Philips
HomeDock HD
For iPod
DLA99901
Experience your iPod on TV
with high-definition performance
Enjoy your iPod like never before - on your HDTV! Sit back and easily navigate iPod music
and videos on your TV with the included remote. Upscale digital video up to 1080i via
HDMI to your high-definition TV for the ultimate iPod experience
Enjoy iPod on TV
• iPod dock with high-definition performance
• Upscales digital video up to 1080i via HDMI
• Intuitive user interface for easy iPod navigation
• Multiple connection options
Remote control included
• RF technology to control music playback from afar
Complete power solution
• Secure and convenient charging dock for iPod
• Multi-national plugs included
Page 2
DLA99901/30
HomeDock HD
For iPod
Specifications
iPod compatibility
• Compatible with: iPod with docking connector
Accessories
• Audio/Video cable: RCA Cable included
• Quick start guide
• Remote control: Full-function RF
• User Manual: CD-ROM
Connectivity
• Audio Output - Analog: 2x Audio L/R (red/white
cinch)
• Audio Output - Digital: HDMI, Optical (TOSLINK)
• Aux in: Audio (3.5mm stereo mini jack)
• Docking connector: iPod 30-pin
•USB
• Video Output - Analog: Co
video
• Video Output - Digital: HDMI
mposite video out, S-
Outer Carton
• Gross weight: 13.61 kg
• GTIN: 1 06 09585 16992 7
•Outer carton (L x W x H):
.23 x 56.52 x 33.66 cm
62
• Nett weight: 0.66 kg
• Number of consumer packagings: 2
• Tare weight: 12.95 kg
Packaging dimensions
• Packaging dimensions (W x H x D):
13.97 x 23.5 x 6.35 cm
• Gross weight: 0.34 kg
• Nett weight: 0.33 kg
• Number of products included: 1
• Packaging type: Blister
• Tare weight: 0.01 kg
• UPC: 6 09585 16992 0
•
Highlights
High-definition iPod dock
The iPod dock features high-definition menus and
HDMI connectivity so you can easily connect your
iPod to your HDTV. This allows you to navigate and
view your iPod music and videos in unbelievable
quality.
Intuitive user interface
The user interface graphically represents the
categories of content on your docked iPod so you
can intuitively navigate your iPod music, videos and
more on your TV screen. For the most complete
iPod experience on TV, the interface includes
existing iPod Album Art.
Multiple connection options
Whether you have a high-definition TV and home
stereo system, or a standard TV, there are plenty of
connection options available to enjoy your docked
iPod. Featuring HDMI, S-Video, Composite Video,
Digital Audio and RCA Audio for multiple
connectivity configurations.
Upscales video via HDMI
HDMI is a direct digital connection that carries
digital high definition resolution video as well as
digital audio. The connection allows for transmission
from a source device to a TV without the loss of
image quality. With video upscaling, the resolution of
standard definition video signals can be increased to
resolutions up to 1080i. This results in a sharper,
more true-to-life picture.
Issue date 2017-04-04
Version: 1.0.1
12 NC: 8670 000 52312
UPC: 6 09585 16992 0
© 2017 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
