PHILIPS D6001B, D6052B, D6051B User Manual

Always there to help you

Question?

Contact

Philips

www.philips.com/support

D600 D605

Extended user documentation

Contents

1 Important safety instructions 3

8 Text and numbers 19

Enter text and numbers 19 Switch between uppercase and

lowercase 19

2 Your phone 5

What is in the box 5 Overview of the phone 6 Overview of the base station 7

3 Main menu icons 8

4 Display icons 9

5 Get started 10

Connect the base station 10 Insert the supplied batteries 11

Congure your phone (country

dependent) 11

Change the remote access PIN code 12 Charge the handset 12 Check the battery level 12

What is standby mode? 13

Check the signal strength 13

6 Calls 14

Make a call 14 Answer a call 14 End a call 15 Adjust the earpiece/speaker volume 15 Mute the microphone 15 Turn the speaker on or off 15 Make a second call 15 Answer a second call 15 Switch between two calls 15 Make a conference call with the

external callers 15

7 Intercom and conference calls 17

Make a call to another handset 17 Transfer a call 17 Make a conference call 17

9 Phonebook 20

View the phonebook 20 Search a record 20 Call from the phonebook 20 Access the phonebook during a call 20 Add a record 20 Edit a record 21 Set the personalized melody 21 Set the speed dial keys 21 Delete a record 21 Delete all records 21 Add a contact to the exception list 22

10 Call log 23

Call list type 23 View the call records 23 Save a call record to the phonebook 23 Return a call 23 Delete a call record 24 Delete all call records 24

11 Redial list 25

View the redial records 25 Save a redial record to the phonebook 25 Redial a call 25 Delete a redial record 25 Delete all redial records 25

12 Phone settings 26

Sound settings 26 Set the date and time 27 ECO mode 27 ECO+ mode 28 Name the handset 28 Set the display language 28 Display settings 29

13 Alarm clock 30

1EN

Set the alarm 30 Turn off the alarm 30

14 Baby monitor 31

Activate/Deactivate the baby unit 31 Send an alert 31

Set the baby cry level 32

15 Telephone answering machine 33

Turn the answering machine on or off 33 Set the answering machine language 33

Set the answer mode 33 Announcements 33

Incoming messages 34

16 Services 38

Auto conference 38

Call barring 38

Call list type 38

Auto prex 39 Network type 39

Select the recall duration 39 Dial mode 39

First ring 40

Auto clock 40

Call services 41

Restore default settings 42

21 Index 50

17 Technical data 43

18 Notice 44

Declaration of conformity 44

Use GAP standard compliance 44

Compliance with EMF 44 Disposal of your old product and

batteries 44

19 Frequently asked questions 46

20 Appendix 48

Text and number input tables 48

2 EN

1 Important safety

instructions

Power requirements

• This product requires an electrical supply of 100-240 volts AC. In case of power failure, the communication can be lost.

• The voltage on the network is classied as TNV-3 (Telecommunication Network Voltages), as dened in the standard EN

60950.

Warning

• The Electrical network is classied as hazardous. The

only way to power down the charger is to unplug the power supply from the electrical outlet. Ensure that the electrical outlet is always easily accessible.

• Do not open the handset, base station or charger as

you could be exposed to high voltages.

• For pluggable equipment, the socket-outlet shall

be installed near the equipment and shall be easily

accessible.

• Handsfree activation could suddenly increase the

volume in the earpiece to a very high level: make sure the handset is not too close to your ear.

• This equipment is not designed to make emergency

calls when the power fails. An alternative has to be made available to allow emergency calls.

• Do not allow the product to come into contact with

liquids.

• Do not use any cleaning agents containing alcohol,

ammonia, benzene, or abrasives as these may harm

the set.

• Do not expose the phone to excessive heat caused by

heating equipment or direct sunlight.

• Do not drop your phone or allow objects to fall on

your phone.

• Active mobile phones in the vicinity may cause

interference.

When using the phone as a baby monitor

To avoid damage or malfunction

Caution

• Use only the power supply listed in the user

instructions.

• Use only the batteries listed in the user instructions.

• Risk of explosion if battery is replaced by an incorrect

type.

• Dispose of used batteries according to the instructions.

• Do not dispose of batteries in re.

• Always use the cables provided with the product.

• Do not allow the charging contacts or the battery to

come into contact with metal objects.

• Do not let small metal objects come into contact with

the product. This can deteriorate audio quality and damage the product.

• Metallic objects may be retained if placed near or on

the handset receiver.

• Do not use the product in places where there are

explosive hazards.

Caution

• Children should be supervised to ensure that they do

not play with the appliance.

• Make sure the baby unit and the cord are always out of

reach of the baby (at least 1 metre/3 feet away).

• Keep the parent unit at least 1.5 metres/5 feet away

from the baby unit to prevent acoustic feedback.

• Never place the baby unit inside the baby’s bed or

playpen.

• Never cover the parent unit and the baby unit with

anything (e.g. a towel or blanket). Always make sure the cooling vents of the baby unit are free.

• Take every precaution to make sure that your baby can

sleep safely .

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• If you place the parent unit next to a transmitter or

other DECT appliance (e.g. a DECT telephone or

wireless router for the internet), the connection with

the baby unit may be lost. Move the baby monitor

further away from the other wireless appliances until

the connection is restored.

• This baby monitor is intended as an aid. It is not a

substitute for responsible and proper adult supervision

and should not be used as such.

3EN

About operating and storage temperatures

• Operate in a place where temperature is always between 0°C to +40°C (up to 90% relative humidity).

• Store in a place where temperature is always between -20°C and +45°C (up to 95% relative humidity).

• Battery life may be shorter in low temperature conditions.

4 EN

2 Your phone

Congratulations on your purchase and welcome to Philips! To fully benet from the support that Philips offers, register your product at www.philips. com/welcome.

What is in the box

Base station (D600)

Base station (D605)

Power adapter**

Line cord*

Guarantee

4XLFNVWDUWJXLGH

Short user manual

Note

• * In some countries, you have to connect the line

adapter to the line cord, then plug the line cord to the telephone socket.

• ** In multi-handset packs, there are additional handsets,

chargers and power adapters.

Handset**

Charger**

5EN

Overview of the phone

o n m l

k j i

a Earpiece b

• Scroll up on the menu.

• Increase the earpiece/speaker volume.

• Access the contacts in standby mode.

Move the cursor to the right in editing mode.

• Press to delete individual text or digit.

Press and hold to remove all text.

• Cancel operation.

• Enter the redial list in standby mode.

• Change the sound prole during a call.

• Select the function displayed on the handset screen directly above the key.

b c d e

f g h

• End the call.

• Exit the menu/operation.

• Press to enter a space during text editing.

• Press and hold to lock/unlock the keypad in standby mode.

• Press and hold to enter a pause when editing the contact's name and number.

• Switch to upper/lower case during editing.

Mute or unmute the microphone.

i Microphone j

• Turn the speaker phone on/off.

• Make and receive calls through the speaker.

• Press and hold to make an intercom call (for multi-handset versions only).

• Set the dial mode (pulse mode or temporary tone mode).

• Scroll down on the menu.

• Decrease the earpiece/speaker volume.

• Access the call log in standby mode.

Move the cursor to the left in editing mode.

• Make and receive calls.

• Recall key

• Access the main menu in standby mode.

• Conrm selection.

6 EN

• Enter the options menu.

• Select the function displayed on the handset screen directly above the key.

p Loudspeaker q Battery door

Overview of the base station

D600

• Find handsets.

• Enter the registration mode.

D605

e /

Decrease/increase the speaker volume.

f /

Skip backward/forward during playback.

• Play messages.

• Stop messages playback.

Turn the answering machine on or off.

a Speaker (back of the base station) b

• Find handsets

• Enter the registration mode.

• Delete the current playback message.

• Press and hold to delete all old messages.

d Message counter

a b c d

e f g h

7EN

3 Main menu

icons

The following is an overview of the menu options that are available in your D600/D605.

For detailed explanation of the menu options,

see the corresponding sections in this user manual.

Icon Descriptions

[Phone setup] - Set the date and time, sounds, ECO mode, ECO+ mode phone

name, display language, and display settings.

[Services] - Set the auto conference,

auto prex, network type, recall time, auto clock, call services etc. The services are network and country dependent.

[Alarm] - Set date and time, alarm, alarm

tone etc. [Phonebook] - Add, edit, manage

phonebook entries etc.

[Incoming calls] - Displays the call history of all missed or received calls

(Displays only in D600).

[Baby monitor] - Set the alert to other

handsets and the baby cry level.

[Answer machine] - Setup, listen to,

delete phone messages, etc. (Displays only in D605).

8 EN

4 Display icons

In standby mode, the icons shown on the main screen tell you what features are available on

your handset.

Icon Descriptions

• When the handset is off the base station/charger, the bars indicate the battery level (from full to low).

• When the handset is on the base station/charger, the bars keep scrolling until charging completes.

• The empty battery icon ashes and you hear an alert tone.

• The battery is low and needs recharging.

The number of bars indicates the connection status between the

handset and base station. The more bars are shown, the better the signal strength is.

This icon indicates missed calls on the

standby screen or in the incoming call list. It changes color from red to white after reviewing calls.

The silent mode is set, but is outside

of active period.

• The ringer is off.

• The silent mode is set and within active period (the phone does not ring).

The alarm is activated. Answering machine: it ashes when

there is a new message. It displays when the telephone answering machine is turned on.

• It ashes when there is a new voice message.

• It remains steadily on when the voice messages are already viewed in the call log.

• The icon is not shown when there is no voice message.

ECO The ECO mode is activated. ECO+ The ECO+ mode is activated.

9EN

5 Get started

Caution

• Make sure that you have read the safety instructions in

the 'Important safety instructions' section before you connect and install your handset.

Connect the base station

Warning

• Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on the back or underside of the phone.

• Use only the supplied power adapter to charge the

batteries.

Note

• If you subscribe to the digital subscriber line (DSL)

high speed internet service through your telephone line, ensure you install a DSL lter between the telephone line cord and the power socket. The lter

prevents noise and caller ID problems caused by DSL

interference. For further information on DSL lters, contact your DSL service provider.

• The type plate is located on the bottom of the base

station.

1 Connect each end of the power adapter

to:

• the DC input jack at the back of the

base station;

• the power socket on the wall.

2 Connect each end of the line cord to:

• the telephone socket at the back of

the base station;

• the telephone socket on the wall.

3 Connect each end of the power adapter

to (for multi handset versions only):

• the DC input jack at the bottom of the extra handset charger.

• the power socket on the wall.

10 EN

Insert the supplied batteries

Congure your phone

(country dependent)

Caution

• Risk of explosion! Keep batteries away from heat,

sunshine or re. Never discard batteries in re.

• Use only the supplied batteries.

• Risk of decreased battery life! Never mix different

brands or types of batteries.

Note

• Charge the batteries for 8 hours before rst use.

• If the handset becomes warm when the batteries are

charging, it is normal.

1 When using your phone for the rst time,

you see a welcome message.

2 Press [OK].

Set the country/language

Select your country/language, then press [OK] to conrm.

» The country/language setting is saved.

Note

• The country/language setting option is country

dependent. If no welcome message is displayed, it means the country/language setting is preset for your country. Then you can set the date and time.

To re-set the language, see the following steps.

1 Select [Menu] > > [Language], then

press [OK] to conrm.

2 Select a language, then press [OK] to

conrm.

» The setting is saved.

Set the date and time

1 Select [Menu] > > [Date & time], then

press [OK] to conrm.

2 Select [Set date]/[Set time], then press

[OK] to conrm.

3 Press the numeric buttons to enter the

date and time.

Warning

• Check the battery polarity when inser ting in the

battery compar tment. Incorrect polarity may damage the product.

Note

• If the time is in 12-hour format, press to select [am]

or [pm].

4 Press [OK] to conrm.

11EN

Set the date and time format

1 Select [Menu] > > [Date & time], then

press [OK] to conrm.

2 Select [Date format] or [Time format]. 3 Press / to select [DD-MM-YYYY] or

[MM-DD-YYYY] as the date display, and [12 Hours] or [24 Hours] as the time display. Then press [OK] to conrm.

» The setting is saved.

Note

• The date and time format setting is country dependent.

Change the remote access PIN code

Note

• The default answering machine remote access PIN

code is 0000 and it is important to change it to ensure the security.

• This feature is available only for D605.

a docking tone (see 'Set the docking tone' on page 27).

» The handset starts charging.

Note

• Charge the batteries for 8 hours before rst use.

• If the handset becomes warm when the batteries are

being charged, it is normal.

• Over time, capacity of batteries decreases. This is a

normal battery behavior.

Your phone is now ready to use.

Check the battery level

1 Select [Menu] > > [Remote access] >

[Change PIN], then press [OK] to conrm.

2 Enter the old PIN/passcode, then press

[OK] to conrm.

3 Enter the new PIN/passcode, then press

[OK] to conrm.

4 Enter the new PIN/passcode again, then

press [Save] to conrm.

» The setting is saved.

Charge the handset

Place the handset on the base station to charge the handset. When the handset is

placed correctly on the base station, you hear

12 EN

The battery icon displays the current battery

level.

When the handset is off the base

station/charger, the bars indicate the battery level (from full to low).

When the handset is on the base

station/charger, the bars ash until charging is complete.

The empty battery icon ashes.

The battery is low and needs

recharging.

If you are on the phone, you hear warning tones when the batteries are almost empty.

The handset turns off when the batteries are

completely empty.

What is standby mode?

Your phone is in standby mode when it is idle. When the handset is off the charging cradle, the standby screen displays the date and time. When the handset is on the charging cradle,

the standby screen displays the time as a screen

saver.

Check the signal strength

The number of bars indicates the connection status between

the handset and base station. The

more bars are shown, the better

the connection is.

• Make sure the handset is linked to the base

station before you make or receive calls

and carry out the functions and features.

• If you hear warning tones when you are

on the phone, the handset is almost out

of battery or the handset is out of range. Charge the battery or move the handset closer to the base station.

Note

• When ECO+ is on, the signal strength is not displayed.

13EN

6 Calls

Note

• When the power fails, the phone cannot access

emergency services.

Tip

• Check the signal strength before you make a call or

when you are in a call (see 'Check the signal strength' on page 13).

Make a call

You can make a call in these ways:

• Normal call

• Predial call

• Call through the speed dial key You can also make a call from the redial list (see 'Redial a call' on page 25), phonebook list (see 'Call from the phonebook' on page 20) and call log (see 'Return a call' on page 23).

Normal call

1 Press or . 2 Dial the phone number.

» The number is dialed out. » The duration of your current call is

displayed.

Call through the speed dial key

If you have already pre-saved a contact in the speed dial key, press and hold the key to make

a call.

Tip

• For information of how to set the speed dial keys, see

the chapter 'Phonebook', section 'Set the speed dial keys'.

Note

• The talk time of your current call is displayed on the

call timer.

• If you hear warning tones, the phone is almost out of

battery or out of range. Charge the battery or move the phone close to the base station.

Answer a call

When there is an incoming call, the phone rings and the LCD backlight ashes. Then you can:

• press or to answer the call.

• select [Divert] to send incoming call to the answering machine (only applied to D605).

• select [Silent] to turn off the ringer of the current incoming call.

Warning

• When the handset rings or when the handsfree is

activated, keep the handset away from your ear to

avoid ear damage.

Predial call

1 Dial the phone number

• To erase a digit, press [Clear].

• To enter a pause, press and hold .

2 Press or to dial out the call.

14 EN

Note

• The caller ID service is available if you have registered

to the caller ID service with your service provider.

Tip

• When there is a missed call, a notication message

appears.

End a call

You can end a call in these ways:

• Press ; o r

• Place the handset to the base station or charging cradle.

Adjust the earpiece/speaker volume

Press / on the handset to adjust the volume during a call.

» The earpiece/speaker volume is

adjusted and the phone is back to the

call screen.

Mute the microphone

2 Dial the second number.

» The number displayed on the screen is

dialed out.

Answer a second call

Note

• This service is network dependent.

When there is a periodical beep to notify you

of an incoming call, you can answer the call in these ways:

1 Press and to answer the call.

» The rst call is put on hold, and you

are now connected to the second call.

2 Press and to end the current call and

answer the rst call.

1 Press during a call.

» The handset displays [Mute on]. » The caller cannot hear you, but you

can still hear his voice.

2 Press again to unmute the microphone.

» You can now communicate with the

caller.

Turn the speaker on or off

Press .

Make a second call

Note

• This service is network dependent.

1 Press during a call.

» The rst call is put on hold.

Switch between two calls

Note

• This service is network dependent.

You can switch your calls in these ways:

• Press and ; or

• Press [Option] and select [Switch calls], then press [OK] again to conrm.

» The current call is put on hold, and you

are now connected to the other call.

Make a conference call with the external callers

Note

• This service is network dependent. Check with the

service provider for additional charges.

When you are connected to two calls, you can

make a conference call in these ways:

15EN

+ 37 hidden pages
