Philips CT9A9ZBLK, CT9A9ZWHT User Manual

Discover Your Phone

Main screen

Left softkey/ OK key

Navigation keys

Pick up key

Microphone/ Headset/Charger connector

Philips continuously strives to improve its products. Therefore, Philips reserves the rights to revise this user guide or withdraw it at any time without prior notice. Philips provides this user guide “as is” and does not accept, except as required by applicable law, liability for any error, omission or discrepancy between this user guide and the product described. The device is meant to be connected to GSM/GPRS networks.

Right softkey

Hang up and on/

off key

Alphanumeric keypad

How to ...

Switch the phone On/Off

Store numbers in Phonebook

Make a call Enter the phone number

Answer a call Press ( when your phone

End a call Press ).

Reject a call Press ) when your phone

Adjust earpiece volume

Access Phonebook Press - in idle mode.

Access main menu Press L in idle mode.

Switch to silent mode

Long press ).

Enter the phone number and press L and select Store

number.

using the keypad and press ( to dial.

rings.

Press + or - during a call.

Long press + key in idle mode to toggle between the silent mode and personal mode.

Return to previous menu

Quickly return to idle mode

Press R.

Press ).

The Left/Right key

Press the left and right soft keys L and R located at the top of the keypad to perform the function displayed at the bottom of the screen.

Table of contents

1. Getting Started .......................................... 4

Insert the SIM card .......................................... 4

Switch on the phone ....................................... 5

Charge the battery .......................................... 6

2. Calling ............................................................... 7

Make a call ......................................................... 7

Using the phonebook ...................................... 7

Make an Emergency call ................................. 7

Answer and end a call ..................................... 7

Options during a call ....................................... 7

Adjust earpiece volume .................................. 8

Handle multiple calls ....................................... 8

3. Text or number Entry ........................... 9

Input Method .................................................... 9

Function keys ..............................................9

Multitap ABC/Abc/abc Input ......................... 9

T9® text input ................................................ 10

Numeric input ................................................. 12

Symbol Input ................................................... 12

4. Messages ....................................................... 13

SMS .................................................................... 13

Broadcast SMS ................................................ 14

Settings ............................................................. 15

5. Settings .......................................................... 16

Time and date ................................................. 16

Language ........................................................... 16

Hotkeys ............................................................ 16

Security ............................................................ 16

Network Settings ........................................... 17

Sounds .............................................................. 17

Display .............................................................. 18

6. Games & appli. ......................................... 19

Games ............................................................... 19

Alarm clock ..................................................... 19

Calculator ........................................................ 20

7. Call Info ........................................................ 21

Call Counters ................................................. 21

Settings ............................................................. 21

Call list .............................................................. 22

8. Multimedia .................................................. 24

FM Radio .......................................................... 24

Sounds .............................................................. 25

Memory status ................................................ 25

MP3 ................................................................... 25

Pictures ............................................................ 25

9. STK .................................................................. 26

STK .................................................................... 26

10. Contacts .................................................... 27

Settings ............................................................. 27

Search for a contact in the phonebook .... 27

Create new contacts ..................................... 28

Manage contacts ............................................. 28

Icons & symbols ............................................ 29

Precautions ....................................................... 30

Troubleshooting ........................................... 35

Philips Authentic Accessories .............. 37

Trademark Declaration ........................... 38

Specific Absorption Rate Information

........................................................ 39

Limited warranty .......................................... 40

Declaration of conformity....................... 43

1. Getting Started

Please read the safety instructions in the “Precautions” section before using your phone.

To use your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The SIM card contains your subscription information, your mobile phone number and a memory in which you can store phone numbers and messages.

Insert the SIM card

Follow the steps below to insert your new SIM card. Remember to switch off your mobile phone before removing the back cover and battery.

Remove the back cover

To insert the SIM card, you must first remove the back cover. Press on the back cover with your finger and slide the cover downwards (1). Then lift up the door of the battery compartment (2) as shown below.

4 Getting Started

Remove the battery

To remove the battery, lift up the battery from the top as shown below.

Insert the SIM card

Make sure the clipped corner of the SIM card is facing the correct direction and the metallic contacts facing downwards. Slide the SIM card into the SIM card slot until it stops.

Replace the back cover

Replace the back cover by sliding it down into its slot, until it stops.

Remove the protective film covering the screen before using the phone.

Replace the battery

Slide the battery back to its slot, with the gold contacts facing downwards until it stops. Then lock it by pushing it downwards.

Switch on the phone

To switch on the phone, long press ) key. Enter the PIN code if required. It is preconfigured and communicated to you by your operator or retailer. For more information on PIN code, see “Security”.

If you enter an incorrect PIN code three times in succession, your SIM card will be locked. To unlock it, you must obtain the PUK code from your network operator.

Getting Started 5

Charge the battery

Your phone is powered by a rechargeable battery. A new battery is partially charged and a sound alert will warn you when the battery reaches low. Once you have installed the battery, you can start charging the phone. Plug in the charger connector as shown below. Then plug the other end into an AC power socket.

During charging, the charge indicators will scroll. It takes around 3 hours to fully charge the battery. When all the scroll bars are steady, the battery is fully charged. You can then disconnect the charger.

Depending on the network and condition of use, talk time and stand-by time can go up to 8 hours and 750 hours respectively.

Keeping the charger plugged to the mobile phone when the battery is fully charged will not damage the battery. The only way to turn off the charger is to unplug it, so use an easily accessible AC power socket. You can connect the charger to an IT supply.

6 Getting Started

2. Calling

Make a call

From idle screen

1. In idle mode, enter the phone number using the

keypad. To correct an error, press R.

2. Press ( to dial the number.

3. Press ) to hang up.

To make an international call, long press *to insert the international prefix “+”.

Using the phonebook

1. Press - in idle mode.

2. Select a contact from the list and press ( to

dial the selected number. To select a different number, press + or - (see “Contacts” for more information).

3. Press ) to hang up.

Make an Emergency call

Without a SIM card in phone, you can press L (SOS) to dial emergency call. With a SIM card in phone, you can enter emergency number in idle mode, then press (.

In Europe the standard emergency number is 112, in the UK it is 999.

Answer and end a call

When there is an incoming call, the number of the caller may be displayed if the caller has chosen to display his or her identity. If the number is stored in the phonebook, the corresponding name will be displayed instead of the number.

• To an s we r t h e c al l : press (.

•

To reject the call:

• To han g u p: press ).

The phone will not ring when it is in silent mode.

If you have selected Any key answer, you can answer a call by pressing any key, except ).

press ).

Options during a call

During a call, press L Option to access the following options:

- Activate h/free

- Send and receive Messages

- Call list

- Call hold

- Access Notepad

Calling 7

- End call

- Access Names list

- Mute the call

Adjust earpiece volume

During a call, press the + or - key to increase or decrease the volume.

Handle multiple calls

You can handle two or more calls at the same time, as well as make conference calls using your phone. The availability of this feature is dependent on your network operator and/or subscription.

Make a second call

You can make a second call when there is an active call or with a call on hold. While on the phone, dial the number (or select a contact from the phonebook) and press (. The first call is put on hold and the second number is dialled. You can then press L to access the following options:

• Activate h/free

• Transfer call

• Call hold

• Conference to introduce the caller into a conference call.

• End call

• Switch calls to toggle between 2 calls

• Mute the current call

Answer a second call

When you receive a second call while already in communication, the phone will emit a beep tone and the screen displays information about the incoming call. You can then:

Press ( To answer the call (the first one

is put on hold).

Press ) To reject the call.

Press L Option To access options list. You can

select Accept call, Reject call,

Accept in h/free and End call.

8 Calling

3. Text or number Entry

Input Method

Your phone supports 7 types of input methods: Multitap ABC/Abc/abc T9 ABC/Abc/abc T9 PinYin Simplified Chinese stroke Traditional Chinese Zhuyin Numeric Symbols

You can select in the option list the appropriate input method to enter English letters, words, symbols and numbers. Icons appearing on the screen indicate the active input mode.

Function keys

R Delete the characters on the left of the

cursor or exit from editing mode.

+/-/</> Move the cursor, select a letter, word or

symbol from the list, or scroll down a list.

) Return to idle mode. L Select the highlighted word from the list or

enter Options menu.

# Enter symbols. * Switch input mode.

Multitap ABC/Abc/abc Input

1. Press once on the numeric key (2 to 9) to

enter the first letter on the key, press twice to enter the second letter on the key, so on and so forth. If the letter you wish to enter and the one you have just entered are on the same key, just wait for a few seconds for the cursor to re-appear.

2. Press R to delete the characters on the left of

the cursor.

Example: how to enter the word "home":

Press 4, 4 (GHI) 6, 6, 6 (MNO), 6 (MNO), 3, 3 (DEF). Press L when the message is completed.

You can press key 1 to insert a space in ABC/abc Multitap input mode. Press key different cases.

The letters located on each key are as follows:

Key Characters in the order displayed

1 . , - ? ! @ : # $ / _ 1

2 a b c 2 à ä å æ ç

to switch between

Text or number Entry 9

3 d e f 3 é è ∆ Φ 4 g h i 4 Γ ì

5 j k l 5 Λ

m n o 6 ñ ò ö

p q r s 7 β Π Θ Σ

t u v 8 ü ù

9 w x y z 9 Ω ø Ξ Ψ

0 0

T9® text input

T9® Predictive Text Input is an intelligent editing mode for entering text

Tegic Euro. Pat.

App. 0842463

keys you have pressed. You press once on the key corresponding to each letter needed to spell a word and T9 several words are available, the first word in the list is displayed and highlighted. Press +/- or L to browse the list and press L to insert the word.

on a mobile phone. It allows you to enter text more quickly by anticipating the word you want to enter based on the

suggests a word based on your keystrokes. If

T9 ABC/Abc/abc Input

T9 English input method offers a faster way for you to enter English words.

1. You only need to press once on the numeric key

(2 to 9) corresponding to each letter needed to spell a word. As you enter the letters, the words displayed on the screen will be updated accordingly.

2. Press R to delete the entries on the left of the

cursor.

3. Use the navigation key to select the desired word

and press L to enter it.

Examples: how to enter the word "home":

1. Press key 4, key 6, key 6, key 3. The

screen displays the first word of a list: Good.

2. Press + to scroll and select Home.

3. Press L to confirm.

T9 PinYin Input (China & Hong Kong only).

This is an intelligent editing mode that not only allows you to press only once on a key corresponding to each letter needed to form a character, but is also equipped with association input feature. Keystrokes are analysed and all the possible pinyin combinations will be displayed at the bottom of the screen.

10 Text or number Entry

Using T9 PinYin input method

1. Enter the pinyin letters accordingly. Press once on the key corresponding to the pinyin letter without having to consider its position on the key. As you enter the letters using your keypad, the pinyin combinations on the screen will be updated accordingly.

2. Use the navigation keys to select your desired pinyin combination and press L to select the candidate line. Press < or > to select the character (the selected pinyin character will be highlighted) and press the L to enter the character. If the desired character is not on the current list, press + or - to check from the list.

3. Enter the association character: As soon as you have selected and entered a character, the candidate list will be updated and a list of association characters will be displayed. Use the navigation key to select the desired association character and press to L confirm entry. If you do not need to enter the association character, simply press R to exit, or enter the new pinyin letters directly.

Simplified Chinese Stroke Input (China & Hong Kong only)

Using Stroke input method

1. Enter the strokes: Enter the strokes of the chinese character according to its stroke sequence. When you press the keys corresponding to the required strokes, the strokes will display on the screen. The phone will display the candidate characters corresponding to the strokes you have entered. As you enter the strokes, the candidate characters on the screen will be updated accordingly.

2. Enter character: Use the navigation key to select the required chinese character from the candidate list. Press L to input the chinese character and press R to clear the strokes you have entered.

3. Enter associate character: As soon as you have selected and entered a character, the candidate list will be updated and a list of association characters will be displayed. Use the navigation key to select the desired association character and press to L confirm entry. If you do not need to enter the association character, simply press R to exit, or enter the new strokes directly.

Text or number Entry 11

Traditional Chinese Zhuyin Input (China, Hong Kong & Taiwan only)

Using Zhuyin input method

1. Enter the zhuyin letters accordingly. Press once on the key corresponding to the zhuyin letter without having to consider its position on the key. As you enter the letters using your keypad, the zhuyin combinations on the screen will be updated accordingly.

2. Use the navigation keys to select your desired zhuyin combination and press L to select the candidate line. Press < or > to select the character (the selected zhuyin character will be highlighted) and press the L to enter the character. If the desired character is not on the current list, press + or - to check from the list.

Numeric input

1. Press the numeric keys (0 to 9) to enter the

numbers corresponding to the keys.

2. To delete a number, press R.

Symbol Input

Press # to enter punctuation or symbols. Use the navigation keys to select the desired punctuation or symbol and press L to enter it. Press - to scroll down the list of punctuation or symbols.

12 Text or number Entry

4. Messages

SMS

This menu allows you to send text messages using Short Messaging Service (SMS), as well as manage the messages you have sent and received.

Write message

To compose and send an SMS, select <Create

message> and start to write your message. When you

finish writing your message, press L Option to access the next options:

Send Send the message.

Send to Multiple

Save Save the message in drafts folder.

Language Select the language to be displayed.

Add sound Insert a melody.

Add graphic Insert a picture.

Send the message to several recipients.

When you send a message via the SMS network, your phone may display “SMS Sent”. This means the message has been sent to the SMS center which you have set in your SIM card. However, this does not imply that the message has been sent to its destination.

Inbox

This menu allows you to read the SMS messages which you have received. The messages are displayed in a list. When a message is displayed, press L to read it, then press L to access the following menu options:

Reply Reply to the sender.

Forward Forward the selected message.

Delete all Delete all messages in the Inbox.

Delete Delete a selected message.

Move to Archive

Call back Call the sender.

Store Number Save the sender’s number.

Move the selected message to

Archive folder.

Messages 13

+ 30 hidden pages

Philips CT9A9ZBLK, CT9A9ZWHT User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
