Page 1
Philips Fidelio
docking sound system
Wireless sound towers
Bluetooth
DualDock
DTM9030
Obsessed with sound
Be immersed in high-fidelity sound with the Philips Fidelio sound towers. Stream music
wirelessly with Bluetooth® aptX and AAC. Play your CDs or any iPod or iPhone with
Philips DualDock. Get room-filling sound with only two speakers.
Enjoy freedom with Bluetooth® wireless technology
• Floor standing speakers for ideal music reproduction
• Playback music via Bluetooth® wireless technology and aptX®
Enjoy your music from multiple sources
• Play MP3/WMA-CD, CD and CD-RW
• USB Direct for MP3/WMA music playback
• MP3 Link for portable music playback
• DualDock to charge & play iPod/iPhone (Lightning & 30pin)
Enrich your sound experience
• 160W RMS total output power
Design that blends into your interior
• Unique tower design to fit your lifestyleUnique tower design
Page 2
Docking sound system
Bluetooth DualDock
Highlights
DTM9030/10
USB Direct
With the USB Direct mode, simply plug in your
USB device to the USB port on your Philips
device and your digital music will be played
directly from the Philips device.
MP3 Link
The MP3 link connectivity allows direct
playback of MP3 content from portable media
players. Besides the benefit of enjoying your
favorite music in the superior sound quality
delivered by the audio system, the MP3 link is
also extremely convenient as all you have to do
is to plug your portable MP3 player to the
audio system.
DualDock to charge & play
Created to meld sleek styling with Lightning
and 30-pin Apple device connectivity, the
DualDock pops out when needed to reveal
connectors and act as an iPhone/iPod stand.
Floor standing speakers
Fidelio Sound Towers are floor standing
speakers that offer the optimum amount of
acoustic volume for the creation of a rich and
pristine sound. They combine the mid-range
accuracy of a traditional 2-way speaker design
with bass extensions to supportthe low end of
the sonic spectrum, making them ideally tuned
for exquisite music reproduction.
Play MP3/WMA-CD, CD and CD-RW
Audio compression technology allows large
digital music files to be reduced up to 10 times
in size without radically degrading their audio
quality. MP3 or WMA are two of the
compression formats that let you enjoy a
world of digital music on your Philips player.
Download MP3 or WMA songs from
authorized music sites on the Internet or
create your own MP3 or WMA music files by
ripping your audio CDs and transferring them
onto your player.
Playback music via Bluetooth
Playback mobile phone and PC music via
Blue
tooth® wireless technology and aptX®
Page 3
Docking sound system
Bluetooth DualDock
Specifications
DTM9030/10
iPod compatibility
• Compatible with: iPod nano 7th generation, iPod
touch 5th generation, iPod classic, iPod nano 2nd
generation, iPod nano 3rd generation, iPod nano
4th generation, iPod nano 5th generation, iPod
nano 6th generation, iPod touch, iPod touch 2nd
generation, iPod touch 3rd generation, iPod touch
4th generation
iPhone compatibility
• Compatible with: iPhone 5, iPhone 4, iPhone 4S,
iPhone, iPhone 3G, iPhone 3GS
Sound
• Output power (RMS): 2 x 80W (<1% THD)
• Sound enhancement: digital sound control 4 modes
• Volume control: up/down
Loudspeakers
• Main Speaker: Bass Reflex Speaker System, 4"
woofer
• No. of built-in speakers: 6
Audio Playback
• Playback Media: CD, CD-R, CD-RW, MP3-CD,
WMA-CD, USB flash drive
• Disc Playback Modes: Rep
Shuffle Play, 20-Track Programmable, Fast
Forward/Backward, Next/Previous Track Search
•Loader Type: Motorised
• ID3-tag support
• USB Direct Modes: Fast Backward/Fast Forward,
Play/Pause, Previou
Shuffle, Stop
• Cradle playback mode: Charging iPhone, Charging
d
iPo
eat/one/all/program,
s/Next, Program Play, Repeat,
Tuner/Reception/Transmission
• Tuner Bands: FM Stereo
• Auto digital tuning
• RDS: Program Type, Station Name, RDS Clock Set
• Station presets: 20
• Antenna: FM antenna
• Tuner Enhancements: Auto Store
Connectivity
• Other connections: FM Antenna
• 3.5mm stereo line in: MP3 Link
• Rear Connections: AUX in, Digital coaxial in,
al optical in
Digit
• Bluetooth profiles: A2DP, AVRCP, aptX
Convenience
• Alarms: CD Alarm, Radio Alarm, Sleep timer, USB
alarm, iPod Alarm
• Clock: On main display, sleep timer
• Display Type: VFD display
• Eco Power Standby: 0.5 watt
• Charging device: iPhone, iPod
• Display type: VFD display
Accessories
• Included accessories: AC Power Cord, FM
antenna, Audio Cable
• Quick start guide: English, German, Dut
Spanish, Italian
•Remote control
• User Manual: 16 languages
ch, French,
Dimensions
• Packaging dimensions (W x H x D):
560 x 1120 x 390 mm
• Gross weight: 30.7 kg
• Net weight: 26.3 kg
• Main unit depth: 300 mm
• Main unit height: 985 mm
• Main unit width: 300 mm
Power
• Power supply: 220-240V, 50Hz
•
Issue date 2013-12-23
Version: 2.1.5
12 NC: 8670 001 06009
EAN: 08 71258 16962 07
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
