DA1103
DA1103Portable DAB Radio
Register your product and get support at
www.philips.com/welcome
User manual
CAUTION
Use of controls or adjustments or performance of procedures other than herein
may result in unsafe operation.
The type plate is located on the rear of the set
2
.
DAB RADIO DA1103
1
2
4
36
7 5
8
9
1
3
2 x AAA
1
2
3
Pull open the
protective
cover
Align the
latches with
the slots
1
2
3
Pull open the
protective
cover
Align the
latches with
the slots
2
3
4
4
Contents
Controls ––––––––––––––––––––––––––––––––––––––––––––––––––––– 6
General Information
Safety instructions ––––––––––––––––––––––––––––––––––––––––––– 7
Environmental information –––––––––––––––––––––––––––––––––––– 7
Hearing safety ––––––––––––––––––––––––––––––––––––––––––––– 7-8
About Digital Audio Broadcasting (DAB) ––––––––––––––––––––––––––9
Getting started
Power supply –––––––––––––––––––––––––––––––––––––––––––––– 10
Changing the back cover ––––––––––––––––––––––––––––––––––––– 10
Transfer –––––––––––––––––––––––––––––––––––––––––––––––––– 10
Headphones ––––––––––––––––––––––––––––––––––––––––––––––– 11
Adjusting the volume –––––––––––––––––––––––––––––––––––––––– 11
HOLD: Locking buttons–––––––––––––––––––––––––––––––––––––––11
DAB radio
Radio reception –––––––––––––––––––––––––––––––––––––––––––– 12
Switching off, Tuning/retuning ––––––––––––––––––––––––––––––––– 13
Selecting a station –––––––––––––––––––––––––––––––––––––––––– 14
Saving & recalling presets ––––––––––––––––––––––––––––––––––––– 14
Deleting a preset–––––––––––––––––––––––––––––––––––––––––––– 15
Viewing the service info (DAB only) –––––––––––––––––––––––––––– 15
Music mode
Playing stored music ––––––––––––––––––––––––––––––––––––––––– 16
Setting play mode ––––––––––––––––––––––––––––––––––––––––––– 16
Recordings
Make recordings –––––––––––––––––––––––––––––––––––––––––––– 17
Play back recordings –––––––––––––––––––––––––––––––––––––––– 17
Upload recordings to PC ––––––––––––––––––––––––––––––––––––– 17
Delete recordings –––––––––––––––––––––––––––––––––––––––––– 17
Settings ––––––––––––––––––––––––––––––––––––––––––––––––––––– 18
Technical Specifications –––––––––––––––––––––––––––––––––––– 19
Tr oubleshooting –––––––––––––––––––––––––––––––––––––––––––– 20
English
5
Controls (see Figure 1)
p
1
English
– 3.5mm headphone socket.
2
Display
– shows menu, options, tack information
and station information.
3 REC/SCAN
– searches and stores DAB stations (Local
Scan/Full Scan/Manu Tune).
– press and hold to record voices in record-
ing mode.
4 1/2/3/4
– navigation controls (left, right, up,down)
for scrolling through the option lists.
1/2
– scrolls radio stations.
3/4
– increases / decreases the volume.
2;
/B
– confirms selection.
– starts playback.
– press and hold to switch on/off the set.
This set complies with the radio interference requirements of the European Union.
PHILIPS reserves the right to make design and specification changes for product
improvement without prior notice.
5 INFO (for DAB only)
– displays station information in seven types.
6 MENU/
– enters the main menu or returns to
previous menu.
– enables access to advanced setup
options.
– press and hold to set lock function on/off.
7 PRESET
– saves 20 stations for quick access.
8 MIC
– Microphone.
9
– USB jack.
Supplied accessories
1 x USB cable
2 x AAA batteries
1 x headphones (Model No.: MH-837F8-2)
2 x changeable back cover (red/blue)
6
General information
Safety instructions (see Figure 4)
•
Do not expose the unit or batteries to humidity, rain, sand or excessive heat (caused
by heating equipment or direct sunlight).
• You can clean the radio with a soft, slightly dampened, lint-free cloth. Do not use any
cleaning agents as they may have a corrosive effect.
• Active mobile phones in the vicinity of the radio may cause malfunctions.
• Avoid dropping the radio as this may cause damage.
• Apparatus shall not be exposed to dripping or splashing.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
Environmental information
All redundant packing material has been omitted.We have done our utmost to make
•
the packaging easily separable into two mono materials: cardboard and polyethylene.
• Your set consists of materials which can be recycled if disassembled by a specialized
company. Please observe the local regulations regarding the disposal of packingmaterials,
exhausted batteries and old equipment.
Hearing Safety
Listen at a moderate volume:
• Using headphones at a high volume can impair your hearing. This product can produce
sounds in decibel ranges that may cause hearing loss for a normal person, even for
exposure less than a minute. The higher decibel ranges are offered for those that may
have already experienced some hearing loss.
• Sound can be deceiving. Over time your hearing “comfort level” adapts to higher vol-
umes of sound. So after prolonged listening, what sounds “normal” can actually be loud
and harmful to your hearing. To guard against this, set your volume to a safe level
before your hearing adapts and leave it there.
English
7
