Page 1
Smart lever door
lock
7000 series
The elaborate f ree handle
Sliding cover design
Lift up the lever to lock
Safehandle function
DDL172LKAS0
Stable and lasting performance
Good life is always safeguarded
Adopted with an OLED display, Philips 7200 allows an easier and more intuitive operation. A sliding cover to
protect the fingerprint sensor area and the keypad area,
Craftsmanship ensures high quality
More protection for home security
Prevent mortise from violently opening
Easy installation with high adaptability
Prevent damage from dust and the sun
Upgraded smart chip enhances home security
One button to prevent safety risks while away
Verification portfolio provides double security
Protect real password from being peeping
Easy life doesn't stop here
Say goobye to key-only era
Slightly touch to unlock
Page 2
Smart lever door lock
DDL172LKAS0/97
Highlights Specifications
32-digit hidden PIN code
Featured with the 32-digit hidden PIN code
technology, Philips 7200 allows you to enter
any random number combination for
verification and unlock the door as long as
there is a consecutive input of the valid
password. This feature can effectively prevent
peeping and safeguard the real password.
Dual verfication
In the dual verification mode, you could open
the door with any two verification methods via
fingerprint, PIN code, and key tag, which
provides double protection for home security.
Mechanical key opening alert
Phili ps 7200 smart lever door lock is equipped
with a smart alert function. When someone
opens the lock through the mechanical
keyhole, the lock will give an alert, which can
effectively prevent violent damage and
technical lock picking.
Safehandle switch
Once the safehandle function is enabled, the
indoor handle would be locked up, which
allows nobody to open the door by pressing
down the inside handle. This can effectively
prevent the suspicious unlocking from the
inside through the door viewer, children, or
pets from unlocking the door accidentally by
pressing down the indoor handle, thus
reducing security risks for the family.
Semiconductor fingerprinting
Phili ps 7200 employs a semiconductor
fingerprint sensor, which could verify the
identification by human skin temperature,
capacitance value, etc. Fingerprints can not be
duplicated or copied. When you touch the
fingerprint sensor area sli ghtly, after the
successful verification, you can directly press
down the handle to unlock the door in one
step, which gives you a convenient door
opening experience.
Sliding cover design
The sli ding cover design of the Philips 7200
can protect the fingerprint recognition area and
the keypad area from damage caused by wind,
rain, direct sunlight, or artificial scratches, and
it is also dust-proof. Thanks to the sliding
cover, the fingerprint recognition area, and the
keypad area could be more rugged and
durable.
Support concealed rods
Phili ps 7200 smart lever door locks can be
installed on a variety of materials and types of
doors, such as wooden doors, copper doors,
iron doors, security doors, etc., and i t is also
suitable for doors equipped with concealed
multi-point lock rods. You can directly remove
the old lock and install the smart lock to open
up a smart life.
The elaborate free handle
The handle is left in a free state after locking,
through lift and lower the handle, the mortise
would no longer being touched, which can
prevent the mortise from violently opening.
Various ways of unlocking
There are four methods like fingerprint, PIN
code, key tag, and mechanical key to unlock
the door lock. Multiple choices to meet different
user needs in the family.
Access Solution
Card/Key Tag
Fingerprint
Password/PIN Code
Design & Appearance
Color: Pearl silver
Display: OLED display
Fingerprint Sensor: Semiconductor
Handle: Lever handle
Easy Operation
Voice Guide: Human voice guide
Installation
Door Opening D irecti on: Left inward opening,
Left outward opening, Right inward opening,
Right outward oepning
Door Thickness: 38-60 mm, 60-90 mm, 90-
120 mm, Other range*
Door Type: Antitheft door, Wooden door
Lock Capacity
Card/Key Tag: Up to 100
Master PIN Code: 1
Power Specification
Battery Type: Alkali ne Batteries
Emergency Power Supply: 5V power bank
Maximum Batteries Capacity: 8 batteries
Power Supply: 4 AA batteries
Time of Use: 8 months*
Working Voltage: 4.5-6V
© 20 21 Koninklijke Philips N.V.
All Right s reserved.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips N.V. or
their respective owners.
Issue date 2021‑ 06‑13
Version: 2.2 .1
12 NC: 8670 001 60782
EAN: 69 71318 500 56 5
www.phili ps.com
