Page 1
Your Phone
Microphone
TFT LCD
Left soft key
Navigation and
confirm keys
Pick-up key
Philips continuously strives to improve its products. Due to software
upgrading, some contents in this user guide may be different from your
product.Philips reserves the rights to revise this user guide or withdraw it
at any time without prior notice. Please take your product as standard.
Right soft key
Hang up and
power key
Charger, Headset
connector & USB
port
Portable mobile
phone charger port
1
Page 2
Home screen
Your phone’s home screen consists of the following areas:
Status Bar
SIM1&SIM2
display
Clock display
Shortcut
Keys
Learn about the main keys.
Icons Definition Function
( Dial Make or answer a call.
Confirm and
,
navigation key
) Hang-up/
Exit/
Power
L
Left soft key Select the options on the screen.
R
Right soft key Select the options on the screen.
Select or confirm an option;
Long press to turn on or off the torch.
End a call;
Return to home screen;
Hold to turn on/off the phone.
* Lock/unlock Long press * to lock keys on home screen;
Press left soft key
R and then * to unlock
keys.
2
Page 3
Icons & symbols
Learn about the icons and symbols on the screen.
Icons Definition Function
Ringtone Your phone will ring when receiving a call.
Vibration
only
Battery The bars indicate the battery level.
SMS You have a new message.
MMS You have a new multimedia message.
Wap
message
Missed call You have missed a call.
Call diverts All your incoming voice calls are being
Headset The headset is plugged into the phone.
Alarm The alarm clock is activated.
Roaming Displayed when your phone is registered to a
Home zone A zone designated by your network operator.
GSM
network
Key lock The keypad has been locked.
GPRS
attach
Your phone will vibrate when receiving a call.
You have received a Wap push message.
forwared to a number.
network other than your own (especially when
you’re abroad).
Contact your service provider for details.
your phone is connected to a GSM network.
The more bars are shown the better the
reception is.
Your phone is connected to the GPRS
network.
3
Page 4
Getting started
Insert SIM card and Charge the battery
Learn about installing SIM card and charging the battery for the first use.
Insert SIM card
1
Remove the back cover.
3
Insert the SIM card.
5
Replace the back cover.
2
Take out the battery.
4
Install the battery.
4
Page 5
Charge the battery
A new battery is partially charged. The battery icon in the upper-right
corner shows the battery level of charging status.
Tips:
•
You can use the phone while it is charging.
•
Keeping the charger plugged to the mobile
phone when the battery is fully charged
will not damage the battery. The only way
to turn off the charger is to unplug it, so it
is advisable to use an easily accessible
power socket.
•
If you do not intend to use your phone for
several days, we recommend that you
remove the battery.
•
If a fully charged battery left unused, it will
lost its charge over time.
•
If a battery is being used for the first time
or the battery has not been used for a
prolonged period, it may take longer time
to recharge.
Insert a Micro SD card (Memory card)
You can expand the memory of your
phone by adding a micro SD card.
The phone can support Micro SD
card up to 8GB.
1
Push down the card holder and
lift it up. Align your micro SD
card with the slot. Put it in place.
2
Press down the card holder and
pull it until it is locked.
5
Page 6
Portable mobile phone charger
Portable mobile phone charger is a function that can charge for other
smart phone products.
1
Connect another smart phone product to the phone by the USB
cable.
2
Press navigation key - on the home screen or go to Charger in the
home menu to choose to open/close the portable mobile phone
charger.
3
After opening the portable mobile phone charger, the phone is
charging for this product.
4
You can choose to open/close the portable mobile phone charger
during charging or finished charging.
5
If you haven’t connected any product when the charger is opened,
the phone will automatically enter underloaded mode to reduce the
power consumption.
Note:
•
The working temperature of the portable mobile phone charger is: -20-50° C, if the
temperature is over this range, the phone will close the charger and give irrelative tips.
•
The portable mobile phone charger is applicable for smart phone products that carry an
output charging voltage of 5V and a maximum output current of 480mA.
Portable mobile
phone charger is
opening
6
Page 7
Using your phone
Use basic call functions
Make a call
1
Enter the phone number.
2
Press (to dial the number.
3
Press )to hang up.
Tips:
•
For international calls, long press 0 to enter the "+" sign for the international prefix.
•
After the primary card set, if you dial on home screen, all calls would dial from primary
card by default, you can press left soft key R to make a call from another card.
Answer and end a call
1
Press (to answer the call (Press the navigation key + or - to
adjust the volume).
2
Press right soft key R to select handsfree mode.
3
Press )to hang up.
Tips:
•
You can use the supplied headset to answer or end a call.
Use speed dial
On the home screen, you can call a number by long pressing a numeric
key.
To assign a contact to a speed-dial key:
1
Select Contacts>Options>Advanced>Speed dial.
2
Choose the Status to On.
3
Go to Set numbers to choose a numeric key to add a number.
7
Page 8
Receive and send messages
You can use the Messaging menu to send text message.
1
Select Messaging> Write message>Write SMS/MMS.
2
Write your text message.
3
Press ROptions to add multimedia contents (picture, sound,
attachment or bookmark text).
4
Press , to send the message.
Tips:
•
When you edit new message, message will send out from primary card by default, you
can press left soft key R to send message from SIM1 or SIM2.
•
When you send a message from call history or message inbox, the message will send
out from received card, you can press left soft key R to select SIM1 or SIM2 to send
a message.
Enter text
Your mobile phone supports a number of text entry methods, English
input, numeric input and symbol input.
Keys:
Keys Function
# Select an input method.
* Enter symbols and punctuations.
0 Insert a space.
R (Right soft key) Delete the previous character.
L (Left soft key) Select the character on the screen.
,
Select or confirm a character.
+/- To browse the candidate character on the previous or
next page.
Note:
•
Depending on the language you select for your phone, the supported input methods
may vary.
8
Page 9
Introduction of input methods:
Input method Function
English input Press the keys that are marked with the letter you
wish to enter. Press once to get the first letter on
the key, press twice quickly to get the second letter
and so on until the letter you want is displayed on
the screen.
Numeric input Press the numeric key to enter a number.
Manage your phonebook
Learn about basic phonebook function.
Add a new contact
Method one:
1
On the home screen, enter a number. Go to LOptions> Save to
contacts
2
3
Method two:
1
2
3
Search for a contact
1
2
3
4
5
/Save to existing.
Save the number, and add details as desired.
Press left soft key L to finish saving.
Go to Contacts, select Add new contact.
Select a location (To SIM1/To SIM2/To phone).
Add details as desired, and press left soft key L to finish saving.
Go to Contacts.
There are four phonebooks above the list: All, Phone, SIM1 and
SIM2.
Press the navigation key < or > to select a desired phonebook.
Enter the letters of the name in the search bar. (For example “John
Henry” enter “J H”)
Select the contact from the list.
9
Page 10
Manage your contacts
You can copy or move contacts between the SIM card and phone, or
delete contacts. Go to
desired option.
1
Set group:
You can group your contacts as different groups. For different groups,
you can use different ringtones for identification.
2
Add contacts to a group:
-
Select Contacts>Options>Caller groups>Add new group, add
group name and ringtone, and save.
-
In Group member, press left soft key L to add members for
the group.
Contacts>Options, press + or - to select the
Media player
Save MP3 music files under the My music folder on your memory card.
Play music
1
Go to Entertainment>Audio player, go to List select your desired
song in the folder.
2
Press LOptions> Play to start playing.
3
Using the following keys to control playback:
Function Definition
,
<
>
R (Right soft key) Return to the previous menu.
)
Pause and resume playback.
Select previous track.
Select next track.
Press the navigation key
Go to the home screen.
+ or - to adjust volume.
10
Page 11
Player settings
Go to Audio player>List>Options>Settings:
•
Pre.playlist: Play audio files from your phone or memory card.
•
List auto gen.: Refresh all audio files in your list.
•
Repeat: Choose to repeat current file/all the audio files.
•
Shuffle: Play audio files in the folder randomly or not.
•
Background play: Continue to play music after exiting the music
player.
To turn off the music player on the home screen
Press
), and then press LYes.
Note:
•
When listening to music, adjust the volume to a moderate level. Continuous exposure
to high volume may impair your hearing.
FM radio
Lear about listening to radio programs by using a FM radio.
Listen to a radio station
1
Plug the supplied headset into your phone.
2
Go to FM radio, press L Options>Auto search. It starts scanning
automatically and save the available channels.
3
Press the navigation key < or > to select a channel.
4
Press the navigation key + or - to adjust the volume.
5
Press LOptions>Turn off FM radio to turn off FM radio.
FM radio settings
Go to LOptions>Settings:
•
Background play: Continue playback after exiting FM radio.
•
Loudspeaker: Listen to radio through the speaker.
•
Record format: Select file format.
•
Audio quality: Select audio quality.
•
Record storage: Select your storage location.
11
Page 12
Manage your calendar
You can create your to-do list and make a plan on your calendar.
Create your to-do list
1
Go to Tools>Calendar select a date, and then press
LOptions>Add event.
2
Edit reminder settings.
3
Press , to save the event.
4
To change your to-do list, select the event, and then press
LOptions>Edit, to edit the task.
Check the calendar
Go to Tools>Calendar, you can check the calendar.
Alarm
Learn about how to set and use an alarm. You can set up three alarms.
Set an alarm
1
Go to Tools>Alarm.
2
Select an alarm, press left soft key L to edit the alarm.
3
Press right soft key L to finish setting the alarm.
Turn off an alarm
1
Go to Tools>Alarm.
2
Select the alarm you want to turn off, press LEdit.
3
Press the navigation key < or >
Stop an alarm
When the alarm rings,
•
Select Stop: The alarm stops.
•
Select Snooze: The alarm will sound again after 5 mins.
to select
Off
.
12
Page 13
File management
Learn about how to use and manage your files and folders.
Use your files
1
Set a photo as wallpaper or sreen saver:
-
Open My files>Pictures, select a photo.
-
Press LOptions>Use as>Wallpaper/Screen saver.
2
Set an audio file as ringtone:
-
Select an audio file.
-
Press LOptions>Use as>SIM1/2 incoming call.
Bluetooth
Your phone can connect to a compatible Bluetooth device for
exchanging data.
Connect to a Bluetooth device
1
Go to Connectivity>Bluetooth>Activation, turn on the
Bluetooth function.
2
Select Find devices>Search new device, a list of available
Bluetooth devices appears.
3
Select the device you wish to connect and press LPair.
4
The pairing is made if your pairing request is accepted by the other
part.
Send files via Bluetooth
1
Go to My files, select the file you want to send.
2
Press L Options>Send>Via Bluetooth.
3
Select a device.
4
Press , to start sending the file.
Receive files via Bluetooth
1
Go to Bluetooth>Settings, turn on the visibility.
2
Accept the request.
3
The files received are saved to My files>Phone/Memory card
>Received.
13
Page 14
Tips:
•
If you do not use the Bluetooth feature for some time, you should deactivate it in order
to conserve battery power.
•
If the size of the received file is too big, you can go to Bluetooth>Settings>Storage
to choose to save the file on the memory card.
Browser
You can use this function to browse the Internet. Consult your network
operator for the service subscription, data account information, and
WAP settings.
Access web sites
1
Go to Connectivity>Browser>Input address, enter your
desired websites.
2
Press L Options>Done to access the website.
3
Select L Options>Add to bookmarks. You can add your
favorite websites to bookmarks.
Browse settings
1
Go to Browser>Settings, you can set the default homepage,
choose the card for accessing the websites, choose the data
account, and set other options to customize the browse.
Customize your phone
Customize your phone to match your preferences.
Set clock
1
On the home screen, go to Menu>Settings> Phone settings >
Time and date.
2
Select Set time/date: use the numeric key to enter the digits.
SIM Settings
1
Check that your phone is turned on. Enter the PIN code if required.
2
Go to Menu>Settings>SIM Settings>Dual SIM settings>SIM1/
SIM2 settings,
3
Go to Menu>Settings>SIM Settings>Mode settings to activate
the dual cards or one card.
name your SIM card and set your primary card.
14
Page 15
Note:
•
The PIN code is preconfigured and communicated to you by your network operator or
retailer.
•
If you enter an incorrect PIN code three times in succession, your SIM card will be
blocked. To unblock it, you must request the PUK code from your operator.
•
If you enter an incorrect PUK code ten times in succession, the SIM card will be locked
permanently. When this happens, please contact your network operator or retailer.
Settings
SIM Settings
Function Definition
Dual SIM
settings
Mode Settings Select dual SIM active/one SIM active.
User profiles
The profiles are defined for several scenes. They consist of the settings
for ringtone, volume, and others. With preset profiles, you can easily
adjust the settings for incoming calls and messages as desired.
1
Go to Settings>User Profiles, press LOptions>Activate to
activate the profile.
2
Go to Customize to modify ringtone, volume and others.
To activate
Phone settings
Function Definition
Time and date Set the clock of the phone.
Schedule
power on/off
Language Select a language for your phone.
Pref.input
method
Dedicated key Select a navigation key as direct access to a menu.
Set SIM card name and select the primary card.
Silent mode, long press # on the home screen.
Set time for the phone to be switched on/off
automatically.
Set the preferred inputing method.
15
Page 16
Auto keypad
lock
Security
settings
Restore
factory
settings
Set a keypad span for the keypad to be locked
automatically.
This menu allows you to use passwords to protect
your phone.
Restore your phone settings to the default values.You
need to enter your phone lock password(1122 by
default).
Display
Function Definition
Font size Select the size of font.
Wallpaper Select an image as the wall paper of your phone.
Screen saver Select the images as the screen saver.
LCD back light Set the LCD brightness and the duration of backlight.
Greeting text Select whether to show greetings when your phone is
Show date and
time
Show
supplementary
information
Greeting text Select whether to show the greeting text when
turned on.
Select whether to show the date and time.
Select whether to show operator name, SIM card
name, Broadcast message.
power on.
16
Page 17
Call settings
Function Definition
Call waiting Get informed of an incoming call when on the phone
Call divert Divert incoming calls to your voice mailbox or
Call barring Set limits to your incoming and outgoing calls.
Line switching Operator-dependent function, please contact the
Advanced Set advanced settings of calling.
Auto redial Keep redialing the number that fails to go through.
Call time
reminder
Answer mode Select the answer mode.
(network-dependent).
another phone number.
local operator for details.
Set reminder when the call time reachs the setting
time.
Network settings
Function Definition
Network
select mode
Select the network for your phone (service
subscription dependent). Auto-select is
recommended.
17
Page 18
Tips & tricks
Optimizing your Philips Xenium battery performance
Here are some steps to help you optimize your Philips Xenium’s battery
performance.
How to optimize the standby and talk time of your phone?
•
Always ensure that your phone profile is appropriately set to meet
your actual usage. Profile setting significantly impacts the phone’s
battery performance. In general, Outdoor Mode is the most powerdraining setting while Silent Mode consumes the least amount of
power.
•
If you’re using a Xenium phone with a dual SIM feature, try to
activate the 2 SIM cards only when absolutely necessary. If you are in
a country with single coverage, deactivate the non-covered SIM to
prolong battery usage.
•
If you’re not using applications like Bluetooth, WIFI, GPS and JAVA,
turn them off. And be sure to lock your phone to prevent accidental
pressing of the keys with the auto-lock feature.
•
Adjust the intensity and duration of your display screen’s backlight
to low or medium level and for the shortest duration. In general, the
lower the backlight level and the shorter the duration, the more
power you will save.
•
Avoid using or placing your phone near magnetic objects (eg. a radio
or television) or on metal surfaces, which will impact the network
connection and ultimately drain power from your battery.
How to extend your battery’s life?
•
Full charging and full running down of your battery will extend its
life. Charge the battery once the low-battery warning comes on.
•
Temperature will impact battery usage. Over time, heat will degrade
your battery’s performance. Keep your phone out of the sun or a
hot car. If in low temperature, place your phone in a warmer place
(eg. your pocket), as battery capacity decreases as the temperature
drops.
•
Always use authentic accessories as they enable your battery to
perform at its peak. Non-authentic accessories (eg. chargers) can
damage your battery and even your phone.
18
Page 19
Safety & Precaution
Precaution
Keep your phone away from small children
Keep your phone and all accessories out of the reach of small children. Small parts may cause
choking or serious injury if swallowed.
Radio Waves
Your phone transmits/receives radio waves in the GSM frequency (900/1800/1900MHz).
Check with the vehicle manufacturer that electronic equipment used in your vehicle will not be
affected by radio energy.
Switch off your phone...
Turn off the phone when in an aircraft. The use of mobile phones in an aircraft may be dangerous
for the operation of the aircraft, disrupt the mobile phones network and may be illegal.
In hospitals, clinics, other health care centers and anywhere else where you may be in the close
vicinity of medical equipment.
In areas with a potentially explosive atmosphere (e.g. petrol stations and also areas where the
air contains dust particles, such as metal powders).In a vehicle transporting flammable products
or a vehicle powered by liquefied petroleum gas (LPG).In quarries or other areas where blasting
operations are in progress.
Your mobile phone and your car
Avoid using your phone while driving and obey all regulations that restrict the use of mobile
phones while driving. Use hands free accessories to increase your safety when possible. Ensure
that your phone and car kit do not block any air bags o r other security devices fi tted in your car.
Handle your phone carefully and sensibly
For the optimal and satisfactory operation of the phone you are recommended to use the
phone in the normal operating position.
•
Do not expose your phone to extreme temperatures.
•
Do not immerse the phone in any liquid; if your phone is damp, switch it off, remove the battery
and let them dry for 24hrs before using them again.
•
To clean the phone, wipe it with a soft cloth.
•
In hot weather or after prolonged exposure to the sun(e.g.,behind a window or a wind
screen),the temperature of your phone's cashing mighe increase.Be very careful in this case when
picking up your phone and also avoid using i t with an ambient temperature over 40°.
Protect batteries from damage
You should only use Philips Authentic Accessories, as the use of any other accessories may
damage your phone and may be danger ous, and will make all guarantees for your Philips phone
null and void. The use of an unspecified type of battery may also cause an explosion.
Make sure damaged parts are replaced immediately by a qualified technician and that they are
replaced with genuine Philips replacement parts.
•
Your phone is powered by a rechargeable battery.
•
Use specified charger only.
•
Do not incinerate.
•
Do not deform or open the battery.
•
Do not allow metal object s (such as keys in your pocket) to short circuit the battery contacts.
•
Avoid exposure to exce ssive heat (>60° C or 140° F), moisture or caustic environments.
Environmental care
Remember to obser ve the local regulatio ns regarding the dispos al of the packaging m aterials,
exhausted batteries and old phone and please promote their recycling.Philips has marked the
battery and packaging with standard symbols designed to promote the recycling and appropriate
disposal of your eventual waste.
:The labeled packaging material is recyclable.
:A financial contribution has been made to the associated national packaging recovery and
recycling system.
19
Page 20
:The plastic material is recyclable (also identifies the type of plastic).
WEEE Marking in the DFU: “Information to the Consumer”
Disposal of your old product
Your product is designed and m anufactured with high quality m aterials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means the product is
covered by the European Directive 2002/96/EC
Please inform yourself about the local separate collection system for electrical and electronic
products.
Please act according to your local rules and do not dispose of your old products with your normal
household waste. The co rrect disposal of your old product will help prevent po tential negative
consequences for the environment and human health.
This device may contain commodities, technology or software subject to export laws and regulations
from the US and other countries. Diversion contrary to law is prohibited.
Tips
Pacemakers
If you have a pacemaker:
•
Always keep the phone more than 15 cm from your pacemaker when the phone is switched on,
in order to avoid potential interference.
•
Do not carry the phone in a breast pocket.
•
Use the ear opposite to the pacemaker to minimize the potential interference.
•
Switch off your phone if you suspect that interference is taking place.
Hearing aids
If you are a user of a hearing aid, consult your physician and hearing aid manufacturer to learn
whether your particular device is susceptible to cellular phone interference.
How to prolong the battery life of your phone
To have your mobile phone function properly, sufficient battery power is important. For the powersaving purpose, do the following, if applicable:
•
Turn off the Bluetooth function of your phone.
•
Set the backlight level and duration of your phone to a low value.
•
Turn on the auto keypad lock, turn off the key sounds, tap vibration, or vibration alerts.
•
Establish GPRS connection when needed. Otherwise, your phone will keep searching for GPRS
connection, and drain your battery power.
•
Turn off your phone if there is no coverage. Otherwise, the phone will keep searching for
network, and drain your battery power.
Troubleshooting
The phone does not switch on
Remove/reinstall the battery. Then charge the phone until the battery icon stops scrolling. Unplug
the charger and try to switch the mobile on.
The display shows BLOCKED when you switch on the phone
Somebody tried to use your phone but didn’t know the PIN code nor the unblocking code (PUK).
Contact your service provid er.
The display shows IMSI failure
This problem is related to your subscription. Contact your operator.
Your phone doesn’t return to idle screen
Long press the hang-up key or switch off the phone, check that the SIM card and the battery are
installed correctly and switch it on again.
20
Page 21
The network symbol is not displayed
The network connection is lost. Either you are in a radio shadow (in a tunnel o r between tall
buildings) or you are outside the network coverage area. Try from another place, try to reconnect
to the network (especially when abroad), check that the antenna is in place if your mobile has an
external antenna, or contact your network operator for assistance/information.
The display doesn’t respond (or the display responds slowly) to key presses
The display responds more slowly at very low temperatures. This is normal and does not affect the
operation of the phone. Take the phone to a warmer place and try again. In other cases please
contact your phone supplier.
Your battery seems to over heat
You might be using a charge r that was not intended for use w ith your phone. Make sure you al ways
use the Philips authentic accessory shipped with your phone.
Your phone doesn’t display the phone numbers of incoming calls
This feature is network and subscription dependent. If the network doesn’t send the caller’s number,
the phone will display Call 1 or Withheld instead. Cont act your operator for detailed information o n
this subject.
You can’t send text messages
Some networks don’t allow message exchanges with other networks. First check that you have
entered the number of your SMS centre, or contact your operator for detailed information on this
subject.
You can’t receive and/or store JPE G pictures
A picture may not be accepted by your mobile phone if it is too large, if its name is too long, or if it
doesn’t have the correct file format.
You feel that you have missed some calls
Check your call divert options.
When charging, the battery icon shows no bar and the outline is flashi ng
Only charge the battery in an environment where the temperature does not go below 0°C (32°F) or
above 50°C (113°F).
In other cases please contact your phone supplier.
The display shows SIM failure
Check that the SIM card has been inserted correctly. If the problem persists, your SIM card may be
damaged. Contact your operator.
When attempting to use a feature in the menu, the display shows NOT ALLOWED
Some features are network dependent. They are only available, therefore, if the network or your
subscription supports them. Contact your operator for detailed information on this subject.
The display shows INSERT YOUR SIM CARD
Check that the SIM card has been inserted correctly. If the problem persists, your SIM card may be
damaged. Contact your operator.
The autonomy of your phone seems lower than indicated on the user guide
The autonomy is linked to your settings (e.g., ringer volume, backlig ht duration) and the features you
use. To increase the autonomy, and whenever possible, you must deactivate features you do not use.
Your phone doesn’t work well in your car
A car contains many metallic parts that absorb electromagnetic waves which can affect the phone’s
performance. A car kit is available to provide you with an external antenna and enables you to make
and receive phone calls wit hout handling the handset.
Note:
•
Check with the local authorities whether or not you are allowed to use the phone while driving.
Your phone is not charging
If the battery is completely flat, it might take several minutes of pre-charge (up to 5 minutes in some
cases) before the charging icon is displayed on the screen.
21
Page 22
The picture captured with the phone camera is not clear
Make sure that the camera lens on both sides is clean.
Trademark Declaration
Philips PHILIPS and PHILIPS’ Shield Emblem are registered trademarks of Koninklijke
Specific Absorption Rate Information
International standards
THIS MOBILE PHONE MEETS THE INTERNATIONAL RECOMMENDATIONS FOR EXPOSURE
TO RADIO WAVES
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed
the limits for exposure to radio frequency (RF) energy defined by the international standards. These
recommendations have been established by the International Commission on Non-Ionizing Radiation
Protection (ICNIRP) and, the Institute of Electrical and Electronics Engineers (IEEE) that forecast a
substantial safety margin for assuring the protection of all persons, regardless of age and health.
The exposure recommendations for mobile phones use a measurement unit known as the Specific
Absorption Rate (SAR). The SAR limit recommended by the ICNIRP for the mobile phones used by
the general public is
gram of tissue
Tests for SAR have bee n conducted using recommended operating po sitions with the mobile phone
transmitting at its highest certified power level in all tested frequen cy bands. Although the SAR is
determined at the highest certified power level, the actual SAR levels of the mobile phone while
operating are generally below the maximum SAR value. This is because the phone is de signed to
operate at multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a base station antenna, the lower the power output.
While there may be differences between the SAR levels of various phones and at various positions,
they all meet the international protection standards for exposure to radio waves.
The highest SAR value for this Xenium X130 model phone when tested for compliance
against the standard was 0.699 W/kg for ICNIRP recommendation.
For limiting the radio waves exposure, it is recommended to reduce the mobile phone call duration
or to use a headset. The purpose of those precautions is to take the mobile phone away from the
head and the body.
Limited warranty
1
Philips warrants to the original retail purchaser (“Consumer” or “You”) that this Philips cellular
product and all accessories originally provided by Philips in the sales package (“Product”) are free
from defects in materials, design and workmanship under normal use in accordance with the
operating instructions and pursuant to the following t erms and conditions. This limited warranty
extends only to the Consum er for Products purchased and used in the origin al country of purchase.
The limited warranty is valid only in Philips’ intended count ry of sales of the product.
2.
The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase
of the Product, documented by valid proof of purchase. The lim ited warranty for original Philips
rechargeable battery e xtends for six (6) mont hs from the date of purcha se.
3.
During the limited warranty period, Philips or its authorized service representative will, at its option
either repair or replace, without charge for parts or labour, a materially defective Product with new
or refurbished parts or Product and return such repaired or replaced Product to the Consumer in
working condition. Philips will retain defective parts, modules or equipment.
Philips Electronics N.V. manufactured by Shenzhen San g Fei Consumer
Communications Co., Ltd. Under license from Koninklijke Philips Electronics N.V..
2.0W/kg averaged over ten grams of tissue and, is 1,6 W/kg averaged over one
by IEEE Std 1528 for the head.
What Does This Limited Warranty Cover?
How Long is The Limited Warranty Period?
What Will Philips Do if The Product is Not Free From Material Defects in Materials and
Workmanship During The Limited Warranty Period?
22
Page 23
Repaired or replaced Product will be covered by this limited warranty for the balance of the original
limited warranty period or ninety (90) days from the date of repair or replacement whichever is
longer. Repair or replacement of Product, at Philips’ option is your exclusive remedy.
4.
What is Not Covered By This Limited Warranty?
This limited warranty does not cover:
a) Product that has been subjected to misuse, accident, shipping or other physical damage, improper
installation, abnormal operation handling, negl ect, inundation, fire, water or other liquid intrusion; or
b) Product that has been damaged due to repair, alteration, or modification by anyone not authorized
by Philips; or
c) Product that has reception or operation problems caused by signal conditions, network reliability
or cable or antenna systems; or
d) Product defects or problems caused by uses with non-Philips products or accessories; or
e) Product which warranty/qu ality stickers, product serial number or electronic serial number has
been removed, altered or rendered illegible; or
f) Product purchased, used, serviced, or shipped for repair from outside the original country of
purchase, or used for commercial or institutional purposes (including but not limited to Products
used for rental purposes); or
g) Product returned without valid proof of purchase or which proof of purchase has been altered or
is illegible.
h)Normal wear and tear or Force Majeure.
5.
How Do You Get Warranty Service?
a) Return the Product to an authorized service center of Philips. You may contact the local Philips
office for the location of the nearest authorized service center.
b)The SIM card must be remo ved from the Product before it is given to Philips. Philips as sumes no
liability for damaged or loss of the SIM card or the data co ntained therein.
c)If the Product failure is not covered by this limited warranty, or this limited warranty is inap plicable,
void or invalid due to any terms and conditions st ated herein, the Consumer will be charged for the
cost of repair or replacement of the Product and all other related cost incurred in repairing or
replacing the Product.
d) IMPORTANT - you are required to return the Product together with a valid proof of purchase
which must identify the point of purchase, date of purchase, Product model and Product serial
number clearly.
6.
Other Limitation: This Warranty is The Entire Agreement.
EXCEPT FOR THE EXPRESS WARRANTIES SET FORTH ABOVE AND THOSE IMPLIED BY LAW
AND WHICH CANNOT BE EXCLUD ED OR MODIFIED BY AGREEMENT, PHILI PS PROVIDES
NO OTHER WARRANTY WHETHER EXPRESS OR IMPLIED (WHETHER BY ST ATUTE, UNDER
THE OPERATION OF LAW OR OTHERWISE) AND SPECIALLY DISCLAIMS ANY WARRANTY
OF SATISFACTORY QUALITY MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
PHILIPS’ TOTAL LIABILITY FOR DAMAGES RELATING TO OR ARISING OUT OF THE
PURCHASE OR USE OF THE PRODUCT, REGARDLESS OF THE TYPE OR CAUSE OF SUCH
DAMAGE OR THE FORM OR CHARACTERISATION OF THE CLAIM ASSERTED (E.G.
CONTRACT OR TOPIT), SHALL NOT EXCEED THE ORIGINAL PURCHASE PRICE PAID FOR
THE PRODUCT.
HOWEVER IN NO EVENT SHALL PHILIPS BE LIABLE FOR ANY PUNITIVE, SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED
TO THE LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERIAL LOSS, LOST PROFITS,
LOST BUSINESS OPPORTUNITIES, COST OF SUBSTITUTION OF GOODS OR SERVICES,
INVESTMENTS, DAMAGE TO GOODWILL OR REPUTATION, OR LOSS OF DA TA AND
CLAIMS BY THIRD PARTIES) RESULTING FROM PURCHASE OR USE OF THE PRODUCT, TO
THE FULLEST EXTENT ALLOWED BY LAW, WHETHER OR NOT PHILIPS HAS BEEN ADVISED
OF THE POSSIBILTY OF SUCH DAMAGES. THESE LIMITATIONS SHALL APPLY
NOTWITHSTANDING THE FAILURE OF THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.
23
Page 24
This limited warranty represents the complete and exclusive agreement between the Consumer and
Philips with respect to this cellular Product and it supercedes all prior agreements between the
parties, oral or written, and all other communications b etween the parties relating t o the subject
matter of this limited warranty. No carrier, retailer, agent, dealer, employee, thereof, or employee
of Philips is authorized to make modifications to this limited warranty and you should not rely on any
such representation.
This limited warranty does not affect the Consumer’s statutory rights under applicable national laws
in force.
Declaration of Conformity
We,
Shenzhen Sang Fei Consumer
Communications Co., Ltd.
11 Science and Technology Road,
Shenzhen Hi-tech Industrial Park,
Nanshan District, Shenzhen 518057
China
declare under our sole responsibility that the product
Xenium X130
Philips GSM/GPRS 900/1800/1900
TAC number: 8636 3001
to which this declaration relates, is in conformity with the following Stan dards:
SAFETY : EN 60950-1:2006/A12:2011
HEALTH: EN 62209-1:2006
EN 62209-2:2010
EN 50360-2001
EMC: EN 301 489-1 v1.9.2
EN 301 489-7 v1.3.1
EN 301 489-17 v2.1.1
EN 55013 2001 A2:2006
EN 55020 2007
SPECTRUM: ETSI 301 511 v9.0.2
EN 300 328 v1.7.1
We hereby declare that all essential radio test suites have been carried out and that the above named
product is in conformity to all the essential requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in Annex IV of Directive
1999/5/EC has been followed with the involvement of the following Notified Body :
British Approvals Board for Telecommunications TUV SUD Group Balfour House Churdhfield Roadwalton-on-Thames Surrey - KT12 2TD United Kingdom
Identification mark: CE0168
July 5th, 2012
Quality Manager
24
Loading...
