Philips DCP850-07B User Manual

Docking Entertainment System DVD Portable with dock for iPod

User manual

Manuel d'utilisation

Manual del usuario

Gebruikershandleiding

DCP750/850

Meet Philips at the Internet

http://www.philips.com

Printed in China WK701

CLASS 1

LASER PRODUCT

DCP750/850

3 4 6 75

(

@ # %^ & *$

3 2

iPod

4 5

7 0

(

^ %

DISPOSAL OF YOUR OLD PRODUCT

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

Please inform yourself about the local separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with your normal household waste. The correct disposal of your old product will help prevent potential negative consequences for the environment and human health.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reserve engineering or disassembly is prohibited.

English

FUNCTIONAL OVERVIEW

Main unit controls ( see figure 1)

1 OPEN .....................Open the disc door to insert or remove disc.

2 MENU.....................Display the MENU page.

3 MONITOR..............Switch the aspect ratio between 16:9 or 4:3.

4 SOURCE... ..............Select respective sources: DISC, iPod, SD/MMC or AV.

5 J( / § ..................Skip to the previous/next chapter, track or title.

6 3, 4, 1, 2 ...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

;

.........................Start or interrupt playback.

.........................Confirm a selection.

7 ..........Push in to connect with a well placed iPod player or pull

out to disconnect it.

8 DOCK for iPod... ...Place an iPod player.

9 IR.............................Remote sensor.

Front of player ( see figure 1)

0 POWER ON/OFF... Switch the power on/off. ! POWER and CHG...Power and charge indicators.

Left of player ( see figure 1)

@ ....................Power supply socket.

# ... ...........Finetune the TFT screen brightness.

FUNCTIONAL OVERVIEW

$ ...............Headphone jacks.

% AV OUT... ...............Audio/Video output jack.

^ AV IN... ...................Audio/Video input jack.

& SD/MMC CARD....Insert an SD/MMC card.

* ...................Volume control.

Right of player ( see figure 1)

( 2

/ EJECT ..................Lift up this handle to eject the iPod player with video.

Remote controls ( see figure 2)

1 Source keys ........Select respective sources: DISC, iPod (iPod with video),

SD/MMC CARD or AV.

2 REPEAT ..................Repeat a chapter/track/title.

3 A-B... ......................Repeat playback of a specific section on a disc.

4 SHUFFLE ................Play a disc randomly.

5 PROG ......................Enter the program menu.

6 9 .............................Stop playback or erase a program.

7 2

;

...........................Start or interrupt playback.

8 DISC MENU ..........Enter or exit the disc contents menu.

REMOTE CONTROL

9 SETUP ....................Enter or exit the system menu.

0 3, 4, 1, 2 ...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

! OK ...........................Confirm a selection.

@ J( / § ...................Skip to the previous/next chapter, track or title.

# Numeric Keypad (0-9)...Input numbers.

$ ZOOM .....................Enlarge or reduce a picture or active image on the TFT.

% MONITOR ..............Switch the aspect ratio between 16:9 or 4:3.

^ DISPLAY ................Display information on TFT during playback.

& TITLE/RETURN ......Display the disc title or return to the previous level of the

VCD disc menu.

* SUBTITLE ..............Select a subtitle language.

( AUDIO ....................Select an audio language when playing a DVD disc or

select an audio mode (Stereo, Mono-Left or Mono-Right) when playing a VCD/CD disc.

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

INTRODUCTION

Your portable DVD player

Your portable DVD player plays digital video discs conforming to the universal DVD Video standard. With it, you will be able to enjoy full-length movies with true cinema picture quality, and stereo or multichannel sound (depending on the disc and on your playback set-up).

The unique features of DVD-Video, such as selection of soundtrack and subtitle languages, and of different camera angles (again depending on the disc), are all included.

What’s more, parental lock lets you decide which discs your children will be able to see. You will find your player remarkably easy to use with the On-Screen Display and player display in combination with the remote control.

Unpacking

First check and identify the contents of your package, as listed below:

• Portable DVD player • Remote Control

• Car adaptor (12V) • AC power adaptor

• Audio / Video cable • User Manual

• Warranty • Quick Start Guide

Placement

• Place the player on a firm, flat surface.

• Keep away from domestic heating equipment and direct sunlight.

• If the player cannot read CDs/DVDs correctly, try using a commonly available cleaning CD/DVD to clean the lens before taking the player to be repaired. Other cleaning methods may destroy the lens.

• Always keep the disc door closed to avoid dust on the lens.

• The lens may cloud over when the player is suddenly moved from cold to warm surroundings. It is then not possible to play a CD/DVD. Leave the player in a warm environment until the moisture evaporates.

INTRODUCTION

About Built-in Rechargeable Battery

Precautions related to battery recharge 1 Once the battery is fully discharged (the power indicator will flash as a prior

warning), immediately recharge it (regardless of whether you plan to use the battery or not) in order to maximize the battery life.

2 To charge the battery, please directly connect this DVD player to AC mains

and the charge indicator will turn on.

Using and maintaining your rechargeable batteries 1 Please make sure you always use only the AC adapter included with the

player to recharge your batteries.

2 Recharge efficiency will degrade when the environmental temperature drops

3 The lasting time of the fully charged battery when a headphone is connected

F (10oC) or exceed 95oF (35oC).

below 50

to the DVD player is approximately 2.5 hours.

Playable disc formats

In addition to DVD-Video disc, you will also be able to play all Video CDs and audio CDs (including CDR, CDRW,DVD

±R and DVD±RW).

DVD-Video

Depending on the material on the disc (a movie, video clips, a drama series, etc.) these discs may have one or more Titles, and each Title may have one or more Chapters. To make access easy and convenient, your player lets you move between Titles, and also between Chapters.

CD with JPEG files

You can also view JPEG still photos on this player.

INTRODUCTION

Video CD

Depending on the material on the disc (a movie, video clips, a drama series, etc.) these discs may have one or more Tracks, and tracks may have one or more indexes, as indicated on the disc case.To make access easy and convenient, your player lets you move between tracks and between indexes.

Audio CD / MP3 CD

Audio CDs / MP3-CD contain music tracks only. You can play them in the conventional way through a stereo system using the keys on the remote control and/or main unit, or via the TV using the On Screen Display (OSD).

About DivX

DivX is a popular media technology created by DivX, Inc. DivX media files contain highly compressed video with high visual quality that maintains a relatively samll file size. DivX files can also include advanced media features like menus, subtitles, and alternate audio tracks. Many DivX media files are available for download online, and you can create your own using your personal content and easy-to-use tools from www.DivX.com.

Zero Bright Dot

Enjoy highest-quality images that are free from annoying blank spots on the LCD screen. LCD displays commonly have imperfections, termed as 'bright dots' by the LCD industry. A limited number of bright dots were once considered an inevitable side effect of LCD mass production. With Philips' strict quality control procedures used in our Portable DVD Players, our LCD displays are produced with zero tolerance for bright dots. Select Portable DVD Players come with Philips Zero Bright DotTMPolicy to guarantee optimal screen quality. Warranty service varies from region to region. Contact your local Philips representative for more detailed information.

About SD Memory Card

SD Memory Card is a slim and compact bridge media linking various kinds of digital equipment through its easy connectivity. The card's control circuitry allows data to be read and written (in its protection area) only when appropriate external devices are detected. Using decoder software, an SD Memory Card-compatible device can play music, video clips and more without a drive mechanism like those in CD and DVD players.
