DSS350
CMYB
DSS350
Digital Speaker System
Digital Speaker System
Active High Power - 2x15Watt (RMS) - Speaker System
•
Using Philips newest and patented highly efficient Amplifiers (SODA)
Future Proof - Most Versatile Speaker System
•
The speakers allow audio playback using the soundcard under Windows® 3.1/95
and digital audio streaming via USB with Windows® 98
USB - Universal Serial Bus
•
The Sound and Control is transferred in digital format through the USB
HiFi Digital Multimedia Sound
•
True CD Quality Sound (or higher) can be achieved with these USB speakers
Incredible Surround
•
Patented Philips technology which provides unmatched 3D Audio experience
Dynamic Bass Boost
•
Provides rich, smooth bass at any volume level when activated
Hot Plug & Play
•
Under Windows® 98 just plug the speakers into an active USB port, no soundcard required
Graphic User Interface
•
Makes it easy to operate the speakers via the PC and provides extra sound controls
Automatic Standby Control
•
When no audio signal detected than the system goes automatically into standby
Magnetically Shielded
•
In order to prevent harmful distortion to TV/Monitor or other magnetical products
DSS350
ASC
Digital Speaker System
standard product information
Universal Serial Bus
When the Audio CD was introduced by Philips in 1981, the superiority of
digital over analog technology was widely recognized. With USB a
comparable revolution is taking place in multimedia audio. The Sound is
transferred in a digital format through the USB and converted to music at
the most appropriate place: inside the speakers.
HiFi Digital Multimedia Sound
By doing so Signal/Noise ratio can be achieved of 98dB and because the
wave table synthesis is now carried out by the operating system (Windows®
98), future upgrades are possible. This technology ensures high quality digital
sound at sampling rates up to 55kHz. In comparison, Audio CD technology
works at 44kHz.
High Power
In addition this 30-watt speaker system, with an airtight acoustical enclosure
and aerodynamic designed bass ports, guarantees fantastic sound
performance. The highly efficient sound reproduction is achieved through a
new, patented amplifier concept known as SODA (Self Oscillating class D
Amplifier). The SODA concept achieves results that can not be matched by
other amplifier concepts.
Hot Plug & Play
In combination with Windows® 98 the speakers offer true Hot PnP. Just plug
in the speakers, and the sound from the PC will be played. No complicated
installation of drivers and switches is necessar y. Thanks to USB, the sound
card with all its complicated installation procedures will become obsolete.
Most Versatile Speaker System
For customers that do not have Windows® 98 yet, the speakers are
delivered with drivers for Windows® 95, enabling audio playback via the
soundcard and USB control under Windows® 95.
The DSS350/370 are 100% compatible with Windows® 98 taking full
advantage of the digital audio streaming.
The speakers even allow analog playback under Windows® 3.1 (using the
soundcard) which make them the most versatile speaker system in the
market.
Incredible Surround
The patented Philips Incredible Surround provides unmatched 3D sound
experience. By using special algorithms phantom images are created of
sound sources outside the area of the speakers. Especially in multimedia
setups where the speakers are positioned close to the listener, this feature
has a great effect.
Dynamic Bass Boost
This feature enhances the bass performance of the speakers in order to give
you that smooth and warm bass for music and that extra punchy or
booming bass with games and sound effect
Graphic User Interface
Although the speakers can be controlled via the standard applets of
Windows® or via the soundcard, they are provided with a Graphic User
Interface as well to allow easier control of the speakers and offer additional
controls such as: Bass, Treble, Balance and Mute
Digital Speaker System
DSS350
System
• Power Supply : AC-DC adapter included
• Amplifier : Self Oscillating class D Amplifier (SODA)
: 30 Watts RMS (2 x 15 W)
: 360 Watts PMPO
• Drivers : 2” tweeter
: 4” woofer
• Frequency Range : 60-20.000Hz
Features - Sound
• Two Way Bass Reflex System
• Incredible Surround
• Dynamic Bass Boost
• Aerodynamic Bass Port
Features - System
• USB DAC
• Magnetically Shielded
• Automatic Standby Control
Controls on Speaker
• Volume Control Up/Down
• Incredible Surround On/Off
• Dynamic Bass Boost On/Off
• Power On/Off
Controls via Graphic User Interface
• Volume Up/Down
• Treble Up/Down
• Bass Up/Down
• Balance Left/Right
• Dynamic Bass Boost On/Off
• Mute On/Off
In/Outputs
• Power : Mains + Adapter
• USB Input : Fixed cable
• Analog Input : 3.5 mm jack
• Subwoofer Out : 2.5 mm jack
• Speaker Out : 3.5 mm jack
• Headphone Out : 3.5 mm jack
Size/Weight
• Speaker (hxwxd) : 270 x 140 x 187mm
• Weight of Speaker : 3.9kg
System Requirements
• Analog Input : Soundcard (controls only via signal)
• Analog Input + USB Control : USB port, Soundcard, Windows® 95 OSR2.1 version
• Full USB Streaming : USB port, Windows® 98
Europe/Eastern Europe
North America
UPC : 037849871706
Printed in Singapore
Specifications subject to change without notice.
® Windows is a registered trademark of the Microsoft Corporation
