Philips cte168bk User Manual
Your Phone
TFT LCD
Headphone jack
Left soft key
Navigation and
confirm keys
Pick-up key
Right soft key
Hang up and
power key
Charger &
Micro USB port
Torch
Philips continuously strives to improve its products. Due to software
upgrading, some contents in this user guide may be different from your
product. Philips reserves the rights to revise this user guide or withdraw
it at any time without prior notice. Please take your product as standard.
1
Home screen
Status Bar
Shortcut
Clock display
Your phone’s home screen consists of the following areas:
Keys
Learn about the main keys.
Icons Definition Function
( Dial Make or answer a call.
Confirm and
,
navigation key
) Hang-up/
Exit/
Power
L
Left soft key Select the options on the screen.
R
Right soft key Select the options on the screen.
Select or confirm an option.
End a call;
Return to home screen;
Hold to turn on/off the phone.
* Lock/unlock Long press * to lock keys on home screen;
Press
L and then * to unlock keys.
2
Icons & symbols
Learn about the icons and symbols on the screen.
Icons Definition Function
Ringtone Your phone will ring when receiving a call.
Vibration
only
Silent Your phone will not ring when receiving a call.
Battery The bars indicate the battery level.
SMS You have a new message.
Missed call You have missed a call.
Call diverts All your incoming voice calls are being
Headset The headset is plugged into the phone.
Alarm The alarm clock is activated.
GSM
network
Flight Mode Flight mode is activated.
Bluetooth Bluetooth is activated.
Your phone will vibrate when receiving a call.
forwarded to a number.
Your phone is connected to a GSM network.
The more bars are shown the better the
reception is.
3
Getting started
Insert SIM card and Charge the battery
Learn about installing SIM card and charging the battery for the first use.
Insert SIM card
1
Remove the back cover.
3
Insert the SIM card.
5
Replace the back cover.
2
Take out the battery.
4
Install the battery.
4
Charge the battery
Tips:
•
You can use the phone while it is charging.
•
Keeping the charger plugged to the mobile
phone when the battery is fully charged
will not damage the battery. The only way
to turn off the charger is to unplug it, so it
is advisable to use an easily accessible
power socket.
•
If you do not intend to use your phone for
several days, we recommend that you
remove the battery.
•
If a fully charged battery left unused, it will
lost its charge over time.
•
If a battery is being used for the first time
or the battery has not been used for a
prolonged period, it may take longer time
to recharge.
You can expand the memory of your
phone by adding a micro SD card.
1
Push down the card holder and lift
it up. Align your micro SD card
with the slot. Put it in place.
2
Press down the card holder and
pull it until it is locked.
A new battery is partially charged. The battery icon in the upper-right
corner shows the battery level of charging status.
Insert a Micro SD card (Memory card: up to 16GB)
5
Customize your phone
Note:
Tips:
Customize your phone to match your preferences.
Set clock
1
On the home screen, go to Menu>Settings> Phone settings >
Time & date.
2
Select Set time/date: use the numeric key to enter the digits.
SIM Settings
1
Check that your phone is turned on. Enter the PIN code if required.
2
Go to Menu>Settings>Dual-SIM>Set SIM name, name your SIM
card.
3
Go to Menu>Settings>Dual SIM>Standby mode to activate the
dual cards or one card.
•
The PIN code is preconfigured and communicated to you by your network operator or
retailer.
•
If you enter an incorrect PIN code three times in succession, your SIM car d will be
blocked. To unblock it, you must request the PUK code from your operator.
•
If you enter an incorrect PUK code ten times in succession, the SIM card will be locked
permanently. When this happens, please contact your network operator or retailer.
Using your phone
Use basic call functions
Make a call
1
Enter the phone number.
2
Press ( to dial the number.
3
Press ) to hang up.
•
For international calls, long press 0 to enter the "+" sign for the international prefix.
Answer and end a call
1
Press (to answer the call.
2
Press confirm and navigation key ,to select handsfree mode.
3
Press)to hang up.
6
