press SEARCH or DISPLAY repeatedly to change the counter among SINGLE ELAPSED, SINGLE REMAIN,TOTAL ELAPSED or TOTAL REMAIN, the counter you select appears on the top of the TVscreen

• You can not access the Display during programmed play.

Helpful Hints

Page 23

Zoom/Reduce, Camera Angle 23

Zoom/Reduce

You can reduce or enlarge the video image during playback.

Press ZOOM repeatedly during Disc playback to make the

picture two, three,or four times larger. Or,keep pressing ZOOM to reduce the picture to 1/2,1/3,or 1/4 its normal size.

Press 341 2 to move around in the enlarged picture. The

blue box within a larger gray box that appears during zoomed play indicates the position of the zoomed area within the overall picture.

To return the picture to regular size,press ZOOM until the

picture returns to its normal size.

DVD

Camera Angle

Some DVDs include scenes recorded from different angles.To watch segments from a different angle,follow these steps.The DVD must have multiple angles available.Check the DVD Disc case or Disc menu for details and availability.

During DVD playback, press the ANGLE button repeatedly to select a different angle.

In a few seconds,playback changes to the selected angle.If multiple angles are not available, B may appear in the top left corner of the TV screen when you press ANGLE.

DVD

VIDEO CD

1,3

• You also can change Angle in the Display.During DVD play, press DISPLAY on the remote to access the Display Screen.Press or to highlight ANGLE, then press OK,use the Number buttons to choose an available angle. Press DISPLAY on the

remote to remove the display. This feature is not be possible on all DVDs.

• Zooming is not available on DVDs that have the PAL color system.Details are on page 7.

Helpful Hints

Page 24

24 Repeat/Shuffle, Repeat A-B

Repeat/Shuffle

You may play a Chapter,Track,Title, or entire Disc repeatedly.

During Disc playback,press REPEAT to choose a Repeat option. Depending on the type of Disc, you may choose to play the

Chapter, Track, Title, or ALL (Disc) repeatedly.Or,continue to press REPEAT to choose SHUFFLE or SHUFFLE REPEAT. The Tracks, Chapters,and/or Titles will play in random order (SHUFFLE) instead of the order recorded (1,2,3, etc .). If you choose SHUFFLE REPEAT, all the Tracks, Chapters, and/or Titles will play in random order repeatedly.

To cancel repeat or shuffled playback,press REPEAT until all

the repeat and shuffle modes disappear from the TV screen.

Repeat A-B

You also may set the Player to play only a specific portion of a Disc repeatedly.Follow these steps.

Press PLAY BBto start Disc playback.

When the Disc reaches the point at which you want repeated playback to begin,press REPEAT A-B.

When the Disc reaches the point at which you want to end the segment, press REPEAT A-B again. The segment will begin

playing repeatedly. On a DVD,make sure the entire A-B segment is within a single Title. On a Video CD or Audio CD,the A-B segment should be within a single Track. If you do not enter the B setting before the end of the Title or Track is reached, Repeat A-B will be cancelled.

To resume regular playback,press REPEAT A-B until the

repeat mode disappears from the TV screen.

DVD

VIDEO CD AUDIO CD

DVD

VIDEO CD AUDIO CD

1,2

2-4

• You can not use the Number buttons to play a different Track or Chapter during Shuffled playback.

• If you press STOP 7 to stop repeat or shuffled play,when you resume play,REPEAT or SHUFFLE will be cancelled.On an Audio CD,play will stop at the end of the current Track. When you start play again, play will start at the beginning of the Audio CD.

• You also can set up Repeat Play in the Display.During DVD or Video CD play,press DISPLAY on the remote to access the display screen.Press 3or 4 to highlight REPEAT,then press OK. Press 3or 4 to choose a Repeat mode, then press OK. Press DISPLAY on the remote to remove the display.This feature is not available with all Discs.

Helpful Hints

Page 25

DVD Audio Language 25

Some DVDs are recorded in multiple languages;some may have extra audio options such as a director’s commentary or a music soundtrack. You can choose the language or the soundtrack that you want to hear by adjusting AUDIO in the PREFERENCE PAGE. To do so,follow the steps below.

The easiest way to choose a different audio language or soundtrack is to press the AUDIO button on the remote during DVD playback.The audio will change to the language or soundtrack you select.

Press STOP 7 twice to stop DVD playback.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4. You can select the

PREFERENCE PAGE icon only if you have completely stopped DVD playback by pressing STOP 7 twice as directed in step 1.

AUDIO will be selected in green. Press 2.

Language options will appear to the right of AUDIO. Press 3 or 4 to choose the language you want,then press OK.The

selected language will be highlighted in brown. You can only hear these languages if the language is recorded on the DVD.

If there is another language on the DVD that does not show in this AUDIO menu,choose OTHERS,then press OK.At the next screen,press the Number buttons to enter the fourdigit language code for the language you want.Use the codes

listed on page 49 of this manual.Then, press OK. The PREFERENCE PAGE menu will reappear with a different feature selected.

Press SYSTEM MENU to remove the menus.

DVD

2,6

3-5

• Some Audio CDs, Video CDs,or

Super Video CDs are recorded on multiple audio channels. For example, a Karaoke Disc may record music on the left channel and vocals on the right channel. Press AUDIO during playback to choose which channels you want to hear.Options may include MONO LEFT,MONO RIGHT, MIX-MONO,or STEREO.Check your Disc case for details. If DIGITAL OUTPUT is set to ALL,you may not be able to select MONO LEFT or MONO RIGHT.Details are on page 40.

• If adjusting the Audio language

as described on this page does

not change the Audio, c hange the settings in the DVD’s Disc menu or by pressing the AUDIO button repeatedly during DVD playback. Make sure the language you want is available on the current DVD.

• When you press STOP twice to stop playback and adjust AUDIO, this cancels the Resume feature.When you play the DVD again,playback starts at the

beginning of the DVD.

• You also can change the Audio

in the Display.During playback,

press DISPLAY on the remote to

access the display screen.Press

3 or 4 to highlight AUDIO,then

press OK.Press 3 or 4 to choose an audio option, then press OK.Press DISPLAY on the remote to remove the display. This feature is not available with all DVDs.

Helpful Hints

Page 26

26 DVD Subtitle Language

Some DVDs include subtitles.Choose the language you want for available subtitles by adjusting SUBTITLE in the PREFERENCE PAGE. To do so, follow the steps below. Or,the easiest way to choose subtitles is to press the SUBTITLE button on the remote repeatedly during DVD playback.The subtitles will appear in the language you select.

Press STOP 7 twice to stop DVD playback.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4. You can select the

PREFERENCE PAGE icon only if you have completely stopped DVD playback by pressing STOP 7 twice as directed in step 1.

Press 4 to select SUBTITLE, then press 2.

Language options will appear to the right of SUBTITLE.Press 3 or 4 to choose the language in which you want subtitles to

appear.Then, press OK.The selected language will be highlighted in brown. You can see subtitles in these languages only if available on the current DVD.Check the DVD case for details on available subtitle languages.

If there is a subtitle language on the DVD that does not show in the Player’s SUBTITLE menu, choose OTHERS and press OK. At the next screen,press the Number buttons to enter the four-digit language code for the language you want. Use the

codes listed on page 49 of this manual.Then, press OK. The PREFERENCE PAGE menu will reappear with a different feature selected.

Press SYSTEM MENU to remove the menus.

DVD

• Some DVDs only allow you to

choose Subtitle languages in the DVD Disc menu.If adjusting the Subtitle language as described on this page does not change the Subtitles during DVD playback,change the settings in the DVD’s Disc menu or by pressing the SUBTITLE button repeatedly during DVD playback.Make sure the language you want is available on the current DVD.

• When you press STOP 7twice

to stop playback and adjust SUBTITLE,this cancels the Resume feature.When you start to play the DVD again, playback automatically starts at the beginning of the DVD.

• You also can change the Subtitle

language in the Display.During playback, press DISPLAY on the remote to access the display screen.Press 3 or 4 to highlight SUBTITLE,then press OK.Press 3 or 4 to choose a subtitle language option,then press OK. Press DISPLAY on the remote to remove the display.This feature is not available with all DVDs.

Helpful Hints

2,6

3-5

Page 27

DVD Disc Menu Language 27

DVDs have a Disc menu that allows you to choose options such as Audio Language, Subtitles, or other special features.Features vary among DVDs,so the menus are different for every DVD. Some menus may be available in multiple languages. To choose a language for a Disc menu using the PREFERENCE PAGE,follow these steps.

Press STOP 7 twice to stop DVD playback.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4. You can select the

PREFERENCE PAGE icon only if you have completely stopped DVD playback by pressing STOP 7 twice as directed in step 1.

Press 4 to select DISC MENU, then press 2.

Language options will appear to the right of DISC MENU.Press 3 or 4 to choose the language in which you want the DVD Disc menu to appear.Then, press OK.The selected language

will be highlighted in brown. You can see Disc menus in these languages only if available on the current DVD.Check the DVD case for details on available menu languages.

If there is a menu language on the DVD that does not show in the Player’s DISC MENU list,choose OTHERS and press OK. At the next screen,press the Number buttons to enter the four-digit language code for the language you want. Use the

codes listed on page 49 of this manual.Then, press OK. The PREFERENCE PAGE menu will reappear with a different feature selected.

Press SYSTEM MENU to remove the menus.

• If adjusting the Disc menu

language as described on this page does not change the language as you preferred, change the settings in the DVD’s Disc menu.Make sure the language you want is available on the current DVD.

• When you press STOP 7twice

to stop DVD playback so you can adjust DISC MENU,play automatically starts at the beginning of the DVD when you start play again.

Helpful Hints

DVD

2,6

3-5

Page 28

28 Parental Password

The PARENTAL feature limits viewing of DVDs. You need a password to change the PARENTAL settings or to play Locked Discs.To set your password,follow the steps below. To adjust the PARENTAL level so DVDs cannot play if they exceed that level,see page 30. To prevent specific DVDs from playing,regardless of how you set the PARENTAL level,see page 29.

Press SYSTEM MENU.

Press 2 to select the PASSWORD SETUP PAGE icon at the top of the menu,then press OK or 4.

PASSWORD will be highlighted in green.

Press 2 to highlight CHANGE in green,then press OK.

A box beside OLD PASSWORD will be highlighted.

Press the Number buttons to enter your old six-digit password in the OLD PASSWORD box. (If this is the first time

you have set a password,you do not have to enter an OLD PASSWORD.The numbers you enter will go into the NEW PASSWORD box automatically instead.) Next,press the Number

buttons to enter a new six-digit password of your choice in the NEW PASSWORD box.Then, press the Number buttons to enter the same new six-digit password in the

CONFIRM PWD box.

Press OK to save the new password. The previous menu will

appear.

Press SYSTEM MENU to remove the menus.

DVD

• The default or factory preset password is 842100. You can use it to play a Locked Disc or enter it as the old password. The 842100 password is acceptable even after you set your own personal password.

• Philips denies any liability associated with unintended watching of Discs. Make sure your Discs play according to your PARENTAL settings before you allow children access to the Player.

• Your password must have exactly six digits.A series of *s will appear instead of your actual password to protect the password's identity.

• If you make a mistake or can

not remember the new password when you get to the CONFIRM PWD box,press SYSTEM MENU to quit.Then, start again at step 1.

Helpful Hints

2-3,5

1,6

Page 29

Disc Lock 29

Not all DVDs are rated or coded by the Disc maker.You can specifically lock or unlock a DVD,regardless of its rating.If you lock a specific DVD, you must enter your password before you can watch the DVD. Password

details are on page 28.

Press SYSTEM MENU.

The GENERAL SETUP PAGE icon will be selected at the top of the menu. Press OK or 4.

Press 4 to select DISC LOCK, then press 2.

Press 3 or 4 to select UNLOCK or LOCK, then press OK.

Your selection will be highlighted in brown. If you choose UNLOCK, the DVD that is currently in the DVD Player will be unlocked for future viewing.You can view the Disc without having to enter your six-digit password. If you choose LOCK,the DVD that is currently in the DVD Player cannot play unless you enter your six-digit password.PLEASE ENTER PASSWORD will appear on the TV screen to prompt you to enter your password the next time you play the disc.Press the

Number buttons to enter your password, then press OK.

Your password will not appear on the TV screen.This protects its identity. Password details are on page 28. You may need to turn the DVD player off, then on again, for the lock setting to take effect.

Press SYSTEM MENU to remove the menus.

1,5

2-4

• Two-sided DVDs may have a different ID for each side.To unlock the entire Disc , unlock

each side.

• Multi-volume Video CDs or

DVD sets may have a different ID for each volume or Disc.To unlock the set, unloc k each volume or Disc.

• Once you enter your password

to play a Locked Disc, you can stop and resume playback without reentering the password every time you resume play.However, if you open the disc tray or turn off the DVD Player,you will have to enter the password to play the Disc again.

• You cannot select DISC LOCK

if there is no Disc in the Player.

Helpful Hints

Page 30

30 Parental Levels

You can set the Player to block or allow playback according to the DVD movie rating. Some DVDs may give you the option of entering your password to allow playback. If not, change the PARENTAL setting so you can watch the Disc. Not all DVDs conform to the levels you select,as not all DVDs are coded or protected by the DVD manufacturer. Therefore, make sure the DVD plays according to your PARENTAL setting before you allow children unlimited access to the Player or DVDs. To prevent specific DVDs from playing,regardless of how you set the PARENTAL level,see page 29.

Press STOP 7 twice to stop DVD playback.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4. You can select the

PREFERENCE PAGE icon only if you have completely stopped DVD playback by pressing STOP 7 twice as directed in step 1.

Press 4 to select PARENTAL, then press 2.

Press 3 or 4 to choose the Parental level at which you want to restrict playback,then press OK.

For example,if you do not want children to watch movies rated above PG,select 3 PG.DVDs rated PG can play without entering a password;however, DVDs rated PG-13,R,NC-17, or X (ADULT) cannot play unless you enter your password.

A screen will prompt you to enter your password. Press the Number buttons to enter your six-digit password, then press OK.The Parental settings will appear,with the level you

selected highlighted in brown. Your password will not appear on the TV screen,but Xs will show as you enter each digit.Password details

are on page 28.

Press SYSTEM MENU to remove the menus.

RATING EXPLANATIONS

• ADULT - Mature material;should be viewed only by adults due to graphic sexual material,violence,or language.

• NC-17 - No children under age 17; not recommended viewing for children under age 17.

• R - Restricted; recommended that parents restrict children under age 17 from viewing or allow children to view only when supervised by a parent or adult guardian.

• PGR - Parental Guidance Required

• PG 13 - Material is unsuitable for children under age 13.

• PG - Parental Guidance suggested.

• G - General Audience;recommended as acceptable for viewers of all ages.

• KID SAFE - Safe for children to view

2,7

3-6

• When you press STOP 7twice to stop DVD play so you can adjust the PARENTAL level,play starts at the beginning of the DVD when you resume play.

• The PARENTAL settings do not affect Video CDs,Super Video CDs, or Audio CDs.PARENTAL only affects DVD playback.

Helpful Hints

Page 31

Program 31

You may play Tracks or Chapters in an order you specify instead of normal order (1,2, 3, etc.).The order you set is a Program.For example, if you want to set up an Audio CD so Track 12 will play first, put Track 12 in Program position number one (1). To set up a Program, follow these steps.

Press SYSTEM MENU.

The GENERAL SETUP PAGE icon will be selected.Press OK or 4.

Press 4 to select PROGRAM.

Press 2 to select INPUT MENU, then press OK. The

PROGRAM menu will appear.This is where you enter the Track/Chapter numbers in the order in which you want to play them. The Number 1 space will be selected automatically as your starting point.

While the Number 1 space is highlighted, press the Number buttons to enter the Title and/or Chapter/Track number you want to play first. The number of available Titles,

Chapters,or Tracks will appear at the top of the screen.

Use the Number buttons on the remote to enter other Titles/Chapters/Tracks.Use the 3 4 1 2 buttons to move to other Program positions. Repeat this process to fill the Program.

If you enter an incorrect Title/Chapter/Track number,press 34 1 2 to select the Program position.Use the Number buttons to reenter the correct Title/Chapter/Track number. To delete an item from the Program, use the 3 4 1 2 buttons to select it. Then, press OK or PLAY 2 to erase the item.

When you have entered all the items you want,press 4, 1, and/or 2 to select START at the bottom of the screen. Then, press OK. This will store the Tracks in the Program.The

Program will start playing automatically.You can start playing a Program only from the Program menu.

To resume normal playback,press STOP C twice to stop playing the Program.Press PLAY 2 to start play at the beginning of the Disc.

2-6

• To access other Program pages, press Previous 4 or Next

¢ .

• To stop entering Tracks in the

Program,press 4 and 1 or 2 to select EXIT at the bottom of the screen,then press OK.The Disc will resume play in normal order.

• The Program will accept a

Title/Chapter/Track number only if it is on the current Disc.

• A Program can have up to 20

Tracks/Chapters.

Helpful Hints

4-5

AUDIO CD VIDEO CDDVD

Audio CD example

Page 32

32 Preview

Some Video CDs or Super Video CDs may contain preview or introductory information.If you are not sure of the contents of a Video CD or its Tracks, use the Preview features to see the content of the Tracks.Not all Video CDs contain this information.See your Disc case for details.

Press the PREVIEW button to see the Preview menu.

Press 3 or 4 to select TRACK DIGEST,DISC INTERVAL,or TRACK INTERVAL, then press OK.

• If you select TRACK DIGEST, the first five seconds of each

Track will play.This introduces you to the contents of each Track on the Disc. Six Tracks will show on one screen.To see other Tracks, press Previous 4 or Next ¢ on the remote. To play a certain Track,press 3 to go to the SELECT line in the display at the bottom of the TV screen. Press the Number buttons to enter the Track you want.Then, press OK to start playback.

• If you select DISC INTERVAL,the Disc contents will be divided into six segments. This helps you preview the contents of the entire Disc. To start playing the Disc from a certain interval, press 3 to go to the SELECT line in the display at the bottom of the screen. Press the Number buttons to choose a segment (1-6),then press OK to start play from that point.

• If you select TRACK INTERVAL, the current Track will be divided into six parts.This helps you see the contents of the current Track.To play the Track from a certain interval, press 3 to go to the SELECT line in the display at the bottom of the screen.Press the Number buttons (1-6) to choose a segment,then press OK to start play from that point.

To remove the PREVIEW menus,press PREVIEW again or press 4 and/or 1 to choose EXIT, then press OK. To go to the first PREVIEW screen, press 4 and/or 2 to select MENU,then press OK.

1,3

2-3

VIDEO CD

SELECT DIGEST TYPE: TRACK DIGEST DISC INTERVAL TRACK INTERVAL

TYPE: TRACK SELECT (01-09) : - -

EXIT MENU

TYPE: DISC INTERVAL SELECT (01-06) : - -

EXIT MENU

TYPE: TRACK 01 INTERVAL SELECT (01-06) : - -

EXIT MENU

Page 33

Navigator 33

This DVD Player can play some Compact Disc-Recordable (CD-R) discs that you record on your computer.These CD-Rs may contain pictures in a JPEG format or audio files/tracks in an MP3 format.For example, you may have photographic film developed by a retailer that places the pictures on a CD-R for you.These pictures may be in JPEG format.Or, you may copy or download MP3 music files from certain legal Internet sites,then copy those files onto a CD-R. (You cannot make or record such CD-Rs using this DVD Player.See your computer manual for details on making CD-R recordings.) If you are playing a CD-R on this Player and the CD-R contains JPEG or MP3 files,you may want to access the CD-R menu using Navigator.

Press STOP 7 during MP3 playback or press DISC MENU during JPEG playback to stop Disc playback completely.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4.You can select the

PREFERENCE PAGE only if Disc play is stopped.

Press 4 to select MP3/JPEG NAV (Navigator), then press 2.

Press 3 or 4 to select WITHOUT MENU or WITH MENU, then press OK. Your selection will be highlighted in brown.If you

select WITHOUT MENU,all individual Tracks will be listed in order in the menu.If you select WITH MENU, both Folders and Individual Tracks show in the menu.You must open the Folders (by selecting and pressing OK) to see the Tracks that are available inside the Folders.

Press SYSTEM MENU to remove the menus.

2,6

3-5

Page 34

34 JPEG and MP3 Features

General Information on CD-R and CD-RWs

● When you make CDs to play on this DVD Player,the Disc should have

at least 6-10 pictures or 2-3 MP3 music files.Make sure there are at least 3 MB (three megabytes) of information on the Disc.The maximum number of files per folder is 500.

● JPEG file names should end with the “.jpg” extension.

● To select a JPEG or MP3 file for playback, press the Number buttons to

select an item,then press OK. Or,press 3 or 4 to select an item,then press OK.

JPEG features

● Press 3 or 4 to highlight an item in the Disc's menu, then the picture

will be previewed on the right side of the menu.

● While playback is stopped,you will see miniature images of the pictures.

A maximum of 12 images will appear.Press Previous 4 or Next

¢ to see the other pictures on the Disc.

● Press ZOOM to enlarge a JPEG image. Press 3, 4,1, or 2 to move or

pan through the picture.

● When play is stopped,press 4 and 1 to select the filmstrip icon at the

bottom of the screen,then press OK. This will star t play at the first picture on the current page.

● During JPEG playback,press 3,4, 1,or 2 to flip or rotate the image.

● Press the ANGLE button repeatedly during playback to determine how

the images will progress or "scan" in and out.

Repeat/Shuffle

● During JPEG play, press REPEAT to choose:

REPEAT ONE - Keep the current JPEG image still on the screen. REPEAT ALL - Play all files on the Disc repeatedly. SHUFFLE - Play files in random order.

REPEAT OFF - Cancel all repeat options and resume normal playback.

● While the menu is on the screen,press REPEAT to choose:

FOLDER - All files in the current folder will play once.

REPEAT ONE - Keep a JPEG image still on the screen or play an MP3

file repeatedly.

REPEAT FOLDER - Play files in the selected folder repeatedly.

SHUFFLE - Play files in random order.

MP3 Program

While the Disc menu is on the screen and play is stopped, press 1 to switch into the FILELIST.FILELIST will flash briefly at the bottom of the screen.

2 Press 3 or 4 to choose a Track to add to the playlist, then press 2.

ADD TO PLAYLIST will appear briefly at the bottom of the screen.(To remove an item from the Program,press 1 to go to the PLAYLIST. Press 3 or 4 to choose the item, then press 2 to remove it.REMOVE FROM PLAYLIST will appear briefly at the bottom of the screen.)The maximum number of files for a Program is 100.

3 To play the Program,press 1 to go to the PLAYLIST.PLAYLIST will flash

briefly at the bottom of the screen.press 3 or 4 to select any item in the PLAYLIST,then press OK to start playing the Program from that point.

Playing MP3 and JPEG files simultaneously “Setting your pictures to music”

Start playing the MP3 file as described above.

2 Select a JPEG for playback as described above. 3 To stop simultaneous playback,press DISC MENU to stop JPEG

playback.Then press STOP 7 to stop MP3 playback.

Page 35

• DVDs only play in the format in which they were recorded.

For example, if the DVD case says the DVD is recorded in Letterbox or Widescreen format,you may play the DVD only with the black bars showing at the top and bottom of the widened picture. Even if you set TV DISPLAY to 4:3 PAN SCAN, the picture will show in the widened format.

• Some widescreen TVs may

show only part of the DVD Player’s menu.Adjust the screen mode on your TV.See your TV owner’s manual for details.

Helpful Hints

TV Display 35

You may set the DVD Player to display video in one of three formats: Letter Box,Pan & Scan, or Widescreen (16:9). To choose a format, follow these steps. The format you select must be available on the DVD.If it is not, the settings for TV DISPLAY will not affect the picture during DVD playback.

Press SYSTEM MENU.

Press 2 to select the VIDEO SETUP icon at the top of the menu,then press OK or 4.

Press 4 to select TV DISPLAY. Then press 2.

Press 3 or 4 to select 4:3 PANSCAN, 4:3 LETTER BOX,or 16:9 (widescreen),then press OK. Your selection will be

highlighted in brown. Select 4:3 PAN SCAN if you want the picture to be trimmed or formatted to fit your TV screen.This setting is possible only if the DVD is recorded in pan & scan or regular format.Check the Disc case for details. Select 4:3 LETTER BOX if you want to see the entire,widened picture with black bars at the top and bottom of the screen.This looks like the picture you see when watching movies in a theater.This setting is possible only if the DVD was recorded in the letterbox or widescreen format.Check the Disc case for details. Select 16:9 (widescreen) if you connected the DVD Player to a widescreen TV.

Press SYSTEM MENU to remove the menus.

1,5

2-4

16:9 (Widescreen TV)

4:3 LETTER BOX

4:3 PAN SCAN

Page 36

36 Smar t Picture, Picture Setting

Just as you can adjust your picture on your TV, you can adjust some picture elements at the DVD Player.Choose a picture setting that best displays the Disc you are playing.This feature is known as Smart Picture and can be adjusted by following these steps.

Press SYSTEM MENU.

Press 2 to select the VIDEO SETUP icon at the top of the menu,then press OK or 4.

Press 4 to select SMART PICTURE.Press 2.

Press 3 or 4 to select STANDARD,BRIGHT, SOFT, or PERSONAL, then press OK. Your selection will be highlighted

in brown.

If you selected BRIGHT, STANDARD,or SOFT, you are finished. Press SYSTEM MENU to remove the menus.You

may want to play a Disc for a few minutes in each setting to decide which you prefer.

If you selected PERSONAL,you can adjust specific picture elements for your preference. Go to step 6 to adjust these items.

Press 1 to reselect SMART PICTURE.SMART PICTURE will be highlighted in green. Press 4 to select PICTURE SETTING, then press OK.

Press 3 or 4 to select BRIGHTNESS, CONTRAST,TINT, or COLOR, then press 2.

2-7

1,5

Page 37

Smart Picture, Picture Setting (cont’d) 37

An adjustment scale will appear on the TV screen. Press 1 or 2 to adjust the element you selected.

• For BRIGHTNESS,choosing a more positive value brightens the color on the screen and seems to add white to the picture. Choosing a more negative value darkens the colors in the picture. Choose zero (0) for the average setting.

• For CONTRAST,choosing a more positive value adds more noticeable difference between the black and white in your picture and sharpens the picture.Choose a more negative CONTRAST value to blur the distinction between black and white in the picture. The picture will not seem as sharp.

• For TINT, choose a more positive value to add red to the picture. Choose a negative value to add yellow to the picture. Choose zero (0) to balance the reds and yellows in the picture.You can adjust TINT when you need people’s skin tones to look more natural.

• For COLOR,choose a more positive value to increase the color in your picture. To decrease the color in the picture,choose a more negative value. As you decrease the COLOR,the picture becomes more black and white.Choose zero (0) to balance the color.

Press OK to save the setting and return to the PICTURE SETTING menu.Repeat steps 7-8 as necessary to adjust all the elements you want.

When you are finished,press SYSTEM MENU.

8-9

Page 38

TV Type

DVDs are recorded in a color system,usually NTSC or PAL.NTSC is the most common in the United States.Your TV also has a color system. This Player is compatible with NTSC and PAL.However,the color system of the DVD,the TV,and the Player should match.If all three are not the same, the DVD may play in only black and white,the picture may roll continuously, or the picture may appear distorted. TV TYPE lets you set the Player to match the color systems of your DVDs and your TV.

Press SYSTEM MENU.

Press 2 to select the VIDEO SETUP PAGE icon at the top of the menu,then press OK or 4.

TV TYPE will be highlighted in green. Press 2.

Press 3 or 4 to select MULTI,NTSC, or PAL, then press OK. Your selection will be highlighted in brown.Choose NTSC if

your TV is NTSC-compatible and your DVDs are recorded in NTSC. Choose PAL if your TV is PAL-compatible and your DVDs are recorded in PAL.Choose MULTI if your TV is compatible with both NTSC and PAL and you want the DVD Player to automatically select the color system of the current DVD.

Press SYSTEM MENU to remove the menus.

• Your DVD must be recorded in NTSC or PAL.Discs recorded in other color systems will not play on this Player.Chec k the Disc case for details. NTSC or PAL may appear on the inside ring of the DVD.

• You can deactivate Progressive Scan so you can use a different hookup.For example, you may want to change TVs later. To cancel Progressive Scan at the DVD player,open the disc tray. Press

s on the remote, then

press MUTE.

Helpful Hints

38 TV Type, Progressive Scan

1,5

2-4

Progressive Scan

If you connected the Player to a TV using the Y Pb Pr jacks and your TV has Progressive Scan,set PROGRESSIVE to ON. Otherwise, set PROGRESSIVE to OFF.

Press SYSTEM MENU.

Press 2 to select the VIDEO SETUP PAGE icon at the top of the menu,then press OK or 4.

Press 4 to select PROGRESSIVE, then press 2.

Press 3 or 4 to choose ON or OFF,then press OK on the remote. Choose ON only if your TV has Progressive Scan.

A message will ask you to verify your hookups and the availability of Progressive Scan.Press 2 or s to choose OK,then press OK. If Progressive Scan is not detected,the VIDEO SETUP PAGE will reappear.Set PROGRESSIVE to OFF. Or,if you realize you do not have Progressive Scan,choose CANCEL and press OK.Set PROGRESSIVE to OFF.

Press SYSTEM MENU to remove the menus.

1,6

2-5

Page 39

Display Dim,Analog Output 39

Analog Output

Use the AUDIO SETUP PAGE to adjust some of the Player’s audio settings. Adjust DOWNMIX according to how you connected the Player to your TV and/or Stereo.Balance the volume during playback by adjusting Dynamic Range Control (D.R.C.).

Press SYSTEM MENU.

Press 2 to select the AUDIO OUTPUT PAGE icon at the top of the menu. Press OK or 4.

ANALOG AUDIO SETUP will be highlighted in green.Press 2.

Press 3 or 4 to select DOWNMIX or D.R.C.,then press 2 and follow step 5 according to your choice.

• If you selected DOWNMIX, press 3 or 4 to select LT/RT (left/right) or STEREO,then press OK. Choose LT/RT if you

connected the Player to a stereo that has Dolby Pro Logic.Details are on page 14. Select STEREO if you connected the Player to a TV or

Stereo that has left and right Audio In jacks but does not have Dolby Pro Logic.

• If you selected D.R.C., press 3or 4to select ON or OFF,then press OK.To level the volume during Disc playback,choose ON.There

will not be such a large range between the loudest and softest parts of the sound.To hear the highs and lows of the volume,set D.R.C.to OFF.

Press SYSTEM MENU to remove the menus.

1,6

2-5

1,5

2-4

Display Dim

You can adjust the brightness of the display panel on the front of the Player by following these steps.

Press SYSTEM MENU.

The GENERAL SETUP PAGE icon will be selected. Press OK or 4.

Press 4 to select DISPLAY DIM, then press 2.

Press 3 or 4 to select 100%,70%, or 40%, then press OK. Your

selection will be highlighted in brown.The display panel will dim or brighten according to your choice.

Press SYSTEM MENU to remove the menus.

Page 40

LPCM Output

If you connected the Player to a Stereo using the COAXIAL or OPTICAL jack as shown on page 15,adjust LPCM OUTPUT. Discs are recorded in a certain sampling rate. The higher the sampling rate, the better the sound quality. Some Discs are recorded in a high sampling rate of 96 kHz. Set LPCM OUTPUT to 96K if you are playing Discs recorded at this high rate.Otherwise, set LPCM OUTPUT to 48K.

Press SYSTEM MENU.

Press 2 to select the AUDIO SETUP PAGE icon at the top of the menu. Press OK or 4.

Press 3 or 4 to select DIGITAL AUDIO SETUP,then press OK.Press 4 to select LPCM OUTPUT,then press 2.

Press 3 or 4 to select 48K or 96K, then press OK. Your

selection will be highlighted in brown.

Press SYSTEM MENU to remove the menus.

Digital Output

If you connected the Player to a Stereo using the COAXIAL jack as shown on page 15,adjust DIGITAL OUTPUT (audio) as described below.If you are not using the COAXIAL jack,no adjustment is necessary.

Press SYSTEM MENU.

Press 2 to select the AUDIO SETUP PAGE icon at the top of the menu. Press OK or 4.

Press 4 to select DIGITAL AUDIO SETUP,then press OK. DIGITAL OUTPUT will be highlighted in green.Press 2.

Press 3or 4to select ALL or PCM ONLY, then press OK.

Choose ALL to select the original default audio settings as received by most Stereos. If the sound is distorted, your Stereo may need to receive audio in the PCM format (pulse code modulation,contains only left and right audio signals).Choose PCM ONLY if your Stereo is PCM-compatible or cannot decode MPEG-2 or DTS audio.Refer to your Stereo owner’s manual for details.

Press SYSTEM MENU to remove the menus.

40 Digital Output, LPCM Output

1,5

2-4

1,5

2-4

Page 41

Sound Mode, 3D Sound 41

Sound Mode

Select the sound mode that matches the type of music you play most often. These preset sound modes adjust the frequency bands of the audio to enhance your favorite music style. Or,you can choose a Sound Mode quickly by pressing the SURROUND button on the remote during DVD playback.

Press SYSTEM MENU.

Press 2 to select the AUDIO SETUP PAGE icon at the top of the menu. Press OK or 4. ANALOG AUDIO SETUP will be highlighted in green.Press OK.

Press 4 to select SOUND MODE, then press 2.

Press 3 or 4 to select NONE, ROCK, POP,LIVE, DANCE, TECHNO,CLASSIC, or SOFT, then press OK.Your selection

will be highlighted in brown. Choose NONE to play the Disc with its original sound effects.

Press SYSTEM MENU to remove the menus.

3D Sound

During music playback,this feature simulates echoes and frequencies that may be available in a particular environment. Choose the environment that you would like to recreate by changing the 3D SOUND setting.

Press SYSTEM MENU.

Press 2 to select the AUDIO SETUP PAGE icon at the top of the menu. Press OK or 4. ANALOG AUDIO SETUP will be highlighted in green.Press OK.

Press 4 to select 3D SOUND,then press 2.

Press 3 or 4 to select OFF,CONCERT, LIVING ROOM, HALL,ARENA, or CHURCH, then press OK. Your selection

will be highlighted in brown. Choose OFF to play the Disc with its original sound effects.

Press SYSTEM MENU to remove the menus.

1,5

2-4

1,5

2-4

Page 42

42 Display Language, Closed Captions

Display Language

You can set the DVD Player’s Setup menus and on-screen messages to appear in English,Spanish, or French.These are the only three languages available.This language selection will not affect the languages of DVD Disc or Title menus or any audio, subtitle , or Closed Caption languages. To change the DVD Player’s menu language, follow these steps.

Press SYSTEM MENU.

The GENERAL SETUP PAGE will be selected. Press OK or 4.

OSD LANGUAGE (on-screen display) will be highlighted in green.

Press 2.

Press 3 or 4 to select ENGLISH, ESPAÑOL (Spanish), or FRANCAIS (French),then press OK.Your selection will be

highlighted in brown.The menus will change to the language you selected.

Press SYSTEM MENU to remove the menus.

Helpful Hint

• If you have French or Spanish menus and need English:

1) Press SYSTEM MENU.2)The first icon on the left (PAG.CONFIG.GENERAL or PAGE REGLAGES GENERAUX) will be selected.Press OK.

3) With LANGUE OSD or IDIOMA MENUS highlighted in green,press 2.

4) Press 3 to select ENGLISH, (or INGLES),then press OK.

5) Press SYSTEM MENU.

Closed Captions

Closed captions are hidden in the video signal of some Discs.Different than subtitles,closed captions are intended for the hearing impaired and also show sound effects.For example,closed captions may include information such as “phone ringing” or “footsteps approaching,” while a subtitle would only show spoken text. Though you can turn on Closed Captions in the DVD Player’s menu,the captions must be available on the Disc.Also make sure you turn on Closed Captioning on your TV. Otherwise, the captions will not appear.

Press SYSTEM MENU.

Press 2 to select the VIDEO SETUP PAGE icon at the top of the menu.Press OK or 4.

Press 4 to select CLOSED CAPTIONS. Press 2.

Press 3 or 4 to select ON or OFF,then press OK.Your selection

will be highlighted in brown.

Press SYSTEM MENU to remove the menus.

1,5

2-4

1,5

2-4

Page 43

DVD Player Defaults

To restore the original settings of the DVD Player, follow the steps below.

Press STOP 7 twice to stop Disc playback completely.

Press SYSTEM MENU.

Press 2 to select the PREFERENCE PAGE icon at the top of the menu,then press OK or 4.

Press 4 to select DEFAULT. Press 2 to highlight RESET in green,then press OK.The original settings of the DVD

Player will be restored. The menus will disappear automatically.

3,4

Screen Saver,DVD Player Defaults 43

Screen Saver

The Screen Saver is the moving DVD logo that appears on your TV screen when playback is stopped.It prevents damage to your TV screen caused by leaving a still image on the TV too long.

Press SYSTEM MENU.

The GENERAL SETUP PAGE will be selected. Press OK or 4.

Press 4 to select SCREEN SAVER,then press 2.

Press 3 or 4 to select ON or OFF, then press OK.Your

selection will be highlighted in brown.Choose ON to have the Screen Saver appear on your TV screen when you have not used the Player or its remote for approximately five minutes and playback is stopped or paused.To disable the screen saver, choose OFF.A dark blue DVD screen will appear when playback is stopped.

Press SYSTEM MENU to remove the menus.

Helpful Hint

• Restoring the Defaults will reset the Player’s menus to English.

1,5

2-4

Page 44

44 Setting the Remote to Operate Your TV

The DVD Player’s remote can operate some features of some televisions.First, you must tell the remote your brand of TV using the codes on pages 44-45.

Press and hold RETURN and OK on the remote for three seconds,then release.

Immediately press the Number buttons to enter the code for your brand of TV.

Press DVD/TV to put the remote in TV mode when you want it to

control TV features. Press DVD/TV again to return to using the remote to work the DVD Player.

AOC . . . . . . . . .0046,0057

ASA . . . . . . . . . . . . . . .0114

AWA . . . . . . . . . . . . . .0036

Acura . . . . . . . . . . . . .0036

Admiral . . . . . . .0114,0120,

. . . . . . . . . . . . . .0190,0490

Adyson . . . . . . . . . . . .0244

Aiko . . . . . . . . . . . . . . .0119

Aiwa . . . . . . . . . . . . . .0728

Akai . . . . .0036,0057,0235,

. . . . . . . . . . . . . .0245,0629

Akura . . . . . . . . .0245,0291

Alaron . . . . . . . .0206, 0243

Alba . . . . .0036,0245,0063,

. . . . . . . . . . . . . .0398,0695

Allorgan . . . . . . . . . . . .0321

Ambassador . . . . . . . .0204

America Action . . . . . .0207

Amplivision . . . . . . . . .0244

Ampro . . . . . . . . . . . . .0778

Amstrad . . . . . .0204,0198,

. . . . . . . . . . . . . .0398,0036

Anam . . . . . . . .0188,0207,

. . . . . . . . . . . . . .0277,0036

Anam National .0188,0277

Anitech . . . . . . . . . . . .0036

Arcam . . . . . . . .0243, 0244

Asuka . . . . . . . . . . . . .0245

Atlantic . . . . . . . . . . . .0233

Audiosonic . . . . . . . . .0136

Audiovox . . . . .0119, 0207,

. . . . . . . . . . . . . .0478,0650

Autovox . . . . . .0233,0114

BPL . . . . . . . . . . . . . . .0309

BSR . . . . . . . . . . . . . . .0321

BTC . . . . . . . . . . . . . . .0245

Bang & Olufsen . . . . . .0114

Basic Line . . . . . .0036,0245

Baur . . . . . . . . . . . . . . .0037

Baysonic . . . . . . . . . . .0207

Beaumark . . . . . . . . . .0205

Beko . . . . . . . . .0397,0741

Belcor . . . . . . . . . . . . .0046

Bell & Howell . .0043,0181

Binatone . . . . . . . . . . .0244

Blaupunkt . . . . . . . . . .0222

Blue Sky . . . . . . .0245,0695

Blue Star . . . . . . . . . . .0309

Bondstec . . . . . . . . . . .0274

Boots . . . . . . . . . . . . . .0244

Bradford . . . . . . . . . . .0207

Brandt . . . . . . . . . . . . .0136

Brionvega . . . . . . . . . .0114

Britannia . . . . . . . . . . .0243

Brockwood . . . . . . . . .0046

Broksonic . . . . .0263,0490

Bruns . . . . . . . . . . . . . .0114

Bush . . . .0398,0695,0245,

. . . . . . . .0036,0063,0309,

. . . . . . . . .0321,0382,0401

CCE . . . . . . . . . . . . . .0244

CGE . . . . . . . . . .0101,0274

CS Electronics . . . . . . .0243

CTC . . . . . . . . . . . . . .0274

CXC . . . . . . . . . . . . . .0207

Candle . . .0213, 0057,0083

Carnivale . . . . . . . . . . .0057

Carrefour . . . . . . . . . .0063

Carver . . . . . . . .0081, 0197

Cascade . . . . . . . . . . . .0036

Century . . . . . . . . . . . .0114

Cimline . . . . . . . . . . . .0036

Cineral . . . . . . . .0478,0119

Citizen . . . . . . .0213, 0083,

. . . . . . . . .0057,0087,0119

Clatronic . . . . . .0274,0397

Concerto . . . . . . . . . .0083

Condor . . . . . . . . . . . .0397

Contec . . . . . . .0036, 0063,

. . . . . . . . . . . . . .0207,0243

Craig . . . . . . . . .0207, 0188

Crosley . .0101,0114,0081

Crown . . . . . . .0397,0036,

. . . . . . . . . . . . . .0207,0445

Curtis Mathes . . . . . .0087,

. . .0057,0043,0074, 0078, . . .0081,0083,0120, 0172,

. . . .0181,0193,0478, 0493

Cybertron . . . . . . . . . .0245

Daewoo . . . . . .0119, 0650,

. . . . . . . .0046,0651,0401,

. . . . . . . . .0478,0036,0181

Dainichi . . . . . . . . . . . .0245

Dayton . . . . . . . . . . . .0036

Daytron . . . . . . . . . . . .0046

De Graaf . . . . . . . . . . .0235

Decca . . . . . . . . . . . . .0099

Denon . . . . . . . . . . . . .0172

Dixi . . . . . . . . . . . . . . .0036

Dual Tec . . . . . . . . . . .0244

Dumont . . . . . .0114, 0044,

. . . . . . . . . . . . . .0046,0097

Dwin . . . . . . . . .0747,0801

Elite . . . . . . . . . . . . . . .0245

Elta . . . . . . . . . . . . . . .0036

Emerson . . . . . .0263,0207,

. . .0205,0206,0490, 0204,

. . .0309,0114,0651, 0650,

. . . . . . . . . . . . . .0046,0181

Envision . . . . . . . . . . . .0057

Erres . . . . . . . . . . . . . .0039

Etron . . . . . . . . . . . . . .0036

Expert . . . . . . . . . . . . .0233

Ferguson . . . . . .0100,0136

Fidelity . . . . . . . . . . . . .0243

Finlandia . . . . . . . . . . .0235

Finlux . . . . . . . .0114,0097,

. . . . . . . . . . . . . .0099,0206

Firstline . . . . . . .0036, 0243,

. . . .0244,0274,0321, 0695

Fisher . . . . . . . .0181,0244,

. . . . . . . . . . . . . .0235,0397

Flint . . . . . . . . . . . . . . .0482

Formenti . . . . . . . . . . .0114

Fortress . . . . . . . . . . . .0120

Frontech .0190,0274, 0291

Fujitsu . . . . . . . .0206,0099,

. . . . . . . . . . . . . .0233,0710

Funai . . . .0207,0321,0198,

. . . . . . . . . . . . . .0206,0291

Futuretech . . . . . . . . . .0207

GE .0048,0074, 0078, 0205,

. . . . . . . . .0478,0120,0309

GEC . . . . . . . . . .0099,0244

GPM . . . . . . . . . . . . . .0245

Geloso . . . . . . . . . . . .0036

General . . . . . . . . . . . .0213

Genexxa . . . . . .0190, 0245

Gibralter .0044,0046, 0057

Goldstar . . . . . .0205, 0046,

. . . .0057,0244,0083, 0136

Goodmans . . . .0099,0206,

. . . . . . . .0398,0651,0063,

. . . . . . . . . . . . . 0244,0401

Gorenje . . . . . . . . . . . .0397

Gradiente . . . . . . . . . .0083,

. . . . . . . . . . . . . .0080,0197

Graetz . . . . . . . . . . . . .0190

Granada . .0099, 0235,0244

Grandin . . . . . . .0309,0637

Grundig . . . . . . .0097,0222,

. . . . . . . . .0514,0583,0614

Grunpy . . . . . . .0206,0207

HCM . . . . . . . . .0036,0309

Hallmark . . . . . . . . . . .0205

Hanseatic . . . . . . . . . .0583

Harley Davidson . . . . .0206

Harman/Kardon . . . . .0081

Harvard . . . . . . . . . . . .0207

Hinari . . . . . . . .0036, 0063,

. . . . . . . . . . . . . .0245,0206

Hisawa . . . . . . . .0309,0482

Hitachi . . . . . . .0172, 0190,

. . . . . . . .0178,0136,0244,

. . . .0063,0083,0043, 0605

Huanyu . . . . . . .0243,0401

Hypson . . . . . . .0291,0309

ICE . . . . . .0244, 0291,0398

ICeS . . . . . . . . . . . . . . .0245

ITS . . . . . . . . . . . . . . . .0398

ITT . . . . . . . . . . . . . . .0190

Imperial . . . . . . .0274, 0101,

. . . . . . . . . . . . . .0445,0397

Infinity . . . . . . . . . . . . .0081

Ingelen . . . . . . . . . . . . .0190

Inno Hit . . . . . . . . . . . .0099

Inteq . . . . . . . . . . . . . .0044

Interfunk . . . . . .0190, 0274

Intervision . . . . .0244, 0291

Isukai . . . . . . . . . . . . . .0245

JBL . . . . . . . . . . . . . . . .0081

JVC . . . . . . . . . .0080,0063,

. . . . . . . . . . . . . .0187,0398

KEC . . . . . . . . . . . . . . .0207

KTV . . . . .0207,0244,0057

Kaisui . . . .0245,0244,0036,

. . . . . . . . . . . . . .0243,0309

Helpful Hint

• The MUTE and TV VOL -/+ buttons control the TV’s volume. Use the TV PROG -/+ buttons to change TV channels.

Page 45

Kamp . . . . . . . . . . . . . .0243

Kapsch . . . . . . . .0190,0233

Karcher . . . . . . . . . . . .0637

Kathrein . . . . . . . . . . .0583

Kawasho . . . . . . . . . . .0243

Kenwood . . . . . .0057,0046

Kingsley . . . . . . . . . . . .0243

Konka . . .0734, 0659,0655,

. . . . . . . . . . . . . .0665,0730

Korting . . . . . . . . . . . .0114

Koyoda . . . . . . . . . . . .0036

LG . . . . . . . . . . . . . . . .0083

LXI .0181,0074,0081, 0205

Leyco . . . .0099,0291, 0321

Loewe . . . . . . . . . . . . .0114

Logik . . . . . . . . . . . . . .0043

Luma . . . . . . . . . . . . . .0233

Luxman . . . . . . . . . . . .0083

M Electronic . . .0244, 0036,

. . . .0136,0190,0401, 0507

MGA . . . . . . . . .0177, 0046,

. . . . . . . . . . . . . .0057,0205

MTC . . . . . . . . .0087, 0057,

. . . . . . . . .0046,0083,0243

Magnadyne . . . .0114, 0274

Magnavox . . . . .0081,0057,

. . . . . . . . .0063,0206,0213

Majestic . . . . . . . . . . . .0043

Manesth . . . . . . .0244,0291

Marantz . .0081,0583,0057

Marelli . . . . . . . . . . . . .0114

Matsui . . . . . . . .0036, 0204,

. . .0382, 0235, 0244, 0398,

. . .0038,0062,0063, 0099,

. . . . . . . . . . . . . .0321,0514

Matsushita . . . . . . . . . .0277

Mediator . . . . . . . . . . .0039

Medion . . . . . . . . . . . .0695

Megatron . . . . . .0172,0205

Memorex . . . . .0206,0490,

. . .0205,0036,0043, 0083,

. . . . . . . . .0177,0181,0277

Metz . . . . . . . . . . . . . .0114

Midland . .0044,0074,0078

Minerva . . . . . . .0514, 0097

Minutz . . . . . . . . . . . . .0048

Mitsubishi . . . . .0177,0063,

. . . . . . . .0135,0205,0046,

. . . . . . . . . . . . . .0120,0114

Mivar . . . . . . . . . . . . . .0243

Motorola . . . . . . . . . . .0120

Multitech . . . . . .0036,0207,

. . . . . . . . . . . . . .0243,0244

Myryad . . . . . . . . . . . .0583

NAD . . . . . . . . .0193, 0205

NEC . . . .0057, 0197, 0063,

. . . . . . . . .0046,0083,0482

NTC . . . . . . . . . . . . . .0119

National . . . . . . . . . . .0253

Neckermann . . .0114,0583

Nesco . . . . . . . . . . . . .0206

Nicamagic . . . . . . . . . .0243

Nikkai . . . . . . . .0062,0245,

. . . . . . . . .0099,0243,0291

Nikko . . . .0205, 0057, 0119

Nokia . . . . . . . . . . . . .0507

Nordmende . . . . . . . .0136

Oceanic . . . . . . . . . . . .0190

Onwa . . . . . . . . . . . . .0207

Optimus . .0277, 0193,0181

Optonica . . . . . . . . . . .0120

Orion . . .0204,0321, 0490,

. . . . . . . . .0206,0263,0382

Osaki . . . . . . . .0099, 0244,

. . . . . . . . . . . . . .0245,0291

Oso . . . . . . . . . . . . . . .0245

Osume . . . . . . . . . . . .0099

Otto Versand . . . . . . .0037,

. . . . . . . . .0063,0244,0583

Palladium . . . . . .0397,0445

Panama . . . . . . .0244,0291

Panasonic . . . . .0078, 0277,

. . . . . . . . .0188,0253,0190

Pathe Cinema . . . . . . .0243

Pausa . . . . . . . . . . . . . .0036

Penney . . . . . . .0074,0087,

. . . . . . . .0057,0048,0205,

. . . . . . . . .0078,0046,0083

Philco . . . . . . . .0114,0101,

. . . . . . . .0274,0172,0046,

. . . . . . . . .0057,0081,0490

Philips . . . . . . . .0583,0039,

. . . . . . . . .0081,0114,0401

Phoenix . . . . . . . . . . . .0114

Phonola . . . . . . .0039,0114

Pilot . . . . . . . . . .0046,0057

Pioneer . . . . . . .0193,0136,

. . . . . . . . . . . . . .0190,0706

Portland . . . . . . .0046, 0119

Princeton . . . . . . . . . . .0744

Prism . . . . . . . . . . . . . .0078

Profex . . . . . . . . . . . . .0036

Proscan . . . . . . . . . . . .0074

Protech . .0036,0695, 0244,

. . . . . . . . .0274,0291,0445

Proton . . . . . . . .0493, 0205

Pulsar . . . . . . . . .0044,0046

Pye . . . . . . . . . . . . . . . .0039

Quasar . . . . . . . .0078, 0277

Quelle . . . . . . . .0097,0101,

. . . . . . . . . . . . . .0037,0038

Questa . . . . . . . . . . . .0063

RBM . . . . . . . . . . . . . .0097

RCA . . . . . . . . .0074,0706,

. . . . . . . . .0046,0078,0120

RFT . . . . . . . . . . . . . . .0114

Radio Shack . . .0207,0057, 0205,0181,0046, 0074, 0083

Radiola . . . . . . . . . . . .0039

Radiomarelli . . . . . . . .0114

Rank Arena . . . . . . . . .0063

Realistic . .0207,0181,0057,

. . . . . . . . .0205,0046,0083

Rex . . . . . .0233,0190,0291

Rhapsody . . . . . . . . . . .0243

Roadstar . . . . . .0036, 0291,

. . . . . . . . . . . . . .0245,0445

Runco . . .0630, 0044, 0057

SBR . . . . . . . . . . . . . . .0039

SEG 0244, 0695,0063,0291 SEI .0037,0114,0204,0321

SSS . . . . . . . . . . .0046, 0207

Saba . . . . .0136,0114,0190

Sagem . . . . . . . . . . . . .0637

Saisho0038,0204,0036, 0291

Salora . . . . . . . . . . . . .0190

Sampo . . . . . . . . . . . . .0057

Samsung .0087,0046, 0205,

. . .0244,0291,0397, 0036,

. . . .0057,0083,0583, 0614

Sandra . . . . . . . . . . . . .0243

Sansei . . . . . . . . . . . . .0478

Sansui . . . . . . . . . . . . .0490

Sanyo . . . .0181,0063,0235,

. . . . . . . . .0038,0099,0451

Schneider . . . . .0245,0274,

. . . . . . . . . . . . . .0398,0695

Scimitsu . . . . . . . . . . . .0046

Scotch . . . . . . . . . . . . .0205

Scott . . . . . . . . .0263,0046,

. . . . . . . . .0205,0206,0207

Sears . . . .0181, 0083,0074,

. . . .0081,0198,0205, 0206

Seleco . . . . . . . .0233,0190

Semivox . . . . . . . . . . . .0207

Sentra . . . . . . . . . . . . .0062

Sharp . . . . . . . . .0120,0063,

. . . . . . . . . . . . . .0715,0283

Shogun . . . . . . . . . . . .0046

Shorai . . . . . . . . . . . . .0321

Siarem . . . . . . . . . . . . .0114

Siemens . . . . . . . . . . . .0222

Signature . . . . . . . . . . .0043

Silver . . . . . . . . . . . . . .0063

Simpson . . . . . . . . . . . .0213

Singer . . . . . . . . . . . . .0114

Sinudyne . . . . . .0037,0114,

. . . . . . . . . . . . . .0204,0321

Solavox . . . . . . . . . . . .0190

Sonitron . . . . . . . . . . .0235

Sonoko . . . . . . . . . . . .0036

Sonolor . . . . . . .0190, 0235

Sony . . . . .0037, 0063,0038

Soundesign . . . .0205, 0206,

. . . . . . . . . . . . . .0207,0213

Soundwave . . . . . . . . .0445

Squareview . . . . . . . . .0198

Standard . .0244, 0245,0036

Starlite . . . . . . . . . . . . .0207

Stern . . . . . . . . .0233, 0190

Sunkai . . . . . . . .0321,0382

SuperTech . . . . . . . . . .0243

Supra . . . . . . . . . . . . . .0083

Susumu . . . . . . . . . . . .0245

Sylvania . . . . . . .0081,0057

Symphonic . . . . .0198,0207

TMK . . . . .0083,0204,0205

TNCi . . . . . . . . . . . . . .0044

Tandy . . . . . . . .0190,0245,

. . . . . . . . .0099,0244,0120

Tashiko . . . . . . . .0063,0244

Tatung . . . . . . . .0099, 0244

TEC . . . . . . . . . .0244, 0274

Technics . . . . . . .0078,0277

Technol Ace . . . . . . . .0206

Techwood . . . . .0078,0083

Teknika . .0213, 0043,0081,

. . .0206,0207,0046, 0119,

. . . . . . . . .0083,0087,0177

Telefunken . . . . .0136,0652,

. . . . . . . . . . . . . .0083,0101

Teletech . . . . . . . . . . . .0036

Teleton . . . . . . .0233, 0063,

. . . . . . . . . . . . . .0213,0244

Tensai . . . . . . . . .0245, 0321

Texet . . . . . . . . .0243,0245

Thomson . . . . . . . . . . .0136

Thorn . . . .0062,0101,0099

Tomashi . . . . . . . . . . . .0309

Toshiba . .0062, 0535,0097,

. . . . . . . . .0087,0063,0181

Triumph . . . . . . . . . . . .0204

Uher . . . . . . . . . . . . . .0233

Universum . . . . .0291,0397

Vector Research . . . . .0057

Victor0063,0080,0187, 0277

Videosat . . . . . . . . . . .0274

Videotechnic . . . . . . . .0244

Vidikron . . . . . . . . . . .0081

Vidtech . . .0046,0063,0205

Voxson . . . . . . . .0114,0190

Waltham . . . . . . . . . . .0244

Wards . . .0081,0205,0043, 0046,0048,0057, 0083, 0206

Wega . . . . . . . . .0114,0063

White Westinghouse .0651,

. . . . . . . . .0650,0243,0490

Yamaha . . . . . . .0046, 0057

Yoko . . . . . . . . .0244,0291

Zanussi . . . . . . . . . . . .0233

Zenith . . . . . . . .0044, 0651,

. . . . . . . . .0043,0119,0490

Setting the Remote to Operate Your TV 45

Helpful Hints

• Before using the remote with the TV,press the DVD/TV button to put the remote in TV mode.

• If the remote does not operate your TV after the first attempt, try the other codes . Repeat these steps until you have tried all the codes for your brand of TV.

• The remote is not guaranteed to be compatible with all TVs.

Page 46

46 Helpful Hints

If you are having problems with your product,check this list of problems and possible solutions before requesting service. You may be able to solve the problem yourself. If you need to call a customer service representative,please know the model number and serial number of your product before you call. This information is on the rear of the product.Also,please take a moment to identify the problem you are having,and be prepared to explain this to the representative.If you believe the representative will need to help you with operations,please stay near the product.Our representatives will be happy to assist you.

No power

• Press the STANDBY-ON yybutton on the front of the DVD Player or POWER yyon the remote.

A red light appears on the front of the Player if the DVD Player is in Standby mode (power off).

• Make sure you connected the DVD Player’s power cord to an AC power outlet.

• Make sure the AC outlet has power by trying another appliance in the same outlet.

No picture

• Make sure the TV power is on.

• Check the video cables.Make sure the cable(s) are fastened securely to the DVD Player and to the TV.

• Set your TV to the correct Video In channel.These channels are usually near channel zero.Or, you may have a button on the TV remote control that selects an Auxiliar y, A/V IN, or Video channel.See your TV owner’s manual for details.Or,go to your lowest TV channel (01 or 02), then change channels down until you see DVD playback or the blue DVD screen on the TV. If you are using an RF modulator as described on page 10,set the TV to channel 3 or 4 instead.

• You only need one video connection between the DVD Player and the TV. Details are on page nine.

• If you did not connect the DVD player using Progressive Scan jacks on the TV,make sure the DVD player is not set to Progressive Scan.Details are on page 38.

Distorted picture

• Check the Disc for fingerprints or scratches.Clean the Disc with a soft cloth,wiping from the center to the edge in a straight line. Do not wipe the Disc in a circular motion.

• Sometimes a small amount of picture distortion may appear.This is not a malfunction.

The picture is distorted, the picture rolls,or the picture is only black and white.

• TVs have a color system standard,usually NTSC in the United States. If the Disc’s or DVD Player’s color system is different than your TV’s color system,the picture may be distorted or colorless. Set the Player’s TV TYPE to match your TV and your DVDs. Details are on page 38.

• A DVD or Video CD picture may become distorted or black and white if you switch among PAL and NTSC (for TV TYPE). If so,set SMART PICTURE to STANDARD to correct the picture.Details

are on page 36.

The sound is distorted or there is no sound during Disc playback.

• Make sure you did not connect any cables from the DVD Player to a Stereo’s “PHONO IN” jack.

• Make sure you did not connect the Player’s COAXIAL or OPTICAL digital audio out jack to an analog jack on the Stereo.(Analog audio jacks are usually labeled as such and are usually red and white.The COAXIAL jack of the DVD player is black.The OPTIC AL jack is square.

No sound

• Check the audio connections.Details are on pages 10-15.Remember, you only need one audio connection.See page nine to see what connection best suits your situation.

• Make sure cables are connected firmly to all equipment.

• Select another channel,sound source,or Auxiliary station at your Stereo or TV.See your Stereo or TV manual for details.Or, continue selecting the different sound sources or modes on the Stereo or TV until you hear sound from the Disc that is in the DVD Player.Details are on pages 10-15.

• Make sure your DOWNMIX,DIGITAL OUTPUT,and LPCM OUTPUT settings match the capabilities of your Stereo or TV. Details are on pages 39-40.

• Check the Audio setting of a DVD in the DVD Disc Menu,if available,and adjust as necessary.

• Deactivate mute at both the DVD Player and your TV.

Page 47

Helpful Hints (cont'd) 47

Disc will not play.

• Make sure the Disc label is facing up.If you are playing a two-sided Disc, make sure the label of the side you want to play is facing up. Details are on page 16.

• Check the Parental controls. Details are on pages 28-30.

• Check the Region Code of the DVD.The DVD must be coded for All regions or Region 1 in order to play on this DVD Player. Details are on page seven.

• See if the Disc is defective by trying another Disc . Make sure the Disc is not scratched or warped. Carefully clean the Disc.Details are on page six.

• You must finalize CD-R, DVD+R,and DVD+RW discs before playing them on this Player.

• If you are playing a CD-R or CD-RW you made, make sure it contains at least 3 MB of data.Details

are on page 34.

An Audio CD will not play.

• Some Audio CDs available on the market are copy protected.These discs will not play on this DVD Player. See your retailer for options regarding non-protected Audio CDs.

The DVD logo does not appear on the TV screen after you remove a Disc.

• Reset the DVD Player by switching it off,then on again.

The DVD Player does not respond to the remote control.

• Aim the remote at the remote sensor on the front of the Player (not toward the TV).

• Remove any obstacles between the DVD Player and the remote control.Move closer to the Player and try the remote again.

• Inspect or replace the batteries in the remote control.Details are on page eight.

• Press the DVD/TV button on the remote once,then try the remote again. If the remote is in TV mode, it cannot control the Player.Pressing DVD/TV switches the remote between TV and DVD Player modes.

The DVD Player will not select some features, such as Angles, Subtitles, or multi-language Audio.

• The feature may not be available on the Disc.If it is not, the B will appear on the TV screen.Check the Disc case to see if the Disc has the feature.If the Disc does not have the feature,the DVD Player cannot create the feature.This is not a malfunction of the Player. Or,the feature may not be available at the present time. Some features are only available during playback,while other items can be accessed only when play is stopped.Try stopping or starting playback,then try the feature again.

The DVD Player does not work.

• Disconnect the power cord from the power outlet for a few minutes. Reconnect the power cord and try to operate the Player again as usual.

The DVD Player turns itself off.

• If there is no activity at the DVD Player or with its remote control for 15 minutes and playback is stopped,the Player will turn itself off.This is an energ y-saving feature that cannot be altered.Press STANDBY-ON y on the Player or POWER y or PLAY 2 on the remote to turn on the Player.

Disc play is irregular or DVD Disc menu operation is faulty.

• Due to the inconsistency of Disc formats provided by various Disc manufacturers,your DVD Player may require a playability enhancement or upgrade. As DVD technology has advanced,these enhancements have become both common and easy to complete. Please contact Philips at 1-800-531-0039 for assistance.

Page 48

Analog: Sound that has not been turned into numbers.Analog sound varies, while digital sound has specific numerical values.Analog sound is available when you use the red and white audio jacks on your equipment. These jacks send audio through two channels,the left and right.

AUDIO OUT Jacks: Jacks on the rear of the DVD Player that send audio to another system (TV, Stereo,etc.). The jacks are red and white.

CD: Compact Disc. Chapter: A part of a Title. COAXIAL jack: Sends digital audio to a Stereo,allowing you to adjust the volume at the Stereo.The Stereo

must have a Coaxial In jack.This connection provides the 5.1 channel surround sound as heard in movie theaters. The COAXIAL jack on the DVD Player is black.

Color system: There are various systems for transmitting television signals,for example PAL, SECAM, and NTSC. NTSC is the most common color system in the United States of America.

Component Video Y Pb Pr Jacks: The Video Out jacks on the rear of the DVD Player that send high-quality video to a TV that has Component Video In jacks. The jacks on the DVD Player are red,blue, and green.

Digital: Sound that has been converted into numerical values.Digital sound is available when you use the Player’s COAXIAL or OPTICAL jack, which sends audio through multiple channels instead of two channels as analog does.

Dolby Digital: A surround sound system that provides 5.1 channel sound as used in movie theaters. DVD: Digital Video Disc. Letter Box: Widescreen format;a TV aspect ratio setting (4:3). Displays the video in full-width, with black bars

at the top and bottom of the TV screen.This format is similar to seeing a movie in a theater. If the Disc does not include a letter box format,selecting letter box may have no effect.Some DVDs are two-sided,with one side playing in widescreen format and the other side playing in a normal (pan & scan) format.

Optical Jack: Converts electrical signals into optical signals before sending the audio to the Stereo.Optical audio is not prone to external electrical influences and has less noise.Keep the protective cap on the jack when it is not in use;this keeps dust out of the jack.

Pan & Scan: A TV aspect ratio setting (4:3).Displays the video with full-height picture with one or both sides of the picture trimmed to fit on your TV screen. Some movie companies refer to this as “reformatting the picture to fit your TV screen.”

PBC: Playback Control.A special feature on some Video CDs/Super Video CDs that enables interactive use. PCM: Pulse Code Modulation. A digital audio encoding system. RGB: Red-Green-Blue.A top-quality video connection where red,green, and blue components of the picture

are carried through separate wires.This also is referred to as the component video connection. S-Video: Produces a clear picture by sending separate signals for the luminance and the color. Title: A unit of recording on a DVD. VCD: Video Compact Disc. VIDEO OUT Jack: Yellow jack on the rear of the DVD Player that sends video (picture) to a TV.

Widescreen: A TV aspect ratio setting (16:9). Displays the video appropriately when you connect the DVD Player to a widescreen TV.

48 Glossar y

Page 49

Specifications, Language Codes 49

PLAYABLE DISCS

DVD-Video Audio CD Video CD Super Video CD Picture CD MP3-CD CD Recordable (CD-R) CD Rewritable (CD-RW) DVD Recordable (DVD+R) DVD Rewritable (DVD+RW)

TV STANDARD PAL/50Hz NTSC/60Hz

Number of lines 625 525 Playback Multistandard (PAL/NTSC)

VIDEO PERFORMANCE

VIDEO OUT 1Vpp---75Ω S-VIDEO OUT Y:1.00Vpp---75Ω

C:0.30Vpp---75Ω

Y Pb Pr Y:1.00Vpp---75Ω

Pb:0.7Vpp---75Ω Pr: 0.7Vpp---75Ω

CABINET

Dimensions (w x h x d): 17.1 x 1.7 x 11.8 inches Weight: Approximately 6.6 lbs.

REAR CONNECTIONS

Component Video Out Cinch (green/blue/red) S-Video Out Mini DIN 4-pins Video Out Cinch (yellow) Audio Out Cinch (white/red) Digital Audio Out One coaxial,one optical

IEC958 for CDDA/LPCM/MPEG1 IEC1937 for MPEG2,Dolby Digital, and DTS

AUDIO FORMAT

Digital Mpeg/ AC-3/ DTS compressed Digital

PCM 16,20, 24 bits

fs,44.1, 48, 96 kHz

MP3(ISO 9660) 24,32, 56, 64, 96, 128,

256 kbps & variable bit rate fs,16, 22.05, 24,32, 44.1, 48kHz

Analog Sound Stereo

AUDIO PERFORMANCE

DA Converter 24 bit Signal to Noise (1kHz) 100dB Dynamic range (1kHz) > 90 dB DVD fs 96 kHz 4 Hz -44 kHz

fs 48 kHz 4 Hz -22 kHz

Super Video CD fs 48 kHz 4 Hz -22 kHz

fs 44.1 kHz 4 Hz -20 kHz

Video CD/Audio CD fs 44.1 kHz 4 Hz -20 kHz

LASER

Type Semiconductor laser GaAIAs Wavelength 650nm (DVD)

780nm (Video CD/Audio CD)

Output power 7mW (DVD)

10mW (Video CD/Audio CD)

Beam divergence 60 degree

Abkhazian . . . . .6566

Afar . . . . . . . . .6565

Afrikaans . . . . . .6570

Albanian . . . . . .8381

Amharic . . . . . .6577

Arabic . . . . . . . .6582

Armenian . . . . .7289

Assamese . . . . .6583

Avestan . . . . . . .6569

Aymara . . . . . . .6589

Azerbaijani . . . .6590

Bashkir . . . . . . .6665

Basque . . . . . . .6985

Belarusian . . . . .6669

Bengali . . . . . . .6678

Bihari . . . . . . . .6672

Bislama . . . . . . .6673

Bokmal,

Norwegian . . . .7866

Bosnian . . . . . . .6683

Breton . . . . . . .6682

Bulgarian . . . . . .6671

Burmese . . . . . .7789

C Castilian,Spanish 6983

Catalan . . . . . . .6765

Chamorro . . . . .6772

Chechen . . . . . .6769

Chewa,Chichewa,

Nyanja . . . . . . .7889

Chinese . . . . . .9072

Chuang,Zhuang 9065 Church Slavic,

Slavonic . . . . . . .6785

Chuvash . . . . . .6786

Cornish . . . . . . .7587

Corsican . . . . . .6779

Croatian . . . . . .7282

Czech . . . . . . . .6783

Danish . . . . . . .6865

Dutch . . . . . . . .7876

Dzongkha . . . . .6890

English . . . . . . .6978

Esperanto . . . . .6979

Estonian . . . . . .6984

Faroese . . . . . . .7079

Fijian . . . . . . . . .7074

Finnish . . . . . . .7073

French . . . . . . .7082

Frisian . . . . . . . .7089

G Gaelic, Scottish Gaelic .7168

Gallegan . . . . . .7176

Georgian . . . . . .7565

German . . . . . .6869

Gikuyu,Kikuyu .7573

Greek . . . . . . . .6976

Guarani . . . . . . .7178

Gujarati . . . . . . .7185

Hausa . . . . . . . .7265

Hebrew . . . . . .7269

Herero . . . . . . .7290

Hindi . . . . . . . . .7273

Hiri Motu . . . . .7279

Hungarian . . . . .7285

Icelandic . . . . . .7383

Ido . . . . . . . . . .7379

Indonesian . . . .7368

Interlingua, International Interlingue7365, 7369

Inuktitut . . . . . .7385

Inupiaq . . . . . . .7375

Irish . . . . . . . . .7165

Italian . . . . . . . .7384

Japanese . . . . . .7465

Javanese . . . . . .7486

Kalaallisut . . . . .7576

Kannada . . . . . .7578

Kashmiri . . . . . .7583

Kazakh . . . . . . .7575

Khmer . . . . . . .7577

Kinyarwanda . . .8287

Kirghiz . . . . . . .7589

Komi . . . . . . . . .7586

Korean . . . . . . .7579

Kuanyama,

Kwanyama . . . .7574

Kurdish . . . . . . .7585

Lao . . . . . . . . . .7679

Latin . . . . . . . . .7665

Latvian . . . . . . .7686

Letzeburgesch . .7666 Limburgan,Limburger,

Limburgish . . . .7673

Lingala . . . . . . . .7678

Lithuanian . . . . .7684

Luxembourgish .7666

Macedonian . . . .7775

Malagasy . . . . . .7771

Malay . . . . . . . .7783

Malayalam . . . . .7776

Maltese . . . . . . .7784

Manx . . . . . . . . .7186

Maori . . . . . . . .7773

Marathi . . . . . . .7782

Marshallese . . . .7772

Moldavian . . . . .7779

Mongolian . . . . .7778

Nauru . . . . . . . .7865

Navaho,Navajo .7886 Ndebele, North 7868 Ndebele, South .7882

Ndonga . . . . . . .7871

Nepali . . . . . . . .7869

Northern Sami .8369

Norwegian . . . .7879

Nynorsk,

Norwegian . . . .7878

O Occitan,Proven 7967 Old Bulgarian,Old Slavonic,Old Church

Slavonic . . . . . . .6785

Oriya . . . . . . . .7982

Oromo . . . . . . .7977

Ossetian,Ossetic7983

Pali . . . . . . . . . .8073

Panjabi . . . . . . .8065

Persian . . . . . . .7065

Polish . . . . . . . .8076

Portuguese . . . .8084

Provencal . . . . .7967

Pushto . . . . . . .8083

Quechua . . . . . .8185

R Raeto-Romance 8277

Romanian . . . . .8279

Rundi . . . . . . . .8278

Russian . . . . . . .8285

Samoan . . . . . . .8377

Sango . . . . . . . .8371

Sanskrit . . . . . . .8365

Sardinian . . . . . .8367

Serbian . . . . . . .8382

Shona . . . . . . . .8378

Sindhi . . . . . . . .8368

Sinhalese . . . . . .8373

Slovak . . . . . . . .8375

Slovenian . . . . . .8376

Somali . . . . . . . .8379

Sotho,Southern 8384

Sundanese . . . . .8385

Swahili . . . . . . .8387

Swati . . . . . . . . .8383

Swedish . . . . . . .8386

Tagalog . . . . . . .8476

Tahitian . . . . . . .8489

Tajik . . . . . . . . .8471

Tamil . . . . . . . . .8465

Tatar . . . . . . . . .8484

Telugu . . . . . . . .8469

Thai . . . . . . . . .8472

Tibetan . . . . . . .6679

Tigrinya . . . . . . .8473

Tonga (Tonga Islands) .8479

Tsonga . . . . . . .8483

Tswana . . . . . . .8478

Turkish . . . . . . .8482

Turkmen . . . . . .8475

Twi . . . . . . . . . .8487

Uighur . . . . . . .8571

Ukrainian . . . . .8575

Urdu . . . . . . . . .8582

Uzbek . . . . . . . .8590

Vietnamese . . . .8673

Volapuk . . . . . . .8679

Walloon . . . . . .8765

Welsh . . . . . . . .6789

Wolof . . . . . . . .8779

Xhosa . . . . . . . .8872

Yiddish . . . . . . .8973

Yoruba . . . . . . .8979

Zulu . . . . . . . . .9085

Specifications

Language Codes

You will need these codes if you want a different language for Subtitles,Audio,or Disc menus. Details are on pages 25-27.

Page 50

50 Limited Warranty

Digital Video Disc Player

90 days Free Product Exchange / 91 days–One Year Reduced-Cost Exchange

WHO IS COVERED?

You must have proof of the date of purchase to exchange your product.A sales receipt or other document showing the date that you purchased the product is considered such proof.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product.For 90 days thereafter, you may exchange the defective product for

a free new or renewed product through Philips. From 91 days to one year from the date of purchase , you will pay a preset exchange fee to obtain a new or renewed product. Follow the exchange procedures on the next page.This exchange opportunity ends one year after the date of purchase. The replacement product is covered only for the warranty period of the original product.When the warranty on the original product expires,the warranty on all replaced products also expires.

When it is necessary for you to ship the product to Philips for exchange, you will pay the shipping costs for shipment to Philips. Philips will pay the shipping costs when returning a product to you.

WHAT IS EXCLUDED?

Your warranty does not cover:

• shipping charges to return defective product.

• labor charges for installation or setup of the product, adjustment of customer controls on the product,and installation or repair of antenna systems outside of the product.

• product repair and/or part replacement because of improper installation,abuse, neglect, misuse, accident, unauthorized repair or other cause not within the control of Philips.

• a product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed,manufactured,approved and/or authorized,or repair of products damaged by these modifications.

• incidental or consequential damages resulting from the product.(Some states do not allow the exclusion of incidental or consequential damages,so the above exclusion may not apply to you.This includes, but is not limited to,prerecorded material,whether copyrighted or not copyrighted.)

• a product used for commercial or institutional purposes (including but not limited to rental purposes).

WHERE IS EXCHANGE AVAILABLE?

Warranty exchange is available in all countries where the product is officially distributed by Philips.In countries where Philips does not distribute the product,the local Philips service organization will attempt to exchange the product, although there may be a delay if the appropriate product is not readily available.

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of date of purchase. Attach it to the owner’s manual and keep both nearby. Also keep the original box and packing material in case you need to return your product.

BEFORE EXCHANGING THE PRODUCT...

Please check your owner’s manual before exchanging the product. Adjustments of the controls discussed there may save you time and money.

LIMITATION OF LIABILITY AND REMEDY...

PHILIPS IS NOT LIABLE UNDER ANY CIRCUMSTANCES FOR ANY DIRECT,INDIRECT,SPECIAL, INCIDENTAL,OR CONSEQUENTIAL DAMAGES, HOWSOEVER INCURRED, EVEN IF NOTIFIED OF THE POSSIBILITY OF SUCH DAMAGES. TO THE EXTENT PERMITTED BY LOCAL LAW,THE REMEDIES PROVIDED IN THIS WARRANTY STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDY. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE/PROVINCE TO STATE/PROVINCE.

TO EXCHANGE YOUR PRODUCT IN THE U.S.A., PUERTO RICO, OR U.S. VIRGIN ISLANDS...

FOLLOW THE INSTRUCTIONS STATED PREVIOUSLY IN THE “WHAT IS COVERED” SECTION,OR REFER TO THE EXCHANGE INSTRUCTIONS ON THE NEXT PAGE. IN THE U.S.A.,PUERTO RICO, AND U.S. VIRGIN ISLANDS, ALL IMPLIED WARRANTIES,INCLUDING THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,ARE SPECIFICALLY DISCLAIMED, AND TO THE EXTENT INCONSISTENT WITH LAW OF THE LOCALITY OF THE USER,LIMITED IN DURATION TO THE DURATION OF THIS EXPRESS WARRANTY. BECAUSE SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY MAY LAST,THIS LIMITATION MAY NOT APPLY TO YOU.

TO EXCHANGE A PRODUCT IN CANADA...

Please contact Philips at:

1-800-661-6162 (French Speaking)

1-800-531-0039 (English or Spanish Speaking) In Canada,this warranty is given in lieu of all other warranties. There are no other warranties,express or implied, including any implied warranties of merchantability or fitness for a particular purpose.

REMEMBER...

Please record below the model and serial numbers found on the product. Also, please fill out and mail your warranty registration card promptly.It will be easier for us to notify you if necessary. MODEL #__________________________________ SERIAL #__________________________________

Philips, P.O. Box 520890, Miami, FL 33152 (402) 536-4171

EL6490E003 /11-02

Page 51

Limited Warranty (cont’d) 51

To exchange your product with Philips (per the warranty conditions stated previously),remember:

• If you exchange the product within 90 days of the original purchase,there is no cost to you.*

• If you exchange the product more than 90 days after but less than one year after the day of original purchase,contact Philips at 1-800-531-0039 to determine the preset cost for exchange.

• If you do not have your original sales receipt,or if you have any questions,call Philips at 1-800-531-0039.

To obtain a replacement product from Philips:

1. Contact Philips at 1-800-531-0039 to determine the cost for exchange.

2. Complete the Exchange Form below.

3. Pack the product and its accessories in the original box or a suitable alternative.You will receive replacement accessories

with your replacement product. For packing details,call Philips at 1-800-531-0039.

4. Put the completed Exchange Form,a copy of the original sales receipt,and the proper payment amount into an envelope. DO NOTSEND CASH. Do not staple or clip these items together.Label the envelope “Return Documents Enclosed.” Place this envelope in the box with the product.

5. Seal the box with packing tape and return the product via United Parcel Service (UPS), insured and freight prepaid,to the address provided by Philips. For details call 1-800-531-0039.A replacement will be sent to you via UPS within 48 business hours of Philips’ receipt of the product.

*When it is necessary for you to ship the product to Philips for exchange, you will pay the shipping costs for shipment to Philips. Philips will pay the shipping costs when returning a product to you.

EXCHANGE INSTRUCTIONS

EXCHANGE FORM

Your Address (street address to which replacement should be delivered, no P.O. boxes allowed):

Name: Street Address: Apt.#: City: State/Province: Zip Code/Postal Code: Phone (day): Phone (night):

Exchange Fee: + Sales Tax: = Total:

Method of Payment: (Check one. Please , no cash or CODs.)

_____ Check/Money order Check/Money order No.

Account number Expiration date _____ American Express ___________________________ __________ _____ Visa ___________________________ __________ _____ Novus/Discover ___________________________ __________ _____ Mastercard ___________________________ __________

Signature: _____________________________________________________________________________________ Detailed reason for return,use additional paper if necessary:_____________________________________________ _______________________________________________________________________________________________

Model Number Serial Number

Remember, the return box should include the following:

• The product,

• Completed Exchange Form and sales receipt,

• Accessories supplied with the product, and

• Payment, if applicable.

Page 52

Printed in China

IB8419E002

3141 015 24721

This owner’s manual is made of recyclable materials.Remember to recycle!

AC power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

ALL (Digital output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Analog audio setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39, 41

ANGLE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 23

Arrow 341 2 buttons . . . . . . . . . . . . . . . . . . . . . . . . .17, 20-21

AUDIO button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17,25

AUDIO OUT (left/right) jacks . . . . . . . . . . . . . . . . . . .10-14, 19

Battery installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

BRIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Camera angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Chapter selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Cleaning discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

COAXIAL jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15, 19, 40

COLOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-37

Color systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 38

Component Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

CONTRAST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-37

Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Digital Audio Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Digital Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Disc lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

DISC MENU button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 20

Disc menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16, 18

DISPLAY button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17,20, 22

Display dim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Downmix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Dynamic Range Control (D.R.C.) . . . . . . . . . . . . . . . . . . . . . .39

Environmental information . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Exchange instructions/exchange form . . . . . . . . . . . . . . . . .50-51

Fast forward and fast reverse . . . . . . . . . . . . . . . . . . . . . . . . .21

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Frame-by-frame playback . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-15

Component Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Composite or CVBS (yellow) video . . . . . . . . . . . . . . . . . .11

Connecting to a TV and a digital stereo . . . . . . . . . . . . . . .15

Connecting to a TV and a two-channel stereo . . . . . . . . . .14

Determining the best possible connection . . . . . . . . . . . . . .9

Progressive Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13,38

RF Modulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

TV has ANTENNA IN or RF IN jack only . . . . . . . . . . . . .10

JPEG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33-34

Language codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Language settings

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Disc menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Player display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Letter Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50-51

LPCM OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33-34

MP3/JPEG NAV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

MUTE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Next ¢ button . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17, 20-21

NTSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7,38

Number buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 20

OK button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

OPEN/CLOSE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17-18

OPTICAL jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15,19

OSD LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

PAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 38

PanScan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Parental levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Parental password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

PAUSE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 22

PCM only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

PERSONAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-37

Picture setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-37

PLAY button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-18

Playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

POWERyybutton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Preview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PREVIEW button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 20, 32

Previous 4 button . . . . . . . . . . . . . . . . . . . . . . . .16-17, 20-21

Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Progressive Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13,38

Quick disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Reduce . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Region codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Remote control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24, 34

REPEAT button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 24,34

Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

REPEAT A-B button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 24

RETURN button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

3D Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Screen saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

SEARCH button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 22

Slow motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

SOFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Sound mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

STANDARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Standby-On y button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Still picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

STOP button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 18

SUBTITLE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 26

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

S-VIDEO (video out) jack . . . . . . . . . . . . . . . . . . . . . . . . .12, 19

SYSTEM MENU button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Time search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

TINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-37

TITLE button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Title menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Track selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

TV display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

TV type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

VIDEO (video out) jack . . . . . . . . . . . . . . . . . . . . . . . .10, 11, 19

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50-51

Widescreen (16:9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Y Pb Pr (component video out) jacks . . . . . . . . . . . . . .13, 19, 38

Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

ZOOM button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 23

52 Information Index
